-0- Ma DigitalNightVision Model:NV-880/VC-2000 Patent:202130724450.6(CN),008747075(EU)USD965658(USA) -1- IControls -2- IIUsage DeviceispotableNVcamerawithneckstrap,alsosupporthelmet,tripod,external lightmounted.(Helmet,tripod,externallightarenotincluded) 1Viewer 2Cover11Audioin 3Screenbrightnessbutton12IRilluminator 4IRilluminatoradjustbutton13Mountingrail 5MicroSDcardslot14Batterycover（3.7V,3000mAh以上，18650x1） 6Helmetinterface15Backbutton/Colorful,B&W,Greenmodeswitch 7RECbutton/Downbutton16OKbutton,Zoom1-8X 8 WIFIbutton(longpress)/Up button 17 Type–Cinterface 9Simplebracketinterface18On/Off,Video/Photo/timelapse/Playback/Setting 10Lens(rotateforfocusing) SupportBattery:18650,3.7V,3000mAhHighquality(notinclude) -3- SafetyNotes 1,Multilayercoatedopticalglasslenses,payattentiontooilanddust,anduseasoft wipingclothtowipefromthemiddletotheperiphery! 2,themachinecannotbeimmersedinwatertoavoiddamagetotheinstrumentcircuit causedbyimmersion.Nowarrantyisprovidedforwateringress. 3,Whenusing,donotfacethesun,anddonotplaceitinahightemperatureenvironment, suchasacarorworkshopexposedtohightemperature. 4,PleaseinsertMicroSDcardatcorrectdirection.Turnoffthemachinebeforeinserting andremovingtheMicroSDcard. IIIFunctions Mode:Video/Photo/Timeplase/playback 1）Button18#: a.Off b. Video :PressRECbuttontostartandenda video. c. Photo ：PressRECbuttontotakeaphoto d.Timelapse:countdown10stowork SetPhoto/VideoinMenusetting,interval5s-24h.(default:1minuteavideo) Note:ThescreencanbeclosedwhenDigitalnightvisionisTimelapsemodeto savepowerandextendbatteryworkingtime) e. Playback :PressWIFI(Up)/REC(Down)button PressBackbuttoninDeletemode f.MENUsetting -4- 1.0-8.0XZoomFactor TheDigitalZoommagnificationfactorisdisplayedhere.(1.0x – 8.0x) IVMENU VideoSize: FHD1080P HD720P Photo Resolution: 16MP 12MP 8MP 6MP Date&Time DateType 2022/7/1/00:00 YY/MM/DD WiFIPassword: CAM_****** 1234567890 Timelapse:Interval00:00:05 TimeLapse Mode: PHOTO VIDEO TimeLapse Work1: Off/On Start00:00End00:00 TimeLapse Work2: Off/On Start00:00End00:00 TimeLapse Work3: Off/On Start00:00End00:00 DateStamp ： GPS Off/On Lng:000.0000N Lat:000.0000E -5- Language English Français Español Italiano Pyccknn Deutsch 日本語 Polski Čeština HUDColor: Green/White/Red/ Yellow/Cyan/Magenta NVFilter ：Green/B&W PowerSave 10Min 30Min 60Min 3Hours 5Hours 8Hours 12Hours 24Hours Never MicroSD Overwrite ： Off/On USBMode MSDC PCCAM Format: Yes/No FactoryReset: Yes/No System: 00.00.41 VConnectingdevice ConnectionviaUSBcable MSDC:Devicecouldbeusedasadiskwhile connectingwithUSBcable PCCAM:DevicecouldbeusedasaWEBcamerawhileconnectingUSBcablewith computer -6- (TheunitisabletoinstallDriverusedasaWEB camerawhilecomputersystemisunder Windows2000,AndTheunitiscompatiblewithkinds ofWEBcamerasoftwareonlineandusageissame ascomputercameraafterinstallingdriver successfully),suchas:SPCA1628_V1200_WHQLSetup.exe VIWIFIshare Download"Nightvision"AndroidorIOSAPPfirstlyintheapplication storeofmobiledevice,andtheninstallitintothemobiledevice.This appisafreeapplicationdevelopedbyourcompany （WIFIdistanceisMax25mwithoutanyinterferenceinthearea） WIFIAPPinstallandsetting 1,TurnOnWIFIofNVcamera Longpress“WIFI”buttontoTurnonWIFIfunction,countdown120stoconnect. 2,MobiledeviceWIFIconnection Searchthedevicename"CAM-5E...”(everyNVhasadifferentWIFIserialnumber)on Mobiledeviceandconnect,WIFIdefaultpasswordis123456790. “MENU”mode-“WIFI”passwordsetting(0-1,A-Z) 3,NVCamerashowconnectinginformationonscreen 4,Click“Nightvision”APP,Click“ADDNewCamera”toaddaNVcameraandenter Operationinterface PleaserefertothefollowingAPPoperationinterface -7- Note:WhenWIFIisconnectedsuccessfully,NVcameraandtheAPPwouldbe synchronised.ChangesonAPPwillbesameonNVcamera,camerabuttonareoutof function. 5 ： Playback ： See ★ fastview “ Photo/Video ” 6,Filename“DigitalNV”inphonetosaveVideoandphotowhichdownloadfromNV camera -8- VIIFirmwareupgrade Whenupgradingthesoftware,pleaseensurethatthereisenough powerandnopowerloss. 1,Copythesoftware"SPHOST.BRN"totherootdirectoryofthe Micromemorycard 2,Enterthesoftwareupgradesetinthemenu Nootheroperationswillbedoneduringtheupgradeprocess.Waituntilthesoftware upgradeiscompleted,andthenenterthemenu"System"againtocheckthenew softwareversionnumber. AppendixI:TechnicalSpecification BuildIn1.5 ” TFT,ViewLargeLCDScreenUPTO3 ” display ResolutionofScreen:640*480 Magnification(optical):3 DigitalZoom ： 8 Lensdiameter:20mm CMOSinterpolate16mp FforObjectivelens ： 7.8*4.4,F=38mm JPEG:5376 × 3024 ， 4608 × 2592 ， 3840 × 2160 ， 3264 × 1832 Video:1920*1080 ， 1280*720@30FPSwithsound InfraredIlluminator:850NM1WInfraredLED ObservingDistance(FullDarkEnvironment):490ft/150M TFcard:upto64G(noincluded) TimelapseFunction:YES,PhotoorVideo GPSIDstamponthepictureorvideo:YES Adjustableeyepiece Timestamp:Dateandtime,GPSonpictureandvideo Screenturn:on/off ， WIFIfunction:YES Language:English,French,German,Italian,Japanese, Russian,Spanish,Czechen,Polish WorkingPowerVoltage:3.7V RechargeableBattery:1*18650(Notinclude) Built-in1tripodmountable:YES USB:TypeC OperatingTemperatureRange:-10-+45 ° Cameraweight(withoutbatteryandpackage):320g Certification:CE,FCC-ID ， ROHS -9- *Without battery, Micro SD card Please Format the Micro-SD memory card before use. Files n the card from other device may affect the functionality of the cmera. FCC NOTE This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to corr…
