2AJN7-LN500EG4QConvertible PC

Lenovo 100e Chromebook Gen 4, Lenovo 300e/500e Yoga Chromebook Gen 4 User Guide Read this first Before using this documentation and the product it supports, ensure that you read and understand the following: • Safety and Warranty Guide • Setup Guide • Generic Safety and Compliance Notices First Edition (January 2023) © Copyright Lenovo 2023. LIMITED AND RESTRICTED RIGHTS NOTICE: If data or software is delivered pursuant to a General Services Administration “GSA” contract, use, reproduction, or disclosure is subject to restrictions set forth in Contract No. GS- 35F-05925. Contents Discover your Chromebook. . . . . . . . . . . ii Chapter 1. Meet your Chromebook. . . 1 Front. . . . . . . . . . . . . . . . . . . . 1 Base. . . . . . . . . . . . . . . . . . . . 3 Left. . . . . . . . . . . . . . . . . . . . 5 Right. . . . . . . . . . . . . . . . . . . . 6 Bottom view. . . . . . . . . . . . . . . . . 7 Features and specifications. . . . . . . . . . . 8 Statement on USB transfer rate. . . . . . . . . 9 Operating environment. . . . . . . . . . . . 10 Avoid constant body contact with specific hot sections (for Lenovo 100e Chromebook Gen 4 and Lenovo 300e Yoga Chromebook Gen 4). . . . . 10 Chapter 2. Get started with your Chromebook. . . . . . . . . . . . . . 11 Charge your Chromebook. . . . . . . . . . . 11 Lock your Chromebook. . . . . . . . . . . . 11 Connect to Wi-Fi. . . . . . . . . . . . . . 12 Use the keyboard shortcuts. . . . . . . . . . 12 Use the touchpad. . . . . . . . . . . . . . 13 Use the camera. . . . . . . . . . . . . . . 14 Use audio. . . . . . . . . . . . . . . . . 14 Use the electronic pen (for selected models). . . 15 Connect to an external display. . . . . . . . . 15 Connect to Bluetooth devices. . . . . . . . . 15 Set the power plan. . . . . . . . . . . . . 16 Chapter 3. CRU replacement. . . . . 17 What are CRUs. . . . . . . . . . . . . . . 17 Replace a CRU. . . . . . . . . . . . . . . 17 Pen dummy (for selected models). . . . . . 17 Base cover assembly. . . . . . . . . . . 18 Chapter 4. Help and support. . . . . 21 Frequently asked questions. . . . . . . . . . 21 Lenovo Customer Support Center. . . . . . . 21 Get help from Google. . . . . . . . . . . . 22 Appendix A. Safety instructions for teachers, parents and adult supervisors. . . . . . . . . . . . . . . 25 Appendix B. Open source information. . . . . . . . . . . . . . . 27 Appendix C. Notices and trademarks. . . . . . . . . . . . . . . 29 © Copyright Lenovo 2023i Discover your Chromebook Thank you for choosing a Lenovo ® Chromebook ™ ! We are dedicated to delivering the best solution to you. Before starting your tour, please read the following information: • This guide applies to Lenovo product model(s) listed below. Illustrations in this guide may look slightly different from your product model. Model name Machine type (MT) Lenovo 100e Chromebook Gen 4 82W0, 82W1 Lenovo 300e Yoga Chromebook Gen 4 82W2, 82W3 Lenovo 500e Yoga Chromebook Gen 482W4, 82W5 • For further compliance information, refer to the Generic Safety and Compliance Notices at https:// pcsupport.lenovo.com/docs/generic_notices . • Depending on the model, some optional accessories, features, software programs, and user interface instructions might not be applicable to your Chromebook. • Documentation content is subject to change without notice. To get the latest documentation, go to https:// pcsupport.lenovo.com . Chapter 1. Meet your Chromebook Front Lenovo 100e Chromebook Gen 4, Lenovo 300e Yoga Chromebook Gen 4 Lenovo 500e Yoga Chromebook Gen 4 1. Camera lightIf the light is on, the camera is in use. 2. Camera coverCover or uncover the camera lens. Note:The camera cover helps you better protect your privacy. © Copyright Lenovo 20231 3. CameraCapture still and moving images for taking photos, recording videos, and video chatting. 4. Microphone(s)Capture or record sound and voice. 5. Wireless antennas* • For Lenovo 100e Chromebook Gen 4 (WLAN + WWAN models): Send and receive radio waves for the built-in wireless WAN (wide area network) module. • For Lenovo 300e Yoga Chromebook Gen 4 and Lenovo 100e Chromebook Gen 4 (WLAN models): Send and receive radio waves for the built-in wireless LAN (local area network) and Bluetooth module. Notes: • Lenovo 100e Chromebook Gen 4 has two models: WLAN model and WLAN + WWAN model • The antennas are not visible from the outside of the computer. 6. ScreenDisplay text, graphics, and videos. Selected models support multi- touch function. * for Lenovo 100e Chromebook Gen 4 and Lenovo 300e Yoga Chromebook Gen 4 2 Lenovo 100e Chromebook Gen 4, Lenovo 300e/500e Yoga Chromebook Gen 4 User Guide Base Lenovo 100e Chromebook Gen 4 Lenovo 300e/500e Yoga Chromebook Gen 4 1. Power buttonPress the button to turn on the computer or put the computer into sleep mode. Notes:When you finish working with your Chromebook, shut it down to save power. • Click in the system tray. • Press the power button. 2. KeyboardEnter characters and interact with programs. Note:The keyboard also includes hotkeys and function keys for changing settings and performing tasks quickly. Chapter 1.Meet your Chromebook3 3. TouchpadPerform finger touch and all the functions of a traditional mouse. Note:The touchpad also supports multi-touch function. 4. Wireless LAN antennasFor Lenovo 100e Chromebook Gen 4 (WLAN + WWAN models): Send and receive radio waves for the built-in wireless LAN (local area network) and Bluetooth module. Notes: • The antennas are not visible from the outside of the computer. • The locations of wireless LAN antennas vary on different models. 5. Wireless WAN antennasSend and receive radio waves for the built-in wireless WAN (wide area network) and Bluetooth module. Notes: • The antennas are not visible from the outside of the computer. • The locations of wireless WAN antennas vary on different models. 6. Camera*Capture still and moving images for taking photos, recording videos, and video chatting. 7. Camera light*If the light is on, the camera is…

