2AK2Q-RACCOONBOTBLE Device

Rev 1/26/2023 ROBOMATION Co., Ltd. A-1101, 1102, 1103, 1104, 128, Beobwon-ro, Songpa-gu, Seoul, Republic of Korea Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 USA Date: Jan. 05 2026 Ref: Attestation Statements Part 2.911(d)(5)(i) Filing FCC ID: 2AK2Q-RACCOONBOT ROBOMATION Co., Ltd. (“the applicant”) certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. ROBOMATION Co., Ltd. (“the applicant”) certifies that the equipment for which authorization is sought does not include cybersecurity or anti-virus software produced or provided by Kaspersky Lab, Inc. or any of its successors and assignees, including equipment with integrated Kaspersky Lab, Inc. (or any of its successors and assignees) cybersecurity or anti-virus software pursuant to DA-24-886 and KDB 986446 D01 Covered Equipment Guidance section B(2a). Device is inherently compliant based on hardware limitations or software controls. or A Software Bill of Materials (SBOM) is provided to the TCB for review, and The end-user or third parties cannot install additional software on this device. Sincerely, ROBOMATION Co., Ltd. SANGHOON KIM (Applicant signature) Rev 1/26/2023 ROBOMATION Co., Ltd. A-1101, 1102, 1103, 1104, 128, Beobwon-ro, Songpa-gu, Seoul, Republic of Korea Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 USA Date: Jan. 05 2026 Ref: Attestation Statements Part 2.911(d)(5)(ii) Filing FCC ID: 2AK2Q-RACCOONBOT ROBOMATION Co., Ltd. (“the applicant”) certifies that, as of the date of the filing of the application, the applicant is not identified on the Covered List ( as a specifically named entity or any of its subsidiaries or affiliates) as an entity producing “covered” equipment. Sincerely, ROBOMATION Co., Ltd. SANGHOON KIM (Applicant signature)

U.S. Agent Designation for Service of Process ATTENTION: Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 USA REGARDING: FCC Certification – Section 2.911(d)(7) Information Designated U.S. Agent Company Name: Approve-IT, Inc. Contact Name: Nathan Grinager Street Address: 8011 34 th Ave South, Suite 342 City/Province/Zip: Bloomington, MN 55425 Telephone No: 651-247-1678 Email: [email protected] FRN #: 0027533835 This letter is to confirm that we (“the Designated U.S. Agent) have accepted the responsibility to act as the Designated U.S. Agent for Service of Process as required by section 47 CFR 2.911(d)(7) on behalf of the Applicant noted below. U.S. Agent Signature: Date: 1/20/2025 Signed by (Printed Name/Title): Nathan Grinager / Co-President The Applicant confirms its explicit consent and acknowledges that they must maintain an agent for no less than one year after terminating all marketing and importation OR the conclusion of any Commission-related proceeding involving the equipment. The applicant further acknowledges their responsibility to inform the FCC whenever the Designated U.S. Agent information above changes. Applicant Company name: ROBOMATION Co. Ltd. Grantee FRN: 0026203414 Grantee Code: 2AK2Q Contact Name: KIM SANG HOON Street Address: A-1101, 1102, 1103, 1104, 128, Beobwon-ro City/Province/Zip: Songpa-gu, Seoul, Republic of Korea Telephone No: +82-10-5170-5419 Email: [email protected] Date: January 15, 2025 Signed by (Printed Name/Title): KIM SANG HOON / Senior Research engineer

ROBOMATION Co., Ltd. A-1101, 1102, 1103, 1104, 128, Beobwon-ro, Songpa-gu, Seoul, Republic of Korea Date: Jan, 05, 2026 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 USA SUBJECT: Application for Certification for FCC ID: 2AK2Q-RACCOONBOT To Whom It May Concern: We, the undersigned, hereby authorize SangHoon, Yu at Lab-T, Inc. on our behalf, to apply to the Federal Communications Commission on our equipment. Any and all acts carried out by SangHoon, Yu at Lab-T, Inc. on our behalf shall have the same effect as acts of our own. This is to advise that we are in full compliance with the Anti- Drug Abuse Act. We, the applicant, are not subject to a denial of federal benefits pursuant to Section 5301 of the Anti-Drug Act of 1988, 21 USC853a, and no party to the application is subject to a denial of federal benefits pursuant to that section. Regards, (Signature) SANGHOON KIM / Senior Research engineer +82 10-5170-5419 A-1101, 1102, 1103, 1104, 128, Beobwon-ro, Songpa-gu, Seoul, Republic of Korea

