2ANYX-RF-R-1FLEDFlex LED Receiver

UNI FAN SL-INF FLEX 120 Installation Guide ▪Guide d'installation

▪Installationsanleitung

▪Guía de instalación ▪Installationsguide ▪Instrukcja instalacji

▪Руководство
по
установке ▪安裝指南

▪インストールガイド Package Contents - 1 -- 2 -- 3 -- 4 - ▪Contenu du colis

▪Verpackungsinhalt

▪Contenido del paquete

▪Förpackningens innehåll

▪Zawartość opakowania




▪Содержимое
упаковки

▪包裝內容物

▪パッケージ内容物 Receiver cable direction conversion diagram ▪Schéma de conversion de direction du câble du récepteur

▪Diagramm zur Richtungsumwandlung des Empfängerkabels

▪Diagrama de conversión de dirección del cable del receptor

▪Diagram för riktningsomvandling av mottagarkabel

▪Schemat zmiany kierunku przewodu odbiornika

▪Схема
изменения
направления
кабеля
приемника

▪接收器電線轉換方向示意

▪レシーバーケーブル方向変換図 Switch direction Max 4 LED fans per channel LED FAN LED FANLCD FAN No Mix of LED and LCD Fan to Fan Connection ▪Connexion ventilateur à ventilateur ▪Lüfter-zu-Lüfter-Verbindung

▪Conexión de ventilador a ventilador

▪Fläkt till fläkt-anslutning ▪Połączenie wentylatora z wentylatorem
▪Соединение
вентиляторов
между
собой ▪風扇之間的連接

▪ファン同士の接続




▪Check orientation ▪Attention au sens ▪Richtung beachten ▪Cuidado con la orientación ▪Kontrollera riktning ▪Zwróć uwagę na kierunek ▪Соблюдайте
ориентацию ▪注意方向 ▪方向注意 Receiver installation ▪Installation du récepteur

▪Empfängerinstallation

▪Instalación del receptor

▪Installation av mottagare ▪Instalacja odbiornika

▪Установка
приемника

▪接收器安裝

▪レシーバーの取り付け Secure direction - 3 - 21 Supports cable output on both sides ▪Prend en charge la sortie de câble des deux côtés

▪Unterstützt beidseitige Kabelführung ▪Compatible con salida de cable en ambos lados

▪Stöder kabelutgång på båda sidor ▪Obsługuje wyprowadzenie kabli po obu stronach

▪Поддерживает
вывод
кабеля
с
двух
сторон ▪支援雙邊出線

▪両側配線対応 Usage of the Rubber Pads ▪Utilisation des patins en caoutchouc ▪Verwendung der Gummipads ▪Uso de las almohadillas de goma ▪Användning av gummidynor ▪Zastosowanie podkładek gumowych
▪Использование
резиновых
прокладок

▪橡膠墊使用方式
▪ゴムパッドの使用方法

▪Remove fan clip if radiator ports interfere ▪Retirer le clip si les ports du radiateur gênent ▪Clip entfernen bei Störung durch Radiatoranschlüsse ▪Retire el clip si los puertos del radiador interfieren ▪Ta bort klämman om radiatorportar stör ▪Usuń klips, jeśli porty chłodnicy przeszkadzają ▪Снимите
клипсу,
если
порты
радиатора
мешают ▪若水冷排進出水干涉，移除卡扣鎖 ▪干渉時はクリップを取り外す ▪Install screws and replace rubber pads for a clean look ▪Visser et remplacer les patins pour un rendu propre ▪Schrauben einsetzen, Gummipads ersetzen ▪Instalar tornillos y cambiar almohadillas ▪Skruva fast och byt gummipads ▪Zamontuj śruby i wymień podkładki ▪Установить
винты
и
заменить
прокладки ▪安裝螺絲並更換橡膠墊，外觀更整潔 ▪ネジ固定・ゴムパッド交換で見た目を整える Remove the Fan Interlocking Key ▪Retirez la clé d’interconnexion du ventilateur ▪Entfernen Sie den Lüfterverriegelungsschlüssel ▪Retire la llave de interconexión del ventilador

