Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.
L'application Haylou Fun(ci-après dénommée "App") est indispensable pour utiliser la montre. Vous pouvez gérer la montre et découvrir plus de fonctionnalités via l'App. 1. Maintenez le bouton d'alimentation de la montre enfoncé pour l'allumer. 2.Scannez le code QR sur l'écran de la montre avec votre téléphone pour télécharger l'App. 3.Vous pouvez également scanner le code QR ci-dessous, ou télécharger et installer l'App depuis votre magasin d'applications. Les utilisateurs d'iPhone peuvent aussi la rechercher, la télécharger et l'installer depuis l'App Store. 4.Ouvrez l'App, appuyez sur "+" en haut à droite, sélectionnez "Scanner" pour scanner le code QR et lier la connexion. Ou sélectionnez "Ajouter un appareil" et trouvez l'appareil à appairer dans la liste des appareils en fonction du nom de la montre pour effectuer la recherche et la liaison. Lors de l'appairage, confirmez que les noms Bluetooth du téléphone et de la montre correspondent. 5.Une fois l'appairage réussi, vous pouvez commencer à utiliser la montre. Please scan the QR code For more language versions: 한국어, Italiano, 日本語, Português, Русский 80 mm 90 mm HAYLOU S mart Watch User Manual Manual do Usuário Guide d'utilisation Guía Del Usuario Contents English Pt-BR Français Español 01 - 08 09 - 16 17 - 24 25 - 32 02 Charging 04 Wear Note: Wearing too loosely may affect data collection by the heart rate sensor. 03 Download and match 08 Safety information 09 Warranty card Model Number Date of Purchasing User ' s Name User ' s Phone User ' s Address Shop ' s Name Shop ' s Address Comments 07 Basic parameters Product name:Smart Watch Product model:HSS02 Main body size:47*42 * 11.5mm Watch weight (including strap) :48g Resolution:390*450 Battery capacity:370mAh Input parameter:5V 500mA Working temperature:-10°C~45°C Data sync platform:Haylou Fun Equipment requirements:Android 9.0 and above, iOS13.4 and above 01 Appearance and package list 06 More functions 05 Strap assembly and disassembly Use Help Align and fit the charging contacts on back of the watch to the metal contacts of the charging head, wait for the watch screen to display charging power indicator. Note:After assembling the strap, please pull the strap appropriately to ensure that the assembly is successful. You can wear it with no worry as the watch is made of healthy materials that have undergone strict allergy testing. Due to individual skin difference, if you feel skin discomfort when wearing, please stop wearing and consult a doctor. Haylou Fun If you need to assemble/disassemble the strap, please refer to the diagram. 1. For daily wear, wear the watch about one finger distance from the wrist bone, and adjust the tightness of the strap to a comfortable position. 2. We recommend to tighten the watch strap during exercise and loosen it appropriately after exercise. Precautions: 1. Please use the charging cable in the package, and dry the charging contacts before charging. 2. Connect the charging cable to a standard USB charger purchased through regular channels, and a power adapter that has obtained CCC certification and meets the standard requirements. 3. If the watch cannot power on after being left for a long time, when used again, it need to be pre-charged for about 1 minute to display charging icon. FCC Requirement Any Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: -Reorient or relocate the receiving antenna. -Increase the separation between the equipment and receiver. -Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. -Consult the dealer or an experienced radio/TV technician for help. This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter.The device has been evaluated to meet general RF exposure requirement. The device can be used in portable exposure condition without restriction. Before using and operating the device, please read and observe the following precautions to ensure the best performance of the device, and avoid dangerous or illegal situations. Precautions for usage scenarios and operating environment: 1. Strictly prohibit children or pets to swallow this product or its accessories to avoid harm to them. 2. Do not place this product in an area where the temperature is too high or too low, otherwise it may cause fire or explosion. 3. Strictly prohibit to bring this product close to heat sources or exposed fire sources, such as ovens and electric heaters. 4. Some people have allergies. Their skin are allergic to plastics, cortex, fiber and other materials, and symptoms such as redness, swelling and inflammation will occur in long-term contact areas. Please stop using and consult a doctor when similar situation occurs. 5. Do not use unauthorized or incompatible power adapters or data cables, otherwise it …
Text truncated - open the document above for the full version.