ROBOMATION Co., Ltd. A-1101, 1102, 1103, 1104, 128, Beobwon-ro, Songpa-gu, Seoul, Republic of Korea Federal Communications Commission Authorization and Evaluation Division Confidentiality Request regarding application for certification of FCC ID: 2AK2Q- RACCOONBOT Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, we hereby request confidential treatment of information accompanying this application as outlined below: Exhibit Type File Name - Block Diagram - Schematics - Operational Description - Tune-up Procedure - 06. Block Diagram.pdf - 07. Schematics.pdf - 10. Operation Description.pdf - 12. Tune-up procedure.pdf The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Pursuant to DA04-1705 June 15, 2004 of the Commission’s public notice, we also request temporary confidential treatment of information accompanying this application as outlined below for a period of 180 days Exhibit Type File Name - RF Test Setup photos - External Photos - Internal Photos - User manual - 03. Test Setup Photos.pdf - 04. External Photos.pdf - 05. Internal Photos.pdf - 08. User Manual.pdf (Signature) SANGHOON KIM / Senior Research engineer +82 10-5170-5419 A-1101, 1102, 1103, 1104, 128, Beobwon-ro, Songpa-gu, Seoul, Republic of Korea

Copyright ⓒ 2026. Lab-T, Inc . Label Informaion 1 A 2 3 4 5 678 12 3 4 5 678 B C D E F A B C D E F Dept.Technical referenceCreated byApproved by Document typeDocument status TitleDWG No. Rev. Date of issueSheet 2025-11-15 1/1 Raccoon_Mold_20250403_for Render jungwoo kim 60.2 30.2 21.5 FCC ID: 2AK2Q-RACCOONBOT Manufactured by: ROBOMATION Co., Ltd. (Republic of Korea) Type of equipment : BLE Device Model Name: RaccoonBot Manufactured Date (YYYY.MM): 2025.12 S/N: RAWR1TK2526-0001 Label

[(max. power of channel, including tune-up tolerance, mW) / (min. test separation distance, mm)] ꞏ [√f(GHz)] ≤ 3.0 for 1-g SAR, and ≤ 7.5 for 10-g extremity SAR where f(GHz) is the RF channel transmit frequency in GHz Power and distance are rounded to the nearest mW and mm before calculation The result is rounded to one decimal place for comparison Step.2 For 100 MHz to 6 GHz and test separation distances > 50 mm, the 1-g and 10-g SAR test exclusion thresholds are determined by the following {[Power allowed at numeric threshold for 50 mm in step a)] + [(test separation distance – 50 mm)ꞏ (f(MHz)/150)]} mW, for 100 MHz to 1500 MHz {[Power allowed at numeric threshold for 50 mm in step a)] + [(test separation distance – 50 mm)ꞏ10]} mW, for > 1500 MHz and ≤ 6 GHz Step.2-1 Step.2-2 RF EXPOSURE KDB447498 was used as the guidance. SAR test exclusion considerations Step.1 For 100 MHz to 6 GHz and test separation distances ≤ 50 mm, the 1-g and 10-g SAR test exclusion threshold are determined by the following : The test exclusions are applicable only when the minimum test separation distance is ≤ 50 mm, and for transmission frequencies between 100 MHz and 6 GHz. When the minimum test separation distance is < 5 mm, a distance of 5 mm according to 4.1 f) is applied to determine SAR test exclusion. The values 3.0 and 7.5 are referred to as numeric thresholds in step b) below Copyright ⓒ 2026. Lab-T, Inc. Page :1 / 2 ( - EIRP = P + G- NOTE - Maximum Peak Antenna Gain :3.40 dBi The EUT will only be used with a separation of 5 millimeters or lesser between the antenna and the body of the SAR Exclusion calculation for this exposure is shown below. Minimum : -7.60 dBm ) - Target Power & Tolerance -6.60 dBm & ± dB ( Maximum : -5.60 dBm & 1.00 SAR test exclusion considerations FCCID : 2AK2Q-RACCOONBOT - Measured RF Maximum Output Power :-6.51 dBm MHz- Frequency Range : 2402 MHz ~ 2480 (Worst case : BLE1M_Lowest Frequency) = [( 0.28 / 5.00 Estimated SAR at the specific separation dBiP : Max tuneup Power (dBm) = -2.20 dBmG : Maximum Peak Antenna Gain (dBi) = -5.60 dBm + 3.40 =0.60mW - PdBm- NOTE =0.28 mW -5.60 P : Max tuneup Power (dBm) = - S = [(P(mW) / R)] X [√f(GHz)] - NOTE f(GHz) : the RF channel transmit frequency in GHz RF Exposure Compliance Issue Therefore, EUT is not required the SAR Evaluation. = 0. 09P(mW) : Max tuneup Power (mW) R : Distance to the center of the radiation of the antenna5.00 mm ) <3 S : Maximum Estimated SAR )] X [ √( 2.48 ) ] Copyright ⓒ 2026. Lab-T, Inc. Page :2 / 2

