Rev 1/26/2023 Medi Plus Solution Co.,Ltd. B2, 101, 24, Seongbuk-ro 9-gil, Seongbuk-gu, Seoul, South Korea Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 USA Date: Jul, 22, 2024 Ref: Attestation Statements Part 2.911(d)(5)(i) Filing FCC ID: 2ANRT-DF-P01 Medi Plus Solution Co.,Ltd. (“the applicant”) certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. Sincerely, Medi Plus Solution Co.,Ltd. Yoonjung Bae (Applicant signature) Rev 1/26/2023 Medi Plus Solution Co.,Ltd. B2, 101, 24, Seongbuk-ro 9-gil, Seongbuk-gu, Seoul, South Korea Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 USA Date: Jul, 22, 2024 Ref: Attestation Statements Part 2.911(d)(5)(ii) Filing FCC ID: 2ANRT-DF-P01 Medi Plus Solution Co.,Ltd. (“the applicant”) certifies that, as of the date of the filing of the application, the applicant is not identified on the Covered List ( as a specifically named entity or any of its subsidiaries or affiliates) as an entity producing “covered” equipment. Sincerely, Medi Plus Solution Co.,Ltd. Yoonjung Bae (Applicant signature)
Certification designating a U.S. Agent for service of process: As required by section 2.911(d)(7), the applicant must designate a contact located in the United States for purposes of acting as the applicant’s agent for service of process, regardless of whether the applicant is a domestic or foreign entity. An applicant located in the United States may designate itself as the agent for service of process. In either scenario, the designation of the U.S. agent for service of process should be provided as an attachment to the equipment authorization application. The applicant must provide a written certification, which must: i. Be signed by both the applicant and designated agent for service of process, if the agent is different from the applicant. ii. Acknowledge the applicant’s consent and the designated agent’s obligation to accept service of process. iii. Provide a physical U.S. address and email for the designated agent. iv. Acknowledge the applicant’s acceptance to maintain an agent for no less than one year after the grantee has terminated all marketing and importation or the conclusion of any Commission-related proceeding involving the equipment. Unofficial information provided by FCC personnel on February 14, 2023, via the monthly call with the TCB Council: The Agent for Process of Service: • cannot be a TCB or affiliated with a TCB (e.g. could not be a person who works for a TCB or a company that owns or is owned by the TCB) • cannot be a [FCC recognised] Lab or affiliated with a test lab (e.g. could not be a person who works for a Lab or a company that owns or is owned by the Lab) • Agent can be Individual Entity or a Company Entity • Agent Entity must be located in US, US address/phone • Entity acting as Agent must have FRN (best practice, put FRN on Agent Letter) • Agent letter does not have to be FCC ID specific, can be general Agent for Grantee For devices being marketed or for which marketing has ceased for less than 1 year, if the Agent for Process of Service changes, then for every TC Number the TCB must request the FCC to put application into Audit Mode and Agent Letter needs to be updated (superseded). NOTE: The U.S. Agent for Service of Process should not be confused with the authorized agent used for signing the 731 form, other cover letters within the application, and/or the agent who may interface with the TCB. MEDI PLUS SOLUTION CO., LTD. B2, 101, 24, Seongbuk-ro 9-gil , Seongbuk-gu / Seoul South Korea / 02880 U.S. Agent Designation for Service of Process ATTENTION: Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 USA REGARDING: FCC Certification – Section 2.911(d)(7) Information Designated U.S. Agent Company Name: Approve-IT, Inc. Contact Name: Nathan Grinager Street Address: 8011 34 th Ave South, Suite 342 City/Province/Zip: Bloomington, MN 55425 Telephone No: 651-247-1678 Email: [email protected] FRN #: 0027533835 This letter is to confirm that we (“the Designated U.S. Agent) have accepted the