CELLULAR SETUP Download the Strike Force Wireless app from the App Store or Google Play on your mobile device. Set up an account on the new App. From the App, select “Setup New Camera”. This will bring up a QR code reader. Power on the trail camera and press the Mode button. Highlight either ATT or Verizon as your preferred carrier. Confirm your selection. Scan the QR Code that appears on the camera’s screen with the QR code reader on your mobile app. This will register the camera information on your Strike Force Wireless account. Follow the App instructions for picking your camera’s data. After 5 minutes, your camera will be set up on the cellular network. You can do a manual test by navigating to the LTE TEST camera menu. This will make test communication to your account at Strike Force Wireless. CAMERA SETTINGS After powering on the trail camera, press the mode button to access the avaliable setting options. The setting options are as follows: Set Date Set Time Camera Mode: Trail / Video Capture Delay:1, 5, 10, 30 seconds, 1, 2, 5, 10, 30, 60 minutes Picture Size: 2, 4, 8 or 20MP MultiShot: 1-8 shots per trigger Temperature Units: Fahrenheit or Celcius Picture Info Strop: on / off SD Card Management: on / off Motion Test: Activate to test the PIR range and check setup in the field. Camera Name: Add a custom name for your camera in tis field. Set Default: Resets your camera to factory defaults. Delete All: This erases and reformats your SD card. Software Update: You can update your camera software here. LTE Test: You can run a manual cellular test here by pressing the OK button. FCC STATEMENT This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: • Reorient or relocate the receiving antenna. • Increase the separation between the equipment and receiver. • Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. • Consult the dealer or an experienced radio/TV technician for help. FCC Radiation Exposure Statement: This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. In order to avoid the possibility of exceeding the FCC radio frequency exposure limits, Human proximity to the antenna shall not be less than 20cm (8 inches) during normal operation. Shielded cables with ferrite must be used with this unit to ensure compliance with the Class B FCC limits. Warning: Changes or modifications to this unit not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. This user manual covers both versions of the Defender Pro Scout Max Cameras Model Number: BTC-PSM, BTC-PSM-IF. FCC ID: 2ALGTBTC-PSM

Rev 11/20/07 PROMETHEUS GROUP LLC Federal Communications Commission Authorization and Evaluation Division Confidentiality Request regarding application for certification of FCC ID: 2ALGTBTC-PSM Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, we hereby request confidential treatment of information accompanying this application as outlined below: Exhibit Type File Name • (Block Diagram, Schematics, Operational Description,Partlist, PCB layout, Tune-Up Procedure) (Block Diagram.pdf, Schematics.pdf, Operational Description.pdf, Partlist.pdf, PCB layout.pdf, Tune-Up Procedure.pdf) The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Pursuant to DA04-1705 June 15, 2004 of the Commission’s public notice, we also request temporary confidential treatment of information accompanying this application as outlined below: Exhibit Type File Name Sincerely, Signature: printed name: JOHN TRAYWICK

PROMETHEUS GROUP LLC To:
Federal Communications Commission



Authorization and Evaluation Division



1435 Oakland Mills Road



Columbia, MD 21046 Regarding: File for a new FCC ID for the entire host including the certified module. To Whom It May Concern, We, PROMETHEUS GROUP LLC, declare on our role responsibility for the product of model BTC-PSM, BTC-PSM-IF, FCC ID: 2ALGTBTC-PSM According to KDB 996369 D02 A1, “it is permissible to upload relevant test reports from an original module filing, if they accurately represent test results under the new conditions described in the new application(s). When original results are used, the new applicant must provide a statement and explanations that the original test reports accurately represent test results under the new conditions.” The certified module ID is FCC ID: QIPEXS62-W, granted on: 12/30/2019 and the test report numbers are 191019009EMC-1, 191019009RFM-2, 191019009RFC-1. This certified module will be integrated into a host that is a Trail camera. Therefore, it is the same mobile condition as the original filling. In this case, this certified module is same as the original filling. Additional test reports will be provided to demonstrate full compliance, we will verified the power first and test for new radiated emission/exposure evaluation. Sincerely, Printed Name: JOHN TRAYWICK Title: Technical Chief Development Officer Company Name: PROMETHEUS GROUP LLC Signature:

