Kaiterra Sensedge Mini Air Quality Monitor Made in China [email protected] Origins Technology Limited. 603 6/F, Laws Commercial Plaza, 788 Cheung Sha Wan Road, Hong Kong ENGLISH Kaiterra Sensedge Mini Air Quality Monitor User Manual What’s Included ● Sensedge Mini ● Sensedge Mini sensor modules x 2 ● Surface / Drywall mount ● Electrical box mount ● Drywall screws and anchors (3 pairs) ● Electrical box screws (US) x 2 ● Electrical box screws (China and EU) x 2 ● Fastening screws x 2 ● USB cable ● Charger ● Certificate of calibration and testing ● User manual ● Certificate of conformity Important Safeguards Please read the safety warnings before use and take the necessary precautions to reduce the risk of fire, electric shock, or injury. The Kaiterra limited warranty applies only if the unit is used according to these instructions. WARNING ● To reduce safety risks, always use service personnelfrom the manufacturer or service provider, or other qualified personnel for installation and maintenance. ● Make sure the power is OFF during installation or maintenance. ● DO NOT tamper with or use nonofficial spare parts for repair or maintenance. ● DO NOT use the device in environments with high humidity or possible direct exposure to water. ● DO NOT use the device in an outdoor environment. ● DO NOT use the device near heat sources such asradiators, furnaces, ovens, or stoves. Getting Started The Sensedge Mini is a commercial-grade air quality monitor. This user manual will provide a basic guide to its first use. Further information can be found on the Kaiterra Support Portal athttp://support.kaiterra.com/sensedge-mini Operational Temperature：0 - 40°C Externals and Air Flow Air is drawn into the Sensedge Mini from the lower side, as well as the air intake on the upper side. It is vital that neither side of the device is covered. Any changes in airflow may affect the readings and accuracy. Power and Connectivity The Sensedge Mini provides multiple power and connectivity options: Power: ● USB-C: Only use the cable and charger/adapter suppliedwith the device ● DC direct wiring: Used for power supply of 12V,1000mA ● PoE (Power over Ethernet): Available for model SE000200P Connectivity: ● 2.4GHz Wi-Fi (802.11 b/g/n) ● Ethernet: Used for data transfer via Ethernet ● RS-485: Used for Modbus communication ● Bluetooth Sensor Modules The Sensedge Mini utilizes a modular design to allow for easy control and replacement of sensors. A CO2 sensor and a temperature and relative humidity sensor areis built into the core of the device, and a variety of other sensors may be inserted using the two sensor bays on the lower side of the device. To insert a sensor module, simply align it with the bay and press it in, ensuring the Kaiterra logo on the plastic tab is facing outwards. When inserted correctly, the module will click into place, and an LED light above the bay will briefly flash red if the device is powered on. To remove a sensor module, gently pull the tab outward and remove the module from the bay. Make sure to pull at a 90 degree angle. Sensors may be inserted in either sensor bay, and in any order. They may be swapped both when the Sensedge Mini is powered on and operational, and when the device is turned off. By default, the Sensedge Mini is shipped with the KM-200 and KM-203 sensor modules, which together measure PM2.5, and TVOC., temperature, and relative humidity. Sensor Module Status Light Indications: Steady OFFSensor working normal Flash red onceSensor module powered on Steady ONSensor module needs to be changed FlashSensor module failure Flash slowlySensor module in sleep mode Control and Status Move the ON/OFF switch right to turn on the device. The STATUS light will go on briefly to indicate the device has been powered on. To reset the device, use a paperclip and hold down the RESET pinhole. The STATUS light will flash red rapidly, indicating that the reset is successful. STATUS Light Indications: Standard operation: Steady OFFDevice working normal Flash red onceDevice powered on Flash red rapidlyReset successful Configuration: Flash yellowDevice in configuration mode Flash yellow rapidly for 5 seconds Identify via configuration tool Flash green rapidlyConnecting to the network Glow green graduallyConnecting to the cloud Troubleshooting: Steady ON in redDevice failure Flash redNo network connection Installation The Sensedge Mini can be mounted on a concrete block wall, drywall, ceiling, or to an electrical box. For detailed instructions on installation, power, and connectivity setup, please visit our support center website athttp://support.kaiterra.com/sensedge-minior scan the QR code below. Warranty Information Kaiterra provides a 1-year limited manufacturer warranty on the Sensedge Mini. To obtain a copy of the warranty for this product, please visit https://support.kaiterra.com/policies Troubleshooting For additional support, please contact your sales representative or email us at [email protected] 中文 Kaiterra 睿石 Mini 空气质量监测仪用户手册 包装清单 ● 睿石 Mini 主机 ●睿石 Mini 传感器模块 x 2 ●墙面/石膏板墙安装圆盘底座 ●有底盒安装方盘底座 ●石膏板螺丝&锚栓（3 对） ●底盒螺丝（美标）x 2 ●底盒螺丝（国标/欧标）x 2 ●固定螺丝 x 2 ●USB 数据线 ●充电器 ●校准测试报告 ●用户手册 ●合格证书 重要预防措施 请在使用前阅读安全须知，并采取必要预防措施来降低火灾、电击或受伤的风险。原点生 活（Kaiterra）有限保修仅在遵照这些说明使用设备时适用。 安全须知 ●为了避免危险，必须始终由制造商、服务代理商或有资质的人员进行安装、维护等操 作。 ●安装与维护前，请确保电源已断开。 ●请勿以任何方式改造或使用非官方配件维修维护设备。 ●请勿将设备置于高湿度环境或可能直接接触水的位置。 ●请勿将设备置于室外。 ●请勿将设备放在散热器、壁炉、烤箱、炉灶等热源附近。 开始使用 睿石 Mini 是一款商用空气质量监测仪。此手册为用户首次使用设备提供指导，更多信息 可以在 Kaiterra 官网的“客户支持”中查询，链接地址： http://support.kaiterra.com/sensedge-mini。 运行温度：0 - 40°C 外观和空气流动 睿石 Mini 的进气口位于设备的上方和下方，使用时请确保设备的任何一侧都不能被覆盖。 气流的变化可能影响睿石 Mini 的读数及准确性。 供电和联网方式 睿石 Mini 提供多种供电和联网选择： 供电： ●USB-C：仅可使用设备随附的数据线及充电器或适配器 ●DC 电源接口：用于 12V，1000mA 供电 ●PoE（通过以太网供电）：适用于型号 SE000200P 联网： ● 2.4GHz Wi-Fi （802.11 b/g/n） ●以太网：用于通过以太网进行数据传输 ●RS-485：用于支持 Modbus 通讯 传感器模块 睿石 Mini 采用模块化设计，便于控制及更换传感器。其中，二氧化碳和温湿度传感器内 置于设备内部，设备下方的两个传感器凹槽可用于装载各种其他的传感器模块。 安装传感器模块时，只需将传感器轻压入凹槽内，确保铝制外壳上的Kaiterra标志朝外即 可。当正确安装后，模 块 将被 锁 定于凹槽内，如 设备 已 经 接入 电…

