2AJNO-24PFARMAeroGarden

Differences Declaration To whom it may concern, We AeroGrow International, Inc. hereby declare: The product model 100024-BLK-Version B, 100024-WHT-Version B, 100025-WHT-Version B,100026-BLK-Version B, 100026-WHT-Version B are identical in the same PCB layout, interior structure and electrical circuits with the model 100025-BLK-Version B which has been tested by Global Unit Technology Co., Ltd., the only differences are the model name, the enclosure color and the high of appliance. Authorized signature: Date: June 16, 2020

AeroGrow International, Inc. DATE : 2020-06-12 Equipment Autorisation Division Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 FCC ID: 2AJNO-24PFARM Product Name: AeroGarden Request for Confidentiality Pursuant to Sections 0.457 and 0.459 of the commissions rules, we hereby request that the following documents be held confidential: (List here the documents for which you are seeking confidentiality – for example ...)  Schematics  Block diagram  Operation description These materials contain trade secrets and proprietary information and are not customarily released to the public. The public disclosure of this information might be harmful to the company and provide unjustified benefits to our competitors. Signature: Name: Mely Wilcox Title: Product/Project Manager Company: AeroGrow International, Inc.

DATE : 2020-06-12 Federal Communications Commission Authorization & Evaluation Division 7345 Oakland Mills Road Columbia, Maryland 21046 Authority to Act as Agent On our behalf, I appoint Jason Wu of Global United Technology Services Co., Ltd.and No. 123-128, Tower A, Jinyuan Business Building, No.2, Laodong Industrial Zone, Xixiang Road, Baoan District, Shenzhen, Guangdong, China to act as our agent in the preparation of this application for equipment certification. I certify that submitted documents properly describe the device or system for which equipment certification is sought. I also certify that each unit manufactured, imported or marketed, as defined in the Federal Communications Commission’s regulations will have affixed to it a label identical to that submitted for approval with this application. For instances where our authorized agent signs the application for certification on our behalf, I acknowledge that all responsibility for complying with the terms and conditions for certification, still resides with AeroGrow International, Inc. and 6075 Longbow Dr. Suite #200, Boulder, Colorado 80301, United States Signature: Name: Mely Wilcox Title: Product/Project Manager Company: AeroGrow International, Inc.

Test Model No.: 100025-BLK-Version B

PET material

100025-BLK-Version B_Label sample and label location 100 024-BLK_Label sample a nd label location

Test Model No.: 100025-BLK-Version B

FCC ID: 2AJNO-24PFARM RF Exposure Evaluation Limits The criteria listed in the following table shall be used to evaluate the environment impact of human exposure to radio frequency (RF) radiation as specified in 1.1307(b) Limits for Maximum Permissible Exposure (MPE) Frequency range (MHz) Electric field strength (V/m) Magnetic field strength (A/m) Power density (mW/cm 2 ) Averaging time (minutes) (A) Limits for Occupational/Controlled Exposures 0.3–3.0 614 1.63 *(100) 6 3.0–30 1842/f 4.89/f *(900/f 2 ) 6 30–300 61.4 0.163 1.0 6 300–1500 f/300 6 1500–100,000 5 6 (B) Limits for General Population/Uncontrolled Exposure 0.3–1.34 614 1.63 *(100) 30 1.34–30 824/f 2.19/f *(180/f 2 ) 30 30–300 27.5 0.073 0.2 30 300–1500 f/1500 30 1500–100,000 1.0 30 f = frequency in MHz Friis transmission formula: Pd = (Pout*G)/(4*pi*r 2 ) Where Pd = power density in mW/cm 2 , Pout = output power to antenna in mW; G = gain of antenna in linear scale, Pi = 3.1416; R = distance between observation point and center of the radiator in cm Pd id the limit of MPE, 1 mW/cm 2 . If we know the maximum gain of the antenna and the total power input to the antenna, through the calculation, we will know the distance r where the MPE limit is reached. Test Procedure Software provided by client enabled the EUT to transmit and receive data at lowest, middle and highest channel individually. Test Result of RF Exposure Evaluation WiFi mode Channel Output power to antenna (mW) Power Density at R=20cm (mW/cm 2 ) Limit (mW/cm 2 ) Result Lowest (2412MHz) 58.48 0.018382353 1.0 PASS Middle (2437MHz) 54.20 0.017037497 1.0 PASS Highest (2462MHz) 56.23 0.017676105 1.0 PASS Remark: antenna gain=2dBi

