2AKL2-R160801Network Video Recorder

Shenzhen Kean Digital Co., Ltd.

Click to zoom

Application Details

Equipment Class: NII - Unlicensed National Information Infrastructure TX
Date of Grant: Sep 12, 2026
Application Purpose: Original Equipment
Equipment Note: Network Video Recorder
Frequency Range: 5180.00000000 - 5240.00000000
Company: Shenzhen Kean Digital Co., Ltd.
Country: China

Documents & Files

Select a file to view

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

§ 15.19 Labelling requirements. This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions:(1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. § 15.21 Information to user. Any Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. § 15.105 Information to the user. Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: -Reorient or relocate the receiving antenna. -Increase the separation between the equipment and receiver. -Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. -Consult the dealer or an experienced radio/TV technician for help. *RF warning for Mobile device: This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance 20cm between the radiator & your body.

Attestation Statements

Rev1/26/2023 ShenzhenKeanDigitalCo.,Ltd. FederalCommunicationsCommission AuthorizationandEvaluationDivision 7435OaklandMillsRoad Columbia,MD21046 USA Date:September2,2026 Ref:AttestationStatementsPart2.911(d)(5)(i)Filing FCCID:2AKL2-R160801 [ShenzhenKeanDigitalCo.,Ltd.]certifiesthattheequipmentforwhichauthorizationissoughtisnot “covered”equipmentprohibitedfromreceivinganequipmentauthorizationpursuanttosection2.903of theFCCrules. [ShenzhenKeanDigitalCo.,Ltd.]certifiesthattheequipmentforwhichauthorizationissoughtdoesnot includecybersecurityoranti-virussoftwareproducedorprovidedbyKasperskyLab,Inc.oranyofits successorsandassignees,includingequipmentwithintegratedKasperskyLab,Inc.(oranyofits successorsandassignees)cybersecurityoranti-virussoftwarepursuanttoDA-24-886andKDB986446 D01CoveredEquipmentGuidancesectionB(2a). Deviceisinherentlycompliantbasedonhardwarelimitationsorsoftwarecontrols. or ASoftwareBillofMaterials(SBOM)isprovidedtotheTCBforreview,and Theend-userorthirdpartiescannotinstalladditionalsoftwareonthisdevice. Sincerely, ContactName:XiaolinZeng Rev1/26/2023 ShenzhenKeanDigitalCo.,Ltd. FederalCommunicationsCommission AuthorizationandEvaluationDivision 7435OaklandMillsRoad Columbia,MD21046 USA Date:September2,2026 Ref:AttestationStatementsPart2.911(d)(5)(ii)Filing FCCID:2AKL2-R160801 [ShenzhenKeanDigitalCo.,Ltd.]certifiesthat,asofthedateofthefilingoftheapplication,theapplicant isnotidentifiedontheCoveredList(asaspecificallynamedentityoranyofitssubsidiariesoraffiliates) asanentityproducing“covered”equipment. Sincerely, ContactName:XiaolinZeng

Attestation Statements

ShenzhenKeanDigitalCo.,Ltd. Address：1001RujunBuilding,No.105,ZhongxingRoad,Ma'antangCommunity,Bantian Street,LonggangDistrict,Shenzhen,518129,China. FRN:0026103432 Date:2026-09-01 FederalCommunicationsCommission AuthorizationandEvaluationDivision 7435OaklandMillsRoad Columbia,MD21046 Ref:AttestationStatementsPart2.911(d)(7)Filing SUBJECT:FCCApplicationforFCCID:2AIT9-R160801 (“ShenzhenKeanDigitalCo.,Ltd.”)certifiesthat,asofthedateofthefilingoftheapplication, (PlethyInc)isourdesignatedU.S.agentforserviceofprocessforthe abovereferencedFCCID.(“ShenzhenKeanDigitalCo.,Ltd.”)acceptstomaintainan agentfornolessthanoneyearafterthegranteehasterminatedallmarketingand importationorthe conclusionofanyCommission-relatedproceedinginvolvingtheequipment. ( PlethyInc )accepts,asofthedateofthefilingoftheapplication,theobligationofthe designatedU.S.agentforserviceofprocessfortheabovereferencedFCCID. DesignatedU.S.AgentInformation: Name:PlethyInc FRN:0035219609 Address:2362QumeDr,Suite#DSanJose,CA95131UnitedStates ContactPerson:RajaSundaram/CEO Tel.:(408)607-7646 Email:[email protected] Sincerely, ShenzhenKeanDigitalCo.,Ltd.PlethyInc Name:XiaolinZengName:RajaSundaram Title:ManagerTitle:CEO Date:2026-09-01 Date:2026-09-02

