2AJMN-S661LPMobile Phone

Vision 3 User Manual Explosion diagram specification 1 CTP LCM ASSEMBLY 2 FRONT SHELL ASSEMBLY 3 F CAM RUBBER 4 FRONT CAMERA 5 RECEIVER 6 REC CON FB 7 F CAM COP FOIL 8 MAIN PCB 9 LCM WATERPROOF RUBBER 10 BAT FPC CONN RUBBER 11 R MAIN CAM CON FOAMS 12 R CAM CON FB 8W 13 FM SUPPORT MYLAR 14 FM CON FOAMS 15 FM 16 FP SEAL SILICONE LOOP 17 CAM FF 8M 18 CAM FF 8W 19 R VICE CAM RUBBER 20 UP FRAME ASM 21 UP FRAMEWATERPROOF MYLAR 22 R MAIN CAM LENS 23 R VICE CAM LENS 24 R VICE CAM LENS2 25 MC SCREW SILVER GIUE 26 CARD HOLDER 27 BAT COVER ASM 28 R CAMDECO ASM 29 MACHINE SCREW BLACK 30 SPK FRAMEWATERPROOF MYLAR 31 USB RUBBER 32 EAR PHONE RUBBER 33 SPK FRAME ASM 34 MOTOR 35 COAXIAL CABLE 36 SPK 37 PCBA SUB 38 FPC SIDE KEY 39 BAT Know your phone 1. Front camera 2. Volume + key 3. Volume - key 4. Power key SIM/SD card installation 1. Power off mobile. 2. Refer to the following picture for SIM / SD card installation. Charging the phone You can charge your device using a charger or by connecting it to the computer using a USB cable (comes with the phone). 1. Please remind the front and back of the plug. 2 2 . . Use only itel charger and cables. Other chargers or cables may damage the device. This will invalidate your phone warranty. FCC Caution Labelling requirements. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference. (2) This device must accept any interference received, including interference that may cause undesired operation. Information to user. Any changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. Information to the user. Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: -Reorient or relocate the receiving antenna. -Increase the separation between the equipment and receiver. -Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. -Consult the dealer or an experienced radio/TV technician for help. Specific Absorption Rate (SAR) information: This mobile phone meets the government's requirements for exposure to radio waves. The guidelines are based on standards that were developed by independent scientific organizations through periodic and thorough evaluation of scientific studies. The standards include a substantial safety margin designed to assure the safety of all persons regardless of age or health. FCC RF Exposure Information and Statement The SAR limit of USA (FCC) is 1.6 W/kg averaged over one gram of tissue. Device types: S661LP (FCC ID: 2AJMN-S661LP) has also been tested against this SAR limit. The highest SAR value reported under this standard during product certification for use at the ear is 1.16 W/kg and when properly worn on the body is 0.58 W/kg. Body-worn Operation This device was tested for typical body-worn operations. To comply with RF exposure requirements, a minimum separation distance of 1.0 cm must be maintained between the user’s body and the handset, including the antenna. Third-party belt-clips, holsters, and similar accessories used by this device should not contain any metallic components. Body-worn accessories that do not meet these requirements may not comply with RF exposure requirements and should be avoided. Use only the supplied or an approved antenna. Operating System：Android TM Android is a trademark of Google LLC.