PROMETHEUS GROUP LLC Model Confirmation Letter We, Prometheus Group LLC declared that our product Trail Camera, item No.: BTC-PSM, BTC-PSM-IF, except the IR LED illumination board, IR LED component and the plastic lens at the IR illumination area, others were identical including the electrical circuit design, camera controller PCB layout, components and internal wiring, The marketing requirement is as below, BTC-PSM is equipped with 850nm IR LEDs for illumination BTC-PSM-IF is equipped with 940nm IR LEDs for illumination Signature: Name: JOHN TRAYWICK Title: Chief Development Officer Company: PROMETHEUS GROUP LLC Date: June 17, 2021

Macintosh HD:Users:traywick:Desktop:TIM FCC letters:POA Letter.docx PROMETHEUS GROUP LLC Federal Communications Commission Authorization and Evaluation Division 1435 Oakland Mills Road Columbia, MD 21046 Date: July 13, 2021 SUBJECT: FCC Application for (FCC ID: 2ALGTBTC-PSM) To Whom It May Concern: We, the undersigned, hereby authorize Mina Xu at Centre Testing International Group Co., Ltd / Building C, Hongwei Industrial Park Block 70, Bao'an District, Shenzhen, China on our behalf, to apply to the Federal Communications Commission on our equipment. Any and all acts carried out by Mina Xu at Centre Testing International Group Co., Ltd / Building C, Hongwei Industrial Park Block 70, Bao'an District, Shenzhen, China on our behalf shall have the same effect as acts of our own. This is to advise that we are in full compliance with the Anti- Drug Abuse Act. We, the applicant, are not subject to a denial of federal benefits pursuant to Section 5301 of the Anti-Drug Act of 1988, 21 USC853a, and no party to the application is subject to a denial of federal benefits pursuant to that section. Regards, Signature: printed name: JOHN TRAYWICK

Report No. EED32N80406801Page 16 of 26 PHOTOGRAPHS OF EUT Constructional Details Test model No.: BTC-PSM View of Product-1 View of Product-2 Report No. EED32N80406801Page 17 of 26 View of Product-3 View of Product-4 Report No. EED32N80406801Page 18 of 26 View of Product-5 View of Product-6

Report No. EED32N80406801Page 19 of 26 View of Product-7 View of Product-8 Report No. EED32N80406801Page 20 of 26 View of Product-9 View of Product-10 Report No. EED32N80406801Page 21 of 26 View of Product-11 View of Product-12 Report No. EED32N80406801Page 22 of 26 View of Product-13 View of Product-14 Report No. EED32N80406801Page 23 of 26 View of Product-15 View of Product-16 Report No. EED32N80406801Page 24 of 26 View of Product-17 View of Product-18 Report No. EED32N80406801Page 25 of 26 View of Product-19 View of Product-20 Report No. EED32N80406801Page 26 of 26 View of Product-21 View of Product-22 The test report is effective only with both signature and specialized stamp, The result(s) shown in this report refer only to the sample(s) tested. Without written approval of CTI, this report can’t be reproduced except in full. *** End of Report ***

