G450A1 STARTUP GUIDE GETTING STARTED Thank you for using Mason products. In this scope of this quick guide, we want to introduce to you some important basics and some precautions. TABLET OVERVIEW specification parameter Model G450A1 HW version PVT2.0 Rf emission power <160mW Manufacturer Mason HOW TO INSERT THE SIMCARD AND MEMORY CARD 1. Setting up SIM and SD card 1) To remove the card tray, insert the SIM eject PIN included with your device into the small hole next to the car tray 2) The SIM card tray will pop-up. Withdraw the SIM tray 3) Insert a SIM card or micro SD into the card tray with the SIM’s chip surface facing downwards 4) Insert the card tray back into your device in the correct orientation 2. Press and hold the power button during 3~5 second to turn power on . Notes: Mason is not responsible in case of damage caused by incorrect assembly or removal of cards or damage caused by using non-standard equipment. KEY FEATURES OF G450A1 Navigation bar: 1. Left button: Return to previous screen 2. Right button: Touch on to go Task manager 3. Home button: Touch on to go IDLE G450A1 SAFETY INSTRUCTIONS Thank you for using Mason products. we will introduce to you some safety precautions. Please make sure that you read this user guide carefully before using this product safety. - 1 This product can be used across EU member states. 2 CAUTION : RISK OF EXPLOSION IF BATTERY IS REPLACED BY AN INCORRECT TYPE. DISPOSE OF USED BATTERIES ACCORDING TO THE INSTRUCTIONS. 3 The product shall only be connected to a USB interface of version USB2.0 4 Adapter shall be installed near the equipment and shall be easily accessible. 5 Operating temperature: -20°C~40°C 6 The plug considered as disconnect device of adapter 7 The device complies with RF specifications when the device used at 0 cm form your body 8 We declare that this device is in compliance with the essential requirements and other relevant provisions of Directive 2014/53/EU. 9 Only indoor use for band 5150-5350MHz. FCC Statement This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Any Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: -- Reorient or relocate the receiving antenna. -- Increase the separation between the equipment and receiver. -- Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. -- Consult the dealer or an experienced radio/TV technician for help. To maintain compliance with FCC RF exposure requirements, use accessories that maintain a 0mm separation distance between the user's body and the device. IC STATEMENT This device complies with Industry Canada’s licence-exempt RSSs. Operation is subject to the following two conditions: (1) This device may not cause interference; and (2) This device must accept any interference, including interference that may cause undesired operation of the device. (3) This device is indoor use only when operate in frequency band 5150-5250MHz. Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux appareils radio exempts de licence. L'exploitation est autorisée aux deux conditions suivantes: (1) l'appareil ne doit pas produire de brouillage, et (2) l'utilisateur de l'appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible d'en compromettre le fonctionnement. The information listed above provides the user with information needed to make him or her aware of a RF exposure, and what to do to assure that this radio operates within the exposure limits.The device complies with RF specifications when the device used at 0mm from the body.

7.EXTERNAL AND INTERNAL PHOTOS OF THE EUT External photos of the EUT M odel:G450A1