Dongguan Liesheng Electronic Co., Ltd. Covered Equipment Certification Attestation Letter 4/24/2026 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 USA ATTN.: Reviewing Engineer FCC ID: 2AMQ6-HSS02 Dongguan Liesheng Electronic Co., Ltd. (“the applicant”) certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. Note: If the equipment for which the applicant seeks authorization is produced by any of the entities identified on the current Covered List, the applicant should include an explanation on why the equipment is not “covered” equipment. Dongguan Liesheng Electronic Co., Ltd. (“the applicant”) certifies that, as of the date of the filing of the application, the applicant is not identified on the Covered List (as a specifically named entity or any of its subsidiaries or affiliates) as an entity producing “covered” equipment. Dongguan Liesheng Electronic Co., Ltd. (“the applicant”) certifies that the equipment for which authorization is sought does not include cybersecurity or anti-virus software produced or provided by Kaspersky Lab, Inc. or any of its successors and assignees, including equipment with integrated Kaspersky Lab, Inc. (or any of its successors and assignees) cybersecurity or anti-virus software pursuant to DA-24-886 and KDB 986446 D01 Covered Equipment Guidance section B(2a). Signed: Printed name: FAN XIONG Title: Staff Company Name: Dongguan Liesheng Electronic Co., Ltd. Date: 5/20/2026
The information provided in this letter is based on the referenced rule parts of Title 47 of the CFR as well as KDB 986446 D01. An expiration date for this letter does not exist. In case the U.S. agent changes, the grantee is obligated to notify the FCC within 30 days via the granting TCB. 48_[model] US_Agent_2.911(d)(7) - U, V05 Dongguan Liesheng Electronics Co., Ltd. Room 101, 801& 901, No. 1 Chilong RD, Humen Town, Dongguan City, Guangdong Province, China Federal Communications Commission Authorization and Evaluation Division Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 Date: Jun. 12, 26 U.S. Agent Designation Dongguan Liesheng Electronics Co., Ltd. acknowledges their consent for the following contact located in the United States to act as their agent for service of process for the equipment for which authorization is sought (FCC ID: 2AMQ6-HSS02) Name and company of U.S. agent: GLOCERTS TECHNOLOGY INC Physical U.S. address of agent: 19784 SUNKISSED RIDGE DR, RIVERSIDE, CA 92507 FRN of U.S. agent: 0036339737 Email address of U.S. agent: [email protected] Telephone of U.S.agent: (626) 588-8039 GLOCERTS TECHNOLOGY INC acknowledges their obligation to accept service of process on behalf of Dongguan Liesheng Electronics Co., Ltd.. Dongguan Liesheng Electronics Co., Ltd. with the FRN [0026655068] accepts its obligation to maintain an agent for service of process in the United States for no less than 1 year after either the grantee has permanently terminated all marketing and importation of the applicable equipment within the U.S., or the conclusion of any Commission-related administrative or judicial proceeding involving the equipment, whichever is later. By signing this form, we confirm the above and that we are aware of the application requirements listed under § 2.911(d)(7). The information provided in this letter is based on the referenced rule parts of Title 47 of the CFR as well as KDB 986446 D01. An expiration date for this letter does not exist. In case the U.S. agent changes, the grantee is obligated to notify the FCC within 30 days via the granting TCB. Sincerely, Signature Signature fan xiong Huiying Fan Staff Director Dongguan Liesheng Electronics Co., Ltd. GLOCERTS TECHNOLOGY INC
Dongguan Liesheng Electronic Co., Ltd. DATE: April 24, 2026 Federal Communications Commission Authorization & Evaluation Division 7345 Oakland Mills Road Columbia, Maryland 21046 Authority to Act as Agent On our behalf, I appoint Shenzhen Tongzhou Testing Co.,Ltd. (1st Floor, Building 1, Haomai High-tech Park, Huating Road 387, Dalang Street, Longhua, Shenzhen, China) to act as our agent in the preparation of this application for equipment certification. I certify that submitted documents properly describe the device or system for which equipment certification is sought. I also certify that each unit manufactured, imported or marketed, as defined in the Federal Communications Commission’s regulations will have affixed to it a label identical to that submitted for approval with this application. For instances where our authorized agent signs the application for certification on our behalf, I acknowledge that all responsibility for complying with the terms and conditions for certification, still resides with Dongguan Liesheng Electronic Co., Ltd. (Room 101, 801 & 901, No. 1 Chilong RD, Humen Town, Dongguan City, Guangdong Province, China) <Signature> Name: FAN XIONG Title: Staff Applicant Company: Dongguan Liesheng Electronic Co., Ltd.
