石头科技产品包装图纸 北京石头科技有限公司 图纸 提供 单位 材 质 工 艺 要 求 历 史 版 本 版本号：V2.0 修改点： Tanos V 说明书修改意见12.16.docx 修改人：许戈 版本号：V3.0 修改点： 第三轮修改意见 修改人：许戈 版本号：V4.0 修改点： 修改人：许戈 备 注 项目名称Tanos V说明书FCC版 4.03.0173 V4.0 2020.01.14 许戈 料号 版本号 设计时间 设计师 设计师 比例1:1单位mm 材质：105g哑粉，骑钉 成品尺寸：172*130mm 页数：40P 参考色：PANTONE Cool Gray 11 C PANTONE 185 C 尺寸偏差：±0.5mm 印刷偏位：±1mm Roborock S6 MaxV Robot Vacuum Cleaner User Manual Before using the product, read this manual thoroughly and save it for future reference. Roborock S6 MaxV Robot Vacuum Cleaner User Manual Before using the product, read this manual thoroughly and save it for future reference. 1 6 8 9 15 21 25 32 33 35 Product Overview Safety Information FCC IC Statement Installation Instructions for Use Routine maintenance Basic Parameters Troubleshooting FAQs Battery and Charging 1 Safety Information IMPORTANT SAFETY INSTRUCTIONS When using an electrical appliance, basic precautions should always be followed, including the following: READ ALL INSTRUC- TIONS BEFORE USING (THIS APPLIANCE), Failure to follow the warnings and instructions may result in electric shock, fire and/or serious injury. WARNING To reduce the risk of fire, electric shock, or injury: · Do not use outdoors or on wet surfaces. · Do not allow to be used as a toy. Close attention is necessary when used by or near children, pets or plants. · Use only as described in this manual. Use only manufacturer’s recommended attachments. · Do not use with damaged cord or plug. If appliance is not working as it should, has been dropped, damaged, left outdoors, or dropped into water, return it to a service center. · Do not pull or carry by cord, use cord as a handle, close a door on cord, or pull cord around sharp edges or corners. · Do not run appliance over cord. Keep cord away from heated surfaces. · Do not unplug by pulling on cord. To unplug, grasp the plug, not the cord. · Do not handle charger, including charger plug, and charger terminals with wet hands. · Do not put any object into openings. Do not use with any opening blocked; keep free of dust, lint, hair, and anything that may reduce air flow. · Keep hair, loose clothing, fingers, and all parts of body away from openings and moving parts. · Do not use to pick up flammable or combustible liquids, such as gasoline, or use in areas where they may be present. · Do not pick up anything that is burning or smoking, such as cigarettes, matches, or hot ashes. · Do not use without dust bag. · Prevent unintentional starting. Ensure the switch is in the off-position before connecting to battery pack, picking up or carry- ing the appliance. Carrying the appliance with your finger on the switch or energizing appliance that have the switch on invites accidents. 2 Safety Information · For use only with roborock CDZ��RR or CDZ��RR charger. Recharge only with the charger specified by the manufacturer. A charger that is suitable for one type of battery pack may create a risk of fire when used with another battery pack. · Use appliances only with specifically designated battery packs. Use of any other battery packs may create a risk of injury and fire. · Turn off the appliance before making any adjustments, changing accessories, or storing appliance. Such preventive safety measures reduce the risk of starting the appliance accidentally. · When battery pack is not in use, keep it away from other metal objects, like paper clips, coins, keys, nails, screws or other small metal objects, that can make a connection from one terminal to another. Shorting the battery terminals together may cause burns or a fire. · Under abusive conditions, liquid may be ejected from the battery; avoid contact. If contact accidentally occurs, flush with water. If liquid contacts eyes, additionally seek medical help. Liquid ejected from the battery may cause irritation or burns. · Do not use a battery pack or appliance that is damaged or modified. Damaged or modified batteries may exhibit unpredic table behavior resulting in fire, explosion or risk of injury. · Do not expose a battery pack or appliance to fire or excessive temperature. Exposure to fire or temperature above ���° C may cause explosion. · Follow all charging instructions and do not charge the battery pack or appliance outside of the temperature range specified in the instructions. Charging improperly or at temperatures outside of the specified range may damage the battery and increase the risk of fire. · Have servicing performed by a qualified repair person using only identical replacement parts.This will ensure that the safety of the product is maintained. · Do not modify or attempt to repair the appliance or the battery pack except as indicated in the instructions for use and care. Place the cords from other appliances out of the area to be cleaned. · Do not operate the vacuum in a room where an infant or child is sleeping. · Do not operate the vacuum in an area where there are lit candles or fragile objects on thefloor to be cleaned. · Do not operate the vacuum in a room that has lit candles on furniture that the vacuum may accidentally hit or bump into. · Do not allow children to sit on the vacuum. · Do not use the vacuum cleaner on a wet surface. Risk Of Injury. Brush May Start Unexpectedly.Disconnect the main Brush Before Cleaning or Servicing. · Do not use the product when the temperature is higher than ��°C or lower than �°C, or there is any liquid or sticky substance on the floor. 3 Safety Information SAVE THESE INSTRUCTIONS Household use only. IMPORTANTES MESURES DE S CURIT L’utilisation d’un appareil électrique demande certaines précautions: LIRE TOUTES LES INSTRUCTIONS AVANT DE FAIRE FONCTIONNER (CETAPPAREIL), Le non-respect des mises en garde et des instructions peut causer des chocs électriques, des incendies et/ou des blessures graves. AVERTISSEMENT · Pour réduire les risques d’incendie, de choc électrique ou de blessure: · Ne pas exposer à la pluie, Ranger à l’intérieur. · Ne pas permettre aux enfants de jouer avec l’appareil. Une atte…

