2AJVQ-MWH630BWIFI/BT Module

TheusermanualofTV’sWIFImodule 1.Theproductdescription TheusercanachieveTVconnectionWIFInet,throughthismoduleandthevoltagesuppliedbythesystemtothe moduleneedstobetransmittedbyavoltageregulatororcircuit ThisequipmentmaybeoperatedinallEuropeancountries. Themoduleinstallationmethodisasfollows:passthelargeroundholeofthemodulethroughthelimitcolumnof thebracketoftheTV,andfixthemodulebythesnap-fitonthebracket. 2.Basicparameters FeatureDescriptionFeatureDescription ModelMWH630B ProductNameWiFi/BTModule MajorChipset MT7663UNandRTL8852BE AntennaReferenceInternalPrintedPCBANT Interface MT7663UNUSB2.0,RTL8852BEPCIEanduart SupplyVoltage5V±0.5V Dimension 200.0×190.0×8.3mm(Tolerance±0.3mm) OperatingTemperature-10°Cto70°C StorageTemperature-40°Cto80°C 3.RFoutputpower BandLimitedpower WLAN MT7663BUN： 2400-2483.5MHz;5170-5330MHz； 5490-5710MHz;5735-5835MHz RTL8852BE-VR-CG 2400-2483.5MHz;5170-5330MHz； 5490-5710MHz;5735-5835MHz <20dBm 4.ThedisplaymethodofModelapprovedcode Inthefactory,themodelapprovalcodeisdisplayedonthePCBboardthroughsilkscreenprinting. 5.FCCStatement ThisequipmenthasbeentestedandfoundtocomplywiththelimitsforaClassBdigitaldevice,pursuanttopart15ofthe FCCrules.Theselimitsaredesignedtoprovidereasonableprotectionagainstharmfulinterferenceinaresidential installation.Thisequipmentgenerates,uses,andcanradiateradiofrequencyenergyandifnotinstalledandusedin accordancewiththeinstructionsmaycauseharmfulinterferencetoradiocommunications.Howeverthereisno guaranteethatinterferencewillnotoccurinaparticularinstallation.Ifthisequipmentdoescauseharmfulinterferenceto radioortelevisionreception,whichcanbedeterminedbyturningtheequipmentoffandon,theuserisencouragedtotry tocorrecttheinterferencebyoneormoreofthefollowingmeasures： Reorientorrelocatethereceivingantenna. Increasetheseparationbetweentheequipmentandreceiver. Connecttheequipmentintoanoutletonacircuitdifferentfromthattowhichthereceiverisconnected. Consultthedealeroranexperiencedradio/TVtechnicianforhelp. Thisdevicecomplieswithpart15oftheFCCRules.Operationissubjecttothefollowingtwoconditions: (1)Thisdevicemaynotcauseharmfulinterference,and(2)thisdevicemustacceptanyinterference received,includinginterferencethatmaycauseundesiredoperation. 6.RadiationExposureStatement ThisequipmentcomplieswithFCCradiationexposurelimitssetforthforanuncontrolledenvironmentanditalso complieswithPart15ofFCCRFRules.Thisequipmentshouldbeinstalledandoperatedwithminimumdistanceof20in (50cm)betweentheradiatorandyourbody.Thistransmittermustnotbeco-locatedoroperatedinconjunctionwithany otherantennaortransmitter CAUTION: TocomplywiththelimitsoftheClassBdigitaldevicepursuanttoPart15oftheFCCRules,thisdeviceiscompliantwith ClassBlimits.Allperipheralsmustbeshieldedandgrounded.Operationwithnon-certifiedperipheralsornon-shielded cablesmayresultsininterferencetoradioorreception MODIFICATION Toassurecontinuedcompliance,Anychangesormodificationsnotexpresslyapprovedbythegranteeofthisdevice couldvoidtheusersauthoritytooperatethedevice. 7.RadiationExposureStatement ThisequipmentcomplieswithICradiationexposurelimitssetforthforanuncontrolledenvironment.Thisequipment shouldbeinstalledandoperatedwithminimumdistanceof50cm(8in)betweentheradiatorandyourbodyNOTETo satisfyFCCexteriorlabelingrequirements,thefollowingtextmustbeplacedontheexterioroftheendproductContains TransmittermoduleFCCID:****TosatisfyIESDexteriorlabelingrequirements,thefollowingtextmustbeplacedonthe exterioroftheendproduct"ContainsTransmittermoduleIC:******* Thissymbolontheproductoronitspackagingindicatesthatthisproductmustnotbedisposedofwith yourhouseholdwaste.Instead,itisyourresponsibilitytodisposeofyourwasteequipmentbyhandingitovertoa designatedcollectionpointfortherecyclingofwasteelectricalandelectronicequipment.Theseparatecollectionand recyclingofyourwasteequipmentatthetimeofdisposalwillhelptoconservenaturalresourcesandensurethatitis recycledinamannerthatprotectshumanhealthandtheenvironment.Formoreinformationaboutwhereyoucan dropoffyourwasteequipmentforrecycling,pleasecontactyourlocalcityoffice,yourhouseholdwastedisposal serviceortheshopwhereyoupurchasedtheproduct. Thedeviceisrestrictedtoindooruseonlywhenoperatinginthe5150to5350MHzfrequencyrange. 8.ICStatement i、whereapplicable,antennatype(s),antennamodels(s),andworst-casetiltangle(s)necessarytoremaincompliantwith thee.i.r.p.elevationmaskrequirementsetforthinsection6.2.2.3shallbeclearlyindicated. ThisdevicecomplieswithIndustryCanada’slicence-exemptRSSs.Operationissubjecttothefollowingtwo conditions: "Operationissubjecttothefollowingtwoconditions:(1)thisdevicemaynotcauseinterference,and(2)thisdevice mustacceptanyinterference,includinginterferencethatmaycauseundesiredoperationofthedevice." LeprésentappareilestconformeauxCNRd’IndustrieCanadaapplicablesauxappareilsradioexemptsdelicence.L’ exploitationestautoriséeauxdeuxconditionssuivantes: 1)l’appareilnedoitpasproduiredebrouillage; 2)l’appareildoitacceptertoutbrouillageradioélectriquesubi,mêmesilebrouillageestsusceptibled’en compromettrelefonctionnement. Manufacturer:QingdaoIntelligent&PreciseElectronicsCo.,Ltd. Address:No.218QianwangangRoad,QingdaoEconomic&TechnologicalDevelopment Zone,QingdaoCity,ShandongProvince,P.R.China Importers: HisenseFranceSAS Address:9Ruedes3Soeurs,93420Villepinte,France HisenseIberia,S.L.U Address:RondaAugusteyLouisLumiere.23Nave12.EdificioLumiere-Parque Tecnológico46980 Paterna(Valencia)-Spain HisenseItaliaS.r.l Address:ViaMontefeltro,6/A,20156MILANO HisenseSouthAfrica Address:TheEstuaries,Building17OxbowCrescent,CenturyCity,CapeTown,SouthAfrica Warning： Withoutapproval,companies,businesses,orusersarenotallowedtochangethefrequency, increasepower,orchangethecharacteristicsandfunctionsoftheoriginaldesignof low-powerRFequipmentthathasobtainedtheverificationcertificate. Theuseoflow-powerRFequipmentshallnotaffectflightsafetyorinterferewithlegitimate communication;Wheninterferenceisfound,itshouldbeimmediatelystoppedand improveduntilthereisnointerferencebeforecontinuingtouse. Legalcommunicationreferstowirele…

