2AN2MONFOKUSPFOKUS+, BuddyPhones CosmosFun, StudyPhones+, FireWork

ONANOFF LTD

Click to zoom

Application Details

Equipment Class: DSS - Part 15 Spread Spectrum Transmitter
Date of Grant: Sep 26, 2023
Application Purpose: Original Equipment
Date of Application: Sep 26, 2023
Equipment Note: FOKUS+, BuddyPhones CosmosFun, StudyPhones+, FireWork
Frequency Range: 2402.00000000 - 2480.00000000
Company: ONANOFF LTD
Country: Hong Kong

Documents & Files

Select a file to view

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

Bluetooth Fokus+ 1. English - EN 2. French - FR 3. German - DE 4. Spanish - ES 5. Italian - IT 6. Portuguese - PT 7. Dutch - NL 8. Finnish - FI 9. Swedish - SV 10. Danish - DK 11. Norwegian - NO 12. Polish - PL FokusMode® Switch Active Noise Cancellation(ANC)/ Transparency Mode Control Switch 3.5mm AUX-in/out USB Type-C Port LED Indicator Multi-Function Button(MFB) Volume Up Volume Down User Manual 1s 3s Power On Marche Ein Encendido Acceso Ligar Aan-knop Virta Päälle Ström På Tænd For Av Питание Вкл Power O Arrêt Aus Apagado Spento Desligar Uit-knop Virta Pois Ström Av Sluk For På Питание выкл Zasilanie Włączone Zasilanie Wyłączone Güç açık Güç kapalı Zapněte Vypněte Bekapcsolás Kikapcsolás Ενεργοποίηση Απενεργοποίηση เปิดเครื่อง ปิดเครื่อง הלעפה הקספה تشغيل إيقاف التشغيل Bluetooth Pairing Multi-Point Pairing Power on/o ANC & Transparency Mode Charging Recharge Laden Cargando Ricarica in Corso Recarga Opladen Lataa Laddar Genoplader Lader Перезарядка Low Power Batterie faible Batterie schwach Batería Baja Batteria Scarica Bateria Fraca Batterij-bijna-leeg Akun virta vähäinen Låg batterinivå Lavt strømniveau Lite batteri Низкий уровень зарядки Fully charged Entièrement chargé Vollständig laden Carga Completa Ricarica Completata Bateria Totalmente Carregada Volledig opladen Akku täysin ladattu Full laddad Fuld opladning Fullt ladet Полная зарядка Niski poziom bateriiŁadowanieW pełni naładowany Düşük güçŞarj oluyorTamamen şarj edildi Nízký stav baterieNabíjí seBaterie plně nabitá Akkufeszültség alacsonyTöltésTeljesen feltöltve Χαμηλή μπαταρίαΕπαναφόρτισηΠλήρως φορτισμένο แบตเตอรี่ต่ํากําลังชาร์จชาร์จเต็มแล้ว נמוכה קיבולת طاقة منخفضة טוען إعادة شحن במלואו טעון شحن كامل Charging Recharge Laden Cargando Ricarica in Corso Recarga Opladen Lataa Laddar Genoplader Lader Перезарядка Standby Etre prêt Bereithalten Apoyar Pausa Espera Stand-by Valmiina Står fast vid Stå ved Vent litt Стоять рядом с Fully charged Entièrement chargé Vollständig laden Carga Completa Ricarica Completata Bateria Totalmente Carregada Volledig opladen Akku täysin ladattu Full laddad Fuld opladning Fullt ladet Полная зарядка CzekajŁadowanieW pełni naładowany Yanında olmakŞarj oluyorTamamen şarj edildi PohotovostníNabíjí seBaterie plně nabitá Készenlétben lévőTöltésTeljesen feltöltve ΑναμονήΕπαναφόρτισηΠλήρως φορτισμένο รอกําลังชาร์จชาร์จเต็มแล้ว המתנה تعليق טוען إعادة شحن במלואו טעון شحن كامل Low PowerCharging Stand Play/Pause Lecture/Pause Wiedergabe/Pause Reproducir/Pausar Avvio/Pausa Reproduzir/Pausar Afspelen/Pauzeren Toista/Keskeytä Spela/Pausa Afspil/pause Avspilling/pause Odtwarzanie/Pauza Oynat/Duraklat Přehrát / Pozastavit Lejátszás/szünet Αναπαραγωγή/Παύση เล่น/หยุดชั่วคราว השהה/הפעל 1x 1x 1x Volume Up/Down Volume Up Augmenter le volume