2AN8FMSL-M9012Bluetooth speaker with RGB

Instruction Manual (M9012) IPX7 Outdoor Bluetooth Speaker with Colorful LED Light ① ② ③ ④ ⑤ 1x IPX7 Bluetooth Speaker with Colorful LED Light 1x USB to Type C Charging Cable 1x Instruction Manual 1.Vol+/Next Track 2.Power ON/OFF 3.Vol-/Previous Track 4.Bluetooth LED Indicator 5.Type C input • • • • • • • • • What’s included: : Functions: Size:Ф90*180mm Material:ABS+Woven cloth Waterproof level:IPX7 Playing time:up to 3 hours at max volume Charging time:up to 2 hours Pairing Name:MSL-M9012 The interface type:USB-C Battery capacity:4000mAh Type C input: 5V1A • ** • • Frequency:80Hz-20KHz Speaker driver: 4Ω,5Wx2 LED light power:0.2Wx6 Lanyard length: 12cm (Be sure to fully charge the speaker before using for the first time) Charging the Speaker: Connect the provided charging cable to a power source and to the Type-C port (5) on the speaker. The RED LED light(4) will turn on when the speaker is being charged. When the speaker is fully charged the RED LED light (4) will change to GREEN Bluetooth® Setup: Press and hold Speaker ON/OFF Button(2) to turn ON the speaker, Bluetooth LED indicator(4) will flash BLUE. Turn on the Bluetooth function on mobile device, Select “M9012”pairing name. LED will turn solid BLUE if successfully paired. Speaker will automatically pair if the mobile device has been paired before. Press and hold Speaker ON/OFF Button(2) to turn off the device. Using the Speaker: When receiving a phone call, press ON/OFF button to answer and again to hang up. Double press to redial the last call. “Vol+/Next track” (1):Long press - next track.Short press - increase volume. “Vol-/Previous track” (3): Long press - previous track Short press - reduce volume LED rhythm light: LED light rhythmically flashes according to volume and rhythm.After the speaker is turn on,press ON/OFF Button(2) twice,the LED light will be turn off. 1. 2. 3. Instructions: When the speaker is playing the music,short press the ON/OFF Button(2) to pause the music playing. When the bluetooth is not paired, the device will automatically shut down after standby for more than 5 minutes, and the LED indicator light (4)will be turned off. MADE IN CHINA * SAFETY PRECAUTIONS: WARNING-When using this product, basic precautions should always be followed: 1. Read all the instructions before use. 2. Never store or use this product in temperatures below 32°F (0°C) or above 115°F (45°C). 3. Do not overcharge Phone. Unit may get hot with excessive use. Remove Phone when it is fully charged. Never charge for more than 7 hours at a time. 4. The unit’s full performance is achieved only after 2 or 3 completed charge and discharge cycles. 5. To reduce the risk of injury, close supervision is necessary when the product is used near children. 6. Do not use the device in excess of its output rating. Overload outputs above rating may result in a risk of fire or injury.rating may result in a risk of fire or injury. 7. Do not use the device if damaged or modified. 8. Damaged or motified batteries may exhibit unpredictable behavior resulting in fire,explosion or risk of injury. 9. Do not disassemble the device. for repairs,seek a qualified service professional. incorrect reassembly may result in a risk of fire or injury. 10.Do not expose the device to fire or temperatures above 104°F may cause explosion. 11.Ensure that qualified service professionals use only identical replacement parts to ensure product safety. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference. (2) This device must accept any interference received, including interference that may cause undesired operation. FCC Statement: Warning: Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. 107 mm 322 mm 79 mm FCC Caution： This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Any Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: -Reorient or relocate the receiving antenna. -Increase the separation between the equipment and receiver. -Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. -Consult the dealer or an experienced radio/TV technician for help. The device has been evaluated to meet general RF exposure requirement. The device can be used in portable exposure condition without restriction.

