2AJIV-MF1705Creative T60

Creative T60 台灣RoHS信息 有關台灣RoHS，登陸creative.com/compliance/T60 點擊下載Creative T60 Taiwan RoHS Languages: 20+1125x5 = 625 180x4 = 720 PN: 03MF170500000 Rev A 使用产品前请阅读使用说明 Quick Start Guide Model No. / 型號 / 型号: MF1705 1. OVERVIEW R R L L Front Back a b c d Volume Knob Clear Dialog Button Surround Button Speaker / Headphones Switch Button Power / Source Button e Headphones / Headset Port g USB-C Port f Microphone Port h 3.5 mm AUX-in Port i Output to Left Speaker j DC Power Port 2. INTERCHANGEABLE AC PLUGS / SWITCHING POWER ADAPTERS CONTROLS Creative T60 features a power adapter with interchangeable AC plugs, suitable for use in multiple regions. Refer to the instructions below for more information. Note: The available interchangeable AC plugs are suitable for use in Singapore, Europe, UK, USA, Canada, Japan, Taiwan, China, Korea, Australia, and other regions using the same AC plugs. Replacing Interchangeable AC Plugs Available Interchangeable AC Plugs * For Singapore and Malaysia, only bundled EU AC Plug is suitable for use. * Interchangeable AC Plugs are bundled according to regions i) Place the AC plug on the power adapter, then push it down until you hear a click ii) Pull the power adapter’s clip down to release the AC plug from its attachment iii) To replace or reattach the AC plug, refer to the initial steps given 4 ii) UK / Hong Kong / Saudi Arabia / UAE v) Korea i) Singapore / EU / Malaysia iv) China iii) USA / Japan / Taiwan vi) Australia 4. MASTER RESET Master Reset is reserved for scenarios where users encounter problems such as Bluetooth pairing problems or other connectivity issues. Follow the steps below to reset your Creative T60: • Press and hold both Clear Dialog and Surround buttons for 5s • Creative T60 will return to USB mode once Master Reset is complete 3. CONNECTIVITY AND SOURCE SELECTION Note: Creative T60 does not feature a built-in microphone. A headset or an external microphone is required for chat features when connected to a supported platform. ButtonActionsLED Indicators Solid White LED – Surround On Off – Surround Off x1 Solid Red – Power Off 2s OFF x1 ON Solid White LED – Clear Dialog On Off – Clear Dialog Off x1 2s Speaker Mode Headphones / Headset Mode x1 Solid Purple – USB Audio Blinking Blue – Bluetooth Pairing Mode Solid Blue – Bluetooth Connected Solid Cyan – AUX-in USB Audio Bluetooth ® AUX-in RL Back USB-C to USB-A Converter 6. PRODUCT REGISTRATION 5. TECHNICAL SPECIFICATIONS 7. OTHER INFORMATION Power Output: 2 x 15W RMS Total System Power: Up to 30W RMS Peak Power: 60W SNR: ≥ 75 dB System Configuration: 2.0 System Frequency Range: 50–20,000 Hz Bluetooth Version: Bluetooth 5.0 Bluetooth Operating Frequency: 2402–2480 MHz Supported Bluetooth Profiles: A2DP (Wireless Stereo Bluetooth), HFP (Hands-Free Profile) Supported Codec: SBC Operating Range for Bluetooth Devices: Up to 10 meters (Measured in open space. Walls and structures may affect range of device) Operating Temperature Range: 0–40ºC Power Adapter: Input: 100–240V 50 / 60 Hz 0.8A Output: 18V 2A Power Adapter Model: NBS 30D180200D5 Note: Compliance marking are located at the bottom of this product. Please visit creative.com/compliance/T60 for the user guide, safety and regulatory information, ErP information where applicable. Visit support.creative.com to resolve and troubleshoot technical queries at Creative’s 24-hour self- help Knowledge Base. You can also find Customer Support Services and other helpful information here. Registering your product ensures you receive the most appropriate service and product support available. You can register your product at www.creative.com/register. Please note that your warranty rights are not dependent on registration. Warranty information is supplied with your product in a separate document. Please keep your Proof of Purchase for the duration of the Warranty period. Warranty Keep this document for future reference. © 2021 Creative Technology Ltd. All rights reserved. Creative, the Creative logo, Blaster logo and Sound Blaster are trademarks or registered trademarks of Creative Technology Ltd in the United States and/or other countries. The Bluetooth® word mark and logo are owned by the Bluetooth SIG, Inc. and any use of such marks by Creative Technology Ltd is under license. All other trademarks are the property of their respective owners and are hereby recognized as such. All specifications are subject to change without notice. Actual product may differ slightly from images shown. Use of this product is subject to a limited warranty. For details on the Creative Warranty period of your product, please visit https://www.creative.com/warranty Pour plus de détails sur la période de garantie Creative de votre produit, veuillez consulter https://www.creative. com/warranty Details zur Dauer der Creative-Garantie auf Ihr Produkt finden Sie unter https://www.creative.com/warranty Para obtener más información sobre el periodo de garantía de Creative referente a su producto, visite https://www. creative.com/warranty Per dettagli sul periodo di garanzia Creative del prodotto, visitare https://www.creative.com/warranty Ga naar https://www.creative.com/warranty voor bijzonderheden over de garantieperiode op uw Creative- product Para obter mais detalhes acerca do Período de garantia da Creative para o seu produto, visite o site https://www. creative.com/warranty For detaljer om Creative-garantiperioden for dit produkt, besøg venligst https://www.creative.com/warranty För detaljerad information om garantiperioden för din Creative-produkt, gå till https://www.creative.com/warranty For detaljer om Creative-garantiperioden for produktet ditt, vennligst besøk https://www.creative.com/warranty Lisätietoja tuotteesi Creative-takuujaksosta on osoitteessa https://www.creative.com/warranty Szczegóły dotyczące okresu gwarancji Creative dla Twojego produktu można znaleźć na stronie https://www.creative. com/warranty Podrobné informácie o lehote záruky od spoločnosti Creative na váš vý…