Text truncated - open the document above for the full version.

Beijing Roborock Technology Co.,Ltd. Date: December 28, 2019 To: Federal Communications Commission, Authorization & Evaluation Division, 7435 Oakland Mills Road, Columbia, MD 21046 To Whom It May Concern: The Beijing Roborock Technology Co.,Ltd. the undersigned, hereby authorizes Mr. Hongfei Wu of TÜV Rheinland Shanghai Co., Ltd, to act on the behalf of the Beijing Roborock Technology Co.,Ltd. solely in matters relating to the application for an FCC equipment authorization for FCC ID: 2AN2O-S6MAXV including the signing of documents in connection with this Application. Necessary acts carried out by Beijing Roborock Technology Co.,Ltd. on our behalf of the Beijing Roborock Technology Co.,Ltd. in connection with the Application shall have the same effect as acts of the Beijing Roborock Technology Co.,Ltd. The Beijing Roborock Technology Co.,Ltd. also hereby certify that no party to this application is subject to a denial of benefits, including FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 853(a). Thank you for your attention to this matter. Yours Sincerely, Name ： (Qianqian Hu) Title：Certification Engineer Company：Beijing Roborock Technology Co.,Ltd.

Confidentiality Letter Date: 2020-03-20 Subject: Confidentiality Request for ID: 2AN2O-S6MAXV Pursuant to FCC 47 CRF 0.457(d) and 0.459, the applicant requests that a part of the subject FCC application be held confidential. Type of Confidentiality Requested Exhibit Short Term Permanent Block Diagrams Short Term Permanent External Photos Short Term Permanent Internal Photos Short Term Permanent Operation Description/Theory of Operation Short Term Permanent Part List/Tune-Up Procedure Short Term Permanent Schematics Short Term Permanent Test Setup Photos Short Term Permanent User’s Manual Beijing Roborock Technology Co., Ltd. has spent substantial effort in developing this product and it is one of the first of its kind in industry. Having the subject information easily available to "competition" would negate the advantage they have achieved by developing this product. Not protecting the details of the design will result in financial hardship. Permanent Confidentiality: The applicant requests the exhibits listed above as permanently confidential be permanently withheld from public review due to materials that contain trade secrets and proprietary information not customarily released to the public. Short-Term Confidentiality: The applicant requests the exhibits selected above as short term confidential be withheld from public view for a period of 45 days from the date of the Grant of Equipment Authorization and prior to marketing. This is to avoid premature release of sensitive information prior to marketing or release of the product to the public. Applicant is also aware that they are responsible to notify TUV Rheinland in the event information regarding the product or the product is made available to the public. TUV Rheinland will then release the documents listed above for public disclosure pursuant to FCC Public Notice DA 04- 1705. Sincerely, CertificationEngineer By: Qianqian Hu (Signature/Title) (Print name)

