2AMSOSTW003Portable Alarm Clock Wireless Speaker

COBY CCR101 U s e r M a n u a l I M a n u a l d e u s u a r i o 蓝眠 B T B o A M P M C O B Y 0 Bluetooth· (§) 10 01 oe Portabl Alarm Clock Wireless Speaker e Safety Statement Safety Precautions 1. Avoid dropping. 2. Do not disassemble this device. 3. Do not expose this device to rain or moistu『eo『subme『ge in water. 4. Ideal tempe『atu『esa『eo•c to 35'C. Avoid ext『eme tempe『atu『es. 5. Keep the device away from excessive heat, such as sunshine, fi『e orthe like. 6. Do not use the device outdoo『sduring thunde『sto『ms. 7. Use o『iginalo『certifiedcables. 8. Do not use any co的sive cleaner/oil to clean. 9. Keep out of『each of child『en. It contains small parts which may be a choking haza『d. 10. Observe local laws and regulations while using the device. 11.To p『eventdamage to you『device'sparts o『internalci『cuits,do not use it in dusty, smoky, damp or dirty environments. 12. Do not use, store o『transportthe device where flammables or explosives a『e stored. Using you『devicein these environments increases the risk of explosion o『fire. 13. Remove battery from the device if you a『e not going to use it for a long time. FCC Statement FCC ID :2AMSOSTW003 This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation Warning: Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to P art 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not in­stalled and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful i nterfer­ence to radio or television reception, which can be determined by turning the equipment EN 6 off and on, the user is encouraged to try to correct the interference by one or more of the f ollowing measures: (1) Reorient or relocate the receiving antenna. (2) Increase the s eparation between the equipment and receiver. (3) Connect the equipment into an o utlet on a circuit different from that to which the receiver is connected. (4) Consult the dealer or an experienced radio/ TV technician for help . RF Exposure Statement: T his d evice complies w ith FCC radiation exposure limits set forth an uncontrolled environment and meets the FCC radio frequency RF exposure Guidelines . Disclaimer All information, design and specifications contained in this manual were correct at the time of this publication. As the product goes under continuous upgrades and chang­ es, however, the final device may have slight differences. The contents of this manual are subject to change without prior notice, and Coby will not be liable for any errors contained herein or for incidental or consequential damages in connection with the furnishing performance or use of this manual. COBY" IS A REGISTERED TRADEMARK OF HEARST COMMUNICATION, INC. AND USED UNDER LICENSE BY SUMMIT ELECTRONICS, LLC. © 2022 HEARST COMMUNICATION, INC. ALL RIGHTS RESERVED AND ANY USE OF SUCH MARKS BY SUMMIT ELECTRONICS LLC IS UNDER LICENSE. OTHER TRADEMARKS AND TRADE NAMES ARE THOSE OF THEIR RESPECTIVE OWNERS. 心WARNING:CANCER AND REPRODUCTIVE HARM - WWW. P65WARNINGS. CA.GOV. 0 Bluetooth ® The Bluetooth® word mark and logos are registered trademarks owned by the Bluetooth SIG, Inc. and any use of such marks by Fesco Distributors, Inc. is under license. Other trademarks and trade names are those of their respective owners. EN 7 e Declaracion de seguridad Precauciones de seguridad 1. Evite las caidas 2. No desmonte este dispositivo 3. No exponga este dispositivo a la lluvia o la humedad ni lo sumerja en agua 4. Las temperaturas ideales son de O °C a 35 ° C. Evite las temperaturas extremas 5. Mantenga el dispositivo alejado del calor excesivo, como la luz solar, el fuego o similares. 6. No utilice el dispositivo al aire libre durante tormentas electricas 7. Utilice cables originales o certificados. 8. No utilice ningun limpiador / aceite corrosivo para limpiar. 9. Mantengase fuera del alcance de los nifios. Contiene piezas pequenas que pueden representar un peligro de asfixia. 10. Respete las leyes y normativas locales al utilizar el dispositivo. 11.Para evitar da竹osa las partes o circuitos internos de su dispositivo, no lo use en ambientes polvorientos, con humo, humedos o sucios. 12. No utilice, almacene ni transporte el dispositivo donde se almacenen inflamables o explosivos. El uso de su dispositivo en estos entornos aumenta el riesgo de explosi6n o incendio. 1 3. Retire la bateria del dispositivo si no lo va a utilizar durante un tiempo prolongado. Declaraci6n de la FCC FCC ID :2AMSOSTW003 E ste dispositivo cumple con la Parle 15 de las Reglas de la FCC. El funcionamiento esta sujeto a las dos condiciones siguientes: ( 1 ) e s t e d i s � o � i t i v _ o n o _ p u e d � c a u � a _ r i n t e r ( e '. � n c i � s � a _n i n _ a s , y (2) este dis � ositivo debe aceptar cualquier _ interferencia recibida, , incluidas las interferencias que puedan causar un funcionamiento no deseado. Advertencia: Los cambios o modificaciones no aprobados expresamente por la parte responsable del cumplimiento podrian anular la autoridad del usuario para operar el equipo. Nola: E ste equipo ha sido probado y cumple con los limites para un dispositivo digital de Clase B, de acuerdo con la Parle 15 de las Reglas de la FCC. Estos limites estan disenados para proporcionar una protecci6n razonable contra interferencias perjudiciales en una …