Text truncated - open the document above for the full version.

Agent Authorization Company: Creative Labs Pte. Ltd. Address: 31 International Business Park, #03-01, Singapore 609921 Product Name: Creative T60 Model Number(s): MF1705 Equipment Description: Creative T60 We authorize MiCOM Labs Inc., 575 Boulder Court, Pleasanton, California 94566, USA, to act on our behalf on all matters concerning the certification of above named equipment. We declare that MiCOM Labs Inc. is allowed to forward all information related to the approval and certification of equipment to the regulatory agencies as required and to discuss any issues concerning the approval application. Any and all acts carried out by MiCOM Labs on our behalf shall have the same effect as acts of our own. Signature: Date: 2021-04-06 Name: Toh Mary Title: Manager Company: Creative Labs Pte. Ltd.

CREATIVE LABS PTE. LTD. Date: 8 April 2021 CREATIVE LABS PTE. LTD. To: Federal Communications Commission, Authorization & Evaluation Division, 7435 Oakland Mills Road, Columbia, MD 21046 To Whom It May Concern: The CREATIVE LABS PTE. LTD. the undersigned, hereby authorizes Mr. Wu Xuewen from Shenzhen BALUN Technology Co., Ltd. to act on the behalf of the CREATIVE LABS PTE. LTD. solely in matters relating to the application for an FCC equipment authorization for FCC ID: 2AJIV-MF1705 including the signing of documents in connection with this Application. Necessary acts carried out by Shenzhen BALUN Technology Co., Ltd. in connection with the Application shall have the same effect as acts of the CREATIVE LABS PTE. LTD. The CREATIVE LABS PTE. LTD. also hereby certify that no party to this application is subject to a denial of benefits, including FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. Section 862. Yours Sincerely, _______ Toh Mary

