2AKL2N44WETNetwork Video Recorder

Shenzhen Kean Digital Co., Ltd. Room 1001, Rujun Building, No. 105, Zhongxing Road, Ma'antang Community, Bantian Street, Longgang District, Shenzhen, 518129 China Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 USA Date: Sep. 19, 2024 Ref: Attestation Statements Part 2.911(d)(5)(i) Filing FCC ID: 2AKL2N44WET FRN: 0026103432 [Shenzhen Kean Digital Co., Ltd.] (“the applicant”) certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. Sincerely, (Applicant signature) (Xiaolin Zeng)

Shenzhen Kean Digital Co., Ltd. Room 1001, Rujun Building, No. 105, Zhongxing Road, Ma'antang Community, Bantian Street, Longgang District, Shenzhen, 518129 China Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 USA Date: Sep. 19, 2024 Ref: Attestation Statements Part 2.911(d)(5)(ii) Filing FCC ID: 2AKL2N44WET FRN: 0026103432 [Shenzhen Kean Digital Co., Ltd.] (“the applicant”) certifies that, as of the date of the filing of the application, the applicant is not identified on the Covered List as an entity producing “covered” equipment. Sincerely, (Applicant signature) (Xiaolin Zeng)

Shenzhen Kean Digital Co., Ltd. Room 1001, Rujun Building, No. 105, Zhongxing Road, Ma'antang Community, Bantian Street, Longgang District, Shenzhen, 518129 China Sep. 19, 2024 Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 USA Subject: Explanation of differences between product types FCC ID: 2AKL2N44WET Models: N44WET, N44WEF, N44WEE, N44WEV, N44WER, N44WES, N44WEP, N48WED, N48WEE, N48WEF, L7134, L7174, L7154, L7164, L8004, L8014, L8024, L5064, L5074, L5514, L5524, L5534 To Whom It May Concern: We, Shenzhen Kean Digital Co., Ltd. hereby declare that all the models are the same except for the model name and color. Sincerely, Shenzhen Kean Digital Co., Ltd. Signature: [Xiaolin Zeng, Manager]

Shenzhen Kean Digital Co., Ltd. Room 1001, Rujun Building, No. 105, Zhongxing Road, Ma'antang Community, Bantian Street, Longgang District, Shenzhen, 518129 China Letter of Authorization Company: Shenzhen Kean Digital Co., Ltd. Address: Room 1001, Rujun Building, No. 105, Zhongxing Road, Ma'antang Community, Bantian Street, Longgang District, Shenzhen, 518129 China Product Name: Network Video Recorder Model Number(s): N44WET, N44WEF, N44WEE, N44WEV, N44WER, N44WES, N44WEP, N48WED, N48WEE, N48WEF, L7134, L7174, L7154, L7164, L8004, L8014, L8024, L5064, L5074, L5514, L5524, L5534 Product Description: Network Video Recorder We authorize MiCOM Labs Inc., 575 Boulder Court, Pleasanton, California 94566, USA, to act on our behalf on all matters concerning the certification of above named equipment. We declare that MiCOM Labs Inc. is allowed to forward all information related to the approval and certification of equipment to the regulatory agencies as required and to discuss any issues concerning the approval application. Any and all acts carried out by MiCOM Labs on our behalf shall have the same effect as acts of our own. Signature: Date: Sep. 19, 2024 Name: Xiaolin Zeng Title: General Manager Company: Shenzhen Kean Digital Co., Ltd.