Cover Letter(s)

ShenzhenKeanDigitalCo.,Ltd. OfficeofEngineeringTechnology FederalCommunicationsCommission 7435OaklandMillsRoad Columbia,MD21046 USA Date:September8,2026 Subject;RequestforConfidentiality FCCID:2AKL2-R160801 ToWhomItMayConcern, PursuanttotheprovisionsoftheCommission’srulesTitle47Sections§0.457and§0.459,we arerequestingtheCommissiontowithholdthefollowingattachment(s)asconfidential documentsfrompublicdisclosureindefinitely. Thesedocumentscontaindetailedsystemandequipmentdescriptionsandareconsideredas proprietaryinformationinoperationoftheequipment.Thepublicdisclosureofthese documentsmightbeharmfultoourcompanyandwouldgivecompetitorsanunfairadvantage inthemarket. SchematicDiagram BlockDiagram OperationalDescription FCCSoftwareSecurityRequirementsforUNIIdevices Inadditionaltoabovementioneddocuments,inordertocomplywiththemarketingregulations inTitle47CFR§2.803andtheimportationrulesinTitle47CFR§2.1204,whileensuringthat businesssensitiveinformationremainsconfidentialuntiltheactualmarketingofnewly authorizeddevices,werequestShortTermConfidentialityofthefollowingattachment(s); ExternalPhotos TestSetupPhotos InternalPhotos UserManual For45days,pursuanttoPublicNoticeDA04-1705. OR For180dayspursuanttoKDB726920D01. Itisourunderstandingthatallmeasurementtestreports,FCCIDlabelformatand correspondenceduringthecertificationreviewprocesscannotbegrantedasconfidential documentsandthisinformationwillbeavailableforpublicreviewoncethegrantofequipment authorizationisissued. Sincerely, Signature: Name:XiaolinZeng Title:Manager

Cover Letter(s)

ShenzhenKeanDigitalCo.,Ltd. To:QAILABORATORIESLTD. DECLARATIONOFIDENTITY Herebywe: ShenzhenKeanDigitalCo.,Ltd. (NameofManufacturer) BasicModelNumber:N98WHR BasicBrandName:/ BasicProductName:NetworkVideoRecorder BasicTestReportApplication Number:QCT26HR-0172E-01、QCT26HR-0172E-02、 QCT26HR-0173E-01、QCT26HR-0173E-02、 DeclaretheCircuit,PCBLayout;ElectricalPartsandOutlookofthefollowing product(s)areidenticaltothebasicmodel: □  New/☑AdditionalModelNumber(s):N98WHG □New/□AdditionalBrandName(s): □New/□AdditionalProductName(s): Exceptthefollowing(s):PCBboard,structureandinternalofthese model(s)arethesame,Justdifferenceistheshellandmodel. Remarks: SignaturewithCompanyChop: PrintedName:XiaolinZeng DATE:2026.09.01

Cover Letter(s)

EffectiveDate:April2,2020QSF7.6.4-8–AgentAuthorizationLetterTemplatePage1of1 RevisionDate:Revision:0 ShenzhenKeanDigitalCo.,Ltd. Date:Date:September2,2026 ProductModelNumber:N98WHR FCCID:2AKL2-R160801 Towhomitmayconcern, Re:ProductCertificationRepresentativeAuthorizationLetter WeauthorizeQAILaboratoriesLtd.3980NorthFraserWay,BurnabyB.C.CanadaV5J5K5to actonourbehalfonallmattersconcerningtheabovenamedequipment. Thisshallincludethefollowing: Testing Approvalapplicationsandprocedures WedeclarethatQAILaboratoriesLtd.isallowedtoforwardallinformationrelatedtothe approvalprojecttotheappliedcertificationbodyandtothenotificationentitiesandtodiscuss anyissuesconcerningtheapprovalapplication.AnyandallactscarriedoutbyQAILaboratories Ltd.onourbehalfshallhavethesameeffectasactsofourown. By: ContactListedonFCCWesbite Title:Manager Email:[email protected] Telephone:0755-28286082 Onbehalfof:ShenzhenKeanDigitalCo.,Ltd.