Text truncated - open the document above for the full version.

QingdaoIntelligent&PreciseElectronicsCo.,Ltd. To:FederalCommunicationsCommissionDate:2024/01/29 7435OaklandMillsRoad Columbia,MD21046 USA Attestation Section2.911(d)(5)(i)andSection2.911(d)(5)(ii) (KDB986446D01CoveredEquipment) Section2.911(d)(5)(i) QingdaoIntelligent&PreciseElectronicsCo.,Ltd.(“theapplicant”)certifiesthatthe equipmentforwhichauthorizationissoughtisnot“covered”equipmentprohibited fromreceivinganequipmentauthorizationpursuanttosection2.903oftheFCC rules. Section2.911(d)(5)(ii) QingdaoIntelligent&PreciseElectronicsCo.,Ltd.(“theapplicant”)certifiesthat,as ofthedateofthefilingoftheapplication,theapplicantisnotidentifiedonthe CoveredListasanentityproducing“covered”equipment. TypeofEquipmentsubjecttoFCCCertification: FCCID:2AJVQ-MWH630B Ifyouhaveanyquestions,pleasefeelfreetocontactme ContactPerson:WangHaining PositionintheCompany:CertificationManager DateofSignature:2024/01/29 ___________________________ Signatory (signatureoftheapplicant)

