2ANDL-CB3LWi-Fi and Bluetooth Module

CB3LModuleDatasheet Version:20210507 OnlineVersion Contents i Contents 1Productoverview2 1.1Features...................................................................................................2 1.2Applications.........................................................................................................3 2Moduleinterfaces4 2.1Dimensionsandpackage.............................................................................4 2.2Pindefinition........................................................................................................4 3Electricalparameters7 3.1Absoluteelectricalparameters.....................................................................7 3.2Normalworkingconditions.................................................................................7 3.3RFpowerconsumption.......................................................................................8 3.4Workingcurrent...........................................................................................8 4RFparameters10 4.1BasicRFfeatures.......................................................................................10 4.2Wi-Fitransmissionperformance.......................................................................10 4.3Wi-Fireceivingperformance............................................................................11 4.4Bluetoothtransmissionperformance.........................................................12 4.5Bluetoothreceivingperformance..............................................................12 5Antennainformation12 5.1Antennatype..............................................................................................12 5.2Antennainterferencereduction.................................................................13 6Packaginginformationandproductioninstructions14 6.1Mechanicaldimensions.............................................................................14 6.2Sideview............................................................................................................15 6.3Theschematicdiagramofpackaging........................................................16 6.4ThediagramofPCBpackaging-pinheader.....................................................16 6.5Productioninstructions..............................................................................17 6.6Recommendedoventemperaturecurve....................................................19 6.7Storageconditions.....................................................................................22 Contents ii 7MOQandpackaginginformation23 8Appendix-Statement23 1/25 Contents CB3Lisanembeddedlow-powerWi-FimodulethatTuyahasdeveloped.Itconsistsof ahighlyintegratedRFchipBK7231Nandafewperipherals.CB3Lnotonlysupports theWi-FiAPandSTAmodes,butalsosupportstheBluetoothLE. 1PRODUCTOVERVIEW 2 /25 1Productoverview CB3Lisbuiltinwitha32-bitMCUwhoserunningspeedcanbeupto120MHz,a2-MB flashmemory,anda256-KBRAM,soastosupporttheTuyacloudconnection.The MCUinstructionsspeciallyextendedforsignalprocessingcaneffectivelyimplement audioencodinganddecoding.Besides,ithasrichperipherals,suchasPWM,UART andSPI.Therearesix32-bitPWMoutputs,makingthechipverysuitableforhigh- qualityLEDcontrol. 1.1Features •Builtinwiththelow-power32-bitCPU,whichcanalsofunctionasanapplication processor •Theclockrate:120MHz •Workingvoltage:3.0to3.6V •Peripherals:7GPIOs,1UART,and1ADC •Wi-Ficonnectivity –802.11b/g/n – [email protected] – SupportWEP,WPA/WPA2,andWPA/WPA2PSK(AES)securitymodes – Upto+16dBmoutputpowerin802.11bmode –SupportSTA/AP/STA+APworkingmode –SupportWi-FiandhotspotnetworkconfigurationmannersforAndroidand iOSdevices – OnboardPCBantennawithagainof2.4dBi – Workingtemperature:-40°Cto105°C •Bluetoothconnectivity –SupporttheBluetoothLEV5.1 – Supportthetransmitpowerof6dBminBluetoothmode –CompleteBluetoothcoexistenceinterface – OnboardPCBantennawithagainof2.4dBi 1PRODUCTOVERVIEW 3 /25 1.2Applications •Intelligentbuilding •Smarthouseholdandhomeappliances •Smartsocketandlight •Industrialwirelesscontrol •Babymonitor •Networkcamera •Intelligentbus 2MODULEINTERFACES 4 /25 2Moduleinterfaces 2.1Dimensionsandpackage CB3Lhastworowsofpinswithaspacingof2±0.1mm. TheCB3Ldimensionsare16±0.35mm(W)×24±0.35mm(L)×2.8±0.15mm(H). 2.2Pindefinition PinnumberSymbolI/OtypeFunction 1RSTI/OResetpin, effectivecurrently 2ADCAIADC,which correspondsto P23oftheIC 2MODULEINTERFACES 5 /25 PinnumberSymbolI/OtypeFunction 3ENIEnablingpin,the modulehasbeen pulledup 4P14I/OGeneralI/Opin 5P26I/OSupporthardware PWMand correspondtoP26 ontheinternalIC 6P24I/OSupporthardware PWMand correspondtoP24 ontheinternalIC 7P6I/OSupporthardware PWMand correspondtoP6 ontheinternalIC 8VCCPPowersupplypin (3.3V) 9GNDPPowersupply referenceground 10P9I/OSupporthardware PWMand correspondtoP9 ontheinternalIC 11TXD2I/OUART2_TX, debug_log_Uart correspondstoP0 oftheIC 2MODULEINTERFACES 6 /25 PinnumberSymbolI/OtypeFunction 12CSNI/OItisnot recommendedfor customers.Ifyou needtouseit, makesurethat thelevelofthe CSNpinremains highbefore poweringon.The pincorresponds toP21oftheIC. 13P8I/OSupporthardware PWMand correspondtoP8 ontheinternalIC 14P7I/OSupporthardware PWMand correspondtoP7 ontheinternalIC 15RXD1I/OUserserial interface UART_RX,which correspondsto P10oftheIC 16TXD1I/OUserserial interface UART_TX,which correspondsto P11oftheIC Note:PindicatesapowersupplypinandI/Oindicatesaninput/outputpin. 3ELECTRICALPARAMETERS 7 /25 3Electricalparameters 3.1Absoluteelectricalparameters ParameterDescription Minimum value Maximum valueUnit TsStorage-55125°C temperature VBATPowersupply-0.33.9V voltage StaticTAMB-25°C-44KV electricity discharge voltage (humanbody model) StaticTAMB-25°C-200200V electricity discharge voltage (machine model) 3.2Normalworkingconditions ParameterDescription Minimum value Typical value Maximum valueUnit TaWorking tempera- ture -40-105°C VBATPower supply voltage 33.33.6V 3ELECTRICALPARAMETERS 8 /25 ParameterDescription Minimum value Typical value Maximum valueUnit VOLI/Olow level output…

