2AJYB-S1955Network Audio Streaming Module

2AJYB-S1955 FCC IC Instruction For Use_20200110.docx January 10, 2020 Page 6 of 11 StreamUnlimited Engineering GmbH Gutheil-Schoder-G. 10, 1100 Vienna, Austria T +43-1-667 2002, F +43-1-667 2002 4401 3.1 Product labelling requirements Product label must contain following text: “contains FCC ID: 2AJYB-S1955” “contains IC: 20504-S1955” See below example for reference 3.2 Instruction for use requirements Instructions for use must contain warnings and customer information, see next two pages for detailed text Declaration of Conformity This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. This product does not contain any user serviceable components. Any unauthorized product changes or modifications will invalidate warranty and all applicable regulatory certifications and approvals, including authority to operate this device. Warning This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: ∑ Reorient or relocate the receiving antenna. ∑ Increase the separation between the equipment and receiver. ∑ Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. ∑ Consult the dealer or an experienced radio /TV technician for help. Caution: Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. 2AJYB-S1955 FCC IC Instruction For Use_20200110.docx January 10, 2020 Page 7 of 11 StreamUnlimited Engineering GmbH Gutheil-Schoder-G. 10, 1100 Vienna, Austria T +43-1-667 2002, F +43-1-667 2002 4401 Operations in the 5.15 – 5.25GHz band are restricted to indoor usage only. RF Exposure Requirements To comply with FCC requirements, a minimum separation distance of 20cm (8 inches) is required between the equipment and the body of the user or nearby persons. Canada: This Class B digital apparatus complies with Canadian ICES-003 and RSS-247. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation. The installer of this radio equipment must ensure that the product is located such that it does not emit RF field in excess of Health Canada limits for the general population: consult Safety Code 6, obtainable from Health Canada ́s We site www.hc-sc.gc.ca/rpb. As mentioned before, the installer cannot control the antenna orientation. However, they could place the complete product in a way that causes the problem mentioned above. The device for operation in the band 5150-5250 MHz is only for indoor use to reduce the potential for harmful interference to co-channel mobile satellite systems. Be advices that high-power radars are allocated as primary users (i.e. priority users) of the bands 5250-5350MHz and 5650-5850MHz and that these radars could cause interference and/or damage to LE-LAN devices. Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. Cet appareil numérique de classe B est conforme aux normes NMB-003 et CNR-247 en vigueur au Canada. Son fonctionnnement est soumis aux deux conditions suivantes : (1) Cet appareil ne doit pas créer d'interférences nuisibles. (2) Cet appareil doit tolérer toutes les interférences reçues, y compris les interférences pouvant entraîner un fonctionnement indésirable. L'installateur du présent matériel radio doit veiller à ce que le produit soit placé ou orienté de manière à n'émettre aucun champ radioélectrique supérieur aux limites fixées pour le grand public par le ministère fédéral Santé Canada ; consultez le Code de sécurité 6 sur le site Web de Santé Canada à l'adresse : www.hc-sc.gc.ca/rpb. Comme indiqué auparavant, l'installateur ne peut pas contrôler l'orientation de l'antenne. Il peut néanmoins placer le produit tout entier de manière à provoquer le problème décrit ci-dessus. Les dispositifs fonctionnant dans la bande 5150-5250 MHz sont réservés uniquement pour une utilisation à l'intérieur afin de réduire les risques de brouillage préjudiciable aux systèmes de satellites mobiles utilisant les mêmes canaux. Les utilisateurs de radars de haute puissance sont désignés utilisateurs principaux (c.-à-d., qu'ils ont la priorité) pour les bandes 5250-5350 MHz et 5650-5850 MHz et que ces radars pourraient causer du brouillage et/ou des dommages aux dispositifs LAN-EL.

Coverletter: StreamUnlimited Engineering GmbH wants to get FCC-Certification for the following product: WiFi and Bluetooth Audio Streaming Module. The unit will get the following FCC-ID: 2AJYB-S1955 List of documents: Exhibit Thema File Exhibit 01 Label and placement Stream1955 label template.pdf Exhibit 02 Not needed -------------------- Exhibit 03 External Photos extern_19-198.pdf * Exhibit 04 Block Diagrams 2AJYB-S1955 block diagram.pdf AP6398S_BLOCK DIAGRAM.pdf * Exhibit 05 Schematic Diagrams 2AJYB-S1955 Schematics.pdf AP6398S_SCH_20191223.pdf Exhibit 06 Testreport FG19-195_signed_2x.pdf FG19-196_signed_2x.pdf FG19-197_signed_2x.pdf FG19-198_part1.pdf FG19-198_part2.pdf FG19-198_part3.pdf Exhibit 07 Test Set-up Photos setup_19-198.pdf Exhibit 08 User Manual 2AJYB-S1955-Instructions-For-Use_labelling requirements.pdf Exhibit 09 Internal Photos intern_19-198.pdf Exhibit 10 Informations -------------------- Exhibit 11 RF exposure -------------------- * Exhibit 12 Operational Description 2AJYB-S1955 WiFi RF module description.pdf 2AJYB-S1955-Instructions-For-Use.pdf 2AJYB-S1955-list-of-certified-antennas.pdf Exhibit 13 Cover letter Request for confidentiality This file 2AJYB-S1955 Confidentiality request.pdf For the Exhibits marked with ‘*’ StreamUnlimited Engineering GmbH requested Confidentiality according to 47 CFR 0.457 and 0.459 of the FCC rules because these are sensitive parts owned by this company and include much of Know-How or sensitive data, it will not be provided to the public. The labelling on some photos may be not the actual status. The correct labelling you can see on the label photo in Exhibit 1.