Cover Letter(s)

ShenzhenKeanDigitalCo.,Ltd. FCCSoftwareConfigurationControlDeclaration Date:September8,2026 FederalCommunicationsCommission 7435OaklandMillsRoad Columbia,MD21046 USA Attn:OETDept. Product/ModelNumber:NetworkVideoRecorder/N98WHR FCCID:2AKL2-R160801 RegardingFCCCountryCodeSelectionguidelinesidentifiedinKDB594280. “Allapplicationsforequipmentauthorizationfortransmittersthatcanhave radioparameters,orothertechnicalparameters,reportedtotheCommission setbysoftwaremusthaveanattestationindicatingthatnothirdpartywillhave software,orconfigurationcontrol,toprogramthedeviceoutofcomplianceof thetechnicalrulesunderwhichithasbeencertified.” Wedeclarethatnothirdpartywillhavesoftware,orconfigurationcontrol,toprogram thedeviceoutofcomplianceofthetechnicalrulesunderwhichithasbeencertified. Name:XiaolinZengDate:September8,2026 Title:Manager Signatureofapplicant ：

External Photos

ID Label/Location Info

FCCID:2AKL2-R160801 Size:60*40

Internal Photos

RF Exposure Info

ShenzhenQCTestingLaboratoryCo.,Ltd. Page1of5 Address:Eastof1/F.,BuildingE,XinghongSciencePark,No.111,ShuikuRoad,Fenghuanggang,XixiangStreet,Bao'anDistrict,Shenzhen,Guangdong,China Tel:0755-23008269Fax:0755-23726780http://www.qctest.com.cn FCCID:2AKL2-R160801 RFExposureEvaluation FCCKDBpublication447498D01GeneralRFExposureGuidancev06:MobileandPortableDevicesRF ExposureProceduresandEquipmentAuthorizationPolicies. Limits Thecriterialistedinthefollowingtableshallbeusedtoevaluatetheenvironmentimpactofhumanexposure toradiofrequency(RF)radiationasspecifiedin1.1307(b) LimitsforMaximumPermissibleExposure(MPE) Frequencyrange (MHz) Electricfield strength (V/m) Magneticfieldstrength (A/m) Powerdensity (mW/cm 2 ) Averagingtime (minutes) (A)LimitsforOccupational/ControlledExposures 0.3–3.06141.63*(100)6 3.0–301842/f4.89/f*(900/f 2 )6 30–30061.40.1631.06 300–1500f/3006 1500–100,00056 (B)LimitsforGeneralPopulation/UncontrolledExposure 0.3–1.346141.63*(100)30 1.34–30824/f2.19/f*(180/f 2 )30 30–30027.50.0730.230 300–1500f/150030 1500–100,0001.030 f=frequencyinMHz Friistransmissionformula:Pd=(Pout*G)/(4*pi*r 2 ) Where Pd=powerdensityinmW/cm 2 ,Pout=outputpowertoantennainmW; G=gainofantennainlinearscale,Pi=3.1416; R=distancebetweenobservationpointandcenteroftheradiatorincm PdidthelimitofMPE,1mW/cm 2 .Ifweknowthemaximumgainoftheantennaandthetotalpowerinputto theantenna,throughthecalculation,wewillknowthedistancerwheretheMPElimitisreached. TestProcedure SoftwareprovidedbyclientenabledtheEUTtotransmitandreceivedataatlowest,andhighestchannel individually. ShenzhenQCTestingLaboratoryCo.,Ltd. Page2of5 Address:Eastof1/F.,BuildingE,XinghongSciencePark,No.111,ShuikuRoad,Fenghuanggang,XixiangStreet,Bao'anDistrict,Shenzhen,Guangdong,China Tel:0755-23008269Fax:0755-23726780http://www.qctest.com.cn TestResultofRFExposureEvaluation WIFImodule1: For2.4GWIFI AntennaGain:3.39dBi Test Mode Minimum Separation Distance (cm) Output Power (dBm) Target power (dBm) Target power (mW) Antenna Gain (Numeric) Power Density Limit (mW/cm 2 ) Power Density At20cm (mW/cm 2 ) Test Results 802.11b20.0012.8412±131.6232.1810.01346Pass 802.11g 20.0014.37 14±1 25.1192.1810.02133 Pass 802.11 n(HT20) 20.0015.9615±125.1192.1810.02685Pass 802.11 n(HT40) 20.0015.8515±119.9532.1810.02685Pass For5.2GWIFI AntennaGain:4.71dBi Test Mode Minimum Separation Distance (cm) Output Power (dBm) Target power (dBm) Target power (mW) Antenna Gain (Numeric) Power Density Limit (mW/cm 2 ) Power Density At20cm (mW/cm 2 ) Test Results 802.11a20.0013.82 13±1 31.6232.9610.01694Pass 802.11n2020.0013.83 13±1 25.1192.9610.01694 Pass 802.11n4020.0013.1213±125.1192.9610.01694Pass 802.11ac2020.0013.9613±119.9532.9610.01694Pass 802.11ac4020.0012.9912±119.9532.9610.01346Pass ShenzhenQCTestingLaboratoryCo.,Ltd. Page3of5 Address:Eastof1/F.,BuildingE,XinghongSciencePark,No.111,ShuikuRoad,Fenghuanggang,XixiangStreet,Bao'anDistrict,Shenzhen,Guangdong,China Tel:0755-23008269Fax:0755-23726780http://www.qctest.com.cn WIFImodule2: ANT1:For2.4GWIFI AntennaGain:3.30dBi Test Mode Minimum Separation Distance (cm) Output Power (dBm) Target power (dBm) Target power (mW) Antenna Gain (Numeric) Power Density Limit (mW/cm 2 ) Power Density At20cm (mW/cm 2 ) Test Results 802.11b20.0012.3712±131.6232.1410.01310Pass 802.11g 20.0014.89 14±1 25.1192.1410.02076 Pass 802.11 n(HT20) 20.0013.8413±125.1192.1410.01649Pass 802.11 n(HT40) 20.0015.9715±119.9532.1410.02614Pass For5.2GWIFI AntennaGain:3.37dBi Test Mode Minimum Separation Distance (cm) Output Power (dBm) Target power (dBm) Target power (mW) Antenna Gain (Numeric) Power Density Limit (mW/cm 2 ) Power Density At20cm (mW/cm 2 ) Test Results 802.11a20.0013.47 13±1 31.6232.1710.01684Pass 802.11n2020.0013.3213±125.1192.1710.01684 Pass 802.11n4020.0012.4712±125.1192.1710.01338Pass 802.11ac2020.0013.3813±119.9532.1710.01684Pass 802.11ac4020.0012.4712±119.9532.1710.01338Pass ShenzhenQCTestingLaboratoryCo.,Ltd. Page4of5 Address:Eastof1/F.,BuildingE,XinghongSciencePark,No.111,ShuikuRoad,Fenghuanggang,XixiangStreet,Bao'anDistrict,Shenzhen,Guangdong,China Tel:0755-23008269Fax:0755-23726780http://www.qctest.com.cn ANT2:For2.4GWIFI AntennaGain:3.30dBi Test Mode Minimum Separation Distance (cm) Output Power (dBm) Target power (dBm) Target power (mW) Antenna Gain (Numeric) Power Density Limit (mW/cm 2 ) Power Density At20cm (mW/cm 2 ) Test Results 802.11b20.0013.5513±131.6232.1410.01649Pass 802.11g 20.0014.64 14±1 25.1192.1410.02076 Pass 802.11 n(HT20) 20.0014.6414±125.1192.1410.02076Pass 802.11 n(HT40) 20.0015.6715±119.9532.1410.02614Pass For5.2GWIFI AntennaGain:3.37dBi Test Mode Minimum Separation Distance (cm) Output Power (dBm) Target power (dBm) Target power (mW) Antenna Gain (Numeric) Power Density Limit (mW/cm 2 ) Power Density At20cm (mW/cm 2 ) Test Results 802.11a20.0013.14 13±1 31.6232.1710.01684Pass 802.11n2020.0013.10 13±1 25.1192.1710.01684 Pass 802.11n4020.0012.35 12±1 25.1192.1710.01338Pass 802.11ac2020.0013.23 13±1 19.9532.1710.01684Pass 802.11ac4020.0012.41 12±1 19.9532.1710.01338Pass ShenzhenQCTestingLaboratoryCo.,Ltd. Page5of5 Address:Eastof1/F.,BuildingE,XinghongSciencePark,No.111,ShuikuRoad,Fenghuanggang,XixiangStreet,Bao'anDistrict,Shenzhen,Guangdong,China Tel:0755-23008269Fax:0755-23726780http://www.qctest.com.cn Simultaneoustransmit: NO,Configurations MaximumMPEValue Limits WIFI2.4GHzWIFI5GHz Transmit simultaneously 12.4GHz+5GHz0.026140.016840.042981 Note: 1.TwoindependentWLANmodulesareintegratedinEUT.Firmwaretime-divisioncontrolensuresonlyone moduletransmitsatanytime,simultaneoustransmissionisforbidden.Eachmoduleisevaluatedseparately, nopowersuperposition. 2.AccordingtoKDB447498D01GeneralRFExposureGuidancev06,Atthetransmitsimultaneously calculationmethodisasfollows: TransmitsimultaneouslyMPE=ΣofMPEratios MPEratios=Fieldstrengthsorpowerdensity/MPElimitatthetestfrequency Conclusion: ThemeasurementresultscomplywiththeFCCLimitper47CFR2.1091fortheuncontrolledRF Exposure.