ITEL MOBILE LIMITED Address: FLAT N 16/F BLOCK B UNIVERSAL INDUSTRIAL CENTRE 19-25 SHAN MEI STREET FOTAN NT Hong Kong Tel.: +86-0755-61803856 E-mail: [email protected] Date: 2022-11-12 FEDERAL COMMUNICATIONS COMMISSIONS Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 Dear Sir/Madam, Our product Mobile Phone, model: S661LP, FCC ID: 2AJMN-S661LP, for marketing purpose, this product only supports GSM850/PCS1900, WCDMA B2/B4/B5, LTE B2/B4/B5/B7/B12/B17/B38/B41(2535-2655MHz)/B66, Bluetooth, BLE 1M, 2.4G Wi-Fi(2412-2472MHz, 802.11 b/g/n20 mode). The other function, bands and modes was disabled to use by manufacture in the software, the end user has no capability to activate it. Signature: Yiting Luo Certified Engineer

ITEL MOBILE LIMITED Address: FLAT N 16/F BLOCK B UNIVERSAL INDUSTRIAL CENTRE 19-25 SHAN MEI STREET FOTAN NT Hong Kong Tel.: +86-0755-33640189 E-mail:[email protected] QA-FR-170-B FCC Authorization Date: 2022-11-12 FEDERAL COMMUNICATIONS COMMISSIONS Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 Subject: Agent Authorization To whom it may concern: We, ITEL MOBILE LIMITED hereby authorizes Shenzhen Accurate Technology Co., Ltd. to act on its behalf in all matters relating to application for Equipment authorization, including the signing of all documents relating to these matters. All acts carried out by Shenzhen Accurate Technology Co., Ltd. on our behalf shall have the same effect as our own action. We, the undersigned, hereby certify that we are not subject to a denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 862. This authorization is valid until further written notice from the applicant. Sincerely Yours, Signature YitingLuo CertifiedEngineer Tel.: +86-0755-61803856

ITEL MOBILE LIMITED Address: FLAT N 16/F BLOCK B UNIVERSAL INDUSTRIAL CENTRE 19-25 SHAN MEI STREET FOTAN NT Hong Kong Tel.: +86-0755-33640189 E-mail:[email protected] FCC Confidential Authorization Date: 2022-11-12 FEDERAL COMMUNICATIONS COMMISSIONS Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 Subject: Confidentiality Request regarding application for certification of FCC ID: 2AJMN-S661LP In accordance with Sections 0.457 and 0.459 of the Commission’s Rules, ITEL MOBILE LIMITED hereby requests long-term confidential treatment of information accompanying this application as outlined below: Block Diagram Schematics Operation Description Part list/Tune up Procedure (for licensed device) As well as short-term confidential treatment of information accompanying this application for a period of 180 days after grant is issued as outlined below: Internal Photos User’s Manual External Photos Test Set-up Photos The above materials contain proprietary and confidential information not customarily released to the public. The public disclosure of these materials provides unjustified benefits to its competitors in the market. Sincerely Yours, Signature YitingLuo CertifiedEngineer Tel.: +86-0755-61803856

Shenzhen Accurate Technology Co., Ltd. FCC ID: 2AJMN-S661LP External Photos Page 1 of 6 Shenzhen Accurate Technology Co., Ltd. FCC ID: 2AJMN-S661LP External Photos Page 2 of 6 Shenzhen Accurate Technology Co., Ltd. FCC ID: 2AJMN-S661LP External Photos Page 3 of 6 Shenzhen Accurate Technology Co., Ltd. FCC ID: 2AJMN-S661LP External Photos Page 4 of 6 Shenzhen Accurate Technology Co., Ltd. FCC ID: 2AJMN-S661LP External Photos Page 5 of 6 Shenzhen Accurate Technology Co., Ltd. FCC ID: 2AJMN-S661LP External Photos Page 6 of 6