V02072023 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 Qingdao Intelligent&Precise Electronics Co., Ltd USA Qingdao Intelligent&Precise Electronics Co., Ltd. FCC FRN: Date: 2024.01.29 Ref: Attestation Statement Part 2.911(d)(7) Filing FCC ID:2AJVQ-MWH630B Qingdao Intelligent&Precise Electronics Co., Ltd.certifies that, as of the dates of this application, Americas Compliance Consulting LLC dba iCertifi “iCertifi” is our designated U.S. agent for service of process for the above referenced FCC ID. Qingdao Intelligent&Precise Electronics Co., Ltd.accepts to maintain an agent for no less than one year after the grantee has terminated all marketing and importation or the conclusion of any commission-related proceeding involving the equipment. iCertifi accepts, as of the date of the filing of the application, the obligation of the designated U.S. agent for service process for the above referenced FCC ID. Designated U.S. Agent Information: Name: Americas Compliance consultingLLC dba iCertifi FCC FRN: 0033399411 Address: 2445NE Division St, ste 202 Bend, OR 97703 United States Contact Person:PaulA Preston Tel: 866-885-4575 Email: [email protected] Sincerely, 0025785783 Americas Compliance Consulting LLC dba iCertifi Wang Haining Paul A Preston Signature

The Description of No software version on MWH630B Hisense MWH630B wireless model is a highly integrated single-chip that support 2-stream 802.11n solutions with MIMO (Multiple-Input, Multiple-Output) with Wireless LAN (WLAN) USB2.0 and PCIE&uart network interface controller，which is designed for communicating with intelligent terminal products like TV etc. It just transfers the data from model to intelligent terminal by USB2.0 、PCIE&uart and some control signals as the transmission function module only. The software development is all in the TV terminal, and the WiFi module only has data transmission function, so the module itself has no software version, and the working mechanism is similar to the camera module of mobile phone products. That’s stated above all. Qingdao Intelligent&Precise Electronics Co.,Ltd. 2024-03-07

Qingdao Intelligent&Precise Electronics Co.,Ltd. No.218 Qianwangang Road, Qingdao Economic & Technological Development Zone, Qingdao City, Shandong Province, P. R. China Authorization Letter Date: March 7, 2024 To whom it may concern: We, the undersigned, hereby authorize The State Radio_monitoring_center Testing Center (SRTC) to act on our behalf, as our agent, in the following matters related to the RED Directive approval of our product: Product Name: WIFI/BT Module Product Model: MWH630B FCC ID: 2AJVQ-MWH630B Report submittal, related correspondence, the signing of all documents relating to these matters, and any other lawful activity necessary to obtain such certification. Any act carried out by The State Radio_monitoring_center Testing Center (SRTC) within the scope of this authorization shall have the same effects as our own. This authorization shall expire 2 months from original date. If you have any question regarding the authorization, please don’t hesitate to contact with me. Thank you. Sincerely, Wang Haining Qingdao Intelligent&Precise Electronics Co.,Ltd. No.218 Qianwangang Road, Qingdao Economic & Technological Development Zone, Qingdao City, Shandong Province, P. R. China

Qingdao Intelligent&Precise Electronics Co.,Ltd. No.218 Qianwangang Road, Qingdao Economic & Technological Development Zone, Qingdao City, Shandong Province, P. R. China PHOENIX TESTLAB GmbH Date: 8 March 2024 Product Certification Königswinkel 10 D 32825 Blomberg Subject: Declaration Operating Channel Limitation Product Name:WIFI/BT Module Product Model: MWH630B FCC ID: 2AJVQ-MWH630B To Whom it may concern, The operating channels in 802.11 b/g/n mode for the device marketed to the US/Canada are firmware limited to channel 1 ~ 11 (2412 ~ 2462 MHz). The end- user has no possibility to select any other operating channels. If you have any questions, please feel free to contact me. Thank you. Sincerely Wanghaining Qingdao Intelligent&Precise Electronics Co.,Ltd. No.218 Qianwangang Road, Qingdao Economic & Technological Development Zone, Qingdao City, Shandong Province, P. R. China