Text truncated - open the document above for the full version.

Origins Technology Limited U.S. Agent Designation for Service of Process - Certification Attestation Letter March 22, 2023 Nemko North America, Inc. 303 River Road Ottawa K1V 1H2 Canada ATTN.: Reviewing Engineer FCC ID: 2ALV5-SE-200PB Per section 2.911(d)(7) of the FCC rules, (“ Origins Technology Limited.”) certifies that the equipment for which authorization is sought is designated to the following U.S. Designated agent* for service of process: Company Name: Global Product Services & Consultation LLC Physical U.S. Company Address: 328 W Palm Ave, Monrovia. CA91016 Agent name: Chi S. Chan Agent Email Address: [email protected] FRN: 0033406703 The above contact person accepts the obligation for service of process. The applicant accepts to maintain an agent for no less than one year after the grantee has terminated all marketing and importation or the conclusion of any Commission-related proceeding involving the equipment. Applicant Signed: Designated Agent Signed: (Required, if different to Applicant): Signed: Signed: Printed name: xiaolei wang Printed name: Chi S. Chan Title: Manager Title: Technical Director Company Name: Origins Technology Limited Company Name: Global Product Services & Consultation LL Date: March 22, 2023 Date: 2023-03-22 SC 3031716 * the applicant must designate a contact located in the United States for purposes of acting as the applicant’s agent for service of process, regardless of whether the applicant is a domestic or foreign entity. An applicant located in the United States may designate itself as the agent for service of process.