Shenzhen Accurate Technology Co., Ltd. Project No.: RA221026-49391E-RF LABEL AND LOCATION Page 1 of 1 FCC ID Label FCC ID Label Location Information The label shown shall be permanently affixed at a conspicuous location on the device and be readily visible to the user at the time purchase (Labeling requirements per 2.925)

Shenzhen Accurate Technology Co., Ltd. FCC ID: 2AJMN-S661LP Internal Photos Page 1 of 8 Internal photos Shenzhen Accurate Technology Co., Ltd. FCC ID: 2AJMN-S661LP Internal Photos Page 2 of 8 Shenzhen Accurate Technology Co., Ltd. FCC ID: 2AJMN-S661LP Internal Photos Page 3 of 8 Shenzhen Accurate Technology Co., Ltd. FCC ID: 2AJMN-S661LP Internal Photos Page 4 of 8 Shenzhen Accurate Technology Co., Ltd. FCC ID: 2AJMN-S661LP Internal Photos Page 5 of 8 Shenzhen Accurate Technology Co., Ltd. FCC ID: 2AJMN-S661LP Internal Photos Page 6 of 8 Shenzhen Accurate Technology Co., Ltd. FCC ID: 2AJMN-S661LP Internal Photos Page 7 of 8 Antenna-AUX Shenzhen Accurate Technology Co., Ltd. FCC ID: 2AJMN-S661LP Internal Photos Page 8 of 8 Antenna-MIAN ant+2.4G WiFi +BT+BLE

Shenzhen Accurate Technology Co., Ltd. Report No.: RA221026-49391E-SA Page 1 of 45 APPENDIX C PROBE CALIBRATION CERTIFICATES Shenzhen Accurate Technology Co., Ltd. Report No.: RA221026-49391E-SA Page 2 of 45 Shenzhen Accurate Technology Co., Ltd. Report No.: RA221026-49391E-SA Page 3 of 45 Shenzhen Accurate Technology Co., Ltd. Report No.: RA221026-49391E-SA Page 4 of 45 Shenzhen Accurate Technology Co., Ltd. Report No.: RA221026-49391E-SA Page 5 of 45 Shenzhen Accurate Technology Co., Ltd. Report No.: RA221026-49391E-SA Page 6 of 45 Shenzhen Accurate Technology Co., Ltd. Report No.: RA221026-49391E-SA Page 7 of 45 Shenzhen Accurate Technology Co., Ltd. Report No.: RA221026-49391E-SA Page 8 of 45 Shenzhen Accurate Technology Co., Ltd. Report No.: RA221026-49391E-SA Page 9 of 45 Shenzhen Accurate Technology Co., Ltd. Report No.: RA221026-49391E-SA Page 10 of 45 APPENDIX D DIPOLE CALIBRATION CERTIFICATES Shenzhen Accurate Technology Co., Ltd. Report No.: RA221026-49391E-SA Page 11 of 45 Shenzhen Accurate Technology Co., Ltd. Report No.: RA221026-49391E-SA Page 12 of 45 Shenzhen Accurate Technology Co., Ltd. Report No.: RA221026-49391E-SA Page 13 of 45 Shenzhen Accurate Technology Co., Ltd. Report No.: RA221026-49391E-SA Page 14 of 45 Shenzhen Accurate Technology Co., Ltd. Report No.: RA221026-49391E-SA Page 15 of 45 Shenzhen Accurate Technology Co., Ltd. Report No.: RA221026-49391E-SA Page 16 of 45 Shenzhen Accurate Technology Co., Ltd. Report No.: RA221026-49391E-SA Page 17 of 45 Shenzhen Accurate Technology Co., Ltd. Report No.: RA221026-49391E-SA Page 18 of 45 Shenzhen Accurate Technology Co., Ltd. Report No.: RA221026-49391E-SA Page 19 of 45 Shenzhen Accurate Technology Co., Ltd. Report No.: RA221026-49391E-SA Page 20 of 45 Shenzhen Accurate Technology Co., Ltd. Report No.: RA221026-49391E-SA Page 21 of 45 Shenzhen Accurate Technology Co., Ltd. Report No.: RA221026-49391E-SA Page 22 of 45 Shenzhen Accurate Technology Co., Ltd. Report No.: RA221026-49391E-SA Page 23 of 45 Shenzhen Accurate Technology Co., Ltd. Report No.: RA221026-49391E-SA Page 24 of 45 Shenzhen Accurate Technology Co., Ltd. Report No.: RA221026-49391E-SA Page 25 of 45 Shenzhen Accurate Technology Co., Ltd. Report No.: RA221026-49391E-SA Page 26 of 45 Shenzhen Accurate Technology Co., Ltd. Report No.: RA221026-49391E-SA Page 27 of 45 Shenzhen Accurate Technology Co., Ltd. Report No.: RA221026-49391E-SA Page 28 of 45 Shenzhen Accurate Technology Co., Ltd. Report No.: RA221026-49391E-SA Page 29 of 45 Shenzhen Accurate Technology Co., Ltd. Report No.: RA221026-49391E-SA Page 30 of 45 Shenzhen Accurate Technology Co., Ltd. Report No.: RA221026-49391E-SA Page 31 of 45 