Lautstärke erhöhen Subir Volumen Volume Up Aumentar volume Volume verhogen Äänenvoimakkuus ylös Volym upp Lydstyrke op Høyere volum Усилить громкость Zwiększ głośność Ses yükselt Zesílení hlasitosti Hangerő fel Αύξηση έντασης เพิ่มระดับเสียง עוצמה הגבר رفع مستوى الصوت Volume Down Réduire le volume Lautstärke verringern Bajar Volumen Volume Down Diminuir volume Volume verlagen Äänenvoimakkuus alas Volym ner Lydstyrke ned Lavere volume Уменьшить громкость Zmniejsz głośność Ses azalt Zeslabení hlasitosti Hangerő le Μείωση έντασης ลดระดับเสียง עוצמה הנמך خفض الصوت Active Noise Cancellation (ANC) Aktif Gürültü Önleme(ANC) إلغاء الضوضاء النشطة ביטול רעשים פעיל ANC Aktivní potlačení hluku (ANC) Aktív zajcsökkentés (ANC) Ενεργή ακύρωση θορύβου (ANC) Активное подавление шума (ANC) การตัดเสียงรบกวนโดยใช้พลังงานไฟฟ้า (ANC) (ANC) Système anti-bruit actif (ANC) Aktive Geräuschreduzierung (ANC) Cancelación activa de ruido (ANC) Cancellazione attiva del rumore (ANC) Controle ativo de ruído (ANC) Actieve ruisonderdrukking (ANC) Aktiivinen melunpoisto (ANC) Aktiv brusreducering (ANC) Aktiv støjdæmpning (ANC) Aktiv støyreduksjon (ANC) Aktywna redukcja szumów (ANC) Transparency Mode Transparent mode شفافة طريقة שקוף מצב Průhledný režim Átlátszó mód Διαφανής λειτουργία прозрачный режим โหมดโปร่งใส Mode transparent Transparenter Modus Modo transparente Modalità trasparente Modo transparente Transparante modus Läpinäkyvä tila Genomskinligt läge Gennemsigtig tilstand Gjennomsiktig modus Tryb przejrzysty ANC Track Back Piste précédente Vorheriger Titel Pista Anterior Brano Precedente Faixa Anterior Vorige track Siirry taaksepäin Låt bakåt Forrige spor Forrige spor Перемотка трека назад Poprzedni utwór Geri Sar Předchozí skladba Egy zeneszámmal vissza Προηγούμενο κομμάτι เล่นย้อนกลับ אחורה העברה ترجيع المسار Change Volume Mode Change Volume Mode Lautstärkemodus ändern Cambiar Modo de Volumen Modalità Modi°ca Volume Alterar o modo de volume Wijzig volumemodus Vaihda äänenvoimakkuutta Ändring av volymläget Skift lydstyrketilstand Modus for volumkontroll Изменить режим громкости Mode Modi°cation du volume Zmień tryb głośności Ses Değiştirme Modu Změňte režim hlasitosti Hangerőváltó mód Αλλαγή λειτουργίας έντασης เปลี่ยนโหมดระดับเสียง تغي وضع مستوى الصوت הקול עוצמת מצב את שנה SafeAudio® Mode (0-85dB) Default Mode (0-100dB) Incoming Call Appel entrant Eingehender Anruf Llamada Entrante Chiamata in Arrivo Chamada recebida Binnenkomende oproep Saapuva puhelu Inkommande samtal Indgående opkald Innkommende anrop Входящий звонок Answer Call Appel en cours Bei Anruf Llamada Activa Chiamata in Corso Em chamada In gesprek Puhelu kesken I samtal Opkald Samtale Текущий звонок Reject Call Rejeter l'appel Anruf ablehnen Rechazar llamada Ri°uta la chiamata Rejeitar chamada Oproep weigeren Hylkää puhelu Avvisa samtal Afvis opkald Avvis anrop Отклонить звонок 1x Połączenie przychodzące W trakcie rozmowyOdrzuć połączenie Gelen çağrı TelefondaÇağrıyı reddet Příchozí hovor Volání (hovor)Odmítnutí hovoru Bejövő hívás Hívás alattHívás elutasítása Εισερχόμενη κλήση Σε κλήσηΑπόρριψη κλήσης สายเรียกเข้า กําลังใช้สายโทรอยู่ ปฏิเสธการรับสาย נכנסת שיחה مكالمة واردة בשיחה على المكالمة שיחה דחה رفض المكالمة 1s Answer/Reject Calls www.o…

Text truncated - open the document above for the full version.