www.tuv.at | [email protected] | TÜV ® Appendix 2 Photodocumentation Description: Module on test board Division: Industry & Energy Department: FG Test report reference: INE-AT/FG-19/198 Page: 4 of 8 Date: 02.12.2019 www.tuv.at | [email protected] | TÜV ® Appendix 2 Photodocumentation Description: Module on test board with additional shielding and antennas connected Division: Industry & Energy Department: FG Test report reference: INE-AT/FG-19/198 Page: 5 of 8 Date: 02.12.2019

Template for label Model: Stream1955 Version: *44 E-MAC: 501E2DXXXXXX FCC ID: 2AJYB-S1955 IC: 20504-S1955

www.tuv.at | [email protected] | TÜV ® Appendix 2 Photodocumentation Description: Module view #1 Division: Industry & Energy Department: FG Test report reference: INE-AT/FG-19/198 Page: 1 of 8 Date: 02.12.2019 www.tuv.at | [email protected] | TÜV ® Appendix 2 Photodocumentation Description: Module view #2 Division: Industry & Energy Department: FG Test report reference: INE-AT/FG-19/198 Page: 2 of 8 Date: 02.12.2019 www.tuv.at | [email protected] | TÜV ® Appendix 2 Photodocumentation Description: RF shielding detached Division: Industry & Energy Department: FG Test report reference: INE-AT/FG-19/198 Page: 3 of 8 Date: 02.12.2019