FCC ID Label Location 30mm*50mm (On the back of the product) FCC ID: 2AKL2N44WET This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

Page 1 of 10 RF Exposure Report Report No.: AGC08045240801FH01 FCC ID : 2AKL2N44WET APPLICATION PURPOSE : Original Equipment PRODUCT DESIGNATION : Network Video Recorder BRAND NAME : N/A MODEL NAME : N44WET, N44WEF, N44WEE, N44WEV, N44WER, N44WES, N44WEP, N48WED, N48WEE, N48WEF, L7134, L7174, L7154, L7164, L8004, L8014, L8024, L5064, L5074, L5514, L5524, L5534 APPLICANT : Shenzhen Kean Digital Co., Ltd. DATE OF ISSUE : Sep. 18, 2024 STANDARD(S) : FCC Part 2 Subpart J §2.1091 REPORT VERSION : V1.0 Attestation of Global Compliance (Shenzhen) Co., Ltd Report No.: AGC08045240801FH01 Page 2 of 10 Report Revise Record Report Version Revise Time Issued Date Valid Version Notes V1.0 / Sep. 18, 2024 Valid Initial Release Report No.: AGC08045240801FH01 Page 3 of 10 Table of Contents 1. General Information ........................................................................................................................................ 4 2. Product Information ........................................................................................................................................ 5 2.1 Product Technical Description ................................................................................................................... 5 3. Test Environment ............................................................................................................................................ 6 3.1 Address Of The Test Laboratory ............................................................................................................... 6 3.2 Test Facility ................................................................................................................................................ 6 3.3 Environmental Conditions ......................................................................................................................... 7 4. Portable Device Evaluation Method and Limit ............................................................................................. 8 5. Mobile Device Evaluation Method and Limit ................................................................................................ 9 6. Measurement Results ................................................................................................................................... 10 7. Measurement Evaluation .............................................................................................................................. 10 Report No.: AGC08045240801FH01 Page 4 of 10 1. General Information Applicant Shenzhen Kean Digital Co., Ltd. Address Room 1001, Rujun Building, No. 105, Zhongxing Road, Ma'antang Community, Bantian Street, Longgang District, Shenzhen, 518129 China Manufacturer Shenzhen Kean Digital Co., Ltd. Address Room 1001, Rujun Building, No. 105, Zhongxing Road, Ma'antang Community, Bantian Street, Longgang District, Shenzhen, 518129 China Factory Shenzhen Zhongan Xunshi Technology Co., Ltd Address 3rd Floor, Building D, No. 3, Pingxi 7th Road, Nanping Science and Technology Industrial Park, Zhuhai China Product Designation Network Video Recorder Brand Name N/A Test Model N44WET Series Model(s) N44WEF, N44WEE, N44WEV, N44WER, N44WES, N44WEP, N48WED, N48WEE, N48WEF, L7134, L7174, L7154, L7164, L8004, L8014, L8024, L5064, L5074, L5514, L5524, L5534 Difference Description All the same except for the model name and color. Date of receipt of test item Aug. 15, 2024 Date of Test Aug. 15, 2024 to Sep. 18, 2024 Deviation from Standard No any deviation from the test method Condition of Test Sample Normal Test Result Pass Test Report Form No AGCER-FCC-RF Exposure-V1 Note: The test results of this report relate only to the tested sample identified in this report. Prepared By Thea Huang (Project Engineer) Sep. 18, 2024 Reviewed By Calvin Liu (Reviewer) Sep. 18, 2024 Approved By Max Zhang (Authorized Officer) Sep. 18, 2024 Report No.: AGC08045240801FH01 Page 5 of 10 2. Product Information 2.1 Product Technical Description Frequency Band (Operating) WLAN: 2.412GHz ~ 2.462GHz Hardware Version V3.2.2.4 Software Version V111 Modulation Type 2.4G WLAN: 802.11b:(DQPSK, DBPSK, CCK) DSSS 802.11g/n:(64-QAM,16-QAM, QPSK, BPSK) OFDM Device Category Portable (<20cm separation) Mobile (>20cm separation) Others: Antenna Diversity Single antenna Multiple antennas Tx diversity Rx diversity Tx/Rx diversity Antenna Designation Copper Tube Antenna Antenna Gain 2.29dBi Minimum Assessment Distance 20cm Evaluation Applied MPE Evaluation SAR Evaluation Report No.: AGC08045240801FH01 Page 6 of 10 3. Test Environment 3.1 Address Of The Test Laboratory Laboratory: Attestation of Global Compliance (Shenzhen) Co., Ltd. Address: 1-2/F, Building 19, Junfeng Industrial Park, Chongqing Road, Heping Community, Fuhai Street, Bao'an District, Shenzhen, Guangdong, China 3.2 Test Facility The test facility is recognized, certified, or accredited by the following organizations: CNAS-Lab Code: L5488 Attestation of Global Compliance (Shenzhen) Co., Ltd. has been assessed and proved to follow CNAS-CL01 Accreditation Criteria for Testing and Calibration Laboratories (identical to ISO/IEC17025: 2017 General Requirements for the Competence of Testing and Calibration Laboratories.) A2LA-Lab Cert. No.: 5054.02 Attestation of Global Compliance (Shenzhen) Co., Ltd. EMC Laboratory has been accredited by A2LA for technical competence in the field of electrical testing, and proved to follow ISO/IEC 17025: 2017 General Requirements for the Competence of Testing and Calibration Laboratories and any additional program requirements in the identified field of testing. FCC-Registration No.: 975832 Attestation of Global Compliance (Shenzhen) Co., Ltd. EMC Laboratory has been registered and fully described in a report filed with the FCC (Federal Communications Commission). The acceptance letter from the FCC is maintained in our files with Registration 975832. IC-Registration No.: 24842(CAB identifier: CN0063) Attestation of Glo…

