2AL9B-AI9005Wireless Speaker

al AI9005 Speaker User Manu A Quick Look Char ging th e Speaker Contents Features - Speaker - Charging port - LED indicator - Speaker - USB charging cable - User Manual - To charge the speaker, aached the small end of the usb cable to the charging port located on the speaker. - Aached the other end to the USB port on a computer or USB charging adapter. - The LED light will turn RED while the speaker is charging and turn OFF once charging is complete. Power On/Off Play/Pause music Volume + / Next track To turn on the product, toggle the power switch to 'On'. To turn off the product, toggle the power switch to 'Off'. When playing music, press the Play/Pause button to pause the music, press again the same button to resume playing the music. Press the Volume + / Next track button to advance to the next track. Hold down the same button if you want to increase the music volume. Volume - / Previous Press the Volume - / Previous track button to return to the previous track. Hold down the same button if you want to decrease the music volume. Call controls ITEM# AI9005 When receiving an incoming call, press the Call button once to accept call, press again to decline call. If you press and hold the Call button, it will reject the incoming call instead of picking it up. Press the Call button twice and it will redial the last called number. Mode change Press the M button to switch modes: Bluetooth, Card Reader, and FM Radio. Speaker: 52mm Output: 4Ω 3W Bluetooth Version: 5.1 Transmission distance: 10m Battery:300mah Charge time:1-2H Play time:1-2h Size:135*85*45mm Radio mode In FM radio mode, press the '>' button to search for stations. Press and hold the '+' or '-' button to adjust the radio volume. *If the product experience poor signal reception in FM mode, connect it to a charging cable to enhance the signal reception. USB reader / MicroSD card reader Play music from a USB drive or MicroSD card by inserting them into the reader port. Music controls remain the same as in Bluetooth mode. O n an IOS or Android Device Go to SETTING>BLUETOOTH (Make sure Bluetooth is turned ON) Pai ring th e Speaker AI9005 Speaker AI9005 Speaker Controls Specifica�ons FCC Statement 1.USB reader 2.MicroSD card reader 3.Charging port 4.Power On/Off 5.Play / Pause / Call Controls 6.Volume + / Next Track 7.Volume - / Previous Track 8.Mode change 9.LED Indicator 10.Mic Warning To assure continued compliance, any changes or modifications not expressly approved by the party.Responsible for compliance could void the user’s authority to operate this equipment. This equipment complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation. NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: -Reorient or relocate the receiving antenna. -Increase the separation between the equipment and receiver. -Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. -Consult the dealer or an experienced radio/TV technician for help. FCC Radiation Exposure Statement: The device has been evaluated to meet general RF exposure requirement. The device can be used in the portable exposure condition without restriction. • • When you turn your speaker on, it will enter Bluetooth pairing mode and start to blink Blue. Open your smartphone's Bluetooth menu to enable Bluetooth and search for Bluetooth devices. Select "AI9005 Speaker" from the list of devices. Aer successful pairing, the speaker’s LED indicator will turn solid Blue. When playing music, the LED indicator will flash intermiently. • 1 5 9 10 6 7 8 23 4

[Shenzhen Shenglai Technology Co., Ltd] [Room 3110, Block C, Xintian Century Business Centre, Fuming Road, Futian, Shenzhen]] [China] Date: [2024.6.24] Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 FCC ID: [2AL9B-AI9005] FRN: [0026557025] US Agent – Attestation Statement / Part 2.911(d)(7) [Shenzhen Shenglai Technology Co., Ltd] certifies, that as of [2024.6.24], we have designated Sakar International , Inc to accept service o f process on our behalf for FCC ID: [2AL9B-AI9005]. [Shenzhen Shenglai Technology Co., Ltd], accepts to maintain an agent of service of process in the United States for no less than one year after her the grantee has permanently terminated all marketing and importation of the applicable equipment within the U.S., or the conclusion of any Commission-related administrative or judicial proeitceeding involving the equipment, whichever is later. Sakar International , Inc, accepts as of the date of the filing of th is application, the obligation of being the designated agent for the purpose of accepting service of process on behalf of [Shenzhen Shenglai Technology Co., Ltd] for FCC ID:[ 2AL9B-AI9005]. Designated Agent Information: Company Name: Sakar Interna�onal , Inc FRN: 0028102671 Address: 195 Carter Drive Edison, Edison,NJ 8817 United States Contact Person: DAWN LEITAO Phone: （800）637-1090 Email:[email protected] Sincerely, Company: [Shenzhen Shenglai Technology Co., Ltd] Designated Agent: [Sakar Interna�onal , Inc] Company Representative: [Leo Guo] Designated Agent Representative: [DAWN LEITAO] Signature: Signature:

Rev1/26/2023 (ShenzhenShenglaiTechnologyCo.,Limited) FederalCommunicationsCommission AuthorizationandEvaluationDivision 7435OaklandMillsRoad Columbia,MD21046 USA Date:08-01-2024 Ref:AttestationStatementsPart2.911(d)(5)(i)Filing FCCID：2AL9B-AI9005 [ShenzhenShenglaiTechnologyCo.,Limited](“theapplicant”)certifiesthattheequipmentforwhich authorizationissoughtisnot“covered”equipmentprohibitedfromreceivinganequipment authorizationpursuanttosection2.903oftheFCCrules. Sincerely, (Applicantsignature) (LeoGuo) Rev1/26/2023 (ShenzhenShenglaiTechnologyCo.,Limited) FederalCommunicationsCommission AuthorizationandEvaluationDivision 7435OaklandMillsRoad Columbia,MD21046 USA Date:08-01-2024 Ref:AttestationStatementsPart2.911(d)(5)(ii)Filing FCCID：2AL9B-AI9005 [ShenzhenShenglaiTechnologyCo.,Limited](“theapplicant”)certifiesthat,asofthedateofthefilingof theapplication,theapplicantisnotidentifiedontheCoveredList(asaspecificallynamedentityorany ofitssubsidiariesoraffiliates)asanentityproducing“covered” equipment. Sincerely, (Applicantsignature) (LeoGuo)

ShenzhenShenglaiTechnologyCo.,Limited FederalCommunicationsCommission AuthorizationandEvaluationDivision 7435OaklandMillsRoad Columbia,MD21046 Date:08-01-2024 SUBJECT:FCCID:2AL9B-AI9005 ToWhomItMayConcern: I,theundersigned,herebystatesthisequipmenthasbeentestedandfoundtocomply withthelimitsforaClassBdigitaldevice,pursuanttopart15oftheFCCRules,and willapplytheSupplier'sDeclarationofConformityproceduretotheclassB computerperipheralportionofthiscompositedevice.IunderstandthefollowingFCC requirements: 1.DevicessubjecttotheSDoCprocedurearerequiredtobetestedtoshow compliancewiththeFCCtechnicalregulationsbyarecognizedaccreditedtesting laboratory.ThetestinglaboratorymustbeaccreditedbyaCommissionapproved accreditationbodyordesignatedunderthetermsofagovernment-to-government MutualRecognitionAgreement(MRA).Alistingofthoseaccreditedtesting laboratoriesthathavebeenrecognizedbytheCommissionispublishedontheFCC Webpage:https://apps.fcc.gov/oetcf/eas/reports/TestFirmSearch.cfm(Selectthe "accredited"optiontosearchforFCCrecognizedaccreditedtestfirms.) 2.Pt2.1077containsthelistofinformationthatmustbeincludedintheSupplier's DeclarationofConformity,whichmustbesuppliedwitheachproductsold.The SDoCcomplianceinfoshallbeincludedintheUser’sManualorasaseparate sheet.Theinfomustcontainthename,address,andphonenumberofthe responsibleparty,whichmustbelocatedwithintheUnitedStates.Accordingto 2.909(b),theresponsiblepartyiseithertheManufactureroriftheproductis importedtheImporter. Regards, ShenzhenShenglaiTechnologyCo.,Limited ------------------------------- （LeoGuo）