Attestation Statements

Rev 1/26/2023 ONANOFF LTD Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 USA Date: September 5, 2023 Ref: Attestation Statements Part 2.911(d)(5)(i) Filing FCC ID: (2AN2MONFOKUSP) [ONANOFF LTD] (“the applicant”) certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. Sincerely, AGNES YEUNG Rev 1/26/2023 ONANOFF LTD Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 USA Date: September 5, 2023 Ref: Attestation Statements Part 2.911(d)(5)(ii) Filing FCC ID: (2AN2MONFOKUSP) [ONANOFF LTD] (“the applicant”) certifies that, as of the date of the filing of the application, the applicant is not identified on the Covered List (as a specifically named entity or any of its subsidiaries or affiliates) as an entity producing “covered” equipment. Sincerely, AGNES YEUNG

Attestation Statements

Rev 1/26/2023 ONANOFF LTD Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 USA Date: September 5, 2023 Ref: Attestation Statements Part 2.911(d)(7) Filing FCC ID or Grantee Code: [2AN2MONFOKUSP] Applicant FRN: [0026926931] [ONANOFF LTD] (“the applicant”) certifies that, as of the date of the filing of the application, [ONANOFF LLC] is our designated U.S. agent for service of process for the above referenced FCC ID. [ONANOFF LTD] accepts to maintain an agent for no less than one year after the grantee has terminated all marketing and importation or the conclusion of any Commission-related proceeding involving the equipment. [ONANOFF LLC] accepts, as of the date of the filing of the application, the obligation of the designated U.S. agent for service of process for the above referenced FCC ID. Designated U.S. Agent Information: Name: [ONANOFF LLC] U.S. Agent FRN: 0033411646 Address: 202 Canal Street, Suite 303, New York, New York, 10013, United States Contact Person: Agnes Yeung Tel.: 646 850 5888 Email: [email protected] Sincerely, ONANOFF LTD ONANOFF LLC AGNES YEUNG Agnes Yeung [Insert Applicant signature] [U.S. Agent signature]

Cover Letter(s)

Rev 11/20/07 ONANOFF LTD Federal Communications Commission Authorization and Evaluation Division Confidentiality Request regarding application for certification of FCC ID: 2AN2MONFOKUSP Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, we hereby request confidential treatment of information accompanying this application as outlined below: Exhibit Type File Name (Block Diagram, Schematics, Operational Description) (Block Diagram, SCH, Technical Description) The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Pursuant to DA04-1705 June 15, 2004 of the Commission’s public notice, we also request temporary confidential treatment of information accompanying this application as outlined below within xx days from the date of submitting the FCC: Exhibit Type File Name Sincerely, (signature) (printed name) AGNES YEUNG

Cover Letter(s)

To: Bureau Veritas Shenzhen company Limited Dongguan branch Subject: Declaration Letter For Model Similarity We (ONANOFF LIMITED), The undersigned hereby declare that our product: Product Name Model No. Same Difference FOKUS+ BT-ON-FOKUSP electrical circuit design, layout, component used , internal wiring and outward appearance 1. Wireless charging function. 2. Brand name: onanoff StudyPhones+ BT-ON-SPP FireWork BT-ON-FW BuddyPhones CosmosFun BT-BP-COSMOSF 1. No wireless charging function. 2. Brand name: BuddyPhones 3. There are no electrical components of the red circle marked on PCBA. FCC ID: 2AN2MONFOKUSP Best Regards! ONANOFF LIMITED Date: 2023-8-25 Signer:

Cover Letter(s)

