2ANDL-HEWBRQU2Wi-Fi and Bluetooth Module

HEWBRQU2 Module Datasheet Version: 20260228 Online Version Contents Contents 1.Overview ...................................................... 2 1.1.Features ............................................................ 2 1.2.Scope of applications ............................................... 2 2.Module interfaces ............................................. 4 2.1.Dimensions and footprint .......................................... 4 3.Electrical parameters .......................................... 5 3.1.Absolute electrical parameters ..................................... 5 3.2.Operating conditions ............................................... 5 3.3.Radio frequency (RF) power ........................................ 6 3.4.Power consumption in operating mode ............................ 7 4.RF parameters ............................................... 10 4.1.Basic RF features ................................................. 10 4.2.Transmitter (TX) performance .................................... 10 5.Antenna information ......................................... 13 5.1.Antenna type ...................................................... 13 5.2.Antenna interference reduction ................................... 13 6.Power-on and power-off sequence ........................... 14 6.1.Power-on sequence ............................................... 14 6.2.Power-off sequence ............................................... 14 7.Footprint and production instructions ....................... 16 7.1.Mechanical dimensions ........................................... 16 7.2.Production instructions ........................................... 18 7.3.Recommended oven temperature curve ......................... 20 7.4.Storage conditions ................................................ 22 8.MOQ and packaging information ............................. 23 9.Appendix: Statement ......................................... 24 I 1Overview The HEWBRQU2 module is a Wi-Fi and Bluetooth Low Energy (LE) combo module developed by Tuya Smart. This module consists of a highly integrated wireless RF chip W701-VA2-CG with built-in Wi-Fi stacks and various library functions. 1 / 28 1Overview 1.Overview HEWBRQU2 combines a low-power KM4 microcontroller unit (MCU), WLAN MAC, and 1T1R (1 transmitter/1 receiver) design. This module provides output frequency up to 100 MHz, 256 KB embedded SRAM, 2 MB flash memory, and configurable GPIOs that can function as digital peripherals for diverse applications. HEWBRQU2 is a real-time operating system (RTOS), integrated with all Wi-Fi MAC and TCP/IP libraries. All these resources can help you develop your own embedded Wi-Fi products. 1.1.Features •Built-in low-power KM4 MCU that also acts as an application processor. •Clock rate of 100 MHz. •Operating voltage range: 4.5V to 18V. •Peripheral: 1 universal asynchronous receiver/transmitter (UART). •Wi-Fi and Bluetooth connectivity •IEEE 802.11b/g/n20. •Channels 1–[email protected] GHz (CH1–11 for US/CA and CH1–13 for EU/CN). •Support security protocols, including WEP, WPA, WPA2, and WPA2 PSK (AES). •Support Bluetooth LE 4.2. •Support Wi-Fi Easy Connect (EZ mode) pairing mode on Android and iOS devices. •Onboard PCB antenna. •It has passed CE and FCC certifications. •Operating temperature range: −20°C to +85°C. 1.2.Scope of applications •Smart building •Smart home •Smart socket •Smart lighting 2 / 28 2.3Module interfaces •Smart bus •Industrial wireless control •Baby monitor •IP camera 3 / 28 2.3Module interfaces 2.Module interfaces 2.1.Dimensions and footprint The HEWBRQU2 dimensions are 57.96±0.35 mm (W) × 21.70±0.35 mm (L) × 4.6±0.15 mm (H). The figure below shows the dimensions of the HEWBRQU2 module. 4 / 28 3.2Electrical parameters 3.Electrical parameters 3.1.Absolute electrical parameters ParametersDescription Minimum value Maximum value Unit Ts Storage temperature −40105°C VDD Supply voltage −0.318V Electrostatic discharge voltage (human body model) TAMB −25°C-2kV Electrostatic discharge voltage (machine model) TAMB −25°C-0.5kV 3.2.Operating conditions ParametersDescription Minimum value Typical value Maximum value Unit Ta Operating temperature −20-85°C VDD Operating voltage 4.5518V VIL I/O low- level input --0.8V VIH I/O high- level input 2.0--V 5 / 28 4.3RF parameters ParametersDescription Minimum value Typical value Maximum value Unit VOL I/O low- level output --0.4V VOH I/O high- level output 2.4--V Imax I/O drive current --16mA Cpad Input pin capacitor -2-pF 3.3.Radio frequency (RF) power •Power consumption during continuous transmission (TX) SymbolModePower Average value Peak (Typical) value Unit IRF 802.11b, 1 Mbit/s 17 dBm171246mA IRF 802.11b, 11 Mbit/s 17 dBm162240mA IRF 802.11g, 6 Mbit/s 17 dBm156230mA IRF 802.11g, 54 Mbit/s 15 dBm130226mA IRF 802.11n, BW20 MCS0 17 dBm152234mA IRF 802.11n, BW20 MCS7 14 dBm124218mA •Power consumption during continuous reception (RX) 6 / 28 4.4RF parameters SymbolMode Average value Peak (Typical) value Unit IRF 802.11b, 11 Mbit/s 5571mA IRF 802.11g, 54 Mbit/s 5070mA IRF 802.11n, HT20 MCS7 5375mA 3.4.Power consumption in operating mode Operating mode Status (Ta = 25°C) Average value Peak (Typical) value Unit Pairing over Bluetooth The module is pairing over Bluetooth. The network status indicator blinks quickly. 49280mA Pairing over AP The module is in AP mode. The Wi-Fi network status indicator blinks slowly. 51290mA 7 / 28 4.5RF parameters Operating mode Status (Ta = 25°C) Average value Peak (Typical) value Unit Connected and idle mode The module is connected to the cloud. The network status indicator is steady on. 2385mA Connected and operating mode The module is connected to the cloud. The network status indicator is steady on. 45276mA Weakly connected The connection between the module and the access point is intermittent. The network status indicator is steady on. 49265mA 8 / 28 4.5RF parameters Operating mode Status (Ta = 25°C) Average value Peak (Typical) value Unit Disconnected The module is discon…

