2AO2V-HSU006Wireless charger with sterilizing Box

FCC STATEMENT : This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation. Warning: Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: Reorient or relocate the receiving antenna. Increase the separation between the equipment and receiver. Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. Consult the dealer or an experienced radio/TV technician for help. FCC Radiation Exposure Statement: This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance 20cm between the radiator & your body. HSU-006

FCC ID: 2AO2V-HSU006

Label Location On EUT Label Product Name: Wireless charger with sterilizing Box Model No.: HSU-006 FCC ID: 2AO2V-HSU006 This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation.

FCC ID: 2AO2V-HSU006 ANT

version01 Shenzhen Hongshanjie Technology Co., Ltd Declaration concerning Antenna Specification It is hereby declared that the product Model No.: HSU-006 FCC ID : 2AO2V-HSU006 fulfills the requirement in FCC test relating to the antenna type. The device specified above confirms to the FCC recommendations for internal antenna type(s) described below: Model No. of antenna: HSU-006 Type of antenna:Inductive loop coil Antenna Gain of the antenna: 0 dBi Frequency range:110.1-205KHz The mounting of the antenna is fixed to the radio module and no other antenna should be used. Company name: Shenzhen Hongshanjie Technology Co., Ltd Address: 2/F, No.20, Jiuwei 1st Road, Jiuwei Community, Hangcheng Street, Bao'an District, Shenzhen, China City:Shenzhen ZIP / Postal code: N/A Country:Shenzhen Place: Shenzhen Date: 2020-07-16 Signature:

Report No.: 18220WC00078602FCC ID: 2AO2V-HSU006Page 1 of 13 Code:AB-RF-05-a FCC TEST REPORT Client Name: Shenzhen Hongshanjie Technology Co., Ltd Address: 2/F, No.20, Jiuwei 1st Road, Jiuwei Community, Hangcheng Street, Bao'an District, Shenzhen, China Product Name: Wireless charger with sterilizing Box Date: Jul. 15, 2020 Shenzhen Anbotek Compliance Laboratory Limited Report No.: 18220WC00078602FCC ID: 2AO2V-HSU006Page 2 of 13 Code:AB-RF-05-a Contents 1. General Information ............................................................................................................................................... 4 1.1. Client Information ....................................................................................................................................... 4 1.2. Description of Device (EUT) ..................................................................................................................... 4 1.3. Auxiliary Equipment Used During Test ................................................................................................... 5 1.4. Test Equipment List .................................................................................................................................... 5 1.5. Measurement Uncertainty ......................................................................................................................... 5 1.6. Description of Test Facility ........................................................................................................................ 5 2. Measurement and Result ..................................................................................................................................... 6 2.1. Requirements .............................................................................................................................................. 6 2.2. Test Setup .................................................................................................................................................... 7 2.3. Test Procedure ............................................................................................................................................ 7 2.4. Test Result ................................................................................................................................................... 7 2.4.1. Equipment Approval Considerations item 5.b of KDB 680106 D01 v03. ...................................... 7 2.4.2. Environmental evaluation and exposure limit according to FCC CFR 47 part 1, 1.1307(b), 1.1310 .................................................................................................................................................................. 9 APPENDIX I -- TEST SETUP PHOTOGRAPH ................................................................................................... 11 Report No.: 18220WC00078602FCC ID: 2AO2V-HSU006Page 3 of 13 Code:AB-RF-05-a TEST REPORT Applicant: Shenzhen Hongshanjie Technology Co., Ltd Manufacturer: Shenzhen Hongshanjie Technology Co., Ltd Product Name: Wireless charger with sterilizing Box Model No.: HSU-006 Trade Mark: N.A. Rating(s): Input: DC 5V, 2A / DC 9V, 2A Wireless Output: 10W Max Test Standard(s) : FCC Part 1.1310, 1.1307(b) Test Method(s): KDB680106 D01 RF Exposure Wireless Charging Apps v03 The device described above is tested by Shenzhen Anbotek Compliance Laboratory Limited to determine the maximum emission levels emanating from the device and the severe levels of the device can endure and its performance criterion. The measurement results are contained in this test report and Shenzhen Anbotek Compliance Laboratory Limited is assumed full of responsibility for the accuracy and completeness of these measurements. Also,this report shows that the EUT (Equipment Under Test) is technically compliant with the FCC Part 1.1307 & KDB680106 D01 requirements. This report applies to above tested sample only and shall not be reproduced in part without written approval of Shenzhen Anbotek Compliance Laboratory Limited. Date of ReceiptJun. 17, 2020 Date of TestJun. 17~Jul. 10, 2020 Prepared By (Engineer / Dolly Mo) Reviewer (Supervisor / Bibo Zhang) Approved & Authorized Signer (Manager / Tom Chen) Report No.: 18220WC00078602FCC ID: 2AO2V-HSU006Page 4 of 13 Code:AB-RF-05-a 1. General Information 1.1. Client Information 1.2. Description of Device (EUT) Product Name : Wireless charger with sterilizing Box Model No.:HSU-006 Trade Mark: N.A. Test Power Supply: AC 120V, 60Hz for adapter Test Sample No.: 1-2-1(Normal Sample), 1-2-1(Engineering Sample) Product Description : Operation Frequency:110.1-205KHz Modulation Type:Backscatter Antenna Type:Inductive loop coil Antenna Antenna Gain(Peak):0 dBi Remark:1) For a more detailed features description, please refer to the manufacturer’s specifications or the User’s Manual. Applicant: Shenzhen Hongshanjie Technology Co., Ltd Address: 2/F, No.20, Jiuwei 1st Road, Jiuwei Community, Hangcheng Street, Bao'an District, Shenzhen, China Manufacturer: Shenzhen Hongshanjie Technology Co., Ltd Address : 2/F, No.20, Jiuwei 1st Road, Jiuwei Community, Hangcheng Street, Bao'an District, Shenzhen, China Factory: Shenzhen Hongshanjie Technology Co., Ltd Address : 2/F, No.20, Jiuwei 1st Road, Jiuwei Community, Hangcheng Street, Bao'an District, Shenzhen, China Report No.: 18220WC00078602FCC ID: 2AO2V-HSU006Page 5 of 13 Code:AB-RF-05-a 1.3. Auxiliary Equipment Used During Test Adapter: Manufacturer: Anker M/N: A2014 Input: 100-240V 50-60Hz 1.2A Output: 5V 3A / 9V3A / 15V2A / 20V1.5A 1.4. Test Equipment List ItemEquipmentManufacturerModel No.Serial No.Last Cal.Cal. Interval 1 Magnetic field meter NARDAELT-400423623 Dec. 23, 2019 1 Year 2E-Field ProbeNardaEF0391Q15221 Nov.17, 2017 3 Year 3H-Field ProbeNardaHF3061Q15835 Nov.17, 2017 3 Year 1.5. Measurement Uncertainty Radiation Uncertainty: Ur = 3.9 dB (Horizontal) Ur = 3.8 dB (Vertical) Conduction Uncertainty: Uc = 3.4 dB …