Text truncated - open the document above for the full version.

Regulatory Notice for Wireless LAN/WAN modules (July 2023) © Copyright Lenovo 2023. Contents About this manual. . . . . . . . . . . . iii Chapter 1. Notice for users in USA and Canada. . . . . . . . . . . . . . . 1 Approved wireless devices. . . . . . . . . . . 1 Preinstalled wireless LAN module. . . . . . . . . 2 Simultaneous use of RF transmitters. . . . . . . . 2 Canada — Innovation, Science and Economic Development (ISED). . . . . . . . . . . . . . 3 Approved wireless devices. . . . . . . . . . 3 Preinstalled wireless LAN module . . . . . . . 4 Low power license-exempt radiocommunication devices. . . . . . . . . 4 Exposure of humans to RF fields (RSS-102) . . . 4 Canada — Innovation, Sciences et Développement économique (ISDE). . . . . . . . 4 Périphériques sans fil homologués. . . . . . 4 Module réseau local sans fil préinstallé. . . . . 5 Appareils de radio-communication basse tension sans licence d'utilisation. . . . . . . 6 Conformité des appareils de radiocommunication aux limites d'exposition humaine aux radiofréquences (CNR-102) . . . . 6 Location of the FCC ID and IC ID. . . . . . . . . 6 Electronic emission notices. . . . . . . . . . . 7 Federal Communications Commission (FCC) Declaration of Conformity. . . . . . . . . . 7 Usage environment and your health . . . . . . 7 Chapter 2. European Union (EU) / United Kingdom (UK) Compliance. . . . 9 UK declaration of conformity. . . . . . . . . . . 9 EU declaration of conformity. . . . . . . . . . . 9 English. . . . . . . . . . . . . . . . . 9 Bulgarian. . . . . . . . . . . . . . . . 9 Croatian. . . . . . . . . . . . . . . . 10 Czech. . . . . . . . . . . . . . . . . 10 Danish. . . . . . . . . . . . . . . . 11 Dutch. . . . . . . . . . . . . . . . . 11 Estonian. . . . . . . . . . . . . . . . 11 Finnish. . . . . . . . . . . . . . . . 12 French. . . . . . . . . . . . . . . . 12 German. . . . . . . . . . . . . . . . 12 Greek. . . . . . . . . . . . . . . . . 13 Hungarian. . . . . . . . . . . . . . . 13 Italian. . . . . . . . . . . . . . . . . 13 Latvian. . . . . . . . . . . . . . . . 14 Lithuanian. . . . . . . . . . . . . . . 14 Norwegian. . . . . . . . . . . . . . . 15 Polish. . . . . . . . . . . . . . . . . 15 Portuguese. . . . . . . . . . . . . . . 15 Romanian. . . . . . . . . . . . . . . 16 Slovenian. . . . . . . . . . . . . . . 16 Slovakian. . . . . . . . . . . . . . . 16 Spanish. . . . . . . . . . . . . . . . 17 Swedish. . . . . . . . . . . . . . . . 17 Turkish. . . . . . . . . . . . . . . . 17 Chapter 3. 日本のユーザーへの通知. . 19 日本国内で無線 LAN アダプターおよび Bluetooth アダプターをご使用に なる場合の注意. . . . . 19 無線 LAN 製品ご使用時におけるセキュリティに関 するご注意. . . . . . . . . . . . . . . . . 22 使用環境および快適に使用するために. . . . . . 22 日本国内で無線WAN 設備をご使用になる場合の注 意 . . . . . . . . . . . . . . . . . . . . 23 無線通信機能(モジュールを含む)を持つパーソナル コンピュータの比吸収率 （Body SAR）につい て . . . . . . . . . . . . . . . . . . . . 23 Chapter 4. Regulatory notices for other countries/regions. . . . . . . . 