2AKOLPZ0005Personal Protective Equipment for eyes with augmented reality connected to Control Unit

USER MANUAL VisionAR Sommario 1. Smart Glasses Overview .................................................................................................................... 2 2. Smart Glasses Before Starting ........................................................................................................... 3 3. Smart Glasses - What’s in the Box ..................................................................................................... 4 4. Control Unit Overview ...................................................................................................................... 6 5. Control Unit Before Starting .................................................................................................................. 8 6. Control Unit – What’s in the box ........................................................................................................... 9 7. Control Unit – How to charge the battery pack ................................................................................ 10 8. FCC and ISED Compliance ................................................................................................................ 13 1. Smart Glasses Overview VisionAR offers the following: a) Capacitive Touch b) Haptic Feedback c) AR Optical Module d) Inertial Measurement Unit e) Expansion Interface a) Capacitive Touch A capacitive touch sensor which can be programmed to be interpreted as - Tap - Double Tap - Forward - Back b) Haptic feedback A haptic feedback can be programmed for signalling an alarm to VisionAR (i.e. vibration) c) AR Optical Module The optical module is composed of a transparent display which can be aligned with the field of vision d) Inertial Measurement Unit Triaxial accelerometer, gyroscope and magnetometer are on board to detect user's relative position and movement e) Expansion Interface The expansion interface allows to increase the functionalities of VisionAR by connecting compatible device (e.g Camera) through standard I2C protocol 2. Smart Glasses Before Starting Assembling your safety glasses 1. Take the glasses and cables out of the box 2. Fasten the elastic headband to the glasses temples using clips 3. Insert the USB cable into the USB slot on the optical module 4. Lock the USB cable to temples by clip Disassembling your safety glasses Make sure that the Control Unit is turned off 1. Un-plug the USB cable from the Control Unit 2. Unlock the USB cable from clip 3. Un-plug the USB cable from the optical module 4. Remove the elastic headband from glasses 5. Remove the lenses by pulling it from the opposite side respect to the Optical module 6. Remove the optical unit by: a. Lifting the two metal clips which are present on the top of the VisionAR. b. Gently pull the optical unit out of the protective lenses. 3. Smart Glasses - What’s in the Box Opening the VisionAR Smart Glasses box (Figure 1), the portable case is immediately visible; all the accessories will be displayed in this page. Figure 1: Panoramic of VisionAR Smart Glasses box Portable case Inside the box, the portable case has the following content: - Glasses with Gradient lens mounted - Spare Clear lens - Quick User Guide - Informative Note Figure 2: Portable case appearance Figure 3: Portable case content VisionAR design is illustrated in Figure 4, a gradient lens will be mounted as default (Figure 5). Spare clear lens is available in the package (Figure 6): Figure 4: VisionAR design, rear view Accessories All supplied accessories are shown in Figure 8, a dividing layer separates portable case compartment from accessories (Figure 7): Figure 7: Dividing layer Figure 8: All the supplied accessories All the accessories 1 Screwdriver 2 Clip 3 USB cable 4 Cleaning cloth and liquid 5 Elastic headband 4. Control Unit Overview Specs  Processor (model, number of cores, frequency (rate)); Quad-core: NXP IMX6Q @800 MHz  RAM (capacity): 1 GB  Built-in memory (capacity): 4 GB  Use of memory cards: up to 16 GB  GSM, GPS radio-module  Wi-Fi std 802.11 b/g/n  Bluetooth standard 4.2 and BLE connection  Battery (type, battery capacity, run time on a single charge, recharging time): Main battery, 4000 mAh, runtime about 4hrs, recharging time about 4hrs. Additional back- up battery: 500 mAh for hot swap.  Controller availability: four virtual buttons via capacitive touch-pad on the glasses, four physical buttons on the Control Unit.  Sound (speakers, microphone); only by Bluetooth device Figure 1: Frontal view of Univet Control Unit 1. Programmable LEDs (see LED lights) 2. USB type C port (see Ports) 3. USB type micro B port (see Ports) Ports Two ports are present on the top side of the CU (as indicated in Figure 1): - USB Type C port which is used to connect the glasses to the CU - USB Type Micro B port to access to CU in Debug Mode LED Lights The CU has four LED lights (as indicated in Figure 1): o Status LED o Bluetooth, Wi-Fi and GSM LEDs During Control Unit update operations, LED lights behaviour is typical and described in Control Unit Update. Status LED Operating system manage Status LED in this way: - blinking red LED: external battery charge < 20 % and internal battery charge > 50 % - steady red LED: external battery charge < 20 % and internal battery charge < 50 % - blinking violet LED: VisionAR smart glasses is not recognized by Control Unit It is recommended to fix the LED light (e.g. blue color) when application is running. LED light color management is assigned to software application Note: if the Battery Pack is disconnected from the Contol Unit, the Status LED is steady red Bluetooth, Wi-Fi and GSM LEDs The LEDs are programmable and can be turn on through a custom application when modules are active CU Buttons Univet Control Unit has different buttons as you can see in Figure 2: Figure 2: Top and Lateral view of Univet Control Unit 1. Power button 2. ESC 3. Up 4. Enter/Confirm 5. Down 5. Control Unit Before Starting TURN ON/OFF Here the procedure to turn ON and turn OF…

