2AN3WCORES3M5CoreS3

M5STACK -  V0.01 2 :'(2+5,)54:+4:9  7;/)19:'8: .......................................................................... 3 1.1. ARDUINO IDE ..................................................................... 3 1.2. BLUETOOTH SERIAL ................................................................. 3 1.3. WIFI SCANNING ..................................................................... 5 3 7;/)19:'8: 1.1.ARDUINO IDE Visit Arduino's official website(https://www.arduino.cc/en/Main/Software),Select the installation package for your own operating system to download. >1.Open up Arduino IDE, navigate to `File`->`Peferences`->`Settings` >2.Copy the following M5Stack Boards Manager url to `Additional Boards Manager URLs:` https://raw.githubusercontent.com/espressif/arduino-esp32/gh- pages/package_esp32_dev_index.json >3.Navigate to `Tools`->`Board:`->`Boards Manager...` >4.Search `ESP32` in the pop-up window, find it and click `Install` >5.select `Tools`->`Board:`->`ESP32-Arduino-ESP32 DEV Module 1.2.BLUETOOTH SERIAL 4 Open the Arduino IDE and open the example program `File`->`Examples`->`BluetoothSerial`->`SerialToSerialBT`. Connect the device to the computer and select the corresponding port to burn. After completion, the device will automatically run Bluetooth, and the device name is `ESP32test`. At this time, use the Bluetooth serial port sending tool on the PC to realize the transparent transmission of Bluetooth serial data. #include "BluetoothSerial.h" #if !defined(CONFIG_BT_ENABLED) || !defined(CONFIG_BLUEDROID_ENABLED) #error Bluetooth is not enabled! Please run `make menuconfig` to and en able it #endif 5 BluetoothSerial SerialBT; void setup() { Serial.begin(115200); SerialBT.begin("ESP32test"); //Bluetooth device name Serial.println("The device started, now you can pair it with bluetoot h!"); } void loop() { if (Serial.available()) { SerialBT.write(Serial.read()); } if (SerialBT.available()) { Serial.write(SerialBT.read()); } delay(20); } 1.3.WIFI SCANNING Open the Arduino IDE and open the example program `File`->`Examples`->`WiFi`->`WiFiScan`. Connect the device to the computer and select the corresponding port to burn. After completion, the device will automatically run the WiFi scan, and the current WiFi scan result can be obtained through the serial port monitor that comes with the Arduino. 6 #include "WiFi.h" void setup() { Serial.begin(115200); // Set WiFi to station mode and disconnect from an AP if it was pre viously connected WiFi.mode(WIFI_STA); WiFi.disconnect(); delay(100); Serial.println("Setup done"); } void loop() { Serial.println("scan start"); // WiFi.scanNetworks will return the number of networks found int n = WiFi.scanNetworks(); Serial.println("scan done"); if (n == 0) { Serial.println("no networks found"); } else { Serial.print(n); Serial.println(" networks found"); for (int i = 0; i < n; ++i) { // Print SSID and RSSI for each network found Serial.print(i + 1); Serial.print(": "); Serial.print(WiFi.SSID(i)); Serial.print(" ("); Serial.print(WiFi.RSSI(i)); Serial.print(")"); Serial.println((WiFi.encryptionType(i) == WIFI_AUTH_OPEN)?" ":"*"); delay(10); } } Serial.println(""); // Wait a bit before scanning again delay(5000); } M5STACK- CORES3 2023 V0.01 2 TABLE OF CONTENTS 1. OUTLINE ................................................................................... 3 1.1 HARDWARE COMPOSITION ............................................................. 3 2. PIN DESCRIPTION ...................................................................... 4 2.1. USB INTERFACE ...................................................................... 4 2.2. GROVE INTERFACE ................................................................... 4 3. FUNCTIONAL DESCRIPTION ......................................................... 5 3.1. CPU AND MEMORY .................................................................. 5 3.2. STORAGE DESCRIPTION .............................................................. 5 3.2.1. External Flash and SRAM .................................................. 5 3.3. CPU CLOCK ......................................................................... 6 3.4. RTC AND LOWPOWER MANAGEMENT ...................................... 6 4. ELECTRICAL CHARACTERISTICS .................................................... 7 4.1. ABSOLUTE MAXIMUM RATINGS .............................................. 7 4.2. WIFI RADIO AND BASEBAND .................................................... 7 4.3. BLUETOOTH LE RF TRANSMITTER (TX) SPECIFICATIONS ................ 8 4.4. BLUETOOTH LE RF RECEIVER (RX) SPECIFICATIONS ................. 8 3 1. OUTLINE M5Stick CORES3 is ESP32 board which based on ESP32-S3 chip, contained 2-inch TFT screen. The board is made of PC+ABC. 1.1 Hardware Composition The hardware of CORES3: ESP32-S3 chip, TFT screen, Green LED, Button, GROVE interface, TypeC-to-USB interface, Power Management chip and battery. ESP32-S3 The ESP32 is a dual-core system with two Harvard Architecture Xtensa LX6 CPUs. All embedded memory,external memory and peripherals are located on the data bus and/or the instruction bus of these CPUs.With some minor exceptions (see below), the address mapping of two CPUs is symmetric, meaning that they usethe same addresses to access the same memory. Multiple peripherals in the system can access embeddedmemory via DMA. TFT Screen is a 2-inch color screen driven ILI9342C with a resolution of 320 x 240. Operating voltage range is 2.6~3.3V, working temperature range is -25~55°C. Power Management chip is X-Powers's AXP2101. The operating voltage range is 2.9V~6.3V and the charging current is 1.4A. CORES3 equips ESP32 with everything needed for programming, everything needed for operation and development 4 2. PIN DESCRIPTION 2.1. USB INTERFACE M5CAMREA Configuration Type-C type USB interface, support USB2.0 standard communication protocol. 2.2. GROVE INTERFACE 4p spacing 2.0mm M5CAMREA GROVE Ports.A, Port.B, and Port.C, the internal cab…