Shenzhen Accurate Technology Co., Ltd. Report No.: RA221026-49391E-SA Page 32 of 45 Shenzhen Accurate Technology Co., Ltd. Report No.: RA221026-49391E-SA Page 33 of 45 Shenzhen Accurate Technology Co., Ltd. Report No.: RA221026-49391E-SA Page 34 of 45 Shenzhen Accurate Technology Co., Ltd. Report No.: RA221026-49391E-SA Page 35 of 45 Shenzhen Accurate Technology Co., Ltd. Report No.: RA221026-49391E-SA Page 36 of 45 Shenzhen Accurate Technology Co., Ltd. Report No.: RA221026-49391E-SA Page 37 of 45 Shenzhen Accurate Technology Co., Ltd. Report No.: RA221026-49391E-SA Page 38 of 45 Shenzhen Accurate Technology Co., Ltd. Report No.: RA221026-49391E-SA Page 39 of 45 Shenzhen Accurate Technology Co., Ltd. Report No.: RA221026-49391E-SA Page 40 of 45 Shenzhen Accurate Technology Co., Ltd. Report No.: RA221026-49391E-SA Page 41 of 45 Shenzhen Accurate Technology Co., Ltd. Report No.: RA221026-49391E-SA Page 42 of 45 Shenzhen Accurate Technology Co., Ltd. Report No.: RA221026-49391E-SA Page 43 of 45 Shenzhen Accurate Technology Co., Ltd. Report No.: RA221026-49391E-SA Page 44 of 45 Shenzhen Accurate Technology Co., Ltd. Report No.: RA221026-49391E-SA Page 45 of 45

Note: This report may contain data that are ★ not covered by the A2LA accreditation and are marked with an asterisk “ ”. Shenzhen Accurate Technology Co., Ltd. is not responsible for the authenticity of any test data provided by the applicant. Data included from the applicant that may affect test results are marked with an asterisk ’*’. Customer model name, addresses, names, trademarks etc. are not considered data. This report cannot be reproduced except in full, without prior written approval of the Company. Unless otherwise stated the results shown in this test report refer only to the sample(s) tested. This report is valid only with a valid digital signature. The digital signature may be available only under the Adobe software above version 7.0. Shenzhen Accurate Technology Co., Ltd. 1/F., Building A, Changyuan New Material Port, Science & Industry Park, Nanshan District, Shenzhen, Guangdong, P.R. China Tel: +86 755-26503290 Fax: +86 755-26503396 Web: www.atc-lab.com Version 801: 2021-11-09 Page 1 of 87 FCC SAR 4G TEST REPORT Applicant Name : ITEL MOBILE LIMITED Address : FLAT N 16/F BLOCK B UNIVERSAL INDUSTRIAL CENTRE 19-25 SHAN MEI STREET FOTAN NT Hong Kong Report Number : RA221026-49391E-SA FCC ID: 2AJMN-S661LP Test Standard (s) FCC Part 2.1093 Sample Description Product Type: Mobile Phone Model No.: S661LP Trade Mark: itel Serial Number: RA221026-49391E-SA-S1 Date Received: 2022/10/26 Date of Test: 2022/11/09~2022/11/14 Report Date: 2022/11/18 Test Result: Pass* * In the configuration tested, the EUT complied with the standards above. Prepared and Checked By: Approved By: Lance Li Candy Li EMC Engineer EMC Engineer Shenzhen Accurate Technology Co., Ltd. Report No.: RA221026-49391E-SA Version 801: 2021-11-09 Page 2 of 87 FCC SAR 4G Attestation of Test Results MODE Max. SAR Level(s) Reported(W/kg) Limit (W/kg) GSM 850 1g Head SAR 0.60 1.6 1g Body SAR 0.18 PCS 1900 1g Head SAR 1.09 1g Body SAR 0.57 WCDMA Band 2 1g Head SAR 1.16 1g Body SAR 0.51 WCDMA Band 4 1g Head SAR 0.95 1g Body SAR 0.40 WCDMA Band 5 1g Head SAR 0.57 1g Body SAR 0.22 LTE Band 2 1g Head SAR 0.66 1g Body SAR 0.49 LTE Band 5 1g Head SAR 0.46 1g Body SAR 0.23 LTE Band 7 1g Head SAR 0.67 1g Body SAR 0.57 LTE Band 12&17 1g Head SAR 0.10 1g Body SAR 0.02 LTE Band 41&38 1g Head SAR 0.80 1g Body SAR 0.58 LTE Band 66&4 1g Head SAR 0.83 1g Body SAR 0.48 2.4G Wi-Fi 1g Head SAR 0.42 1g Body SAR 0.26 Bluetooth 1g Head SAR 0.01 1g Body SAR 