responsibility to act as the Designated U.S. Agent for Service of Process as required by section 47 CFR 2.911(d)(7) on behalf of the Applicant noted below. U.S. Agent Signature: Date: July 15, 2024 Signed by (Printed Name/Title): Nathan Grinager / Co-President *This letter is valid indefinitely for all applications submitted within the period of 7/15/2024 – 7/14/2025 The Applicant confirms its explicit consent and acknowledges that they must maintain an agent for no less than one year after terminating all marketing and importation OR the conclusion of any Commission-related proceeding involving the equipment. The applicant further acknowledges their responsibility to inform the FCC whenever the Designated U.S. Agent information above changes. Applicant Company name: MEDI PLUS SOLUTION CO., LTD. Grantee FRN: 0026840660 FCC ID: 2ANRT-DF-P01 Contact Name: Yoonjung Bae Street Address: B2, 101, 24, Seongbuk-ro 9-gil, City/Province/Zip: Seongbuk-gu / Seoul South Korea / 02880 Telephone No: +82-70-4910-3733 Email: [email protected] Applicant Signature: Date: July 15, 2024 Signed by (Printed Name/Title): Yoonjung Bae (CEO)
Medi Plus Solution Co.,Ltd. B2, 101, 24, Seongbuk-ro 9-gil, Seongbuk-gu, Seoul, South Korea Date: Jul, 22, 2024 Timco Engineering, Inc. 849 NW State Road 45 Newberry, FL 32669 SUBJECT: Application for Certification for FCC ID: 2ANRT-DF-P01 To Whom It May Concern: We, the undersigned, hereby authorize SangHoon, Yu at Lab-T, Inc. on our behalf, to apply to the Federal Communications Commission on our equipment. Any and all acts carried out by SangHoon, Yu at Lab-T, Inc. on our behalf shall have the same effect as acts of our own. This is to advise that we are in full compliance with the Anti- Drug Abuse Act. We, the applicant, are not subject to a denial of federal benefits pursuant to Section 5301 of the Anti-Drug Act of 1988, 21 USC853a, and no party to the application is subject to a denial of federal benefits pursuant to that section. Regards, (Signature) Yoonjung Bae / CEO +82-70-4910-3733 B2, 101, 24, Seongbuk-ro 9-gil, Seongbuk-gu, Seoul, South Korea
Medi Plus Solution Co.,Ltd. B2, 101, 24, Seongbuk-ro 9-gil, Seongbuk-gu, Seoul, South Korea Federal Communications Commission Authorization and Evaluation Division Confidentiality Request regarding application for certification of FCC ID: 2ANRT-DF-P01 Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, we hereby request confidential treatment of information accompanying this application as outlined below: Exhibit Type File Name - Block Diagram - Schematics - Operational Description - Tune-up Procedure - 06. Block Diagram.pdf - 07. Schematics.pdf - 10. Operation Description.pdf - 12. Tune-up procedure.pdf The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Pursuant to DA04-1705 June 15, 2004 of the Commission’s public notice, we also request temporary confidential treatment of information accompanying this application as outlined below for a period of 180 days Exhibit Type File Name - RF Test Setup photos - Internal Photos - User manual - 03. Test Setup Photos.pdf - 05. Internal Photos.pdf - 08. User Manual.pdf (Signature) Yoonjung Bae / CEO +82-70-4910-3733 B2, 101, 24, Seongbuk-ro 9-gil, Seongbuk-gu, Seoul, South Korea
Page: 1 / 5 Copyright ⓒ 2024, Lab-T, Inc. External Photos Page: 2 / 5 Copyright ⓒ 2024, Lab-T, Inc. External Photos Front Rear Page: 3 / 5 Copyright ⓒ 2024, Lab-T, Inc. External Photos Top Bottom Page: 4 / 5 Copyright ⓒ 2024, Lab-T, Inc. External Photos Left Right Page: 5 / 5 Copyright ⓒ 2024, Lab-T, Inc. External Photos Charger_Front Charger_Rear
Copyright ⓒ 2024 Lab-T, Inc. Label Information