CREATIVE LABS PTE. LTD. Date: 8 April 2021 CREATIVE LABS PTE. LTD. To: Federal Communications Commission, Authorization & Evaluation Division, 7435 Oakland Mills Road, Columbia, MD 21046 Re: CREATIVE LABS PTE. LTD. FCC ID: 2AJIV-MF1705 FCC Certification Confidentiality Request Gentlemen: This letter is to comply with 47 CFR 0.457 and 0.459 pertaining to confidentiality material. CREATIVE LABS PTE. LTD. requests that the following documents regarding this submission for FCC ID: 2AJIV-MF1705 be kept confidential: Exhibit Type File Name Block Diagram Block Diagram.pdf Schematics Schematics.pdf Operational Description Operational Description.pdf And below exhibit kept short-term confidential (180 days): External photos External photos.pdf Test setup photos test photo.pdf Internal photos Internal photos.pdf User manual User manual.pdf Those documents contain detailed system and equipment description and related information about the product which CREATIVE LABS PTE. LTD. considers to be confidential proprietary, a custom design and, otherwise, not releasable to the general public. Since this design is a basis form which future technological products will evolve, CREATIVE LABS PTE. LTD. considers this information would be of benefit to its competitors, and that the disclosure of the information in these documents would give competitors an unfair advantage in the market. Yours Sincerely, _____________ Toh Mary

Annex No.: BL-SZ2110601-AW 1 / 6 EUT EXTERNAL PHOTOS FRONT VIEW OF EUT REAR VIEW OF EUT Annex No.: BL-SZ2110601-AW 2 / 6 LEFT SIDE VIEW OF EUT RIGHT SIDE OF EUT Annex No.: BL-SZ2110601-AW 3 / 6 TOP VIEW OF EUT BOTTOM VIEW OF EUT Annex No.: BL-SZ2110601-AW 4 / 6 Accessory-Power Adapter CLOSE-UP Annex No.: BL-SZ2110601-AW 5 / 6 Accessory-TYPE-C Cable Accessory-AUX Cable Annex No.: BL-SZ2110601-AW 6 / 6 Accessory-USB Connector

PART DESCRIPTION: STICKER,MF1705 RATING LABEL PART NO: 01MF170500000 DRAWING NO: 01MF170500000 MODEL: MF1705 CD AB AB DO NOT SCALE All Dimensions in MM unless otherwise specified DRAWN MATERIAL COLOUR SEE NOTES 66 55 44 33 22 11 REVDESCRIPTIONAPPROVEDDATE REVISIONS PRINTING SEE NOTES TOOLINGEMBOSSENGRAVE FINISH TEXTURE REF DESIGNEDCHECKEDAPPROVED REV: A SHEET 1 1ISSUED Specifications: 1. Material Use : 3M (Scotch Mark) 7818 Matte Silver Polyester Film or equivalent. 2. Colour : 1 Colour (Black) 3. Size : 59mm (W) x 38.5mm (H) 4. Application on : Product 5. Orientation : Sheet form 6. Printing content should follow artwork provided. 7. Inner surface with adhesive: Hi-strength acrylic (0.025mm) Printing Side Permanent type adhesive 0.1 MM 59mm + 0 - 0.1 38.5mm + 0 - 0.1 产品名称 / 產品名稱: 蓝牙音箱 / 藍牙音箱 / Bluetooth динамик MODEL NO. / Модель / 型号 / 型號: MF1705 INPUT / Питание / 输入 / 輸入 : 18V 2A Made in China / Сделано в Китае / 原产地 / 原產地: 中国 Manufacturer / Производитель /生产者 / 生產者: CREATIVE LABS PTE. LTD. FCC ID:2AJIV-MF1705 CAN ICES-3 (B)/NMB-3(B) IC:20469-MF1705 Europe Office: Creative Labs (Europe) Ltd. Unit Q2, North Ring Business Park Santry, Dublin, D09 EV70, Ireland. T33724 ROHS xxx - xxxxxx R R-R-C2T-MF1705 CMIIT ID: XXXXXXXXXX XXXXXXXXXXXXXX This device complies with Part 15 of the FCC Rules. Operation is subject to the foll owing two conditions: [1] this device may not cause harmful interf erence, and [2] this device must accept any interf erence received, including interf erence that may cause undesired operation. Recess open area 60.60mm x 40.36mm Z571(R-NZ only) 主机后壳正面图 主机底盖 技术贴纸 主机装饰件正面图