0.02 Simultaneous 1g Head SAR 1.58 1g Body SAR 0.84 1g Body SAR 0.84(Hotspot) Applicable Standards FCC 47 CFR part 2.1093 Radiofrequency radiation exposure evaluation: portable devices RF Exposure Procedures: TCB Workshop April 2015(Overlapping LTE Bands) IEEE1528:2013 IEEE Recommended Practice for Determining the Peak Spatial-Average Specific Absorption Rate (SAR) in the Human Head from Wireless Communications Devices: Measurement Techniques IEC 62209-1:2016 Measurement procedure for the assessment of specific absorption rate of human exposure to radio frequency fields from hand-held and body-mounted wireless communication devices – Part 1: Devices used next to the ear (Frequency range of 300 MHz to 6 GHz) KDB procedures KDB 447498 D04 Interim General RF Exposure Guidance v01 KDB 648474 D04 Handset SAR v01r03 KDB 865664 D01 SAR Measurement 100 MHz to 6 GHz v01r04 KDB 865664 D02 RF Exposure Reporting v01r02 KDB 941225 D01 3G SAR Procedures v03r01 KDB 941225 D05 SAR for LTE Devices v02r05 KDB 941225 D06 Hotspot Mode v02r01 Shenzhen Accurate Technology Co., Ltd. Report No.: RA221026-49391E-SA Version 801: 2021-11-09 Page 3 of 87 FCC SAR 4G KDB 248227 D01 802 11 Wi-Fi SAR v02r02 Note: This wireless device has been shown to be capable of compliance for localized specific absorption rate (SAR) for General Population/Uncontrolled Exposure limits specified in FCC 47 CFR part 2.1093 and has been tested in accordance with the measurement procedures specified in IEEE 1528-2013 and RF exposure KDB procedures. The results and statements contained in this report pertain only to the device(s) evaluated. Shenzhen Accurate Technology Co., Ltd. Report No.: RA221026-49391E-SA Version 801: 2021-11-09 Page 4 of 87 FCC SAR 4G TABLE OF CONTENTS DOCUMENT REVISION HISTORY ......................................................................................................................... 5 EUT DESCRIPTION ................................................................................................................................................... 6 TECHNICAL SPECIFICATION ............................................................................................................................................. 6 REFERENCE, STANDARDS, AND GUIDELINES ................................................................................................. 7 SAR LIMITS ..................................................................................................................................................................... 8 FACILITIES ................................................................................................................................................................. 9 DESCRIPTION OF TEST SYSTEM ........................................................................................................................ 10 EQUIPMENT LIST AND CALIBRATION ............................................................................................................. 14 EQUIPMENTS LIST & CALIBRATION INFORMATION ........................................................................................................ 15 SAR MEASUREMENT SYSTEM VERIFICATION ............................................................................................. 16 LIQUID VERIFICATION ................................................................................................................................................... 16 SYSTEM ACCURACY VERIFICATION ....................................................…

Text truncated - open the document above for the full version.