Step.2-2 {[Power allowed at numeric threshold for 50 mm in step a)] + [(test separation distance – 50 mm)· (f(MHz)/150)]} mW, for 100 MHz to 1500 MHz {[Power allowed at numeric threshold for 50 mm in step a)] + [(test separation distance – 50 mm)·10]} mW, for > 1500 MHz and ≤ 6 GHz KDB447498 was used as the guidance. SAR test exclusion considerations Step.1 For 100 MHz to 6 GHz and test separation distances ≤ 50 mm, the 1-g and 10-g SAR test exclusion threshold are determined by the following : [(max. power of channel, including tune-up tolerance, mW) / (min. test separation distance, mm)] · [√f(GHz)] ≤ 3.0 for 1-g SAR, and ≤ 7.5 for 10-g extremity SAR where f(GHz) is the RF channel transmit frequency in GHz Power and distance are rounded to the nearest mW and mm before calculation The result is rounded to one decimal place for comparison Step.2 For 100 MHz to 6 GHz and test separation distances > 50 mm, the 1-g and 10-g SAR test exclusion thresholds are determined by the following The test exclusions are applicable only when the minimum test separation distance is ≤ 50 mm, and for transmission frequencies between 100 MHz and 6 GHz. When the minimum test separation distance is < 5 mm, a distance of 5 mm according to 4.1 f) is applied to determine SAR test exclusion. The values 3.0 and 7.5 are referred to as numeric thresholds in step b) below Step.2-1 RF EXPOSURE FCC ID : 2ANRT-DF-P01 Copyright ⓒ 2024. Lab-T, Inc. Page :1 / 2 ( f(GHz) : the RF channel transmit frequency in GHz 1.00dBm = [(P(mW) / R)] X [√f(GHz)] 7.5< mm ) =S : Maximum Estimated SAR P(mW) : Max tuneup Power (mW)= [[(1.26/ 1.00 dB- Target Power & Tolerance :0.00 dBm&± 1.00 dBm Maximum : mW √( 2.48 ) - Frequency Range :2 402 MHz~2 480 - Measured RF Maximum Output Power :0.35 dBm 10.00 The EUT will only be used with a separation of 10 millimeters between the antenna and the body of the The MPE calculation for this exposure is shown below. (&Minimum :-1.00 dBm 1.26 SAR test exclusion considerations : Bluetooth LE MHz ) P : Max tuneup Power (dBm) - Maximum Output Power for the Calculation : - NOTE- P= = 1.00 dBm ] 0.198 26 Power Density at the specific separation - NOTE- S This device is intended to be used under limb exposure conditions. (≤ 7.5 for 10-g extremity SAR) 10.00)]X R : Distance to the center of the radiation of the antenna Copyright ⓒ 2024. Lab-T, Inc. Page :2 / 2
REPORT No.:TRRFCC24-0012(1) Total 49 pages TRF-R-003(00) Page: 2 / 49 Copyright ⓒ 2024, Lab-T, Inc. CONTENTS 1. Revision history ........................................................................................................................................ 3 2. Information ................................................................................................................................................ 4 2.1 Applicant Information................................................................................................................................ 4 2.2 Test Laboratory information...................................................................................................................... 4 2.3 Test Site.................................................................................................................................................... 4 3. Information About Test Equipment ......................................................................................................... 5 3.1 Equipment Information ............................................................................................................................. 5 3.2 Antenna Information ................................................................................................................................. 5 3.3 Test Frequency ......................................................................................................................................... 5 3.4 Operation conditions for the EUT ............................................................................................................. 5 4. Test Report ................................................................................................................................................ 6 4.1 Summary .................................................................................................................................................. 