▪Ta bort fläktens sammankopplingsnyckel ▪Usuń klucz blokujący wentylator

▪Снятие
фиксатора
вентилятора


▪風扇扣鎖拆除


▪ファン連結キーを取り外します
Receiver cable management ▪Gestion des câbles du récepteur

▪Kabelführung des Empfängers

▪Organización de cables del receptor ▪Kabelhantering för mottagare

▪Organizacja przewodów odbiornika

▪Укладка
кабелей
приемника ▪接收器電線整理

▪レシーバー配線整理 ac d b e 2.4g wireless spec : frequency 2402-2480MHz Transmition : Below 10mw LIAN LI INDUSTRIAL CO., LTD. 2F., NO. 20, ANKANG RD., NEIHU DIST., TAIPEI CITY 114, TAIWAN [email protected] 低功率射頻器材技術規範 取得審驗證明之低功率射頻器材，非經核准，公司、商號或使用者均不得擅自變更頻率、加大功率或變更原設計之特性及 功能。低功率射頻器材之使用不得影響飛航安全及干擾合法通信；經發現有干擾現象時，應立即停用，並改善至無干擾時 方得繼續使用。前述合法通信，指依電信管理法規定作業之無線電通信。低功率射頻器材須忍受合法通信或工業、科學及 醫療用電波輻射性電機設備之干擾。 ▪
3-Year Warranty ▪ Garantie de 3 an ▪ 3 Jahr Garantie ▪ 3 año de garantía ▪ 3 års garanti ▪ 3 rok gwarancji ▪
Гарантия
3
год ▪ 3 年保固 ▪
3 年間保証 Usage of the Pin Cover ▪Utilisation du capuchon de broche ▪Verwendung der Stiftabdeckung ▪Uso de la cubierta del pin ▪Användning av stiftlocket ▪Zastosowanie osłony pinów

▪Использование
защитной
крышки
контактов ▪風扇塑膠薄片使用

▪ピンカバーの使用方法 ▪Exposed POGO PIN contacts may short if touched by metal; use a plastic cover for protection. ▪Les broches POGO exposées peuvent provoquer un court-circuit; utilisez une protection en plastique. ▪Freiliegende POGO-PINs können Kurzschluss verursachen; Kunststoffschutz verwenden. ▪Los pines POGO expuestos pueden causar cortocircuito; use protección plástica. ▪Exponerade POGO-pinnar kan kortsluta; använd plastskydd. ▪Odsłonięte piny POGO mogą powodować zwarcie; użyj osłony z tworzywa. ▪Открытые
POGO-пины
могут
вызвать
короткое
замыкание;
используйте
пластиковую
защиту. ▪POGO
PIN端子外露易短路，建議加塑膠片保護。 ▪POGO
PIN露出部は短絡の恐れがあるため保護カバー推奨。 FCC Caution. This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Any Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: -Reorient or relocate the re…

Text truncated - open the document above for the full version.

LIANLIINDUSTRIALCO.,LTD. CoveredEquipmentCertificationAttestationLetter 8/3/2026 NemkoNorthAmerica,Inc. 303RiverRoad Ottawa K1V1H2 Canada ATTN.:ReviewingEngineer FCCID:2ANYX-RF-R-1FLED LIANLIINDUSTRIALCO.,LTD.(“theapplicant”)certifiesthattheequipmentforwhich authorizationissoughtisnot“covered”equipmentprohibitedfromreceivingan equipmentauthorizationpursuanttosection2.903oftheFCCrules. Note:Iftheequipmentforwhichtheapplicantseeksauthorizationisproducedby anyoftheentitiesidentifiedonthecurrentCoveredList,theapplicantshould includeanexplanationonwhytheequipmentisnot“covered”equipment. LIANLIINDUSTRIALCO.,LTD.(“theapplicant”)certifiesthat,asofthedateofthefiling oftheapplication,theapplicantisnotidentifiedontheCoveredListasanentity producing“covered”equipment. LIANLIINDUSTRIALCO.,LTD.(“theapplicant”)certifiesthattheequipmentforwhich authorizationissoughtdoesnotincludecybersecurityoranti-virussoftwareproducedor providedbyKasperskyLab,Inc.oranyofitssuccessorsandassignees,including equipmentwithintegratedKasperskyLab,Inc.(oranyofitssuccessorsandassignees) cybersecurityoranti-virussoftwarepursuanttoDA-24-886andKDB986446D01 CoveredEquipmentGuidancesectionB(2a). Signed: Printedname:JOVIWEI Title:Manager CompanyName:LIANLIINDUSTRIALCO.,LTD. Date:8/3/2026