Text truncated - open the document above for the full version.

Rev 1/26/2023 Hangzhou Tuya Information Technology Co., Ltd Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 USA Date: 2026-02-12 Ref: Attestation Statements Part 2.911(d)(7) Filing FCC ID or Grantee Code: 2ANDL-HEWBRQU2 Applicant FRN: 0026759332 [Hangzhou Tuya Information Technology Co., Ltd] certifies that, as of the date of the filing of the application, [Tuya Smart Inc.] is our designated U.S. agent for service of process for the above referenced FCC ID. [Hangzhou Tuya Information Technology Co., Ltd] accepts to maintain an agent for no less than one year after the grantee has terminated all marketing and importation or the conclusion of any Commission-related proceeding involving the equipment. [Tuya Smart Inc.] accepts, as of the date of the filing of the application, the obligation of the designated U.S. agent for service of process for the above referenced FCC ID. Designated U.S. Agent Information: Name: Tuya Smart Inc. U.S. Agent FRN: 0034102913 Address: 160 Greentree Drive, Suite 101, Dover, DELAWARE,19904 Contact Person: Jingchao Wang Tel.: 818-699-5031 Email: [email protected] Sincerely, Hangzhou Tuya Information Technology Co.,Ltd Tuya Smart Inc. Linyun Li Jingchao Wang