UNIIDeclarationLetter WehavedeclaredbelowfeaturedforFCCequipmentauthorization,deviceFCCID:2AJVQ-MWH630B (1)DFSDevice--Master,ClientwithRadardetectioncapability, Clientwithoutradardetectioncapability,N/A (2)Active/PassiveScanning,adhocmodeaccesspointcapability FrequencyBand (MHz) ActiveScanning (thedevicecan transmitaprobe (beacon)) passivescanning (wherethedevice is canlistenonly withno probes) AdHocMode capability Accesspoint capability 2412–2462MHzYes,NoYes,NoYes,NoYes,No 2422–2452MHzYes,NoYes,NoYes,NoYes,No 5745–5825MHzYes,NoYes,NoYes,NoYes,No 5755–5795MHzYes,NoYes,NoYes,NoYes,No 5180–5240MHzYes,NoYes,NoYes,NoYes,No 5190–5230MHzYes,NoYes,NoYes,NoYes,No 5260–5320MHzYes,NoYes,NoYes,NoYes,No 5270–5310MHzYes,NoYes,NoYes,NoYes,No 5500–5700MHzYes,NoYes,NoYes,NoYes,No 5510–5670MHzYes,NoYes,NoYes,NoYes,No (3)Countrycodeselectionability-Yes,No Ifno,plsexplainhowwasimplemented:useMicrosoftnetworkutility (4)Meet15.202requirement-Yes,No, plscheckbelow: Amasterdeviceisdefinedasadeviceoperatinginamodeinwhichithasthecapabilitytotransmitwithout receivinganenablingsignal.Inthismodeitisabletoselectachannelandinitiateanetworkbysendingenabling signalstootherdevices Aclientdeviceisdefinedasadeviceoperatinginamodeinwhichthetransmissionsofthedeviceareunder controlofthemaster.Adeviceinclientmodeisnotabletoinitiateanetwork. (5)Forclientdevicesthathavesoftwareconfigurationcontroltooperateindifferentmodes(activescanningin someandpassivescanninginothers)indifferentbands(deviceswithmultipleequipmentclassesorthosethat operateonnon-DFSfrequencies)ormodulardeviceswhichconfigurethemodesofoperationsthroughsoftware, theapplicationmustprovidesoftwareandoperationsdescriptiononhowthesoftwareand/orhardwareis implementedtoensurethatproperoperationsmodescannotbemodifiedbyenduseroraninstaller. Apply,NoApply, (Ifapply,plshelptoprovideexplanationonhowitwasimplement(Byhardwareorsoftware,andhowsoftwarewascontrolled) Applicant:QingdaoIntelligent&PreciseElectronicsCo.,Ltd. Address:No.218QianwangangRoad,QingdaoEconomic&TechnologicalDevelopmentZone, QingdaoCity,ShandongProvince,P.R.China Signature: Name:WangHaining Date:2024-3-7

