CELL CAMERA INSTRUCTION MANUAL Hunting Camera www.browningtrailcameras.com 23 BrowNiNG TrAil CAmerAS CAMERA DIAgRAM thank you for purchasing a browning trail camera. our trail cameras are constructed of the finest workmanship and materials available. as hunters ourselves, Hunting Camera we have designed our products to help you get the most of your time in the field. we hope you enjoy scouting game for years to come with your new browning trail camera. our customer ser- vice team is here to help you with any questions you may have operating or setting up your new trail camera. our representa- tives are available monday through Friday from 9am to 5pm cst. Toll Free Customer Service: 1.888.618.4496 Customer Service: [email protected] CAMERA CONTENTS Your 4g browning ridgeline Pro camera includes pre installed sim cards for att or V erizon activation, 6 ft. tree strap and an instruction manual . Light Sensor PIR Sensor LCD Screen Battery Eject Button Power Switch Camera Sensor Programming Buttons 12 Volt External Power Microphone Night Vision IR LEDs SD Card Slot Mode Button Motion Test LED www.browningtrailcameras.com 45 BrowNiNG TrAil CAmerAS BATTERy & SD CARD INSTALLATION You will need to provide and install a good quality card. the best brands of sD cards are browning branded cards, sandisk or Kingston branded cards. Your new camera will accept sD cards from 8gb-512gb. i nsert your sD card into the sD card slot in the camera. r elease the battery tray by pressing the b attery e ject button. t he tray will eject about 1/2”. w ith a slight pull, the battery tray will completely eject. i nstall 8 aa a lkaline or lithium batteries in the battery tray. make sure you install the batteries with the correct polarity, following the markings on the battery tray. For optimal performance we recommend using browning branded batteries, energizer or Du- racell. slide the battery tray into the closed position. MOBILE APPS Your browning Defender wireless camera will also work with a robust mobile app that is compatible with ios and android devic- es. simply download the free strike Force wireless app from the app store or google Play. Your strike Force wireless app allows you full control of all camera settings as well as the ability to view pictures and video clips* uploaded by your cameras. *if applicable STRIkE FORCE WIRELESS ACCOUNT SET UP in order to start transmitting pictures from your browning De- fender wireless camera, you will need to do a quick account set up. t his can be done by installing the strike Force w ireless app on your mobile device from either the apple app store, or google Play. You can also set up an account on your laptop computer at www.STrikeForCewireleSS.Com simply follow the on screen menu to create a user account. CAMERA SETUP Power on your ridgeline Pro camera. Press the moDe button. the camera setup menu will appear. Press the UP arrow key until the menu option “lte carrier” appears. Press the enter button. Use the UP or Down buttons to highlight either att or Verizon as your preferred cellular network. Press the enter button to con- firm your selection. a Qr code will appear on the camera display screen. o pen your strike Force w ireless app on your mobile device. s imply choose the “aDD camera ” option in the app loca ted as a ‘+’ symbol in the upper right corner of the ‘cameras’ screen. a Qr code scanner will appear on your screen. scan the Qr code displayed on the camera screen with your mobile device. Follow the on screen options for setting the data plan for your new camera. www.browningtrailcameras.com 67 BrowNiNG TrAil CAmerAS QUICk CELLULAR TEST after you have installed batteries and an empty sD card in your camera, set up an account at strike Force wireless, and finishs your subscription plan details, its time to do a test transmission. STEP 1 - Power on your camera, and take a test picture by press- ing the enter button. the sD card meter on your camera will display the number of pictures taken. STEP 2 - on your camera navigate to the “lte test” option in the settings menu, and click on enter button to start the test. Your camera will make connection with a cell tower and transmit the images to your strike Force wireless account. You can view the pictures on your laptop or mobile app. Your camera screen will display the cellular signal strength. if your camera registers the cell tower strength low, you may need to relocate the camera to an area with a stronger signal. Upon a successful image transmission your images will appear in your image inbox within a couple of minutes. remember to refresh your app (by swiping down on the screen) or refresh your computer screen to see the images. when you set up your camera in the field, the camera will auto- matically connect to the strike Force wireless servers and con- nect to your account. the camera will update its settings and communication times with the ones set in the camera settings menu of your online account or mobile app. www.browningtrailcameras.com 89 BrowNiNG TrAil CAmerAS CAMERA SETTINgS INFORMATION Date/Time: the day, month, year and time can be set here. OPERATION MODE Trail Cam: this setting will take still pictures of game in daylight and nighttime. this is the most widely used setting and works well for trails and feeding areas. Video: this setting will take video clips of game in daytime and nighttime. Full HD video clips will be stored on the sD card for re- view. the camera will upload a picture from the video clip to your account. the entire video clip will not upload to your account. PhOTO QUALITy Options: low (2mP), medium (4mP), High (8mP), Ultra (22mP) VIDEO QUALITy High and Ultra are the options here, both video settings capture in 1920x1080 resolution @ 30 fps. the Ultra setting has a lower compression rate than the HigH setting. VIDEO LENgTh Options: 5, 10, 20, 30 seconds, 1 and 2 minutes. notes: to conserve battery power, your night videos are limited to a maximum time of 20 sec…
Text truncated - open the document above for the full version.