Applicant Declaration QSF27-14-04 Rev 1.4 April 25, 2025 Page 1 of 1 Original Issue: Jan. 4, 2021 SGS North America Inc. 620 Old Peachtree Road SUITE 100 Suwanee, Georgia 30024 United States Applicant Legal Business Name Hangzhou Tuya Information Technology Co., Ltd Address Room 301,Building 1,Huace Center,Xihu District,Hangzhou City,Zhejiang Province, China FRN 0026759332 Grantee Code 2ANDL FCC ID: 2ANDL-HEWBRQU2 Authorized Contact Name Linyun Li Contact Phone +86-571-86581786 Contact Email [email protected] I, the undersigned, certify that I am an authorized signatory for the Applicant and therefore declare; a) in accordance with 47CFR2.911(d), all of the statements herein and the exhibits attached hereto are true and correct to the best of my knowledge and belief. b) in accepting a Grant of Equipment Authorization issued by a TCB, under the authority of the FCC, as a result of the representations made in this application, the Applicant is responsible for: (1) labeling the equipment with the exact FCC ID as specified in this application, (2) compliance statement labeling pursuant to the applicable rules, (3) compliance of the equipment with the applicable technical rules, c) if the Applicant is not the actual manufacturer of the equipment, appropriate arrangements have been made with the manufacturer to ensure that production units of this equipment will continue to comply with the FCC’s technical requirements. d) in accordance with 47 CFR 2.909 and KDB394321, the Applicant has read, understood and agrees to accept that they are the responsible party and agree to abide by their responsibilities as specified under 47 CFR 2.909 and KDB394321. e) in accordance with ISO 17065, FCC KDB641163, FCC KDB610077, KDB394321 and RSP-100, the Applicant has read, understood, accepts and agrees to abide by the post market surveillance requirements. (1) the Applicant understands, accepts and agrees that a sample may be requested for surveillance testing. (2) the Applicant shall make provisions to always have a production sample available upon request by SGS, FCC and/or ISED. (3) the Applicant shall, upon request by SGS, at the Applicant’s expense, provide a production sample of the requested product to SGS, FCC and/or ISED as instructed. The sample shall include all support devices, cables, software, accessories or other hardware or software required for evaluation, review, certification and audit surveillance of products certified by SGS. f) neither the Applicant nor any party to the application is subject to a denial of Federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. §862 because of a conviction for possession or distribution of a controlled substance. See 47CFR 1.2002(b) for the definition of a “party” for these purposes. g) the Applicant has read, understood, accepts and agrees to abide by the SGS North America, Inc. terms and conditions as specified in the TCB Application Form 731 (QSF27-14-01). Link to CFRs: https://www.fcc.gov/wireless/bureau-divisions/technologies-systems-and-innovation-division/rules-regulations-title-47 Link to KDBs: https://apps.fcc.gov/oetcf/kdb/index.cfm Link to RSP-100: https://www.ic.gc.ca/eic/site/smt-gst.nsf/eng/sf01130.html Link to the Covered List: Covered List Applicant Signature: Date: 2026-02-11 Print Name: Linyun Li Title: Manager *NOTE: This declaration cannot be signed by an Agent, it shall be signed by an authorized person listed in the FCC database

FCC COVERED LIST DECLARATION LETTER Page 1 of 1 Revision 1.0 SGS North America Inc. 620 Old Peachtree Road SUITE 100 Suwanee, Georgia 30024 United States Applicant Legal Business Name Hangzhou Tuya Information Technology Co., Ltd Address Room 301,Building 1,Huace Center,Xihu District,Hangzhou City,Zhejiang Province, China FRN 0026759332 Grantee Code 2ANDL FCC ID: 2ANDL-HEWBRQU2 Authorized Contact Name Linyun Li Contact Phone +86-571-86581786 Contact Email [email protected] Hangzhou Tuya Information Technology Co., Ltd (“the applicant”) certifies: - the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. - as of the date of the filing of the application, the applicant [is not] identified on the Covered list, established pursuant to §1.50002, as an entity producing “covered” equipment. - the software to be loaded prior to marketing of the equipment identified above is not “covered” software manufactured by any entity including predecessors, successors, parents, subsidiaries, affiliates or any entity which has rebranded or relabeled the software produced by the entity(ies) identified on the “Covered List”. - the device is not capable of storing or running software listed on the covered list and therefore is inherently compliant. Link to the Covered List: Covered List Applicant Signature: Date: 2026-02-11 Print Name: Linyun Li Title: Manager *NOTE: This declaration cannot be signed by an Agent, it shall be signed by an authorized person listed in the FCC database