Text truncated - open the document above for the full version.

SPE CIFIC A TIO N Shenzhen Guandetong Electronic Co., Ltd. 2.4G 2DB Copper Tube Antenna Product Specifications Customer MAB Frequency band 2400MHz-2500MHz Customer Opinion： ☑OK □NG Table of contents 1、cover............................................1 2、parameter ...............................................................................3 3、date .........................................................................................4 4、Product Structure ...............................................................4 5、Antenna gain........................................................................ 5 6、Reliability Test..................................5 Company Address: 3rd Floor, Building D, Maoyuan Industrial Park, Huanguan South, Guanhu Street, Longhua District, ShenzhenTell：0755-88298396 FAX：0755-89733896 http://ww w.szgdtrf.com Page 2 1- Product images 2、parameter Test parameters 2.4G a n t e n n a (Na m e) ( Model Type) GDT-TG-P2.4G-75 (Electrical Specifications) (Frenquency Range) 2400MHz-2500MHz （Polarization） vertical (I m pedance) （VS W R） (Gain) 50 Ω ≦2.0 2.29dBi Vertacal (Po w er) (Band width 50W 100MHz ( Mechanical Specifications) Gray，yellow (Di mensions) 4.4MM*24.5MM IPEX (1 ) (Chassis Color) (Cable Length) (Connector) (Chassis Material) 140±3mm Brass -40°C-+85°C -40°C-+85°C ( W orking Te m p erature) (Li mit Te m p erature) http://ww w.szgdtrf.com Page 3 3、S11（ VS W R 、Return loss 、S mith）data 4、Product Structure http://ww w.szgdtrf.com Page 4 5、Antenna gain 6、Reliability Test