Text truncated - open the document above for the full version.

Sincerely, Name/Title： Jimmy Lai/CEO Company: M5Stack Technology Co.,Ltd Address: 5F, Tangwei Stock Commercial Building Youli Road, Bao'an District Shenzhen,Guangdong China Phone: +8613509230623 Fax: 0755-69815195 E-Mail: [email protected]

Page 1 of 5 FCC ID: 2AN3WCORES3 Dongguan Yaxu (AiT) Technology Limited No.22, Jinqianling 3rd Street, Jitigang, Huangjiang, Dongguan, Guangdong, China. External Photos Photo 1 Photo 2 Page 2 of 5 FCC ID: 2AN3WCORES3 Dongguan Yaxu (AiT) Technology Limited No.22, Jinqianling 3rd Street, Jitigang, Huangjiang, Dongguan, Guangdong, China. Photo 3 Photo 4 Page 3 of 5 FCC ID: 2AN3WCORES3 Dongguan Yaxu (AiT) Technology Limited No.22, Jinqianling 3rd Street, Jitigang, Huangjiang, Dongguan, Guangdong, China. Photo 5 Photo 6 Page 4 of 5 FCC ID: 2AN3WCORES3 Dongguan Yaxu (AiT) Technology Limited No.22, Jinqianling 3rd Street, Jitigang, Huangjiang, Dongguan, Guangdong, China. Photo 7 Photo 8 Page 5 of 5 FCC ID: 2AN3WCORES3 Dongguan Yaxu (AiT) Technology Limited No.22, Jinqianling 3rd Street, Jitigang, Huangjiang, Dongguan, Guangdong, China. Photo 9 Photo 10 ------End------

