2ANP7EGG190098Triple coil embedded wireless charging system

USER MANUAL EGG190098 Triple coil embedded system Product overview The “Triple coil embedded system” is a wireless charging module designed to be integrated in any surface. Using the provided adhesive mounting tape, it can be installed under slim surfaces (maximum 5 mm thickness). No need for screws: the installation process is quick and easy, and the charger can be removed without damaging the top. The “Triple coil embedded system” is Qi certified and works with any Qi-certified device. A triple-coil system ensures high positioning freedom. Maximum power delivered is 5W. How to use 1. Remove the layer on the adhesive mounting tape. 2. Apply under surface. Works with most non-metal surfaces. Model: EGGTX025 3.Connectthecabletothepowersource. 4.LaydownanyQi-enabledsmartphoneonthewirelesschargingareato startcharging. Features ●CertifiedwithWPCQi1.2.4 ●Designedforintegration:acompletelyhiddensolution ●Industrialadhesivemountingtape,noneedforscrews ●Quickandpracticalinstallationprocess,easychargerremovalwithout damagingthetop ●Maximumpower5W ●Triplecoilfreepositioningtechnologyallowswiderchargingarea comparedtostandardsolutions ●Designedtobeinstalledundersurfaceswithmaximumthicknessof5mm (0.19in) ●Designedintwovariants: ●Variant01:twopowerinputlines ●Variant02:twopowerinputlinesandoneoutputStatusSignal(SS). TheSSiscontrolledbythesystemanditsfunctionistoindicateifa deviceisincharge(3.3Voutput)ornot(OpenDrain-HiZoutput) Specifications Physicalspecifications Dimensions:61x103x9mm(2.40x4.05x0.35in)|Weight:2pin(V01): 87g(0.19Ibs);3pin(V02):90g(0.20Ibs)|Cablelength:65cm(1.47ft). Electricalspecifications InputMin11.4VMax14.5V|InputcurrentMax1A|Outputwireless5W| AverageSstandbymodeconsumption~25mA|Storagetemperature-10°C/ 70°C|Operatingtemperature0°C/40°C|Operatingfrequency115-205 kHz. PinOutput Variant01:Triplecoilembeddedsystem2pin MOLEX430250200 Pin1signal:12V Pin2signal:GND PinOutput Variant02:Triplecoilembeddedsystem3pin MOLEX436450300 Pin1signal:12V Pin2signal:statussignal Pin3signal:GND Technicaldrawings Variant01:Triplecoilembeddedsystem2pin Item Number PartnumberDescriptionMaterialQuantity 1EGGM200001- V01R01-Shell bottom BottomCoverABS1 2EGGTX025_S01G01PCBAssemblyFR41 3EGGM200002- V01R01-Shelltop UpperCoverABS1 4EGG190098-E01- TripleCoil Wirelesscharging coilA24 Copperwire+ferrite1 5EGG190098-E02- Cable 2wirescableCopperwire1 6EGG190098-C01- Adhesive Adhesivetape- OCS5030GP WhiteashAcrylic1 7EGG190098-E03- Connector MOLEX 430250200. Polarization: PIN1:12V-Red PIN2:GND- Black Nylon1 Generaltolererance Nominallengths[mm]table 0.5upto3±0.1 3upto6±0.1 6upto30±0.2 30upto120±0.3 ExternalRadiusandChamferHeight 0.5upto3±0.2 3upto6±0.5 Angulardimension upto10±1° over10upto50±0°30’ over50upto120±0°20’ Variant02:Triplecoilembeddedsystem3pin Item Number PartnumberDescriptionMaterialQuantity 1EGGM200001- V01R01-Shell bottom BottomCoverABS1 2EGGTX025_S01G01PCBAssemblyFR41 3EGGM200002- V01R01-Shelltop UpperCoverABS1 4EGG190098-E01- TripleCoil