Text truncated - open the document above for the full version.

Control Unit QUICK GUIDE What’s in the box?Control Unit (CU) Top View 3 • Put your VisionAR on For more information scan here! 2 • Placement the Control Unit 5 • Turn on the CU 1 • Check the status of the battery 4 • Plug the VisionAR into the CU LEVEL 1: 1 Control Unit (CU) and battery pack 1 Spare battery 1 Charger 3 Plug Adapters 1 USB type A to type micro-B PowerUSB C Port Battery release latch Bluetooth WI-FI GSM Status LED Turn ON/OFF slide Battery status button/LED 20cm USB Charger Micro - B Port ETL-PN0006.01 Rev.1.0

VisionAR Terms and Conditions VisionAR Exported on 10/16/2020 VisionAR – VisionAR Terms and Conditions – 2 Table of Contents 1Warranty..................................................................................................................4 2General Terms and Conditions...............................................................................5 3Precautions and Recommendations......................................................................6 3.1General Usage Notes.....................................................................................................................6 3.2Cables............................................................................................................................................6 3.3Battery...........................................................................................................................................7 3.4Third Party Accessories.................................................................................................................7 3.5Third Party Control Units..............................................................................................................7 3.6Control Unit Safety........................................................................................................................7 4Risks.........................................................................................................................9 4.1Electromagnetic Interference......................................................................................................9 4.2Magnetic Connector......................................................................................................................9 4.3Radio Modules...............................................................................................................................9 4.4Personal Safety...........................................................................................................................10 4.5Health..........................................................................................................................................10 VisionAR – VisionAR Terms and Conditions – 3 • • • • The following pages describe the terms and conditions which apply to the use of VisionAR glasses,the possible health and safety risks and the limitations on the applicability of the product warranty. Warranty(see page 4) General Terms and Conditions(see page 5) Precautions and Recommendations(see page 6) Risks(see page 9) VisionAR – VisionAR Terms and Conditions Warranty – 4 • • • 1 Warranty This product is guaranteed to be free from defects in materials and workmanship according to European standards. This product does not contain user serviceable parts. Repairs must be carried out exclusively by an authorized Univet s.r.l Service Center. Unauthorized repairs or modifications could cause permanent damage and invalidate the warranty; furthermore, modifications to the PPE by anyone other than the manufacturer and/or replacement of parts that do not conform to the required standards, may reduce performance and invalidate its certification. Spare parts, if required, can be requested from Univet S.r.l. The replacement of structural components, if not specified in the packages or in a separate note, must be carried out only by Univet S.r.l. This warranty does not cover damage caused by normal wear and tear or as a result of opening or repairing the Product by an unauthorized Service Center and does not cover damage caused by: improper use, moisture, liquids, proximity or exposure to heat and accidents, abuse, non-compliance with the instructions supplied with the Product, negligence or incorrect application. This warranty does not cover physical damage to the PPE or to the device. Furthermore, this limited warranty does not cover: third-party software or drivers that can be installed on the Control Unit which is not supplied pre-installed software downloadable software from our website or by an authorized technician The limited warranty does not cover the installation, removal or maintenance of the device or any related costs. In addition, this warranty does not cover any issues related to the use of our drivers, software or this device with systems, including Operating Systems and hardware, that do not meet the requirements indicated in the related documentation. We do not provide commercial or other warranties for our devices and accessories other than the warranty set out in these Terms and Conditions. This limited warranty is provided in place of any other warranties or similar obligations (if any) created by advertising, documentation, packaging, or similar. The provisions of this clause do not affect any of your legal rights under applicable mandatory national law, including but not limited to your legal guarantee of conformity for goods. Univet S.r.l. reserves the right to evaluate the complete replacement and/or restoration of the article. Items that have deteriorated due to wear, improper use or tampering with are excluded from maintenance and/or replacement operations. VisionAR – VisionAR Terms and Conditions General Terms and Conditions – 5 • • • • • • • 2 General Terms and Conditions You acknowledge, using this device, that its software and services are not intended or suitable for environments where they could cause inaccuracies or delays in the information provided by the device, injury, death or damage to the environment. Univet S.r.l, within the limits of the law, declines responsibility for damages that may occur if the device is used in unsuitable conditions. Before using the PPE (Personal Protective Equipment) it is necessary: Verify that the item meets your requirements (by reading this disclaimer) Verify that the frame, lenses and display are not damaged or defective in any way that could compromise visibility or their structural impact resistance. If they are damaged or defective, the …