ONANOFF LTD Federal Communications Commission Authorization and Evaluation Division 7 435 Oakland Mills Road Columbia, MD 21046 Date: 2023.9.5 SUBJECT: FCC Application for FCC ID: 2AN2MONFOKUSP To Whom It May Concern: We, the undersigned, hereby authorize _Glyn He by_Bureau Veritas Shenzhen Co., Ltd. Dongguan Branch at No. 96, Chenwulu Section, Guantai Rd., Houjie Town, Dongguan City, Guangdong 523942, China on our behalf, to apply to the Federal Communications Commission on our equipment. Any and all acts carried out by Glyn He Bureau Veritas Shenzhen Co., Ltd. Dongguan Branch on our behalf shall have the same effect as acts of our own. This is to advise that we are in full compliance with the Anti- Drug Abuse Act. We, the applicant, are not subject to a denial of federal benefits pursuant to Section 5301 of the Anti-Drug Act of 1988, 21 USC853a, and no party to the application is subject to a denial of federal benefits pursuant to that section. Regards, (Signature): (Printed Name): AGNES YEUNG

External Photos

ID Label/Location Info

FOKUS+ with Charging Stand Product Spec Lable & Tracking Lable Artwork R Driver Holder 20221228 OFANCBHDGCHWW/YY 25mm 15.9mm R Driver Holder Product Tracking Lable & Product Spec Sticker Material: Silvery Sticker Location: R Speaker Panel Rule for tracking code: (WW stands for production week, which is nature number from 01-52, YY stands for the last two name of the production year) ONANOFF LIMITED Name: FOKUS+ M odel: B T - ON-FOKUSP F C C ID: 2AN2MONFOKUSP B a t t e r y O utput: 3.7V 660m A h I nput: DC 5V 1A IC: 27546-FOKPL xxx-xxxxxx Y U xxxxx x -xxxxx ONANOFF LIMITED Name: FOKUS+ M odel: B T - ON-FOKUSP F C C ID: 2AN2MONFOKUSP B a t t e r y O utput: 3.7V 660m A h I nput: DC 5V 1A IC: 27546-FOKPL xxx-xxxxxx Y U xxxxx x -xxxxx