Wirelesscharging coilA24 Copperwire+ferrite1 5EGG190098-E02- Cable 3wirescableCopperwire1 6EGG190098-C01- Adhesive Adhesivetape- OCS5030GP WhiteashAcrylic1 7EGG190098-E05- Connector MOLEX 436450300. Polarization: PIN1:12V-Red |PIN2:signal- White| PIN3:GND- Black Nylon1 Generaltolererance Nominallengths[mm]table 0.5upto3±0.1 3upto6±0.1 6upto30±0.2 30upto120±0.3 ExternalRadiusandChamferHeight 0.5upto3±0.2 3upto6±0.5 Angulardimension upto10±1° over10upto50±0°30’ over50upto120±0°20’ Safetyinformation Pleasereadthissafetyinformationcarefullybeforeusingtheproducttoprevent injurytoyourselforothersanddamagetoyourdevice. Pleasekeepthismanualforfuturereference. ●Donotdamagethecable.Doingsomaycauseelectricshockorfire. ●Keeptheproductawayfromhotsurfacesandsharpcorners. ●Donotcarryordragtheproductbythecable. ●Donotusetheproductifoneormoreofitscomponentsaredamagedor faulty. ●Theproductcontainselectronicparts.Keepyourdevicedry.Humidity andliquidsmaydamagetheelectroniccircuitsofthedeviceandmay causeelectricshockandfire.Handlewithcare. ●Donotdropyourdevice.Itmaygetdamagedormaymalfunction. ●Donotplaceanymetalobjectonthecharger,asitmayoverheat.Donot placeanyotherobjectbetweenthesmartphoneandthewirelesscharging spot. ●Donotstoremagneticcardsneartheproduct.Magneticcards,including creditcards,phonecardsandboardingpassesmaybedamagedby magneticfields. ●Handletheproductwithcare.Donotdropyourdevice.Itmayget damagedormaymalfunction. ●Donotdisassemble,modify,orrepairyourcharger.Anyalterationor modificationofyourdevicemayvoidthemanufacturer’swarranty.If yourdeviceneedsservicing,contactthemanufacturer. ●Donotmodifytheproductinanyway.Anymodificationmayincrease theriskofinjury. ●Donotbiteorsuckonthedevice.Doingsomaydamagethedeviceor resultinanexplosionorfire. ●Childrenmaychokeonsmallparts.Ifchildrenusethedevice,makesure thattheyuseitproperly.Warning:chokinghazard.Keepoutofthereach ofchildren. ●Ifyounoticestrangesmellsorsmokecomingfromyourdevice,stopusing itimmediately.Continuingtousethedevicemayresultinfireor explosion. ●Donotusethedeviceforanythingotherthanitsintendeduse.Thedevice maymalfunctionormaycauseanelectricshockorfire. ●Neverdisposeofthedeviceinafire. ●Avoidexposingyourdevicetoverycoldorveryhottemperatures. ●Donotthrowawaytheproductwiththehouseholdtrash.Theproduct needstoberecycledanddisposedofresponsibly. Limitedwarranty Forproductwarrantyvisitourwebsiteatthepage www.eggtronic.com/support/download-area Thisproductismeantforuseonlywithappropriatedevices.Pleaseconsultyour devicepackagingtodeterminewhetherthisproductiscompatiblewithyour particulardevice.Manufacturerwillnotberesponsibleforanydamagesyouor anythirdpartythatmaysufferasaresultofuse,intendedorunintended,or misuseofthisproduct.YouagreetoindemnifyManufacturerforanyresulting injuryordamageiftheproductisusedwithanunintendeddevice.Product names,logos,brandsandothertrademarksreferredtowithinthisproductare propertyoftheirrespectivetrademarkholders.Thesetrademarkholdersare notaffiliatedwithourcompany,ourproductsorourwebsite.Theydonot spo…