PROMETHEUS GROUP LLC Address: PO BOX 130100 BIRMINGHAM, ALABAMA 35213-0100 USA Tel.: 18886184496 Fax: 18886289877 E-mail: [email protected] FCC Authorization Date: 2021-10-22 FEDERAL COMMUNICATIONS COMMISSIONS Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 Subject: Agent Authorization To whom it may concern: We, PROMETHEUS GROUP LLC hereby authorizes Shenzhen Accurate Technology Co., Ltd. to act on its behalf in all matters relating to application for Equipment authorization, including the signing of all documents relating to these matters. All acts carried out by Shenzhen Accurate Technology Co., Ltd. on our behalf shall have the same effect as our own action. We, the undersigned, hereby certify that we are not subject to a denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 862. This authorization is valid until further written notice from the applicant. Sincerely Yours, Signature Name:John Traywick Title:Chief Development Officer
PROMETHEUS GROUP LLC Address: PO BOX 130100 BIRMINGHAM, ALABAMA 35213-0100 USA Tel.: 18886184496 Fax: 18886289877 E-mail: [email protected] FCC Confidential Authorization Date: 2021-11-08 FEDERAL COMMUNICATIONS COMMISSIONS Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 Subject: Confidentiality Request regarding application for certification of FCC ID: 2ALGTBTC-4G-RLDCP In accordance with Sections 0.457 and 0.459 of the Commission’s Rules, PROMETHEUS GROUP LLC hereby requests long-term confidential treatment of information accompanying this application as outlined below: •Block Diagram •Schematics •Operation Description The above materials contain proprietary and confidential information not customarily released to the public. The public disclosure of these materials provides unjustified benefits to its competitors in the market. Sincerely Yours, Signature Name: John Traywick Title: Chief Development Officer · Part list/Tune-up procedure
PROMETHEUS GROUP LLC Address: PO BOX 130100 BIRMINGHAM, ALABAMA 35213-0100 USA Tel.: 18886184496 Fax: 18886289877 E-mail: [email protected] FEDERAL COMMUNICATIONS COMMISSIONS Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 Date: 2021-10-22 To whom it may concern, Reference: Original module’s FCC ID: 2ALGTEG91NAXD, Model Name: EG91-NAXD New FCC ID: 2ALGTBTC-4G-RLDCP, Model Name: BTC-4G-RLDCP We, PROMETHEUS GROUP LLC, our product Hunting Camera (Model Name: BTC-4G- RLDCP, FCC ID: 2ALGTBTC-4G-RLDCP) supports LTE and WCDMA. EUT contains one certified module ( model name: EG91-NAXD) with the FCC ID: 2ALGTEG91NAXD, we haven't made any changes to this chip. So test results for RF parameters will be referred to the certified module (Model: EG91-NAXD, FCC ID: 2ALGTEG91NAXD) with reports: R2006A0379-R1, R2006A0379-R2, R2006A0379-R4, R2006A0379-R5, R2006A0379-R3 and R2006A0379-R6, which issued by TA Technology (Shanghai) Co., Ltd. We confirm that all information above is true, and we will be responsible for all consequences. Please contact me if you have any questions. Sincerely, Signature: Name:John Traywick Title:Chief Development Officer
Shenzhen Accurate Technology Co., Ltd. Project No.: SZNS210903-45923E-RF External Photos Page 1 of 5 External Photos Shenzhen Accurate Technology Co., Ltd. Project No.: SZNS210903-45923E-RF External Photos Page 2 of 5 Shenzhen Accurate Technology Co., Ltd. Project No.: SZNS210903-45923E-RF External Photos Page 3 of 5 Shenzhen Accurate Technology Co., Ltd. Project No.: SZNS210903-45923E-RF External Photos Page 4 of 5 Shenzhen Accurate Technology Co., Ltd. Project No.: SZNS210903-45923E-RF External Photos Page 5 of 5
