2ANDL-CBUWiFi-Bluetooth Module

CBU Module Datasheet Hardware Product Development > Network Modules > Wi-Fi & BLE Dual Mode Module > CB Series Module Version: 20201221 Online Version Contents Contents 1 Product overview2 1.1 Features. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2 1.2 Applications. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2 1.3 Change history. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3 2 Module interfaces3 2.1 Dimensions and package. . . . . . . . . . . . . . . . . . . . . . . .3 2.2 Pin definition. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4 3 Electrical parameters8 3.1 Absolute electrical parameters. . . . . . . . . . . . . . . . . . . . .8 3.2 Normal working conditions. . . . . . . . . . . . . . . . . . . . . . .8 3.3 RF power consumption. . . . . . . . . . . . . . . . . . . . . . . . .9 3.4 Working current. . . . . . . . . . . . . . . . . . . . . . . . . . . . .9 4 RF parameters10 4.1 Basic RF features. . . . . . . . . . . . . . . . . . . . . . . . . . . .10 4.2 Wi-Fi transmission performance. . . . . . . . . . . . . . . . . . . . .11 4.3 Wi-Fi receiving performance. . . . . . . . . . . . . . . . . . . . . . .12 4.4 BLE transmission performance. . . . . . . . . . . . . . . . . . . . .12 4.5 BLE receiving performance. . . . . . . . . . . . . . . . . . . . . . .13 5 Antenna information13 5.1 Antenna type. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13 5.2 Antenna interference reduction. . . . . . . . . . . . . . . . . . . . .13 6 Packaging information and production instructions14 6.1 Mechanical dimensions. . . . . . . . . . . . . . . . . . . . . . . . .14 6.2 Production instructions. . . . . . . . . . . . . . . . . . . . . . . . .14 6.3 Recommended oven temperature curve. . . . . . . . . . . . . . . . .16 7 MOQ and packaging information17 8 Appendix: Statement17 i Contents CBU is a low-power embedded Wi-Fi module that Tuya has developed. It consists of a highly integrated RF chip BK7231N and a few peripherals, and not only supports the AP and STA dual-network-connection manner but supports the BLE network con- nection manner. 1 / 19 1 PRODUCT OVERVIEW 2 / 19 • Intelligent building 1.2 Applications – Onboard PCB antenna with a gain of 2.21 dBi – Complete Bluetooth coexistence interface – Up to 20 dBm transmit power in Bluetooth mode • BLE connectivity – Working temperature: -40°C to 105°C – Onboard PCB antenna with a gain of 2.2 dBi and iOS devices – Support SmartConfig and AP network configuration manners for Android – Support STA/AP/STA+AP working mode – Up to + 17 dBm output power in 802.11b mode – Support WEP, WPA/WPA2, and WPA/WPA2 PSK (AES) security modes – Channels 1 to [email protected] GHz – 802.11 b/g/n • Wi-Fi connectivity ceiver/transmitter (UART), and 1 serial peripheral interface (SPI) • Peripherals: 5 pulse width modulations (PWM), 2 universal asynchronous re- • Working voltage: 2.1 to 3.6V • The clock rate: 120 MHz processor • Embedded low-power 32-bit CPU, which can also function as an application 1.1 Features 32-bit PWM output makes the chip very suitable for high-quality LED control. decoding. Besides, it has rich peripherals, such as PWM, UART, and SPI. The five instructions for processing signals can effectively implement audio encoding and KB RAM, so as to support the multi-cloud connection. The MCU’s specially extended CBU is built-in with a 32-bit MCU with a running speed of up to 120 MHz and a 256- 1 Product overview 2 MODULE INTERFACES •Smart household and home appliances •Smart socket and light •Industrial wireless control •Baby monitor •Network camera •Intelligent bus 1.3Change history Update dateUpdated content Version after update 10/16/2020This is the first release. V1.0.0 11/24/2020Updated test data V1.0.1 2Module interfaces 2.1Dimensions and package The CBU dimensions are 15.8±0.35 mm (L)×20.3±0.35 mm (W) ×3±0.1 mm (H). The dimensions of CBU are as follows: 3 / 19 2 MODULE INTERFACES 2.2Pin definition Pin numberSymbolI/O typeFunction 1P14I/OCommon GPIO, which can be reused as SPI_SCK 2P16I/OCommon GPIO, which can be reused as SPI_MOSI 3P20I/OCommon GPIO 4P22I/OCommon GPIO 5ADCIADC, which corresponds to P23 on the internal IC 4 / 19 2 MODULE INTERFACES Pin numberSymbolI/O typeFunction 6RX2I/OUART_RX2, which corresponds to P1 on the internal IC 7TX2I/OUART_TX2, which is used for outputting logs and corresponds to P0 of the internal IC 8P8I/OSupport hardware PWM 9P7I/OSupport hardware PWM 10P6I/OSupport hardware PWM 11P26I/OSupport hardware PWM 12P24I/OSupport hardware PWM 13GNDPPower supply reference ground 143V3PPower supply 3V3 15TX1I/OUART_TX1, which is used for transmitting user data and corresponds to P11 of the internal IC 5 / 19 2 MODULE INTERFACES Pin numberSymbolI/O typeFunction 16RX1I/OUART_RX1, which is used for receiving user data and corresponds to P10 of the internal IC 17P28I/OCommon GPIO 18CENI/OReset pin 19P9I/OCommon GPIO 20P17I/OCommon GPIO, which can be reused as SPI_MISO 21P15I/OCommon GPIO, which can be reused as SPI_CS 6 / 19 2 MODULE INTERFACES Pin numberSymbolI/O typeFunction Test pointCSNI/OMode selection pin. If connected to the ground before powered on, enter the firmware test mode. If not connected or connected to VCC before powered on, enter the firmware application mode Correspond to P21 on the internal IC Note: P indicates a power supply pin and I/O indicates an input/output pin. 7 / 19 3 ELECTRICAL PARAMETERS 3Electrical parameters 3.1Absolute electrical parameters Parameter Description Minimum value Maximum valueUnit TsStorage temperature -55125°C VBATPower supply voltage -0.33.9V Static electricity discharge voltage (human body model) TAMB-25°C-44KV Static electricity discharge voltage (machine model) TAMB-25°C -200 200 V 3.2Normal working conditions Parameter Description Minimum value Typical value Maximum valueUnit TaWorking tempera- ture -40-105°C VBATPower supply voltage 2.13.33.6V 8 / 19 3 ELECTRICAL PARAMETERS Parameter Description Minimum value Typical value …
