2ALSZ-CL3100NPhotocontroller

Page 1 Installation and Commissioning Procedure For iSLC3100-7P-N CIMCON Lighting, Inc. ISLC3100-7P-N Place the Photocontroller into the 7-pin NEMA receptacle and rotate it clockwise to lock. Fig. 1 Installation of ISLC3100-7P-N on the luminaire Installation Procedure ISLC3100-7P Page 2 Fig. 2: Installation wiring diagram Installation Procedure ISLC3100-7P Page 3 The cables protruding from the receptacle have following function as mentioned into table. Once the Photo-controller is installed and luminaire is powered ON then depending on the daylight condition Lamp will operate. In the Lab environment, you can just cover the cap with cloth or by hand and see the Lamp turning ON if wired correctly and if you remove the cloth, it will turn OFF. Installation Procedure ISLC3100-7P Page 4 iSLC SIM CARD NBIOT node comes with either ESIM configuration or Normal SIM configuration ESIM configuration: - ESIM will be solder on bottom of RF board with this configuration Normal SIM configuration: - For Normal SIM user need to arrange Micro SIM card and need to insert into module as per below. ESIM Configuration Installation Procedure ISLC3100-7P Page 5 Normal SIM Configuration Micro Size Sim Card Installation Procedure ISLC3100-7P Page 6 LED indication on RF board LED Indication chart Flicker slowly (200 ms High/1800ms Low) Network searching Flicker slowly (1800 ms High/200ms Low) Idle Flicker quickly (125ms High/125ms Low) Data transfer is ongoing Always high Voice calling Installation Procedure ISLC3100-7P Page 7 Safety Consideration for the Installation crew:  Ensure that the supply voltage matches the SLC’s voltage rating.  Firmly place the SLC into the NEMA twist lock receptacle/socket on top of the fixture by aligning the large prong on the SLC with the large opening in the receptacle/socket. Push down on SLC and twist clockwise until it locks into place.  PHOTOCONTROL MUST BE LOCKED IN! Note: window or arrow on top of SLC should be pointed away from the mounting surface. The receptacle/socket may be repositioned by loosening the screw in the center of the receptacle/socket. Rotate to the new position and retighten screw. Do not rotate receptacle/socket over 360 degrees because you can twist receptacle/socket wires. Eventually stripping the insulation and cause the fixture to fail.  To check operation during the daylight hours, cover the SLC’s photocell window (or top surface) completely to simulate darkness. FCC Statement: 15.19 This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operati on. 5.105 This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to p art 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interferen ce in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communic ations. However, there is no guarantee that interference will not occur in a particular installation. If this equip ment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: —Reorient or relocate the receiving antenna. —Increase the separation between the equipment and receiver. —Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. —Consult the dealer or an experienced radio/TV technician for help. Installation Procedure ISLC3100-7P Page 8 FCC Radiation Exposure Statement This device complies with FCC radiation exposure limits set forth for an uncontrolled environment and it also complies with Part 15 of the FCC RF Rules. This equipment must be installed and operated in accordance with provided instructions and the antenna(s) used for this transmitter must be installed to provide a separation d istance of at least 20 cm from all persons and must not be co- located or operating in conjunction with any other antenna or transmitter. End- users and installers must be provided with antenna installation instructions and consider removing the no- collocation statement.

