2AO37-ATLASEXPProCom

Westcom Wireless Inc.

Application Details

Equipment Class: DSS - Part 15 Spread Spectrum Transmitter
Date of Grant: Jun 09, 2024
Application Purpose: Original Equipment
Date of Application: Jun 05, 2024
Equipment Note: ProCom
Frequency Range: 902.00000000 - 923.00000000
Company: Westcom Wireless Inc.
Country: United States

Documents & Files

Select a file to view

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Attestation Statements

Westcom Wireless Inc. * the applicant must designate a contact located in the United States for purposes of acting as the applicant’s agent for service of process, regardless of whether the applicant is a domestic or foreign entity. An applicant located in the United States may designate itself as the agent for service of process. U.S. Agent Designation for Service of Process - Certification Attestation Letter May 30, 2024 Nemko North America, Inc. 303 River Road Ottawa K1V 1H2 Canada ATTN.: Reviewing Engineer FCC ID: 2AO37-ATLASEXP Per section 2.911(d)(7) of the FCC rules, Westcom Wireless Inc. (“the applicant”) certifies that the equipment for which authorization is sought is designated to the following U.S. Designated agent* for service of process: Company Name: Westcom Wireless Inc. Physical U.S. Company Address: 2773 Leechburg Road, Lower Burrell, Pennsylvania, 15068, United States Agent name: Frank Dominick Girardi Agent Email Address: [email protected] FRN: 0023758659 The above contact person accepts the obligation for service of process. The applicant accepts to maintain an agent for no less than one year after the grantee has terminated all marketing and importation or the conclusion of any Commission-related proceeding involving the equipment. Applicant Signed: Designated Agent Signed: (Required, if different to Applicant): Signed: Signed: Printed name: Frank Dominick Girardi Printed name: Frank Dominick Girardi Title: President Title: President Company Name: Westcom Wireless Inc. Company Name: Westcom Wireless Inc. FRN No.: 0023758659 FRN No.: 0023758659 FCC Grantee Code: 2AO37 FCC Grantee Code: 2AO37 Date: May 30, 2024 Date: May 30, 2024

Attestation Statements

Westcom Wireless Inc. Covered Equipment Certification Attestation Letter May 30, 2024 Nemko North America, Inc. 303 River Road Ottawa K1V 1H2 Canada ATTN.: Reviewing Engineer FCC ID: 2AO37-ATLASEXP Westcom Wireless Inc. (“the applicant”) certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. Note: If the equipment for which the applicant seeks authorization is produced by any of the entities identified on the current Covered List, the applicant should include an explanation on why the equipment is not “covered” equipment. Westcom Wireless Inc. (“the applicant”) certifies that, as of the date of the filing of the application, the applicant is not identified on the Covered List as an entity producing “covered” equipment. Signed: Printed name: Frank Dominick Girardi Title: President Company Name: Westcom Wireless Inc. Date: 5/30/2024

Cover Letter(s)

Westcom Wireless Inc. May 30, 2024 Nemko North America, Inc. 303 River Road Ottawa, Ontario, Canada K1V 1H2 REQUEST FOR CONFIDENTIALITY - FCC FCC ID: 2AO37-ATLASEXP Pursuant to Sections 0.457(d) and 0.459 of the Commission’s Rules and FCC Guidance document 726920, we hereby request permanent confidential treatment of exhibits identified as such in the table below and request they are permanently withheld from public review based on the documents containing trade secrets and proprietary information not customarily released to the public. The public disclosure of this information might be harmful to the applicant and provide unjustified benefits to its competitors. We also request short-term confidentiality on certain exhibits until the intended date of marketing as outlined below. We request the exhibits be withheld from public view for a period of 180 days. We attest marketing of the product will only commence after the period of short-term confidentiality expires, or if marketing is to commence before the requested number of days listed above, the grantee will inform Nemko to release the Short-Term Confidentiality information withheld on the FCC equipment authorization website. Exhibit Type of Confidentiality Requested Block Diagrams ☒ Permanent ☐ Short Term External Photos ------------------ ☒ Short Term Internal Photos ☐ Permanent* ☒ Short Term Operation Description ☒ Permanent ☐ Short Term Parts List & Placement/BOM ☒ Permanent ☐ Short Term Tune-Up Procedure ☐ Permanent ☐ Short Term Schematic Diagrams ☒ Permanent ☐ Short Term Test Setup Photos ------------------ ☒ Short Term User’s Manual ☐ Permanent* ☒ Short Term The asterisked items (*) require further information to be provided in this justification letter before permanent confidentiality will be extended to these exhibits. Please refer to FCC KDB 726920 D01 found at: https://apps.fcc.gov/oetcf/kdb/forms/FTSSearchResultPage.cfm?switch=P&id=41731 and review section II, 3) regarding specific information that must accompany these requests. Note: any documents held under the Short-Term confidentiality will automatically become public after the requested time if an appropriate extension request has not been received. Any exhibits (i.e., schematic diagrams) that may have already been requested to have “Permanent” confidentiality as shown above need not be repeated under Short-Term confidentiality request. Sincerely, Signed: Printed name: Frank Dominick Girardi Title: President Company Name: Westcom Wireless Inc.