25 Notice for users in Brazil (Aviso para os utilizadores no Brasil) . . . . . . . . . . . . 25 Notice for users in Mexico (Nota para uso en Mexico). . . . . . . . . . . . . . . . . . 25 Notice for users in Morocco . . . . . . . . . . 25 Notice for users in Nigeria. . . . . . . . . . . 28 Notice for users in Taiwan region. . . . . . . . 28 根據NCC低功率電波輻射性電機管理辦法規 定 . . . . . . . . . . . . . . . . . . 28 Trademarks. . . . . . . . . . . . . . . . xxix © Copyright Lenovo 2023i iiRegulatory Notice for Wireless LAN/WAN modules About this manual This publication contains regulatory information for wireless modules that may be included by Lenovo computers. Different computer products support different wireless modules. Devices that are certified with a specific absorption rate (SAR) are listed separately. Table 1. Wireless modules for SAR-certified devices Product Name Wireless Modules Yoga 6 13ABR8 RTL8852BE, MT7921 Yoga Slim 6 14IAP8 AX201NGW, AX211NGW, RTL8852BE, RTL8852CE Yoga Slim 6 14IRP8 AX201NGW, AX211NGW, RTL8852BE, RTL8852CE IdeaPad Pro 5 14IRH8AX203NGW, RTL8852BE , AX211NGW, RTL8852CE IdeaPad Pro 5 14ARP8 RTL8852BE, MT7921, RTL8852CE, MT7922A22M Lenovo Slim 7 14IRP8AX201NGW, AX211NGW, RTL8852BE, RTL8852CE Yoga 7 14IRL8 AX203NGW, AX211NGW Yoga 7 16IRL8 AX203NGW, AX211NGW Yoga Pro 7 14IRH8 MT7922A22M, RTL8852CE Yoga Pro 7 14ARP8 MT7922A22M, RTL8852CE Lenovo Slim Pro 7 14ARP8MT7922A22M, RTL8852CE Lenovo Slim Pro 7 14IRH8RTL8852CE, AX211NGW Yoga 7 14ARP8 RTL8852CE, MT7922A22M Yoga 7 16ARP8 RTL8852CE, MT7922A22M Yoga Slim 6 14APU8 RTL8852CE, RTL8852BE, MT7921, MT7922A22M Lenovo 100e Chromebook Gen 4MT7921, FM101-GL Lenovo 300e Yoga Chromebook Gen 4 MT7921 IP Slim 3 Chrome 14M868MT7921 ThinkBook 14 G5 IRL9560NGW R, RTL8822CE, AX203NGW, RTL8852BE, AX211NGW, RTL8852CE ThinkBook 15 G5 IRL9560NGW R, RTL8822CE, AX203NGW, RTL8852BE, AX211NGW, RTL8852CE ThinkBook 14 G5 ABPRTL8822CE, RTL8852BE, RTL8852CE, MT7921, MT7922A22M ThinkBook 15 G5 ABPRTL8822CE, RTL8852BE, RTL8852CE, MT7921, MT7922A22M ThinkBook 14s Yoga G3 IRU AX203NGW, RTL8852CE, RTL8852BE, AX211NGW Legion Slim 5 16IRH8 AX211NGW, AX203NGW, RTL8852CE, RTL8852BE Legion Slim 5 16APH8 MT7922A22M, MT7921, RTL8852CE, RTL8852BE Legion Slim 5 16APH8A MT7922A22M, MT7921, RTL8852CE, RTL8852BE Legion Slim 7 16IRH8 AX211NGW, RTL8852CE Legion Slim 7 16APH8 MT7922A22M, RTL8852CE © Copyright Lenovo 2023iii Table 1. Wireless modules for SAR-certified devices (continued) Product Name Wireless Modules IdeaPad Slim 5 14IRL8AX211NGW, RTL8852CE, AX203NGW, RTL8852BE IdeaPad Slim 5 16IRL8AX211NGW, RTL8852CE, AX203NGW, RTL8852BE IdeaPad Slim 5 14ABR8MT7922A22M, RTL8852CE, MT7921, RTL8852BE IdeaPad Slim 5 16ABR8MT7922A22M, RTL8852CE, MT7921, RTL8852BE Lenovo 500e Yoga Chromebook Gen 4 AX211NGW, MT7921, FM101-GL, EM060K-GL IdeaPad Slim 3 14IAN8AX203NGW, 9560NGW R, RTL8852BE, RTL8822CE IdeaPad Slim 3 15IAN8AX203NGW, 9560NGW R, RTL8852BE, RTL8822CE IdeaPad Slim 3 14AMN8RTL8852BE, RTL8822CE, MT7921 IdeaPad Slim 3 15AMN8RTL8852BE, RTL8822CE, MT7921 IdeaPad Slim 3 14ABR8RTL8852BE, RTL8822CE, MT7921 IdeaP…