ShenzhenShenglaiTechnologyCo.,Limited Rev11/20/07 FederalCommunicationsCommission AuthorizationandEvaluationDivision ConfidentialityRequestregardingapplicationforcertificationofFCCID:2AL9B-AI9005 PursuanttoSections0.457and0.459oftheCommission’sRules,weherebyrequestconfidential treatmentofinformationaccompanyingthisapplicationasoutlinedbelow: ExhibitTypeFileName BlockDiagram Schematics OperationalDescription BlockDiagram Schematics OperationalDescription Theabovematerialscontaintradesecretsandproprietaryinformationnotcustomarilyreleasedto thepublic.Thepublicdisclosureofthesematerialsmaybeharmfultotheapplicantandprovide unjustifiedbenefitstoitscompetitors. TheapplicantunderstandsthatpursuanttoSection0.457oftheRules,disclosureofthis applicationandallaccompanyingdocumentationwillnotbemadebeforethedateoftheGrant forthisapplication. PursuanttoDA04-1705June15,2004oftheCommission’spublicnotice,Wealsorequestingthe commissiontograntshort-termconfidentialityrequestonthefollowingattachmentsuntil180 daysaftertheGrantDateofEquipmentAuthorizations. ExhibitTypeFileName Sincerely, LeoGuo 08-01-2024

ShenzhenShenglaiTechnologyCo.,Limited Declarationonmodeldifference Wetheundersignedherebyconfirmthatthesemodelsareidentical,andallmodelshavethesame RFmodule,PCBlayout,Antenna,schematicsandcomponent.Onlydifferentonmodelnameand thecoloroftheproducte. ProductionnameTrademarkFCCModelno. WirelessSpeakerAIWA2AL9B-AI9005AI9005,AI9005-BLK Confirmedby: LeoGuo ShenzhenShenglaiTechnologyCo.,Limited 08-01-2024

ShenzhenShenglaiTechnologyCo.,Limited FederalCommunicationsCommission AuthorizationandEvaluationDivision 7435OaklandMillsRoad Columbia,MD21046 Date:08-01-2024 SUBJECT:FCCApplicationforFCCID:2AL9B-AI9005 ToWhomItMayConcern: We,theundersigned,herebyauthorizeSamLv.atEMTEK(DONGGUAN)CO.,LTD.on ourbehalf,toapplytotheFederalCommunicationsCommissiononourequipment.Any andallactscarriedoutbyEMTEK(DONGGUAN)CO.,LTD.onourbehalfshallhave thesameeffectasactsofourown. ThisistoadvisethatweareinfullcompliancewiththeAnti-DrugAbuseAct.We,the applicant,arenotsubjecttoadenialoffederalbenefitspursuanttoSection5301ofthe Anti-DrugActof1988,21USC853a,andnopartytotheapplicationissubjecttoadenial offederalbenefitspursuanttothatsection. Regards, Sincerely, LeoGuo 08-01-2024

ReportNo.EDG2406240009E003Page1of4Ver.1.0 FCCID:2AL9B-AI9005 ReportNo.EDG2406240009E003Page2of4Ver.1.0 ReportNo.EDG2406240009E003Page3of4Ver.1.0 ReportNo.EDG2406240009E003Page4of4Ver.1.0

ReportNo.EDG2406240009E003Page1of2Ver.1.0 FCCID:2AL9B-AI9005 BTANT ReportNo.EDG2406240009E003Page2of2Ver.1.0