Qingdao Intelligent&Precise Electronics Co., Ltd. No.218 Qianwangang Road, Qingdao Economic & Technological Development Zone, Qingdao City, Shandong Province, P. R. China PHOENIX TESTLAB GmbH Product Certification Königswinkel 10 D 32825 Blomberg Date: March 7, 2024 Subject:PART 15 UNLICENSED MODULAR TRANSMITTER APPROVAL To Whom It May Concern: We,Qingdao Intelligent & Precise Electronics Co., Ltd., here by requests for part 15 unlicensed modular transmitter approval of our device, described as follows: Brand name: Hisense Model name: MWH630B FCC ID: 2AJVQ-MWH630B In FCC Public Notice DA 00-1407 released June 26,2000 there are eight numbered requirements that our device complies with: 1. The modular transmitter must have its own shielding. Yes,it has a metal shielding. 2. The modular transmitter must have buffered modulation/data inputs Yes,it has a buffer for modulation and data input.The highly integrate single-chip is MT7663BUN&RTL8852BE 3. The modular transmitter must have its own power supply regulation Yes,it has a power supply regulation for transmitter inside the chip. 4. The modular transmitter must comply with the antenna requirements of Section 15.203 and 15.204c Yes, WiFi antenna are pcb antenna on the module board by pcbtrace. 5. The modular transmitter must be tested in a stand-alone configuration Qingdao Intelligent&Precise Electronics Co., Ltd. No.218 Qianwangang Road, Qingdao Economic & Technological Development Zone, Qingdao City, Shandong Province, P. R. China Yes,it has been tested in a stand-alone configuration ,not inside another device . 6. The modular transmitter must be labelled with its own FCC ID number Yes,FCC ID: 2AJVQ-MWH630B 7. The modular transmitter must comply with any specific rule or operating requirements applicable to the transmitter and the manufacturer must provide adequate instructions along with the module to explain any such requirements. Yes, our module has complied the FCC spec and operating requirements . The manufacturer has corresponding module installation instructions. 8. The modular transmitter must comply with any applicable RF exposure requirements. Yes,our module has detailed application notes for users,installers and other interested parties to ensure that it comply with any applicable RF exposure requirements . Qingdao Intelligent&Precise Electronics Co.,Ltd. No.218 Qianwangang Road, Qingdao Economic & Technological Development Zone, Qingdao City, Shandong Province, P. R. China Yours sincerely， Signatory Name: Wang Haining Job Title: Certification Manager

Qingdao Intelligent&Precise Electronics Co.,Ltd. No.218 Qianwangang Road, Qingdao Economic & Technological Development Zone, Qingdao City, Shandong Province, P. R. China Request of Confidentiality Federal Communications Commission Authorization and Evaluation Division Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, the Applicant hereby requests confidential treatment of information accompanying of following product: Product Name:WIFI/BT Module Product Model: MWH630B FCC ID: 2AJVQ-MWH630B The following information should be held confidential: All Schematics/block diagrams/BOM All Parts list for the above schematic diagram Operational description and technical overview of product The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Rule 0.457, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Certification Manager Qingdao Intelligent&Precise Electronics Co.,Ltd. No.218 Qianwangang Road, Qingdao Economic & Technological Development Zone, Qingdao City, Shandong Province, P. R. China

ExternalPhoto MWH630B 1/1 1、模组尺寸正面 2、模组尺寸背面

CMIIT ID:XXXXXXXXXXX 0000-000000-00000000- ZDJG9030RA0-YYMDD00001 5.2 5.2 SN:XXXXXXX 7.25 20mm 12mm 20mm 6mm 30mm 200mm