REPORT No.:TRRFCC26-0001 Total 42 pages TRF-R-003(00) Page: 2 / 42 Copyright ⓒ 2026, Lab-T, Inc. CONTENTS 1. REVISION HISTORY ......................................................................................................................................... 3 2. INFORMATION ................................................................................................................................................ 4 2.1 Applicant Information ................................................................................................................................................................. 4 2.2 Test Laboratory information ..................................................................................................................................................... 4 2.3 Test Location.................................................................................................................................................................................... 4 3. INFORMATION ABOUT TEST EQUIPMENT ................................................................................................. 5 3.1 Equipment Information .............................................................................................................................................................. 5 3.2 Antenna Information ................................................................................................................................................................... 5 3.3 Test Frequency ................................................................................................................................................................................ 5 3.4 Tested Companion Device Information .............................................................................................................................. 5 3.5 Operating conditions for the EUT ......................................................................................................................................... 5 4. TEST REPORT ................................................................................................................................................... 6 4.1 Summary ........................................................................................................................................................................................... 6 4.2 Measurement Uncertainty ......................................................................................................................................................... 6 4.3 Transmitter Requirements ......................................................................................................................................................... 7 4.3.1 Antenna Requirement ......................................................................................................................................................... 7 4.3.2 Maximum Peak Output Power ........................................................................................................................................ 8 4.3.3 Peak Power Spectral Density .........................................................................................................................................10 4.3.4 6 dB Bandwidth(DTS Bandwidth).................................................................................................................................14 4.3.5 Spurious Emission, Band Edge, and Restricted bands ......................................................................................21 4.3.6 Conducted Emission ..........................................................................................................................................................39 APPENDIX I ............................................................................................................................................................ 41 REPORT No.:TRRFCC26-0001 Total 42 pages TRF-R-003(00) Page: 3 / 42 Copyright ⓒ 2026, Lab-T, Inc. 1. Revision history Test Report No. Date Description TRRFCC26-0001 2026-01-06 Initial issue REPORT No.:TRRFCC26-0001 Total 42 pages TRF-R-003(00) Page: 4 / 42 Copyright ⓒ 2026, Lab-T, Inc. 2. Information 2.1 Applicant Information Applicant name ROBOMATION Co., Ltd. Address A-1101, 1102, 1103, 1104, 128, Beobwon-ro, Songpa-gu, Seoul, Republic of Korea Telephone No. +82-10-5170-5419 Person in charge SANG HOON KIM / [email protected] Manufacturer ROBOMATION Co., Ltd. Address A-1101, 1102, 1103, 1104, 128, Beobwon-ro, Songpa-gu, Seoul, Republic of Korea 2.2 Test Laboratory information Corporate name Lab-T, Inc. Representative Duke (Jongyoung) Kim Address 2182-42 Baegok-daero, Mohyeon-eup, Cheoin-gu, Yongin-si, Gyeonggi-do 17036, Republic of Korea FCC & IC MRA Designation No. KR0159 ISED No. 22000 Telephone +82-31-322-6767 Fax +82-31-322-6768 E-mail [email protected] 2.3 Test Location Test Site used Address Building L 2182-40 Baegok-daero, Mohyeon-eup, Cheoin-gu, Yongin-si, Gyeonggi-do 17036, Republic of Korea Building T 2182-42 Baegok-daero, Mohyeon-eup, Cheoin-gu, Yongin-si, Gyeonggi-do 17036, Republic of Korea Building A 2182-44 Baegok-daero, Mohyeon-eup, Cheoin-gu, Yongin-si, Gyeonggi-do 17036, Republic of Korea REPORT No.:TRRFCC26-0001 Total 42 pages TRF-R-003(00) Page: 5 / 42 Copyright ⓒ 2026, Lab-T, Inc. 3. Information About Test Equipment 3.1 Equipment Information Equipment type BLE Device Equipment model name RaccoonBot Frequency range 2 402 MHz ~ 2 480 MHz Modulation type GFSK Power supply DC 3.6 V H/W version v1.0 S/W version v1.0.0 Note 1 : The above EUT information was declared by the manufacturer. Note 2 : The only difference is the capacity of the capacitor used for energy storage. 3.2 Antenna Information Type Model No. Gain Note. Chip antenna - 3.4 dBi - 3.3 Test Frequency Test mode Test frequency (MHz) Lowest frequency Middle frequency Highest frequency Bluetooth LE(1M…