Text truncated - open the document above for the full version.

Via G. Prati, 87 - 25086 Rezzato (BS) - Italy Tel. +39 030-2499411 Fax. +39 030-2499430 www.univet.it - [email protected] EXTERNAL PHOTO CONTROL UNIT Via G. Prati, 87 - 25086 Rezzato (BS) - Italy Tel. +39 030-2499411 Fax. +39 030-2499430 www.univet.it - [email protected] Via G. Prati, 87 - 25086 Rezzato (BS) - Italy Tel. +39 030-2499411 Fax. +39 030-2499430 www.univet.it - [email protected] Via G. Prati, 87 - 25086 Rezzato (BS) - Italy Tel. +39 030-2499411 Fax. +39 030-2499430 www.univet.it - [email protected] Eyeglasses and Control unit

FCC ID: 2AKOLPZ0005

Via G. Prati, 87 - 25086 Rezzato (BS) - Italy Tel. +39 030-2499411 Fax. +39 030-2499430 www.univet.it - [email protected] INTERNAL PHOTO CONTROL UNIT Computational Unit Via G. Prati, 87 - 25086 Rezzato (BS) - Italy Tel. +39 030-2499411 Fax. +39 030-2499430 www.univet.it - [email protected] Via G. Prati, 87 - 25086 Rezzato (BS) - Italy Tel. +39 030-2499411 Fax. +39 030-2499430 www.univet.it - [email protected] Battery Pack