InternalPhoto MWH630B 1/1 1、模组正面尺寸 2、模组背面尺寸

Certificate#5505.02 MPEREPORT ReportNo.: SRTC2024-9004(F)-24012204(I) ProductName: WiFi/BTModule ModelName: MWH630B Applicant: QingdaoIntelligent&PreciseElectronicsCo.,Ltd. Manufacturer: QingdaoIntelligent&PreciseElectronicsCo.,Ltd. FCCID: 2AJVQ-MWH630B ReferenceSpecification FCCPart§1.1310 TheStateRadio_monitoring_centerTestingCenter(SRTC) 15thBuilding,No.30,ShixingStreet,ShijingshanDistrict, Beijing,P.R.China Tel:86-10-57996183Fax:86-10-57996388 No.:SRTC2024-9004(F)-24012204(I) TheStateRadio_monitoring_centerTestingCenter(SRTC)Pagenumber: 1 of6 Tel:86-10-57996183 Fax:86-10-57996388V3.0.0 CONTENTS 1GENERALINFORMATION.......................................................................................................................................2 1.1NOTESOFTHETESTREPORT.....................................................................................................................................2 1.2INFORMATIONABOUTTHETESTINGLABORATORY.....................................................................................................2 1.3APPLICANT’SDETAILS .................................................................................................................................................2 1.4MANUFACTURER’SDETAILS........................................................................................................................................2 1.5TESTENVIRONMENT...................................................................................................................................................3 2DESCRIPTIONOFTHEDEVICEUNDERTEST ...................................................................................................4 2.1FINALEQUIPMENTBUILDSTATUS.............................................................................................................................4 3REFERENCESPECIFICATION...............................................................................................................................6 4RESULTSUMMARY.................................................................................................................................................6 5.CALCULATIONRESULT ..........................................................................................................................................7 5.1MAXIMUMPERMISSIBLEEXPOSURE(MPE)...............................................................................................................7 No.:SRTC2024-9004(F)-24012204(I) TheStateRadio_monitoring_centerTestingCenter(SRTC)Pagenumber: 2 of6 Tel:86-10-57996183 Fax:86-10-57996388V3.0.0 1GENERALINFORMATION 1.1Notesofthetestreport Thetestreportmayonlybereproducedorpublishedinfull.Reproductionorpublicationofextracts fromthereportrequiresthepriorwrittenpermissionofTheStateRadio_monitoring_centerTesting Center(SRTC).Thetestresultsrelateonlytoindividualitemsofthesampleswhichhavebeen tested.Thecertificationandaccreditationidentifiersusedinthisreportshallnotbeapplicabletothe testedorcalibratedsamplesthereof.Themanufacturershallnotmarkthetestedsamplesoritems (oraseparatepartoftheitem)withtheidentifiersofcertificationandaccreditationtomislead relevantpartiesaboutthetestedsamplesoritems. 1.2Informationaboutthetestinglaboratory Company:TheStateRadio_monitoring_centerTestingCenter(SRTC) TestSite1:15thBuilding,No.30ShixingStreet,ShijingshanDistrict TestSite2:No.80,Zhaojiachang,Beizang,DaxingDistrict City:Beijing CountryorRegion:P.R.China Contactedperson:LiuJia Tel:+861057996183 Fax:+861057996388 Email:[email protected] DesignationNumber:CN1267 Registrationnumber:239125 1.3Applicant’sdetails Company:QingdaoIntelligent&PreciseElectronicsCo.,Ltd. Address: No.218QianwangangRoad,QingdaoEconomic&Technological DevelopmentZone,QingdaoCity,ShandongProvince,P.R.China 1.4Manufacturer’sdetails Company:QingdaoIntelligent&PreciseElectronicsCo.,Ltd. Address: No.218QianwangangRoad,QingdaoEconomic&Technological DevelopmentZone,QingdaoCity,ShandongProvince,P.R.China No.:SRTC2024-9004(F)-24012204(I) TheStateRadio_monitoring_centerTestingCenter(SRTC)Pagenumber: 3 of6 Tel:86-10-57996183 Fax:86-10-57996388V3.0.0 1.5TestEnvironment DateofReceiptoftestsampleatSRTC:2024-01-23 TestingStartDate: 2024-01-24 TestingEndDate: 2024-03-07 EnvironmentalData:Temperature(°C)Humidity(%) Ambient2540 MaximumExtreme70--- MinimumExtreme-10--- NormalSupplyVoltage(Vd.c.):5.0 MaximumExtremeSupplyVoltage(Vd.c.):5.5 MinimumExtremeSupplyVoltage(Vd.c.):4.5 No.:SRTC2024-9004(F)-24012204(I) TheStateRadio_monitoring_centerTestingCenter(SRTC)Pagenumber: 4 of6 Tel:86-10-57996183 Fax:86-10-57996388V3.0.0 2DESCRIPTIONOFTHEDEVICEUNDERTEST 2.1FinalEquipmentBuildStatus BT FrequencyRange:2.402GHz~2.480GHz NumberofChannel:79 ModulationType:GFSK,π/4DQPSK,8DPSK DuplexMode:TDD ChannelSpacing:1MHz DataRate:1Mbps,2Mbps,3Mbps PowerSupply:DCsupply Antennagain:-2.69dBi SoftwareRevision:NA HardwareRevision:V1.00 IMEI:NA Antennatype: Slot BLE FrequencyRange:2.402GHz~2.480GHz NumberofChannel:40 ModulationType:GFSK EquipmentClass:DTS ChannelSpacing:2MHz DataRate: LE1Mbps/2MbpsCoded500K/Coded125K PowerSupply:DCsupply Antennagain:-2.69dBi SoftwareRevision:NA HardwareRevision:V1.00 IMEI:NA Antennatype: Slot Wi-Fi2.4G FrequencyBand:2.412GHz~2.462GHz No.:SRTC2024-9004(F)-24012204(I) TheStateRadio_monitoring_centerTestingCenter(SRTC)Pagenumber: 5 of6 Tel:86-10-57996183 Fax:86-10-57996388V3.0.0 NumberofChannelFor20MHz: 11 NumberofChannelFor40MHz: 7 ModulationType: 802.11b 802.11g 802.11n(HT20/HT40) 802.11ax(HE20/HE40) PowerSupply:DCsupply Antennagain:2.52dBi(max) DirectionalGain:NA SoftwareRevision:NA HardwareRevision:V1.00 IMEI:NA Antennatype:InvertedFAntenna Wi-Fi5G FrequencyBand(s): U-NII-1:5150MHz-5250MHz U-NII-2A:5250MHz-5350MHz U-NII-2C:5470MHz-5725MHz U-NII-3:5725MHz-5850MHz TheDFSrelatedoperating mode(s)oftheequipment: □Master □Slavewithradardetection  Slavewithoutradardetection ModulationType: 802.11a 802.11n(HT20/HT40) 802.11ac(VHT20/VHT40/VHT80) 802.11ax(HE20/HE40/HE80) AntennaType:I…