Serial # Font style: Arial Bold 8pt Model BTC-4G-RLDCP FCC ID: 2ALGTBTC-4G-RLDCP Hunting Camera
Shenzhen Accurate Technology Co., Ltd. Project No.: SZNS210903-45923E-RF Internal Photos Page 1 of 9 Internal Photos Shenzhen Accurate Technology Co., Ltd. Project No.: SZNS210903-45923E-RF Internal Photos Page 2 of 9 Shenzhen Accurate Technology Co., Ltd. Project No.: SZNS210903-45923E-RF Internal Photos Page 3 of 9 Shenzhen Accurate Technology Co., Ltd. Project No.: SZNS210903-45923E-RF Internal Photos Page 4 of 9 Shenzhen Accurate Technology Co., Ltd. Project No.: SZNS210903-45923E-RF Internal Photos Page 5 of 9 Shenzhen Accurate Technology Co., Ltd. Project No.: SZNS210903-45923E-RF Internal Photos Page 6 of 9 Shenzhen Accurate Technology Co., Ltd. Project No.: SZNS210903-45923E-RF Internal Photos Page 7 of 9 Shenzhen Accurate Technology Co., Ltd. Project No.: SZNS210903-45923E-RF Internal Photos Page 8 of 9 3G/4G main antenna 4G auxiliary antenna GPS antenna Shenzhen Accurate Technology Co., Ltd. Project No.: SZNS210903-45923E-RF Internal Photos Page 9 of 9
Shenzhen Accurate Technology Co., Ltd. Report No.: SZNS210903-45923E-00B Version 37: 2021-11-09 Page 8 of 12 FCC –Part 90 LTE FCC §1.1307 (b) (1) & §2.1091- Maximum Permissible exposure (MPE) Applicable Standard According to subpart 1.1307 (b)(1), 2.1091 systems operating under the provisions of this section shall be operated in a manner that ensures the public is not exposed to RF energy level in excess of the communication guidelines. Limits for General Population/Uncontrolled Exposure Limits for General Population/Uncontrolled Exposure Frequency Range (MHz) Electric Field Strength (V/m) Magnetic Field Strength (A/m) Power Density (mW/cm 2 ) Averaging Time (Minutes) 0.3-1.34 614 1.63 *(100) 30 1.34-30 824/f 2.19/f *(180/f 2 ) 30 30-300 27.5 0.073 0.2 30 300-1500 / / f/1500 30 1500-100,000 / / 1.0 30 f = frequency in MHz * = Plane-wave equivalent power density Result Calculated Formulary: Predication of MPE limit at a given distance S = 2 4R PG π S = power density (in appropriate units, e.g. mW/cm 2 ) P = power input to the antenna (in appropriate units, e.g., mW). G = power gain of the antenna in the direction of interest relative to an isotropic radiator, the power gain factor, is normally numeric gain. R = distance to the center of radiation of the antenna (appropriate units, e.g., cm) Shenzhen Accurate Technology Co., Ltd. Report No.: SZNS210903-45923E-00B Version 37: 2021-11-09 Page 9 of 12 FCC –Part 90 LTE For worst case: Mode Frequency (MHz) Antenna Gain Tune up conducted power Evaluation Distance (cm) Power Density (mW/cm 2 ) MPE Limit (mW/cm 2 ) (dBi) (numeric)(dBm)(mW) WCDMA B2 1850-1910 2.8 1.91 24 251.19 20 0.095 1 WCDMA B4 1710-1755 2.7 1.86 24 251.19 20 0.093 1 WCDMA B5 824-849 0.8 1.20 24 251.19 20 0.060 0.549 LTE B2 1850-1910 2.8 1.91 24.5 281.84 20 0.107 1 LTE B4 1710-1755 2.7 1.86 24.5 281.84 20 0.104 1 LTE B5 824-849 0.8 1.20 24.5 281.84 20 0.067 0.549 LTE B12 699-716 0.33 1.08 24.5 281.84 20 0.060 0.466 LTE B13 777-787 0.33 1.08 24.5 281.84 20 0.060 0.518 LTE B25 1850-1915 2.8 1.91 25 316.23 20 0.120 1 LTE B26 (Part 90) 814-824 0.8 1.20 25 316.23 20 0.076 0.543 LTE B26 (Part 22) 824-849 0.8 1.20 25 316.23 20 0.076 0.549 Note 1: The tune up conducted power was declared by the applicant. To maintain compliance with the FCC’s RF exposure guidelines, place the equipment at least 20cm from nearby persons. Result: Compliant.
