version01 NLU Products, LLC dba BGZ brands Declaration concerning Antenna Specification It i s hereby declared that the product Model No.: 5801-00T, 5801-001, 5801-002, 5801-003, 5801-004, 5801-005, 5801-006, 5801-007, 5801-008, 5801- 009, 5801- 00P, 5801-00A, 5801-00V FCC ID: 2ALQR-CTT5801 fulfills the requirement in FCC test relating to the antenna type. The device specified above confirms to the FCC recommendations for FPC Antenna antenna type(s) described below: Model No. of antenna: N/A Type of antenna: FPC Antenna Gain of the antenna: 1.7 dBi Frequency range in MHz Rated RF power output (Watts) FCC Equipment Code (ex:: DTS, DSS, PCE) 2412 2462 0.0214 15.247 DTS The mounting of the antenna is fixed to the radio module and no other antenna should be used. Company name: NLU Products, LLC dba BGZ brands Address: 2801 N Thanksgiving Way #300, Lehi, UT 84043, U.S.A. City: Lehi ZIP / Postal code: 84043 Country: United States Contact: Ryan Clark Date: 13/05/2021 Signature:

Address: 101, No. 7, Zone 2, Xinxing Industrial Park, Fuhai Avenue, Xinhe Community, Fuhai Street, Bao’ an District, Shenzhen, Guangdong, China. Tel: (86-755)88850135 Fax: (86-755) 88850136 Web:www.mtitest.com E-mail: [email protected] MPE Test Report Report No.: MTi20031913-5E2 Date of issue: May 11, 2021 Applicant: NLU Products, LLC dba BGZ brands Product name: Portable Over-Door Camera Model(s): 5801-00T, 5801-001, 5801-002, 5801-003, 5801-004, 5801-005, 5801-006, 5801-007, 5801-008, 5801- 009, 5801- 00P, 5801-00A, 5801-00V FCC ID: 2ALQR-CTT5801 Shenzhen Microtest Co., Ltd. http://www.mtitest.com - Page 2 of 6 - Report No.: MTi20031913-5E2 Address: 101, No. 7, Zone 2, Xinxing Industrial Park, Fuhai Avenue, Xinhe Community, Fuhai Street, Bao’ an District, Shenzhen, Guangdong, China. Tel: (86-755)88850135 Fax: (86-755) 88850136 Web:www.mtitest.com E-mail: [email protected] Instructions 1. The report shall not be partially reproduced without the written consent of the laboratory; 2. The test results of this report are only responsible for the samples submitted; 3. This report is invalid without the seal and signature of the laboratory; 4. This report is invalid if transferred, altered or tampered with in any form without authorization; 5. Any objection to this report shall be submitted to the laboratory within 15 days from the date of receipt of the report. - Page 3 of 6 - Report No.: MTi20031913-5E2 Address: 101, No. 7, Zone 2, Xinxing Industrial Park, Fuhai Avenue, Xinhe Community, Fuhai Street, Bao’ an District, Shenzhen, Guangdong, China. Tel: (86-755)88850135 Fax: (86-755) 88850136 Web:www.mtitest.com E-mail: [email protected] Table of Contents 1 RF EXPOSURE EVALUATION ............................................................................................................................ 5 1.1 LIMITS FOR MAXIMUM PERMISSIBLE EXPOSURE (MPE) ........................................................................................ 5 1.2 MEASUREMENT RESULT ......................................................................................................................................... 6 - Page 4 of 6 - Report No.: MTi20031913-5E2 Address: 101, No. 7, Zone 2, Xinxing Industrial Park, Fuhai Avenue, Xinhe Community, Fuhai Street, Bao’ an District, Shenzhen, Guangdong, China. Tel: (86-755)88850135 Fax: (86-755) 88850136 Web:www.mtitest.com E-mail: [email protected] Testing Engineer : (Danny Xu) Technical Manager : (Leo Su) Authorized Signatory : (Tom Xue) TEST RESULT CERTIFICATION Applicant’s name ................... : NLU Products, LLC dba BGZ brands Address ................................. : 2801 N Thanksgiving Way #300, Lehi, UT 84043, U.S.A. Manufacturer's Name ............ : CTT Co., Ltd Address ................................. : Building 2 of Industril park No 197 Xinhua Blvd Tongqiao town Zhongkai High-teck zone Huizhou, Guangdong, China Product description Product name............................ : Portable Over-Door Camera Trademark ............................ : BodyGuardz Model Name ......................... : 5801-00T Serial Model ........................... 5801-001, 5801-002, 5801-003, 5801-004, 5801-005, 5801-006, 5801-007, 5801-008, 5801- 009, 5801- 00P, 5801-00A, 5801-00V Standards .............................. : N/A Test procedure ...................... : KDB 447498 D01 v06 Date of Test Date (s) of performance of tests ............. : Jan. 05, 2021 ~ Jan. 22, 2021 Test Result ............................................. : Pass This device described above has been tested by Shenzhen Microtest Co., Ltd. and the test results show that the equipment under test (EUT) is in compliance with the FCC requirements. And it is applicable only to the tested sample identified in the report. - Page 5 of 6 - Report No.: MTi20031913-5E2 Address: 101, No. 7, Zone 2, Xinxing Industrial Park, Fuhai Avenue, Xinhe Community, Fuhai Street, Bao’ an District, Shenzhen, Guangdong, China. Tel: (86-755)88850135 Fax: (86-755) 88850136 Web:www.mtitest.com E-mail: [email protected] 1 RF EXPOSURE EVALUATION According to FCC 1.1310: The criteria listed in the following table shall be used to evaluate the environment impact of human exposure to radio frequency (RF) Radiation as specified in §1.1307(b) 1.1 Limits for Maximum Permissible Exposure (MPE) MPE Calculation Method Friis transmission formula: Pd= (Pout*G)\ (4*pi*R 2 ) Where Pd= Power density in mW/cm2 Pout=output power to antenna in mW G= Numeric gain of the antenna relative to isotropic antenna Pi=3.1415926 R= distance between observation point and center of the radiator in cm(20cm) Pd the limit of MPE, 1mW/cm2. If we know the maximum gain of the antenna and total power input to the antenna, through the calculation, we will know the distance where the MPE limit is reached. - Page 6 of 6 - Report No.: MTi20031913-5E2 Address: 101, No. 7, Zone 2, Xinxing Industrial Park, Fuhai Avenue, Xinhe Community, Fuhai Street, Bao’ an District, Shenzhen, Guangdong, China. Tel: (86-755)88850135 Fax: (86-755) 88850136 Web:www.mtitest.com E-mail: [email protected] 1.2 Measurement Result WIFI: Operation Frequency: WIFI 802.11b/g/n HT20: 2412-2462MHz, 802.11n HT40: 2422-2452MHz, Power density limited: 1mW/ cm 2 Antenna Type: Wifi Antenna: FPC Antenna; WIFI antenna gain: 1.7dBi R=20cm mW=10^(dBm/10) antenna gain Numeric=10^(dBi/10)= 10^(1.7/10)=1.48 Channel Freq. (MHz) modulation conducted power Tune- up power Max Antenna Evaluation result at 20cm Power density Limits (dBm) (dBm) tune-up power Gain Power density(mW/cm2 ) (mW/cm2) (dBm) (mW) Numeric Ant A Ant A Ant A Ant A Ant A Ant A 2412 802.11b 12.63 13±1 14 25.118864 1.48 0.00740 1 2437 13.30 13±1 14 25.118864 1.48 0.00740 1 2462 12.79 13±1 14 25.118864 1.48 0.00740 1 2412 802.11g 10.61 11±1 12 15.848932 1.48 0.00467 1 2437 11.35 11±1 12 15.848932 1.48 0.00467 1 2462 10.86 11±1 12 15.848932 1.48 0.00467 1 2412 802.11n H20 10.49 11±1 12 15.848932 1.48 0.00467 1 2437 11.42 11±1 12 15.848932 1.48 0.00467 1 2462 10.80 11±1 12 15…
