2AKCIYJ2020C27MHZToy RC DIY Trike

Reverse Forward Left Right Wheel Alignment Wheel Alignment Dial Turn the wheel alignment tab to the right if your trike drifts to the left. Turn the tab to the left if your trike tends to drift to the right. BUILDING YOUR REMOTE CONTROLOPERATING INSTRUCTIONS A B C D E FG I J K 3 1 2 425 L PO Q N M X 6 1 X 2 X 1 X 1 X 2 X 2 X 4 H DIY RC RACE TRIKE 6 + AGES • For indoor use only. Avoid water when operating. • Do not submerge car or controller in water. • Do not use people or animals as obstacles. • Do not run car into furniture objects or hard surfaces as this will cause damage to both the objects and car. • Keep fingers, hair and loose clothing away from the tires, gears and motor while car is switched to “ON’. • Do not leave car or transmitter near sources of heat or under direct sunlight for long periods of time. • Remove all batteries when not in use to avoid accidental operation. • Adult supervision is recommended when operating car. • Thoroughly inspect products before every use. If the product appears worn, frayed/splintered, cracked, or broken in any manner, discontinue use and discard immediately. SAFETY WARNINGS: PLEASE READ BEFORE USE WARNING: CHOKING HAZARD - Small Parts. Not for Children under 3 years. BATTERY INSTALLATION The chassis requires 4 “AA” 1.5V batteries (not included) and the remote requires one 9V battery (not included). Use a Phillips head screwdriver to loosen the screw securing the corresponding battery cover plate. Insert the batterie(s), ensuring the correct polarity per the diagrams. Replace the battery cover and tighten the screw. • Do not mix old and new batteries. • Do not mix alkaline, standard (carbon-zinc), or rechargeable batteries. • Alkaline batteries are recommended. Use only the specified voltage. • Insert batteries using the correct polarity. Always use, replace, and recharge (if applicable) batteries under adult supervision. • Do not charge with non-rechargable batteries. • Do not short-circuit the battery supply terminals. • Do not dispose of batteries in fire, batteries may explode or leak. • Remove batteries before storing. • Recycle or dispose of batteries according to federal, state, and local laws. • Keep this package for future reference. BATTERY WARNING: INTRODUCTION Congratulations on your purchase of the DIY RC Race Trike Kit. Please read all instructions and warnings on this sheet prior to using the product. Keep this instruction sheet as it contains important information for future reference. CONTENTS Parts to Assemble Your Remote Control A. 1 x Front Body B. 1 x Rear Body C. 1 x Antenna D. 1 x Circuit Board E. 1 x On/Off Switch F. 2 x Joysticks G. 1 x Battery Cover with Screw H. 1 x Connect Remote PCB and Antenna 1. 6 x Short Cross Screws ( 2.3 x 6 PB ) 2. 1 x Cross Screw ( 2.3 x 6 PWB x 6 ) Parts to Assemble Your Race Trike I. 1 x Shell Body J. 1 x Chassis K. 2 x Front Tires L. 2 x Shocks M. 1 x Rear Axle with Rear Tire N. 1 x Rear Axle O. 1 x Circuit Board P. 1 x Top Decorative Bar Q. 1 x Battery Cover with Screw 1. 2 x Short Cross Screws ( 2.3 x 6 PB ) 2. 4 x Cross Screws ( 2.3 x 6 PWB x 6 ) 3. 2 x Long Cross Screws ( 2.3 x 8 PB ) 4. 1 x Cross Screw ( 12.6 x 12 PWB x 8 ) 5. 2 x Cross Screws ( 2.3 x 8 PWB x 8 ) Model NO. : 1012380 This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. WARNING: Changes or modifications to this unit not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: — Reorient or relocate the receiving antenna. — Increase the separation between the equipment and receiver. — Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. — Consult the dealer or an experienced radio/ TV technician for help. B. 1 x Rear Body C. 1 x Antenna H. 1 x Connect Remote PCB and Antenna 2. 1 x Cross Screw ( 2.3 x 6 PWB x 6 ) Battery Cover Connect the wire from the battery compartment to the Circuit Board. NOTE: Circuit Board - R (connect Red wire) Y (connect Yellow wire) 1 2 1 12 3 5 4 D. 1 x Circuit Board 1. 2x Short Cross Screws ( 2.3 X 6 PB ) A. 1 x Front Body F. 2 x Joysticks E. 1 x On/Off Switch 1. 4 x Short Cross Screws ( 2.3 X 6 PB ) G. 1 x Battery Cover with Screw Attach the Front Body and Rear Body using screws provided. Insert a 9V battery (not included) matching the polarity etched in the battery tray. Attach the Battery Cover. Insert the Circuit Board into the back side of the Rear Body. Attach the Antenna to the Rear Body.Attach On/Off Switch and left and right Joysticks to the Front Body. BUILDING YOUR RACE TRIKE (continue) KEEP THIS INSTRUCTION MANUAL AS IT CONTAINS IMPORTANT INFORMATION FOR FUTURE REFERENCE. Due to continuous product improvements, the pictures on this manual may differ slightly from the actual product. FAO ® and FAO Schwarz ® names and logos are trademarks or registered trademarks. All rights reserved. www.fao.com Distributed by and © 2020 MerchSource, LLC. Irvine, CA 92618. For customer supp…