Global United Technology Services Co., Ltd. Report No.: GTS202005000159F01 Authorized Signature: Robinson Lo Laboratory Manager This results shown in this test report refer only to the sample(s) tested, this test report cannot be reproduced, except in full, without prior written permission of the company. The report would be invalid without specific stamp of test institute and the signatures of compiler and approver. Page 1 of 49 TEST REPORT Applicant: AeroGrow International, Inc. Address of Applicant: 6075 Longbow Dr. Suite #200, Boulder, Colorado 80301, United States Manufacturer: AeroGrow International, Inc. Address of Manufacturer: 6075 Longbow Dr. Suite #200, Boulder, Colorado 80301, United States Factory: Zhangzhou Wanlida ZhonghuanTechnology Inc Address of Factory: 10# Jin da Road, Wanlida Industry Zone, Jinfeng, Zhangzhou, Fujian, China Equipment Under Test (EUT) Product Name: Model No.: Trade Mark: FCC ID: Applicable standards: Date of sample receipt: Date of Test: Date of report issued: Test Result : AeroGarden 100024-BLK-Version B, 100024-WHT-Version B, 100025-BLK-Version B, 100025-WHT-Version B, 100026-BLK-Version B, 100026-WHT-Version B AeroGarden 2AJNO-24PFARM FCC CFR Title 47 Part 15 Subpart C Section 15.247 June 03, 2020 June 03- June 15, 2020 June 15, 2020 PASS * * In the configuration tested, the EUT complied with the standards specified above. Report No.: GTS202005000159F01 Global United Technology Services Co., Ltd. No. 123-128, Tower A,Jinyuan Business Building, No.2, Laodong Industrial Zone, Xixiang Road, Baoan District, Shenzhen, Guangdong, China 518102 Telephone: +86 (0) 755 2779 8480 Fax: +86 (0) 755 2779 8960 Page 2 of 49 2 Version Version No. Date Description 00 June 15, 2020 Original Prepared By: Date: June 15, 2020 Project Engineer Check By: Date: June 15, 2020 Reviewer Report No.: GTS202005000159F01 Global United Technology Services Co., Ltd. No. 123-128, Tower A,Jinyuan Business Building, No.2, Laodong Industrial Zone, Xixiang Road, Baoan District, Shenzhen, Guangdong, China 518102 Telephone: +86 (0) 755 2779 8480 Fax: +86 (0) 755 2779 8960 Page 3 of 49 3 Contents Page 1 COVER PAGE ........................................................................................................................................... 1 2 VERSION .................................................................................................................................................. 2 3 CONTENTS .............................................................................................................................................. 3 4 TEST SUMMARY ..................................................................................................................................... 4 5 GENERAL INFORMATION ...................................................................................................................... 5 5.1 GENERAL DESCRIPTION OF EUT ......................................................................................................... 5 5.2 TEST MODE ........................................................................................................................................ 7 5.3 DESCRIPTION OF SUPPORT UNITS ....................................................................................................... 7 5.4 DEVIATION FROM STANDARDS ............................................................................................................. 7 5.5 ABNORMALITIES FROM STANDARD CONDITIONS ................................................................................... 7 5.6 TEST FACILITY .................................................................................................................................... 7 5.7 TEST LOCATION ................................................................................................................................. 7 5.8 ADDITIONAL INSTRUCTIONS ................................................................................................................. 7 6 TEST INSTRUMENTS LIST ..................................................................................................................... 8 7 TEST RESULTS AND MEASUREMENT DATA .................................................................................... 10 7.1 ANTENNA REQUIREMENT ................................................................................................................... 10 7.2 CONDUCTED EMISSIONS ................................................................................................................... 11 7.3 CONDUCTED PEAK OUTPUT POWER .................................................................................................. 14 7.4 CHANNEL BANDWIDTH ...................................................................................................................... 15 7.5 POWER SPECTRAL DENSITY ............................................................................................................. 18 7.6 BAND EDGES .................................................................................................................................... 21 7.6.1 Conducted Emission Method ..................................................................................................... 21 7.6.2 Radiated Emission Method ........................................................................................................ 24 7.7 SPURIOUS EMISSION ......................................................................................................................... 29 7.7.1 Conducted Emission Method ..................................................................................................... 29 7.7.2 Radiated Emission Method ........................................................................................................ 32 8 TEST SETUP PHOTO ..............................................................................................................…

Text truncated - open the document above for the full version.

Test Model No.: 100025-BLK-Version B Radiated Emission Conducted Emission