Shenzhen Test Plot 1 DUT: Mob Communi c Medium pa Phantom s DASY5 C o • P • • E • P • M Area Sca n Maximum Zoom Sc a Reference Peak SAR SAR(1 g) = Maximum Accurate Tech 1#: GSM 850 bile Phone; T cation System arameters use ection: Left S onfiguration: Probe: EX3D Senso r-Surfac Electronics: D Phantom: Twi Measurement n (8x10x1): M value of SAR an (5x5x7)/Cu Value = 21.50 (extrapolated = 0.535 W/kg value of SAR 0 dB = 0. hnology Co., L 0_Head Left C Type: S661LP m: Generic GSM d: f = 836.6 M ection V4 - SN7441 ce: 4mm (Mec DAE4 SN1211 in SAM; Type t SW: DASY5 Measurement g R (interpolated ube 0: Measur 0 V/m; Power d) = 0.926 W/k g; SAR(10 g) R (measured) = .551 W/kg = - Ltd. Cheek_Middl P; Serial: RA M (0); Freque MHz; σ = 0.94 ; ConvF(10.04 chanical Surfa 1;Calibrated: 2 e: QD000P40C 52, Version 52 grid: dx=15mm d) = 0.598 W/k rement grid: d r Drift = -0.13 kg = 0.341 W/k g = 0.551 W/kg -2.59 dB dBW Page 1 of 1 le A221026-4939 ency: 836.6 M 43 S/m; ε r = 41 4, 10.04, 10.0 ace Detection) 2022/03/01 CD; Serial: TP 2.10 (4); SEMC m, dy=15mm kg dx=8mm, dy=8 3 dB g g W/kg 66 1E-SA-S1; MHz;Duty Cyc 1.603; ρ = 100 04) @836.6 M ) P:1744 CAD X Versio 8mm, dz=5mm Report No le: 1:8 00 kg/m 3 ; MHz; Calibrate on 14.6.12 (75 m o.: RA221026-4 ed: 2022/5/16; 501) 49391E-SA Shenzhen Test Plot 2 DUT: Mob Communi c Medium pa Phantom s DASY5 C o • P • • E • P • M Area Sca n Maximum Zoom Sc a Reference Peak SAR SAR(1 g) = Maximum Accurate Tech 2#: GSM 850 bile Phone; T cation System arameters use ection: Left S onfiguration: Probe: EX3D Senso r-Surfac Electronics: D Phantom: Twi Measurement n (8x10x1): M value of SAR an (5x5x7)/Cu Value = 19.1 (ex trapolated = 0.467 W/kg value of SAR 0 dB = 0. hnology Co., L 0_Head Left T Type: S661LP m: Generic GSM d: f = 836.6 M ection V4 - SN7441 ce: 4mm (Mec DAE4 SN1211 in SAM; Type t SW: DASY5 Measurement g R (interpolated ube 0: Measur 1 V/m; Power d) = 0.856 W/k g; SAR(10 g) R (measured) = .503 W/kg = - Ltd. Tilt_Middle P; Serial: RA M (0); Freque MHz; σ = 0.94 ; ConvF(10.04 chanical Surfa 1;Calibrated: 2 e: QD000P40C 52, Version 52 grid: dx=15mm d) = 0.531 W/k rement grid: d r Drift = -0.13 kg = 0.269 W/k g = 0.503 W/kg -2.98 dB dBW Page 2 of 1 A221026-4939 ency: 836.6 M 43 S/m; ε r = 41 4, 10.04, 10.0 ace Detection) 2022/03/01 CD; Serial: TP 2.10 (4); SEMC m, dy=15mm kg dx=8mm, dy=8 3 dB g g W/kg 66 1E-SA-S1; MHz;Duty Cyc 1.603; ρ = 100 04) @836.6 M ) P:1744 CAD X Versio 8mm, dz=5mm Report No le: 1:8 00 kg/m 3 ; MHz; Calibrate on 14.6.12 (75 m o.: RA221026-4 ed: 2022/5/16; 501) 49391E-SA Shenzhen Test Plot 3 DUT: Mob Communi c Medium pa Phantom s DASY5 C o • P • • E • P • M Area Sca n Maximum Zoom Sc a Reference Peak SAR SAR(1 g) = Maximum Accurate Tech 3#: GSM 850 bile Phone; T cation System arameters use ection: Right onfiguration: Probe: EX3D Senso r-Surfac Electronics: D Phantom: Twi Measurement n (8x10x1): M value of SAR an (5x5x7)/Cu Value = 20.32 (extrapolated = 0.361 W/kg value of SAR 0 dB = 0. hnology Co., L 0_Head Right Type: S661LP m: Generic