Text truncated - open the document above for the full version.

Company: Hangzhou Tuya Information Technology Co.,Ltd Address: Room701,Building3,More Center,No.87 GuDun Road, Hangzhou,Zhejiang, China Tel: 86-571-86581786 Fax: 86-571-86581786 Date (03/05/2021) TUV SUD BABT UNLIMITED TCB Octagon House, Segensworth North, Fareham, Hampshire, PO15 5RL, United Kingdom Confidentiality Request FCC ID: 2ANDL-CB3L Pursuant to Sections 0.457(d)(1)(ii) and 0.459 of the Commission’s Rules, (Hangzhou Tuya Information Technology Co.,Ltd) hereby requests permanent confidential treatment of information accompanying this application as outlined below: Schematics Block Diagrams Theory of Operation The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. The Applicant understands that pursuant to Rule 0.457(d)(1)(ii), disclosure of this Application and all accompanying materials will not be made before the date of the Grant for this Application. Yours sincerely, Company Officer: Telephone Number: 86-571-86581786 Email: [email protected]

Company: Hangzhou Tuya Information Technology Co.,Ltd Address: Room701,Building3,More Center,No.87 GuDun Road, Hangzhou,Zhejiang, China Tel: 86-571-86581786 Fax: 86-571-86581786 Date (01/03/2020) TUV SUD BABT UNLIMITED TCB Octagon House, Segensworth North, Fareham, Hampshire, PO15 5RL, United Kingdom Dear Sir or Madam, We, (Hangzhou Tuya Information Technology Co.,Ltd ；Room701,Building3,More Center,No.87 GuDun Road, Hangzhou, Zhejiang, China), hereby authorize Jiaxi XU from TÜV SÜD Certification and Testing (China) Co., Ltd. Shanghai Branch 3-13, No.151 Heng Tong Road Shanghai 201108 P.R. China to act as our agent in all matters relating to applications for equipment authorization, including the signing of all documents relating to these matters. This authorization expires on (Dec. 31, 2021). Sincerely, Company Officer: Shou XiaoDong Telephone Number: 86-571-86581786 Email: [email protected]