Text truncated - open the document above for the full version.

External photos FCC ID: 2AMSOSTW003 FCC ID: 2AMSOSTW003 FCC ID: 2AMSOSTW003 FCC ID: 2AMSOSTW003

PORTABLE ALARM CLOCK WIRELESS SPEAKER Model: CCR101 90730 POWER: DC 5V/500mA Battery: 1500mAh Made in China FCC ID: 2AMSOSTW003 FCC ID: 2AMSOSTW003 Label & location

FCC ID: 2AMSOSTW003 Internal photos FCC ID: 2AMSOSTW003 FCC ID: 2AMSOSTW003 FCC ID: 2AMSOSTW003 RF Chip RF Chip

Summit Electronics LLC Declaration concerning Antenna Specification It is hereby declared that the product Model No.: CCR101, FCC ID: 2AMSOSTW003 fulfills the requirement in FCC test relating to the antenna type. The device specified above confirms to the FCC recommendations for PCB antenna type(s) described below: Model No. of antenna: 2.4G ANT Type of antenna: PCB Antenna Size of antenna: See below diagram Frequency of range: 2402-2480MHz Antenna Photo: The mounting of the antenna is fixed to the radio module and no other antenna should be used. Sincerely, Signature Print name: Moshe Dancikier Title: Sourcing Summit Electronics LLC

Inverted F Antenna Specification Summary ITEM ANT SPEC Model Name 2.4G ANT Horizontal Vertical 2400MHz 2400MHz2500MHz2400MHz2400MHz 2500MHz Center Frequency -1.26 -0.76 -0.58 -5.25 -2.46 -1.86 MAX. Gain -0.58dB Polarization Horizontal and Vertical Azimuth Beam Pattern Omni-directional Impedance 50 Ohm Antenna Length 38.20mm Manufacture ZHUHAI JIELI TECHNOLOGY CO.,LTD Antenna Photo & Length (mm) Horizontal: 2400 MHz 2450 MHz 2500 MHz Power (dBm) Max: 0 Min: -40 Scale: 5/div Gain(dB) Frequency (MHz) Max Min Avg 2400 -1.26174 -30.0801 -7.18716 2450 -0.765802 -36.5604 -7.48023 2500 -0.585582 -22.0315 -6.59127 Vertical: 2400 MHz 2450 MHz 2500 MHz Power (dBm) Max: 0 Min: -30 Scale: 5/div Gain(dB) Frequency (MHz) Max Min Avg 2400 -5.2537 -22.1424 -12.4294 2450 -2.4652 -24.5837 -10.4702 2500 -1.86120 -29.5214 -9.20432 ANT Test Labs：Attestation of Global Compliance Co., Ltd.