GSM d: f = 836.6 M Section V4 - SN7441 ce: 4mm (Mec DAE4 SN1211 in SAM; Type t SW: DASY5 Measurement g R (interpolated ube 0: Measur 2 V/m; Power d) = 0.556 W/k g; SAR(10 g) R (measured) = .383 W/kg = - Ltd. t Cheek_Mid P; Serial: RA M (0); Freque MHz; σ = 0.94 ; ConvF(10.04 chanical Surfa 1;Calibrated: 2 e: QD000P40C 52, Version 52 grid: dx=15mm d) = 0.383 W/k rement grid: d r Drift = 0.18 kg = 0.234 W/k g = 0.383 W/kg -4.17 dB dBW Page 3 of 1 dle A221026-4939 ency: 836.6 M 43 S/m; ε r = 41 4, 10.04, 10.0 ace Detection) 2022/03/01 CD; Serial: TP 2.10 (4); SEMC m, dy=15mm kg dx=8mm, dy=8 dB g g W/kg 66 1E-SA-S1; MHz;Duty Cyc 1.603; ρ = 100 04) @836.6 M ) P:1744 CAD X Versio 8mm, dz=5mm Report No le: 1:8 00 kg/m 3 ; MHz; Calibrate on 14.6.12 (75 m o.: RA221026-4 ed: 2022/5/16; 501) 49391E-SA Shenzhen Test Plot 4 DUT: Mob Communi c Medium pa Phantom s DASY5 C o • P • • E • P • M Area Sca n Maximum Zoom Sc a Reference Peak SAR SAR(1 g) = Maximum Accurate Tech 4#: GSM 850 bile Phone; T cation System arameters use ection: Right onfiguration: Probe: EX3D Senso r-Surfac Electronics: D Phantom: Twi Measurement n (8x10x1): M value of SAR an (5x5x7)/Cu Value = 17.46 (extrapolated = 0.296 W/kg value of SAR 0 dB = 0. hnology Co., L 0_Head Right Type: S661LP m: Generic GSM d: f = 836.6 M Section V4 - SN7441 ce: 4mm (Mec DAE4 SN1211 in SAM; Type t SW: DASY5 Measurement g R (interpolated ube 0: Measur 6 V/m; Power d) = 0.472 W/k g; SAR(10 g) R (measured) = .322 W/kg = - Ltd. t Tilt_Middle P; Serial: RA M (0); Freque MHz; σ = 0.94 ; ConvF(10.04 chanical Surfa 1;Calibrated: 2 e: QD000P40C 52, Version 52 grid: dx=15mm d) = 0.289 W/k rement grid: d r Drift = -0.02 kg = 0.181 W/k g = 0.322 W/kg -4.92 dB dBW Page 4 of 1 e A221026-4939 ency: 836.6 M 43 S/m; ε r = 41 4, 10.04, 10.0 ace Detection) 2022/03/01 CD; Serial: TP 2.10 (4); SEMC m, dy=15mm kg dx=8mm, dy=8 2 dB g g W/kg 66 1E-SA-S1; MHz;Duty Cyc 1.603; ρ = 100 04) @836.6 M ) P:1744 CAD X Versio 8mm, dz=5mm Report No le: 1:8 00 kg/m 3 ; MHz; Calibrate on 14.6.12 (75 m o.: RA221026-4 ed: 2022/5/16; 501) 49391E-SA Shenzhen Test Plot 5 DUT: Mob Communi c Medium pa Phantom s DASY5 C o • P • • E • P • M Area Sca n Maximum Zoom Sc a Reference Peak SAR SAR(1 g) = Maximum Accurate Tech 5#: GSM 850 bile Phone; T cation System arameters use ection: Flat S e onfiguration: Probe: EX3D Senso r-Surfac Electronics: D Phantom: Twi Measurement n (8x14x1): M value of SAR an (5x5x7)/Cu Value = 13.10 (extrapolated = 0.175 W/kg value of SAR 0 dB = 0. hnology Co., L 0_Body Worn Type: S661LP m: Generic GSM d: f = 836.6 M ection V4 - SN7441 ce: 4mm (Mec DAE4 SN1211 in SAM; Type t SW: DASY5 Measurement g R (interpolated ube 0: Measur 0 V/m; Power d) = 0.286 W/k g; SAR(10 g) R (measured) = .189 W/kg = - Ltd. n Back_Midd P; Serial: RA M (0); Freque MHz; σ = 0.94 ; ConvF(10.04 chanical Surfa 1;Calibrated: 2 e: QD000P40C 52, Version 52 grid: dx=15mm d) = 0.180 W/k rement grid: d r Drift = -0.05 kg = 0.107 W/k …

Text truncated - open the document above for the full version.