< Hangzhou Tuya Information Technology Co., Ltd > To: SGS North America Inc. 620 Old Peachtree Road SUITE 100 Suwanee, Georgia United States From: Hangzhou Tuya Information Technology Co., Ltd Room 301,Building 1,Huace Center,Xihu District,Hangzhou City,Zhejiang Province, China Regarding: Confidentiality Request regarding application for FCC ID: 2ANDL-HEWBRQU2 LONG TERM CONFIDENTIALITY Pursuant to 47 CFR Section 0.459 and 0.457 of the commission’s rules, the applicant hereby request confidential treatment of the documents listed below, associated with the certification application referenced above. Schematic(s) Block Diagrams Operational Descriptions The documents above contain proprietary information not released to the public. Public disclosure of this information may prove harmful to the business of the applicant. Sincerely, Signature: Printed Name (on file with the FCC associated with the Grantee Code): Linyun Li Title: Manager Company Name: Hangzhou Tuya Information Technology Co., Ltd

< Hangzhou Tuya Information Technology Co., Ltd > Date: 2026-02-11 TO: Federal Communication Commission Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MID 21046 Regarding: 2ANDL-HEWBRQU2 To whom it may concern: We, the undersigned, hereby authorize Parlam Zhan to act on our behalf in all manners relating to application for equipment authorization with respect to the FCC ID above, including signing of all documents relating to these matters. Any and all acts carried out by the agent on our behalf shall have the same effect as acts of our own. We, the undersigned, hereby certify that we are not subject to a denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 853(a). Where our agent signs the application for certification on our behalf, I acknowledge that all responsibility for complying with the terms and conditions for Certification, as specified by SGS North America, Inc., still resides with Hangzhou Tuya Information Technology Co., Ltd This authorization is valid until further written notice from the applicant. Name (Printed): Linyun Li Title: Manager Signature: On behalf of Company: Hangzhou Tuya Information Technology Co., Ltd Telephone: +86-571-86581786