Report No.: NTC2211009F01 Page 2 of 11 Table of Contents 1. General Description of EUT ................................................................................................................................ 4 2. Test Facility and Location ................................................................................................................................... 6 3. Applicable Standards and References ................................................................................................................ 7 4. Maximum Permissible Exposure Limit ................................................................................................................ 8 5. RF Exposure Evaluation Results ...................................................................................................................... 11 Report No.: NTC2211009F01 Page 3 of 11 Revision History Report Number Description Issued Date NTC2211009F01 Initial Issue 2022-11-10 Report No.: NTC2211009F01 Page 4 of 11 1. General Description of EUT Product Information Product name: Portable Alarm Clock Wireless Speaker Main Model Name: CCR101 Additional Model Name: CCR500, CCR501, CCR502, CCR503, CCR504, CCR505, CCR506, CCR507, CCR508 Model Difference: These models have the same circuitry, electrical mechanical, PCB Layout and physical construction. The differences are model number and the shell color due to marketing purpose. S/N: 2211-5743 Brand Name: COBY Hardware version: DY-Q38-CLK-V2.1 Software version: DY-Q38S-CLK-V3.0 Rating: DC 5V /500mA from Micro USB port or DC 3.7V from one 18650 Lithium-ion battery Typical Arrangement: Tabletop / Portable I/O Port: Refer to the User’s Manual Accessories Information Adapter: N/A Cable: USB line: 0.5m unshielded, detachable Other: N/A Additional information Note: According to the model differences, all the tests performed on model CCR101. Remark: All the information above are provided by the manufacturer. More detailed feature of the EUT please refers to the user manual. Report No.: NTC2211009F01 Page 5 of 11 Technical Specification Bluetooth Version: V5.0 Frequency Range: 2402-2480MHz Modulation Type: GFSK, Π4/-DQPSK Number of Channel: 79 (refer to following channel list for details) Channel Space: 1MHz Antenna Type: PCB Antenna Antenna Gain: -0.58 dBi (Declared by the manufacturer) Note: The EUT does not support 8DPSK and Bluetooth Low Energy feature in accordance with the declaration of the manufacturer. Report No.: NTC2211009F01 Page 6 of 11 2. Test Facility and Location Test Site : Dongguan Nore Testing Center Co., Ltd. (Dongguan NTC Co., Ltd.) Accreditations and Authorizations : The Laboratory has been assessed and proved to be in compliance with CNAS/CL01 Listed by CNAS, August 13, 2018 The Certificate Registration Number is L5795. The Certificate is valid until August 13, 2024 The Laboratory has been assessed and proved to be in compliance with ISO17025 Listed by A2LA, November 01, 2017 The Certificate Registration Number is 4429.01 Listed by FCC, November 06, 2017 Test Firm Registration Number: 907417 Listed by Industry Canada, June 08, 2017 The Certificate Registration Number. Is 46405-9743A Test Site Location : Building D, Gaosheng Science and Technology Park, Hongtu Road, Nancheng District, Dongguan City, Guangdong Province, China Report No.: NTC2211009F01 Page 7 of 11 3. Applicable Standards and References According to the specifications of the manufacturer, the EUT must comply with the requirements of the following standards: Test Standards: 47 CFR Part 1, 1.1307 47 CFR Part 2, 2.1091 & 2.1093 KDB 447498 D04 v01 Report No.: NTC2211009F01 Page 8 of 11 4. Maximum Permissible Exposure Limit According to 47 CFR Part 1, 1.1307, for single RF sources (i.e., any single fixed RF source, mobile device, or portable device, as defined in paragraph (b)(2) of this section): A single RF source is exempt if: 47 CFR Part 1, 1.1307 (A) The available maximum time- averaged power is no more than 1 mW, regardless of separation distance. This exemption may not be used in conjunction with other exemption criteria other than those in paragraph (b)(3)(ii)(A) of this section. Medical implant devices may only use this exemption and that in paragraph (b)(3)(ii)(A); (B) Or the available maximum time- averaged power or effective radiated power (ERP), whichever is greater, is less than or equal to the threshold P th (mW) described in the following formula. This method shall only be used at separation distances (cm) from 0.5 centimeters to 40 centimeters and at frequencies from 0.3 GHz to 6 GHz (inclusive). P th is given by: Where, And, d = the minimum separation distance (cm) in any direction from any part of the device antenna(s) or radiating structure(s) to the body of the device user. For multiple RF sources: Multiple RF sources are exempt if: Report No.: NTC2211009F01 Page 9 of 11 (A) The available maximum time- averaged power of each source is no more than 1 mW and there is a separation distance of two centimeters be-tween any portion of a radiating structure operating and the nearest portion of any other radiating structure in the same device, except if the sum of multiple sources is less than 1 mW during the time-averaging period, in which case they may be treated as a single source (separation is not required). This exemption may not be used in conjunction with other exemption criteria other than those is paragraph (b)(3)(i)(A) of this section. Medical implant devices may only use this exemption and that in paragraph (b)(3)(i)(A). (B) in the case of fixed RF sources operating in the same time-averaging period, or of multiple mobile or portable RF sources within a device operating in the same time averaging period, if the sum of the fractional contributions to the applicable thresholds is less than or equal to 1 as indicated in the following equation. Where, a = number of fixed, mobile, or portable RF sources claiming exemption using para-graph (b)(3)(i)(B) of this sect…

Text truncated - open the document above for the full version.