Company: Hangzhou Tuya Information Technology Co.,Ltd Address: Room701,Building3,More Center,No.87 GuDun Road, Hangzhou,Zhejiang, China Tel: 86-571-86581786 Fax: 86-571-86581786 WIFI Channel 12 ,13 and 14 Declaration Letter We declare the equipment identified below with regards to Channel 12,13 and 14 capabilities for FCC ID: 2ANDL-CB3L Declaration Product hardware does not have the capability to operate on Channel 12,13 and 14. Product hardware has the capability to operate on Channel 12 ,13 and 14. However, these three channels will be disabled via software and will not be accessible to user. Product hardware has the capability to operate on Channel 12 ,13 and 14. However, all the operated channels can’t be changed in the RF parameter via software. All channels have complied with all of the requirements sets out in FCC Part 15.247. Product hardware has the capability to operate on WiFi Channel 12 ,13 and 14, and meets the requirements of KDB 594280 D01 v02r01. Please note: 1.) By default, this device operates in a mode that is compliant with the U.S. requirements. 2.) This device will also use supplemental information such as geo-location data to determine that it is operating outside the U.S., if necessary, to change its power. Such supplemental data will be derived from the following: Global Navigation Satellite System (GNSS)7 sensors in the device Mobile Country Code (MCC),8 or MCC with a Mobile Network code (MNC), received from a CMRS9 carrier and received directly by a receiver on the device Country information derived from multiple adjacent access points (for example using IEEE Std 802.11d provisions) may be permitted on case-by-case basis Other suitable geo-location data based on IP addresses or other reliable source. Name / Title: / General Manager Signature: Phone: 86-571-86581786 Email: [email protected] Date: Dec 18,2019

Company: Hangzhou Tuya Information Technology Co.,Ltd Address: Room701,Building3,More Center,No.87 GuDun Road, Hangzhou,Zhejiang, China Tel: 86-571-86581786 Fax: 86-571-86581786 Date (03/05/2021) Federal Communications Commission Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 Modular Approval Request FCC ID: 2ANDL-CB3L The following attestation addresses the requirements to support modular approval: Modular approval requirement Yes (provide brief statement) No * (a) The radio elements must have the radio frequency circuitry shielded. Physical components and tuning capacitor(s) may be located external to the shield, but must be on the module assembly The module has a metal shied. Refer to the external photo of EUT. (b) The module must have buffered modulation/data inputs to ensure that the device will comply with Part 15 requirements with any type of input signal Data to the modulation circuit is buffered as described in the operational description provided with the application. (c) The module must contain power supply regulation on the module The module contains its own power supply regulation. Please refer to schematic filed with this application. (d) The module must contain a permanently attached antenna, or The module has a PCB antenna and which permanently attached Company: Hangzhou Tuya Information Technology Co.,Ltd Address: Room701,Building3,More Center,No.87 GuDun Road, Hangzhou,Zhejiang, China Tel: 86-571-86581786 Fax: 86-571-86581786 contain a unique antenna connector, and be marketed and operated only with specific antenna(s), per Sections 15.203, 15.204(b), 15.204(c), 15.212(a), 2.929(b) the module. Refer to the photo of EUT. (e) The module must demonstrate compliance in a stand-alone configuration The module was tested stand- alone as shown in test setup photographs filed with this application. (f) The module must be labelled with its permanently affixed FCC ID label, or use an electronic display (See KDB Publication 784748 about labelling requirements) The FCC ID is printed on the label of the module. Refer to the label of EUT. (g) The module must comply with all specific rules applicable to the transmitter. The grantee must provide comprehensive instructions to explain compliance requirements The module complied with all specific rules. Refer to the datasheet. Modular approval requirement Yes (provide brief statement) No * (h) The module must comply with RF exposure requirements Please refer exhibition RF Exposure for the compliance of MPE RF exposure rule. * Please provide a detailed explanation if the answer is “No.” Yours sincerely, Name: Title: General Manager