www.cimconlighting.com Worldwide Headquarter Asia Pacific Office 200 Summit Drive, Suite 500, 802, Sakar IV, Ellisbridge, South Tower, Burlington, MA 01803 Ahmedabad-380 006, India Tel:(978)-320-4002 Tel: +91-79-2657 8639 Fax:(978)-299-5212 Fax: +91-79-2657 8659 RF_160, Issue 04 Declaration of Authorization We Name: CIMCON Lighting, Inc. Address: 200 Summit Drive, Suite 500, South Tower City: Burlington State: Massachusetts Country: United States Declare that: Name Representative of agent: Ms. Melody Wu Agent Company name: BTL Inc. Address: 4F,No.18, Ln. 171, Sec. 2, Jiuzong Rd., Neihu Dist.114, City: Taipei Country Taiwan is authorized to apply for Certification of the following product(s): Product description: Photocontroller Type designation: ISLC3100-7P-N Trademark: CIMCON Validity/ expiry date: From December 23, 2020 to December 22, 2021 on our behalf. Date:December 23, 2020 City: Burlington Name: Sudhanshu Jha Function: VP - Engineering Signature: Notes: (1): Required for FCC application (2): For FCC it must be the Grantee Code “owner” or the authorized agent.

FCC, Request for non-disclosure Date: 23-Dec-2020 RF_501, Issue 8 Page 1 of 1 Company Name: CIMCON Lighting, Inc. Address: 200 Summit Drive,Suite 500, South Tower City: Burlington Country: United States To: Telefication B.V., Dept. FCC TCB Edisonstraat 12A 6902 PK ZEVENAAR The Netherlands Subject: Request for confidentiality FCC ID: 2ALSZ-CL3100N Reference number: ###### Dear FCC TCB, 1. Long-Term Confidentiality Pursuant to 47 CFR Section 0.459(a) & (b), we hereby requests non-disclosure and confidential treatment of the following materials submitted in support of FCC certification application: Bill(s) of Material Block Diagrams Operational Description Schematic Diagrams Tune-up Procedure Above materials contain secrets, proprietary and technical information, which would customarily be guarded from competitors under 47 CFR, section 0.457(d)(2). Disclosure or publication or any portion of this company confidential material to other parties could cause substantial competitive harm and provide unjustified benefits for competitors. 2. Short-Term Confidentiality (STC) Pursuant to Public Notice DA 04-1705 of the Commission’s policy, in order to comply with the marketing regulations in 47 CFR §2.803 and the importation rules in 47 CFR §2.1204, applicant hereby requests Short-Term Confidential treatment of the following materials (See notes below): Internal Photos User’s Manual Test Set-up Photos External Photos Justification: Date: 2020-12-23 Name and signature of applicant: Sudhanshu Jha Notes: 1) A document or type of document can only have ONE type of confidentiality! 2) Short-Term confidentiality is in principle for 45 days from date of grant; it can be extended max 3 times (total time 180 days max.)! The planned date should stated in the RF731 application form. 3) FCC must be informed when marketing begins earlier. 4) Release takes place automatically thus extension must be requested in time. Telefication does not remind you of this! 5) Request for extension or for release must be received by Telefication at least 7 days before date of actual marketing or before expiration of the STC period

Appendix No.: EP-2010T074-1 APPENDIX-EUT PHOTOS Project No.: 2010T074 Page 1 of 11 Appendix No.: EP-2010T074-1 APPENDIX-EUT PHOTOS Project No.: 2010T074 Page 2 of 11 Appendix No.: EP-2010T074-1 APPENDIX-EUT PHOTOS Project No.: 2010T074 Page 3 of 11

