2AO2V-HSU002Wireless charger with sterilizing Box

多功能杀菌盒 使用说明书 产品介绍使用步骤 适用杀菌范围 工作方式： 1，关闭盒子自动开启杀菌模式，每半小时自动开启杀菌一次， 每次3分钟。 2，开盖关闭杀菌，盒盖后再次转为3分钟的持续杀菌 3，自动杀菌16次后（即8小时），自动关闭杀菌功能，等到 下次开盖再次重复。 4，盒盖时，任何状态长按开关一次，开启强杀菌模式，持续 杀菌15分钟，15分钟后关闭杀菌功能。如有开启无线充 功能，则无线充不受影响。 产品参数 常见菌种及疾病参考 包装清单 菌种 易引发的疾病 本款产品是一款紫外线杀菌盒，采用紫外线杀菌技术， 杀菌只需3分钟。杀菌率达99.9%，无辐射，使用安全放心 1 1 2 3 4 1 2 3 2 4 5 3 开关按键 无线指示灯 杀菌指示灯（环形灯） LED杀菌灯珠 5USB接口（Type-C) 杀菌盒*1 USB线（Type-C)*1 使用说明书*1 4 绒布袋*1 1.先将USB线连接产品Type-C接口 用于日常使用小物件的杀菌，如手机类电子产品、女性 化妆用品、婴儿奶嘴类、等各种小物件。 1.产品名称：多功能杀菌盒 手足口病病毒发热、皮疹、心肌炎、脑膜炎等 淋病奈瑟菌尿道炎、宫颈炎、关节炎、脑膜炎 肝炎病毒甲肝、乙肝等病毒性肝炎 痢疾杆菌痢疾等肠道传染病 伤寒沙门菌伤寒、肠热症、胃肠炎、败血症等 流感病毒流感性感冒、禽流感等 大肠杆菌腹泻、败血症、尿道感染等 结核杆菌结核病、炎症等 诺如病毒感染性腹泻、呕吐、腹部疼痛等 2.产品型号：HSU-002 3.额定输入：5V/2A 4.输入接口：USB接口（T ype-C） 7.LED灯珠数量：6*2mW 5.LED波长：260-280nm 6.机身尺寸：245*134*60(mm) 杀菌原理 通过LED紫外线杀菌，紫外线能够破坏细菌的DNA或 者RNA分子结构，使细菌彻底死亡，不能繁衍再生。 安全保护 产品内置智能保护系统，在消毒时不小心打开盒子，紫 外线将立刻停止杀菌工作，防止紫外线直接照射到眼睛、皮 肤造成伤害。 8.辐射照度： 9.灯珠寿命：5000小时 10.温度：工作温度（0~40 C），储存温度（-20~55 C） 充电温度（0~40 C） 1000 2 W/cm 禁止水洗远离火源 2.将需要杀菌的物品平整地放入盒子中关闭，指示灯亮蓝色， 并开始杀菌（指示灯停止呼吸闪烁，杀菌完成） 3.手机无线充电 将产品连接电源，把手机放入杀菌盒中。 单击按键打开无线充电，此时无线充电的指示灯在闪烁2次 后常亮蓝色。双击按键关闭无线充电，指示灯也一起熄灭。 温馨提示 ■ 本产品选用高品质环保材质，敬请放心使用。 ■ 本产品在开盖时，禁止裸眼直视杀菌灯。 ■ 切勿摔碰、自行拆开或刺穿本产品。 ■ 勿将本产品暴露在火中、高温中或水中。 ■ 使用本产品时建议选用正规品牌电源充电器、USB线。 ■ 如果发现杀菌盒有其他不良现象，请停止使用。 ■ 此设备不适用于生理、感知和心智能力低下的人士（包括 孩童），也不适用于缺乏相关经验和知识的人士，除非 有专门负责他们人身安全的人士监督或指导他们使用此 设备。应当看管好小孩，以确保不将此设备当作玩具。 禁止裸眼直视 Model： HSU-002 Multi-function UVC Sterilization Box Instruction Product introductionUsing steps Applicable sterilization scope Product parameters Common bacteria and disease reference BacteriaPredisposing diseases The product is UVC sterilization box, made of the technolofy of UVC sterilization.It takes only 3 minutes for one key sterilization. The bactericidal rate is 99.9%. No radiation, Be safe and reliable. 2. Put the things into the box flat and close the box. The round breathing light will be blinked with blue color. Then start to sterilize the things.(The light will be stopped to blink when the sterilization is completed) 1 1 2 3 4 2 3 4 5 Switch Key Wireless charging indicator Sterilization light (Round style) Led sterilization lamp 5 USB port (Type-C) FCC STATEMENT : This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1)This device may not cause harmful interference, and (2)This device must accept any interference received, including interference that may cause undesired operation. Warning: Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: Reorient or relocate the receiving antenna. Increase the separation between the equipment and receiver. Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. Consult the dealer or an experienced radio/TV technician for help. FCC Radiation Exposure Statement: This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance 20cm between the radiator & your body. 1. Connect the USB cable to the type-C port firstly. For daily use of small objects sterilization, such as mobile phone or electronic products, women's cosmetics, baby nipples, and other small objects. 1. Product Name: multi-function UVC sterilization box HFMD virusFever, rash, myocarditis, meningitis, etc Neisseria gonorrhoeae Urethritis, cervicitis, arthritis, meningitis hepatitis virus Hepatitis A, hepatitis B and other viral hepatitis Shigella dysenteriens Diarrhea and other intestinal infectious diseases Salmonella typhiTyphoid, enterofebrile, gastroenteritis, septicemia, etc Influenza virusInfluenza, avian influenza, etc Escherichia coliDiarrhea, septicemia, urinary tract infection, etc Mycobacterium tuberculosis Tuberculosis, inflammation, etc Norovirus Infectious diarrhea, vomiting, abdominal pain, etc 2. Product model: HSU-002 3. Rated input: 5V / 2A 4. Input port: Type-C 7. Power of LED: 6 * 2mW 5. Led wavelength: 260-280nm 6. Product size: 245 * 134 * 60 (mm) 8. Irradiance: 9. LED life: 10000 hours 10. Temperature: working temperature (0 ~ 40 C), storage temperature (- 20 ~ 55 C), charging temperature (0 ~ 40 C) Sterilization principle Through LED ultraviolet sterilization, ultraviolet can destroy the DNA or RNA molecular structure of bacteria, so that bacteria will be died completely and not be reproduced. Safeguard Operation mode The product is equipped with a built-in intelligent protection system. If the box was opened carelessly during disinfection, The sterilization will be stoped immediately. So it could prevent the damage caused by direct ultraviolet radiation to eyes or skin. 3. Wireless charging for mobile phone (connect the power supply and put the phone into the box. Single-click the key to turn on wireless charging.The wireless indicator will be blue after blinking twice Double-click the key to turn off wireless charging. The wireless indicator will be also turned off. 500 2 W/cm Sterilization mode 1. Start the sterilization mode automatically when contact to the power. The sterilization time is 3 mintues per time. Then start the sterilization every half an hour automatically. 2.Ope…