6 4.2 Measurement Uncertainty ........................................................................................................................ 6 4.3 Transmitter Requirements ........................................................................................................................ 7 4.3.1 Antenna Requirement ........................................................................................................................ 7 4.3.2 Maximum Peak Output Power........................................................................................................... 8 4.3.3 Peak Power Spectral Density .......................................................................................................... 10 4.3.4 6 dB Bandwidth(DTS Bandwidth) .................................................................................................... 16 4.3.5 Spurious Emission, Band Edge, and Restricted bands .................................................................. 26 4.3.6 Conducted Emission ....................................................................................................................... 46 APPENDIX I .................................................................................................................................................... 48 REPORT No.:TRRFCC24-0012(1) Total 49 pages TRF-R-003(00) Page: 3 / 49 Copyright ⓒ 2024, Lab-T, Inc. 1. Revision history Test Report No. Date Description TRRFCC24-0012 2024-07-23 Initial issue TRRFCC24-0012(1) 2024-07-25 Added Conducted Emission REPORT No.:TRRFCC24-0012(1) Total 49 pages TRF-R-003(00) Page: 4 / 49 Copyright ⓒ 2024, Lab-T, Inc. 2. Information 2.1 Applicant Information Applicant name Medi Plus Solution Co.,Ltd. Address B2, 101, 24, Seongbuk-ro 9-gil, Seongbuk-gu, Seoul, South Korea Telephone No. +82-70-4910-3733 Person in charge Yoonjung Bae Manufacturer Medi Plus Solution Co.,Ltd. Address B2, 101, 24, Seongbuk-ro 9-gil, Seongbuk-gu, Seoul, South Korea 2.2 Test Laboratory information Corporate name Lab-T, Inc. Representative Duke (Jongyoung) Kim Address 2182-42 Baegok-daero, Mohyeon-eup, Cheoin-gu, Yongin-si, Gyeonggi-do 17036, Korea(Republic of) Telephone +82-31-322-6767 Fax +82-31-322-6768 E-mail [email protected] FCC/IC Designation No. KR0159 2.3 Test Site Test Site used Address Building L 2182-40 Baegok-daero, Mohyeon-eup, Cheoin-gu, Yongin-si, Gyeonggi-do 17036, Korea(Republic of) Building T 2182-42 Baegok-daero, Mohyeon-eup, Cheoin-gu, Yongin-si, Gyeonggi-do 17036, Korea(Republic of) Building A 2182-44 Baegok-daero, Mohyeon-eup, Cheoin-gu, Yongin-si, Gyeonggi-do 17036, Korea(Republic of) REPORT No.:TRRFCC24-0012(1) Total 49 pages TRF-R-003(00) Page: 5 / 49 Copyright ⓒ 2024, Lab-T, Inc. 3. Information About Test Equipment 3.1 Equipment Information Equipment type DOFIT PRO Model name DF-P01 Variant model name - Frequency range 2 402 MHz ~ 2 480 MHz Modulation Type (Symbol rate / Data rate) GFSK(1 Msps, 2 Msps / 1 Mbps, 2 Mbps) Modulation Technology Bluetooth LE 1 Mbps, 2 Mbps Power supply DC 3.7 V H/W version 1.0 S/W version 12.36 Note1: The above EUT information was declared by the manufacturer. 3.2 Antenna Information Type Model No. Gain Note Wire Antenna - 1.63 dBi - 3.3 Test Frequency Test mode Test frequency (MHz) Lowest frequency Middle frequency Highest frequency Bluetooth LE 1 Mbps 2 402 2 440 2 480 Bluetooth LE 2 Mbps 2 402 2 440 2 480 3.4 Operation conditions for the EUT Firmware state 12.36 Test software name(version) FCC/CE/BQB certification test instructions (Rev1.9) Test power setting Default setting value Serial number (Setup mode) EUT #1 #1 (RF conducted measurement) EUT #2 #2 (Radiated Emission, Conducted Emission) REPORT No.:TRRFCC24-0012(1) Total 49 pages TRF-R-003(00) Page: 6 / 49 Copyright ⓒ 2024, Lab-T, Inc. 4. Test Report 4.1 Summary FCC Part 15 FCC Rule Parameter Clause Status Transmitter Requirements 15.203 15.247(b)(4) Antenna Requirement 4.3.1 C 15.247(b)(3) Maximum Peak Output Power 4.3.2 C 15.247(e) Peak Po…
Text truncated - open the document above for the full version.