Text truncated - open the document above for the full version.

Copyright ⓒ 2026. Lab-T, Inc . Antenna datasheet Application Bluetooth Zigbee WLAN (IEEE 802.11 b/g) ISM 2.4GHz Wireless Devices Features PIFA Structure Small Size (3.0*1.5*1.2mm 3 ) Easy Optimizing with external lumped matching components SMT Available under Pb-free Condition RoHSCompliant DATASHEET DocumentDatasheet TypeDielectricChip Antenna Application2.4GHz Part No.AMAN301512ST01 Revision1.1 Notes The contents of this datasheet are subject to change without notice. Please confirm the specifications and delivery conditions when placing your order. AMOTECH AMOTECH Co., Ltd. Datasheet / Dielectric Chip Antenna / 2.4GHz AMAN301512ST01 (Rev 1.1) 2 Rev. NoDateTitleContentsPage 0’08.09.30New Published 1’09.03.24Data Added Efficiency data8 Changed carrier tape width (W16mm →W12mm)12 1.1’09.04.07FormatChangeddocument format Table of Content Revision History 1.Specifications 3 1.1 Electrical Specifications 3 1.2 Mechanical Specifications 3 1.3 Appearance and Material 3 2. PCB Design for Test 4 2.1 Evaluation BoardDimension 4 2.2 PCB Design Guide 4 3. Measurement Result 5 3.1 Typical Measurement Result (VSWR/RL,Smithchart) 5 3.2 Typical Measurement Result(Gain, Radiation Pattern) 6 4. Reliability 7 5. Soldering Reflow Profile 7 6. Packaging 8 6.1 Carrier Tape Dimension 8 6.2 PackagingQuantity 8 6.3 Packaging Label 8 Datasheet / Dielectric Chip Antenna / 2.4GHz AMAN301512ST01 (Rev 1.1) 3 NoItemSpec.Remark 1Frequency Range [GHz]2.4 ~2.485 2VSWRMax 3.0:1 3Peak Gain [dBi]typ. 3.4 4Total Avg. Gain [dBi]typ. -0.8 5Efficiency [%]typ. 82 6PolarizationLinear 7Impedance [Ω]Nominal 50 The results are measured on the 50x50mm 2 evaluation board(EVB). See Page 6. for more detail gain parameter NoItemSpec.Remark 1Dimensions (LxWxH)3.0x1.5x1.2 mm 3 2Unit Weighttyp. 20 mg 3Operating Temperature-35 ~ +85 °C 1.1 Electrical Specifications 1.2 Mechanical Specifications NoItemFunctionMaterial ① Marking Feeding Index Ink ② MarkingWeek numberInk ③ ElectrodeRadiation ElementAg ④ Ceramic Body - Ceramic 1.3 Appearance & Material 1. Specifications ② ③ ① ④ [unit : mm] Datasheet / Dielectric Chip Antenna / 2.4GHz AMAN301512ST01 (Rev 1.1) 4 2.1 Evaluation Board Dimension 2.2 PCB Design Guide 2. PCB Design for Test ② ③ ① NoPin Assignment ① Feeding ②GND ③ GND Matching Component 