FCC ID Label FCC ID: 2AN3WCORES3

Page 1 of 4 FCC ID: 2AN3WCORES3 Dongguan Yaxu (AiT) Technology Limited No.22, Jinqianling 3rd Street, Jitigang, Huangjiang, Dongguan, Guangdong, China. Internal Photos Photo 1 Photo 2 Antenna Page 2 of 4 FCC ID: 2AN3WCORES3 Dongguan Yaxu (AiT) Technology Limited No.22, Jinqianling 3rd Street, Jitigang, Huangjiang, Dongguan, Guangdong, China. Photo 3 Photo 4 Page 3 of 4 FCC ID: 2AN3WCORES3 Dongguan Yaxu (AiT) Technology Limited No.22, Jinqianling 3rd Street, Jitigang, Huangjiang, Dongguan, Guangdong, China. Photo 5 Photo 6 Page 4 of 4 FCC ID: 2AN3WCORES3 Dongguan Yaxu (AiT) Technology Limited No.22, Jinqianling 3rd Street, Jitigang, Huangjiang, Dongguan, Guangdong, China. Photo 7 ------End------

ReportNo.: WSCT-A2LA-R&E230300001A-SAR Page 2 of 35 Table of contents 1 General information .......................................................................................................................................... 4 1.1 Notes ........................................................................................................................................................... 4 1.2 Application details ..................................................................................................................................... 4 1.3 Statement of Compliance .......................................................................................................................... 5 1.4 EUT Information ......................................................................................................................................... 6 2 Testing laboratory ............................................................................................................................................. 7 3 ACCREDITATIONS ............................................................................................................................................ 7 4 Test Environment .............................................................................................................................................. 7 5 Applicant and Manufacturer ............................................................................................................................ 7 6 Test standard/s: .................................................................................................................................................. 8 6.1 RF exposure limits ..................................................................................................................................... 9 6.2 SAR Definition ............................................................................................................................................ 9 7 SAR Measurement System .............................................................................................................................. 10 7.1 The Measurement System ...................................................................................................................... 10 7.2 Robot ......................................................................................................................................................... 11 7.3 Probe ......................................................................................................................................................... 11 7.4 Measurement procedure ......................................................................................................................... 13 7.5 Description of interpolation/extrapolation scheme .............................................................................. 13 7.6 Phantom .................................................................................................................................................... 14 7.7 Device Holder ........................................................................................................................................... 15 7.8 Video Positioning System ....................................................................................................................... 16 7.9 Tissue simulating liquids: dielectric properties ................................................................................... 17 7.10 Tissue simulating liquids: parameters .................................................................................................. 18 8 System Check .................................................................................................................................................. 19 8.1 System check procedure ........................................................................................................................ 19 8.2 System checkresults ............................................................................................................................... 20 9 SAR Test Test Configuration ......................................................................................................................... 21 9.1 Wi-Fi Test Configuration ....................................................................................................................... 21 ReportNo.: WSCT-A2LA-R&E230300001A-SAR Page 3 of 35 9.2 WiFi 5G SAR Test Procedures ................................................................................................................ 22 10 Detailed Test Results .............................................................................................................................. 24 10.1 Conducted Power measurements .......................................................................................................... 24 10.1.1 Conducted Power of Wi-Fi 2.4G ............................................................................................................. 24 10.1.2 Conducted Power of BLE ........................................................................................................................ 25 10.1.3 Tune-up powertolerance ......................................................................................................................... 25 10.2 SAR test results ....................................................................................................................................... 26 10.2.1 Results overview of Wi-Fi 2.4G .............................................................................................................. 27 11 Multiple Transmitter Information ............................................................................................................ 28 11.1.1 Stand-alone SAR test exclusion ......................................................................…

Text truncated - open the document above for the full version.