Hangzhou Tuya Information Technology Co., Ltd Cover Letter-Modular Approval FCC ID: 2ANDL-HEWBRQU2 Date: 2026-02-11 Gentlemen: There’s a Wi-Fi and Bluetooth Module that would like to have your authorization as a modular approval. The specific product as below, radar Module with its designed features and specified description, meets special requirements for Full modular approval on FCC KDB996369 by cross-reference list below. Company Hangzhou Tuya Information Technology Co., Ltd Model Name Wi-Fi and Bluetooth Module Model Number HEWBRQU2 FCC ID 2ANDL-HEWBRQU2 Requirement of FCC KDB996369 Comply（Y/N） 1. The modular transmitter must have its own RF shielding. Y The EUT has its own RF shielding. Please refer to EUT Photos. 2. The modular transmitter must have buffered modulation/data inputs (if such inputs are provided) to ensure that the module will comply with Part 15 requirements under conditions of excessive data rates or over-modulation. Y The EUT uses the chip: W701-VA2 as an embedded processor to buffer the data. Please refer to Schematics. 3. The modular transmitter must have its own power supply regulation. Y The EUT has its own power supply regulation, The power supply of this module is 5V. Please refer to Schematics. 4. The modular transmitter must comply with the antenna and transmission system requirements of Sections 15.203, 15.204(b) and 15.204(c). The antenna must either be permanently attached or employ a “unique” antenna coupler (at all connections between the module and the antenna, including the cable). The “professional installation” provision of Section 15.203 is not applicable to modules but can apply to limited modular approvals under paragraph (b) of this section. Y The EUT meets the FCC antenna requirements; The photo of antenna is shown in the test report. 5. The modular transmitter must be tested in a stand-alone configuration, i.e., the module must not be inside another device during testing. Y The EUT was tested with a test cable, see test report and setup photo 6. The modular transmitter must be labeled with its own FCC ID number, and, if the FCC ID is not visible when the module is installed inside another device, then the outside of the device into which the module is installed must also display a label referring to the enclosed module. This exterior label can use wording such as the following: “Contains Transmitter Module FCC ID: 2ANDL-HEWBRQU2” or “Contains FCC ID: 2ANDL-HEWBRQU2” Any similar wording that expresses the same meaning may be used. The Grantee may either provide such a label, an example of which must be included in the application for equipment authorization, or, must provide adequate instructions along with the module which explain this requirement. In the latter Y Please see exhibition label sample for the FCC ID of this module. And also in the exhibition User’s manual, there are instructions to the OEM on how to label the end product. Hangzhou Tuya Information Technology Co., Ltd case, a copy of these instructions must be included in the application for equipment authorization. 7. The modular transmitter must comply with any specific rule or operating requirements applicable to the transmitter and the manufacturer must provide adequate instructions along with the module to explain any such requirements. A copy of these instructions must be included in the application for equipment authorization. Y The EUT is compliant with all applicable FCC rules. Details instructions for maintaining compliance are given in the User Manual. 8. The modular transmitter must comply with any applicable RF exposure requirements. For example, FCC Rules in Sections 2.1091, 2.1093 and specific Sections of Part 15, including 15.319(i), 15.407(f), 15.253(f) and 15.255(g), require that Unlicensed PCS, UNII and millimeter wave devices perform routine environmental evaluation for RF Exposure to demonstrate compliance. In addition, spread spectrum transmitters operating under Section 15.247 are required to address RF Exposure compliance in accordance with Section 15.247(b)(4). Y The EUT complies with RF exposure requirement. Thank you. Sincerely, Print Name: Linyun Li Title: Manager Signature: On behalf of Company: Hangzhou Tuya Information Technology Co., Ltd Telephone: +86-571-86581786

Page: 1 of 2 Appendix External Photos for SUCR2601000052MO Test Model No.: HEWBRQU2 Page: 2 of 2 EUT Constructional Details (EUT Photos) ---End of Report---

Page 1 of 1

Page: 1 of 2 Appendix Internal Photos for SUCR2601000052MO Test Model No.: HEWBRQU2 Page: 2 of 2 EUT Constructional Details (EUT Photos) ---End of Report---

