2AMI2-IM040304Remote control switch

WIRELESS REMOTE CONTROL E26 LIGHT BULB SOCKET & LAMP SWITCH KIT USER GUIDE Spec: Remote control socket Remote control switch Base type: Standard E26 Working voltage: 120VAC/60Hz Maximum load: 40W Wireless protocol: 433.925MHz Working temperature: 0~40 Size: Die 60MM x 62mm Model No. :IM040303 Power: 3V(CR2032x1 included) Wireless protocol: 433.925MHz Working temperature: 0~40 Max Remote Control Distance: 35 meters. (Free Area) size: 70mm 115mm* 14mm Model No. :IM040304 1. Install the remote control socket to the present standard E26 socket. Install the light bulb onto the remote control socket. 2.Mount the remote control switch to the wall mount or stick the switch to anywhere you like. 1. Power the socket. 2. Long press set button 2 seconds. The button flashes blue slowly indicates the socket entered pairing mode. 3. Press the switch to pair. The button flashes 3 times indicates the switch and the socket paired succeed. *Socket will quit the pairing mode if no switch been paired in 30 seconds. Or you may quit pairing mode by pressing the set button. Long press set button 10 seconds to unpair all the switch that paired to this socket. The button flashes 3 times indicates the switch and the socket unpaired succeed. How to use: How to unpair? How to pair? Pairing options We have 2 optional control kits available for you. a.Multiple switches controls one socket. ( max 10 switches ) b. One switches controls One socket. ab FCC Statement Any Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation. Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: —Reorient or relocate the receiving antenna. —Increase the separation between the equipment and receiver. —Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. —Consult the dealer or an experienced radio/TV technician for help. ISED RSS Warning: This device complies with Innovation, Science and Economic Development Canada licence-exempt RSS standard(s). Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this device must accept any interference, including interference that may cause undesired operation of the device. Le présent appareil est conforme aux CNR d'ISED applicables aux appareils radio exempts de licence. L'exploitation est autorisée aux deux conditions suivantes: (1) l'appareil ne doit pas produire de brouillage, et (2) l'utilisateur de l'appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible d'en compromettre le fonctionnement.

Company: Hangzhou Great Star Industrial Co., Ltd. Add: No.35, Jiuhuan Road, Jianggan District, Hangzhou, 310019 China Tel: 0086-571-816013 Fax: 0086-571-816011 Email: [email protected] FCC Authorization Date: 2020-08-18 FEDERAL COMMUNICATIONS COMMISSION Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 Subject: Agent Authorization To whom it may concern: We, Hangzhou Great Star Industrial Co., Ltd., the undersigned, Hereby authorizes Bay Area Compliance Laboratories Corporation to act on its behalf in all matters relating to application for Equipment authorization, including the signing of all documents relating to these matters. All acts carried out by Bay Area Compliance Laboratories Corp. on our behalf shall have the same effect as our own action. We, the undersigned, hereby certify that we are not subject to a denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 862. This authorization is valid until further written notice from the applicant. Sincerely Yours, Signature: Typed or Printed Name: Jiamei Han Title: Manager QA-FR-170-B

Company: Hangzhou Great Star Industrial Co., Ltd. Add: No.35, Jiuhuan Road, Jianggan District, Hangzhou, 310019 China Tel: 0086-571-816013 Fax: 0086-571-816011 Email: [email protected] FCC Confidential Authorization Date: 2020-08-18 FEDERAL COMMUNICATIONS COMMISSIONS Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 Subject: Confidentiality Request regarding application for certification of FCC ID: 2AMI2-IM040304 To: whom it may concern, In accordance with Sections 0.457 and 0.459 of the Commission’s Rules, Hangzhou Great Star Industrial Co., Ltd. hereby requests long-term confidential treatment of information accompanying this application as outlined below: Block Diagram Schematics Operation Description The above materials contain proprietary and confidential information not customarily released to the public. The public disclosure of these materials provides unjustified benefits to its competitors in the market. Sincerely Yours, Signature: Typed or Printed Name: Jiamei Han Title: Manager