Page 1 of 35 Report No.: AIT23012901W1 Dongguan Yaxu (AiT) Technology Limited No.22, Jinqianling 3rd Street, Jitigang, Huangjiang, Dongguan, Guangdong, China. TEST REPORT Client Information: Applicant: M5Stack Technology Co., Ltd Applicant add.: 5F, Tangwei Stock Commercial Building, Youli Road, Bao’an District, Shenzhen, China Manufacturer: M5Stack Technology Co., Ltd Manufacturer add.: 5F, Tangwei Stock Commercial Building, Youli Road, Bao’an District, Shenzhen, China Product Information: Product Name: M5CoreS3 Model No.: CoreS3 Brand Name: M5STACK FCC ID: 2AN3WCORES3 Applicable standards: FCC CFR Title 47 Part 15 Subpart C Section 15.247 Prepared By: Dongguan Yaxu (AiT) Technology Limited No.22, Jinqianling 3rd Street, Jitigang, Huangjiang,Dongguan, Guangdong, China Tel.: +86-769-8202 0499 Fax.: +86-769-8202 0495 Date of Receipt: Jan. 29, 2023 Date of Test: Jan. 29, 2023~ Feb. 21, 2023 Date of Issue: Feb. 22, 2023 Test Result: Pass This device described above has been tested by Dongguan Yaxu (AiT) Technology Limited and the test results show that the equipment under test (EUT) is in compliance with the FCC requirements. And it is applicable only to the tested sample identified in the report. Note: This report shall not be reproduced except in full, without the written approval of Dongguan Yaxu (AiT) Technology Limited, this document may be altered or revised by Dongguan Yaxu (AiT) Technology Limited, personal only, and shall be noted in the revision of the document. This test report must not be used by the client to claim product endorsement. Reviewed by: Approved by: Simba Huang Seal.chen Page 2 of 35 Report No.: AIT23012901W1 Dongguan Yaxu (AiT) Technology Limited No.22, Jinqianling 3rd Street, Jitigang, Huangjiang, Dongguan, Guangdong, China. 1 Contents Page COVER PAGE 1 CONTENTS ......................................................................................................................................................................... 2 2 TEST SUMMARY ............................................................................................................................................................... 4 2.1 Statement of the Measurement Uncertainty ..................................................................................... 4 2.2 Measurement Uncertainty ................................................................................................................ 4 3 TEST FACILITY .................................................................................................................................................................. 5 3.1 Deviation from standard ................................................................................................................... 5 3.2 Abnormalities from standard conditions ............................................................................................ 5 3.3 Test Location .................................................................................................................................... 5 4 GENERAL INFORMATION .............................................................................................................................................. 6 4.1 Test frequencies ............................................................................................................................... 7 4.2 EUT Peripheral List .......................................................................................................................... 7 4.3 Test Peripheral List ........................................................................................................................... 7 4.4 TEST METHODOLOGY ................................................................................................................... 8 4.5 Description of Test Modes ................................................................................................................ 9 5 EQUIPMENT USED DURING TEST ............................................................................................................................. 10 6 TEST RESULTS AND MEASUREMENT DATA ......................................................................................................... 11 6.1 Antenna requirement ....................................................................................................................... 11 6.2 On Time and Duty Cycle ................................................................................................................ 12 6.3 Maximum Conducted Output Peak Power Measurement ............................................................... 13 6.4 6 dB Spectrum Bandwidth Measurement ....................................................................................... 14 6.5 Power Spectral Density .................................................................................................................. 15 6.6 Conducted Spurious Emissions and Band Edges Test ................................................................... 17 6.7 Restrict-band Band-edge Measurements ....................................................................................... 19 6.8 Radiated Emissions Measurement ................................................................................................. 22 6.9 Conducted Emissions..................................................................................................................... 32 7 TEST SETUP PHOTOGRAPHS OF EUT ..................................................................................................................... 35 8 EXTERNAL PHOTOGRAPHS OF EUT ........................................................................................................................ 35 9 INTERNAL PHOTOGRAPHS OF EUT ......................................................................................................................... 35 Page 3 of 35 Report No.: AIT23012901W1 Dongguan Yaxu…

Text truncated - open the document above for the full version.