Page 1 of 119 FCC Test Report Report No.: AGC08045240801FR01 FCC ID : 2AKL2N44WET APPLICATION PURPOSE : Original Equipment PRODUCT DESIGNATION : Network Video Recorder BRAND NAME : N/A MODEL NAME : N44WET, N44WEF, N44WEE, N44WEV, N44WER, N44WES, N44WEP, N48WED, N48WEE, N48WEF, L7134, L7174, L7154, L7164, L8004, L8014, L8024, L5064, L5074, L5514, L5524, L5534 APPLICANT : Shenzhen Kean Digital Co., Ltd. DATE OF ISSUE : Sep. 18, 2024 STANDARD(S) : FCC Part 15 Subpart C §15.247 REPORT VERSION : V1.0 Attestation of Global Compliance (Shenzhen) Co., Ltd Report No.: AGC08045240801FR01 Page 2 of 119 Report Revise Record Report Version Revise Time Issued Date Valid Version Notes V1.0 / Sep. 18, 2024 Valid Initial Release Report No.: AGC08045240801FR01 Page 3 of 119 Table of Contents 1. General Information ........................................................................................................................................ 5 2. Product Information ........................................................................................................................................ 6 2.1 Product Technical Description ................................................................................................................... 6 2.2 Table of Carrier Frequency ........................................................................................................................ 7 2.3 IEEE 802.11n Modulation Scheme ........................................................................................................... 8 2.4 Related Submittal(S) / Grant (S) ............................................................................................................... 9 2.5 Test Methodology ...................................................................................................................................... 9 2.6 Special Accessories .................................................................................................................................. 9 2.7 Equipment Modifications ........................................................................................................................... 9 2.8 Antenna Requirement................................................................................................................................ 9 2.9 Description of Test Software ................................................................................................................... 10 3. Test Environment .......................................................................................................................................... 12 3.1 Address of The Test Laboratory .............................................................................................................. 12 3.2 Test Facility .............................................................................................................................................. 12 3.3 Environmental Conditions ....................................................................................................................... 13 3.4 Measurement Uncertainty ....................................................................................................................... 13 3.5 List of Equipment Used ........................................................................................................................... 14 4. System Test Configuration ........................................................................................................................... 16 4.1 EUT Configuration ................................................................................................................................... 16 4.2 EUT Exercise ........................................................................................................................................... 16 4.3 Configuration of Tested System .............................................................................................................. 16 4.4 Equipment Used in Tested System ......................................................................................................... 16 4.5 Summary of Test Results ........................................................................................................................ 17 5. Description of Test Modes ........................................................................................................................... 18 6. Duty Cycle Measurement ............................................................................................................................. 19 7. RF Output Power Measurement .................................................................................................................. 23 7.1 Provisions Applicable .............................................................................................................................. 23 7.2 Measurement Procedure ......................................................................................................................... 23 7.3 Measurement Setup (Block Diagram of Configuration) .......................................................................... 23 7.4 Measurement Result ............................................................................................................................... 24 8. 6dB Bandwidth Measurement ...................................................................................................................... 26 8.1 Provisions Applicable .............................................................................................................................. 26 8.2 Measurement Procedure ......................................................................................................................... 26 8.3 Measurement Setup (Block Diagram of Configuration) .......................................................................... 26 8.4 Measurement Re…

Text truncated - open the document above for the full version.