External Photos Documentation Manufacturer: Hangzhou Tuya Information Technology Co.,Ltd Page 1 of 1 Product: Wi-Fi and Bluetooth module FCC ID: 2ANDL-CB3L Antenna

Label & Location

Internal Photos Documentation Manufacturer: Hangzhou Tuya Information Technology Co.,Ltd Page 1 of 1 Product: Wi-Fi and Bluetooth module FCC ID: 2ANDL-CB3L

Report No: 709502102938-00A EMC_SHA_F_R_02.06E TÜV SÜD Certification and Testing (China) Co., Ltd. Shanghai Branch 3-13, No.151, Heng Tong Road, Shanghai, 200070, P.R. China Phone: +86 21 61410123, Fax:+86 21 61408600 Page 1 of 2 Rev. 20.00 MPE Calculation Applicant: Hangzhou Tuya Information Technology Co.,Ltd Address: Room701,Building3,More Center,No.87 GuDun Road,Hangzhou,Zhejiang China Product: Wi-Fi and Bluetooth Module FCC ID: 2ANDL-CB3L Model No.: CB3L Reference RF report # 709502102938-00; 709502102939-00 According to subpart 15.247(i) and subpart §1.1307(b)(1), systems operating under the provisions of this section shall be operated in a manner that ensures that the public is not exposed to radio frequency energy level in excess of the Commission’s guidelines. Limits for Maximum Permissible Exposure (MPE) (§1.1310, §2.1091) (B) Limits for General Population/Uncontrolled Exposure Frequency Range (MHz) Electric Field Strength (V/m) Magnetic Field Strength (A/m) Power Density (mW/cm 2 ) Averaging Time (minutes) 0.3–1.34 614 1.63 *(100) 30 1.34–30 824/f 2.19/f *(180/f²) 30 30–300 27.5 0.073 0.2 30 300–1,500 / / f/1500 30 1,500–100,000 / / 1.0 30 f = frequency in MHz; * = Plane-wave equivalent power density; According to §1.1310 and §2.1091 RF exposure is calculated. Calculated Formulary: Predication of MPE limit at a given distance S = PG/4πR² = power density (in appropriate units, e.g. mW/cm 2 ); P = power input to the antenna (in appropriate units, e.g., mW); G = power gain of the antenna in the direction of interest relative to an isotropic radiator, the power gain factor, is normally numeric gain; R = distance to the center of radiation of the antenna (appropriate units, e.g., cm); Report No: 709502102938-00A EMC_SHA_F_R_02.06E TÜV SÜD Certification and Testing (China) Co., Ltd. Shanghai Branch 3-13, No.151, Heng Tong Road, Shanghai, 200070, P.R. China Phone: +86 21 61410123, Fax:+86 21 61408600 Page 2 of 2 Rev. 20.00 Calculated Data: FPC Antenna For 2.4GHz Wi-Fi (Report number: 709502102915-00) Maximum peak output power at antenna input terminal (dBm): 23.18 Maximum peak output power at antenna input terminal (mW): 207.97 Prediction distance (cm): 20 Antenna Gain, typical (dBi): 2.4 Maximum Antenna Gain (numeric): 1.74 The worst case is power density at predication frequency at 20 cm (mW/cm 2 ): 0.0719 MPE limit for general population exposure at prediction frequency (mW/cm 2 ): 1.00 The max power density 0.0719 (mW/cm2) < 1 (mW/cm2) Result: Compliant For 2.4GHz BLE (Report number: 709502102919-00) Maximum peak output power at antenna input terminal (dBm): 7.13 Maximum peak output power at antenna input terminal (mW): 5.16 Prediction distance (cm): 20 Antenna Gain, typical (dBi): 2.4 Maximum Antenna Gain (numeric): 1.74 The worst case is power density at predication frequency at 20 cm (mW/cm 2 ): 0.0018 MPE limit for general population exposure at prediction frequency (mW/cm 2 ): 1.00 The max power density 0.0018 (mW/cm2) < 1 (mW/cm2) Result: Compliant - TÜV SÜD Certification and Testing (China) Co., Ltd. Shanghai Branch Reviewed by: Prepared by: Tested by: _____________________ _____________________ ______________________ Hui TONG Wenqiang LU Jiaxi XU EMC Section Manager EMC Project Engineer EMC Test Engineer Date: 05-10, 2021 Date: 05-10, 20201 Date: 05-10, 2021