Report No.: SUCR260100005203 Page: 1 of 10 This document is issued by the Company subject to its General Conditions of Service printed overleaf, available on request or accessible at http://www.sgs.com/en/Terms-and-Conditions and, for electronic format documents, subject to Terms and Conditions for Electronic Documents at http://www.sgs.com/en/Terms-and-Conditions/Terms-e-Document. Attention is drawn to the limitation of liability, indemnification and jurisdiction issues defined therein. Any holder of this document is advised that information contained hereon reflects the Company’s findings at the time of its intervention only and within the limits of Client’s instructions, if any. The Company’s sole responsibility is to its Client and this document does not exonerate parties to a transaction from exercising all their rights and obligations under the transaction documents. This document cannot be reproduced except in full, without prior written approval of the Company. Any unauthorized alteration, forgery or falsification of the content or appearance of this document is unlawful and offenders may be prosecuted to the fullest extent of the law. Unless otherwise stated the results shown in this test report refer only to the sample(s) tested and such sample(s) are retained for 30 days only. Attention: To check the authenticity of testing / inspection report & certificate, please contact us at telephone:(86-755) 8307 1443, or email: [email protected] RF Exposure Evaluation Report Application No.: SUCR2601000052MO Applicant: Hangzhou Tuya Information Technology Co., Ltd. Address of Applicant: Room 301, Building 1, Huace Center, Xihu District, Hangzhou City, Zhejiang Province, China Manufacturer: Hangzhou Tuya Information Technology Co., Ltd. Address of Manufacturer: Room 301, Building 1, Huace Center, Xihu District, Hangzhou City, Zhejiang Province, China Equipment Under Test (EUT): EUT Name: Wi-Fi and Bluetooth Module Model No.: HEWBRQU2 FCC ID: 2ANDL-HEWBRQU2 Standard(s) : FCC Rules 47 CFR §2.1091 KDB 447498 D04 interim General RF Exposure Guidance v01 Date of Receipt: 2026-01-20 Date of Issue: 2026-01-31 Test Result: Pass* * In the configuration tested, the EUT complied with the standards specified above. Report No.: SUCR260100005203 Page: 2 of 10 Revision Record Version Description Date Remark 01 Original 2026-01-31 / Authorized for issue by: Tested By Hayley Zhang/Project Engineer Approved By Cedar Cheng /Reviewer Report No.: SUCR260100005203 Page: 3 of 10 1 Contents Page 1 Contents ................................................................................................................................................... 3 2 General Information ................................................................................................................................ 4 2.1 General Description of E.U.T. .......................................................................................................... 4 2.2 Separation Distance ......................................................................................................................... 4 2.3 Test Location .................................................................................................................................... 5 2.4 Test Facility ...................................................................................................................................... 5 3 RF Exposure Test Exemptions .............................................................................................................. 6 3.1 RF Exposure Test Exemptions for single RF sources ..................................................................... 6 3.2 RF Exposure Test Exemptions for Simultaneous Transmission ...................................................... 8 4 Measurement and Calculation ............................................................................................................. 10 4.1 Maximum transmit power ............................................................................................................... 10 4.2 RF Exposure Calculation................................................................................................................ 10 Report No.: SUCR260100005203 Page: 4 of 10 2 General Information 2.1 General Description of E.U.T. Hardware Version: HEWBRQU2-P_V1.0.0 Software Version: 1.0.3 Power Supply: DC 5V Antenna Type: PCB Antenna Antenna Gain: WIFI 2.4G: 0.77dBi Bluetooth: 0.77dBi Note: The antenna gain are derived from the gain information report provided by the manufacturer. Note: Since the above data and/or information is provided by the client relevant results or conclusions of this report are only made for these data and/or information, SGS is not responsible for the authenticity, integrity and results of the data and information and/or the validity of the conclusion. 2.2 Separation Distance Separation distance between the antenna to person (R): ＞20cm Remark: This minimum test separation distance is determined by the smallest distance from the antenna and radiating structures or outer surface of the device, according to the host form factor, exposure conditions and platform requirements, to any part of the body or extremity of a user or bystander. R has been stated in user manual. Report No.: SUCR260100005203 Page: 5 of 10 2.3 Test Location All tests were performed at: SGS-CSTC Standards Technical Services (Suzhou) Co., Ltd. South of No. 6 Plant, No. 1, Runsheng Road, Suzhou Industrial Park, Suzhou Area, China (Jiangsu) Pilot Free Trade Zone Post code: 215000 No tests were sub-contracted. Note: 1. SGS is not responsible for wrong test results due to incorrect information (e.g. max. clock frequency, highest internal frequency, antenna gain, cable loss, etc ) is provided by the applicant. (if applicable). 2. SGS is not responsible for the authenticity, integrity and the validity of the conclusion based on results of the data provided by applica…

Text truncated - open the document above for the full version.