OriginsTechnologyLimited CoveredEquipmentCertificationAttestationLetter 3/20/2023 NemkoNorthAmerica,Inc. 303RiverRoad Ottawa K1V1H2 Canada ATTN.:ReviewingEngineer FCCID: 2ALV5-SE-200PB ( OriginsTechnologyLimited )certifiesthattheequipmentforwhichauthorizationis soughtisnot“covered”equipmentprohibitedfromreceivinganequipmentauthorization pursuanttosection2.903oftheFCCrules. Note:Iftheequipmentforwhichtheapplicantseeksauthorizationisproducedby anyoftheentitiesidentifiedonthecurrentCoveredList,theapplicantshould includeanexplanationonwhytheequipmentisnot“covered”equipment. (OriginsTechnologyLimited)certifiesthat,asofthedateofthefilingoftheapplication, theapplicantisnotidentifiedontheCoveredListasanentityproducing“covered” equipment. Signed: Printedname:xiaoleiwang Title:Manager CompanyName: OriginsTechnologyLimited Date: 3/20/2023

2023-03-20 NemkoCanadaInc 303RiverRoad Ottawa,Ontario,Canada K1V1H2 Attn:DirectorofCertification AuthoritytoActasAgent Onourbehalf,IappointShenzhenHuatongweiInternationalInspectionCo., Ltd./1/F,Bldg3,HongfaHi-techIndustrialPark,GenyuRoad,Tianliao, Gongming,Shenzhen,China/HansHu,.toactasouragentinthepreparationof thisapplicationforequipmentcertification.Icertifythatsubmitteddocumentsproperly describethedeviceorsystemforwhichequipmentcertificationissought.Ialsocertify thateachunitmanufactured,importedormarketed,asdefinedintheFederal CommunicationsCommission’sregulationswillhaveaffixedtoitalabelidenticalto thatsubmittedforapprovalwiththisapplication. Forinstanceswhereourauthorizedagentsignstheapplicationforcertificationonour behalf,Iacknowledgethatallresponsibilityforcomplyingwiththetermsandconditions forcertification,asspecifiedbyNemkoCanadaInc,stillresideswithOrigins TechnologyLimited/6036/F,LawsCommercialPlaza,788CheungSha WanRoad,HongKong Agencyagreementexpirationdate: 2024-03-19 By: xiaoleiwang SignaturePrinted Onbehalfof: OriginsTechnologyLimited Telephone: +86-010-57161350

2023-03-20 EquipmentAutorisationDivision FederalCommunicationsCommission 7435OaklandMillsRoad Columbia,MD21046 FCCID: 2ALV5-SE-200PB ProductName: KaiterraSensedgeMiniAirQualityMonitor RequestforConfidentiality PursuanttoSections0.457and0.459ofthecommissionsrules,weherebyrequestthat thefollowingdocumentsbeheldconfidential: Schematics Blockdiagram  Operationdescription  Thesematerialscontaintradesecretsandproprietaryinformationandarenot customarilyreleasedtothepublic.Thepublicdisclosureofthisinformationmightbe harmfultothecompanyandprovideunjustifiedbenefitstoourcompetitors. By: xiaoleiwang SignaturePrinted Onbehalfof: OriginsTechnologyLimited Telephone: +86-010-57161350

Differences declaration To whom concern: Our company(Origins Technology Limited) Here by declares: Multi-model differences are as follows: Main model: Listed model: SE-200PB Schematic diagram 电路原理图 PCB layout PCB走线 Appearance 外观结构 Model name 型号命名 Other 其它 SE-200B  ∆ Note: 1. If it is a same, mark it as 如相同 , 则标识为  2. If there is a difference, mark it as ∆; If there are differences other than model name differences, please describe them in detail 如有差异，则标注为∆;除了型号命名差异外，如有其它差异则需要在下面详细描述 Model No.:Differences describe SE-200PB Support POE power supply SE-200B POE power supply not supported ∆ By: xiaoleiwang SignaturePrinted Title:Manager Onbehalfof:OriginsTechnologyLimited