ID Label/Location Info

Atlas Exp Label Atlas Exp Location

RF Exposure Info

Page 1 of 73 Report No. OT-244-RFD-001 This Report is not correlated with the authentication of KOLAS. It should not be reproduced except in full, without the written approval of ONETECH Corp. OTC-TRF-SAR-002(0) ONETECH Corp.: 43-14, Jinsaegol-gil, Chowol-eup, Gwangju-si, Gyeonggi-do, 12735, Korea (TEL: 82-31-799-9500, FAX: 82-31-799-9599) FCC SAR Test Report Test Report No. : OT-244-RFD-001 Reception No. : 2403001107 Applicant : Westcom Wireless Inc. Address : 2773 Leechburg Road, Lower Burrell, PA 15068 United States Manufacturer : Westcom Wireless Inc. Address : 2773 Leechburg Road, Lower Burrell, PA 15068 United States Type of Equipment : ProCom FCC ID : 2AO37-ATLASEXP Model Name : ATLAS EXP Multiple Model Name: N/A Serial number : Refer to DUT Information Total page of Report : 73 pages (including this page) Date of Incoming : Mar. 28, 2024 Date of Test : Apr. 22, 2024 Date of issue : Apr. 30, 2024 SUMMARY The equipment complies with the regulation; CFR §2.1093. This test report only contains the result of a single test of the sample supplied for the examination. It is not a generally valid assessment of the features of the respective products of the mass-production. Tested by Young Chan, Lee / Engineer ONETECH Corp. Reviewed by Kyoung Hoo, Min / Senior Manager ONETECH Corp Approved by Cheon Sig, Choi / Technical Manager ONETECH Corp. Page 2 of 73 Report No. OT-244-RFD-001 This Report is not correlated with the authentication of KOLAS. It should not be reproduced except in full, without the written approval of ONETECH Corp. OTC-TRF-SAR-002(0) ONETECH Corp.: 43-14, Jinsaegol-gil, Chowol-eup, Gwangju-si, Gyeonggi-do, 12735, Korea (TEL: 82-31-799-9500, FAX: 82-31-799-9599) Revision history Report No. Reason for Change Date Issued OT-244-RFD-001 Initial release 2024-04-30 Page 3 of 73 Report No. OT-244-RFD-001 This Report is not correlated with the authentication of KOLAS. It should not be reproduced except in full, without the written approval of ONETECH Corp. OTC-TRF-SAR-002(0) ONETECH Corp.: 43-14, Jinsaegol-gil, Chowol-eup, Gwangju-si, Gyeonggi-do, 12735, Korea (TEL: 82-31-799-9500, FAX: 82-31-799-9599) TABLE OF CONTENTS 1. Summary of Maximum SAR Value ............................................................................ 4 2. Device Under Test .................................................................................................... 4 3. INTRODUCTION ...................................................................................................... 6 4. DOSIMETRIC ASSESSMENT .................................................................................. 8 5. TEST CONFIGURATION POSITIONS ..................................................................... 9 6. RF EXPOSURE LIMITS .......................................................................................... 10 7. FCC MEASUREMENT PROCEDURES .................................................................. 11 8. RF CONDUCTED POWERS .................................................................................. 12 9. SYSTEM VERIFICATION ....................................................................................... 14 10. SAR TEST DATA SUMMARY ................................................................................. 16 11. EQUIPMENT LIST .................................................................................................. 18 12. MEASUREMENT UNCERTAINTIES ...................................................................... 19 13. CONCLUSION ........................................................................................................ 20 14. REFERENCES ....................................................................................................... 21 APPENDIX A: SYSTEM VERIFICATION ................................................................................... 23 APPENDIX B: SAR TEST DATA ............................................................................................... 25 APPENDIX C: PROBE & DIPOLE ANTENNA CALIBRATION .................................................. 28 APPENDIX D: SAR TISSUE SPECIFICATIONS ....................................................................... 57 APPENDIX E: SAR SYSTEM VALIDATION .............................................................................. 59 APPENDIX F: DUT ANTENNA DIAGRAM & SAR TEST SETUP PHOTOGRAPHS ................. 60 Page 4 of 73 Report No. OT-244-RFD-001 This Report is not correlated with the authentication of KOLAS. It should not be reproduced except in full, without the written approval of ONETECH Corp. OTC-TRF-SAR-002(0) ONETECH Corp.: 43-14, Jinsaegol-gil, Chowol-eup, Gwangju-si, Gyeonggi-do, 12735, Korea (TEL: 82-31-799-9500, FAX: 82-31-799-9599) 1. Summary of Maximum SAR Value Equipment Class Band & Mode Tx Frequency [㎒] SAR 1 g Head (W/kg) 1 g Body (W/kg) 10g Hands (W/kg) DSS 900 ㎒ ISM Band 902 ~ 928 N/A 2.11 N/A Simultaneous SAR per KDB 690783 D01v01r03: N/A N/A N/A Note: 1. This wireless portable device has been shown to be capable of compliance for localized specific absorption rate (SAR) for controlled environment/professional population exposure limits specified in ANSI/IEEE C95.1-1992 and has been tested in accordance with the measurement procedures specified in Section 6 of this report. 2. Device Under Test 2.1. DUT Information DUT Type ProCom FCC ID 2AO37-ATLASEXP Model Name ATLAS EXP Additional Model Name(s) - DUT S/N #1 Antenna Type Flexible Rubber Duck Antenna DUT Stage Identical Prototype Note: 1. For antenna peak gain and detailed antenna information, refer to the antenna report in FCC filing. 2.2. Device Overview Band & Mode Operating Modes Tx Frequency [㎒] 900 ㎒ Band Data 902 ~ 928 2.3. Power Reduction for SAR There is no power reduction used for any band/mode implemented in the device for SAR purposes. 2.4. Nominal and Maximum Output Power Specifications This device operates using the following maximum and nominal output power specifications. SAR values…

