2AK4CCC10USPetcube Cam

品牌 SETUP PLACEMENT LIGHT STATUS 0 Download the Petcube App and register an account e Power up the camera and wait for yellow light to flash 0 Press the Setup button at the bottom until you hear a sound 严 0 Follow instructions ,n the app to finish the setup 丿 We recommend placing Petcube Cam on a table or shelf at least 3 feet above the floor. Consider a location that allows for maximum coverage through wide angle lens. It's always a good idea to point Cam in the direction where your pets tend to spend most of their time. Table or shelf top Petcube Cam has a non-slip rubber bottom, which provides a secure grip on flat surfaces Camera tilt can be adjusted manually for a better viewing angle. Hooks at the foot allow to fold the cord firmly. Mounting The device can be placed on a wall or a shelf bottom. Petcube Cam comes with a metal plate and a mounting tape. Mount the plate in the desired location and the camera foot will magnetically snap to it. It also works with other metallic surfaces 5@ ． Pulsing blue Cam 1s streaming video Blue blinking once Care recording started Solid blue Cam is online 、 I / Fast flashing blue 一 ． 一 Connecting to the cloud, ， I 、 finishing setup 、 I ／ Flashing blue and yellow 一毫0- / I 、 Connecting to the router 0 Solid yellow Cam is booting up 、 I ／ Fast flashing yellow - 0 - ／ I 、 Device is ready for setup 冒 Pulslng yellow Connection or system error 2020.05.22 V1.0首次创建 CONTACT PRODUCT INFO PETCUBE CAM QUICK START GUIDE For any assistance with the device, please contact us directly via Amazon. We'll resolve any issue ASAP. Pet parents'experience is our top priority. Please tell us what you think about the camera Share your feedback Join the Petcube pack 貊 @ petcube #petcube ＠望fa Petcube user guide The explanations provided in this guide are for informational purposes only and may be modified. The latest version of this guide can be found at petcube.com/user-gulde/cam Software Your Petcube Cam connects to Petcube, Inc copyrighted software to control its operation One-year limited warranty When Petcube Cam is purchased new through Petcube authorized resellers, it is warranted against defects in materials and workmanship under normal use for a period of 1 year from the date of the retail purchase. Full terms can be found at petcube.com/docs/warranty Safety and handling For more Information about safety and handling, please see petcube.com/user-gulde/cam. To avoid injury or harm. read all safety information and operating instructions prior to using Petcube Cam Regulations This device complies with RoHS, FCC. Please visit petcube.com/terms-of-use for more information. FCC STATEMENT : This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation. Warning: Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment g enerates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause h armful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television r eception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: Reorient or relocate the receiving antenna. Increase the separation between the equipment and receiver. Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. Consult the dealer or an experienced radio/TV technician for help. FCC Radiation Exposure Statement: This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance 20cm between the radiator & your body. 刀 线 刀 槽 穿 合 切 厂齿 开 半粘 1,: 沁;';'.;-;'.;:� 爷， './汽召 (,f 」 ： f'x-/> 宁 (,,J Scale 1:1 Unit:mm 型号：CC10US 规格 ：CC10US-KSZ P01 V1.0 物料编码： 04060060 0 064 产品名陟宠物摄像头 印刷颜色售 k 物料材质� 105 g无光 铜 样品 样品数量售 设计千伶曹佳丽 成品尺寸P 60 x 100mm 特种工艺陟风琴折 CC10US

FCC ID: 2AK4CCC10US

Label Location On EUT Label Product Name: Petcube Cam Model No.: CC10US FCC ID: 2AK4CCC10US This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation.

FCC ID: 2AK4CCC10US ANT

version01 Petcube, Inc. Declaration concerning Antenna Specification It is hereby declared that the product Model No.:CC10US FCC ID : 2AK4CCC10US fulfills the requirement in FCC test relating to the antenna type. The device specified above confirms to the FCC recommendations for internal antenna type(s) described below: Model No. of antenna: CC10US Type of antenna:PIFA Antenna Gain of the antenna: 3.91 dBi Frequency range:2412MHz~2462MHz The mounting of the antenna is fixed to the radio module and no other antenna should be used. Company name: Petcube, Inc. Address: 251 Little Falls Drive, Wilmington, DE 19808, USA City: Wilmington ZIP / Postal code: N/A Country:USA Place:USADate: 2020-07-14 Signature:

RF EXPOSURE EVALUATION According to FCC 1.1310: The criteria listed in the following table shall be used to evaluate the environment impact of human exposure to radio frequency(RF) Radiation as specified in §1.1307(b) FCC ID: 2AK4CCC10US EUT Specification EUTPetcube Cam Frequency band (Operating) WLAN: 2.412GHz ~ 2.462GHz WLAN: 5.18GHz ~ 5.24GHz WLAN: 5.745GHz ~ 5.825GHz Others: 2.402GHz~2.480GHz Device category Portable (<20cm separation) Mobile (>20cm separation) Others ___ Exposure classificationOccupational/Controlled exposure (S = 5mW/cm2) General Population/Uncontrolled exposure (S=1mW/cm2) Antenna diversitySingle antenna Multiple antennas Tx diversity Rx diversity Tx/Rx diversity Max. output power15.60dBm (0.0363W) Antenna gain (Max)3.91 dBi Evaluation applied MPE Evaluation SAR Evaluation Limits for Maximum Permissible Exposure(MPE) Frequency Range(MHz) Electric Field Strength(V/m) Magnetic Field Strength(A/m) Power Density(mW/cm 2 ) Average Time (A) Limits for Occupational/Control Exposures 300-1500----F/3006 1500-100000----56 (B) Limits for General Population/Uncontrol Exposures 300-1500----F/15006 1500-100000----130 Friis transmission formula: Pd=(Pout*G)\(4*pi*R2) Where Pd= Power density in mW/cm 2 Pout=output power to antenna in Mw G= gain of antenna in linear scale Pi=3.1416 R= distance between observation point and center of the radiator in cm Pd the limit of MPE, 1mW/cm2. If we know the maximum gain of the antenna and total power input to the antenna, through the calculation, we will know the distance where the MPE limit is reached. Measurement Result 2.4GHz WiFi: Operating Mode Channel Frequency Measured Power Tune up tolerance Max. Tune up Power Antenna Gain Power density at 20cm Power density Limits (mW/cm 2 ) (MHz)(dBm)(dBm)(dBm)(dBi)(mW/ cm 2 ) 802.11b 241215.17 15.17±116.173.910.02031 243715.60 15.60±116.603.910.02241 246214.80 14.80±115.803.910.01861 802.11g 241212.47 12.47±113.473.910.01091 243712.87 12.87±113.873.910.01191 246212.17 12.17±113.173.910.01021 802.11n (HT20) 241212.19 12.19±113.193.91 0.0102 1 243713.16 13.16±114.163.910.01281 246212.19 12.19±113.193.910.01021

Report No.: 18220WC00071001FCC ID: 2AK4CCC10USPage 1 of 68 Code:AB-RF-05-a FCC TEST REPORT Client Name: Petcube, Inc. Address: 251 Little Falls Drive, Wilmington, DE 19808, USA Product Name: Petcube Cam Date: Jul. 10, 2020 Shenzhen Anbotek Compliance Laboratory Limited Report No.: 18220WC00071001FCC ID: 2AK4CCC10USPage 2 of 68 Code:AB-RF-05-a Contents 1. General Information ............................................................................................................................................... 5 1.1. Client Information ....................................................................................................................................... 5 1.2. Description of Device (EUT) ..................................................................................................................... 5 1.3. Auxiliary Equipment Used During Test ................................................................................................... 5 1.4. Description of Test Modes ........................................................................................................................ 6 1.5. List of channels ........................................................................................................................................... 7 1.6. Description Of Test Setup ......................................................................................................................... 8 1.7. Test Equipment List .................................................................................................................................... 9 1.8. Measurement Uncertainty ....................................................................................................................... 10 1.9. Description of Test Facility ...................................................................................................................... 10 2. Summary of Test Results ................................................................................................................................... 11 3. Conducted Emission Test ................................................................................................................................... 12 3.1. Test Standard and Limit .......................................................................................................................... 12 3.2. Test Setup .................................................................................................................................................. 12 3.3. Test Procedure .......................................................................................................................................... 12 4. Radiation Spurious Emission and Band Edge ................................................................................................ 17 4.1. Test Standard and Limit .......................................................................................................................... 17 4.2. Test Setup .................................................................................................................................................. 17 4.3. Test Procedure .......................................................................................................................................... 18 4.4. Test Data .................................................................................................................................................... 19 5. Maximum Peak Output Power Test .................................................................................................................. 30 5.1. Test Standard and Limit .......................................................................................................................... 30 5.2. Test Setup .................................................................................................................................................. 30 5.3. Test Procedure .......................................................................................................................................... 30 5.4. Test Data .................................................................................................................................................... 30 6. 6DB Occupy Bandwidth Test ............................................................................................................................. 34 6.1. Test Standard and Limit .......................................................................................................................... 34 6.2. Test Setup .................................................................................................................................................. 34 6.3. Test Procedure ............................................................................................................................... ........... 34 6.4. Test Data .................................................................................................................................................... 34 7. Power Spectral Density Test .............................................................................................................................. 41 7.1. Test Standard and Limit .......................................................................................................................... 41 7.2. Test Setup .................................................................................................................................................. 41 7.3. Test Procedure .......................................................................................................................................... 41 7.4. Test Data .................................................................................................................................................... 41 8. 100kHz Bandwidth of Frequency Band Edge Requiremen…