Internal photos of the EUT M odel:G450A1

Page: 1 of 24 TEST REPORT Report No. .......................................: CHTEW19100135 Report verification : Project No. ..................................: SHT1909064404EW FCC ID ............................................. : 2AJZP-G450A1 Applicant’s name ........................... : Mason America, Inc Address ............................................. : 2101 4th Avenue Suite 1550, Seattle WA, 98121 Manufacturer....................................: Mason America, Inc Address ............................................. : 2101 4th Avenue Suite 1550, Seattle WA, 98121 Test item description .................... : PAD Trade Mark ....................................... : MASON/yprime Model/Type reference ....................... : G450A1 Listed Model(s) ................................. : - Standard ......................................... : FCC CFR Title 47 Part 15 Subpart C Section 15.225 Date of receipt of test sample..........: Sep 27, 2019 Date of testing..............................: Sep 28, 2019- Oct 28, 2019 Date of issue................................: Oct 29, 2019 Result .................. ........................: PASS Compiled by ( position+printedname+signature) ... : File administrators Silvia Li Supervised by (position+printedname+signature) .... : Project Engineer Aaron Fang Approved by (position+printedname+signature) .... : RF Manager Hans Hu Testing Laboratory Name ............. : Shenzhen Huatongwei International Inspection Co., Ltd. Address ............................................. : 1/F, Bldg 3, Hongfa Hi-tech Industrial Park, Genyu Road, Tianliao, Gongming, Shenzhen, China Shenzhen Huatongwei International Inspection Co., Ltd. All rights reserved. This publication may be reproduced in whole or in part for non-commercial purposes as long as the Shenzhen Huatongwei International Inspection Co., Ltd. is acknowledged as copyright owner and source of the material. Shenzhen Huatongwei International Inspection Co., Ltd. takes no responsibility for and will not assume liability for damages resulting from the reader's interpretation of the reproduced material due to its placement and context. The test report merely correspond to the test sample. Report No : CHTEW19100135 Page 2 of 24 Issued:2019-10-29 Shenzhen Huatongwei International Inspection Co., Ltd. Report Template Version: V01 (2018-01) Contents 1. TEST STANDARDS AND REPORT VERSION 3 1.1. Test Standards 3 1.2. Report version information 3 2. TEST DESCRIPTION 4 3. SUMMARY 5 3.1. Client Information 5 3.2. Product Description 5 3.3. EUT operation mode 6 3.4. EUT configuration 6 4. TEST ENVIRONMENT 7 4.1. Address of the test laboratory 7 4.2. Test Facility 7 4.3. Environmental conditions 8 4.4. Statement of the measurement uncertainty 8 4.5. Equipments Used during the Test 9 5. TEST CONDITIONS AND RESULTS 10 5.1. Antenna requirement 10 5.2. AC Power Conducted Emissions 11 5.3. Field Strength of the Fundamental and Mask Measurement 14 5.4. 20dB Bandwidth 16 5.5. Radiated Emission 18 5.6. Frequency Stability 22 6. TEST SETUP PHOTOS OF THE EUT 23 7. EXTERNAL AND INTERNAL PHOTOS OF THE EUT 24 Report No : CHTEW19100135 Page 3 of 24 Issued:2019-10-29 Shenzhen Huatongwei International Inspection Co., Ltd. Report Template Version: V01 (2018-01) 1. TEST STANDARDS AND REPORT VERSION 1.1. Test Standards The tests were performed according to following standards: FCC Rules Part 15.225: Operation within the band 13.110-14.010 MHz. ANSI C63.10-2013: American National Standard for Testing Unlicensed Wireless Devices. 1.2. Report version information Revision No. Date of issue Description N/A 2019-10-29 Original Report No : CHTEW19100135 Page 4 of 24 Issued:2019-10-29 Shenzhen Huatongwei International Inspection Co., Ltd. Report Template Version: V01 (2018-01) 2. TEST DESCRIPTION Test Item Section in CFR 47 Result Test Engineer Antenna requirement 15.203 PASS Jiongsheng Feng AC Power Line Conducted Emissions 15.207 PASS Kang Yang Field Strength of the Fundamental and Mask Measurement 15.225(a)(b)(c) PASS Xu Yang 20dB Bandwidth 15.215 PASS Jiongsheng Feng Radiated Emission 15.225(d)&15.209 PASS Yuantao Liang Frequency Stability 15.225(e) PASS Jiongsheng Feng Report No : CHTEW19100135 Page 5 of 24 Issued:2019-10-29 Shenzhen Huatongwei International Inspection Co., Ltd. Report Template Version: V01 (2018-01) 3. SUMMARY 3.1. Client Information Applicant: Mason America, Inc Address: 2101 4th Avenue Suite 1550, Seattle WA, 98121 Manufacturer: Mason America, Inc Address: 2101 4th Avenue Suite 1550, Seattle WA, 98121 3.2. Product Description Name of EUT: PAD Trade Mark: MASON/yprime Model No.: G450A1 Listed Model(s): - Power supply: DC 3.8V Adapter information 1: Model:A121A-12015OU-EU2 Input: 100-240Va.c., 50/60Hz, 0.5A Output: 5.0Vd.c., 2.5A/9.0Vd.c.,2.0A/12Vd.c.,1.5A Adapter information2: Model: A138A-120150U-US2 Input: 100-240Va.c., 50/60Hz, 0.5A Output: 5.0Vd.c., 2.5A/9.0Vd.c.,2.0A/12Vd.c.,1.5A RF Specification Operation frequency: 13.56MHz Channel number: 1 Modulation Type: ASK Antenna type: FPC+Ferrite Antenna Report No : CHTEW19100135 Page 6 of 24 Issued:2019-10-29 Shenzhen Huatongwei International Inspection Co., Ltd. Report Template Version: V01 (2018-01) 3.3. EUT operation mode TEST MODE For RF test items The engineering test program was provided and enabled to make EUT continuous transmit. For AC power line conducted emissions: The EUT was set to connect with large package sizes transmission. 3.4. EUT configuration The following peripheral devices and interface cables were connected during the measurement: ● - supplied by the manufacturer ○ - supplied by the lab Manufacturer : / Model No. : / Manufacturer : / Model No. : / Report No : CHTEW19100135 Page 7 of 24 Issued:2019-10-29 Shenzhen Huatongwei International Inspection Co., Ltd. Report Template Version: V01 (2018-01) 4. TEST ENVIRONMENT 4.1. Address of the test laboratory Laboratory: Shenzhen Huatongwei International Inspection Co., Ltd. Address: 1/F, Bldg 3, Hongfa H…