Appendix No.: EP-2010T074-1 APPENDIX-EUT PHOTOS Project No.: 2010T074 Page 4 of 11 Appendix No.: EP-2010T074-1 APPENDIX-EUT PHOTOS Project No.: 2010T074 Page 5 of 11 Appendix No.: EP-2010T074-1 APPENDIX-EUT PHOTOS Project No.: 2010T074 Page 6 of 11 Appendix No.: EP-2010T074-1 APPENDIX-EUT PHOTOS Project No.: 2010T074 Page 7 of 11 Appendix No.: EP-2010T074-1 APPENDIX-EUT PHOTOS Project No.: 2010T074 Page 8 of 11 Appendix No.: EP-2010T074-1 APPENDIX-EUT PHOTOS Project No.: 2010T074 Page 9 of 11 Appendix No.: EP-2010T074-1 APPENDIX-EUT PHOTOS Project No.: 2010T074 Page 10 of 11 Appendix No.: EP-2010T074-1 APPENDIX-EUT PHOTOS Project No.: 2010T074 Page 11 of 11

Report No.: BTL-FCCP-3-2010T074 Project No.: 2010T074 Page 1 of 4 Report Version: R01 FCC RF EXPOSURE REPORT FCC ID: 2ALSZ-CL3100N Report No. : BTL-FCCP-3-2010T074 Equipment : Photocontroller Model Name : ISLC3100-7P-N Brand Name : CIMCON Applicant : CIMCON Lighting, Inc. Address : 200 Summit Drive, Suite 500, South Tower, Burlington, Massachusetts, United States 01803 Radio Function : LTE FCC Rule Part(s) : FCC Guidelines for Human Exposure IEEE C95.1 & FCC Part 2.1091 FCC Title 47 Part 2.1091, OET Bulletin 65 Supplement C Date of Receipt : 2020/10/22 Date of Test : 2020/10/22 ~ 2020/11/20 Issued Date : 2021/1/14 The above equipment has been tested and found in compliance with the requirement of the above standards by BTL Inc. Prepared by : Peter Chen, Engineer Approved by : Scott Hsu , Manager BTL Inc. No.18, Ln. 171, Sec. 2, Jiuzong Rd., Neihu Dist., Taipei City 114, Taiwan Tel: +886-2-2657-3299 Fax: +886-2-2657-3331 Web: www.newbtl.com Report No.: BTL-FCCP-3-2010T074 Project No.: 2010T074 Page 2 of 4 Report Version: R01 REPORT ISSUED HISTORY Report Version Description Issued Date R00 Original Issue 2020/12/25 R01 Revised report to address TCB’s comments. 2021/1/14 Report No.: BTL-FCCP-3-2010T074 Project No.: 2010T074 Page 3 of 4 Report Version: R01 MPE CALCULATION METHOD Calculation Method of RF Safety Distance: where: S = power density P = power input to the antenna G = power gain of the antenna in the direction of interest relative to an isotropic radiator R = distance to the center of radiation of the antenna Report No.: BTL-FCCP-3-2010T074 Project No.: 2010T074 Page 4 of 4 Report Version: R01 Table for Filed Antenna: Antenna Manufacture P/N Type Connector Gain (dBi) Note 1 W3419BXXXX FPC I-PEX 4.54 LTE Band 2 4.68 LTE Band 4 -3.66 LTE Band 12 Output power including tune up tolerance Function Target power (dBm) Tolerance (dB) Maximum power (dBm) WWAN NBIOT 23 1.5 24.5 TEST RESULTS Mode Band Frequency (MHz) Antenna Gain (dBi) Max. Output Power (dBm) Power Density (mW/cm 2 ) Limit of Power Density (mW/cm 2 ) Test Result LTE Band 2 1880.0 4.54 24.5 0.1595 1.0000 Complies LTE Band 4 754.8 4.68 24.5 0.1647 0.5032 Complies LTE Band 12 699.2 -3.66 24.5 0.0241 0.4661 Complies Note: The calculated distance is 20 cm. EUT PHOTO Please refer to document Appendix No.: EP-2010T074-1 (APPENDIX-EUT PHOTOS). End of Test Report End of Test Report

Report No.: BTL-FCCP-1-2010T074 Project No.: 2010T074 Page 1 of 46 Report Version: R00 FCC Radio Test Report FCC ID: 2ALSZ-CL3100N Report No. : BTL-FCCP-1-2010T074 Equipment : Photocontroller Model Name : ISLC3100-7P-N Brand Name : CIMCON Applicant : CIMCON Lighting, Inc. Address : 200 Summit Drive, Suite 500, South Tower, Burlington, Massachusetts, United States 01803 Radio Function : LTE Band 2 FCC Rule Part(s) : 47 CFR FCC Part 24 Subpart E 47 CFR FCC Part 2 ANSI/TIA/EIA-603-E-2016 FCC KDB 971168 D01 Power Meas License Digital Systems v03r01 Measurement Procedure(s) : ANSI C63.26-2015 Date of Receipt : 2020/10/22 Date of Test : 2020/10/22 ~ 2020/11/20 Issued Date : 2020/12/25 The above equipment has been tested and found in compliance with the requirement of the above standards by BTL Inc. Prepared by : Peter Chen, Engineer Approved by : Scott