Date: April 24, 2026 Federal Communications Commission Authorization & Evaluation Division 7345 Oakland Mills Road Columbia, Maryland 21046 RE: LETTER OF AGENT AUTHORIZATION To Whom It May Concern: We, the undersigned, hereby authorize Compliance Testing, LLC to act on our behalf in all matters relating to application for equipment authorization, including the signing of all documents relating to these matters. We also hereby certify that no party to the application authorized hereunder is subject to the denial of benefits, including FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C.853(a). Sincerely, <Signature> Name: FAN XIONG Title: Staff Company: Dongguan Liesheng Electronic Co., Ltd.
DATE: April 24, 2026 Equipment Autorisation Division Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 FCC ID: 2AMQ6-HSS02 Product Name: Smart Watch Request for Confidentiality Pursuant to Sections 0.457 and 0.459 of the commission’s rules, we hereby request that the following documents be held confidential: (List here the documents for which you are seeking confidentiality – for example ...) • Schematics • Block diagram • Operation description These materials contain trade secrets and proprietary information and are not customarily released to the public. The public disclosure of this information might be harmful to the company and provide unjustified benefits to our competitors. <Signature> Name: FAN XIONG Title: Staff Company: Dongguan Liesheng Electronic Co., Ltd.
Report No.: TZ0070260402PH02 Page 1 of 4 External Photographs of EUT External Photo 1 External Photo 2 Report No.: TZ0070260402PH02 Page 2 of 4 External Photo 3 External Photo 4 Report No.: TZ0070260402PH02 Page 3 of 4 External Photo 5 External Photo 6 Report No.: TZ0070260402PH02 Page 4 of 4 External Photo 7 External Photo 8
The size of the label is 15mm*10mm with White forecolor. The size of the logo is 5mm*5mm. FCC ID: 2AMQ6-HSS02
Report No.: TZ0070260402PH03 Page 1 of 4 Internal Photographs of EUT Internal Photo 1 Internal Photo 2 Report No.: TZ0070260402PH03 Page 2 of 4 Internal Photo 3 Internal Photo 4 Report No.: TZ0070260402PH03 Page 3 of 4 Internal Photo 5 Internal Photo 6 Report No.: TZ0070260402PH03 Page 4 of 4 Internal Photo 7 Bluetooth antenna
FCC ID: 2AMQ6-HSS02 Page 1 of 2 This report shall not be reproduced except in full, without the written approval of Shenzhen Tongzhou Testing Co.,Ltd RADIO FREQUENCY EXPOSURE Limit According to section B.4 of 447498 D04 Interim General RF Exposure Guidance v01 SAR-based thresholds are derived based on frequency, power, and separation distance of the RF source. The formula defines the thresholds in general for either available maximum time-averaged power or maximum time-averaged ERP, whichever is greater. If the ERP of a device is not easily determined, such as for a portable device with a small form factor, the applicant may use the available maximum time-averaged power exclusively if the device antenna or radiating structure does not exceed an electrical length of λ/4. As for devices with antennas of length greater than λ/4 where the gain is not well defined, but always less than that of a half-wave dipole (length λ/2), the available maximum time-averaged power generated by the device may be used in place of the maximum time-averaged ERP, where that value is not known. The separation distance is the smallest distance from any part of the antenna or radiating structure for all persons, during operation at the applicable ERP. In the case of mobile or portable devices, the separation distance is from the outer housing of the device where it is closest to the antenna. The SAR-based exemption formula of § 1.1307(b)(3)(i)(B), repeated here as Formula (B.2), applies for single fixed, mobile, and portable RF sources with available maximum time-averaged power or effective radiated power (ERP), whichever is