Copyright ⓒ 2024. Lab-T, Inc. Antenna datasheet 规 格 书 SPECIFICATION V1.00 项目名称 Project Name 客户 Customer 天线类型 Antenna Type 2.4G天线 客户终端型号 Terminal Type 产品编号 Product No. 客户编号 Customer NO. 主管签字 Confirmation 客户承认 CustomerApproved 日期 Date 2019/6/5 日期 Date 目录 规 格 书 1 目录 2 1.一般事项/GENERAL 3 2.产品一般规格/SPECIFICATION 3 3.产品规格明细/SPECIFICATION DETIALS 4 3.1产品结构参数/MECHANICAL PROPERTIES 4 3. 2产品电性能测试数据/ELECTRIC PERFORMANCE 5 4. 产品包装方式/PRODUCT PACKAGING 9 5. 文档履历/DOCUMENT RESUME 10 1.一般事项/General 1.1 适用范围/Scope 本规格书只适用于外置2.4G内置天线 1.2 使用温度范围/Operating Temperature Range 本产品使用温度范围-20 ~ +65 °C 1.3 保存温度范围/Preservation Temperature Range 本产品保存于-30 ~ +75 °C 2.产品一般规格/Specification 简述 Rough description 条目 Item Initiall Specification Fina Specification 尺寸 Dimensions 20mm*0.6mm 阻抗 Impedance 50Ω 测试环境 Test environment Free space 应用模式 Spectrum BT 频率范围 Freq. Range 2.4~2.5 GHz 天线形式 Antenna type Wire mono pole antenna 驻波比 VSWR 2.4~2.5 GHz < 2.0 增益 Gain 2.4~2.5 GHz :0.5-1dBi(Peak gain) 辐射方向 Radiation Omni 极化方式 Polarization Linear 辐射效率 Rad. efficiency 2.4~2.5 GHz >40% 连接头型号 Connector type 电缆型号 Cable type 电缆长度 Cable length(Total) 绝缘 Isolation None 3.产品规格明细/Specification Detials 3.1产品结构参数/Mechanical Properties 3.11产品物料组成/Product Composition: 序号/No. 材料/Material 规格(MM)/Size 1 铜 20mm*0.6mm 2 3.12 外观/Apperance 产品外观良好,无伤痕、汗迹、突起等严重影响外观缺陷。 Good appearance without scars 、dirts、protuberances, etc. 3.13产品图片及结构图纸/Antenna Picture and Structure Dimension 产品图片/Entity Picture: 产品图纸/Antenna Drawing: 3. 2产品电性能测试数据/Electric Performance 3.21测试环境及仪器设备/Test condition 测试环境/Environment: 温度/Temperature: 10°C——+30°C 相对湿度/Humidity:≤80%(+40°C) 大气压力/Atmosphere:750mmkg±30mmkg 测试设备/Equipment: Network Analyzer: HP8753D网络分析仪 Anechior Chamber: ETS微波暗室 3.22 产品电性能测试数据/Test Data for Electrical Performance: WiFi天线的S11图: 频率/Marker 2400MHz 2450MHz 2500MHz 反射衰减/Returnloss -13.9 -14.9 -12.5 驻波比/VSWR 1.5 1.45 1.7 Smith图: 增益方向图/Gain and Radiation Pattern 频率/Marker 2400MHz 2450MHz 2500MHz 增益/PeakGain(dBi) 0.59 1.12 1.63 效率/Efficiency(%) 54.7 63.2 73.4 频率点/Frequency 2450MHz 3D H面 E面 4. 产品包装方式/Product Packaging 包装方式/Package: 5. 文档履历/Document Resume 文件编号 Document No. 日期 Release Date 2019/06/5 编制 Author Hungjie 复核 Review WH 文件历次表/Revised History Date Version Revised Record 2018/03/24 1.00 New Project
| # | Rule Parts | Frequency Range | Power Output |
|---|---|---|---|
| 1 | 15C | 2.40 GHz - 2.48 GHz | 1.10 mW |

YAKOOK
Equipment Class
DTS - Digital Transmission System