EXHIBIT A - EUT EXTERNAL PHOTOGRAPHS

EXHIBIT B - EUT INTERNAL PHOTOGRAPHS SRD antenna

FCC PART 15.231 TEST REPORT For Hangzhou Great Star Industrial Co., Ltd. No.35, Jiuhuan Road, Jianggan District, Hangzhou, 310019 China FCC ID: 2AMI2-IM040304 Report Type: Original Report Product Type: Remote control switch Test Engineer: Jack Jiao Report Number: RSHD200818005-00A Report Date: 2020-09-16 Reviewed By: Oscar Ye EMC Manager Prepared By: Bay Area Compliance Laboratories Corp. (Kunshan) No.248 Chenghu Road,Kunshan,Jiangsu province,China Tel: +86-0512-86175000 Fax: +86-0512-88934268 www.baclcorp.com.cn Bay Area Compliance Laboratories Corp. (Kunshan) Report No.: RSHD200818005-00A FCC Part 15.231 Page 2 of 21 TABLE OF CONTENTS GENERAL INFORMATION ....................................................................................................................................... 3 PRODUCT DESCRIPTION FOR EQUIPMENT UNDER TEST (EUT) ..................................................................................... 3 OBJECTIVE ................................................................................................................................................................... 3 RELATED SUBMITTAL(S)/GRANT(S) ............................................................................................................................. 3 TEST METHODOLOGY .................................................................................................................................................. 3 MEASUREMENT UNCERTAINTY .................................................................................................................................... 4 TEST FACILITY ............................................................................................................................................................. 4 SYSTEM TEST CONFIGURATION .......................................................................................................................... 5 JUSTIFICATION ............................................................................................................................................................. 5 EUT EXERCISE SOFTWARE .......................................................................................................................................... 5 EQUIPMENT MODIFICATIONS ....................................................................................................................................... 5 SUPPORT EQUIPMENT LIST AND DETAILS .................................................................................................................... 5 EXTERNAL I/O CABLE .................................................................................................................................................. 5 BLOCK DIAGRAM OF TEST SETUP ................................................................................................................................ 6 SUMMARY OF TEST RESULTS ............................................................................................................................... 7 TEST EQUIPMENT LIST ........................................................................................................................................... 8 FCC§15.203 - ANTENNA REQUIREMENT .............................................................................................................. 9 APPLICABLE STANDARD .............................................................................................................................................. 9 ANTENNA CONNECTED CONSTRUCTION ...................................................................................................................... 9 FCC §15.205, §15.209, §15.231 (B) - RADIATED EMISSIONS ............................................................................. 10 APPLICABLE STANDARD ............................................................................................................................................ 10 EUT SETUP ................................................................................................................................................................ 11 EMI TEST RECEIVER SETUP ....................................................................................................................................... 12 TEST PROCEDURE ...................................................................................................................................................... 12 CORRECTED AMPLITUDE & MARGIN CALCULATION ................................................................................................. 12 TEST RESULTS SUMMARY .......................................................................................................................................... 12 TEST DATA ................................................................................................................................................................ 12 FCC §15.231(A) (1) - DEACTIVATION TESTING ................................................................................................. 17 APPLICABLE STANDARD ............................................................................................................................................ 17 TEST PROCEDURE ...................................................................................................................................................... 17 TEST DATA ................................................................................................................................................................ 17 FCC §15.231(C) - 20DB EMISSION BANDWIDTH TESTING ............................................................................. 19 APPLICABLE STANDARD ............................................................................................................................................ 19 TEST PROCEDURE .......................................................................…

Text truncated - open the document above for the full version.

EXHIBIT C - TEST SETUP PHOTOGRAPHS Radiated Emissions (Below 1GHz) Radiated Emissions (Above 1GHz)
