2AJN7-TP00145AU

LC Future Center

Notebook Computer

Click to zoom

Application Details

Equipment Class: PCB - PCS Licensed Transmitter
Date of Grant: Mar 26, 2023
Application Purpose: Original Equipment
Date of Application: Mar 09, 2023
Equipment Note: Notebook Computer
Frequency Range: 2503.50000000 - 2682.48000000
Company: LC Future Center
Country: Taiwan

Documents & Files

Select a file to view

Users Manual

Attestation Statements

Cover Letter(s)

External Photos

ID Label/Location Info

Internal Photos

RF Exposure Info

Test Report

Test Setup Photos

Contact Information

Applicant

Allen Chen(Design Leader)

[email protected]886-2-2718-8555Fax: 886-2-2532-3719

Technical Contact

Sporton International Inc.Eric Huang

[email protected]886-3-327-3456

No.52, Huaya 1st Rd., Guishan Dist. · Taoyuan · Taiwan

Non-Technical Contact

Sporton International Inc.Ida Chen

[email protected]886-3-327-3456

Test Firm

SPORTON International Inc.Alex Chen

[email protected]886-3-327-3456Fax: +886-3-327-0973

Technical Specifications

#	Rule Parts	Frequency Range	Power Output	Emission	Tolerance
109	27	2.50 GHz - 2.68 GHz	424.60 mW	14M2W7D	2.5 ppm

Confidentiality

Long Term

Grant Notes

Output power listed is ERP for operations below 1 GHz, EIRP for operations above 1 GHz and conducted power for Part 90S (814-824 MHz). LTE supports 5/10 MHz bandwidths in Band 13, Band 14, Band 17, and Band 30; 5/10/15/20 MHz bandwidths in Band 7, Band 71, Band 38, and Band 41; 1.4/3/5/10 MHz bandwidths in Band 5, and Band 12; 1.4/3/5/10/15 MHz bandwidths in Band 26; 1.4/3/5/10/15/20 MHz bandwidths in Band 2, Band 4, Band 25, and Band 66. 5GNR Sub 6GHz supports 5/10/15/20 MHz bandwidths in n2/n5/n7/n25/n71; 5/10 MHz bandwidths in n30; 5/10/15/20 MHz bandwidths in n38; 5/10/15/20/40 MHz bandwidths in n66; 10/15/40/50/80/100 MHz bandwidths in n41; 10/15/20/40/50/60/80/100 MHz bandwidths in n77/n78. This device supports downlink carrier aggregation for inter-band and intra-band, uplink carrier aggregation for intra-band in LTE Band 5/7/66/38/41. Powers listed are for the highest power and widest bandwidth within each band for QPSK and QAM modulations for single carrier operations and, where applicable, widest bandwidth and highest power for intra-band uplink carrier aggregation. The highest reported SAR values for body and simultaneous transmission use conditions are 1.20 W/kg and 1.51 W/kg, respectively.