Report No. : EED32N80406802Page 1 of 9 1 COVER PAGE RF Exposure Evaluation Report Product: Trail Camera Trade mark: BROWNING Model/Type reference : BTC-PSM, BTC-PSM-IF Serial Number: N/A Report Number: EED32N80406802 FCC ID: 2ALGTBTC-PSM Date of Issue: Jul. 15, 2021 Test Standards: 47 CFR Part 1.1307 47 CFR Part 2.1091 KDB447498D01v06 Test result:PASS Prepared for: Prometheus Group LLC P.O. Box 130100 Birmingham, Alabama 35213-0100 USA Prepared by: Centre Testing International Group Co., Ltd. Hongwei Industrial Zone, Bao’an 70 District, Shenzhen, Guangdong, China TEL: +86-755-3368 3668 FAX: +86-755-3368 3385 Compiled by:Reviewed by: Tom ChenAaron Ma Approved by:Date:Jul. 15, 2021 David Wang Check No.:2433270521 Report No. : EED32N80406802Page 2 of 9 2Version Version No.DateDescription 00 Jul. 15, 2021 Original Report No. : EED32N80406802Page 3 of 9 3 Contents Page 1 COVER PAGE .................................................................................................................................................................... 1 2 VERSION ............................................................................................................................................................................. 2 3CONTENTS ......................................................................................................................................................................... 3 4 GENERAL INFORMATION .............................................................................................................................................. 4 4.1 C LIENTINFORMATION ................................................................................................................................................... 4 4.2 G ENERALDESCRIPTION OFEUT ................................................................................................................................ 4 4.3 P RODUCTSPECIFICATION SUBJECTIVE TO THIS STANDARD ....................................................................................... 4 4.4 T ESTLOCATION ............................................................................................................................................................ 6 4.5 D EVIATION FROMSTANDARDS ..................................................................................................................................... 6 4.6 A BNORMALITIES FROMSTANDARDCONDITIONS ......................................................................................................... 6 4.7 O THERINFORMATIONREQUESTED BY THECUSTOMER ............................................................................................. 6 5 RF EXPOSURE EVALUATION ....................................................................................................................................... 7 5.1 RF E XPOSURECOMPLIANCEREQUIREMENT .............................................................................................................. 7 5.2 M AXIMUMPERMISSIBLEEXPOSURE ............................................................................................................................ 8 PHOTOGRAPHS OF EUT CONSTRUCTIONAL DETAILS .......................................................................................... 9 Report No. : EED32N80406802Page 4 of 9 4 General Information 4.1 Client Information Applicant: Prometheus Group LLC Address of Applicant: P.O. Box 130100 Birmingham, Alabama 35213-0100 USA Manufacturer: Hooray Innovation Limited Address of Manufacturer: Flat 3, 15/F, Wah Yiu Industrial Building, 30-32 Au Pui Wan Street, Shatin, HK. Factory: Hooray Innovation Limited Address of Factory: Flat 3, 15/F, Wah Yiu Industrial Building, 30-32 Au Pui Wan Street, Shatin, HK. 4.2 General Description of EUT Product Name: Trail Camera Model No. (EUT): BTC-PSM Add Model No.: BTC-PSM-IF Trade Mark: BROWNING EUT Supports Radios application LTE Band 2: Tx: 1850-1910MHz, Rx: 1930-1990MHz LTE Band 4: Tx: 1710-1755 MHz, Rx: 2110-2155 MHz LTE Band 12: Tx: 699-716 MHz, Rx: 729-746 MHz LTE Band 13: Tx: 777-787 MHz, Rx: 746-756 MHz 4.3 Product Specification subjective to this standard Frequency Range: LTE Band 2: Tx: 1850 MHz – 1910MHz, Rx: 1930 MHz – 1990MHz LTE Band 4: Tx: 1710 MHz – 1755 MHz, Rx: 2110 MHz – 2155 MHz LTE Band 12: TX: 699 MHz to 716 MHz RX: 729 MHz to746 MHz LTE Band 13: Tx: 777 MHz – 787 MHz, Rx: 746 MHz – 756 MHz Modulation Type: QPSK, 16QAM Test Power Grade: Default Test Software of EUT: Default Antenna Type: Dipole Antenna Antenna Gain: 4..2dBi Maximum tune up power LTE Band 222.00 dBm(158.489 mW) LTE Band 422.00 dBm(158.489 mW) LTE Band 1222.00 dBm(158.489 mW) LTE Band 1322.00 dBm(158.489 mW) ： ： ： ： Power Supply: BatteryAA 1.5V*8 Sample Received Date: Jun. 15, 2021 Sample tested Date: Jun. 15, 2021 to Jul. 07, 2021 Company Name and Address shown on Report, the sample(s) and sample Information was/ were pro vided by the applicant who should be responsible for the authenticity which CTI hasn’t verified. Model No.: BTC-PSM, BTC-PSM-IF Report No. : EED32N80406802Page 5 of 9 Only the model BTC-PSM was tested, BTC-PSM compared with BTC-PSM-IF, all RF parts of the product, Their electrical circuit design, layout, components used and internal wiring are identical, except only the model name, IR LED illumination board, IR LED component and the plastic lens at the IR illumination area are different, specific use models see the table below: BTC-PSM is equipped with 850nm IR LEDs for illumination BTC-PSM-IF is equipped with 940nm IR LEDs for illumination The certified module ID is FCC ID: QIPEXS62-W, and report numbers of this certified module are 191019009RFC-1 and RF exposure analysis dated on Dec/21/2019. This certified module will be integrated into a host that is a hunting camera. Therefore, it is the same mobile condition as the original filling. In this report, this certified module is same as the original filling. We have verified the power and …