Test Report

Tengxiang Technology.Inc 东莞市腾祥电子有限公司 Product Number: AN2450-FPC404BX Product Name: Antenna Page 1 Specification For Approval Date: 2025.8.12 Version: 1.0 客户名称 Customer：旭峰客户料号 Customer P/N：腾祥料号 T X P/N： AN2450-FPC404BX 规格描述 Description : 2.4G/5G FPC 天线 1.13mm 黑色线L=240mm+IPEX Tengxiang Checked By: 腾祥审核 CustomerApproved By: 客户审核 DRAWN 制作苏业阳 TESTED BY 检测 CHECKED BY 审核胡超 CHECKED BY 审核 Q.C.DEPT. 品管周志红 Q.C.DEPT. 品管 APPROVED BY 核准韦佳 APPROVEDBY 核准 NO.53 Shatou ShaChong Road, ChangAn Town, Guangdong province, China 中国广东省东莞市长安镇沙头区沙涌路53号 TEL:86-769-81873082 FAX:86-769-82663788 http://www.tenxiang.cn 0.24.001.00016 Tengxiang Technology.Inc 东莞市腾祥电子有限公司 Product Number: AN2450-FPC404BX Product Name: Antenna Page 2 Index: 1. Specification (规格) 2. Antenna - S Parameter Test Data (样品测试数据) 3. Antenna - Radiation Pattern Test Data (辐射模式测试数据) 4. Mechanical and Packing Drawing (图纸包装规范) Revision History（变更履历） RevisionDateChange NotificationDescription 1.02025.8.12 初版 Tengxiang Technology.Inc 东莞市腾祥电子有限公司 Product Number: AN2450-FPC404BX Product Name: Antenna Page 3 1. Specification Sample Photo A. Electrical Characteristics Frequency频率2400-2500 MHz/5150-5850MHz S.W.R.驻波比<= 2.0 Antenna Gain增益3.39dBi/4.76dBi Polarization 极化方式 Linear Impedance 阻抗50 Ohm B. Material & Mechanical Characteristics Cable Type线材规格 1.13mm,BIack Connector Type连接器规格I-PEX C. Environmental Storage Temperature 存储温度 - 40 ̊C ~ +80 ̊C Operation Temperature 工作温度 - 40 ̊C ~ +80 ̊C Tengxiang Technology.Inc 东莞市腾祥电子有限公司 Product Number: AN2450-FPC404BX Product Name: Antenna Page 4 2. Characteristics and Reliability Test Test Items 测试项目 Test Condition and Procedure 测试方法 Requirements 要求Result 结果 1V.S.W.R. 电压驻波比 Set DUT on Network Analyzer; make individual calibration to test设置网络分析仪参数进行测试 Directive DUT specification 符合待测物规范 PASS 2Insertion Loss插入损失 Set DUT on Network Analyzer; make individual calibration to test设置网络分析仪参数进行测试 Directive DUT specification 符合待测物规范 PASS 3Antenna Gain 天线增益 Set DUT on Antenna Chamber; make individual calibration to test设置天线暗室参数进行测试 Directive DUT specification 符合待测物规范 PASS 4Solderability 可焊性 GB / T2423.28-2005 Temp: 260±5°C;Duration: 5 seconds温度260± 5°C;持续5秒 Tin evenly on full 上锡均匀饱满 PASS 5Pull Test 拉力 Holding with individual specification; force applied to axis of terminal .单独定义产品端子拉力 1. Directive DUT specification 2. Frequency Tol.≤5% 符合待测物规范;频率偏移≤5% PASS 6Dimension 尺寸 Inspection of dimension, color, material, package, surface process.检查尺寸,颜色,材料,包装,表面处理 Directive DUT specification 符合待测物规范 PASS 7RoHSWith Reference to IEC 62321:2008 with flow chart 参考IEC 62321测试流程 Directive RoHS 2015/863/EU 符合RoHS 2015/863/EU标准 PASS Tengxiang Technology.Inc 东莞市腾祥电子有限公司 Product Number: AN2450-FPC404BX Product Name: Antenna Page 5 3. Antenna - S Parameter Test Data Tengxiang Technology.Inc 东莞市腾祥电子有限公司 Product Number: AN2450-FPC404BX Product Name: Antenna Page 6 4. Antenna - Radiation Pattern Test Data XZYZXY 2400MHz 2450MHz 无屏幕NVR Tengxiang Technology.Inc 东莞市腾祥电子有限公司 Product Number: AN2450-FPC404BX Product Name: Antenna Page 7 2500MHz 5150MHz 5550MHz 5850MHz 5. Mechanical Drawing See attached files B C D AN2450-FPC404BX / Antenna 1/1 ±0.2±0.1±1 OD1.13 Part Number Name CB-113BS Coaxial Cable 1 No. 2 1 1 Q'ty 1 Material Finish A SYY 2025.08.12 DES BY Note: 1.M ark is important dimension;"Cpk "Identify for pr ocess control(CpK 1.33). 2.To lerance:Unmarked tolerance refer to the standa rd tol erance please. 3.Pay atte ntion to the direction of the connector. APPROVER DATE SIGN DESCRIPTION SCALE: APP BY Tolerance X.XX X.X X° TITLE: PART NO.: CUSTOMER P/N: CHK BY RF BY UNITS: mm REVISION: HFREACHRoHS2.0 CONFIDENTIAL AN2450-FPC1132 FPC Black CR-113-ZP-A 3 Cu I-PEX Au Plated AN2450-FPC1132 Black 1 2 3 WJ 2025.08.12 HC 2025.08.12 YCX 2025.08.12 100pcs/ PE bag Revision : A Customer : ALL APPROVED BY CHECKED BY DESIGNED BY Name: Page: 1 of 1 Date: Part Number : 产品包装规范 PACKING CRITERION 8000pcs/Carton 3. SEALI NG 。 MEAS G W: KGS N W: KGS QTY: PCS ITEM NO: C/NO MADE IN CHINA SIDE FRONT 2.PACKING 1 . Enter PE bag。 2025.08.12 AN2450-FPC404BX Antenna AN2450-FPC1132