Hsu, Manager BTL Inc. No.18, Ln. 171, Sec. 2, Jiuzong Rd., Neihu Dist., Taipei City 114, Taiwan Tel: +886-2-2657-3299 Fax: +886-2-2657-3331 Web: www.newbtl.com Report No.: BTL-FCCP-1-2010T074 Project No.: 2010T074 Page 2 of 46 Report Version: R00 Declaration BTL represents to the client that testing is done in accordance with standard procedures as applicable and that test instruments used has been calibrated with standards traceable to international standard(s) and/or national standard(s). BTL's reports apply only to the specific samples tested under conditions. It is manufacture’s responsibility to ensure that additional production units of this model are manufactured with the identical electrical and mechanical components. BTL shall have no liability for any declarations, inferences or generalizations drawn by the client or others from BTL issued reports. This report is the confidential property of the client. As a mutual protection to the clients, the public and ourselves, the test report shall not be reproduced, except in full, without our written approval. BTL’s laboratory quality assurance procedures are in compliance with the ISO/IEC 17025 requirements, and accredited by the conformity assessment authorities listed in this test report. BTL is not responsible for the sampling stage, so the results only apply to the sample as received. The information, data and test plan are provided by manufacturer which may affect the validity of results, so it is manufacturer’s responsibility to ensure that the apparatus meets the essential requirements of applied standards and in all the possible configurations as representative of its intended use. Limitation For the use of the authority's logo is limited unless the Test Standard(s)/Scope(s)/Item(s) mentioned in this test report is (are) included in the conformity assessment authorities acceptance respective. Please note that the measurement uncertainty is provided for informational purpose only and are not use in determining the Pass/Fail results. Report No.: BTL-FCCP-1-2010T074 Project No.: 2010T074 Page 3 of 46 Report Version: R00 CONTENTS REPORT ISSUED HISTORY 4 1 SUMMARY OF TEST RESULTS 5 1.1 TEST FACILITY 6 1.2 MEASUREMENT UNCERTAINTY 6 1.3 TEST ENVIRONMENT CONDITIONS 6 2 GENERAL INFORMATION 7 2.1 DESCRIPTION OF EUT 7 2.2 TEST MODES 7 2.3 BLOCK DIAGRAM SHOWING THE CONFIGURATION OF SYSTEM TESTED 8 2.4 SUPPORT UNITS 8 3 AC POWER LINE CONDUCTED EMISSIONS TEST 9 3.1 LIMIT 9 3.2 TEST PROCEDURE 9 3.3 DEVIATION FROM TEST STANDARD 9 3.4 TEST SETUP 10 3.5 TEST RESULT 10 4 RADIATED SPURIOUS EMISSIONS MEASUREMENT 11 4.1 LIMIT 11 4.2 TEST PROCEDURE 11 4.3 DEVIATION FROM TEST STANDARD 11 4.4 TEST SETUP 12 4.5 EUT OPERATING CONDITIONS 12 4.6 TEST RESULT 12 5 LIST OF MEASURING EQUIPMENTS 13 6 EUT TEST PHOTO 14 7 EUT PHOTOS 14 APPENDIX A AC POWER LINE CONDUCTED EMISSIONS 15 APPENDIX B RADIATED SPURIOUS EMISSIONS 20 Report No.: BTL-FCCP-1-2010T074 Project No.: 2010T074 Page 4 of 46 Report Version: R00 REPORT ISSUED HISTORY Report Version Description Issued Date R00 Original Issue. 2020/12/25 Report No.: BTL-FCCP-1-2010T074 Project No.: 2010T074 Page 5 of 46 Report Version: R00 1 SUMMARY OF TEST RESULTS Test procedures according to the technical standards. FCC Clause No Description Test Result Judgement Remark 15.207 AC Power Line Conducted Emissions APPENDIX A Pass ------ 2.1053 24.238(a) Radiated Spurious Emissions APPENDIX B Pass ------ NOTE: (1) ”N/A” denotes test is not applicable in this Test Report. (2) The report format version is TP.1.1.1. (3) The spot check test channels were verified based on the worst channel results reported in the original FCC ID (XMR201707BG96) filing