Report No.: 1912WSU006-UE 1 of 7 EUT Photo Report No.: 1912WSU006-UE 2 of 7 Report No.: 1912WSU006-UE 3 of 7 CDZ11PR Adaptor Report No.: 1912WSU006-UE 4 of 7 Report No.: 1912WSU006-UE 5 of 7 Report No.: 1912WSU006-UE 6 of 7 CDZ12PR Adaptor Report No.: 1912WSU006-UE 7 of 7

主机标签 主机警示语标签 标签位置示意图：

Report No.: 1912WSU006-UE 1 of 9 EUT Photo Main Source Report No.: 1910WSU012-UE 2 of 9 Report No.: 1910WSU012-UE 3 of 9 Report No.: 1910WSU012-UE 4 of 9 Second Source Report No.: 1910WSU012-UE 5 of 9 Report No.: 1910WSU012-UE 6 of 9 Report No.: 1910WSU012-UE 7 of 9 WIFI Module Report No.: 1910WSU012-UE 8 of 9 Report No.: 1910WSU012-UE 9 of 9

MRT Technology (Suzhou) Co., Ltd Report No.:1912WSU006-U3 Phone: +86-512-66308358 Report Version: V01 Web: www.mrt-cert.com Issue Date: 02-27-2020 FCC ID: 2AN2O-S6MAXV Page Number: 1 of 7 IC: 23317-S6MAXV RF Exposure Evaluation Declaration FCC ID: 2AN2O-S6MAXV IC: 23317-S6MAXV APPLICANT: Beijing Roborock Technology Co., Ltd. Application Type: Certification Product: Robotic Vacuum Cleaner Model No.: roborock S6 MaxV Brand Name: FCC Rule Part(s): IC Rule Part(s): KDB 447498 D01 General RF Exposure Guidance v06 IEEE C95.1-1992 RSS-102 Issue 5 Test Date: December 13 ~ 25, 2019 Reviewed By: ( Oscar Shi) Approved By: ( Robin Wu ) The test results relate only to the samples tested. The test results shown in the test report are traceable to the national/international standards through the calibration of the equipment and evaluated measurement uncertainty herein. The test report shall not be reproduced except in full without the written approval of MRT Technology (Suzhou) Co., Ltd. Report No.: 1912WSU006-U3 FCC ID: 2AN2O-S6MAXV Page Number: 2 of 7 IC: 23317-S6MAXV Revision History Report No. Version Description Issue Date Note 1912WSU006-U3 Rev. 01 Initial Report 02-27-2020 Valid Report No.: 1912WSU006-U3 FCC ID: 2AN2O-S6MAXV Page Number: 3 of 7 IC: 23317-S6MAXV 1. PRODUCT INFORMATION 1.1. Equipment Description Product Name Robotic Vacuum Cleaner Model No. roborock S6 MaxV Brand Name Wi-Fi Specification 802.11b/g/n-HT20/n-HT40 Antenna Type: PCB Antenna Antenna Gain: 3.21 dBi Frequency Range 2.4GHz: For 802.11b/g/n-HT20: 2412 ~ 2462 MHz For 802.11n-HT40: 2422 ~ 2452 MHz Type of Modulation 802.11b: DSSS 802.11g/n: OFDM Maximum Average Output Power 802.11b: 8.67dBm 802.11g: 13.82dBm 802.11n-HT20: 13.14dBm 802.11n-HT40: 14.62dBm Report No.: 1912WSU006-U3 FCC ID: 2AN2O-S6MAXV Page Number: 4 of 7 IC: 23317-S6MAXV 2. RF Exposure Evaluation 2.1. Limits for FCC: According to FCC 1.1310: The criteria listed in the following table shall be used to evaluate the environment impact of human exposure to radio frequency (RF) radiation as specified in 1.1307(b) LIMITS FOR MAXIMUM PERMISSIBLE EXPOSURE (MPE) Frequency Range (MHz) Electric Field Strength (V/m) Magnetic Field Strength (A/m) Power Density (mW/cm 2 ) Average Time (Minutes) (A) Limits for Occupational/ Control Exposures 300-1500 -- -- f/300 