Text truncated - open the document above for the full version.

Test Report

Page 1 of 35 Report No. : OT-245-RWD-034 It should not be reproduced except in full, without the written approval of ONETECH Corp. OTC-TRF-RF-001(0) ONETECH Corp.: 43-14, Jinsaegol-gil, Chowol-eup, Gwangju-si, Gyeonggi-do, 12735, Korea (TEL: 82-31-799-9500, FAX: 82-31-799-9599) RADIO PERFORMANCE TEST REPORT Test Report No. : OT-245-RWD-034 Reception No. : 2403001107 Applicant : Westcom Wireless Inc. Address : 2773 Leechburg Road, Lower Burrell, Pennsylvania, 15068, United States Manufacturer : Westcom Wireless Inc. Address : 2773 Leechburg Road, Lower Burrell, Pennsylvania, 15068, United States Type of Equipment : ProCom FCC ID. : 2AO37-ATLASEXP Model Name : ATLAS EXP Multiple Model Name : N/A Serial number : N/A Total page of Report : 35 pages (including this page) Date of Incoming : March 26, 2024 Date of issue : May 29, 2024 SUMMARY The equipment complies with the regulation; FCC PART 15 SUBPART C Section 15.247 This test report only contains the result of a single test of the sample supplied for the examination. It is not a generally valid assessment of the features of the respective products of the mass-production. This report is not correlated with the "KS Q ISO/IEC 17025 and KOLAS accreditation" of Korean Laboratory Accreditation Scheme. Tested by Su-Min, Yoo / Sr. Engineer ONETECH Corp. Reviewed by Tae-Ho, Kim / Chief Engineer ONETECH Corp. Approved by Jae-Ho, Lee / Chief Engineer ONETECH Corp. Page 2 of 35 Report No. : OT-245-RWD-034 It should not be reproduced except in full, without the written approval of ONETECH Corp. OTC-TRF-RF-001(0) ONETECH Corp.: 43-14, Jinsaegol-gil, Chowol-eup, Gwangju-si, Gyeonggi-do, 12735, Korea (TEL: 82-31-799-9500, FAX: 82-31-799-9599) CONTENTS Page 1. VERIFICATION OF COMPLIANCE ............................................................................................................................. 6 2. TEST SUMMARY .............................................................................................................................................................. 7 2.1 Test items and results ................................................................................................................................................... 7 2.2 Additions, deviations, exclusions from standards ...................................................................................................... 7 2.3 Related Submittal(s) / Grant(s) .................................................................................................................................... 7 2.4 Purpose of the test ......................................................................................................................................................... 7 2.5 Test Methodology ......................................................................................................................................................... 7 2.6 Test Facility ................................................................................................................................................................... 8 3. GENERAL INFORMATION ............................................................................................................................................ 9 3.1 Product Description ...................................................................................................................................................... 9 3.2 Alternative type(s)/model(s); also covered by this test report. .................................................................................. 9 4. EUT MODIFICATIONS .................................................................................................................................................... 9 5. SYSTEM TEST CONFIGURATION ............................................................................................................................. 10 5.1 Justification ................................................................................................................................................................. 10 5.2 Peripheral equipment ................................................................................................................................................. 10 5.3 Mode of operation during the test ............................................................................................................................. 10 5.4 Configuration of Test System .................................................................................................................................... 16 5.5 Antenna Requirement ................................................................................................................................................ 16 6. PRELIMINARY TEST .................................................................................................................................................... 16 6.1 AC Power line Conducted Emissions Tests .............................................................................................................. 16 6.2 General Radiated Emissions Tests ............................................................................................................................ 16 7. MAXIMUM PEAK OUTPUT POWER ......................................................................................................................... 17 7.1 Operating environment .............................................................................................................................................. 17 7.2 Test set-up ................................................................................................................................................................... 17 7.3 Test Date ...................................................................................................................................................................... 17 7.4 Test data for Mo…