Text truncated - open the document above for the full version.

MWH630B Antenna Test Report 2024.01.09 1 ANT Property WiFi0 WiFi1 BT WiFi0 Antenna Type IFA Antenna Input 50 Ω Frequency 2.4~2.5GHz/5.15~5.85GHz Return Loss 2.4GHz~2.5GHz ： S11 ≤ -10dB 5.15GHz~5.85GHz ： Peak Gain [email protected]~2.5GHz , [email protected]~5.85GHz Efficiency 2.4~2.5GHz ≥ 50%(Avg) , 5.15~5.85GHz ≥ 50%(Avg) WiFi1 Antenna Type IFA Antenna Input 50 Ω Frequency 2.4~2.5GHz/5.15~5.85GHz Return Loss 2.4GHz~2.5GHz ： S11 ≤ -10dB 5.15GHz~5.85GHz ： Peak Gain [email protected]~2.5GHz , [email protected]~5.85GHz Efficiency 2.4~2.5GHz ≥ 45%(Avg) , 5.15~5.85GHz ≥ 45%(Avg) Qingdao Intelligent & Precise Electronics Co., Ltd. BT Antenna Type Slot Antenna Input 50 Ω Frequency 2.4~2.5GHz Return Loss S11 ≤ -3dB Peak Gain -2.69dBi Efficiency ≥ 25%(Avg) 2 ANT Property WiFi2 WiFi3 WiFi2 Antenna Type IFA Antenna Input 50 Ω Frequency 2.4~2.5GHz/5.15~5.85GHz Return Loss 2.4GHz~2.5GHz ： S11 ≤ -10dB 5.15GHz~5.85GHz ： Peak Gain [email protected]~2.5GHz , [email protected]~5.85GHz Efficiency 2.4~2.5GHz ≥ 50%(Avg) , 5.15~5.85GHz ≥ 50%(Avg) WiFi3 Antenna Type IFA Antenna Input 50 Ω Frequency 2.4~2.5GHz/5.15~5.85GHz Return Loss 2.4GHz~2.5GHz ： S11 ≤ -10dB 5.15GHz~5.85GHz ： Peak Gain [email protected]~2.5GHz , [email protected]~5.85GHz Efficiency 2.4~2.5GHz ≥ 45%(Avg) , 5.15~5.85GHz ≥ 45%(Avg) Qingdao Intelligent & Precise Electronics Co., Ltd. 3 L Band M Ban d H Band Wifi0 5GWifi0 2.4G ANT Directivity Pattern Qingdao Intelligent & Precise Electronics Co., Ltd. 4 L Band M Ban d H Band Wifi1 5GWifi1 2.4G ANT Directivity Pattern Qingdao Intelligent & Precise Electronics Co., Ltd. 5 L Band M Ban d H Band Wifi2 5GWifi2 2.4G ANT Directivity Pattern Qingdao Intelligent & Precise Electronics Co., Ltd. 6 L Band M Ban d H Band Wifi3 5GWifi3 2.4G ANT Directivity Pattern Qingdao Intelligent & Precise Electronics Co., Ltd. 7 L Band M Ban d H Band BT ANT Directivity Pattern Qingdao Intelligent & Precise Electronics Co., Ltd. 8 Qingdao Intelligent & Precise Electronics Co., Ltd. ANT Manufacturer Qingdao Intelligent & Precise Electronics Co., Ltd.Address: Hisense Infor. Industrial Park Economic Technology Dev . District Contact information: [email protected] 18354225910 THANKS