Internal Photos

RF Exposure Info

Bureau Veritas Shenzhen Co., Ltd. Dongguan Branch No. 96, Guantai Road (Houjie Section), Houjie Town, Dongguan City, Guangdong Province. 523942. People’s Republic of China. Tel: +86 769 8998 2098 Fax: +86 769 8593 1080 Email: [email protected] Page 1 of 6 Report Version 1 Test Report No.: FM2206WDG0262-1 RF EXPOSURE REPORT Applicant ONANOFF LIMITED Address RM 424, Sino Ind. Plaza, 9 Kai Cheung Road, Kowloon Bay, Kowloon, Hong Kong Manufacturer or Supplier ONANOFF LIMITED Address RM 424, Sino Ind. Plaza, 9 Kai Cheung Road, Kowloon Bay, Kowloon, Hong Kong Product FOKUS+, BuddyPhones CosmosFun Additional Product StudyPhones+, FireWork Brand Name , Model BT-ON-FOKUSP, BT-BP-COSMOSF Additional Model & Model Difference BT-ON-SPP, BT-ON-FW, See section 1 Date of tests Aug. 06, 2023 ~ Aug. 21, 2023 FCC Part 2 (Section 2.1093) KDB 447498 D01 V06 IEEE C95.1 CONCLUSION: The submitted sample was found to COMPLY with the test requirement Tested by Eric Fang Project Engineer / EMC Department Approved by Glyn He Assistant Manager / EMC Department Date: Sep. 06, 2023 This report is governed by, and incorporates by reference, the Conditions of Testing as posted at the date of issuance of this report at http://www.bureauveritas.com/home/about-us/our-business/cps/about-us/terms-conditions/ and is intended for your exclusive use. Any copying or replication of this report to or for any other person or entity, or use of our name or trademark, is permitted only with our prior written permission. This report sets forth our findings solely with respect to the test samples identified herein. The results set forth in this report are not indicative or representative of the quality or characteristics of the lot from which a test sample was taken or any similar or identical product unless specifically and expressly noted. Our report includes all of the tests requested by you and the results thereof based upon the information that you provided to us. Measurement uncertainty is only provided upon request for accredited tests. Statements of conformity are based on simple acceptance criteria without taking measurement uncertainty into account, unless otherwise requested in writing. You have 60 days from date of issuance of this report to notify us of any material error or omission caused by our negligence or if you require measurement uncertainty; provided, however, that such notice shall be in writing and shall specifically address the issue you wish to raise. A failure to raise such issue within the prescribed time shall constitute your unqualified acceptance of the completeness of this report, the tests conducted and the correctness of the report contents. Bureau Veritas Shenzhen Co., Ltd. Dongguan Branch No. 96, Guantai Road (Houjie Section), Houjie Town, Dongguan City, Guangdong Province. 523942. People’s Republic of China. Tel: +86 769 8998 2098 Fax: +86 769 8593 1080 Email: [email protected] Page 2 of 6 Report Version 1 Test Report No.: FM2206WDG0262-1 TABLE OF CONTENTS RELEASE CONTROL RECORD ................................................................................ 3 1. CERTIFICATION .............................................................................................. 4 2. RF EXPOSURE DEFINE ................................................................................. 5 3. CLASSIFICATION ........................................................................................... 5 4. SAR TEST EXCLUSION THRESHOLDS ........................................................ 6 Bureau Veritas Shenzhen Co., Ltd. Dongguan Branch No. 96, Guantai Road (Houjie Section), Houjie Town, Dongguan City, Guangdong Province. 523942. People’s Republic of China. Tel: +86 769 8998 2098 Fax: +86 769 8593 1080 Email: [email protected] Page 3 of 6 Report Version 1 Test Report No.: FM2206WDG0262-1 RELEASE CONTROL RECORD ISSUE NO. REASON FOR CHANGE DATE ISSUED FM2206WDG0262-1 Original release Sep. 06, 2023 Bureau Veritas Shenzhen Co., Ltd. Dongguan Branch No. 96, Guantai Road (Houjie Section), Houjie Town, Dongguan City, Guangdong Province. 523942. People’s Republic of China. Tel: +86 769 8998 2098 Fax: +86 769 8593 1080 Email: [email protected] Page 4 of 6 Report Version 1 Test Report No.: FM2206WDG0262-1 1. CERTIFICATION FCC ID: 2AN2MONFOKUSP PRODUCT: FOKUS+, BuddyPhones CosmosFun ADDITIONAL PRODUCT: StudyPhones+, FireWork BRAND NAME: , MODEL NO.: BT-ON-FOKUSP, BT-BP-COSMOSF ADDITIONAL NO.: BT-ON-SPP, BT-ON-FW APPLICANT: ONANOFF LIMITED STANDARDS: FCC Part 2 (Section 2.1093) KDB 447498 D01 V06 IEEE C95.1 Notes: 1. Additional models BT-ON-SPP, BT-ON-FW are identical with test model BT-ON-FOKUSP except the appearance, product name, brand name and model no. for trading purpose. See model list for details. 2. Model list： Product name Model No. Brand Name Difference FOKUS+ BT-ON-FOKUSP onanoff Has wireless charger function StudyPhones+ BT-ON-SPP FireWork BT-ON-FW BuddyPhones CosmosFun BT-BP-COSMOSF BuddyPhones No wireless charger function Bureau Veritas Shenzhen Co., Ltd. Dongguan Branch No. 96, Guantai Road (Houjie Section), Houjie Town, Dongguan City, Guangdong Province. 523942. People’s Republic of China. Tel: +86 769 8998 2098 Fax: +86 769 8593 1080 Email: [email protected] Page 5 of 6 Report Version 1 Test Report No.: FM2206WDG0262-1 2. RF EXPOSURE DEFINE The corresponding SAR Exclusion Threshold condition, listed below: 1) The 1-g and 10-g SAR test exclusion thresholds for 100 MHz to 6 GHz at test separation distances ≤ 50 mm are determined by: [(max. power of channel, including tune-up tolerance, mW)/(min. test separation distance, mm)] ·[ √f(GHz)] ≤ 3.0 for 1-g SAR and ≤ 7.5 for 10-g extremity SAR,16 where  f(GHz) is the RF channel transmit frequency in GHz  Power and distance are rounded to the nearest mW and mm before calculation  The result is rounded to one decimal place for comparison The test exclusions are applicab…

Text truncated - open the document above for the full version.