Text truncated - open the document above for the full version.

LC Future Center 7F., No.780, Beian Rd., Zhongshan Dist. Taipei 104, Taiwan Tel: 886-2-2718-8555; Fax: 886-2-2532-3719 Federal Communications Commission 7435 Oakland Mills Road Columbia MD 21046 Date: December 18, 2023 Subject: Certifications concerning “covered” equipment pursuant to Part 2.911(d)(5)(i) and (ii) To whom it may concern, LC Future Center (“the applicant”) certifies that the equipment FCC ID: 2AJN7-LN500EG4Q for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. LC Future Center (“the applicant”) certifies that, as of the date of the filing of the application, the applicant is not identified on the Covered List (as a specifically named entity or any of its subsidiaries or affiliates) as an entity producing “covered” equipment. Sincerely, ________________________ Allen Chen Design Leader [email protected]

LC Future Center 7F., No.780, Beian Rd., Zhongshan Dist. Taipei 104, Taiwan Tel: 886-2-2718-8555; Fax: 886-2-2532-3719 Federal Communications Commission 7435 Oakland Mills Road Columbia MD 21046 Date: December 18, 2023 Subject: Certifications concerning “covered” equipment pursuant to Part 2.911(d)(5)(i) and (ii) To whom it may concern, LC Future Center (“the applicant”) certifies that the equipment FCC ID: 2AJN7-LN500EG4Q for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. LC Future Center (“the applicant”) certifies that, as of the date of the filing of the application, the applicant is not identified on the Covered List (as a specifically named entity or any of its subsidiaries or affiliates) as an entity producing “covered” equipment. Sincerely, ________________________ Allen Chen Design Leader [email protected]

LC Future Center 7F., No.780, Beian Rd., Zhongshan Dist. Taipei 104, Taiwan Tel: 886-2-2718-8555; Fax: 886-2-2532-3719 Date: December 18, 2023 FCC Laboratory 7435 Oakland Mills Rd Columbia MD 21046 Subject: Request for Confidentiality FCC ID: 2AJN7-LN500EG4Q To Whom It May Concern, Pursuant to the provisions of Sections 0.457 and 0.459 of Commission’s rules (47CFR§§0.457, 0.459), we are requesting the Commission to withhold the following documents from public disclosure indefinitely. ⚫ Schematic Diagram ⚫ Block Diagram ⚫ Part List ⚫ Operational Description ⚫ Tune-up Procedure Above mentioned documents which contain detailed system and equipment description are considered as proprietary information in operation of the equipment. The public disclosure of above documents might be harmful to our company and would give competitor an unfair advantage in the market. In additional to above mentioned documents, pursuant to Public Notice DA 04-1705 of the Commission’ s policy, in order to comply with the marketing regulations in 47 CFR §2.803 and the importation rules in 47 CFR §2.1204, while ensuring that business sensitive information remains confidential until the actual marketing of newly authorized devices, we are requesting the Commission to withhold the following documents for 180 days after the grant of equipment authorization is issued: ⚫ External Photos ⚫ Internal Photos ⚫ Test Setup Photos ⚫ User Manual It is our understanding that all measurement test reports, FCC ID label format cannot be granted as confidential documents and those information will be available for public review once the grant of equipment authorization is issued. Best Regards, _______________________ Allen Chen Design Leader [email protected]