Report No.: AGC08045240801FR01 Page 62 of 119 Test_Graph_802.11n20_ANT2_2412_MCS0_PSD Test_Graph_802.11n20_ANT2_2437_MCS0_PSD Report No.: AGC08045240801FR01 Page 63 of 119 Test_Graph_802.11n20_ANT2_2462_MCS0_PSD Report No.: AGC08045240801FR01 Page 64 of 119 10. Conducted Band Edge and Out-of-Band Emissions 10.1 Provisions Applicable In any 100kHz bandwidth outside the frequency bands in which the spread spectrum intentional radiator in operating, the radio frequency power that is produced by the intentional radiator shall be at least 20dB below that in the 100kHz bandwidth within the band that contains the highest level of the desired power. 10.2 Measurement Procedure Remove the antenna from the EUT and then connect a low loss RF cable from the antenna port to the spectrum analyzer. Use the following spectrum analyzer settings:  Step 1: Measurement Procedure In-Band Reference Level 1. Set instrument center frequency to DTS channel center frequency. 2. Set the span to ≥ 1.5 times the DTS bandwidth. 3. Set the RBW = 100 kHz. 4. Set the VBW ≥ 3 x RBW. 5. Detector = peak. 6. Sweep time = auto couple. 7. Trace mode = max hold. 8. Allow trace to fully stabilize. 9. Use the peak marker function to determine the maximum PSD level. 10. Note that the channel found to contain the maximum PSD level can be used to establish the reference level. 11. For reference level values, please refer to DTS bandwidth test.  Step 2: Measurement Procedure Out of Band Emission 1. Set RBW = 100 kHz. 2. Set VBW ≥ 300 kHz. 3. Detector = peak. 4. Sweep = auto couple. 5. Trace Mode = max hold. 6. Allow trace to fully stabilize. 7. Use the peak marker function to determine the maximum amplitude level. Note: The cable loss and attenuator loss were offset into measure device as an amplitude offset. 10.3 Measurement Setup (Block Diagram of Configuration) Report No.: AGC08045240801FR01 Page 65 of 119 10.4 Measurement Result Test Graphs of Spurious Emissions in Non-Restricted Frequency Bands-2.4G WIFI (Module: RTL8192FC) Test_Graph_802.11b_ANT1_2412_1Mbps_Lower Band Emissions Report No.: AGC08045240801FR01 Page 66 of 119 Test_Graph_802.11b_ANT1_2412_1Mbps_Higher Band Emissions Test_Graph_802.11b_ANT1_2437_1Mbps_Lower Band Emissions Test_Graph_802.11b_ANT1_2437_1Mbps_Higher Band Emissions Report No.: AGC08045240801FR01 Page 67 of 119 Test_Graph_802.11b_ANT1_2462_1Mbps_Lower Band Emissions Test_Graph_802.11b_ANT1_2462_1Mbps_Higher Band Emissions Report No.: AGC08045240801FR01 Page 68 of 119 Test_Graph_802.11g_ANT1_2412_6Mbps_Lower Band Emissions Test_Graph_802.11g_ANT1_2412_6Mbps_Higher Band Emissions Report No.: AGC08045240801FR01 Page 69 of 119 Test_Graph_802.11g_ANT1_2437_6Mbps_Lower Band Emissions Test_Graph_802.11g_ANT1_2437_6Mbps_Higher Band Emissions Report No.: AGC08045240801FR01 Page 70 of 119 Test_Graph_802.11g_ANT1_2462_6Mbps_Lower Band Emissions Test_Graph_802.11g_ANT1_2462_6Mbps_Higher Band Emissions Report No.: AGC08045240801FR01 Page 71 of 119 Test_Graph_802.11n20_ANT1_2412_MCS0_Lower