Report No.: NTC2211009FV00 Page 2 of 44 Table of Contents 1. Summary of Test Result ...................................................................................................................................... 4 2. General Description of EUT ................................................................................................................................ 5 3. Test Channels and Modes Detail ........................................................................................................................ 8 4. Configuration of EUT ........................................................................................................................................... 8 5. Modification of EUT ............................................................................................................................................. 8 6. Description of Support Device ............................................................................................................................. 9 7. Test Facility and Location ................................................................................................................................. 10 8. Applicable Standards and References .............................................................................................................. 11 9. Deviations and Abnormalities from Standard Conditions ................................................................................. 11 10. Test Conditions ............................................................................................................................................... 12 11. Measurement Uncertainty ............................................................................................................................... 13 12. Sample Calculations........................................................................................................................................ 14 13. Test Items and Results ................................................................................................................................... 15 13.1 Conducted Emissions Measurement ............................................................................................................ 15 13.2 Radiated Spurious Emissions and Restricted Bands Measurement ............................................................ 19 13.3 Channel Separation test ................................................................................................................................ 26 13.4 20dB Bandwidth ............................................................................................................................................ 29 13.5 Hopping Channel Number ............................................................................................................................. 31 13.6 Time of Occupancy (Dwell Time) .................................................................................................................. 33 13.7 Maximum Peak Output Power ...................................................................................................................... 36 13.8 Band Edge Conducted Spurious Emission Measurement ............................................................................ 39 13.9 Antenna Requirement ................................................................................................................................... 40 14. Test Equipment List ......................................................................................................................................... 44 Report No.: NTC2211009FV00 Page 3 of 44 Revision History Report Number Description Issued Date NTC2211009FV00 Initial Issue 2022-11-10 Report No.: NTC2211009FV00 Page 4 of 44 1. Summary of Test Result FCC Rules Description of Test Result Remarks §15.247(a)(1) Channel Separation test PASS --- §15.247(a)(1) 20dB Bandwidth PASS --- §15.247(a)(1)(iii) Hopping Channel Number PASS --- §15.247(a)(1)(iii) Time of Occupancy (Dwell Time) PASS --- §15.247(b) Max Peak output Power test PASS --- §15.247(d) Band edge test PASS --- §15.207 (a) AC Power Conducted Emission PASS --- §15.247(d),§15.209, §15.205 Radiated Emission PASS --- §15.203 Antenna Requirement PASS --- §15.247(d) Conducted Spurious Emission PASS --- Report No.: NTC2211009FV00 Page 5 of 44 2. General Description of EUT Product Information Product Name: Portable Alarm Clock Wireless Speaker Main Model Name: CCR101 Additional Model Name: CCR500, CCR501, CCR502, CCR503, CCR504, CCR505, CCR506, CCR507, CCR508 Model Difference: These models have the same circuitry, electrical mechanical, PCB Layout and physical construction. The differences are model number and the shell color due to marketing purpose. S/N: 2211-5743 Brand Name COBY Hardware Version: DY-Q38-CLK-V2.1 Software Version: DY-Q38S-CLK-V3.0 Rating: DC 5V /500mA from Micro USB port or DC 3.7V from one 18650 Lithium-ion battery Classification: Class B Typical Arrangement: Tabletop / Portable I/O Port: Refer to the user manual Accessories Information Adapter: N/A Cable: USB line: 0.5m unshielded, detachable Other: N/A Additional Information Note: According to the model differences, all the tests performed on model CCR101. Remark: All the information above are provided by the manufacturer. More detailed feature of the EUT please refers to the user manual. Report No.: NTC2211009FV00 Page 6 of 44 Technical Specification Bluetooth Version: V5.0 Frequency Range: 2402-2480MHz Modulation Type: GFSK, Π4/-DQPSK Number of Channel: 79 (refer to following channel list for details) Channel Space: 1MHz Antenna Type: PCB Antenna Antenna Gain: -0.58 dBi (Declared by the manufacturer) Note: The EUT does not support 8DPSK and Bluetooth Low Energy feature in accordance with the declaration of the manufacturer. Report No.: NTC2211009FV00 Page 7 of 44 Channel List Channel Frequency (MHz) Channel Frequency …

Text truncated - open the document above for the full version.

FCC ID: 2AMSOSTW003 Test Photo Radiated emission (Below 30MHz) Radiated emission (30-1000MHz) FCC ID: 2AMSOSTW003 Radiated emission (Above 1000MHz) Conducted Emission