LC Future Center 7F., No.780, Beian Rd., Zhongshan Dist. Taipei 104, Taiwan Tel: 886-2-2718-8555; Fax: 886-2-2532-3719 Date: January 5, 2024 FCC Laboratory 7435 Oakland Mills Rd. Columbia, MD 21046 To whom it may concern: This device with FCC ID: 2AJN7-LN500EG4Q integrates a WWAN module: FCC ID Grant Date WWAN module XMR2022EM060KGL 06/07/2022 10/12/2022 11/01/2023 No hardware design changes are made on the modules, and the software has not been changed to increase the RF output power of the modules. Pursuant to KDB 996369 D02 v02, the original modular reports as following mentioned are submitted to represent the compliance of Part 22/24/27/90/96 conducted RF testing items of this device. Test Report Number 2203RSU045-U2 2203RSU045-U3 2203RSU045-U4 2203RSU045-U5 2203RSU045-U6 2209RSU021-U1 2309RSU052-U1 2309RSU052-U2 2309RSU052-U3 2309RSU052-U4 2309RSU052-U5 2309RSU052-U6 2309RSU052-U7 2203RSU046-U2 2203RSU046-U3 2203RSU046-U4 2203RSU046-U5 2203RSU046-U6 2209RSU022-U1 The radiated RF testing items are tested on this host device, and the test reports are submitted additionally. Sincerely, Allen Chen Design Leader [email protected]

LC Future Center 7F., No.780, Beian Rd., Zhongshan Dist. Taipei 104, Taiwan Tel: 886-2-2718-8555; Fax: 886-2-2532-3719 FCC Agent Authorization Date: December 18, 2023 To whom it may concern, LC Future Center hereby authorize Sporton International Inc. to act on our behalf in all matters relating to applications for FCC equipment authorization, including the signing of all documents relating to these matters. Any and all acts carried out by Sporton International Inc. on our behalf shall have the same effect as acts of our own. We also hereby certify that neither the applicant nor any party to the application is subject to a denial of Federal benefits that includes FCC benefits pursuant to section 5301 of the Anti-Drug Abuse Act of 1988. 21 U.S.C. 862. This authorization is limited to the product of as following: FCC ID: 2AJN7-LN500EG4Q This authorization is valid until further written notice from LC Future Center Sincerely, ________________________ Allen Chen Design Leader [email protected]

-------------- ----------------------------- Lenovo US 8001 Development Drive Morrisville, NC 27560 United States Date: 12/05/2023 Federal Communications Commission 7435 Oakland Mills Road Columbia MD 21046 Subject: Certification designating a U.S. agent for service of process pursuant to Part 2.911(d)(7) To whom it may concern, [ LC Future Center ] and FCC Grantee code：[2AJN7 ] , FRN [ 0025849167 ] (“the applicant”) certifies that, as of the date of the filing of application, [Lenovo (United States) Incorporated] (“the agent”) is designated as the U.S. agent for the purpose of accepting service of process on behalf of the applicant for Lenovo branded products. The physical U.S. address and email for the designated agent are: Physical U.S. address: [8001 Development Drive, Morrisville, NC 27560, United States] FRN: 0012799359 Email: [[email protected]] The applicant accepts to maintain an agent for service of process in the United States for no less than one year after either the grantee has permanently terminated all marketing and importation of the applicable equipment within the U.S., or the conclusion of any Commission-related administrative or judicial proceeding involving the equipment, whichever is later. The agent accepts the designation by (the applicant) as the U.S. agent to accept service of process includes, but is not limited to, delivery of any correspondence, notices, orders, decisions, and requirements of administrative, legal, or judicial process related to Commission proceedings. Signed by the Applicant Signed by the Agent (if different from the Applicant) Signature of Grantee Contact named below Name: Allen Chen Name: Brian Killebrew Title: Certification PM Address: 7F., No.780, Beian Rd., Zhongshan Dist., Taipei 104, Taiwan Title: Director, Corporate Regulatory Compliance, Standards and ISO 9001 Email: [email protected] Email: [email protected]