The results of tests and checks reported in this Test Report refer exclusively to the samples tested and described in the Report itself. This Report shall not be reproduced partially the written approval of IMQ S.p.A.. The authenticity of this Test Report and its contents can be verified by contacting IMQ S.p.A., responsible for this Test Report. EMF ASSESSMENT REPORT No. AR19-0046101-01 performed in accordance with FCC Rules: Code of Federal Regulations (CFR) no. 47 Part 15 Subpart C § 1.1307(b)(1) INDUSTRY CANADA Spectrum Management and Telecommunications Radio Standards Specification RSS-102:2015 Radio Frequency (RF) Exposure Compliance of Radiocommunication Apparatus (All Frequency Bands) PRODUCT Augmented reality safety glasses and control unit MODEL(s) TESTED VISIONAR and VISIONAR – CONTROL UNIT TRADE MARK(s) UNIVET APPLICANT UNIVET S.r.l. ∼ Via G. Prati, 87 ∼ I-25086 Rezzato (BS) Assessed by Robertino Torri [Laboratory technician] Approved by Giovanni Di Turi [Laboratory Manager] Revision Sheet Release No. Date of Issue Revision Description Rev. 0 2020-06-10 First edition Digital signed - AR19-0046101-01_TR_SAR exclusion FCC_UNIVET - Glasses + Control unit Mod. 3609/ 3 B.U. P RODUCTS C ONFORMITY A SSESSMENT - R ADIO E QUIPMENT L ABORATORY Assessment Report No. AR19-0046101-01 Date: 2020-06-10 Page 2 of 10 Mod. 3609/ 3 B.U. P RODUCTS C ONFORMITY A SSESSMENT - R ADIO E QUIPMENT L ABORATORY 1. GENERAL DATA SAMPLE Samples received on / (Item(s) sampled and sent by applicant) IMQ reference samples BEM / Samples tested No. / Object under analysis recognition Not carried out Except where stated, characteristics of products were taken from client description and were not verified by the laboratory TEST LOCATION Testing dates / Testing laboratory. IMQ S.p.A. - Via Quintiliano, 43 – I-20138 Milano Testing site Viale Lombardia, 20 – I-20021 Bollate (MI) ENVIRONMENTAL CONDITIONING Parameter Measured Ambient Temperature / Relative Humidity / Atmospheric Pressure / The laboratory is monitored by a continuous environmental conditions measurements system. Temperature, humidity and pressure data are recorded on a weekly basis and stored in local archive. REMARKS Throughout this report a point is used as the decimal separator. The ability or reliability of this product to perform its intended function in a particular application has not been investigated. IMQ declines any responsibility derived from missing or wrong information provided aside by the applicant. Assessment Report No. AR19-0046101-01 Date: 2020-06-10 Page 3 of 10 Mod. 3609/ 3 B.U. P RODUCTS C ONFORMITY A SSESSMENT - R ADIO E QUIPMENT L ABORATORY 2. REFERENCE DOCUMENT DOCUMENT DATE TITLE 47 CFR Part 15 2015 Radio Frequency Device 447498 D01 v06 2015 RF exposure procedures and equipment authorization policies for mobile and portable devices RSS-102 2015 Radio Frequency (RF) Exposure Compliance of Radiocommunication Apparatus (All Frequency Bands) Assessment Report No. AR19-0046101-01 Date: 2020-06-10 Page 4 of 10 Mod. 3609/ 3 B.U. P RODUCTS C ONFORMITY A SSESSMENT - R ADIO E QUIPMENT L ABORATORY 3. UNIT UNDER TEST (EUT) DETAILS GENERAL DATA MODEL (basic) Description VISIONAR and VISIONAR – CONTROL UNIT Augmented reality safety glasses and control unit VARIANTS (derived) Description / / The VISIONAR – CONTROL UNIT contains the radio modules: Module FCC ID: IC code GSM and GPS N7NHL8548 2417C-HL8548 Wi-Fi, BT and BLE Z64-WL18SBMOD 451I-WL18SBMOD MANUFACTURER UNIVET S.r.l. ∼ Via G. Prati, 87 ∼ I-25086 Rezzato (BS) ASSEBLY PLANT(s) EUT IDENTIFICATION EUT type Glasses and control unit EUT use Fixed Mobile Portable EUT single or system Single System Antenna Type Antenna Model 2450AT45A100E by JOHANSON (for 2.4 GHz module) Type: Integral Dedicated External Gain 1.5 dBi typ. Antenna Model SRFC025-100 by ANTENOVA (for GSM module) Type: Integral Dedicated External Gain -3.31 dBi (@ 824-960 MHz) Assessment Report No. AR19-0046101-01 Date: 2020-06-10 Page 5 of 10 Mod. 3609/ 3 B.U. P RODUCTS C ONFORMITY A SSESSMENT - R ADIO E QUIPMENT L ABORATORY 4. SUMMARY OF EMF ASSESSMENT RESULTS POSSIBLE TEST CASE VERDICTS: Test object meets the requirement PASS Test object does not meet the requirement FAIL Evaluation of test result submit to customer C.E. CFR47 Part 15 TITLE RESULT 1.1307(b)(1) RF humane exposure PASS REF. OF RSS 102 TITLE RESULT RSS 102 - § 2.5.1 RF humane exposure PASS Assessment Report No. AR19-0046101-01 Date: 2020-06-10 Page 6 of 10 Mod. 3609/ 3 B.U. P RODUCTS C ONFORMITY A SSESSMENT - R ADIO E QUIPMENT L ABORATORY 5. RESULTS OF RF EXPOSURE EVALUATION 5.1 FCC TEST REQUIREMENT Systems operating under the provisions of this section shall be operated in a manner that ensures that the public is not exposed to radio frequency energy levels in excess of the Commission's guidelines § 1.1307(b)(1). EUT classification (fixed, mobile or portable devices) Portable according to § 2.1093(b) of this Chapter LIMITS According to § 2.1093 of this Chapter, by means of the following guidelines: OET Mobile and Portable Devices RF Exposure Procedures and Equipment Authorization Policies (447498 D01 General RF Exposure Guidance v06) Limit for maximum permissible Exposure (MPE) Frequency Range (MHz) Electric Field Strength (E) (V/m) Magnetic Field Strength (H) (A/m) Power Density (S) (mW/cm 2 ) Avarage Time (minutes) (A) Limits for Occupational/Controlled Exposure 0.3÷3.0 614 1.63 (100)* 6 3.0÷30 1842/f 4.89/f (900/f 2 )* 6 30÷300 61.4 0.163 1.0 6 300÷1500 -- -- f/300 6 1500÷100,000 -- -- 5 6 (B) Limits for General Population/Uncontrolled Exposure 0.3÷3.0 614 1.63 (100)* 30 3.0÷30 824/f 2.19/f (180/f 2 )* 30 30÷300 27.5 0.073 0.2 30 300÷1500 -- -- f/1500 30 1500÷100,000 -- -- 1.0 30 F = Frequency in MHz *Plane-wave equivalent power density The distance from the device’s transmitting antenna where the exposure level reaches the maximum permitted limit is calculated using the general equation: S = P*G/ 4πR 2 Where: S = Power Density (mW/cm 2 ) P = Conducted power…