ReportNo.EDG2406240009E00302RPage1of7Ver.1.0 TESTREPORT ProductName：WirelessSpeaker ModelNumber：AI9005,AI9005-BLK FCCID：2AL9B-AI9005 Preparedfor:ShenzhenShenglaiTechnologyCo.,Limited Address:Room3110,BlockC,XintianCenturyBusinessCentre, FumingRoad,FutianDistrict,Shenzhen,China Preparedby:EMTEK(DONGGUAN)CO.,LTD. Address:-1&2/F.,Building2,ZoneA,ZhongdaMarineBiotechnology ResearchandDevelopmentBase,No.9,XinchengAvenue, SongshanhuHigh-technologyIndustrialDevelopmentZone, Dongguan,Guangdong,China TEL:+86-0769-22807078 FAX:+86-0769-22807079 ReportNumber:EDG2406240009E00302R Date(s)ofTests:Jun24,2024toJul29,2024 Dateofissue:Jul30,2024 $二维码$ ReportNo.EDG2406240009E00302RPage2of7Ver.1.0 TableofContents 1.TESTRESULTCERTIFICATION...............................................................................................................................................3 2.EUTSPECIFICATION.................................................................................................................................................................5 3.TESTREQUIREMENT................................................................................................................................................................6 4.MEASUREMENTRESULT.........................................................................................................................................................7 ReportNo.EDG2406240009E00302RPage3of7Ver.1.0 1.TESTRESULTCERTIFICATION Applicant:ShenzhenShenglaiTechnologyCo.,Limited Address: Room3110,BlockC,XintianCenturyBusinessCentre,FumingRoad,Futian District,Shenzhen,China Manufacturer:GuangdongShenglaiTechnologyCo.,Ltd Address: ZhongtaiIndustrialZone,HengshanVillage,GuraoTown,ChaoyangArea, ShantouCity,GuangdongProvince,China Factory:GuangdongShenglaiTechnologyCo.,Ltd Address: ZhongtaiIndustrialZone,HengshanVillage,GuraoTown,ChaoyangArea, ShantouCity,GuangdongProvince,China EUT:WirelessSpeaker ModelName:AI9005,AI9005-BLK Trademark:AIWA MeasurementProcedureUsed: APPLICABLESTANDARDS STANDARDTESTRESULT §15.247(i),§2.1093 PASS TheaboveequipmentwastestedbyEMTEK(DONGGUAN)CO.,LTD.Thetestdata,dataevaluation,test procedures,andequipmentconfigurationsshowninthisreportweremadeinaccordancewiththeprocedures giveninANSIC63.10(2013)andtheenergyemittedbythesampleEUTtestedasdescribedinthisreportisin compliancewiththerequirementsofFCCRulesFCC§15.247(i),§2.1093. Thetestresultsofthisreportrelateonlytothetestedsampleidentifiedinthisreport DateofTest: Jun24,2024toJul29,2024 Preparedby: WarrenDeng/Editor Reviewer: TimDong/Supervisor Approve&AuthorizedSigner: SamLv/Manager ReportNo.EDG2406240009E00302RPage4of7Ver.1.0 ModifiedHistory VersionReportNo.RevisionDateSummary EDG2406240009E00302R/OriginalReport ReportNo.EDG2406240009E00302RPage5of7Ver.1.0 2. EUTSpecification CharacteristicsDescription Product:WirelessSpeaker ModelNumber: AI9005,AI9005-BLK Thesemodelarethesameexpectthemodelnameandthecolorofthe product,HereselectAI9005fortest. Sample:1# DataRate: 1MbpsforGFSKmodulation 2Mbpsforπ/4-DQPSKmodulation 3Mbpsfor8DPSKmodulation Modulation: GFSK,π/4-DQPSK,8DPSK OperatingFrequency Range(s): 2402-2480MHz NumberofChannels: 79channels TransmitPowerMax: -0.41dBm(0.000910W) AntennaGain:1.7dBi Powersupply: DC5VfromUSB DC3.7Vfrombattery Evaluationapplied:MPEEvaluation SAREvaluation ReportNo.EDG2406240009E00302RPage6of7Ver.1.0 3. TestRequirement SAREvaluation Accordingto447498D01V06,systemsoperatingundertheprovisionsofthissectionshallbeoperatedina mannerthatensuresthatthepublicisnotexposedtoradiofrequencyenergylevelinexcessofthe Commission’sguidelines. RoutineSARevaluationreferstothatspecificallyrequiredby§2.1093,usingmeasurementsorcomputer simulation.WhenroutineSARevaluationisnotrequired,portabletransmitterswithoutputpowergreaterthan theapplicablelowthresholdrequireSARevaluationtoqualityforTCBapproval. OneantennaisavailablefortheEUT.Theminimumseparationdistanceis5mm. ReportNo.EDG2406240009E00302RPage7of7Ver.1.0 4. MeasurementResult Antennagain:1.7dBi Transmit Frequency (MHz) Mode Measured Power (dBm) Tune upPower (dBm) Maxtuneup power (dBm) Calculation Result 1-gSAR 2402GFSK-3.09 -3±1-2 0.19563 2441GFSK-3.48-3±1-20.19723 2480GFSK-3.57-3±1-20.19873 2402Π/4-DQPSK-1.08-1±100.31003 2441Π/4-DQPSK-1.30-1±100.31253 2480Π/4-DQPSK-1.58-1±100.31503 24028DPSK-0.410±110.39023 24418DPSK-0.830±110.39343 24808DPSK-1.09-1±100.31503 AccordingtoKDB447498D01V06,nostand-alonerequiredforBTantenna,andnosimultaneousSAR measurementisrequired. ***EndofReport***