50 Ohm Feeding Line [unit : mm] Evaluation board size ~ 50x50 Fill Cut Area (GND Clearance) ~ 7.5x3.3 [PCB Solder Land] Datasheet / Dielectric Chip Antenna / 2.4GHz AMAN301512ST01 (Rev 1.1) 5 3.1 Typical Measurement Result (VSWR/RL, Smithchart) 3. Measurement Result The results are measured on the 50x50mm 2 evaluation board(EVB). ② ③ ① NoMatching Value ①1.0 nH ②3.3 nH ③ 1.2 pF Datasheet / Dielectric Chip Antenna / 2.4GHz AMAN301512ST01 (Rev 1.1) 6 [Azimuth plane @2.45GHz ] [Elevation1 plane @2.45GHz ] [Elevation2 plane @2.45GHz ] [3D Radiation Pattern] x y z -y Azimuth E1 E2 3.2 Typical Measurement Result (Gain, Radiation Pattern) Peak Gain (dBi) Avg. Gain (dBi) Total Avg. Gain (dBi) Efficiency (%) Azimuth-0.54-2.46 -0.882 Elevation 13.29-1.80 Elevation 22.81-0.74 Datasheet / Dielectric Chip Antenna / 2.4GHz AMAN301512ST01 (Rev 1.1) 7 NoItemTest ConditionTest Requirements 1 Adhesive Strength of Termination 1.Applied force on SMT chip till detached point from PCB. 1. No mechanical damage by applied force 2. Strength (F) > 3 kgf 2 Thermal Shock (Cycle) 1. Step 1 : -40 ±3°C, 30 min Step 2 : +125 ±3°C, 30 min 2. Number of cycle : 30 1. No visual damage 2. Within electric spec (VSWR) 3 High Temperature Resistance 1. Temperature : +125 ±5°C 2. Time : 1000 ±24 hrs 1. No visual damage 2. Within electric spec (VSWR) 4 Low Temperature Resistance 1. Temperature : -40 ±5°C 2. Time : 1000 ±24 hrs 1. No visual damage 2. Within electric spec (VSWR) 5Humidity 1. Humidity : 85 % RH Temperature : +85 ±3°C 2. Time : 1000 ±24 hrs 1. No visual damage 2. Within electric spec (VSWR) F SMD PAD PCB 4. Reliability 5. Soldering Reflow Profile Datasheet / Dielectric Chip Antenna / 2.4GHz AMAN301512ST01 (Rev 1.1) 8 ItemSpec.ItemSpec.ItemSpec. A01.80 ±0.10P04.00 ±0.10E1.75 ±0.10 B03.30 ±0.10P14.00 ±0.10F5.50 ±0.10 K01.35 ±0.10P22.00 ±0.10W12.00 ±0.30 D01.55 ±0.05--t0.30 ±0.05 Item QuantityDimension Reel2,500eaΦ7” * 12mm Inner Box7,500 ea (3 reel)185 * 185 * 68 (mm 3 ) Outer Box137,500 ea (5 Inner Box)365 * 200 * 200 (mm 3 ) Outer Box2105,000 ea (14 Inner Box)390 * 390 * 280 (mm 3 ) 6.1 Carrier Tape Dimension 6.2 Packaging Quantity 6.3 Packaging Label 6. Packaging AMOTECH Co., Ltd. 5BL-1Lot, 617, Namchon-Dong, Namdong-Gu, Incheon, Korea Dielectric Chip Antenna P/N : AMAN301512ST01 Lot No : Quantity : 2,500 pcs Date : 2009/04/09