Text truncated - open the document above for the full version.

FCC ID: 2ANP7EGG190098

Label Location On EUT Label Product Name: Triple coilembedded wireless charging system Model No.: EGG190098 FCC ID: 2ANP7EGG190098 This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation.

FCC ID: 2ANP7EGG190098 ANT

version01 Eggtronic Engineering Srl Declaration concerning Antenna Specification It is hereby declared that the product Model No.: EGG190098 FCC ID : 2ANP7EGG190098 fulfills the requirement in FCC test relating to the antenna type. The device specified above confirms to the FCC recommendations for internal antenna type(s) described below: Model No. of antenna: N/A Type of antenna:Inductive loop coil Antenna Gain of the antenna: 0 dBi Frequency range:110.1-205KHz The mounting of the antenna is fixed to the radio module and no other antenna should be used. Company name: Eggtronic Engineering Srl Address: Via Giorgio Campagna 8 41126 Modena Italy City:Modena ZIP / Postal code: N/A Country:Italy Place:ItalyDate: 2020-07-31 Signature:

Report No.: 18220WC00049302FCC ID: 2ANP7EGG190098Page 1 of 13 Code:AB-RF-05-a FCC TEST REPORT Client Name: Eggtronic Engineering Srl Address: Via Giorgio Campagna 8 41126 Modena Italy Product Name: Triple coil embedded wireless charging system Date: Jul. 30, 2020 Shenzhen Anbotek Compliance Laboratory Limited Report No.: 18220WC00049302FCC ID: 2ANP7EGG190098Page 2 of 13 Code:AB-RF-05-a Contents 1. General Information ............................................................................................................................................... 4 1.1. Client Information ....................................................................................................................................... 4 1.2. Description of Device (EUT) ..................................................................................................................... 4 1.3. Auxiliary Equipment Used During Test ................................................................................................... 5 1.4. Test Equipment List .................................................................................................................................... 5 1.5. Measurement Uncertainty ......................................................................................................................... 5 1.6. Description of Test Facility ........................................................................................................................ 5 2. Measurement and Result ..................................................................................................................................... 6 2.1. Requirements .............................................................................................................................................. 6 2.2. Test Setup .................................................................................................................................................... 7 2.3. Test Procedure ............................................................................................................................................ 7 2.4. Test Result ................................................................................................................................................... 7 2.4.1. Equipment Approval Considerations item 5.b of KDB 680106 D01 v03. ...................................... 7 2.4.2. Environmental evaluation and exposure limit according to FCC CFR 47 part 1, 1.1307(b), 1.1310 .................................................................................................................................................................. 9 APPENDIX I -- TEST SETUP PHOTOGRAPH ................................................................................................... 11 Report No.: 18220WC00049302FCC ID: 2ANP7EGG190098Page 3 of 13 Code:AB-RF-05-a TEST REPORT Applicant: Eggtronic Engineering Srl Manufacturer: Shenzhen Pilot Technology Co., Ltd Product Name: Triple coil embedded wireless charging system Model No.: EGG190098 Trade Mark: Eggtronic Rating(s): Input: DC 12V, 1A Wireless Output: 5W Test Standard(s) : FCC Part 1.1310, 1.1307(b) Test Method(s): KDB680106 D01 RF Exposure Wireless Charging Apps v03 The device described above is tested by Shenzhen Anbotek Compliance Laboratory Limited to determine the maximum emission levels emanating from the device and the severe levels of the device can endure and its performance criterion. The measurement results are contained in this test report and Shenzhen Anbotek Compliance Laboratory Limited is assumed full of responsibility for the accuracy and completeness of these measurements. Also,this report shows that the EUT (Equipment Under Test) is technically compliant with the FCC Part 1.1307 & KDB680106 D01 requirements. This report applies to above tested sample only and shall not be reproduced in part without written approval of Shenzhen Anbotek Compliance Laboratory Limited. Date of ReceiptMay 08, 2020 Date of TestMay 08~Jun. 05, 2020 Prepared By (Engineer / Dolly Mo) Reviewer (Supervisor / Bibo Zhang) Approved & Authorized Signer (Manager / Tom Chen) Report No.: 18220WC00049302FCC ID: 2ANP7EGG190098Page 4 of 13 Code:AB-RF-05-a 1. General Information 1.1. Client Information 1.2. Description of Device (EUT) Product Name : Triple coil embedded wireless charging system Model No.: EGG190098 Trade Mark: Eggtronic Test Power Supply:DC12V Test Sample No.: 1-2-1(Normal Sample), 1-2-1(Engineering Sample) Product Description : Operation Frequency:110.1-205KHz Modulation Type:QI Antenna Type:Inductive loop coil Antenna Antenna Gain(Peak):0 dBi Remark:1) For a more detailed features description, please refer to the manufacturer’s specifications or the User’s Manual. Applicant: Eggtronic Engineering Srl Address: Via Giorgio Campagna 8 41126 Modena Italy Manufacturer: Shenzhen Pilot Technology Co., Ltd Address : 101 A1 Industrial Park, building a 1, No.7, Shankeng Road, Shanxia community, Pinghu Street, Longgang District, Shenzhen City,China. Factory: Shenzhen Pilot Technology Co., Ltd Address : 101 A1 Industrial Park, building a 1, No.7, Shankeng Road, Shanxia community, Pinghu Street, Longgang District, Shenzhen City,China. Report No.: 18220WC00049302FCC ID: 2ANP7EGG190098Page 5 of 13 Code:AB-RF-05-a 1.3. Auxiliary Equipment Used During Test N/A: 1.4. Test Equipment List ItemEquipmentManufacturerModel No.Serial No.Last Cal.Cal. Interval 1 Magnetic field meter NARDAELT-400423623 Dec. 23, 2019 1 Year 2E-Field ProbeNardaEF0391Q15221 Nov.17, 2017 3 Year 3H-Field ProbeNardaHF3061Q15835 Nov.17, 2017 3 Year 1.5. Measurement Uncertainty Radiation Uncertainty: Ur = 3.9 dB (Horizontal) Ur = 3.8 dB (Vertical) Conduction Uncertainty: Uc = 3.4 dB 1.6. Description of Test Facility The test facility is recognized, certified, oraccredited by the following organizations: FCC-Registration No.: 184111 Shenzhen Anbotek Compliance Laboratory Limited, EMC Lab…

Text truncated - open the document above for the full version.