Productspecification QuickReferenceDate Antennamoduleonthesystemboard Frequency 2.45GHz *1 Ant.PortInputPwr.(dBm)0(Typ.BTclass2outputpower) Tot.Rad.Pwr.(dBm)-2.3(Inputpwr–losspwr) PeakEIRP(dBm)1.3 Directivity(dBi)1 (alldirectionantenna) Efficiency(dB)-2.3(58.5%) Gain(dBi)1.3(PeakGainXY-plane) MaximumPower(dBm)1.3(XY-plane) MinimumPower(dBm)-4(XY-plane) Avg.Power(dBm)-0.5(XY-plane) Max/MinRatio(dB)5.3(XY-plane) Max/AvgRatio(dB)1.8(XY-plane) Min/AvgRatio(dB)-3.5(XY-plane) AverageGain(dB)-0.5(AvgGainXY-plane) Allthetechnicaldataandinformationcontainedhereinaresubjecttochangewithoutpriornotice AntennaLayout&moduleonthesystemboard AntennaGain GainTable [email protected] PeakAvg.PeakAvg.PeakAvg. ModuleBoard 1.3-0.51.7-3.81.1-3.058.5% ReturnLoss TheEnvironmentofAntennaRadiationPattern 3Dradiationpatterndiagram XY-planeXZ-planeYZ-plane