Text truncated - open the document above for the full version.

FCC ID: 2AO2V-HSU002

FCC ID: 2AO2V-HSU002

version01 Shenzhen Hongshanjie Technology Co., Ltd Declaration concerning Antenna Specification It is hereby declared that the product Model No.: HSU-002, CASETiFY_UV001 FCC ID : 2AO2V-HSU002 fulfills the requirement in FCC test relating to the antenna type. The device specified above confirms to the FCC recommendations for internal antenna type(s) described below: Model No. of antenna: HSU-002 Type of antenna:Inductive loop coil Antenna Gain of the antenna: 0 dBi Frequency range:110.1-205KHz The mounting of the antenna is fixed to the radio module and no other antenna should be used. Company name: Shenzhen Hongshanjie Technology Co., Ltd Address: Hongshanjie Industrial Park, Longyankeng, Jiuwei Community, Xixiang Street, Bao'an, Shenzhen China City:Shenzhen ZIP / Postal code: N/A Country:Shenzhen Place: Shenzhen Date: 2020-04-17 Signature:

Report No.: 18220WC00025502FCC ID: 2AO2V-HSU002Page 1 of 13 Code:AB-RF-05-a FCC TEST REPORT Client Name: Shenzhen Hongshanjie Technology Co., Ltd Address: Hongshanjie Industrial Park, Longyankeng, Jiuwei Community, Xixiang Street, Bao'an, Shenzhen China Product Name: Wireless charger with sterilizing Box Date: Apr. 17, 2020 Shenzhen Anbotek Compliance Laboratory Limited Report No.: 18220WC00025502FCC ID: 2AO2V-HSU002Page 2 of 13 Code:AB-RF-05-a Contents 1. General Information ............................................................................................................................................... 4 1.1. Client Information ....................................................................................................................................... 4 1.2. Description of Device (EUT) ..................................................................................................................... 4 1.3. Auxiliary Equipment Used During Test ................................................................................................... 5 1.4. Test Equipment List .................................................................................................................................... 5 1.5. Measurement Uncertainty ......................................................................................................................... 5 1.6. Description of Test Facility ........................................................................................................................ 5 2. Measurement and Result ..................................................................................................................................... 6 2.1. Requirements .............................................................................................................................................. 6 2.2. Test Setup .................................................................................................................................................... 7 2.3. Test Procedure ............................................................................................................................................ 7 2.4. Test Result ................................................................................................................................................... 7 2.4.1. Equipment Approval Considerations item 5.b of KDB 680106 D01 v03. ...................................... 7 2.4.2. Environmental evaluation and exposure limit according to FCC CFR 47 part 1, 1.1307(b), 1.1310 .................................................................................................................................................................. 9 APPENDIX I -- TEST SETUP PHOTOGRAPH ................................................................................................... 11 Report No.: 18220WC00025502FCC ID: 2AO2V-HSU002Page 3 of 13 Code:AB-RF-05-a TEST REPORT Applicant: Shenzhen Hongshanjie Technology Co., Ltd Manufacturer: Shenzhen Hongshanjie Technology Co., Ltd Product Name: Wireless charger with sterilizing Box Model No.: HSU-002, CASETiFY_UV001 Trade Mark: N.A. Rating(s): Input: DC 5V, 2A Wireless Output: 5W Test Standard(s) : FCC Part 1.1310, 1.1307(b) Test Method(s): KDB680106 D01 RF Exposure Wireless Charging Apps v03 The device described above is tested by Shenzhen Anbotek Compliance Laboratory Limited to determine the maximum emission levels emanating from the device and the severe levels of the device can endure and its performance criterion. The measurement results are contained in this test report and Shenzhen Anbotek Compliance Laboratory Limited is assumed full of responsibility for the accuracy and completeness of these measurements. Also,this report shows that the EUT (Equipment Under Test) is technically compliant with the FCC Part 1.1307 & KDB680106 D01 requirements. This report applies to above tested sample only and shall not be reproduced in part without written approval of Shenzhen Anbotek Compliance Laboratory Limited. Date of ReceiptMar. 24, 2020 Date of TestMar. 24~Apr. 16, 2020 Prepared By (Engineer / Dolly Mo) Reviewer (Supervisor / Bibo Zhang) Approved & Authorized Signer (Manager / Tom Chen) Report No.: 18220WC00025502FCC ID: 2AO2V-HSU002Page 4 of 13 Code:AB-RF-05-a 1. General Information 1.1. Client Information 1.2. Description of Device (EUT) Product Name : Wireless charger with sterilizing Box Model No.: HSU-002, CASETiFY_UV001 (Note: All samples are the same except the model appearance, so we prepare "HSU-002" for test only.) Trade Mark: N.A. Test Power Supply: AC 120V, 60Hz for adapter Test Sample No.: 1-2-1(Normal Sample), 1-2-1(Engineering Sample) Product Description : Operation Frequency:110.1-205KHz Modulation Type:Backscatter Antenna Type:Inductive loop coil Antenna Antenna Gain(Peak):0 dBi Remark:1) For a more detailed features description, please refer to the manufacturer’s specifications or the User’s Manual. Applicant: Shenzhen Hongshanjie Technology Co., Ltd Address: Hongshanjie Industrial Park, Longyankeng, Jiuwei Community, Xixiang Street, Bao'an, Shenzhen China Manufacturer: Shenzhen Hongshanjie Technology Co., Ltd Address : Hongshanjie Industrial Park, Longyankeng, Jiuwei Community, Xixiang Street, Bao'an, Shenzhen China Factory: Shenzhen Hongshanjie Technology Co., Ltd Address : Hongshanjie Industrial Park, Longyankeng, Jiuwei Community, Xixiang Street, Bao'an, Shenzhen China Report No.: 18220WC00025502FCC ID: 2AO2V-HSU002Page 5 of 13 Code:AB-RF-05-a 1.3. Auxiliary Equipment Used During Test Adapter: Manufacturer: ZTE M/N: STC-A2050I1000USBA-C S/N: 201202102100876 Input: 100-240V~ 50/60Hz, 0.3A Output: DC 5V, 2000mA 1.4. Test Equipment List ItemEquipmentManufacturerModel No.Serial No.Last Cal.Cal. Interval 1 Magnetic field meter NARDAELT-400423623 Dec. 23, 2019 1 Year 2E-Field ProbeNardaEF0391Q15221 Nov.17, 2017 3 Year 3H-Field ProbeNardaHF3061Q15835 Nov.17, 2017 3 Y…

Text truncated - open the document above for the full version.