6 1500-100,000 -- -- 5 6 (B) Limits for General Population/ Uncontrolled Exposures 300-1500 -- -- f/1500 6 1500-100,000 -- -- 1 30 f= Frequency in MHz Calculation Formula: Pd = (Pout*G)/(4*pi*r 2 ) Where Pd = power density in mW/cm 2 Pout = output power to antenna in mW G = gain of antenna in linear scale Pi = 3.1416 r = distance between observation point and center of the radiator in cm Pd is the limit of MPE, 1mW/cm². If we know the maximum gain of the antenna and the total power input to the antenna, through the calculation, we will know the distance r where the MPE limit is reached. 2.2. Limits for IC: According to RSS-102: Exemption Limits for Routine Evaluation – RF exposure evaluation is required if the separation distance between the user and/or bystander and the device’s radiating element is greater than 20 cm, except when the device operates as follows: • below 20 MHz6 and the source-based, time-averaged maximum e.i.r.p. of the device is equal to or less than 1 W (adjusted for tune-up tolerance); • at or above 20 MHz and below 48 MHz and the source-based, time-averaged maximum e.i.r.p. of Report No.: 1912WSU006-U3 FCC ID: 2AN2O-S6MAXV Page Number: 5 of 7 IC: 23317-S6MAXV the device is equal to or less than 22.48/ƒ0.5 W (adjusted for tune-up tolerance), where ƒ is in MHz; • at or above 48 MHz and below 300 MHz and the source-based, time-averaged maximum e.i.r.p. of the device is equal to or less than 0.6 W (adjusted for tune-up tolerance); • at or above 300 MHz and below 6 GHz and the source-based, time-averaged maximum e.i.r.p. of the device is equal to or less than 1.31 x 10-2 ƒ0.6834 W (adjusted for tune-up tolerance), where ƒ is in MHz; • at or above 6 GHz and the source-based, time-averaged maximum e.i.r.p. of the device is equal to or less than 5 W (adjusted for tune-up tolerance). In these cases, the information contained in the RF exposure technical brief may be limited to information that demonstrates how the e.i.r.p. was derived. Report No.: 1912WSU006-U3 FCC ID: 2AN2O-S6MAXV Page Number: 6 of 7 IC: 23317-S6MAXV 2.3. Test Result of RF Exposure Evaluation for FCC and IC Product Robotic Vacuum Cleaner Test Item RF Exposure Evaluation FCC: Test Mode Frequency Band (MHz) Maximum EIRP (dBm) Tune-up (dBm) Power Density at R = 20 cm (mW/cm2) Limit (mW/cm2) 802.11b/g/n 2412 ~ 2462 17.83 19.03 0.0159 1 IC: Test Mode Frequency Band (MHz) Maximum EIRP (dBm) Tune-up (dBm) Maximum EIRP (W) Limit (W) 802.11b/g/n 2412 ~ 2462 17.83 19.03 0.07998 2.6840 CONCLUSION: The Max Power Density at R (20 cm) =0.0159mW/cm 2 < 1mW/cm 2 . The device is excluded for SAR test and complies with the IC exposure requirements since the maximum conducted peak output power is lower than the SAR test exclusion thresholds. So the EUT complies with RF Exposure requirement. The End Report No.: 1912WSU006-U3 FCC ID: 2AN2O-S6MAXV Page Number: 7 of 7 IC: 23317-S6MAXV Appendix A - EUT Photograph Refer to “1912WSU006-UE” file.