Test Report

Page1 TengxiangTechnology.Inc 东莞市腾祥电子有限公司 ProductNumber:AN2450-75F67GX-B ProductName:Antenna SpecificationForApproval Date:2024.12.20 Version:1.0 客户名称 Customer：旭峰客户料号 CustomerP/N：腾祥料号 TXP/N：AN2450-75F67GX-B 规格描述 Description:2.4G/5G黑色天线1.13mm灰色线L=160mm+IPEX TengxiangCheckedBy: 腾祥审核 CustomerApprovedBy: 客户审核 DRAWN 制作路婷 TESTEDBY 检测 CHECKEDBY 审核胡超 CHECKEDBY 审核 Q.C.DEPT. 品管江美如 Q.C.DEPT. 品管 APPROVEDBY 核准韦佳 APPROVEDBY 核准 NO.53ShatouShaChongRoad,ChangAnTown,Guangdongprovince,China 中国广东省东莞市长安镇沙头区沙涌路53号 TEL:86-769-81873082FAX:86-769-82663788 http://www.tenxiang.cn Page2 TengxiangTechnology.Inc 东莞市腾祥电子有限公司 ProductNumber:AN2450-75F67GX-B ProductName:Antenna Index: 1.Specification(规格) 2.CharacteristicsandReliabilityTest(产品特性和可靠性测试标准) 3.Antenna-SParameterTestData(样品测试数据) 4.Antenna-RadiationPatternTestData(辐射模式测试数据) 5.MechanicalandPackingDrawing(图纸包装规范) RevisionHistory（变更履历） RevisionDate ChangeNotification Description 1.02024.12.20 初版 Page3 TengxiangTechnology.Inc 东莞市腾祥电子有限公司 ProductNumber:AN2450-75F67GX-B ProductName:Antenna 1.Specification SamplePhoto A.ElectricalCharacteristics Frequency频率 2400-2500MHz/5150-5850MHz S.W.R.驻波比 <=2.5/<=2.5 AntennaGain 增益 3.37dBi/3.75dBi Polarization极化方式 Linear Impedance 阻抗 50Ohm B.Material&MechanicalCharacteristics MaterialofPlastic 塑胶材质 TPE/ABS CableType 线材规格 OD1.13mm，gray AntennaType 天线类型 RubberDuckAntenna ConnectorType 连接器规格 I-PEX C.Environmental StorageTemperature 存储温度 -30 ̊C~+65 ̊C OperationTemperature 工作温度 -30 ̊C~+65 ̊C AntennaColorStoragelife 天线颜色存储寿命 <2year Page4 TengxiangTechnology.Inc 东莞市腾祥电子有限公司 ProductNumber:AN2450-75F67GX-B ProductName:Antenna 2.CharacteristicsandReliabilitTest TestItems测试项目 TestConditionandProcedure 测试方法 Requirements要求 Result 结果 1V.S.W.R. 电压驻波比 SetDUTonNetworkAnalyzer;makeindividual calibrationtotest设置网络分析仪参数进行测试 DirectiveDUTspecification 符合待测物规范 PASS 2 Antenna Gain 天线增益 SetDUTonAntennaChamber;makeindividual calibrationtotest设置天线暗室参数进行测试 DirectiveDUTspecification 符合待测物规范 PASS 3 PullTest 拉力 Holdingwithindividualspecification;force appliedtoaxisofterminal.单独定义产品端子拉力 1.DirectiveDUTspecification 2.FrequencyTol.