greater, of less than or equal to the threshold Pth (mW). This method shall only be used at separation distances from 0.5 cm to 40 cm and at frequencies from 0.3 GHz to 6 GHz (inclusive). Pth is given by Formula (B.2). Where and f is in GHz, d is the separation distance (cm), and ERP 20cm is per Formula (B.1). FCC ID: 2AMQ6-HSS02 Page 2 of 2 This report shall not be reproduced except in full, without the written approval of Shenzhen Tongzhou Testing Co.,Ltd Results BT SS 0.5 Mode Antenna Frequency [MHz] Conducted Power [dBm] Manufacturing tolerance Antenna Gain [dBi] Max of ERP and Conducted Power including Tune Up SAR- based exemption threshold Pth [mW] Target Power [dBm] Tolerance ±[dB] [dBm] [mW] DH5 Ant1 2402 -1.05 -1.5 1 -2 -0.5 0.89 2.79 DH5 Ant1 2441 -0.33 -1 1 -2 0 1.00 2.75 DH5 Ant1 2480 -0.62 -1 1 -2 0 1.00 2.72 2DH5 Ant1 2402 -1.84 -2.5 1 -2 -1.5 0.71 2.79 2DH5 Ant1 2441 -0.94 -1.5 1 -2 -0.5 0.89 2.75 2DH5 Ant1 2480 -1.25 -1.5 1 -2 -0.5 0.89 2.72 3DH5 Ant1 2402 -1.39 -2 1 -2 -1 0.79 2.79 3DH5 Ant1 2441 -0.61 -1 1 -2 0 1.00 2.75 3DH5 Ant1 2480 -1.09 -1.5 1 -2 -0.5 0.89 2.72 BLE SS 0.5 Mode Antenna Frequency [MHz] Conducted Power [dBm] Manufacturing tolerance Antenna Gain [dBi] Max of ERP and Conducted Power including Tune Up SAR- based exemption threshold Pth [mW] Target Power [dBm] Tolerance ±[dB] [dBm] [mW] BLE_1M Ant1 2402 -1.02 -1.5 1 -2 -0.5 0.89 2.79 BLE_1M Ant1 2440 -0.36 -1 1 -2 0 1.00 2.75 BLE_1M Ant1 2480 -0.76 -1.5 1 -2 -0.5 0.89 2.72 BLE_2M Ant1 2402 -1.28 -2 1 -2 -1 0.79 2.79 BLE_2M Ant1 2440 -0.59 -1 1 -2 0 1.00 2.75 BLE_2M Ant1 2480 -0.87 -1.5 1 -2 -0.5 0.89 2.72 Max of ERP and Conducted Power including Tune Up (dBm) = Max Conducted Tune Up Power(dBm) and Max Conducted Tune Up Power(dBm) + Antenna Gain(dBi)-2.15), whichever is greater. The Maximum Erp is used for Routine Evaluation Exemption according to B.4 of 447498 D04 Interim General RF Exposure Guidance v01. So, the SAR evaluation is not required.
Report No.: TZ0070260402FRF01 Page 1 of 35 This publication may be reproduced in whole or in part for non-commercial purposes as long as the Shenzhen Tongzhou Testing Co.,Ltd. is acknowledged as copyright owner and source of the material. Shenzhen Tongzhou Testing Co.,Ltd. takes no responsibility for and will not assume liability for damages resulting from the reader's interpretation of the reproduced material due to its placement and context. The test report apply only to the specific sample(s) tested under stated test conditions. It is not permitted to copy extracts of these test result without the written permission of the test laboratory. TEST REPORT Report Number : TZ0070260402FRF01 Product Name : Smart Watch Model/Type reference : HSS02 FCC ID : 2AMQ6-HSS02 Prepared for : Dongguan Liesheng Electronics Co., Ltd. Room 101, 801& 901, No. 1 Chilong RD, Humen Town, Dongguan City, Guangdong Province, China Prepared By : Shenzhen Tongzhou Testing Co.,Ltd. 1st Floor, Building 1, Haomai High-tech Park, Huating Road 387, Dalang Street, Longhua, Shenzhen, China Standards : FCC CFR Title 47 Part 15C, ANSI C63.10-2020 + Cor.1-2023 Date of Test : 2026-04-23 ~ 2026-04-26 Date of Issue : 2026-04-27 Prepared by : Lena Wen Reviewed by : Allen Lai Approved by : Max Zhang (Authorized Officer) Report No.: TZ0070260402FRF01 Page 2 of 35 ** Report Revise Record ** Report Version Revise Time Issued Date Valid Version Notes V1.0 / 2026-04-27 Valid Initial release Report No.: TZ0070260402FRF01 Page 3 of 35 TABLE OF CONTENTS 1. G E N E R A L I N F O R M A T I O N ........................................................ 4 1.1. Client Information ................................................................................................................... 4 1.2. Description of Device (EUT) ................................................................................................... 