Annex No.: BL-SZ2110601-AI 1 / 4 EUT INTERNAL PHOTOS EUT UNCOVER VIEW EUT UNCOVER VIEW Annex No.: BL-SZ2110601-AI 2 / 4 EUT UNCOVER VIEW EUT UNCOVER VIEW Annex No.: BL-SZ2110601-AI 3 / 4 MAIN BOARD TOP VIEW MAIN BOARD REAR VIEW PCB Antenna RF Chip Annex No.: BL-SZ2110601-AI 4 / 4 SECONDARY BOARD 1 TOP VIEW SECONDARY BOARD 1 REAR VIEW

RF Exposure Evaluation for FCC ID: 2AJIV-MF1705 Refer user manual this device is a Creative T60, and this device was designed used in Mobile devices that the minimum distance between human’s body is 20cm. Based on the 47CFR 2.1091, this device belongs to Mobile device. The definition of the category as following: Mobile Derives: CFR Title 47 §2.1091(b) (b) For purposes of this section, a mobile device is defined as a transmitting device designed to be used in other than fixed locations and to generally be used in such a way that a separation distance of at least 20 centimeters is normally maintained between the transmitter’s radiating structure(s) and the body of the user or nearby persons. FCC KDB 447498 D01 General RF Exposure Guidance v06 Limit Devices operating in standalone mobile exposure conditions may contain a single transmitter or multiple transmitters that do not transmit simultaneously. A minimum test separation distance ≥ 20 cm is required between the antenna and radiating structures of the device and nearby persons to apply mobile device exposure limits. The distance must be fully supported by the operating and installation configurations of the transmitter and its antenna(s), according to the source-based time-averaged maximum power requirements of § 2.1091(d)(2). In cases where cable losses or other attenuations are applied to determine compliance, the most conservative operating configurations and exposure conditions must be evaluated. The minimum test separation distance required for a device to comply with mobile exposure conditions must be clearly identified in the installation and operating instructions, for all installation and exposure conditions, to enable users and installers to comply with RF exposure requirements. For mobile devices that have the potential to operate in portable device exposure conditions, similar to the configurations described in § 2.1091(d)(4), a KDB inquiry is required to determine the SAR test requirements for demonstrating compliance. When the categorical exclusion provision of § 2.1091(c) applies, the minimum test separation distance may be estimated, when applicable, by simple calculations according to plane-wave equivalent conditions, to ensure the transmitter and its antenna(s) can operate in manners that meet or exceed the estimated distance. The source-based time-averaged maximum radiated power, according to the maximum antenna gain, must be applied to calculate the field strength and power density required to establish the minimum test separation distance. When the estimated test separation distance becomes overly conservative and does not support compliance, MPE measurement or computational modeling may be used to determine the required minimum separation distance. According to FCC Part 1.1307, systems operating under the provisions of this section shall be operated in a manner the ensures that the public is not exposed to radio frequency energy level in excess of the commission’s guidelines. Limits for General Population/ Uncontrolled Exposure Frequency Range (MHz) Electric Field Strength(E)(V/m) Magnetic Field Strength (H)(A/m) Power Density (S)(mW/cm 2 ) 0.3-1.34 614 1.63 (100)* 1.34-30 824/f 2.19/f (180/f2)* 30-300 27.5 0.073 0.2 300-1500 f/1500 1500-100,000 1.0 MPE calculation formula Where: S = power density P = output power (mW) G = power gain of the antenna in the direction of interest relative to an isotropic radiator R = Separation distance between radiator and human body (cm) Test data BLUETOOTH Mode BR+EDR GFSK π/4-DQPSK 8-DPSK Peak Power (dBm) 1.17 2.92 3.21 Note: This report listed the worst case peak power value, please refer to RF test report for more details. Turn-up power Mode Range (dBm) Bluetooth 1.00-3.50 Test result Evolution mode Maximum peak output power （dBm） Antenna Gain (typical) (dBi): Total Power (mw) Distance (cm) Limit of Power Density (mW/cm²) Power Density (mW/cm²) Verdict Bluetooth 3.50 3.58 5.11 20 1 0.0010 Pass Note: 1. The Creative T60 work frequency range used is 2400 MHz ~ 2483.5 MHz, the result close to the limit by the above formula, 2. More power list please refer to RF test report. Conclusion: RF exposure Evaluation Results: Compliance