PHOTOGRAPHS OF EUT Report No.: EP2O2105-04 TEL : 0800-800005 Page Number : 1 of 30 FAX: 886-3-328-4978 Issue Date : Dec. 19, 2023 E-mail : [email protected] Report Version : 01 1. External Photograph of EUT Brand Name: Lenovo / Model Name: Lenovo 500e Yoga Chromebook Gen 4 Luxshare-ICT and ZTX Antenna PHOTOGRAPHS OF EUT Report No.: EP2O2105-04 TEL : 0800-800005 Page Number : 2 of 30 FAX: 886-3-328-4978 Issue Date : Dec. 19, 2023 E-mail : [email protected] Report Version : 01 PHOTOGRAPHS OF EUT Report No.: EP2O2105-04 TEL : 0800-800005 Page Number : 3 of 30 FAX: 886-3-328-4978 Issue Date : Dec. 19, 2023 E-mail : [email protected] Report Version : 01 PHOTOGRAPHS OF EUT Report No.: EP2O2105-04 TEL : 0800-800005 Page Number : 4 of 30 FAX: 886-3-328-4978 Issue Date : Dec. 19, 2023 E-mail : [email protected] Report Version : 01 PHOTOGRAPHS OF EUT Report No.: EP2O2105-04 TEL : 0800-800005 Page Number : 5 of 30 FAX: 886-3-328-4978 Issue Date : Dec. 19, 2023 E-mail : [email protected] Report Version : 01 PHOTOGRAPHS OF EUT Report No.: EP2O2105-04 TEL : 0800-800005 Page Number : 6 of 30 FAX: 886-3-328-4978 Issue Date : Dec. 19, 2023 E-mail : [email protected] Report Version : 01 PHOTOGRAPHS OF EUT Report No.: EP2O2105-04 TEL : 0800-800005 Page Number : 7 of 30 FAX: 886-3-328-4978 Issue Date : Dec. 19, 2023 E-mail : [email protected] Report Version : 01 PHOTOGRAPHS OF EUT Report No.: EP2O2105-04 TEL : 0800-800005 Page Number : 8 of 30 FAX: 886-3-328-4978 Issue Date : Dec. 19, 2023 E-mail : [email protected] Report Version : 01 720510 PHOTOGRAPHS OF EUT Report No.: EP2O2105-04 TEL : 0800-800005 Page Number : 9 of 30 FAX: 886-3-328-4978 Issue Date : Dec. 19, 2023 E-mail : [email protected] Report Version : 01 2. Photograph of Accessory Brand Name: Lenovo / Model Name: Lenovo 500e Yoga Chromebook Gen 4 Specification of Accessory AC Adapter Brand Name Lenovo Model Name ADLX65YAC2E Battery Brand Name Lenovo Model Name L22M3PG0 Remark: For accessories equipped with this EUT, please refer to the following photos. PHOTOGRAPHS OF EUT Report No.: EP2O2105-04 TEL : 0800-800005 Page Number : 10 of 30 FAX: 886-3-328-4978 Issue Date : Dec. 19, 2023 E-mail : [email protected] Report Version : 01 720510 PHOTOGRAPHS OF EUT Report No.: EP2O2105-04 TEL : 0800-800005 Page Number : 11 of 30 FAX: 886-3-328-4978 Issue Date : Dec. 19, 2023 E-mail : [email protected] Report Version : 01 AC Adapter PHOTOGRAPHS OF EUT Report No.: EP2O2105-04 TEL : 0800-800005 Page Number : 12 of 30 FAX: 886-3-328-4978 Issue Date : Dec. 19, 2023 E-mail : [email protected] Report Version : 01 Battery

Bottom of the device Label

For US, IC M/N: LN500EG4Q FCC ID: 2AJN7-LN500EG4Q, IC: 21863-LN500EG4Q Contains FCC ID: RAS-MT7921, IC: 7542A-MT7921 P/N: XXXXXXXXXX M/N: LN500EG4Q FCC ID: 2AJN7-LN500EG4Q, IC: 21863-LN500EG4Q Contains FCC ID: PD9AX211NG, IC: 1000M-AX211NG P/N: XXXXXXXXXX