Test Report

Bureau Veritas Shenzhen Co., Ltd. Dongguan Branch No. 96, Guantai Road (Houjie Section), Houjie Town, Dongguan City, Guangdong Province. 523942. People’s Republic of China. Tel.: +86 769 8998 2098 Fax: +86 769 8593 1080 Email: [email protected] Page 1 of 12 Report Version B Test Report No.: AN2206WDG0262 ANTENNA TEST REPORT Applicant ONANOFF LIMITED Address RM 424, Sino Ind. Plaza, 9 Kai Cheung Road, Kowloon Bay, Kowloon, Hong Kong Manufacturer or Supplier ONANOFF LIMITED Address RM 424, Sino Ind. Plaza, 9 Kai Cheung Road, Kowloon Bay, Kowloon, Hong Kong Product Antenna Brand Name Model BT-ON-FOKUSP Max. Peak Gain -0.28 dBi Date of tests Jan. 12, 2023 Tested by Eric Fang Project Engineer / EMC Department Approved by Glyn He Assistant Manager / EMC Department Date: Feb. 06, 2023 This report is governed by, and incorporates by reference, the Conditions of Testing as posted at the date of issuance of this report at http://www.bureauveritas.com/home/about-us/our-business/cps/about-us/terms-conditions/ and is intended for your exclusive use. Any copying or replication of this report to or for any other person or entity, or use of our name or trademark, is permitted only with our prior written permission. This report sets forth our findings solely with respect to the test samples identified herein. The results set forth in this report are not indicative or representative of the quality or characteristics of the lot from which a test sample was taken or any similar or identical product unless specifically and expressly noted. Our report includes all of the tests requested by you and the results thereof based upon the information that you provided to us. Measurement uncertainty is only provided upon request for accredited tests. Statements of conformity are based on simple acceptance criteria without taking measurement uncertainty into account, unless otherwise requested in writing. You have 60 days from date of issuance of this report to notify us of any material error or omission caused by our negligence or if you require measurement uncertainty; provided, however, that such notice shall be in writing and shall specifically address the issue you wish to raise. A failure to raise such issue within the prescribed time shall constitute your unqualified acceptance of the completeness of this report, the tests conducted and the correctness of the report contents. Bureau Veritas Shenzhen Co., Ltd. Dongguan Branch No. 96, Guantai Road (Houjie Section), Houjie Town, Dongguan City, Guangdong Province. 523942. People’s Republic of China. Tel.: +86 769 8998 2098 Fax: +86 769 8593 1080 Email: [email protected] Page 2 of 12 Report Version B Test Report No.: AN2206WDG0262 TABLE OF CONTENTS 1. MEASUREMENTS SETUP ................................................................................................ 3 1.1 TEST PROCEDURE ................................................................................................... 3 2. SIZE OF THE ANTENNA ................................................................................................... 4 3. TEST INSTRUMENTS ....................................................................................................... 4 4. TEST RESULTS ................................................................................................................. 5 5. PHOTOGRAPHS OF THE TEST CONFIGURATION ....................................................... 12 Bureau Veritas Shenzhen Co., Ltd. Dongguan Branch No. 96, Guantai Road (Houjie Section), Houjie Town, Dongguan City, Guangdong Province. 523942. People’s Republic of China. Tel.: +86 769 8998 2098 Fax: +86 769 8593 1080 Email: [email protected] Page 3 of 12 Report Version B Test Report No.: AN2206WDG0262 1. MEASUREMENTS SETUP 1.1 TEST PROCEDURE a. The EUT was placed on the rotating table 1.5 meters above the ground at a Fully Anechoic Room, the table was rotated 360 degrees. b. The EUT was set 3 meters away from the receiving antenna, which was mounted on the top of a antenna tower. c. The antenna is 1.5 meters above the ground. Both horizontal and vertical polarizations of the antenna are set to make the measurement. d. During the test, each emission was maximized by: having the EUT continuously working, investigated all operating modes, rotated about all 3 axis (X, Y & Z) and considered typical configuration to obtain worst position. Bureau Veritas Shenzhen Co., Ltd. Dongguan Branch No. 96, Guantai Road (Houjie Section), Houjie Town, D…

Text truncated - open the document above for the full version.

Contact Information

Applicant

AGNES YEUNG(OPERATION MANAGER)

[email protected]23930306Fax: N/A

Test Firm

Bureau Veritas Shenzhen Co., Ltd. Dongguan BranchEdwin Ye

[email protected]86-20-8714 8549

Technical Specifications

#	Rule Parts	Frequency Range	Power Output
1	15C	2.40 GHz - 2.48 GHz	2.70 mW

Confidentiality

Long Term

Grant Notes

Output power listed is the maximum conducted output power.