Page 1 of 41 Report No.: AIT23012901W2 Dongguan Yaxu (AiT) Technology Limited No.22, Jinqianling 3rd Street, Jitigang, Huangjiang, Dongguan, Guangdong, China. TEST REPORT Client Information: Applicant: M5Stack Technology Co., Ltd Applicant add.: 5F, Tangwei Stock Commercial Building, Youli Road, Bao’an District, Shenzhen, China Manufacturer: M5Stack Technology Co., Ltd Manufacturer add.: 5F, Tangwei Stock Commercial Building, Youli Road, Bao’an District, Shenzhen, China Product Information: Product Name: M5CoreS3 Model No.: CoreS3 Brand Name: M5STACK FCC ID: 2AN3WCORES3 Applicable standards: FCC CFR Title 47 Part 15 Subpart C Section 15.247 Prepared By: Dongguan Yaxu (AiT) Technology Limited No.22, Jinqianling 3rd Street, Jitigang, Huangjiang,Dongguan, Guangdong, China Tel.: +86-769-8202 0499 Fax.: +86-769-8202 0495 Date of Receipt: Jan. 29, 2023 Date of Test: Jan. 29, 2023~ Feb. 21, 2023 Date of Issue: Feb. 22, 2023 Test Result: Pass This device described above has been tested by Dongguan Yaxu (AiT) Technology Limited and the test results show that the equipment under test (EUT) is in compliance with the FCC requirements. And it is applicable only to the tested sample identified in the report. Note: This report shall not be reproduced except in full, without the written approval of Dongguan Yaxu (AiT) Technology Limited, this document may be altered or revised by Dongguan Yaxu (AiT) Technology Limited, personal only, and shall be noted in the revision of the document. This test report must not be used by the client to claim product endorsement. Reviewed by: Approved by: Simba Huang Seal.chen Page 2 of 41 Report No.: AIT23012901W2 Dongguan Yaxu (AiT) Technology Limited No.22, Jinqianling 3rd Street, Jitigang, Huangjiang, Dongguan, Guangdong, China. 1 Contents Page COVER PAGE 1 CONTENTS ......................................................................................................................................................................... 2 2 TEST SUMMARY ............................................................................................................................................................... 5 2.1 Statement of the Measurement Uncertainty ..................................................................................... 5 2.2 Measurement Uncertainty ................................................................................................................ 5 3 TEST FACILITY .................................................................................................................................................................. 6 3.1 Deviation from standard ................................................................................................................... 6 3.2 Abnormalities from standard conditions ............................................................................................ 6 3.3 Test Location .................................................................................................................................... 6 4 GENERAL INFORMATION .............................................................................................................................................. 7 4.1 Test frequencies ............................................................................................................................... 8 4.2 EUT Peripheral List .......................................................................................................................... 8 4.3 Test Peripheral List ........................................................................................................................... 8 4.4 TEST METHODOLOGY ................................................................................................................... 9 4.5 Description of Test Modes .............................................................................................................. 10 5 EQUIPMENT USED DURING TEST ............................................................................................................................. 11 6 TEST RESULTS AND MEASUREMENT DATA ......................................................................................................... 12 6.1 Antenna requirement ...................................................................................................................... 12 6.1.1 Standard requirement: .......................................................................................................... 12 6.1.2 EUT Antenna: ....................................................................................................................... 12 6.2 On Time and Duty Cycle ................................................................................................................ 13 6.2.1 Standard requirement: .......................................................................................................... 13 6.2.2 Measuring Instruments and Setting: ..................................................................................... 13 6.2.3 Test Procedures ................................................................................................................... 13 6.2.4 Test Setup Layout ................................................................................................................ 13 6.2.5 EUT Operation during Test ................................................................................................... 13 6.2.6 Test result ............................................................................................................................. 13 6.3 Maximum Conducted Output Peak Power Measurement ............................................................... 14 6.3.1 Standard requirement: .......................................................................................................... 14 6.3.2 Measuring Instruments: ..................................................…

Text truncated - open the document above for the full version.