ReportNo.EDG2406240009E00301RPage1of74Ver.1.0 $二维码$ TESTREPORT ProductName：WirelessSpeaker ModelNumber：AI9005,AI9005-BLK FCCID：2AL9B-AI9005 Preparedfor:ShenzhenShenglaiTechnologyCo.,Limited Address:Room3110,BlockC,XintianCenturyBusinessCentre, FumingRoad,FutianDistrict,Shenzhen,China Preparedby:EMTEK(DONGGUAN)CO.,LTD. Address:-1&2/F.,Building2,ZoneA,ZhongdaMarineBiotechnology ResearchandDevelopmentBase,No.9,XinchengAvenue, SongshanhuHigh-technologyIndustrialDevelopmentZone, Dongguan,Guangdong,China TEL:+86-0769-22807078 FAX:+86-0769-22807079 ReportNumber:EDG2406240009E00301R Date(s)ofTests:Jun24,2024toJul29,2024 Dateofissue:Jul30,2024 ReportNo.EDG2406240009E00301RPage2of74Ver.1.0 TableofContents 1TESTRESULTCERTIFICATION..................................................................................................................................................3 2EUTTECHNICALDESCRIPTION.................................................................................................................................................5 3SUMMARYOFTESTRESULT.....................................................................................................................................................6 4TESTMETHODOLOGY.................................................................................................................................................................7 4.1GENERALDESCRIPTIONOFAPPLIEDSTANDARDS......................................................................................................7 4.2MEASUREMENTEQUIPMENTUSED..................................................................................................................................7 4.3DESCRIPTIONOFTESTMODES..........................................................................................................................................8 5FACILITIESANDACCREDITATIONS........................................................................................................................................9 5.1FACILITIES..............................................................................................................................................................................9 5.2EQUIPMENT............................................................................................................................................................................9 5.3LABORATORYACCREDITATIONSANDLISTINGS.........................................................................................................9 6TESTSYSTEMUNCERTAINTY.................................................................................................................................................10 7SETUPOFEQUIPMENTUNDERTEST.....................................................................................................................................11 7.1RADIOFREQUENCYTESTSETUP1.................................................................................................................................11 7.2RADIOFREQUENCYTESTSETUP2.................................................................................................................................11 7.3CONDUCTEDEMISSIONTESTSETUP.............................................................................................................................13 7.4BLOCKDIAGRAMCONFIGURATIONOFTESTSYSTEM.............................................................................................14 7.5SUPPORTEQUIPMENT........................................................................................................................................................14 8FREQUENCYHOPPINGSYSTEMREQUIREMENTS...............................................................................................................15 8.1StandardApplicable.................................................................................................................................................................15 8.2EUTPseudorandomFrequencyHoppingSequence................................................................................................................15 8.3EqualHoppingFrequencyUse................................................................................................................................................16 8.4FrequencyHoppingSystem.....................................................................................................................................................16 9TESTREQUIREMENTS...............................................................................................................................................................17 9.120DB&99%BANDWIDTH.....................................................................................................................................................17 9.2CARRIERFREQUENCYSEPARATION..............................................................................................................................28 9.3NUMBEROFHOPPINGFREQUENCIES............................................................................................................................31 9.4AVERAGETIMEOFOCCUPANCY(DWELLTIME)........................................................................................................34 9.5MAXIMUMPEAKCONDUCTEDOUTPUTPOWER.........................................................................................................44 9.6CONDUCTEDSUPRIOUSEMISSION.................................................................................................................................50 9.7RADIATEDSPURIOUSEMISSION.....................................................................................................................................60 9.8CONDUCTEDEMISSIONTEST...........................................................................................................................................69 9.9ANTENNAAPPLICATION..............................…

Text truncated - open the document above for the full version.

