2AMSUIRC1Mouse Dongle

Report No.: 2002C032A Page 2 of 5 Rep ort No.: 2002C032A Page 3 of 5

200300001 for 中國/美國FOR 日本 尺寸13x5 mm 白色線框為刀模線 銅版紙/K=100 黑色 SANWA RC25 Product label information Due to the size of the products (model SANWA RC25), the FCC ID are located at the product manual and package. X002HRCJ1 N FCC ID: 2AMSUTB155 SANWA RC25 FCC ID:2AMSUIRC1 BQB 㼄㻜㻜㻞㻴㻾㻯㻶㻝㻺 0$'(,1&+,1$ GMA TB155 :LUHOHVV7UDFNEDOO0RXVH )&&,' $0687% 6$1:$5& )&&,'$068,5& %4%

Report No.: 2 002C032A Page 3 of 5 Report No.: 2002 C032A Page 4 of 5 Antenna

Report No.: BTL-FCCP-1-2002C032C Page 1 of 49 FCC Radio Test Report FCC ID: 2AMSUIRC1 This report concerns: Original Grant Project No. : 2002C032C Equipment : Mouse Dongle Brand Name : SANWA Test Model : SANWA RC25 Series Model : N/A Applicant : SANWA LIMITED Address : Room 1005, 10/F., Tower 2, Silvercord 30 Canton Road, Tsim Sha Tsui, Kowloon, Hong Kong, China Manufacturer : iOne Electronic Technology co., LTD. Taiwan Branch Address : Rm. 2, 8F., No. 75, Sec. 1, Xintai 5th Rd., Xizhi Dist., New Taipei city, Taiwan Factory : Dong Guan Ione Electronic Co.,Ltd. Address : Yong Jun 2rd Rd, Jin Qian Ling Ind. District, Jitigang, Huang Jiang Town, Dong Guan, Guang Dong Province, China (Post Code:523715) Date of Receipt : Mar. 20, 2020 Date of Test : Mar. 25, 2020 ~ Mar. 28, 2020 Issued Date : Apr. 23, 2020 Report Version : R02 Test Sample : Engineering Sample No.: DG190521376 for conducted, DG190521377 for radiated. Standard(s) : FCC Part15, Subpart C (15.249) ANSI C63.10-2013 The above equipment has been tested and found compliance with the requirement of the relative standards by BTL Inc. Prepared by : Nick Chen Approved by : Ethan Ma Add: No.3, Jinshagang 1st Road, Shixia, Dalang Town,Dongguan, Guangdong, China. Tel: +86-769-8318-3000 Web: www.newbtl.com Report No.: BTL-FCCP-1-2002C032C Page 2 of 49 Declaration BTL represents to the client that testing is done in accordance with standard procedures as applicable and that test instruments used has been calibrated with standards traceable to international standard(s) and/o r national standard(s). BTL's reports apply only to the specific samples tested under conditions. It is manufacture’s responsibility to ensure that additional production units of this model are manufactured with the identical electrical and mechanical components. BTL shall have no liability for any declarations, inferences or generalizations drawn by the client or others from BTL issued reports. The report must not be used by the client to claim product certification, approval, or endorsement by NVLAP, NIST, A2LA, or any agency of the U.S. Government. This report is the confidential property of the client. As a mutual protection to the clients, the public and ourselves, the test report shall not be reproduced, except in full, without our written approval. BTL’s laboratory quality assurance procedures are in compliance with the ISO/IEC 17025 requirements, and accredited by the conformity assessment authorities listed in this test report. BTL is not responsible for the sampling stage, so the results only apply to the sample as received. The information, data and test plan are provided by manufacturer which may affect the validity of results, so it is manufacturer’s responsibility to ensure that the apparatus meets the essential requirements of applied standards and in all the possible configurations as representative of its intended use. Limitation For the use of the authority's logo is limited