4 1.3. Wireless Function Tested in this Report .............................................................................. 4 1.4. EUT configuration ................................................................................................................... 5 1.5. Description of Test Facility .................................................................................................... 5 1.6. Statement of the Measurement Uncertainty ......................................................................... 5 1.7. Measurement Uncertainty ...................................................................................................... 6 1.8. Description of Test Modes ..................................................................................................... 6 1.9. Frequency of Channels .......................................................................................................... 7 2. T E S T M E T H O D O L O G Y ............................................................ 8 2.1. EUT Configuration .................................................................................................................. 8 2.2. EUT Exercise ........................................................................................................................... 8 2.3. Test Sample ............................................................................................................................. 8 3. S Y S T E M T E S T C O N F I G U R A T I O N .............................................. 9 3.1. Justification ............................................................................................................................. 9 3.2. EUT Exercise Software ........................................................................................................... 9 3.3. Special Accessories ............................................................................................................... 9 3.4. Block Diagram/Schematics .................................................................................................... 9 3.5. Equipment Modifications ....................................................................................................... 9 3.6. Test Setup ................................................................................................................................ 9 4. S U M M A R Y O F T E S T R E S U L T S ................................................ 10 5. M E A S U R E M E N T R E S U L T S ...................................................... 11 5.1. Maximum Peak Conducted Output Power ......................................................................... 11 5.2. Frequency Separation and 20 dB Bandwidth .................................................................... 12 5.3. Number of Hopping Frequency ........................................................................................... 13 5.4. Time of Occupancy (Dwell Time) ......................................................................................... 14 5.5. Conducted Spurious Emissions and Band Edges Test .................................................... 16 5.6. Restricted Band Emission Limit .......................................................................................... 17 5.7. AC Power line conducted emissions .................................................................................. 26 5.8. Band-edge measurements for radiated emissions ........................................................... 29 5.9. Pseudorandom frequency hopping sequence ................................................................... 32 5.10. Antenna requirement ............................................................................................................ 33 6. S U M M A R Y O F T E S T E Q U I P M E N T ............................................ 34 7. T E S T S E T U P P H O T O G R A P H S ................................................. 35 8. E X T E R N A L P H O T O S O F T H E E U T ............................................ 35…
