MDM2 & MRX2 iMO-LEARN Quick Start Guide 1.iMO-LEARN Product Family Members iMO LEARN CUBE active learning iMO LEARN MRX2 receiver antenna iMO LEARN MDM2 dynamic motion sensor 7x Status LED Main components of the iMO LEARN MDM2. 4x Dip Switch USB-C port ON OFF 2. Product Overview USB-A connector Main components of the iMO LEARN MRX2. Antenna Module Insert iMO LEARN MRX2 into your computer, using any USB-A 2.0 input. Download Run the installer. Please note: you may need administrator rights. 3. Download and install Software iMO-CONNECT-2 software from QR or https://www.i3-technologies.com/en/products/ hardware/cube-for-active-learning/ iMO-CONNECT-2 Observe that all status indicators on the MDM2 modules are flashing when connected. 4. Connect the MDM2 modules Open the iMO-CONNECT-2 software on the device where you have installed it in the previous step. The software will search for all iMO-LEARN MDM2 modules near you and display them on the screen with their iD. Power ON all iMO-LEARN MDM2 modules by sliding the orange button up. You can create ‘groups’ of MDM2 modules. First, open the rear cover by pushing the lip and take off the cover. Now you have get access to the 4 upper dipswitches. Randomly change their position. All MDM2 ‘s that have the same pattern of dipswitch positions, will belong to the same group. The iMO-CONNECT-2 software will show these groups.. >Option: setting of groups of MDM2 modules 1ON 2 3 4 4x Dip Switch Open the iMO-CONNECT-2 software. It will guide you through the steps below: Click the icons to connect and wait until they turn green. If you have set groups, you can select them here. Select ‘Done Connecting’ to continue to i3LEARNHUB. 5. Activate the iMO-LEARN MDM2’s. Insert the MDM2 into the slot in the top of the iMO-LEARN cube with the i3-logo facing the yellow sticker (with the O symbol). Refer to the picture below. ON 6. Insert the iMO-LEARN MDM2 into the cube. Orange Button i3-logo When the last status LED shows red, it is time to recharge the MDM2. Plug-in any suitable powered USB-C cable into the port at the bottom and recharge. (5V) The MDM2 is fully charged when the LED turns green. 7. Charging the iMO-LEARN MDM2. Go to the iMO-LEARN website on https://www.i3-technologies.com/ en/products/accessories/imo-learn/ and be inspired to bring active and dynamic education to your class. 8. Supercharge your classroom! Additional information FEDERAL COMMUNICATIONS COMMISSION INTERFERENCE STATEMENT This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: •Reorient or relocate the receiving antenna. •Increase the separation between the equipment and receiver. •Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. •Consult the dealer or an experienced radio/ TV technician for help. CAUTION: Any changes or modifications not expressly approved by the grantee of this device could void the user's authority to operate the equipment. RF EXPOSURE WARNING: The equipment complies with FCC RF exposure limits set forth for an uncontrolled environment. The equipment must not be co-located or operating in conjunction with any other antenna or transmitter. i3-Technologies NV hereby declares that these iMO-LEARN MDM2 and MRX2 products are in compliance with the essential requirements and other relevant provisions of the Directives 2014/53/EU, and 2014/65/EU. The availability of this product may vary by region. This device may contain commodities, technology or software subject to export laws and regulations. Diversion contrary to law is prohibited. Nijverheidslaan 60, B-8540 Deerlijk, BELGIUM This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. © 2024 i3-Technologies N.V. iMO-LEARN, iMO-CONNECT, i3-Technologies and the i3 LOGO are trademarks of i3 GROUP and it’s companies. All other trademarks are the property of their respective owner s

Report No.: 2408TW0502-UE 1 of 3 External Photograph (1) EUT Photo (2) EUT Photo Report No.: 2408TW0502-UE 2 of 3 (3) EUT Photo (4) EUT Photo Report No.: 2408TW0502-UE 3 of 3 (5) EUT Photo (6) EUT Photo