Text truncated - open the document above for the full version.

The results of tests and checks reported in this Test Report refer exclusively to the samples tested and described in the Report itself. This Report shall not be reproduced partially the written approval of IMQ S.p.A.. The authenticity of this Test Report and its contents can be verified by contacting IMQ S.p.A., responsible for this Test Report. TEST REPORT No. AR19-0046100-01 performed in accordance with FCC Rules: Code of Federal Regulations (CFR) no. 47 Part 15 Subpart B Section 15.107 and 15.109 PRODUCT Augmented reality safety glasses and control unit MODEL(s) TESTED VISIONAR and VISIONAR – CONTROL UNIT TRADE MARK(s) UNIVET APPLICANT UNIVET S.r.l. ∼ Via G. Prati, 87 ∼ I-25086 Rezzato (BS) Assessed by Robertino Torri [Laboratory technician] Approved by Giovanni Di Turi [Laboratory manager] Revision Sheet Release No. Date Revision Description Rev. 0 2019-12-02 First edition Digital signed - AR19-0046097-01_TR_FCC Part B_UNIVET - Glasses Mod. TRF 3723/2 B.U. P RODUCTS C ONFORMITY A SSESSMENT – EMC & R ADIO E QUIPMENT L ABORATORY Test Report No. AR19-0046100-01 Date: 2019-12-02 Page 2 of 23 Mod. TRF 3723 / 2 B.U. P RODUCTS C ONFORMITY A SSESSMENT – EMC & R ADIO E QUIPMENT L ABORATORY 1. GENERAL DATA SAMPLE Samples received on 2019-10-30 (Item(s) sampled and sent by applicant) IMQ reference samples BEM 97592 Samples tested No. 1 for type Object under analysis recognition Not carried out Except where stated, characteristics of products were taken from client description and were not verified by the laboratory Date of acceptance of test item 2019-10-30 TEST LOCATION Testing dates 2019-10-30 ÷ 2019-11-29 Testing laboratory. IMQ S.p.A. - Via Quintiliano, 43 – I-20138 Milano Testing site Via Quintiliano, 43 – I-20138 Milano ENVIRONMENTAL CONDITIONING Parameter Measured Ambient Temperature 20.9 ÷ 22.5 °C Relative Humidity 54 ÷ 57 % Atmospheric Pressure 997 ÷ 1004 mbar The laboratory is monitored by a continuous environmental conditions measurements system. Temperature, humidity and pressure data are recorded on a weekly basis and stored in local archive. REMARKS Throughout this report a point is used as the decimal separator. The ability or reliability of this product to perform its intended function in a particular application has not been investigated. Unless otherwise specified, warnings, installation instruction and/or user manual provided with the sample have been checked in Italian or English version only. IMQ declines any responsibility derived from missing or wrong information provided aside by the applicant. Test Report No. AR19-0046100-01 Date: 2019-12-02 Page 3 of 23 Mod. TRF 3723 / 2 B.U. P RODUCTS C ONFORMITY A SSESSMENT – EMC & R ADIO E QUIPMENT L ABORATORY 2. REFERENCE DOCUMENT DOCUMENT DATE TITLE 47 CFR Part 15 2015 Radio Frequency Device ANSI C63.4 2014 Methods of Measurement of Radio-Noise Emissions from Low-Voltage Electrical and Electronic Equipment in the Range of 9 kHz to 40 GHz ANSI C63.10 2013 American National Standard for Testing Unlicensed Wireless Devices Test Report