EMC_SHA_F_R_02.10E TÜV SÜD Certification and Testing (China) Co., Ltd. Shanghai Branch 3-13, No.151, Heng Tong Road, Shanghai, 200070, P.R. China Phone: +86 21 61410123, Fax:+86 21 61408600 Page 1 of 35 Rev. 20.00 FCC - TEST REPORT Report Number : 709502102939-00 Date of Issue: May 11, 2021 Model : CB3L Product Type : Wi-Fi and Bluetooth module Applicant : Hangzhou Tuya Information Technology Co.,Ltd Address : Room701,Building3,More Center,No.87 GuDun Road,Hangzhou,Zhejiang China Manufacturer : Hangzhou Tuya Information Technology Co.,Ltd Address : Room701,Building3,More Center,No.87 GuDun Road,Hangzhou,Zhejiang China Test Result : ◼ Positive  Negative Total pages including Appendices : 35 TÜV SÜD Certification and Testing (China) Co., Ltd. Shanghai Branch is a subcontractor to TÜV SÜD Product Service GmbH according to the principles outlined in ISO 17025. TÜV SÜD Certification and Testing (China) Co., Ltd. Shanghai Branch reports apply only to the specific samples tested under stated test conditions. Construction of the actual test samples has been documented. It is the manufacturer's responsibility to assure that additional production units of this model are manufactured with identical electrical and mechanical components. The manufacturer/importer is responsible to the Competent Authorities in Europe for any modifications made to the production units which result in non-compliance to the relevant regulations. TÜV SÜD Certification and Testing (China) Co., Ltd. Shanghai Branch shall have no liability for any deductions, inferences or generalizations drawn by the client or others from TÜV SÜD Certification and Testing (China) Co., Ltd. Shanghai Branch issued reports. This report is the confidential property of the client. As a mutual protection to our clients, the public and ourselves, extracts from the test report shall not be reproduced except in full without our written approval. Report Number: 709502102939-00 EMC_SHA_F_R_02.10E TÜV SÜD Certification and Testing (China) Co., Ltd. Shanghai Branch 3-13, No.151, Heng Tong Road, Shanghai, 200070, P.R. China Phone: +86 21 61410123, Fax:+86 21 61408600 Page 2 of 35 Rev. 20.00 1 Table of Contents 1 Table of Contents .................................................................................................................. 2 2 Details about the Test Laboratory .......................................................................................... 3 3 Description of the Equipment under Test ............................................................................... 4 4 Summary of Test Standards .................................................................................................. 5 5 Summary of Test Results ...................................................................................................... 6 6 General Remarks .................................................................................................................. 7 7 Test Setups ........................................................................................................................... 8 8 Systems test configuration ................................................................................................... 11 9 Technical Requirement ........................................................................................................ 12 9.1 Conducted Emission ..................................................................................................... 12 9.2 Conducted peak output power ...................................................................................... 15 9.3 6dB bandwidth .............................................................................................................. 17 9.4 Power spectral density .................................................................................................. 19 9.5 Spurious RF conducted emissions ............................................................................... 21 9.6 Band edge .................................................................................................................... 25 9.7 Spurious radiated emissions for transmitter .................................................................. 27 10 Test Equipment List .......................................................................................................... 32 11 System Measurement Uncertainty ................................................................................... 33 12 Photographs of Test Set-ups ............................................................................................ 34 13 Photographs of EUT ........................................................................................................ 35 Report Number: 709502102939-00 EMC_SHA_F_R_02.10E TÜV SÜD Certification and Testing (China) Co., Ltd. Shanghai Branch 3-13, No.151, Heng Tong Road, Shanghai, 200070, P.R. China Phone: +86 21 61410123, Fax:+86 21 61408600 Page 3 of 35 Rev. 20.00 2 Details about the Test Laboratory Details about the Test Laboratory Test Site 1 Company name: TÜV SÜD Certification and Testing (China) Co., Ltd. Shanghai Branch No.16 Lane, 1951 Du Hui Road, Shanghai 201108, P.R. China Test Firm FCC Registration Number: 820234 Test Firm IC Registration Number: 25988 Telephone: +86 21 6141 0123 Fax: +86 21 6140 8600 Report Number: 709502102939-00 EMC_SHA_F_R_02.10E TÜV SÜD Certification and Testing (China) Co., Ltd. Shanghai Branch 3-13, No.151, Heng Tong Road, Shanghai, 200070, P.R. China Phone: +86 21 61410123, Fax:+86 21 61408600 Page 4 of 35 Rev. 20.00 3 Description of the Equipment under Test Description of the Equipment Under Test Product: Wi-Fi and Bluetooth module Model no.: CB3L FCC ID: 2ANDL-CB3L Options and accessories: NA Rating: DC 3.0-3.6V RF Transmission Frequency: For 802.11b/g/n-HT20: 2412~2462 MHz For 802.11n-HT40: 2422~2452 MHz For 802.15.1:2402~2480 MHz No. of Operated Channel: 2.4GHz Wi-Fi: 11 for 802.11b/802.11g/802.11…