Report No.: 18220WC00049301FCC ID: 2ANP7EGG190098Page 1 of 25 Code:AB-RF-05-a FCC TEST REPORT Client Name: Eggtronic Engineering Srl Address: Via Giorgio Campagna 8 41126 Modena Italy Product Name: Triple coil embedded wireless charging system Date: Jul. 30, 2020 Shenzhen Anbotek Compliance Laboratory Limited Report No.: 18220WC00049301FCC ID: 2ANP7EGG190098Page 2 of 25 Code:AB-RF-05-a Contents 1. General Information ............................................................................................................................................... 4 1.1. Client Information ....................................................................................................................................... 4 1.2. Description of Device (EUT) ..................................................................................................................... 4 1.3. Auxiliary Equipment Used During Test ................................................................................................... 5 1.4. Description of Test Modes ........................................................................................................................ 5 1.5. Description Of Test Setup ......................................................................................................................... 6 1.6. Test Equipment List .................................................................................................................................... 7 1.7. Measurement Uncertainty ......................................................................................................................... 8 1.8. Description of Test Facility ........................................................................................................................ 8 2. Summary of Test Results ..................................................................................................................................... 9 3. Conducted Emission Test ................................................................................................................................... 10 3.1. Test Standard and Limit .......................................................................................................................... 10 3.2. Test Setup .................................................................................................................................................. 10 3.3. Test Procedure .......................................................................................................................................... 10 3.4. Test Data .................................................................................................................................................... 10 4. Radiation Spurious Emission and Band Edge ................................................................................................ 11 4.1. Test Standard and Limit .......................................................................................................................... 11 4.2. Test Setup .................................................................................................................................................. 11 4.3. Test Procedure .......................................................................................................................................... 12 4.4. Test Data .................................................................................................................................................... 13 5. Antenna Requirement ......................................................................................................................................... 17 5.1. Test Standard and Requirement ............................................................................................................ 17 5.2. Antenna Connected Construction .......................................................................................................... 17 APPENDIX I -- TEST SETUP PHOTOGRAPH ................................................................................................... 18 APPENDIX II -- EXTERNAL PHOTOGRAPH ..................................................................................................... 19 APPENDIX III -- INTERNAL PHOTOGRAPH ..................................................................................................... 23 Report No.: 18220WC00049301FCC ID: 2ANP7EGG190098Page 3 of 25 Code:AB-RF-05-a TEST REPORT Applicant: Eggtronic Engineering Srl Manufacturer: Shenzhen Pilot Technology Co., Ltd Product Name: Triple coil embedded wireless charging system Model No.: EGG190098 Trade Mark: Eggtronic Rating(s): Input: DC 12V, 1A Wireless Output: 5W Test Standard(s) : FCC Part15 Subpart C 2019, Paragraph 15.209 Test Method(s): ANSI C63.10: 2013 The device described above is tested by Shenzhen Anbotek Compliance Laboratory Limited to determine the maximum emission levels emanating from the device and the severe levels of the device can endure and its performance criterion. The measurement results are contained in this test report and Shenzhen Anbotek Compliance Laboratory Limited is assumed full of responsibility for the accuracy and completeness of these measurements. Also,this report shows that the EUT (Equipment Under Test) is technically compliant with the FCC Part 15 Subpart C requirements. This report applies to above tested sample only and shall not be reproduced in part without written approval of Shenzhen Anbotek Compliance Laboratory Limited. Date of ReceiptMay 08, 2020 Date of TestMay 08~Jun. 05, 2020 Prepared By (Engineer / Dolly Mo) Reviewer (Supervisor / Bibo Zhang) Approved & Authorized Signer (Manager / Tom Chen) Report No.: 18220WC00049301FCC ID: 2ANP7EGG190098Page 4 of 25 Code:AB-RF-05-a 1. General Information 1.1. Client Information Applicant: Eggtronic Engineering Srl Address: Via Giorgio Campagna 8 41126 Modena Italy Manufactu…

Text truncated - open the document above for the full version.

FCC ID: 2ANP7EGG190098 Photo of Radiation Emission Test Photo of MPE Measurement