ShenZhen Mossloo Industrial Co.,Ltd 2022.06.14 Eurofins Electrical and Electronic Testing NA, Inc. 914 W. Patapsco Avenue Baltimore, MD 21230 USA RE: CONFIDENTIALITY REQUEST FOR EUT NAME: Bluetooth speaker with RGB MODEL : MSL-M9012 FCC ID: 2AN8FMSL-M9012 To Whom It May Concern: This letter serves as an official request for confidentiality under sections 0.457 and 0.459 of CFR 47. We have requested that the - Block Diagram - Schematics - Operational Description required to be submitted with this application be permanently withheld from public review. The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. Please contact me if there is any information you may need. Sincerely, Client’s signature: Client’s name / title : Orders Cheng /Manager Contact information / address: Road One No.4, Science Industrial Park, Shangxue Village, Bantian Street, Longgang District, Shenzhen, China

ShenZhen Mossloo Industrial Co.,Ltd 2022.06.14 Eurofins Electrical and Electronic Testing NA, Inc. 914 W. Patapsco Avenue Baltimore, MD 21230 USA RE: LETTER OF AGENT AUTHORIZATION To Whom It May Concern: We, the undersigned, hereby authorize Shenzhen BCTC Testing Co., Ltd to act on our behalf in all matters relating to application for equipment authorization, including the signing of all documents relating to these matters. We also hereby certify that no party to the application authorized hereunder is subject to the denial of benefits, including FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C.853(a). This agreement expires one year from the current date. Sincerely, Client’s signature: Client’s name / title : Orders Cheng /Manager Contact information / address: Road One No.4, Science Industrial Park, Shangxue Village, Bantian Street, Longgang District, Shenzhen, China

External Photos

Size:10*5m FCC ID: 2AN8FMSL-M9012 Label Location

Internal Photos Antenna

Shenzhen BCTC Testing Co., Ltd. FCC ID: 2AN8FMSL-M9012 Portable device According to §15.247(e)(i) and §1.1307(b)(1), systems operating under the provisions of this section shall be operated in a manner that ensures that the public is not exposed to radio frequency energy level in excess of the Commission’s guidelines. According to KDB447498 D01 General RF Exposure Guidance V06 The 1-g SAR and 10-g SAR test exclusion thresholds for 100 MHz to 6 GHz at test separation distances ≤ 50 mm are determined by: [(max. power of channel, including tune-up tolerance, mW)/(min. test separation distance, mm)]·[√f(GHZ)] ≤ 3.0 for 1-g SAR and ≤ 7.5 for 10-g extremity SAR, where: • f(GHZ) is the RF channel transmit frequency in GHz • Power and distance are rounded to the nearest mW and mm before calculation • The result is rounded to one decimal place for comparison When the minimum test separation distance is < 5 mm, a distance of 5 mm is applied to determine SAR test exclusion. Modulation Channel Freq. (GHz) Conducte d power (dBm) Conducte d power (mW) Tune-up power (dBm) Max tune-up power (dBm) Max tune-up power (mW) Distance (mm) Result calculatio n SAR Exclusion threshold SAR test exclusion GFSK2.480-8.490.14-8±1-7.000.20<50.062843.00YES Pi/4 DQPSK 2.480-7.590.17-7±1-6.000.25<50.079113.00YES 8DPSK2.441-7.030.20-7±1-6.000.25<50.078493.00YES Conclusion: For the max result : 0.07911＜3.0, the SAR testing is not required.