MRT Technology (Suzhou) Co., Ltd Report No.:1912WSU006-U1 Phone: +86-512-66308358 Report Version: V01 Web: www.mrt-cert.com Issue Date: 02-27-2020 FCC ID: 2AN2O-S6MAXV Page Number: 1 of 133 IC: 23317-S6MAXV FCC ID: 2AN2O-S6MAXV IC: 23317-S6MAXV APPLICANT: Beijing Roborock Technology Co., Ltd. Application Type: Certification Product: Robotic Vacuum Cleaner Model No.: roborock S6 MaxV FCC Classification: Digital Transmission System (DTS) FCC Rule Part(s): Part 15 Subpart C (Section 15.247) IC Rule(s): RSS-247 Issue 2, RSS-GEN Issue 5 Test Procedure(s): ANSI C63.10-2013, KDB 558074 D01v05r02 Test Date: December 13, 2019~January 15,2020 MEASUREMENT REPORT FCC PART 15C / RSS-247 WLAN 802.11b/g/n Reviewed By: ( Oscar Shi) Approved By: ( Robin Wu ) The test results relate only to the samples tested. This equipment has been shown to be capable of compliance with the applicable technical standards as indicated in the measurement report and was tested in accordance with the measurement procedures specified in ANSI C63.10-2013. Test results reported herein relate only to the item(s) tested. The test report shall not be reproduced except in full without the written approval of MRT Technology (Suzhou) Co., Ltd. Report No.: 1912WSU006-U1 FCC ID: 2AN2O-S6MAXV Page Number: 2 of 133 IC: 23317-S6MAXV Revision History Report No. Version Description Issue Date Note 1912WSU006-U1 Rev. 01 Initial Report 02-27-2020 Valid Report No.: 1912WSU006-U1 FCC ID: 2AN2O-S6MAXV Page Number: 3 of 133 IC: 23317-S6MAXV CONTENTS Description Page 1. INTRODUCTION ...................................................................................................................... 6 1.1. Scope ........................................................................................................................... 6 1.2. MRT Test Location ....................................................................................................... 6 2. PRODUCT INFORMATION ...................................................................................................... 7 2.1. Equipment Description ................................................................................................. 7 2.2. Product Specification Subjective to this Report ............................................................ 7 2.3. Working Frequencies for this report .............................................................................. 8 2.4. Test Mode .................................................................................................................... 8 2.5. Description of Test Software ......................................................................................... 8 2.6. Duty Cycle .................................................................................................................... 9 2.7. Test Configuration ...................................................................................................... 10 2.8. EMI Suppression Device(s)/Modifications ................................................................... 10 2.9. Labeling Requirements ............................................................................................... 10 3. DESCRIPTION of TEST ......................................................................................................... 11 3.1. Evaluation Procedure .................................................................................................. 11 3.2. AC Line Conducted Emissions .................................................................................... 11 3.3. Radiated Emissions .................................................................................................... 12 4. ANTENNA REQUIREMENTS................................................................................................. 13 5. TEST EQUIPMENT CALIBRATION DATE ............................................................................. 14 6. MEASUREMENT UNCERTAINTY ......................................................................................... 16 7. TEST RESULT ....................................................................................................................... 17 7.1. Summary .................................................................................................................... 17 7.2. Occupied Bandwidth Measurement ............................................................................ 18 7.2.1. Test Limit ................................................................................................................ 18 7.2.2. Test Procedure used ............................................................................................... 18 7.2.3. Test Setting ............................................................................................................. 18 7.2.4. Test Setup .............................................................................................................. 19 7.2.5. Test Result .............................................................................................................. 20 7.3. Output Power Measurement ....................................................................................... 29 7.3.1. Test Limit ................................................................................................................ 29 7.3.2. Test Procedure Used .............................................................................................. 29 7.3.3. Test Setting ............................................................................................................. 29 7.3.4. Test Setup .............................................................................................................. 30 Report No.: 1912WSU006-U1 FCC ID: 2AN2O-S6MAXV Page Number: 4 of 133 IC: 23317-S6MAXV 7.3.5. Test Result .............................................................................................................. 31 7.4. Power Spectral Densi…

Text truncated - open the document above for the full version.

Report No.: 1912WSU006-UT 1 of 2 EMC Test Setup Photo Description: Front View of Conducted Emission Test Setup Description: Back View of Conducted Emission Test Setup Report No.: 1912WSU006-UT RF Test Setup Photo Description: Radiated Spurious Emission Test Setup Below 1GHz Description: Radiated Spurious Emission Test Setup Above 1GHZ