Band Emissions Test_Graph_802.11n20_ANT1_2412_MCS0_Higher Band Emissions Report No.: AGC08045240801FR01 Page 72 of 119 Test_Graph_802.11n20_ANT1_2437_MCS0_Lower Band Emissions Test_Graph_802.11n20_ANT1_2437_MCS0_Higher Band Emissions Report No.: AGC08045240801FR01 Page 73 of 119 Test_Graph_802.11n20_ANT1_2462_MCS0_Lower Band Emissions Test_Graph_802.11n20_ANT1_2462_MCS0_Higher Band Emissions Report No.: AGC08045240801FR01 Page 74 of 119 Test_Graph_802.11n40_ANT1_2422_MCS0_Lower Band Emissions Test_Graph_802.11n40_ANT1_2422_MCS0_Higher Band Emissions Report No.: AGC08045240801FR01 Page 75 of 119 Test_Graph_802.11n40_ANT1_2437_MCS0_Lower Band Emissions Test_Graph_802.11n40_ANT1_2437_MCS0_Higher Band Emissions Report No.: AGC08045240801FR01 Page 76 of 119 Test_Graph_802.11n40_ANT1_2452_MCS0_Lower Band Emissions Test_Graph_802.11n40_ANT1_2452_MCS0_Higher Band Emissions Report No.: AGC08045240801FR01 Page 77 of 119 Test Graphs of Band Edge Emissions in Non-Restricted Frequency Bands-2.4G WIFI (Module: RTL8192FC) Test_Graph_802.11b_ANT1_2412_1Mbps_Lower Band Edge Emissions Test_Graph_802.11g_ANT1_2412_6Mbps_Lower Band Edge Emissions Report No.: AGC08045240801FR01 Page 78 of 119 Test_Graph_802.11n20_ANT1_2412_MCS0_Lower Band Edge Emissions Test_Graph_802.11n40_ANT1_2422_MCS0_Lower Band Edge Emissions Report No.: AGC08045240801FR01 Page 79 of 119 Test Graphs of Spurious Emissions in Non-Restricted Frequency Bands-2.4G WIFI (Module: ATBM6012B) Test_Graph_802.11b_ANT2_2412_1Mbps_Lower Band Emissions Test_Graph_802.11b_ANT2_2412_1Mbps_Higher Band Emissions Report No.: AGC08045240801FR01 Page 80 of 119 Test_Graph_802.11b_ANT2_2437_1Mbps_Lower Band Emissions Test_Graph_802.11b_ANT2_2437_1Mbps_Higher Band Emissions Report No.: AGC08045240801FR01 Page 81 of 119 Test_Graph_802.11b_ANT2_2462_1Mbps_Lower Band Emissions Test_Graph_802.11b_ANT2_2462_1Mbps_Higher Band Emissions Report No.: AGC08045240801FR01 Page 82 of 119 Test_Graph_802.11g_ANT2_2412_6Mbps_Lower Band Emissions Test_Graph_802.11g_ANT2_2412_6Mbps_Higher Band Emissions Report No.: AGC08045240801FR01 Page 83 of 119 Test_Graph_802.11g_ANT2_2437_6Mbps_Lower Band Emissions Test_Graph_802.11g_ANT2_2437_6Mbps_Higher Band Emissions Report No.: AGC08045240801FR01 Page 84 of 119 Test_Graph_802.11g_ANT2_2462_6Mbps_Lower Band Emissions Test_Graph_802.11g_ANT2_2462_6Mbps_Higher Band Emissions Report No.: AGC08045240801FR01 Page 85 of 119 Test_Graph_802.11n20_ANT2_2412_MCS0_Lower Band Emissions Test_Graph_802.11n20_ANT2_2412_MCS0_Higher Band Emissions Report No.: AGC08045240801FR01 Page 86 of 119 Test_Graph_802.11n20_ANT2_2437_MCS0_Lower Band Emissions Test_Graph_802.11n20_ANT2_2437_MCS0_Higher Band Emissions Report No.: AGC08045240801FR01 Page 87 of 119 Test_Graph_802.11n20_ANT2_2462_MCS0_Lower Band Emissions Test_Graph_802.11n20_ANT2_2462_MCS0_Higher Band Emissions Report No.: AGC08045240801FR01 Page 88 of 119 Test Graphs of Band Edge Emissions in Non-Restricted Frequency Bands-2.4G WIFI (Module: …

