2ALE7-MINIPROUSmart Body Fat Scale

Product Name: Smart Body Fat Scale Model No.：Mini Pro U, Mini Pro-2, Mini Pro V2.0, S1 Pro V2.0 FCC ID：2ALE7-MINIPROU All models are electrically identical ，only model no is different.

Model No.: Mini Pro U

FCC ID : 2ALE7-MINIPROU

Model No.: Mini Pro U

RF Exposure Evaluation Statement Product Name: Smart Body Fat Scale Model No.：Mini Pro U, Mini Pro-2, Mini Pro V2.0, S1 Pro V2.0 FCC ID：2ALE7-MINIPROU 1.1 RF Exposure Compliance Requirement 1.1.1 Standard Requirement According to KDB447498D01 General RF Exposure Guidance v06 Standalone SAR test exclusion considerations Unless specifically required by the published RF exposure KDB procedures, standalone 1-g head or body and 10-g extremity SAR evaluation for general population exposure conditions, by measurement or numerical simulation, is not required when the corresponding SAR Exclusion Threshold condition, listed below, is satisfied. 1.1.2 Limits The 1-g and 10-g SAR test exclusion thresholds for 100 MHz to 6 GHz at test separation distances ≤ 50 mm are determined by: [(max. power of channel, including tune-up tolerance, mW)/(min. test separation distance, mm)] · [√f(GHz)] ≤ 3.0 for 1-g SAR and ≤ 7.5 for 10-g extremity SAR, where f(GHz) is the RF channel transmit frequency in GHz Power and distance are rounded to the nearest mW and mm before calculation 17 The result is rounded to one decimal place for comparison The test exclusions are applicable only when the minimum test separation distance is ≤ 50 mm and for transmission frequencies between 100 MHz and 6 GHz. When the minimum test separation distance is < 5 mm, a distance of 5 mm is applied to determine SAR test exclusion 1.1.3 EUT RF Exposure Operational Mode: BLE Channel Maximum Peak Conducted Output Power (dBm) Tune up tolerance (dB) Maximum tune-up Power Calculated value Exclusion threshold (dBm) (mW) 2402 MHz -0.019 ±1 0.981 1.25 0.39 3 2442 MHz -0.274 ±1 0.726 1.18 0.37 2480 MHz -0.009 ±1 0.991 1.26 0.40 Conclusion: the calculated value ≤3.0, SAR is exempted.

Page 1 of 56 BlueAsiaofTechnicalServices(Shenzhen)Co.,Ltd. Add:BuildingC,No.107,ShihuanRoad,ShiyanSub-District,BaoanDistrict,Shenzhen,GuangdongProvince,China Tel:+86-755-23059481Email:[email protected] TESTREPORT ProductName: SmartBodyFatScale BrandMark: PICOOC ModelNo.: MiniProU,MiniPro-2,MiniProV2.0, S1ProV2.0 FCCID: 2ALE7-MINIPROU ReportNumber: BLA-EMC-202108-A2302 DateofSampleReceipt: 2021/8/5 DateofTest: 2021/8/5to2021/8/9 DateofIssue: 2021/8/9 TestStandard: 47CFRPart15,SubpartC15.247 TestResult:Pass Preparedfor: PICOOCTechnologyCo.,Ltd Room504,WanweiBuilding,No5,industrial5road,Nanshan District,Shenzhen Preparedby: BlueAsiaofTechnicalServices(Shenzhen)Co.,Ltd. BuildingC,No.107,ShihuanRoad,ShiyanSub-District,BaoanDistrict, Shenzhen,GuangdongProvince,China TEL:+86-755-23059481 Compiledby:Reviewby: Approvedby:Date:2021/8/9 ReportNo.:BLA-EMC-202108-A2302 Page 2 of 56 BlueAsiaofTechnicalServices(Shenzhen)Co.,Ltd.Tel:+86-755-23059481Email:[email protected] REPORTREVISERECORD VersionNo.DateDescription 002021/8/9Original ReportNo.:BLA-EMC-202108-A2302 Page 3 of 56 BlueAsiaofTechnicalServices(Shenzhen)Co.,Ltd.Tel:+86-755-23059481Email:[email protected] TABLEOFCONTENTS 1TESTSUMMARY ....................................................................................................................................................... 5 2GENERALINFORMATION ...................................................................................................................................... 6 3GENERALDESCRIPTIONOFE.U.T. .................................................................................................................... 6 4TESTENVIRONMENT .............................................................................................................................................. 7 5TESTMODE ............................................................................................................................................................... 7 6MEASUREMENTUNCERTAINTY .......................................................................................................................... 7 7DESCRIPTIONOFSUPPORTUNIT ...................................................................................................................... 8 8LABORATORYLOCATION ..................................................................................................................................... 8 9TESTINSTRUMENTSLIST ..................................................................................................................................... 9 10CONDUCTEDBANDEDGESMEASUREMENT ............................................................................................... 13 10.1LIMITS ................................................................................................................................................................ 13 10.2BLOCKDIAGRAMOFTESTSETUP ...................................................................................................................... 13 10.3TESTDATA ............................................................................................................................................................ 14 11CONDUCTEDSPURIOUSEMISSIONS ............................................................................................................. 15 11.1LIMITS ................................................................................................................................................................ 15 11.2BLOCKDIAGRAMOFTESTSETUP ...................................................................................................................... 15 11.3TESTDATA ............................................................................................................................................................ 16 12POWERSPECTRUMDENSITY ........................................................................................................................... 17 12.1LIMITS ................................................................................................................................................................ 17 12.2BLOCKDIAGRAMOFTESTSETUP ...................................................................................................................... 17 12.3TESTDATA ............................................................................................................................................................ 17 13CONDUCTEDPEAKOUTPUTPOWER ............................................................................................................. 18 13.1LIMITS ................................................................................................................................................................ 18 13.2BLOCKDIAGRAMOFTESTSETUP ...................................................................................................................... 18 13.3TESTDATA ............................................................................................................................................................ 19 14MINIMUM6DBBANDWIDTH ............................................................................................................................... 20 14.1LIMITS ................................................................................................................................................................ 20 14.2BLOCKDIAGRAMOFTESTSETUP ...................................................................................................................... 20 14.3TESTDATA ............................................................................................................................................................ 20 ReportNo.:BLA-EMC-202108-A2302 Page 4 of 56 BlueAsiaofTechnicalServices(Shenzhen)Co.,Ltd.Tel:+86-755-23059481Email:marketing@cb…

Text truncated - open the document above for the full version.

Model No.: Mini Pro U