PHOTOGRAPHS OF EUT Report No.: EP2O2105-04 TEL : 0800-800005 Page Number : 13 of 30 FAX: 886-3-328-4978 Issue Date : Dec. 19, 2023 E-mail : [email protected] Report Version : 01 3. Internal Photograph of EUT 720510 Luxshare-ICT and ZTX Antenna PHOTOGRAPHS OF EUT Report No.: EP2O2105-04 TEL : 0800-800005 Page Number : 14 of 30 FAX: 886-3-328-4978 Issue Date : Dec. 19, 2023 E-mail : [email protected] Report Version : 01 PHOTOGRAPHS OF EUT Report No.: EP2O2105-04 TEL : 0800-800005 Page Number : 15 of 30 FAX: 886-3-328-4978 Issue Date : Dec. 19, 2023 E-mail : [email protected] Report Version : 01 PHOTOGRAPHS OF EUT Report No.: EP2O2105-04 TEL : 0800-800005 Page Number : 16 of 30 FAX: 886-3-328-4978 Issue Date : Dec. 19, 2023 E-mail : [email protected] Report Version : 01 PHOTOGRAPHS OF EUT Report No.: EP2O2105-04 TEL : 0800-800005 Page Number : 17 of 30 FAX: 886-3-328-4978 Issue Date : Dec. 19, 2023 E-mail : [email protected] Report Version : 01 WWAN Module PHOTOGRAPHS OF EUT Report No.: EP2O2105-04 TEL : 0800-800005 Page Number : 18 of 30 FAX: 886-3-328-4978 Issue Date : Dec. 19, 2023 E-mail : [email protected] Report Version : 01 PHOTOGRAPHS OF EUT Report No.: EP2O2105-04 TEL : 0800-800005 Page Number : 19 of 30 FAX: 886-3-328-4978 Issue Date : Dec. 19, 2023 E-mail : [email protected] Report Version : 01 WLAN Module_AX211NGW PHOTOGRAPHS OF EUT Report No.: EP2O2105-04 TEL : 0800-800005 Page Number : 20 of 30 FAX: 886-3-328-4978 Issue Date : Dec. 19, 2023 E-mail : [email protected] Report Version : 01 PHOTOGRAPHS OF EUT Report No.: EP2O2105-04 TEL : 0800-800005 Page Number : 21 of 30 FAX: 886-3-328-4978 Issue Date : Dec. 19, 2023 E-mail : [email protected] Report Version : 01 WLAN Module_MT7921 PHOTOGRAPHS OF EUT Report No.: EP2O2105-04 TEL : 0800-800005 Page Number : 22 of 30 FAX: 886-3-328-4978 Issue Date : Dec. 19, 2023 E-mail : [email protected] Report Version : 01 PHOTOGRAPHS OF EUT Report No.: EP2O2105-04 TEL : 0800-800005 Page Number : 23 of 30 FAX: 886-3-328-4978 Issue Date : Dec. 19, 2023 E-mail : [email protected] Report Version : 01 WWAN Main Antenna for Luxshare-ICT PHOTOGRAPHS OF EUT Report No.: EP2O2105-04 TEL : 0800-800005 Page Number : 24 of 30 FAX: 886-3-328-4978 Issue Date : Dec. 19, 2023 E-mail : [email protected] Report Version : 01 WWAN Aux. Antenna for Luxshare-ICT PHOTOGRAPHS OF EUT Report No.: EP2O2105-04 TEL : 0800-800005 Page Number : 25 of 30 FAX: 886-3-328-4978 Issue Date : Dec. 19, 2023 E-mail : [email protected] Report Version : 01 WLAN Main Antenna for Luxshare-ICT PHOTOGRAPHS OF EUT Report No.: EP2O2105-04 TEL : 0800-800005 Page Number : 26 of 30 FAX: 886-3-328-4978 Issue Date : Dec. 19, 2023 E-mail : [email protected] Report Version : 01 WLAN Aux. and Bluetooth Antenna for Luxshare-ICT PHOTOGRAPHS OF EUT Report No.: EP2O2105-04 TEL : 0800-800005 Page Number : 27 of 30 FAX: 886-3-328-4978 Issue Date : Dec. 19, 2023 E-mail : [email protected] Report Version : 01 WWAN Main Antenna for ZTX PHOTOGRAPHS OF EUT Report No.: EP2O2105-04 TEL : 0800-800005 Page Number : 28 of 30 FAX: 886-3-328-4978 Issue Date : Dec. 19, 2023 E-mail : [email protected] Report Version : 01 WWAN Aux. Antenna for ZTX PHOTOGRAPHS OF EUT Report No.: EP2O2105-04 TEL : 0800-800005 Page Number : 29 of 30 FAX: 886-3-328-4978 Issue Date : Dec. 19, 2023 E-mail : [email protected] Report Version : 01 WLAN Main Antenna for ZTX PHOTOGRAPHS OF EUT Report No.: EP2O2105-04 TEL : 0800-800005 Page Number : 30 of 30 FAX: 886-3-328-4978 Issue Date : Dec. 19, 2023 E-mail : [email protected] Report Version : 01 ─────THE END──── WWAN Aux. and BluetoothAntenna for ZTX