Text truncated - open the document above for the full version.
ANWEI commnuication Equipment Co.,Ltd APPROVAL SHEET Customer Le Dai Specs HSS02 Part Number Frequency Band BT Color metal frame Edition REV:A Salesperson Mr.Lin Design HU HUANG Structure QIN YUN LIN Confirm Date 2026/3/18 Signing Date Customer confirmation: Join hands to create the future 2.4G BT Active data measured distance front 10M back side 3M Project development environment Antenna gain Frequency ID 1 2 3 4 5 Frequency(MHz) 1176 1572 2400 2450 2480 Gain(dBi) -8.15 -4.45 -2.46 -2.50 -2.00 Environmental treatment GWB antenna apple diagram Size drawing The End
Appendix Test Data of the Report No.: TZ0070260402FRF01 Page 1 of 56 Appendix Test Data for BT(BDR/EDR) (Conducted Measurement) Product Name: Smart Watch Trade Mark: Haylou Test Model: HSS02 FCC ID: 2AMQ6-HSS02 Environmental Conditions Temperature: 23.5°C Relative Humidity: 58% ATM Pressure: 100.0 kPa Test Engineer: Allen Lai Supervised by: Max Zhang NOTE N/A Appendix A: 20dB Emission Bandwidth Test Result Test Mode Antenna Frequency [MHz] 20db EBW [MHz] FL [MHz] FH [MHz] Limit [MHz] Verdict DH5 Ant1 2402 0.963 2401.535 2402.498 --- --- DH5 Ant1 2441 0.954 2440.541 2441.495 --- --- DH5 Ant1 2480 0.951 2479.541 2480.492 --- --- 2DH5 Ant1 2402 1.347 2401.331 2402.678 --- --- 2DH5 Ant1 2441 1.275 2440.385 2441.660 --- --- 2DH5 Ant1 2480 1.263 2479.376 2480.639 --- --- 3DH5 Ant1 2402 1.293 2401.355 2402.648 --- --- 3DH5 Ant1 2441 1.203 2440.412 2441.615 --- --- 3DH5 Ant1 2480 1.275 2479.361 2480.636 --- --- Note: offset(dB) = cable loss(dB) + attenuator factor(dB) Appendix Test Data of the Report No.: TZ0070260402FRF01 Page 2 of 56 Test Graphs DH5-Ant1-2402 DH5-Ant1-2441 Appendix Test Data of the Report No.: TZ0070260402FRF01 Page 3 of 56 DH5-Ant1-2480 2DH5-Ant1-2402 Appendix Test Data of the Report No.: TZ0070260402FRF01 Page 4 of 56 2DH5-Ant1-2441 2DH5-Ant1-2480 Appendix Test Data of the Report No.: TZ0070260402FRF01 Page 5 of 56 3DH5-Ant1-2402 3DH5-Ant1-2441 Appendix Test Data of the Report No.: TZ0070260402FRF01 Page 6 of 56 3DH5-Ant1-2480 Appendix Test Data of the Report No.: TZ0070260402FRF01 Page 7 of 56 Appendix B: Occupied Channel Bandwidth Test Result Test Mode Antenna Frequency [MHz] OCB [MHz] FL [MHz] FH [MHz] Limit [MHz] Verdict DH5 Ant1 2402 0.84618 2401.5810 2402.4272 --- --- DH5 Ant1 2441 0.85564 2440.5738 2441.4294 --- --- DH5 Ant1 2480 0.82830 2479.5880 2480.4163 --- --- 2DH5 Ant1 2402 1.1756 2401.4152 2402.5908 --- --- 2DH5 Ant1 2441 1.1696 2440.4166 2441.5862 --- --- 2DH5 Ant1 2480 1.1514 2479.4281 2480.5795 --- --- 3DH5 Ant1 2402 1.1751 2401.4215 2402.5966 --- --- 3DH5 Ant1 2441 1.1539 2440.4287 2441.5826 --- --- 3DH5 Ant1 2480 1.1366 2479.4399 2480.5765 --- --- Note: offset(dB) = cable loss(dB) + attenuator factor(dB) Appendix Test Data of the Report No.: TZ0070260402FRF01 Page 8 of 56 Test Graphs DH5-Ant1-2402 DH5-Ant1-2441 Appendix Test Data of the Report No.: TZ0070260402FRF01 Page 9 of 56 DH5-Ant1-2480 2DH5-Ant1-2402 Appendix Test Data of the Report No.: TZ0070260402FRF01 Page 10 of 56 2DH5-Ant1-2441 2DH5-Ant1-2480 Appendix Test Data of the Report No.: TZ0070260402FRF01 Page 11 of 56 3DH5-Ant1-2402 3DH5-Ant1-2441 Appendix Test Data of the Report No.: TZ0070260402FRF01 Page 12 of 56 3DH5-Ant1-2480 Appendix Test Data of the Report No.: TZ0070260402FRF01 Page 13 of 56 Appendix C: Maximum peak conducted output power Test Result Test Mode Antenna Frequency [MHz] Conducted Peak Power [dBm] Conducted Limit [dBm] Verdict DH5 Ant1 2402 -1.05 ≤30 PASS DH5 Ant1 2441 -0.33 ≤30 PASS DH5 Ant1 2480 -0.62 ≤30 PASS 2DH5 Ant1 2402 -1.84 ≤20.97 PASS 2DH5 Ant1 2441 -0.94 ≤20.97 PASS 