ReportNo.EDG2406240009E00301RPage40of74Ver.1.0 2DH5-Ant1-Hop-PASS ReportNo.EDG2406240009E00301RPage41of74Ver.1.0 3DH1-Ant1-Hop-PASS ReportNo.EDG2406240009E00301RPage42of74Ver.1.0 3DH3-Ant1-Hop-PASS ReportNo.EDG2406240009E00301RPage43of74Ver.1.0 3DH5-Ant1-Hop-PASS ReportNo.EDG2406240009E00301RPage44of74Ver.1.0 9.5MAXIMUMPEAKCONDUCTEDOUTPUTPOWER 9.5.1ApplicableStandard AccordingtoFCCPart15.247(b)(1)andKDB558074D0115.247MEASGUIDANCEv05r02 AccordingtoICRSS-247.5.4andRSS-Gen6.12 9.5.2ConformanceLimit ThemaxForfrequencyhoppingsystemsoperatinginthe2400-2483.5MHzbandemployingatleast75 non-overlappinghoppingchannels:1watt.Forallotherfrequencyhoppingsystemsinthe2400-2483.5MHzband: 0.125watts. 9.5.3TestConfiguration Testaccordingtoclause7.1radiofrequencytestsetup1 9.5.4TestProcedure Asanalternativetoapeakpowermeasurement,compliancewiththelimitcanbebasedonameasurementofthe maximumconductedoutputpower. Usethefollowingspectrumanalyzersettings: SetSpan=approximately5timesthe20dBbandwidth,centeredonahoppingchannel(about8MHz) SetRBW>the20dBbandwidthoftheemissionbeingmeasured(about3MHz) SetVBW  RBW SetSweep=auto SetDetectorfunction=peak SetTrace=maxhold Allowthetracetostabilize.Usethemarker-to-peakfunctiontosetthemarkertothepeakoftheemissionto determinethepeakamplitudelevel. TestResults Temperature: 25 ̊ C RelativeHumidity:45% ATMPressure:1011mbar Note:N/A Test Mode AntennaFrequency[MHz] ConductedPeak Powert[dBm] Conducted Limit[dBm] Verdict DH5Ant12402-3.09≤20.97PASS DH5Ant12441-3.48≤20.97PASS DH5Ant12480-3.57≤20.97PASS 2DH5Ant12402-1.08≤20.97PASS 2DH5Ant12441-1.30≤20.97PASS 2DH5Ant12480-1.58≤20.97PASS 3DH5Ant12402-0.41≤20.97PASS 3DH5Ant12441-0.83≤20.97PASS 3DH5Ant12480-1.09≤20.97PASS ReportNo.EDG2406240009E00301RPage45of74Ver.1.0 DH5-Ant1-2402-PASS DH5-Ant1-2441-PASS ReportNo.EDG2406240009E00301RPage46of74Ver.1.0 DH5-Ant1-2480-PASS 2DH5-Ant1-2402-PASS ReportNo.EDG2406240009E00301RPage47of74Ver.1.0 2DH5-Ant1-2441-PASS 2DH5-Ant1-2480-PASS ReportNo.EDG2406240009E00301RPage48of74Ver.1.0 3DH5-Ant1-2402-PASS 3DH5-Ant1-2441-PASS ReportNo.EDG2406240009E00301RPage49of74Ver.1.0 3DH5-Ant1-2480-PASS ReportNo.EDG2406240009E00301RPage50of74Ver.1.0 9.6CONDUCTEDSUPRIOUSEMISSION 9.6.1ApplicableStandard AccordingtoFCCPart15.247(d)andKDB558074D0115.247MEASGUIDANCEv05r02 AccordingtoICRSS-2475.5 9.6.2ConformanceLimit Inany100kHzbandwidthoutsidethefrequencybandinwhichthespreadspectrumintentionalradiatoris operating,theradiofrequencypowerthatisproducedbytheintentionalradiatorshallbeatleast20dBbelowthat inthe100kHzbandwidthwithinthebandthatcontainsthehighestlevelofthedesiredpower,basedoneitheran RFconducted,providedthetransmitterdemonstratescompliancewiththepeakconductedpowerlimits. 