Date09/28/2018VersionNo.A 上海德门电子科技有限公司 1 上海德门电子科技有限公司 SHANGHAIDEMANELECTRONICSTECHNOLOGYCO.,LTD. 产品规格书 PRODUCTSPECIFICATION 客户 Customer 乐鑫 客户编码 Customer’spartnumber 产品料号 ProductMaterialCode TFPD07H09100011 工作频段 WorkingBand 2400-2500MHz 发行日期 IssueDate 2018-09-28 发行版本 ReleaseVersion A 作者 Author 汪龙 Date09/28/2018VersionNo.A 上海德门电子科技有限公司 2 1产品技术指标（PRODUCTTECHNICALSPECIFICATION） 电性能指标ElectricalSpecifications 频率范围FrequencyRange（MHz）2400-2500 频带宽度Bandwidth（MHz）100 输入阻抗InputImpendence（Ω）50 电压驻波比VSWR＜2.5 增益Gain（dBi）＞1.0 极化形式PolarizationType垂直极化Vertical 机械指标MechanicalSpecifications 天线长度AntennaLength（mm）13.75mm 连接方式ConnectionMode焊接Welding 工作温度OperatinTemp（°C）-30～70 储存温度StoringTemp(°C)-30～70 外壳颜色RadomeColor银色Silver 2产品电性能参数（PRODUCTELECTRICALPERFORMANCEPARAMETER） 2.1产品图片（Productpicture） 2.2反射损耗（S11） Date09/28/2018VersionNo.A 上海德门电子科技有限公司 3 2.3驻波比(VSWR) 2.4史密斯图（SmithChart） Date09/28/2018VersionNo.A 上海德门电子科技有限公司 4 2.5效率、增益（Efficiency/Gain） Freq.(MHz)Gain(dBi)Effi.(%) 24001.9456.04 24102.0257.32 24202.3961.25 24302.4661.67 24402.4263.55 24502.2663.16 24602.3063.47 24702.1062.04 24802.2361.82 24901.9659.30 25001.8556.17 Avg.2.1760.52 Date09/28/2018VersionNo.A 上海德门电子科技有限公司 5 3产品尺寸（Productdimensions）

Dongguan Yaxu(AiT) Technology Limited Report No.: AIT23012901W1 FCC ID: 2AN3WCORES3 Page 1 of 35 Appendix B RF Test Data for BLE (Conducted Measurement) Product Name: M5CoreS3 Trade Mark: M5STACK Test Model: CoreS3 Environmental Conditions Temperature: 25.9 C Relative Humidity: 51.8% ATM Pressure: 100.0 kPa Test Engineer: Simba Huang Supervised by: Seal Chen Dongguan Yaxu(AiT) Technology Limited Report No.: AIT23012901W1 FCC ID: 2AN3WCORES3 Page 2 of 35 Contents Page COVER PAGE 1 Duty Cycle .................................................................................................................................................................................................. 3 1.1 Test Result ....................................................................................................................................................................................... 3 1.2 Test Graphs ..................................................................................................................................................................................... 4 2 Maximum Conducted Output Power .......................................................................................................................................................... 7 2.1 Test Result ....................................................................................................................................................................................... 7 2.2 Test Graphs ..................................................................................................................................................................................... 8 3 -6dB Bandwidth ........................................................................................................................................................................................ 11 3.1 Test Result ..................................................................................................................................................................................... 11 3.2 Test Graphs ................................................................................................................................................................................... 12 4 Maximum Power Spectral Density Level ................................................................................................................................................. 15 4.1 Test Result ..................................................................................................................................................................................... 15 4.2 Test Graphs ................................................................................................................................................................................... 16 5 Band Edge ..........................................................…

Text truncated - open the document above for the full version.