Not e: This report may Shenzhen Accu affect testresults This report can n the sample(s) tes Version 2: 2021 Applica Addres Report FCC ID Te s t S t FCC PA Sampl e Produc Model Multip l Trade M Date R Report Test R e * In th e Prepa r Nick F a EMC E contain data that a rate Technology C o are marked with an not be reproduced e sted. This report is v 1/F., Building 1-11-09 ant Name : ss : Number : : tandard (s) ART 27; FCC e Descript ct Type: No.: le Model(s Mark: eceived: Date: esult: e configura red and Ch ang nginee r re not covered by t o., Ltd. is not respo n asterisk ’*’. Custo except in full, witho valid only with a va A, Changyuan Ne w Tel: +86 755- : ) C PART 22H tion ) No.: ation tested hecked By: the A2LA accreditat onsible for the authe mer model name, a ut prior written app lid digital signatur e Shenzhen A w Material Port, Sci -26503290 Page 1 o TES ITEL MOB FLAT N 16 SHAN ME RA221026 2AJMN-S H; FCC PAR Mobile Ph S661LP N/A itel 2022/10 / 2022/11/ Pass* d, the EUT : tion and are marke enticity of any test d addresses, names, roval of the Comp a e. The digital signatu Accurate Tech ience & Industry Pa Fax: +86 755-265 of 142 TREP BILE LIMITE 6/F BLOCK EI STREET F 6-49391E-R 661LP RT 24E hone /26 /23 complied d with an asterisk “ data provided by th trademarks etc. a r any. Unless otherwi ure may be availab nology Co., L ark, Nanshan Distri 503396 Web POR ED KB UNIVER FOTAN NT RF-00C with the st Approv Cand EMC E ★ “”. e applicant. Data i n re not considered d ise stated the result ble only under the A Ltd. ct, Shenzhen, Gua b: www.atc-lab.com RT RSAL INDUS Hong Kon tandards a ved By: dy Li Engineer ncluded from the ap ata. ts shown in this tes Adobe software abo ngdong, P.R. China m FCC -2G,3G,4 STRIAL CEN ng bove. pplicant that may st report refer only t ove version 7.0. a G NTRE 19-2 to 5 Shenzhen Accurate Technology Co., Ltd. Report No.: RA221026-49391E-RF-00C Version 2: 2021-11-09 Page 2 of 142 FCC -2G,3G,4G TABLE OF CONTENTS GENERAL INFORMATION ....................................................................................................................................... 3 PRODUCT DESCRIPTION FOR EQUIPMENT UNDER TEST (EUT) ..................................................................................... 3 OBJECTIVE ................................................................................................................................................................... 3 TEST METHODOLOGY .................................................................................................................................................. 4 MEASUREMENT UNCERTAINTY .................................................................................................................................... 4 TEST FACILITY ............................................................................................................................................................. 4 SYSTEM TEST CONFIGURATION .......................................................................................................................... 5 DESCRIPTION OF TEST CONFIGURATION ...................................................................................................................... 5 EQUIPMENT MODIFICATIONS ....................................................................................................................................... 6 SUPPORT EQUIPMENT LIST AND DETAILS .................................................................................................................... 6 SUPPORT CABLE DESCRIPTION .................................................................................................................................... 6 BLOCK DIAGRAM OF TEST SETUP ................................................................................................................................ 7 SUMMARY OF TEST RESULTS ............................................................................................................................... 8 TEST EQUIPMENT LIST ........................................................................................................................................... 9 FCC §1.1307(B)&§2.1093 - RF EXPOSURE INFORMATION .............................................................................. 11 FCC§2.1047 - MODULATION CHARACTERISTIC ............................................................................................. 12 FCC § 2.1046, § 22.913 (A) (D) & § 24.232(C) (D); §27.50(C)(D)(H)- RF OUTPUT POWER ............................. 13 APPLICABLE STANDARD ............................................................................................................................................ 13 TEST PROCEDURE ...................................................................................................................................................... 13 TEST DATA ................................................................................................................................................................ 13 FCC §2.1049, §22.917, §22.905 & §24.238&§27.53 - OCCUPIED BANDWIDTH ............................…