Report No.: SUCR260100005201 Page: 1 of 94 This document is issued by the Company subject to its General Conditions of Service printed overleaf, available on request or accessible at http://www.sgs.com/en/Terms-and-Conditions and, for electronic format documents, subject to Terms and Conditions for Electronic Documents at http://www.sgs.com/en/Terms-and-Conditions/Terms-e-Document. Attention is drawn to the limitation of liability, indemnification and jurisdiction issues defined therein. Any holder of this document is advised that information contained hereon reflects the Company’s findings at the time of its intervention only and within the limits of Client’s instructions, if any. The Company’s sole responsibility is to its Client and this document does not exonerate parties to a transaction from exercising all their rights and obligations under the transaction documents. This document cannot be reproduced except in full, without prior written approval of the Company. Any unauthorized alteration, forgery or falsification of the content or appearance of this document is unlawful and offenders may be prosecuted to the fullest extent of the law. Unless otherwise stated the results shown in this test report refer only to the sample(s) tested and such sample(s) are retained for 30 days only. Attention: To check the authenticity of testing / inspection report & certificate, please contact us at telephone:(86-755) 8307 1443, or email: [email protected] TEST REPORT Application No.: SUCR2601000052MO FCC ID: 2ANDL-HEWBRQU2 Applicant: Hangzhou Tuya Information Technology Co., Ltd. Address of Applicant: Room 301,Building 1,Huace Center,Xihu District,Hangzhou City,Zhejiang Province, China Manufacturer: Hangzhou Tuya Information Technology Co., Ltd. Address of Manufacturer: Room 301,Building 1,Huace Center,Xihu District,Hangzhou City,Zhejiang Province, China Equipment Under Test (EUT): EUT Name: Wi-Fi and Bluetooth Module Model No.: HEWBRQU2 Standard(s) : 47 CFR Part 15, Subpart C 15.247 Date of Receipt: 2026-01-20 Date of Test: 2026-01-26 to 2026-01-29 Date of Issue: 2026-01-31 Test Result: Pass* * In the configuration tested, the EUT complied with the standards specified above. Report No.: SUCR260100005201 Page: 2 of 94 Revision Record Version Description Date Remark 01 Original 2026-01-31 / Authorized for issue by: Tested By Hayley Zhang/Project Engineer Approved By Cedar Cheng /Reviewer Report No.: SUCR260100005201 Page: 3 of 94 2 Test Summary Radio Spectrum Technical Requirement Item Standard Method Requirement Result Antenna Requirement 47 CFR Part 15, Subpart C 15.247 N/A 47 CFR Part 15, Subpart C 15.203 & 15.247(b)(4) Pass Radio Spectrum Matter Part Item Standard Method Requirement Result Conducted Emissions at AC Power Line (150kHz-30MHz) 47 CFR Part 15, Subpart C 15.247 ANSI C63.10 (2020) Section 6.2 47 CFR Part 15, Subpart C 15.207 Pass Radiated Emissions which fall in the restricted bands ANSI C63.10 (2020) Section 6.10.5 & 11.12 47 CFR Part 15, Subpart C 15.205 & 15.209 Pass Radiated Spurious Emissions Below 1GHz ANSI C63.10 (2020) Section 6.4,6.5 47 CFR Part 15, Subpart C 15.205 & 15.209 Pass Radiated Spurious Emissions Above 1GHz ANSI C63.10 (2020) Section 6.6 & 11.12 47 CFR Part 15, Subpart C 15.205 & 15.209 Pass Maximum Conducted Output Power ANSI C63.10 (2020) Section 11.9.1 47 CFR Part 15, Subpart C 15.247(b)(3) Pass Minimum 6dB Bandwidth ANSI C63.10 (2020) Section 11.8.1 47 CFR Part 15, Subpart C 15.247a(2) Pass Power Spectral Density ANSI C63.10 (2020) Section 11.10.2 47 CFR Part 15, Subpart C 15.247(e) Pass Conducted Band Edges Measurement ANSI C63.10 (2020) Section 6.10.4 47 CFR Part 15, Subpart C 15.247(d) Pass Conducted Spurious Emissions ANSI C63.10 (2020) Section 11.11 47 CFR Part 15, Subpart C 15.247(d) Pass Report No.: SUCR260100005201 Page: 4 of 94 3 Contents Page 1 COVER PAGE ........................................................................................................................................... 1 2 Test Summary ......................................................................................................................................... 3 3 Contents ................................................................................................................................................... 4 4 General Information ................................................................................................................................ 5 4.1 Details of E.U.T. ............................................................................................................................... 5 4.2 Environment Parameter ..................................................................................................…

Text truncated - open the document above for the full version.