ww w.tu v.at | [email protected] | TÜV ® ww w.tu v.at | office@tuv .a QFM-EMV-FG_Protokoll Rev.00 / FG19-195.doc Page 1 of 42 02.12.2019 TEST REPORT of the accredited test laboratory TÜV Nr.:INE-AT/FG-19/195 Applicant: StreamUnlimited Engineering GmbH High Tech Campus Vienna Gutheil-Schoder-Gasse 10 A-1100 Vienna Tested Product: STREAM1955 Bluetooth / BLE / WIFI streaming module Test report for Bluetooth part only FCC-ID: 2AJYB-S1955 IC-ID: 20504-S1955 Manufacturer: See applicant Output power / field strength: 4,57 mW conducted power supply: 12 VDC Frequency range: 2402 - 2480 MHz Channel separation: 1 MHz Standard: FCC: 47 CFR Part 15 (October 1, 2018 edition) RSS-247 Issue 2, February 2017 TUV Austria Services GmbH Test laboratory for EMC Supervisor of EMC-laboratory: Ing. Wilhelm Seier Rundsiegel 02.12.2019 checked by: Ing. Michael Emminger A publication of this test report is only permitted literally. Copying or reproduction of partial sections needs a written permission of TUV Austria Services GmbH. The results of this test report only refer to the provided equipment. TÜV AUSTRIA SERVICES GMBH Office: Deutschstrasse 10 1230 Vienna/Austria T: +43 5 0454-0 F: +43 5 0454-6505 E: [email protected] W: www.tuv.at Business Area Industry & Energy Austria Technik Testing Laboratory, Inspection Body, Certification Body, Calibration Laboratory, Verifizierungsstelle Notified Body 0408 IC 2932K-1 Non-executive Board of Directors: KR DI Johann Marihart Management: DI Dr. Stefan Haas Mag. Christoph Wenninger Registered Office: Deutschstrasse 10 1230 Vienna/Austria Branch Offices: www.tuv.at/standorte Company Register Court / - Number: Vienna / FN 288476 f Bank Details: IBAN AT131200052949001066 BIC BKAUATWW IBAN AT153100000104093282 BIC RZBAATWW VAT ATU63240488 DVR 3002476 ww w.tu v.at | [email protected] | TÜV ® ww w.tu v.at | office@tuv .a Test Report Reference: INE-AT/FG-19/195 Ambient temperature: 23°C Relative humidity: 39% QFM-EMV-FG_Protokoll Rev.00 / FG19-195.doc Page 2 of 42 02.12.2019 Contents Designation PAGE 1. Applicant 3 2. Description of EUT 4 3. Standards / Final result 5 4. Test results List of measurements according to 47 CFR 15 and RSS-247 4.1 Test object data 6 4.2 Number of channels and channel spacing 7 4.3 20 dB Bandwidth 8-13 4.4 Maximum Peak RF Power Output (eirp) 14-15 4.5 Average time of occupancy 16-23 4.6 Out-of-band Emissions 24-29 4.7 Emissions in restricted bands 30-39 4.8 Conducted Limits 40-41 4.9 Maximum permissible exposure 42 Appendix Designation PAGES 1 Test equipment used 4 ww w.tu v.at | [email protected] | TÜV ® ww w.tu v.at | office@tuv .a Test Report Reference: INE-AT/FG-19/195 Ambient temperature: 23°C Relative humidity: 39% QFM-EMV-FG_Protokoll Rev.00 / FG19-195.doc Page 3 of 42 02.12.2019 1. Applicant Company: StreamUnlimited Engineering GmbH Department: Director Systems Address: High Tech Campus Vienna Gutheil-Schoder-Gasse 10 A-1100 Vienna Contact person: Mr. DI Christoph Apel EUT received on: 20.05.2019 Tests were performed on: 27.05. till 17.09.2019 ww w.tu v.at | [email protected] | TÜV ® ww w.tu v.at | office@tuv .a Test Report Reference: INE-AT/FG-19/195 Ambient temperature: 23°C Relative humidity: 39% QFM-EMV-FG_Protokoll Rev.00 / FG19-195.doc Page 4 of 42 02.12.2019 2. Description of EUT EUT: Bluetooth / BLE / WIFI module “STREAM1955” Serial Number: Prototype mounted on evaluation board Manufacturer: StreamUnlimited Engineering GmbH High Tech Campus Vienna Gutheil-Schoder-Gasse 10 A-1100 Vienna Description: StreamUnlimited Engineering GmbH provided the following configuration for the measurements: Prototype mounted on evaluation board with direct connection for conducted measurements and with antenna type of highest gain for radiated measurements Operating mode: The measurements were carried out at the following running states: test-firmware running, transmitting continuously Technical data EUT: Rated voltage: 5VDC Rated current: 450mA Rated frequency: DC Mains voltage during the tests: 5VDC Climatic conditions in the emc laboratory: Relative humidity: 39% Temperature: 23°C ww w.tu v.at | [email protected] | TÜV ® ww w.tu v.at | office@tuv .a Test Report Reference: INE-AT/FG-19/195 Ambient temperature: 23°C Relative humidity: 39% QFM-EMV-FG_Protokoll Rev.00 / FG19-195.doc Page 5 of 42 02.12.2019 3. Standards / Final result Name Title Deviation Result Title 47 CFR Part 15 October 1 st 2018 edition RADIO FREQUENCY DEVICES none OK RSS-247 Issue 2, February 2017 Digital Transmission Systems (DTSs), Frequency Hopping Systems (FHSs) and Licence-Exempt Local Area Network (LE-LAN) Devices none OK Result: Opinions and interpretation of testing laboratory OK: EUT passed NOK: EUT failed ww w.tu v.at | [email protected] | TÜV ® ww w.tu v.at | office@tuv .a Test Report Reference: INE-AT/FG-19/195 Ambient temperature: 23°C Relative humidity: 39% QFM-EMV-FG_Protokoll Rev.00 / FG19-195.doc Page 6 of 42 02.12.2019 4. TEST RESULTS 4.1. TEST OBJECT DATA General EUT Description This Bluetooth / BLE / WIFI module is using either 2.4 GHz frequencies or 5 GHz (WIFI only). This test report is only for the Bluetooth part. See additional test reports: INE-AT/FG-19/196 for BLE INE-AT/FG-19/197 for 2,4 GHz WIFI and INE-AT/FG-19/198 for 5 GHz WIFI measurement results including photodocumentation. 2.1033 (c) Technical description 2.1033 (4) Type of emission: Basic datarate: 976KF1D – Channel spacing 1 MHz Enhanced datarate: 1M40F1D – Channel spacing 1 MHz > 2/3 of channel bandwidth - > maximum power should be 125 mW. 2.1033 (5) Frequency range: 2402 to 2480 MHz (channel center frequencies). 2.1033 (6) Power range and Controls: The maximum peak output power is 4,57 mW and there is no power regulation. 2.1033 (7) Maximum output power rating: 4,57 mW conducted. 2.1033 (8) DC Voltage and Current: 5V DC maximum current consumption: 450 mA RSS-135 This standard does not apply to: 1.1.(a) a receiver that scans radio frequencies for the purpose of enabling its associated transmitter to avoid transmitting in an occupied fre…

Text truncated - open the document above for the full version.

www.tuv.at | [email protected] | TÜV ® Appendix 2 Photodocumentation Description: Test setup below 30 MHz Division: Industry & Energy Department: FG Test report reference: INE-AT/FG-19/198 Page: 6 of 8 Date: 02.12.2019 www.tuv.at | [email protected] | TÜV ® Appendix 2 Photodocumentation Description: Test setup with test board laid down Division: Industry & Energy Department: FG Test report reference: INE-AT/FG-19/198 Page: 7 of 8 Date: 02.12.2019 www.tuv.at | [email protected] | TÜV ® Appendix 2 Photodocumentation Description: Test setup with test board in upright position Division: Industry & Energy Department: FG Test report reference: INE-AT/FG-19/198 Page: 8 of 8 Date: 02.12.2019