No.：BCTC/RF-EMC-005 Page 1 of 83 Edition：A.4 TEST REPORT Shenzhen BCTC Testing Co., Ltd. Report No.: BCTC2206449087E Applicant: Shenzhen Mossloo Industrial Co.,Ltd Product Name: Bluetooth speaker with RGB Model/Type Ref.: MSL-M9012 Tested Date: 2022-05-30 to 2022-06-10 Issued Date: 2022-06-13 Report No.: BCTC2206449087E No.：BCTC/RF-EMC-005 Page 2 of 83 Edition：A.4 FCC ID: 2AN8FMSL-M9012 The test report is effective only with both signature and specialized stamp. This result(s) shown in this report refer only to the sample(s) tested. Without written approval of Shenzhen BCTC Testing Co., Ltd, this report can’t be reproduced except in full. The tested sample(s) and the sample information are provided by the client. Product Name: Bluetooth speaker with RGB Trademark: N/A Model/Type Ref.: MSL-M9012 Prepared For: Shenzhen Mossloo Industrial Co.,Ltd Address: Road One No.4, Science Industrial Park, Shangxue Village, Bantian Street, Longgang District, Shenzhen, China Manufacturer: Shenzhen Mossloo Industrial Co.,Ltd Address: Road One No.4, Science Industrial Park, Shangxue Village, Bantian Street, Longgang District, Shenzhen, China Prepared By: Shenzhen BCTC Testing Co., Ltd. Address: 1-2/F., Building B, Pengzhou Industrial Park, No.158, Fuyuan 1st Road, Tangwei, Fuhai Subdistrict, Bao'an District, Shenzhen, Guangdong, China Sample Received Date: 2022-05-30 Sample tested Date: 2022-05-30 to 2022-06-10 Issue Date: 2022-06-13 Report No.: BCTC2206449087E Test Standards: FCC Part15.247 ANSI C63.10-2013 Test Results: PASS Remark: This is Bluetooth Classic radio test report. Tested by: Approved by: Eric Yang/Project Handler Zero Zhou/Reviewer Report No.: BCTC2206449087E No.：BCTC/RF-EMC-005 Page 3 of 83 Edition：A.4 Table Of Content Test Report Declaration Page 1. Version .................................................................................................................. 5 2. Test Summary ....................................................................................................... 6 3. Measurement Uncertainty ..................................................................................... 7 4. Product Information And Test Setup ..................................................................... 8 4.1 Product Information ............................................................................................... 8 4.2 Test Setup Configuration ...................................................................................... 8 4.4 Channel List .......................................................................................................... 9 4.5 Test Mode ............................................................................................................. 9 4.6 Table Of Parameters Of Text Software Setting ..................................................... 9 5. Test Facility And Test Instrument Used ............................................................... 10 5.1 Test Facility ......................................................................................................... 10 5.2 Test Instrument Used .......................................................................................... 10 6. Conducted Emissions .......................................................................................... 12 6.1 Block Diagram Of Test Setup .............................................................................. 12 6.2 Limit .................................................................................................................... 12 6.3 Test Procedure ................................................................................................... 12 6.4 EUT Operating Conditions .................................................................................. 13 6.5 Test Result .......................................................................................................... 14 7. Radiated Emissions ............................................................................................. 16 7.1 Block Diagram Of Test Setup .............................................................................. 16 7.2 Limit .................................................................................................................... 17 7.3 Test Procedure ................................................................................................... 18 7.4 EUT Operating Conditions .................................................................................. 19 7.5 Test Result .......................................................................................................... 19 8. Radiated Band Emission Measurement And Restricted Bands Of Operation ..... 23 8.1 Block Diagram Of Test Setup .............................................................................. 23 8.2 Limit .................................................................................................................... 23 8.3 Test Procedure ................................................................................................... 24 8.4 EUT Operating Conditions .................................................................................. 24 8.5 Test Result .......................................................................................................... 25 9. Conducted Emission ........................................................................................... 26 9.1 Block Diagram Of Test Setup .............................................................................. 26 9.2 Limit .................................................................................................................... 26 9.3 Test Procedure ................................................................................................... 26 9.4 Test Result .......................................................................................................... 27 10. 20 DB Bandwidth ..............................…

Text truncated - open the document above for the full version.

Conducted Measurement Photo Radiated Measurement Photos