test report. Since the RF module has been certificated, after evaluation, above test items were criticized and reconfirmed in this report. (4) After spot check, this revision does not change original radio parameters. Report No.: BTL-FCCP-1-2010T074 Project No.: 2010T074 Page 6 of 46 Report Version: R00 1.1 TEST FACILITY The test facilities used to collect the test data in this report: No. 68-1, Ln. 169, Sec. 2, Datong Rd., Xizhi Dist., New Taipei City 221, Taiwan The test sites and facilities are covered under FCC RN: 355421 and DN: TW1099. ☒ C05 ☐ CB08 ☐ CB11 ☒ CB15 ☐ CB16 1.2 MEASUREMENT UNCERTAINTY The reported uncertainty of measurement y ± U, where expanded uncertainty U is based on a standard uncertainty multiplied by a coverage factor of k = 2, providing a level of confidence of approximately 95 %. The measurement instrumentation uncertainty considerations contained in CISPR 16-4-2. The BTL measurement uncertainty is less than the CISPR 16-4-2 U cispr requirement. A. AC power line conducted emissions test: Test Site Method Measurement Frequency Range U (dB) C05 CISPR 150 kHz ~ 30MHz 3.44 B. Radiated emissions test : Test Site Measurement Frequency Range U,(dB) CB15 0.03 GHz ~ 0.2 GHz 4.17 0.2 GHz ~ 1 GHz 4.72 1 GHz ~ 6 GHz 5.21 6 GHz ~ 18 GHz 5.51 18 GHz ~ 26 GHz 3.69 26 GHz ~ 40 GHz 4.23 NOTE: Unless specifically mentioned, the uncertainty of measurement has not been taken into account to declare the compliance or non-complia…

Text truncated - open the document above for the full version.

Report No.: BTL-FCCP-2-2010T074 Project No.: 2010T074 Page 1 of 124 Report Version: R00 FCC Radio Test Report FCC ID: 2ALSZ-CL3100N Report No. : BTL-FCCP-2-2010T074 Equipment : Photocontroller Model Name : ISLC3100-7P-N Brand Name : CIMCON Applicant : CIMCON Lighting, Inc. Address : 200 Summit Drive, Suite 500, South Tower, Burlington, Massachusetts, United States 01803 Radio Function : LTE Band 4, 12 FCC Rule Part(s) : 47 CFR FCC Part 27 Subpart H 47 CFR FCC Part 27 Subpart L 47 CFR FCC Part 2 ANSI/TIA/EIA-603-E-2016 FCC KDB 971168 D01 Power Meas License Digital Systems v03r01 Measurement Procedure(s) : ANSI C63.26-2015 Date of Receipt : 2020/10/22 Date of Test : 2020/10/22 ~ 2020/11/20 Issued Date : 2020/12/25 The above equipment has been tested and found in compliance with the requirement of the above standards by BTL Inc. Prepared by : Peter Chen, Engineer Approved by : Scott Hsu, Manager BTL Inc. No.18, Ln. 171, Sec. 2, Jiuzong Rd., Neihu Dist., Taipei City 114, Taiwan Tel: +886-2-2657-3299 Fax: +886-2-2657-3331 Web: www.newbtl.com Report No.: BTL-FCCP-2-2010T074 Project No.: 2010T074 Page 2 of 124 Report Version: R00 Declaration BTL represents to the client that testing is done in accordance with standard procedures as applicable and that test instruments used has been calibrated with standards traceable to international standard(s) and/or national standard(s). BTL's reports apply only to the specific samples tested under conditions. It is manufacture’s responsibility to ensure that additional production units of this model are manufactured with the identical electrical and mechanical components. BTL shall have no liability for any declarations, inferences or generalizations drawn by the client or others from BTL issued reports. This report is the confidential property of the client. As a mutual protection to the clients, the public and ourselves, the test report shall not be reproduced, except in full, without our written approval. BTL’s laboratory quality assurance procedures are in compliance with the ISO/IEC 17025 requirements, and accredited by the conformity assessment authorities listed in this test