2ANDL-WB3L

Hangzhou Tuya Information Technology Co.,Ltd

Wi-Fi and Bluetooth Module

Click to zoom

Application Details

Equipment Class: DTS - Digital Transmission System
Date of Grant: Jan 08, 2020
Application Purpose: Original Equipment
Date of Application: Jan 07, 2020
Equipment Note: Wi-Fi and Bluetooth Module
Frequency Range: 2412.00000000 - 2462.00000000
Company: Hangzhou Tuya Information Technology Co.,Ltd
Country: China

Documents & Files

Select a file to view

Users Manual

Cover Letter(s)

External Photos

ID Label/Location Info

Internal Photos

RF Exposure Info

Test Report

Test Setup Photos

Technical Specifications

#	Rule Parts	Frequency Range	Power Output
2	15C	2.41 GHz - 2.46 GHz	193.20 mW

Modular Type

Single Modular Approval

Confidentiality

Long Term

Grant Notes

Single Modular Approval. Power output listed is conducted. This device has 20 MHz and 40 MHz bandwidth mode. The module grantee is responsible for providing the documentation to the system integrator on restrictions of use, for continuing compliance of the module. The integrator installing this module into their product must ensure that the final composite product complies with the FCC requirements by a technical assessment or evaluation to the FCC rules, including the transmitter operation and should refer to guidance in KDB 996369. Separate approval is required for all other operating configurations, including portable configurations with respect to 2.1093 and different antenna configurations.