External Photos of the EUT SE-200PB SE-200B

Internal Photos of the EUT SE-200PB SE-200B

FCC ID: 2ALV5-SE-200PB RF Exposure Evaluation LIMIT The criteria listed in the following table shall be used to evaluate the environment impact of human exposure to radio frequency (RF) radiation as specified in 1.1307(b) Limits for Maximum Permissible Exposure (MPE) Frequency range (MHz) Electric field strength (V/m) Magnetic field strength (A/m) Power density (mW/cm 2 ) Averaging time (minutes) (A) Limits for Occupational/Controlled Exposures 0.3–3.0 614 1.63 *(100) 6 3.0–30 1842/f 4.89/f *(900/f 2 ) 6 30–300 61.4 0.163 1.0 6 300–1500 - - f/300 6 1500–100,000 - - 5 6 (B) Limits for General Population/Uncontrolled Exposure 0.3–1.34 614 1.63 *(100) 30 1.34–30 824/f 2.19/f *(180/f 2 ) 30 30–300 27.5 0.073 0.2 30 300–1500 - - f/1500 30 1500–100,000 - - 1.0 30 Note: f = frequency in MHz EVALUATION METHOD Transmission formula: Pd = (Pout*G)/(4*pi*r 2 ) Where Pd = power density in mW/cm 2 , Pout = output power to antenna in mW, G = gain of antenna in linear scale; Pi = 3.1416, R = distance between observation point and center of the radiator in cm TEST RESULT Passed Not Applicable Radio Type Frequency range (MHz) Conducted Average Power (dBm) Maximum Tune-up (dBm) Power Density (mW/cm2) Limit (mW/cm2) Result Bluetooth 2402-2480 4.83 5.00 0.0014 1.0000 Pass WIFI 2412-2472 12.47 13.00 0.0087 1.0000 Pass Note: 1) The maximum antenna gain is 3.42dBi 2) The exposure evaluation safety distance is 20cm.