No. AR19-0046100-01 Date: 2019-12-02 Page 4 of 23 Mod. TRF 3723 / 2 B.U. P RODUCTS C ONFORMITY A SSESSMENT – EMC & R ADIO E QUIPMENT L ABORATORY 3. EQUIPMENT UNDER TEST (EUT) DETAILS GENERAL DATA (according to manufacturer declaration) MODEL (basic) Description VISIONAR and VISIONAR – CONTROL UNIT Augmented reality safety glasses and control unit VARIANTS (derived) Description / / The VISIONAR – CONTROL UNIT contains the radio modules: FCC ID: N7NHL8548 (GSM and GPS) FCC ID: Z64-WL18SBMOD (Wi-Fi, BT and BLE) MANUFACTURER UNIVET S.r.l. ∼ Via G. Prati, 87 ∼ I-25086 Rezzato (BS) ASSEMBLY PLANT(s) EUT IDENTIFICATION EUT composition Glasses and control unit EUT classification Fixed Vehicular Portable Other EUT standing / Supply voltage 5 V DC by dedicated battery pack Temperature range / Dimensions / Mass of equipment / Integrated radio module data Radio module / Receiver category / Modulation / Number of channels / Channel bandwidth / Operating frequency / Antenna / / / / Type: Integral Dedicated External Test Report No. AR19-0046100-01 Date: 2019-12-02 Page 5 of 23 Mod. TRF 3723 / 2 B.U. P RODUCTS C ONFORMITY A SSESSMENT – EMC & R ADIO E QUIPMENT L ABORATORY 4. TEST CONFGURATION OF UNIT UNDER TEST EUT PORTS Port Description Max length Enclosure Plastic AC power / / DC power 5 V DC (internal dedicated battery pack) / Earth / / Telecommunication / / Signal & Control / / Antenna / / STATE OF THE EUT DURING TESTS Ref. Mode Description #1 Operating Recharging battery of control unit with AC/DC adapter #2 Operating Glasses in normal operating mode (screen playback) supplied by control unit with Wi-Fi and GSM in transmission SUPPORT EQUIPMENT Defined as equipment needed for correct operation or loading of the EUT, but not considered as tested: Equipment Manufacturer Model AC/DC adapter for control unit battery recharging SHENZHEN KEYU POWER SUPPLY TECHNOLOGY CO. LTD. KA1602-0502000DEU EUT Antenna Port AC Power Port Earth Port Telecommunication Port Signal/Control Port DC Power Port Enclosure Port Test Report No. AR19-0046100-01 Date: 2019-12-02 Page 6 of 23 Mod. TRF 3723 / 2 B.U. P RODUCTS C ONFORMITY A SSESSMENT – EMC & R ADIO E QUIPMENT L ABORATORY ELECTROMAGNETICALLY RELEVANT COMPONENTS Component No. Manufacturer Model Main Board glasses 1 UNIVET Main board control unit 1 UNIVET RFI SUPPRESSION DEVICES Component No. Manufacturer Model Ferrite one turn on cable in proximity of control unit out (see also photographic documentation) 1 WHURT 742 711 31 S EMI PROTECTION DEVICES Component No. Manufacturer Model / / / / EUT TECHNICAL DOCUMENTATION Document Reference / / Test Report No. AR19-0046100-01 Date: 2019-12-02 Page 7 of 23 Mod. TRF 3723 / 2 B.U. P RODUCTS C ONFORMITY A SSESSMENT – EMC & R ADIO E QUIPMENT L ABORATORY 5. METHODS OF MEASUREMENT All compliance measurements have been carried out using the procedures described in the standard ANSI C63.4:2014 and Section 15.31 of CFR47 Part 15 – Subpart A (General)…

Text truncated - open the document above for the full version.

FCC ID: 2AKOLPZ0005 UNIVET Conduced Measurements Test Set-up Radiated Measurements Test Set-up