Text truncated - open the document above for the full version.

Report No.: AGC08045240801FR01 Page 115 of 119 12. AC Power Line Conducted Emission 12.1 Measurement Limits Frequency Maximum RF Line Voltage Q.P (dBμV) Average (dBμV) 150kHz~500kHz 66-56 56-46 500kHz~5MHz 56 46 5MHz~30MHz 60 50 Note: 1. The lower limit shall apply at the transition frequency. 2. The limit decreases linearly with the logarithm of the frequency in the range 0.15 MHz to 0.50 MHz. 12.2 Block Diagram of Line Conducted Emission Test Report No.: AGC08045240801FR01 Page 116 of 119 12.3 Preliminary Procedure of Line Conducted Emission Test 1. The equipment was set up as per the test configuration to simulate typical actual usage per the user’s manual. When the EUT is a tabletop system, a wooden table with a height of 0.8 meters is used and is placed on the ground plane as per ANSI C63.10 (see Test Facility for the dimensions of the ground plane used). When the EUT is a floor-standing equipment, it is placed on the ground plane which has a 3-12 mm non-conductive covering to insulate the EUT from the ground plane. 2. Support equipment, if needed, was placed as per ANSI C63.10. 3. All I/O cables were positioned to simulate typical actual usage as per ANSI C63.10. 4. All support equipment received AC120V/60Hz power from a LISN, if any. 5. The EUT received DC 5V power from adapter which received AC120V/60Hz power from a LISN. 6. The test program was started. Emissions were measured on each current carrying line of the EUT using a spectrum Analyzer / Receiver connected to the LISN powering the EUT. The LISN has two monitoring points: Line 1 (Hot Side) and Line 2 (Neutral Side). Two scans were taken: one with Line 1 connected to Analyzer / Receiver and Line 2 connected to a 50 Ohm load; the second scan had Line 1 connected to a 50 Ohm load and Line 2 connected to the Analyzer / Receiver. 7. Analyzer / Receiver scanned from 150 kHz to 30MHz for emissions in each of the test modes. 8. During the above scans, the emissions were maximized by cable manipulation. 9. The test mode(s) were scanned during the preliminary test. Then, the EUT configuration and cable configuration of the above highest emission level were recorded for reference of final testing. 12.4 Final Procedure of Line Conducted Emission Test 1. EUT and support equipment was set up on the test bench as per step 2 of the preliminary test. 2. A scan was taken on both power lines, Line 1 and Line 2, recording at least the six highest emissions. Emission frequency and amplitude were recorded into a computer in which correction factors were used to calculate the emission level and compare reading to the applicable limit. If EUT emission level was less – 2dB to the A.V. limit in Peak mode, then the emission signal was re-checked using Q.P and Average detector. 3. The test data of the worst case was reported on the Summary Data page. 12.5 Test Result of Line Conducted Emission Test Report No.: AGC08045240801FR01 Page 117 of 119 AC Power Line Conducted Emission Test Test Mode Mode 1 LISN Line Hot Side RESULT: Pass Report No.: AGC08045240801FR01 Page 118 of 119 AC Power Line Conducted Emission Test Test Mode Mode 1 LISN Line Neutral Side RESULT: Pass Note: All modes and antennas in the conducted emission test are pre-scanned. The 2.4G WIFI (Module: RTL8192FC) is evaluated as the worst data. Report No.: AGC08045240801FR01 Page 119 of 119 Appendix I: Photographs of Test Setup Refer to the Report No.: AGC08045240801AP02 Appendix II: Photographs of Test EUT Refer to the Report No.: AGC08045240801AP03 -----End of Report----- Conditions of Issuance of Test Reports 1. All samples and goods are accepted by the Attestation of Global Compliance (Shenzhen) Co., Ltd (the “Company”) solely for testing and reporting in accordance with the following terms and conditions. The company provides its services on the basis that such terms and conditions constitute express agreement between the company and any person, firm or company requesting its services (the “Clients”). 2. Any report issued by Company as a result of this application for testing services (the “Report”) shall be issued in confidence to the Clients and the Report will be strictly treated as such by the Company. It may not be reproduced either in its entirety or in part and it may not be used for advertising or other unauthorized purposes without the written consent of the Company. The Clients to whom the Report is issued may, however, show or send it, or a certified copy thereof prepared by the Company to its customer, supplier or other persons directly concerned. The Company will not, without the consent of the Clients, enter into any discussion or correspondence with any third party concerning the contents of the Report, unless required by the relevant governmental authorities, laws or court orders. 3.The Company shall not be called or be liable to be called to give evidence or testimony on the Report in a court of law without its prior written consent, unless required by the relevant governmental authorities, laws or court orders. 4. In the event of the improper use of the report as determined by the Company, the Company reserves the right to withdraw it, and to adopt any other additional remedies which may be appropriate. 5. Samples submitted for testing are accepted on the understanding that the Report issued cannot form the basis of, or be the instrument for, any legal action against the Company. 6. The Company will not be liable for or accept responsibility for any loss or damage however arising from the use of information contained in any of its Reports or in any communication whatsoever about its said tests or investigations. 7.Clients wishing to use the Report in court proceedings or arbitration shall inform the Company to that effect prior to submitting the sample for testing. 8. The Company is not responsible for recalling the electronic version of the original report when any revision is made to them. The Client assumes the responsibility to providing the revised version to an…