Certificate#5505.02 TESTREPORTFOR BLUETOOTHTESTING ReportNo.:SRTC2024-9004(F)-24012204(D) ProductName:WiFi/BTModule ProductModel:MWH630B Applicant:QingdaoIntelligent&PreciseElectronicsCo.,Ltd. Manufacturer:QingdaoIntelligent&PreciseElectronicsCo.,Ltd. Specification:FCCPart15SubpartC(2022) FCCID：2AJVQ-MWH630B TheStateRadio_monitoring_centerTestingCenter(SRTC) 15thBuilding,No.30ShixingStreet,ShijingshanDistrict,Beijing,P.R.China Tel:86-10-57996183Fax:86-10-57996388 No.:SRTC2024-9004(F)-24012204(D) FCCID:2AJVQ-MWH630B TheStateRadio_monitoring_centerTestingCenter(SRTC)Pagenumber: 1 of 73 Tel:86-10-57996183 Fax:86-10-57996388V3.0.0 CONTENTS 1.GENERALINFORMATION .....................................................................................................................................2 1.1NOTESOFTHETESTREPORT .....................................................................................................................................2 1.2INFORMATIONABOUTTHETESTINGLABORATORY.....................................................................................................2 1.3APPLICANT’SDETAILS.................................................................................................................................................2 1.4MANUFACTURER’SDETAILS ........................................................................................................................................2 1.5TESTENVIRONMENT...................................................................................................................................................3 2DESCRIPTIONOFTHEDEVICEUNDERTEST...................................................................................................3 2.1FINALEQUIPMENTBUILDSTATUS .............................................................................................................................3 2.2DESCRIPTIONOFTESTMODES ...................................................................................................................................4 2.2.1TESTMODEAPPLICABILITYANDTESTEDCHANNELDETAIL.................................................................................4 2.3DUTYCYCLEOFTESTSIGNAL...................................................................................................................................6 2.4EUTOPERATINGCONDITIONS ....................................................................................................................................6 2.5SUPPORTEQUIPMENT................................................................................................................................................6 3REFERENCESPECIFICATION...............................................................................................................................6 4KEYTONOTESANDRESULTCODES ................................................................................................................6 5RESULTSUMMARY .................................................................................................................................................7 6TESTRESULT...........................................................................................................................................................9 7MEASUREMENTUNCERTAINTIES.....................................................................................................................22 8TESTEQUIPMENTS ...............................................................................................................................................23 APPENDIXA–TESTDATAOFCONDUCTEDEMISSION.................................................................................25 APPENDIXB–TESTDATAOFRADIATEDEMISSION.......................................................................................45 No.:SRTC2024-9004(F)-24012204(D) FCCID:2AJVQ-MWH630B TheStateRadio_monitoring_centerTestingCenter(SRTC)Pagenumber: 2 of 73 Tel:86-10-57996183 Fax:86-10-57996388V3.0.0 1.GENERALINFORMATION 1.1Notesofthetestreport Thetestreportmayonlybereproducedorpublishedinfull.Reproductionorpublicationofextracts fromthereportrequiresthepriorwrittenpermissionofTheStateRadio_monitoring_centerTesting Center(SRTC).Thetestresultsrelateonlytoindividualitemsofthesampleswhichhavebeentested. Thecertificationandaccreditationidentifiersusedinthisreportshallnotbeapplicabletothetested orcalibratedsamplesthereof.Themanu…