Text truncated - open the document above for the full version.

EMC_SHA_F_R_02.10E TÜV SÜD Certification and Testing (China) Co., Ltd. Shanghai Branch 3-13, No.151, Heng Tong Road, Shanghai, 200070, P.R. China Phone: +86 21 61410123, Fax:+86 21 61408600 Page 1 of 55 Rev. 20.00 FCC - TEST REPORT Report Number:709502102938-00Date of Issue:May 8, 2021 Model:CB3L Product Type:Wi-Fiand Bluetooth module Applicant:Hangzhou Tuya Information Technology Co.,Ltd Address:Room701,Building3,More Center,No.87 GuDun Road,Hangzhou,Zhejiang China Manufacturer:Hangzhou Tuya Information Technology Co.,Ltd Address:Room701,Building3,More Center,No.87 GuDun Road,Hangzhou,Zhejiang China TestResult:PositiveNegative Total pages including Appendices:55 TÜV SÜD Certification and Testing (China) Co., Ltd. Shanghai Branch is a subcontractor to TÜV SÜD Product Service GmbH according to the principles outlined in ISO 17025. TÜV SÜD Certification and Testing (China) Co., Ltd. Shanghai Branch reports apply only to the specific samples tested under stated test conditions. Construction of the actual test samples has been documented. It is the manufacturer's responsibility to assure that additional production units of this model are manufactured with identical electrical and mechanical components. The manufacturer/importer is responsible to the Competent Authorities in Europe for any modifications made to the production units which result in non-compliance to the relevant regulations. TÜV SÜD Certification and Testing (China) Co., Ltd. Shanghai Branch shall have no liability for any deductions, inferences or generalizations drawn by the client or others from TÜV SÜD Certification and Testing (China) Co., Ltd. Shanghai Branch issued reports. This report is the confidential property of the client. As a mutual protection to our clients, the public and ourselves, extracts from the test report shall not be reproduced except in full without our written approval. Report Number:709502102938-00 EMC_SHA_F_R_02.10E TÜV SÜD Certification and Testing (China) Co., Ltd. Shanghai Branch 3-13, No.151, Heng Tong Road, Shanghai, 200070, P.R. China Phone: +86 21 61410123, Fax:+86 21 61408600 Page 2 of 55 Rev. 20.00 1 Table of Contents .................................................................................................................. .......................................................................................... ............................................................................... .................................................................................................. ...................................................................................................... .................................................................................................................. ........................................................................................................................... ................................................................................................... ........................................................................................................ ..................................................................................................... ...................................................................................... .............................................................................................................. .................................................................................................. ............................................................................... .................................................................................................................... .................................................................. .......................................................................................................... ................................................................................... ............................................................................................ ........................................................................................................ Report Number:709502102938-00 EMC_SHA_F_R_02.10E TÜV SÜD Certification and Testing (China) Co., Ltd. Shanghai Branch 3-13, No.151, Heng Tong Road, Shanghai, 200070, P.R. China Phone: +86 21 61410123, Fax:+86 21 61408600 Page 3 of 55 Rev. 20.00 2 Details about the Test Laboratory Details about the Test Laboratory Test Site 1 Test Firm FCC Registration Number: 820234 Test Firm IC Registration Number: 25988 Report Number:709502102938-00 EMC_SHA_F_R_02.10E TÜV SÜD Certification and Testing (China) Co., Ltd. Shanghai Branch 3-13, No.151, Heng Tong Road, Shanghai, 200070, P.R. China Phone: +86 21 61410123, Fax:+86 21 61408600 Page 4 of 55 Rev. 20.00 3 Description of the Equipment under Test Description of the Equipment Under Test Product:Wi-Fiand Bluetooth module Model no.: CB3L FCC ID: 2ANDL-CB3L Options and accessories:NA Rating:DC3.0-3.6V RF Transmission Frequency: For 802.11b/g/n-HT20: 2412~2462 MHz For 802.11n-HT40: 2422~2452 MHz For 802.15.1:2402~2480 MHz No. of Operated Channel: 2.4GHz WIFI: 11 for 802.11b/802.11g/802.11n(H20) 7 for 802.11n(H40) 2.4GHz BLE: 40 Modulation:For 2.4GHz WIFI: Direct Sequence Spread Spectrum (DSSS) for 802.11b Orthogonal Frequency Division Multiplexing (OFDM) for 802.11g/n For 2.4GHz BLE: GFSK Antenna Type:On Board PCBAntenna Antenna Gain:2.4dBi Description of the EUT:The Equipment Under Test (EUT) is a low-power embedded Wi-Fi and Bluetooth module (5.1). We tested it and listed the worst data in this report. Test sample no.:SHA-568906-1 laboratory therefore assumes no responsibility for accuracy of information on the brand name, model number, origin of manufacture, consignment, antenna gain or any information supplied. Report Number:709502102938-00 EMC_SHA_F_R_02.10E TÜV SÜD Certification and Testing (China) Co., Ltd. Shanghai Branch 3-13, No.151, Heng Tong Road, Shanghai, 200070, P.R. China Phone: +8…

Text truncated - open the document above for the full version.

Manufacturer: Hangzhou Tuya Information Technology Co.,Ltd Product: Wi-Fi and Bluetooth module FCC ID: 2ANDL-CB3L ©2021 Not to be reproduced, except in its entirety, Page 1 of 3 without the Permission of TÜ V SÜ D Certification and Testing (China) Co., Ltd. Shanghai Branch PHOTOGRAPHS OF TEST SET UP Field Strength and Harmonics Test Setup Radiated Emission Setup 9kHz ~ 30MHz 30MHz ~ 1GHz Manufacturer: Hangzhou Tuya Information Technology Co.,Ltd Product: Wi-Fi and Bluetooth module FCC ID: 2ANDL-CB3L ©2021 Not to be reproduced, except in its entirety, Page 2 of 3 without the Permission of TÜ V SÜ D Certification and Testing (China) Co., Ltd. Shanghai Branch 1GHz ~ 18GHz 18GHz ~ 25GHz Manufacturer: Hangzhou Tuya Information Technology Co.,Ltd Product: Wi-Fi and Bluetooth module FCC ID: 2ANDL-CB3L ©2021 Not to be reproduced, except in its entirety, Page 3 of 3 without the Permission of TÜ V SÜ D Certification and Testing (China) Co., Ltd. Shanghai Branch Conducted emission Test Setup