2DH5 Ant1 2480 -1.25 ≤20.97 PASS 3DH5 Ant1 2402 -1.39 ≤20.97 PASS 3DH5 Ant1 2441 -0.61 ≤20.97 PASS 3DH5 Ant1 2480 -1.09 ≤20.97 PASS Note: offset(dB) = cable loss(dB) + attenuator factor(dB) Appendix Test Data of the Report No.: TZ0070260402FRF01 Page 14 of 56 Test Graphs DH5-Ant1-2402-PASS DH5-Ant1-2441-PASS Appendix Test Data of the Report No.: TZ0070260402FRF01 Page 15 of 56 DH5-Ant1-2480-PASS 2DH5-Ant1-2402-PASS Appendix Test Data of the Report No.: TZ0070260402FRF01 Page 16 of 56 2DH5-Ant1-2441-PASS 2DH5-Ant1-2480-PASS Appendix Test Data of the Report No.: TZ0070260402FRF01 Page 17 of 56 3DH5-Ant1-2402-PASS 3DH5-Ant1-2441-PASS Appendix Test Data of the Report No.: TZ0070260402FRF01 Page 18 of 56 3DH5-Ant1-2480-PASS Appendix Test Data of the Report No.: TZ0070260402FRF01 Page 19 of 56 Appendix D: Carrier frequency separation Test Result Test Mode Antenna Frequency [MHz] Result [MHz] Limit [MHz] Verdict DH5 Ant1 Hop 0.996 ≥0.963 PASS 2DH5 Ant1 Hop 1.042 ≥0.898 PASS 3DH5 Ant1 Hop 1 ≥0.862 PASS Note: offset(dB) = cable loss(dB) + attenuator factor(dB) Appendix Test Data of the Report No.: TZ0070260402FRF01 Page 20 of 56 Test Graphs DH5-Ant1-Hop-PASS 2DH5-Ant1-Hop-PASS Appendix Test Data of the Report No.: TZ0070260402FRF01 Page 21 of 56 3DH5-Ant1-Hop-PASS Appendix Test Data of the Report No.: TZ0070260402FRF01 Page 22 of 56 Appendix E: Time of occupancy Test Result Test Mode Antenna Frequency [MHz] Burst Width [ms] TotalHops [Num] Result [s] Limit [s] Verdict DH5 Ant1 Hop 2.868 110 0.315 ≤0.4 PASS 2DH5 Ant1 Hop 2.879 110 0.317 ≤0.4 PASS 3DH5 Ant1 Hop 2.880 110 0.317 ≤0.4 PASS Note: offset(dB) = cable loss(dB) + attenuator factor(dB) Appendix Test Data of the Report No.: TZ0070260402FRF01 Page 23 of 56 Test Graphs DH5-Ant1-Hop-PASS Appendix Test Data of the Report No.: TZ0070260402FRF01 Page 24 of 56 2DH5-Ant1-Hop-PASS Appendix Test Data of the Report No.: TZ0070260402FRF01 Page 25 of 56 3DH5-Ant1-Hop-PASS Appendix Test Data of the Report No.: TZ0070260402FRF01 Page 26 of 56 Appendix F: Number of hopping channels Test Result Test Mode Antenna Frequency [MHz] Result [Num] Limit [Num] Verdict DH5 Ant1 Hop 79 ≥15 PASS 2DH5 Ant1 Hop 79 ≥15 PASS 3DH5 Ant1 Hop 79 ≥15 PASS Note: offset(dB) = cable loss(dB) + attenuator factor(dB) Appendix Test Data of the Report No.: TZ0070260402FRF01 Page 27 of 56 Test Graphs DH5-Ant1-Hop-PASS 2DH5-Ant1-Hop-PASS Appendix Test Data of the Report No.: TZ0070260402FRF01 Page 28 of 56 3DH5-Ant1-Hop-PASS Appendix Test Data of the Report No.: TZ0070260402FRF01 Page 29 of 56 Appendix G: Band edge measurements Test Result Test Mode Antenna Ch.Name Frequency [MHz] RefLevel [dBm] Result [dBm] Limit [dBm] Verdict DH5 Ant1 Low 2402 -1.59 -48.15 ≤-21.59 PASS DH5 Ant1 High 2480 -1.25 -48.02 ≤-21.25 PASS DH5 Ant1 Low Hop_2402 -2.58 -57.11 ≤-22.58 PASS DH5 Ant1 High Hop_2480 -0.66 -56.18 ≤-20.66 PASS 2DH5 Ant1 Low 2402 -2.99 -48 ≤-22.99 PASS 2DH5 Ant1 High 2480 -2.50 -56.44 ≤-22.5 PASS 2DH5 Ant1 …
Text truncated - open the document above for the full version.
Report No.: TZ0070260402PH01 Page 1 of 2 Test Setup Photos of the EUT Conducted Emission Radiated Emission Below 1GHz Report No.: TZ0070260402PH01 Page 2 of 2 Radiated Emission Above 1GHz RF Conducted Test
19784 SUNKISSED RIDGE DR · RIVERSIDE, California, 92507 · United States
| # | Rule Parts | Frequency Range | Power Output |
|---|---|---|---|
| 1 | 15C | 2.40 GHz - 2.48 GHz | 900.00 µW |

Wireless Headphones
Equipment Class
DSS - Part 15 Spread Spectrum Transmitter
True Wireless Noise Cancellation Earphones
Equipment Class
DSS - Part 15 Spread Spectrum TransmitterTrue Wireless Noise Cancellation Earphones
Equipment Class
DTS - Digital Transmission System
True Wireless Noise Cancellation Earphones
Equipment Class
DSS - Part 15 Spread Spectrum Transmitter
Power output listed is conducted.
Equipment Class
DTS - Digital Transmission System