Text truncated - open the document above for the full version.

Test Report

L-com, Inc. 50 High St., West Mill, 3 rd Floor, Suite #30 North Andover, MA 01845 www.L-com.com E-mail: [email protected] Phone: 1-800-343-1455 Fax: 1-978-689-9484 © L-com, Inc. All Rights Reserved. L-com Global Connectivity and the L-com logo are registered marks. HyperLink Wireless 900 MHz 3 dBi RP-SMA Plug High Performance "Rubber Duck" Wireless LAN Antenna – Model: HG903RD-RSP Applications and Features Applications:  900MHz ISM Band  900MHz Cellular Band Applications  900MHz Digital Spread Spectrum Radios  900MHz Telemetry Products  GSM  RFID  Wireless Video Transmitters and Receivers  Multipoint and Mobile Applications Features:  Better performance then most stock AP antennas  Flexible "Rubber Duck" antenna  Tilt and swivel design  Reverse Polarity SMA-Plug (RP-SMA) Connector  RoHS Compliant Description This high performance 900MHz Omnidirectional "rubber-duck" antenna provides broad coverage and 3 dBi gain. It is a coaxial sleeve design with an omni-directional pattern. It is ideally suited for 900MHz ISM band applications as well as 900MHz cellular applications. Measuring 8.62" long, this flexible antenna features a tilt-and-swivel Reverse Polarity SMA-Plug (RP-SMA) connector, allowing them to be used vertically, at a right angle, or any angle in-between. It is suitable as a replacement RF antenna for 900MHz radios that are equipped with RP-SMA connectors such as wireless video transmitters and receivers, 900MHz digital spread spectrum radios and more. Specifications Electrical Specifications Frequency 860-960 MHz Gain 3 dBi Horizontal Beam Width 360° Impedance 50 Ohm Max. Power 50W VSWR < 2.0 Lightning Protection DC Ground L-com, Inc. 50 High St., West Mill, 3 rd Floor, Suite #30 North Andover, MA 01845 www.L-com.com E-mail: [email protected] Phone: 1-800-343-1455 Fax: 1-978-689-9484 © L-com, Inc. All Rights Reserved. L-com Global Connectivity and the L-com logo are registered marks. Mechanical Specifications Weight 1.6 oz. (45 g) Length 8.62" (219 mm) Max. Diameter 0.66" (16.7 mm) Finish Matte Black Connector RP-SMA Plug Operating Temperature -40° C to 60° C (-40° F to 140° F) Polarization Vertical Flame Rating UL 94HB RoHS Compliant Yes Dimensions RF Antenna Patterns Guaranteed Quality This product is backed by L-Com's Limited Warranty

Test Report

RE905U Radiation patterns Electrical testing: Return loss & v.s.w.r. E-Plane 900mhz H-Plane 900mhz