Report No.: 18220WC00025501FCC ID: 2AO2V-HSU002Page 1 of 29 Code:AB-RF-05-a FCC TEST REPORT Client Name: Shenzhen Hongshanjie Technology Co., Ltd Address: Hongshanjie Industrial Park, Longyankeng, Jiuwei Community, Xixiang Street, Bao'an, Shenzhen China Product Name: Wireless charger with sterilizing Box Date: Apr. 17, 2020 Shenzhen Anbotek Compliance Laboratory Limited Report No.: 18220WC00025501FCC ID: 2AO2V-HSU002Page 2 of 29 Code:AB-RF-05-a Contents 1. General Information ............................................................................................................................................... 4 1.1. Client Information ....................................................................................................................................... 4 1.2. Description of Device (EUT) ..................................................................................................................... 4 1.3. Auxiliary Equipment Used During Test ................................................................................................... 4 1.4. Description of Test Modes ........................................................................................................................ 5 1.5. Description Of Test Setup ......................................................................................................................... 6 1.6. Test Equipment List .................................................................................................................................... 7 1.7. Measurement Uncertainty ......................................................................................................................... 8 1.8. Description of Test Facility ........................................................................................................................ 8 2. Summary of Test Results ..................................................................................................................................... 9 3. Conducted Emission Test ................................................................................................................................... 10 3.1. Test Standard and Limit .......................................................................................................................... 10 3.2. Test Setup .................................................................................................................................................. 10 3.3. Test Procedure .......................................................................................................................................... 10 3.4. Test Data .................................................................................................................................................... 10 4. Radiation Spurious Emission and Band Edge ................................................................................................ 13 4.1. Test Standard and Limit .......................................................................................................................... 13 4.2. Test Setup .................................................................................................................................................. 13 4.3. Test Procedure .......................................................................................................................................... 14 4.4. Test Data .................................................................................................................................................... 15 5. Antenna Requirement ......................................................................................................................................... 19 5.1. Test Standard and Requirement ............................................................................................................ 19 5.2. Antenna Connected Construction .......................................................................................................... 19 APPENDIX I -- TEST SETUP PHOTOGRAPH ................................................................................................... 20 APPENDIX II -- EXTERNAL PHOTOGRAPH ..................................................................................................... 22 APPENDIX III -- INTERNAL PHOTOGRAPH ..................................................................................................... 25 Report No.: 18220WC00025501FCC ID: 2AO2V-HSU002Page 3 of 29 Code:AB-RF-05-a TEST REPORT Applicant: Shenzhen Hongshanjie Technology Co., Ltd Manufacturer: Shenzhen Hongshanjie Technology Co., Ltd Product Name: Wireless charger with sterilizing Box Model No.: HSU-002, CASETiFY_UV001 Trade Mark: N.A. Rating(s): Input: DC 5V, 2A Wireless Output: 5W Test Standard(s) : FCC Part15 Subpart C 2019, Paragraph 15.209 Test Method(s): ANSI C63.10: 2013 The device described above is tested by Shenzhen Anbotek Compliance Laboratory Limited to determine the maximum emission levels emanating from the device and the severe levels of the device can endure and its performance criterion. The measurement results are contained in this test report and Shenzhen Anbotek Compliance Laboratory Limited is assumed full of responsibility for the accuracy and completeness of these measurements. Also,this report shows that the EUT (Equipment Under Test) is technically compliant with the FCC Part 15 Subpart C requirements. This report applies to above tested sample only and shall not be reproduced in part without written approval of Shenzhen Anbotek Compliance Laboratory Limited. Date of ReceiptMar. 24, 2020 Date of TestMar. 24~Apr. 16, 2020 Prepared By (Engineer / Dolly Mo) Reviewer (Supervisor / Bibo Zhang) Approved & Authorized Signer (Manager / Tom Chen) Report No.: 18220WC00025501FCC ID: 2AO2V-HSU002Page 4 of 29 Code:AB-RF-05-a 1. General Information 1.1. Client Information Applicant: Shenzhe…

Text truncated - open the document above for the full version.