≤5% 符合待测物规范;频率偏移≤5% PASS 4 Dimension 尺寸 Inspectionofdimension,color,material,package, surfaceprocess.检查尺寸,颜色,材料,包装,表面处理 DirectiveDUTspecification 符合待测物规范 PASS 5 SaltSpray盐雾 GB/T2423.17-2008 Temp:35°C;RH:≥95%;NaClsolution:≥ 5%;Time:24H 温度35°C；湿度≥95%;盐水浓度≥5%；测试24H 1.NoVisualDamage 2.FrequencyTol.≤5% 无明显外观不良;频率偏移≤5% PASS 6 Temperature and Humidity Chamber 恒温恒湿 GB/T2423.3-2006 Temp:65°C/12H;-30°C/12HRH:≥90%;Time: 24H 温度65°C测试12H转-30°C测试12H；湿度≥90%；时间24H After2HoursRecovery 1.NoVisualDamage 2.FrequencyTol.≤5% 恢复2H后，无明显外观不良;频率偏移≤5% PASS 7 Agingtest 老化 GB/T2423.2-2008 Temp:65°C;Time:24hours 温度65°C，测试24H After2HoursRecovery 1.NoVisualDamage 2.FrequencyTol.≤5% 无明显外观不良;频率偏移≤5% PASS 8RoHS WithReferencetoIEC62321:2008withflowchart 参考IEC62321测试流程 DirectiveRoHS2011/65/EU 符合RoHS2015/863/EU标准 PASS y Page5 TengxiangTechnology.Inc 东莞市腾祥电子有限公司 ProductNumber:AN2450-75F67GX-B ProductName:Antenna 3.Antenna-SParameterTestData 4.Antenna-RadiationPatternTestData Page6 TengxiangTechnology.Inc 东莞市腾祥电子有限公司 ProductNumber:AN2450-75F67GX-B ProductName:Antenna XZYZXY 2400MHz 2450MHz 2500MHz 5150MHz Page7 TengxiangTechnology.Inc 东莞市腾祥电子有限公司 ProductNumber:AN2450-75F67GX-B ProductName:Antenna 5550MHz 5850MHz 5.MechanicalDrawingSeeattachedfiles C 27 HF SIGNDATEDESCRIPTIONAPPROVER B RoHS2.0 D REACH CONFIDENTIAL Note: 196.02.0 CC 1.Dimension:Take*istheimportantdimension 2.Tolerance:Unmarkedtolerancerefertothestandardtoleranceplease 5 CR-113-ZP-A I-PEX CuAuPlated 1 4 CB-113GS Cable OD1.13,GRAY 1 3 AN9201-09B-ABS Body3 ABS BLACK 1 2 AN9201-06B Body2 ABS BLACK 1 1 ANT75-WD-01B Body1 TPE BLACK 1 No. PartNumber Name Material Finish Q'ty AA 7 dwf 2024.12.20 Tolerance TITLE: 2.4/5.8GHzAntenna PARTNO.:AN2450-75F67GX-B APPBYCHKBYRFBY YCXHCWJ 2024.12.202024.12.202024.12.20 X.X ±0.5 X.XX±0.2 X° ±1° DWGNAME: DESBY UNITS:mm SCALE:1/1 REVISION: A TengxiangTechnologyInc. Date: 2024.12.20 產品包裝規範 PACKINGCRITERION Page:1of1 PartNumber : AN2450-75F67GX-B Revision:A Name: Antenna Customer:ALL 1.EnterPEbag。 2.PACKING 。 1000pcs/Carton 3.SEALING。 FRONT C/NO MADEINCHINA >> APPROVEDBY： YCX CHECKEDBY： HC DESIGNEDBY： DWF ITEMNO: QTY:PCS NW:KGS GW:KGS MEAS 50pcs/PEbag SIDE