LIANLIINDUSTRIALCO.,LTD. 8/3/2026 NemkoNorthAmerica,Inc. 303RiverRoad Ottawa,Ontario,Canada K1V1H2 REQUESTFORCONFIDENTIALITY-FCC FCCID:2ANYX-RF-R-1FLED PursuanttoSections0.457(d)(1)(ii)and0.459oftheCommission’sRulesandFCCGuidance document726920,weherebyrequestconfidentialtreatmentofinformationaccompanyingthis applicationasoutlinedbelow: PERMANENTLONG-TERMCONFIDENTIALITY: Schematics BlockDiagrams TheoryofOperation Theaboveinformationcontainstradesecretsandproprietaryinformationnotcustomarilyreleasedto thepublic.Thepublicdisclosureofthisinformationmightbeharmfultotheapplicantandprovide unjustifiedbenefitstoitscompetitors.TheApplicantunderstandsthatpursuanttoRule 0.457(d)(1)(ii),disclosureofthisApplicationandallaccompanyingmaterialswillnotbemadebefore thedateoftheGrantforthisApplication. Sincerely, Signed: Printedname:JOVIWEI Title:Manager

FCCID:2ANYX-RF-R-1FLED FCCID:2ANYX-RF-R-1FLED FCCID:2ANYX-RF-R-1FLED FCCID:2ANYX-RF-R-1FLED FCCID:2ANYX-RF-R-1FLED FCCID:2ANYX-RF-R-1FLED FCCID:2ANYX-RF-R-1FLED

LabelandLabelLocation

FCCID:2ANYX-RF-R-1FLED FCCID:2ANYX-RF-R-1FLED

Page 1 of 3 RF EXPOSURE EVALUATION FCC ID: 2ANYX-RF-R-1FLED Product Name : Flex LED Receiver Model Name : RF-R-1FLED Operating frequency : 2402-2480MHz Numbers of Channel : 40 channels for 2.4G SRD Antenna Type : PCB antenna Antenna Gain : 2.1dBi Type of Modulation : GFSK Power supply : DC12V(USB HUB DC5V) Hardware Version : V1.0 Software Version : V1.0 Page 2 of 3 Standard Requirement According to § 15.249 and § 1.1307b(1), systems operating under the provisions of this section shall be operated in a manner that ensures that the public is not exposed to radio frequency energy levels in excess of the Commission’s guidelines. See KDB 447498 D01 General RF Exposure Guidance v06, section 4. 3. 1. The 1-g and 10-g SAR test exclusion thresholds for 100MHz to 6GHz at test separation distances ≤ 50mm are determined by: [ (max. power of channel, including tune-up tolerance, mW)/(min. test separation distance, mm)]*[ √f(GHz)] ≤3.0 for 1-g SAR and ≤7.5 for 10-g SAR extremity SAR, where ⚫ f(GHz) is the RF channel transmit frequency in GHz ⚫ Power and distance are rounded to the nearest mW and mm before calculation ⚫ The result is rounded to one decimal place for comparison. The test exclusions are applicable only when the minimum test separation distance is ≤ 50mm and for transmission frequencies between 100MHz and 6GHz. When the minimum test separation distance is <5mm, a distance of 5mm is applied to determine SAR test exclusion. Routine SAR evaluation refers to that specifically required by § 2.1093, using measurements or computer simulation. When routine SAR evaluation is not required, portable transmitters with output power greater than the applicable low threshold require SAR evaluation to quality for TCB approval. RF Output power Freq. (MHz) Field strength(max)(dBuV/m) EIRP (max) (dBm) 2440 94.21 -0.99 Note: EIRP=E-104.8+20logD, Where E is the electric field strength in dBμV/m. EIRP is the equivalent isotropically radiated power in dBm. d is the specified measurement distance in m. where D=3, EIRP=E-95.2. Page 3 of 3 Channel (MHz) Maximum output power (dBm) Tune up tolerance (dBm) Max Tune Up Power (mW) Distance(mm) Calculation results Limit Operating Mode 2440 -0.99 -0.99±1 1.002305 5 0.313130 3 GFSK_1Mbps According to KDB 447498, The device only support 2.4G SRD function, and no simultaneous SAR measurement is required. Signature Simon Pu Manager Date: 2026-07-28