Label Label location

Report No.: 2408TW0502-UI 1 of 3 Internal Photograph (1) EUT Photo (2) EUT Photo Report No.: 2408TW0502-UI 2 of 3 (3) EUT Photo (4) EUT Photo Report No.: 2408TW0502-UI 3 of 3 (5) EUT Photo

MRT Technology (Taiwan) Co., Ltd Report No.: 2408TW0502-U2 Phone: +886-3-3288388 Report Version: 1.0 Fax: +886-3-3288918 Issue Date: 2024-09-12 Web: www.mrt-cert.com Page Number: 1 of 5 RF Exposure Evaluation Declaration FCC ID: 2ALTTMRX-200 APPLICANT: i3-Technologies N.V. Application Type: Certification Product: iMO-LEARN MRX2 Model No.: MRX-200 Trademark: FCC Rule Part(s): Part 2.1093 (Portable) Test Procedure(s): KDB 447498 D01v06 Test Date: August 21, 2024 Reviewed By : ( Paddy Chen ) Approved By : ( Chenz Ker ) The test results relate only to the samples tested. This equipment has been shown to be capable of compliance with the applicable technical standards as indicated in the measurement report. Test results reported herein relate only to the item(s) tested. The test report shall not be reproduced except in full without the written approval of MRT Technology (Taiwan) Co., Ltd. Report No.: 2408TW0502-U2 Page Number: 2 of 5 Revision History Report No. Version Description Issue Date Note 2408TW0502-U2 1.0 Original Report 2024-09-12 Report No.: 2408TW0502-U2 Page Number: 3 of 5 1. PRODUCT INFORMATION 1.1. Equipment Description 1.2. Antenna Description No. Manufacturer Part No. Antenna Type Peak Gain 1 Gwell STBT40-XXX PCB 0.0dBi Product Name iMO-LEARN MRX2 Model No. MRX-200 Trademark Bluetooth Specification Bluetooth: V5.1 LE Operating Frequency 2402~2480MHz Modulation Type GFSK Report No.: 2408TW0502-U2 Page Number: 4 of 5 2. MAXIMUM PERMISSIBLE EXPOSURE (MPE) 2.1. FCC Limits According to FCC KDB 447498 Section 4.3 - General SAR test exclusion guidance For 100 MHz to 6 GHz and test separation distances ≤ 50 mm, the 1-g and 10-g SAR test exclusion thresholds are determined by the following: [(max. power of channel, including tune-up tolerance, mW) / (min. test separation distance, mm)] · [√f(GHz)] ≤ 3.0 for 1-g SAR, and ≤ 7.5 for 10-g extremity SAR, where 1. f(GHz) is the RF channel transmit frequency in GHz 2. Power and distance are rounded to the nearest mW and mm before calculation 3. The result is rounded to one decimal place for comparison 4.The values 3.0 and 7.5 are referred to as numeric thresholds in step b) below The test exclusions are applicable only when the minimum test separation distance is ≤ 50 mm, and for transmission frequencies between 100 MHz and 6 GHz. When the minimum test separation distance is < 5 mm, a distance of 5 mm according to 4.1 f) is applied to determine SAR test exclusion. Report No.: 2408TW0502-U2 Page Number: 5 of 5 2.2. Test Result Mode Frequency Band (MHz) Average Output Power (dBm) Output Power (mW) FCC SAR Test Exclusion Threshold (mW) BLE 2402~2480 1.31 1.35 3 So, this device can complies the SAR test exclusion. The End

Gwell Technology Co., Ltd. 天線規格書 Absoltute Maximum Ratings Operating Temperature: Range -40~85
Operating Humidity: 85 %RH Storage Temperature Range -20~ 60
Tc=25°C Electrical Specifications 1. Radiated Frequency range: 2400-2483 MHz 2. Radiated Peak Gain: 0 dBi @XZ/Vertical 3. Radiated Average Gain: -3 dBi @XZ/Vertical 4. VSWR: Max. 2 5. Impedance: 50 Ω 6. Return Loss: 10 dB 7. Maximum Power : 4dBm Antenna Type: PCB antenna