Test Report

Shenzhen QC Testing Laboratory Co., Ltd. Report No.: QCT26HR-0172E-02 Page 1 of 65 Address: East of 1/F., Building E, Xinghong Science Park, No.111, Shuiku Road, Fenghuanggang, Xixiang Street, Bao'an District, Shenzhen, Guangdong, China Tel: 0755-23008269 Fax: 0755-23726780 www.qctest.com.cn FCC PART 15.407 TEST REPORT On Behalf of Shenzhen Kean Digital Co., Ltd. Room 1001 Rujun Building, No. 105,Zhongxing Road, Ma' antang Community,Bantian Street, Longgang District, Shenzhen,518129,China. FCC ID: 2AKL2-R160801 Model: N98WHR September10, 2026 T hi s Repor t Concer ns: Or iginal Report Equi pm ent T ype: Network Video Recorder Test Engineer: Fan Yang Report Number: QCT26HR-0172E-02 Test Date: August 13 2026 ~ September10, 2026 Test Result: Pass Reviewed By: Vincent Yang / Approved By: Kendy Wang / Prepared By: Shenzhen QC Testing Laboratory Co., Ltd. East of 1/F., Building E, Xinghong Science Park, No.111, Shuiku Road, Fenghuanggang, Xixiang Street, Bao'an District, Shenzhen, Guangdong, China Tel: 0755-23008269 Fax: 0755-23726780 Shenzhen QC Testing Laboratory Co., Ltd. Report No.: QCT26HR-0172E-02 Page 2 of 65 Address: East of 1/F., Building E, Xinghong Science Park, No.111, Shuiku Road, Fenghuanggang, Xixiang Street, Bao'an District, Shenzhen, Guangdong, China Tel: 0755-23008269 Fax: 0755-23726780 www.qctest.com.cn Table of Contents 1. GENERAL INFORMATION ............................................................................................ 5 1.1 Product Description for Equipment under Test (EUT) ............................................................. 5 1.2 System Test Configuration ...................................................................................................... 6 1.3 Test Facility ............................................................................................................................. 8 1.4 Measurement Uncertainty ....................................................................................................... 8 2. SUMMARY OF TEST RESULTS ................................................................................... 9 3. LIST OF TEST AND MEASUREMENT INSTRUMENTS ............................................. 10 3.1 Conducted Emission Test ..................................................................................................... 10 3.2 Radiated Emission Test ........................................................................................................ 10 3.3 RF Conducted test ................................................................................................................ 11 4. ANTENNA REQUIREMENT ......................................................................................... 12 5. CONDUCTED EMISSIONS .......................................................................................... 13 5.1 Applicable Standard .............................................................................................................. 13 5.2 Limit ....................................................................................................................................... 13 5.3 Test setup .............................................................................................................................. 13 5.4 EMI Test Receiver Setup....................................................................................................... 13 5.5 Test procedure ...................................................................................................................... 13 5.6 Test Data ............................................................................................................................... 13 6. EMISSION BANDWIDTH ............................................................................................. 16 6.1.Test Method of -26dB Bandwidth .......................................................................................... 16 6.2.Test Method of 99% Bandwidth............................................................................................. 16 6.3.Test setup .............................................................................................................................. 16 6.4.Test Data ..........................................................................................................................…

Text truncated - open the document above for the full version.

Contact Information

Applicant

Xiaolin Zeng(Manager)

[email protected]Fax: 0755-28286082

Technical Contact

Plethy IncRaja Sundaram

[email protected]

2362 Qume Dr, Suite #D San Jose, · United States

Test Firm

Shenzhen QC Testing Laboratory CO., Ltd.Kendy Wang

[email protected]

Technical Specifications

#	Rule Parts	Frequency Range	Power Output
1	15E	5.18 GHz - 5.24 GHz	24.89 mW

Confidentiality

Long Term

Grant Notes

Output power listed is maximum conducted power. This device contains 20 and 40 MHz signal bandwidth. The antennas used with this transmitter must be installed to provide a minimum separation distance of at least 20 cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter, except in accordance with FCC multi- transmitter product procedures. End-users must be provided with operating procedures for satisfying RF exposure compliance.