Date: 2023-11-25 System Check_Head_750MHz DUT: D750V3 - SN1117 Communication System: CW; Frequency: 750.000 MHz; Duty Cycle: 1:1 Medium: HSL_750_231125 Medium parameters used: f= 750.000 MHz; σ= 0.879 S/m; ε r = 41.8 Ambient Temperature: 23.5°C; Liquid Temperature: 22.5°C DASY8 Configuration: - Probe: EX3DV4 - SN3925; ConvF(10.36, 10.36, 10.36); Calibrated: 2023-04-25 - Sensor-Surface: 1.4 mm - Electronics: DAE4 Sn703; Calibrated: 2023-05-16 - Phantom: ELI V8.0 (20deg probe tilt); Serial: 2156-; Section: Flat - Measurement Software: 16.2.4.2524 - UID: CW, 0-- Pin=17.0dBm/Area Scan (40.0 mm x 90.0 mm): Measurement Grid: 10.0 mm x 15.0 mm SAR (1g) = 0.399 W/kg; SAR (10g) = 0.267 W/kg; Pin=17.0dBm/Zoom Scan (30.0 mm x 30.0 mm x 30.0 mm): Measurement Grid: 6.0 mm x 6.0 mm x 1.5 mm Power Drift = 0.02 dB SAR (1g) = 0.400 W/kg; SAR (8g) = 0.277 W/kg; SAR (10g) = 0.263 W/kg Date: 2023-11-26 System Check_Head_750MHz DUT: D750V3 - SN1117 Communication System: CW; Frequency: 750.000 MHz; Duty Cycle: 1:1 Medium: HSL_750_231126 Medium parameters used: f= 750.000 MHz; σ= 0.894 S/m; ε r = 41.9 Ambient Temperature: 23.6°C; Liquid Temperature: 22.6°C DASY8 Configuration: - Probe: EX3DV4 - SN3925; ConvF(10.36, 10.36, 10.36); Calibrated: 2023-04-25 - Sensor-Surface: 1.4 mm - Electronics: DAE4 Sn703; Calibrated: 2023-05-16 - Phantom: ELI V8.0 (20deg probe tilt); Serial: 2156-; Section: Flat - Measurement Software: 16.2.4.2524 - UID: CW, 0-- Pin=17.0dBm/Area Scan (40.0 mm x 90.0 mm): Measurement Grid: 10.0 mm x 15.0 mm SAR (1g) = 0.390 W/kg; SAR (10g) = 0.262 W/kg; Pin=17.0dBm/Zoom Scan (30.0 mm x 30.0 mm x 30.0 mm): Measurement Grid: 6.0 mm x 6.0 mm x 1.5 mm Power Drift = -0.04 dB SAR (1g) = 0.390 W/kg; SAR (8g) = 0.319 W/kg; SAR (10g) = 0.262 W/kg Date: 2023-11-20 System Check_Head_835MHz DUT: D835V2 - SN4d060 Communication System: CW; Frequency: 835.000 MHz; Duty Cycle: 1:1 Medium: HSL_835_231120 Medium parameters used: f= 835.000 MHz; σ= 0.915 S/m; ε r = 41.3 Ambient Temperature: 23.2°C; Liquid Temperature: 22.2°C DASY8 Configuration: - Probe: EX3DV4 - SN3925; ConvF(10.29, 10.29, 10.29); Calibrated: 2023-04-25 - Sensor-Surface: 1.4 mm - Electronics: DAE4 Sn703; Calibrated: 2023-05-16 - Phantom: ELI V8.0 (20deg probe tilt); Serial: 2156-; Section: Flat - Measurement Software: 16.2.4.2524 - UID: CW, 0-- Pin=17.0dBm/Area Scan (40.0 mm x 90.0 mm): Measurement Grid: 10.0 mm x 15.0 mm SAR (1g) = 0.455 W/kg; SAR (10g) = 0.303 W/kg; Pin=17.0dBm/Zoom Scan (30.0 mm x 30.0 mm x 30.0 mm): Measurement Grid: 6.0 mm x 6.0 mm x 1.5 mm Power Drift = 0.03 dB SAR (1g) = 0.455 W/kg; SAR (8g) = 0.314 W/kg; SAR (10g) = 0.298 W/kg Date: 2023-11-19 System Check_Head_1750MHz DUT: D1750V2 - SN1120 Communication System: CW; Frequency: 1750.000 MHz; Duty Cycle: 1:1 Medium: HSL_1750_231119 Medium parameters used: f= 1750.000 MHz; σ= 1.35 S/m; ε r = 40.5 Ambient Temperature: 23.4°C; Liquid Temperature: 22.4°C DASY8 Configuration: - Probe: EX3DV4 - SN3925; ConvF(8.92, 8.92, 8.92); Calibrated: 2023-04-25 - Sensor-Surface: 1.4 mm - Electronics: DAE4 Sn703; Calibrated: 2023-05-16 - Phantom: ELI V8.0 (20deg probe tilt); Serial: 2156-; Section: Flat - Measurement Software: 16.2.4.2524 - UID: CW, 0-- Pin=17.0dBm/Area Scan (40.0 mm x 90.0 mm): Measurement Grid: 10.0 mm x 15.0 mm SAR (1g) = 1.57 W/kg; SAR (10g) = 0.850 W/kg; Pin=17.0dBm/Zoom Scan (30.0 mm x 30.0 mm x 30.0 mm): Measurement Grid: 6.0 mm x 6.0 mm x 1.5 mm Power Drift = 0.02 dB SAR (1g) = 1.69 W/kg; SAR (8g) = 0.967 W/kg; SAR (10g) = 0.891 W/kg Date: 2023-11-18 System Check_Head_1900MHz DUT: D1900V2 - SN5d093 Communication System: CW; Frequency: 1900.000 MHz; Duty Cycle: 1:1 Medium: HSL_1900_231118 Medium parameters used: f= 1900.000 MHz; σ= 1.42 S/m; ε r = 39.0 …