MRT Technology (Taiwan) Co., Ltd Report No.: 2408TW0502-U1 Phone: +886-3-3288388 Report Version: 1.0 Fax: +886-3-3288918 Issue Date: 2024-09-12 Web: www.mrt-cert.com Page Number: 1 of 56 FCC ID : 2ALTTMRX-200 APPLICANT : i3-Technologies N.V. Application Type : Certification Product : iMO-LEARN MRX2 Model No. : MRX-200 Trademark : FCC Classification : (DTS) Digital Transmission System FCC Rule Part(s) : Part 15.247 Test Procedure(s) : ANSI C63.10-2013 Received Date : August 21, 2024 Test Date : August 27, 2024~ August 30, 2024 MEASUREMENT REPORT Test By : ( Kaunaz Lee ) Reviewed By : ( Paddy Chen ) Approved By : ( Chenz Ker) The test results only relate to the tested sample. This equipment has been shown to be capable of compliance with the applicable technical standards as indicated in the measurement report and was tested in accordance with the measurement procedures specified in ANSI C63.10. Test results reported herein relate only to the item(s) tested. The test report shall not be reproduced except in full without the written approval of MRT Technology (Taiwan) Co., Ltd. Report No.: 2408TW0502-U1 Page Number: 2 of 56 Revision History Report No. Version Description Issue Date Note 2408TW0502-U1 1.0 Original Report 2024-09-12 Report No.: 2408TW0502-U1 Page Number: 3 of 56 CONTENTS Description Page 1. INTRODUCTION ..................................................................................................................... 6 1.1. Scope .................................................................................................................................... 6 1.2. MRT Test Location ................................................................................................................ 6 2. PRODUCT INFORMATION ..................................................................................................... 7 2.1. Equipment Description .......................................................................................................... 7 2.2. Product Specification Subjective to this Standard .................................................................. 8 2.3. Test Mode ............................................................................................................................. 8 2.4. Operation Frequency / Channel List ...................................................................................... 8 2.5. Test Configuration ................................................................................................................. 9 2.6. Test System Details ............................................................................................................ 10 2.7. Test Software ...................................................................................................................... 10 2.8. Duty Cycle ........................................................................................................................... 11 2.9. EMI Suppression Device(s)/Modifications ........................................................................... 12 2.10. Labeling Requirements.................................................................................................... 12 3. DESCRIPTION of TEST ........................................................................................................ 13 3.1. Evaluation Procedure .......................................................................................................... 13 3.2. AC Line Conducted Emissions ............................................................................................ 13 3.3. Radiated Emissions ............................................................................................................ 14 4. ANTENNA REQUIREMENTS ................................................................................................ 15 5. TEST EQUIPMENT CALIBRATION DATE ............................................................................ 16 6. MEASUREMENT UNCERTAINTY ......................................................................................... 17 7. TEST RESULT ...................................................................................................................... 18 7.1. Summary ............................................................................................................................. 18 7.2. 6dB Bandwidth Measurement ............................................................................................. 19 7.2.1. Test Limit ......................................................................................................................... 19 7.2.2. Test Procedure used ....................................................................................................... 19 7.2.3. Test Setting ..................................................................................................................... 19 7.2.4. Test Setup ....................................................................................................................... 19 7.2.5. Test Result ...................................................................................................................... 20 7.3. Output Power Measurement ................................................................................................ 21 7.3.1. Test Limit ......................................................................................................................... 21 7.3.2. Test Procedure Used ....................................................................................................... 21 7.3.3. Test Setting ..................................................................................................................... 21 7.3.4. Test Setup ....................................................................................................................... 21 7.3.5. Test Result of Output Power ..............................................................…