Report No.: BL-SZ2110601-601 2 / 75 Revision History Version Issue Date Revisions Content Rev. 01 Apr. 07, 2021 Initial Issue TABLE OF CONTENTS 1 ADMINISTRATIVE DATA (GENERAL INFORMATION) .......................................................................... 5 1.1 Identification of the Testing Laboratory ....................................................................................... 5 1.2 Identification of the Responsible Testing Location ...................................................................... 5 1.3 Laboratory Condition ................................................................................................................... 5 1.4 Announce .................................................................................................................................... 5 2 PRODUCT INFORMATION ...................................................................................................................... 6 2.1 Applicant Information ................................................................................................................... 6 2.2 Manufacturer Information ............................................................................................................ 6 2.3 Factory Information ..................................................................................................................... 6 2.4 General Description for Equipment under Test (EUT) ................................................................ 6 2.5 Technical Information .................................................................................................................. 7 2.6 Additional Instructions ................................................................................................................. 8 3 SUMMARY OF TEST RESULTS .............................................................................................................. 9 3.1 Test Standards ............................................................................................................................ 9 3.2 Verdict ....................................................................................................................................... 10 4 GENERAL TEST CONFIGURATIONS ................................................................................................... 11 4.1 Test Environments .................................................................................................................... 11 4.2 Test Equipment List ................................................................................................................... 11 4.3 Measurement Uncertainty ......................................................................................................... 13 4.4 Description of Test Setup .......................................................................................................... 14 4.4.1 For Antenna Port Test ............................................................................................................... 14 4.4.2 For AC Power Supply Port Test ................................................................................................ 14 4.4.3 For Radiated Test (Below 30 MHz) ........................................................................................... 15 4.4.4 For Radiated Test (30 MHz-1 GHz) .......................................................................................... 15 4.4.5 For Radiated Test (Above 1 GHz) ............................................................................................. 16 4.5 Measurement Results Explanation Example ............................................................................. 17 4.5.1 For conducted test items: .......................................................................................................... 17 Report No.: BL-SZ2110601-601 3 / 75 5 TEST ITEMS ........................................................................................................................................... 18 5.1 Antenna Requirements .............................................................................................................. 18 5.1.1 Relevant Standards ................................................................................................................... 18 5.1.2 Antenna Anti-Replacement Construction .................................................................................. 18 5.1.3 Antenna Gain ............................................................................................................................ 18 5.2 Frequency Hopping Systems .................................................................................................... 19 5.2.1 Relevant Standards ................................................................................................................... 19 5.2.2 Description of the systems ........................................................................................................ 19 5.3 Number of Hopping Frequencies .............................................................................................. 21 5.3.1 Limit ........................................................................................................................................... 21 5.3.2 Test Setup ................................................................................................................................. 21 5.3.3 Test Procedure .......................................................................................................................... 21 5.3.4 Test Result ................................................................................................................................ 21 5.4 Peak Output Power and E.I.R.P ................................................................................................ 22 5.4.1 Test Limit ..................................................................…

Text truncated - open the document above for the full version.

Annex No.: BL-SZ2110601-AR 1 / 4 TEST SETUP PHOTOS 1 Radiated Test Photo Below 30MHz 30MHz-1GHz Annex No.: BL-SZ2110601-AR 2 / 4 Close-up Above 1GHz Annex No.: BL-SZ2110601-AR 3 / 4 Close-up 2 Conducted Test Photo Conducted Test-BT Annex No.: BL-SZ2110601-AR 4 / 4 3 Conducted Emissions Test Photo 1 Test Photo 2