report. BTL is not responsible for the sampling stage, so the results only apply to the sample as received. The information, data and test plan are provided by manufacturer which may affect the validity of results, so it is manufacturer’s responsibility to ensure that the apparatus meets the essential requirements of applied standards and in all the possible configurations as representative of its intended use. Limitation For the use of the authority's logo is limited unless the Test Standard(s)/Scope(s)/Item(s) mentioned in this test report is (are) included in the conformity assessment authorities acceptance respective. Please note that the measurement uncertainty is provided for informational purpose only and are not use in determining the Pass/Fail results. Report No.: BTL-FCCP-2-2010T074 Project No.: 2010T074 Page 3 of 124 Report Version: R00 CONTENTS REPORT ISSUED HISTORY 4 1 SUMMARY OF TEST RESULTS 5 1.1 TEST FACILITY 6 1.2 MEASUREMENT UNCERTAINTY 6 1.3 TEST ENVIRONMENT CONDITIONS 6 2 GENERAL INFORMATION 7 2.1 DESCRIPTION OF EUT 7 2.2 TEST MODES 7 2.3 BLOCK DIAGRAM SHOWING THE CONFIGURATION OF SYSTEM TESTED 8 2.4 SUPPORT UNITS 8 3 AC POWER LINE CONDUCTED EMISSIONS TEST 9 3.1 LIMIT 9 3.2 TEST PROCEDURE 9 3.3 DEVIATION FROM TEST STANDARD 9 3.4 TEST SETUP 10 3.5 TEST RESULT 10 4 RADIATED SPURIOUS EMISSIONS MEASUREMENT 11 4.1 LIMIT 11 4.2 TEST PROCEDURE 11 4.3 DEVIATION FROM TEST STANDARD 11 4.4 TEST SETUP 12 4.5 EUT OPERATING CONDITIONS 12 4.6 TEST RESULT 12 5 LIST OF MEASURING EQUIPMENTS 13 6 EUT TEST PHOTO 14 7 EUT PHOTOS 14 APPENDIX A AC POWER LINE CONDUCTED EMISSIONS 15 APPENDIX B RADIATED SPURIOUS EMISSIONS 20 Report No.: BTL-FCCP-2-2010T074 Project No.: 2010T074 Page 4 of 124 Report Version: R00 REPORT ISSUED HISTORY Report Version Description Issued Date R00 Original Issue. 2020/12/25 Report No.: BTL-FCCP-2-2010T074 Project No.: 2010T074 Page 5 of 124 Report Version: R00 1 SUMMARY OF TEST RESULTS Test procedures according to the technical standards. FCC Clause No Description Test Result Judgement Remark 15.207 AC Power Line Conducted Emissions APPENDIX A Pass ------ 2.1053 27.53(g) 27.53(h) Radiated Spurious Emissions APPENDIX B Pass ------ NOTE: (1) ”N/A” denotes test is not applicable in this Test Report. (2) The report format version is TP.1.1.1. (3) The spot check test channels were verified based on the worst channel results reported in the original FCC ID (XMR201707BG96) filing test report. Since the RF module has been certificated, after evaluation, above test items were criticized and reconfirmed in this report. (4) After spot check, this revision does not change original radio parameters. Report No.: BTL-FCCP-2-2010T074 Project No.: 2010T074 Page 6 of 124 Report Version: R00 1.1 TEST FACILITY The test facilities used to collect the test data in this report: No. 68-1, Ln. 169, Sec. 2, Datong Rd., Xizhi Dist., New Taipei City 221, Taiwan The test sites and facilities are covered under FCC RN: 355421 and DN: TW1099. ☒ C05 ☐ CB08 ☐ CB11 ☒ CB15 ☐ CB16 1.2 MEASUREMENT UNCERTAINTY The reported uncertainty of measurement y ± U, where expanded uncertainty U is based on a standard uncertainty multiplied by a coverage factor of k = 2, providing a level of confidence of approximately 95 %. The measurement instrumentation uncertainty considerations contained in CISPR 16-4-2. The BTL measurement uncertainty is less than the CISPR 16-4-2 U cispr requirement. A. AC power line conducted emissions test: Test Site Method Measurement Frequency Range U (dB) C05 CISPR 150 kHz ~ 30MHz 3.44 B. Radiated emissions test : Test Site Measurement Frequency Range U,(dB) CB15 0.03 GHz ~ 0.2 GHz 4.17 0.2 GHz ~ 1 GHz 4.72 1 GHz ~ 6 GHz 5.21 6 GHz ~ 18 GHz 5.51 18 GHz ~ 26 GHz 3.69 26 GHz ~ 40 GHz 4.23 NOTE: Unless specifically mentioned, the uncertainty of measurement has not been taken into a…