9.6.3TestConfiguration Testaccordingtoclause7.1radiofrequencytestsetup1 9.6.4TestProcedure Thetransmitteroutput(antennaport)wasconnectedtothespectrumanalyzer Referencelevelmeasurement Establishareferencelevelbyusingthefollowingprocedure: SetinstrumentcenterfrequencytoDSSchannelcenterfrequency. SetSpan=approximately5timesthe20dBbandwidth,centeredonahoppingchannel. SettheRBW=100kHz.SettheVBW≥3xRBW. SetDetector=peak.SetSweeptime=autocouple. SetTracemode=maxhold.Allowtracetofullystabilize. UsethepeakmarkerfunctiontodeterminethemaximumMaximumconducetedlevel. Notethatthechannelfoundtocontainthemaximumconducetedlevelcanbeusedtoestablishthereference level. Band-edgemeasurement Usethefollowingspectrumanalyzersettings: Span=wideenoughtocapturethepeakleveloftheemissionoperatingonthechannelclosesttotheband-edge, aswellasanymodulationproductswhichfalloutsideoftheauthorizedbandofoperation SetRBW  1%ofthespan=100kHzSetVBW  3xRBW SetSweep=autoSetDetectorfunction=peakSetTrace=maxhold Allowthetracetostabilize.Setthemarkerontheemissionatthebandedge,oronthehighestmodulation productoutsideoftheband,ifthislevelisgreaterthanthatatthebandedge.Enablethemarker-deltafunction, thenusethemarker-to-peakfunctiontomovethemarkertothepeakofthein-bandemission.Themarker-delta valuenowdisplayedmustcomplywiththelimitspecifiedinthisSection. Now,usingthesameinstrumentsettings,enablethehoppingfunctionoftheEUT.Allowthetracetostabilize. Followthesameprocedurelistedabovetodetermineifanyspuriousemissionscausedbythehoppingfunction alsocomplywiththespecifiedlimit. Emissionlevelmeasurement Usethefollowingspectrumanalyzersettings: Span=wideenoughtocapturethepeaklevelofthein-bandemissionandallspuriousemissions(e.g.,harmonics) fromthelowestfrequencygeneratedintheEUTupthroughthe10thharmonic.(30MHzto25GHz).SetRBW= 100kHzSetVBW  RBW SetSweep=autoSetDetectorfunction=peakSetTrace=maxhold Allowthetracetostabilize.Setthemarkeronthepeakofanyspuriousemissionrecorded.Theleveldisplayed mustcomplywiththelimitspecifiedinthisSection. ReportNo.EDG2406240009E00301RPage51of74Ver.1.0 9.6.5TestResults Temperature: 25 ̊ C RelativeHumidity:45% ATMPressure:1011mbar Note:N/A Alltheantennaandmodesmodehavebeentested,andtheworstresultrecordedwasreportasbelow: Bandedgemeasurements TestModeAntennaChNameFrequency[MHz] RefLevel [dBm] Result [dBm] Limit [dBm] Verdict DH5Ant1Low2402-4.34-48.7≤-24.34PASS DH5Ant1High2480-5.06-48.51≤-25.06PASS DH5Ant1LowHop_2402-4.65-47.92≤-24.65PASS DH5Ant1HighHop_2480-4.62-38.78≤-24.62PASS ReportNo.EDG2406240009E00301RPage52of74Ver.1.0 DH5-Ant1-2402-PASS DH5-Ant1-2480-PASS ReportNo.EDG2406240009E00301RPage53of74Ver.1.0 DH5-Ant1-Hop_2402-PASS DH5-Ant1-Hop_2480-PASS ReportNo.EDG2406240009E00301RPage54of74Ver.1.0 ConductedSpuriousEmission TestModeAntennaFrequency[MHz] FreqRange [MHz] RefLevel [dBm] Result [dBm] Limit [dBm] Verdict DH5Ant124020~Reference-4.58-4.58---PASS DH5Ant1240230~1000-4.58-54.46≤-24.58PASS DH5Ant124021000~26500-4.58-50.26≤-24.58PASS DH5Ant124410~Reference-4.49-4.49---PASS DH5Ant1244130~1000-4.49-53.79≤-24.49PASS DH5Ant124411000~26500-4.49-51.23≤-24.49PASS DH5Ant124800~Reference-4.95-4.95---PASS DH5Ant1248030~1000-4.95-53.48≤-24.95PASS DH5Ant124801000~26500-4.95-49.22≤-24.95PASS ReportNo.EDG2406240009E00301RPage55of74Ver.1.0 DH5-Ant1-2402-0~Reference-PASS DH5-Ant1-2402-30~1…

Text truncated - open the document above for the full version.

ReportNo.EDG2406240009E003Page1of2Ver.1.0 FCCID:2AL9B-AI9005 ReportNo.EDG2406240009E003Page2of2Ver.1.0