unless the Test Standard(s)/Scope(s)/Item(s) mentioned in this test report is (are) included in the conformity assessment authorities acceptance respective. Please note that the measurement uncertainty is provided for informational purpose only and are not use in determining the Pass/Fail results. Report No.: BTL-FCCP-1-2002C032C Page 3 of 49 Table of Contents Page REPORT ISSUED HISTORY 5 1 . SUMMARY OF TEST RESULTS 6 1.1 TEST FACILITY 7 1.2 MEASUREMENT UNCERTAINTY 7 1.3 TEST ENVIRONMENT CONDITIONS 7 2 . GENERAL INFORMATION 8 2.1 GENERAL DESCRIPTION OF EUT 8 2.2 DESCRIPTION OF TEST MODES 9 2.3 PARAMETERS OF TEST SOFTWARE 9 2.4 BLOCK DIAGRAM SHOWING THE CONFIGURATION OF SYSTEM TESTED 10 2.5 SUPPORT UNITS 10 3 . AC POWER LINE CONDUCTED EMISSIONS TEST 11 3.1 LIMIT 11 3.2 TEST PROCEDURE 11 3.3 DEVIATION FROM TEST STANDARD 11 3.4 TEST SETUP 12 3.5 EUT OPERATING CONDITIONS 12 3.6 TEST RESULTS 12 4 . RADIATED EMISSION TEST 13 4.1 LIMIT 13 4.2 TEST PROCEDURE 14 4.3 DEVIATION FROM TEST STANDARD 14 4.4 TEST SETUP 15 4.5 EUT OPERATING CONDITIONS 16 4.6 TEST RESULT - 9 KHZ TO 30 MHZ 16 4.7 TEST RESULT - 30 MHZ TO 1000 MHZ 16 4.8 TEST RESULT - ABOVE 1000 MHZ 16 5 . BANDWIDTH TEST 17 5.1 TEST PROCEDURE 17 5.2 DEVIATION FROM STANDARD 17 5.3 TEST SETUP 17 5.4 EUT OPERATION CONDITIONS 17 5.5 TEST RESULTS 17 Report No.: BTL-FCCP-1-2002C032C Page 4 of 49 Table of Contents Page 6 . MEASUREMENT INSTRUMENTS LIST 18 7 . EUT TEST PHOTO 20 APPENDIX A - AC POWER LINE CONDUCTED EMISSIONS 24 APPENDIX B - RADIATED EMISSION - 9 KHZ TO 30 MHZ 27 APPENDIX C - RADIATED EMISSION - 30 MHZ TO 1000 MHZ 32 APPENDIX D - RADIATED EMISSION - ABOVE 1000 MHZ 35 APPENDIX E - BANDWIDTH 48 Report No.: BTL-FCCP-1-2002C032C Page 5 of 49 REPORT ISSUED HISTORY Report Version Description Issued Date R00 Original Issue. Apr. 13, 2020 R01 Change the applicant information. Apr. 16, 2020 R02 Modified the comments of cetecom Apr. 23, 2020 Report No.: BTL-FCCP-1-2002C032C Page 6 of 49 1. SUMMARY OF TEST RESULTS Test procedures according to the technical standard(s): FCC Part15, Subpart C (15.249) Standard(s) Section Test Item Test Result Judgment Remark 15.207(a) AC Power Line Conducted Emissions APPENDIX A PASS ------ 15.209 15.249(a) Radiated Emissions APPENDIX B APPENDIX C APPENDIX D PASS ------ 15.215(c) Bandwidth APPENDIX EPASS ------ Note: (1) “N/A” denotes test is not applicable to this device. Report No.: BTL-FCCP-1-2002C032C Page 7 of 49 1.1 TEST FACILITY The test facilities used to collect the test data in this report is at the location of No.3, Jinshagang 1st Road, Shixia, Dalang Town, Dongguan, Guangdong, China. BTL's Test Firm Registration Number for FCC: 357015 BTL's Designation Number for FCC: CN1240 1.2 MEASUREMENT UNCERTAINTY ISO/IEC 17025 requires that an estimate of the measurement uncertainties associated with the emissions test results be included in the report. The measurement uncertainties given below are based on a 95% confidence level (based on a coverage factor (k=2)) The BTL measurement uncertainty as below table:…

Text truncated - open the document above for the full version.

Report No.: BTL-FCCP-1-2002C032C Page 23 of 58 10. EUT TEST PHOTO AC Power Line Conducted Emissions Test Photos Report No.: BTL-FCCP-1-2002C032C Page 24 of 58 Radiated Emissions Test Photos 9 kHz to 30 MHz Report No.: BTL-FCCP-1-2002C032C Page 25 of 58 Radiated Emissions Test Photos 30 MHz to 1000 MHz Report No.: BTL-FCCP-1-2002C032C Page 26 of 58 Radiated Emissions Test Photos Above 1 GHz