Text truncated - open the document above for the full version.

RF TEST REPORT Applicant Quectel Wireless Solutions Co., Ltd. FCC ID XMR201707BG96 Product Quectel BG96 Brand Quectel Model BG96 Report No. R2003A0151-R7 Issue Date August 18, 2020 TA Technology (Shanghai) Co., Ltd. tested the above equipment in accordance with the requirements in FCC CFR47 Part 2 (2019)/ FCC CFR 47 Part 90S (2019). The test results show that the equipment tested is capable of demonstrating compliance with the requirements as documented in this report. Performed by: Peng Tao Approved by: Kai Xu TA Technology (Shanghai) Co., Ltd. No.145, Jintang Rd, Tangzhen Industry Park, Pudong Shanghai, China TEL: +86‐021‐50791141/2/3 FAX: +86‐021‐50791141/2/3‐8000 FCC RF Test Report Report No: R2003A0151-R7 TA Technology (Shanghai) Co., Ltd. TA-MB-04-010R Page 2 of 46 This report shall not be reproduced except in full, without the written approval of TA Technology (Shanghai) Co., Ltd. TABLE OF CONTENT 1. Test Laboratory ...................................................................................................................................... 4 1.1. Notes of the Test Report ............................................................................................................... 4 1.2. Test facility ..................................................................................................................................... 4 1.3. Testing Location ............................................................................................................................ 5 2. General Description of Equipment under Test ....................................................................................... 6 3. Applied Standards .................................................................................................................................. 7 4. Test Configuration .................................................................................................................................. 8 5. Test Case Results .................................................................................................................................. 9 5.1. RF Power Output ........................................................................................................................... 9 5.2. Effective Radiated Power ............................................................................................................ 11 5.3. Occupied Bandwidth ................................................................................................................... 14 5.4. Emission Mask ............................................................................................................................ 20 5.5. Peak-to-Average Power Ratio (PAPR) ....................................................................................... 27 5.6. Frequency Stability ...................................................................................................................... 29 5.7. Spurious Emissions at Antenna Terminals ................................................................................. 33 5.8. Radiates Spurious Emission ....................................................................................................... 38 6. Main Test Instruments ......................................................................................................................... 