Page: 1 of 29 TEST REPORT For Bluetooth-LE Report No. ...................................... : CHTEW22120020 Report Verification: Project No.................................： SHT2112010901EW FCC ID ............................................. : 2ALV5-SE-200PB Applicant’s name ........................... : Origins Technology Limited Address ............................................. : 603 6/F, Laws Commercial Plaza, 788 Cheung Sha Wan Road, Hong Kong Product Name ................................ : Kaiterra Sensedge Mini Air Quality Monitor Trade Mark ....................................... : Kaiterra Model No. ......................................... : SE-200PB Listed Model(s) ................................. : SE-200B Standard ......................................... : FCC CFR Title 47 Part 15 Subpart C Section 15.247 Date of receipt of test sample..........: Dec.17, 2021 Date of testing.............................: Dec.17, 2021- Dec.02, 2022 Date of issue...............................: Dec.05, 2022 Result .................. ........................: PASS Compiled by ( position+printed name+signature) .. : File administrators Fanghui Zhu Supervised by ( position+printed name+signature) .. : Project Engineer Kiki Kong Approved by (Position+Printed name+Signature): RF Manager Hans Hu Testing Laboratory Name ............. : Shenzhen Huatongwei International Inspection Co., Ltd. Address ............................................. : 1/F, Bldg 3, Hongfa Hi-tech Industrial Park, Genyu Road, Tianliao, Gongming, Shenzhen, China Shenzhen Huatongwei International Inspection Co., Ltd. All rights reserved. This publication may be reproduced in whole or in part for non-commercial purposes as long as the Shenzhen Huatongwei International Inspection Co., Ltd. is acknowledged as copyright owner and source of the material. Shenzhen Huatongwei International Inspection Co., Ltd. takes no responsibility for and will not assume liability for damages resulting from the reader's interpretation of the reproduced material due to its placement and context. The test report merely correspond to the test sample. Report No.: CHTEW22120020 Page: 2 of 29 Date of issue: 2022-12-05 Shenzhen Huatongwei International Inspection Co., Ltd. Report Template Version: V04 (2022-01) Contents 1. TEST S T AN D AR D S A N D R E P O R T V E R S I O N 3 1.1. Test Standards 3 1.2. Report version 3 2. TEST DESCRIPTION 4 3. SUMMARY 5 3.1. Client Information 5 3.2. Product Description 5 3.3. Radio Specification Description 5 3.4. Testing Laboratory Information 6 4. TEST CONFIGURATION 7 4.1. Test frequency list 7 4.2. Descriptions of Test mode 7 4.3. Test sample information 7 4.4. Support unit used in test configuration and system 8 4.5. Testing environmental condition 8 4.6. Statement of the measurement uncertainty 8 4.7. Equipment Used during the Test 9 5. TEST CONDITIONS AND RESULTS 11 5.1. Antenna Requirement 11 5.2. AC Conducted Emission 12 5.3. Peak Output Power 14 5.4. Power Spectral Density 15 5.5. 6dB bandwidth 16 5.6. 99% Occupied Bandwidth 17 5.7. Duty Cycle 18 5.8. Conducted Band edge and Spurious Emission 19 5.9. Radiated Band edge Emission 20 5.10. Radiated Spurious Emission 22 6. TEST SETUP PHOTOS 27 7. EXTERNAL AND INTERNAL PHOTOS 29 8. APPENDIX REPORT 29 Report No.: CHTEW22120020 Page: 3 of 29 Date of issue: 2022-12-05 Shenzhen Huatongwei International Inspection Co., Ltd. Report Template Version: V04 (2022-01) 1. TEST STAND ARDS AND REPORT VERSION 1.1. Test Standards The tests were performed according to following standards: ‒ FCC Rules Part 15.247: Frequency Hopping, Direct Spread Spectrum and Hybrid Systems that are in operation within the bands of 902-928 MHz, 2400-2483.5 MHz, and 5725-5850 MHz ‒ ANSI C63.10:2013: American National Standard for Testing Unlicensed Wireless Devices ‒ KDB 558074 D01 15.247 Meas Guidance v05r02: Guidance for Compliance Measurements on Digital Transmission System, Frequency Hopping Spread Spectrum System, and Hybrid System Devices Operating under Section 15.247 of The FCC Rules 1.2. Report version Revision No. Date of issue Description N/A 2022-12-05 Original Report No.: CHTEW22120020 Page: 4 of 29 Date of issue: 2022-12-05 Shenzhen Huatongwei International Inspection Co., Ltd. Report Template Version: V04 (2022-01) 2. TEST DESCRIPTION Report clause Test Items Standard Requirement Result Test Engineer 5.1 Antenna Requirement 15.203/15.247(c) PASS Hailey Chen 5.2 AC Conducted Emission 15.207 PASS Quanhai Deng 5.3 Peak Output Power 15.247(b)(3) PASS Hailey Chen 5.4 Power Spectral Density 15.247(e) PASS Hailey Chen 5.5 6dB Bandwidth 15.247(a)(2) PASS Hailey Chen 5.6 99% Occupied Bandwidth - PASS *1 Hailey Chen 5.7 Duty cycle - PASS *1 Hailey Chen 5.8 Conducted Band Edge and Spurious Emission 15.247(d)/15.205 PASS Hailey Chen 5.9 Radiated Band Edge Emission 15.205/15.209 PASS Quanhai Deng 5.10 Radiated Spurious Emission 15.247(d)/15.205/15.209 PASS Junman Wang Note: ‒ The measurement uncertainty is not included in the test result. ‒ *1: No requirement on standard, only report these test data. Report No.: CHTEW22120020 Page: 5 of 29 Date of issue: 2022-12-05 Shenzhen Huatongwei International Inspection Co., Ltd. Report Template Version: V04 (2022-01) 3. SUMMARY 3.1. Client Information Applicant: Origins Technology Limited Address: 603 6/F, Laws Commercial Plaza, 788 Cheung Sha Wan Road, Hong Kong Manufacturer: Origins Technology Limited Address: 603 6/F, Laws Commercial Plaza, 788 Cheung Sha Wan Road, Hong Kong 3.2. Product Description Main unit information: Product Name: Kaiterra Sensedge Mini Air Quality Monitor Trade Mark: Kaiterra Model No.: SE-200PB Listed Model(s): SE-200B Power supply: DC 10-30V AC10-30V AC100-240V from adapter 42-57V from POE Hardware version: v1.2 Software version: v3.0.2 Accessory unit information: Adapter information: Model：SOY-0500200-090 IUPUT:100-240Va.c., 50/60Hz 0.5A Max OUTPUT：5.0Vd.c., 2.0A 10.0W 3.3. Radio Specification Description Bluetooth version:…