45 FCC RF Test Report Report No: R2003A0151-R7 TA Technology (Shanghai) Co., Ltd. TA-MB-04-010R Page 3 of 46 This report shall not be reproduced except in full, without the written approval of TA Technology (Shanghai) Co., Ltd. Summary of measurement results No. Test Type Clause in FCC rules Verdict 1 RF power output 2.1046/90.635(b) Refer to the Original 2 Effective Radiated Power 90.635(b) Refer to the Original 3 Occupied Bandwidth 2.1049/ 90.209 Refer to the Original 4 Emission Masks 2.1051 / 90.691 Only test LTE Band 5 Peak-to-Average Power Ratio KDB 971168 D01(5.7) Refer to the Original 6 Frequency Stability 2.1055 / 90.213 Refer to the Original 7 Spurious Emissions at Antenna Terminals 2.1051 / 90.691 Refer to the Original 8 Radiates Spurious Emission 2.1053 /90.691 Refer to the Original Date of Testing: June 24, 2017~ July 3, 2017 and August10, 2020 ~ August12, 2020 Note: PASS: The EUT complies with the essential requirements in the standard. FAIL: The EUT does not comply with the essential requirements in the standard. BG96 (Report No.: R2003A0151-R7) is a variant model of BG96 (Report No.: RXA1706-0199RF04R1). Test values partial duplicated from original for variant. There is only tested Band Edge Compliance of LTE Band for variant in this report. The detailed product change description please refers to the Statement letter_BG96. FCC RF Test Report Report No: R2003A0151-R7 TA Technology (Shanghai) Co., Ltd. TA-MB-04-010R Page 4 of 46 This report shall not be reproduced except in full, without the written approval of TA Technology (Shanghai) Co., Ltd. 1. Test Laboratory 1.1. Notes of the Test Report This report shall not be reproduced in full or partial, without the written approval of TA technology (shanghai) co., Ltd. The results documented in this report apply only to the tested sample, under the conditions and modes of operation as described herein .Measurement Uncertainties were not taken into account and are published for informational purposes only. This report is written to support regulatory compliance of the applicable standards stated above. This report must not be used by the client to claim product certification, approval, or endorsement by any government agencies. 1.2. Test facility FCC (recognition number is 428261) TA Technology (Shanghai) Co., Ltd. has been listed on the US Federal Communications Commission list of test facilities recognized to perform electromagnetic emissions measurements. A2LA (Certificate Number: 3857.01) TA Technology (Shanghai) Co., Ltd. has been listed by American Association for Laboratory Accreditation to per…

Text truncated - open the document above for the full version.

RF TEST REPORT Applicant Quectel Wireless Solutions Co., Ltd. FCC ID XMR201707BG96 Product Quectel BG96 Brand Quectel Model BG96 Report No. R2003A0151-R1 Issue Date July 14, 2020 TA Technology (Shanghai) Co., Ltd. tested the above equipment in accordance with the requirements in FCC CFR47 Part 2 (2019)/ FCC CFR 47 Part 22H (2019). The test results show that the equipment tested is capable of demonstrating compliance with the requirements as documented in this report. Performed by: Peng Tao Approved by: Kai Xu TA Technology (Shanghai) Co., Ltd. No.145, Jintang Rd, Tangzhen Industry Park, Pudong Shanghai, China TEL: +86‐021‐50791141/2/3 FAX: +86‐021‐50791141/2/3‐8000 FCC RF Test Report Report No: R2003A0151-R1 TA Technology (Shanghai) Co., Ltd. TA-MB-04-001R Page 2 of 36 This report shall not be reproduced except in full, without the written approval of TA Technology (Shanghai) Co., Ltd. TABLE OF CONTENT 1. Test Laboratory ...................................................................…

Text truncated - open the document above for the full version.
