2AOKM-FD11Remote Key

Company: Remote Tech LLC Address: 310 ALDER RD,Dover,DE 19904,USA Name:Remote Key Model: RT-FD601 Operation instructions 1. After matching the key to the car, press 1 the unlock key for 2 seconds to open the door and press 2 the lock key for 2 seconds to close the door. 2. The ignition key is used to manually unlock and start the car. Product parameters Rated voltage DC 3V Working current <12mA Operating voltage DC 3.3V-2.2V Transmit power >-8dbm Key operation force 200±50g Operating temperature -5°C +45°C Stand-by current ＜7uA transmitting frequency 433.92MHZ±75KHZ UNLOCK LOCK Trunk Modulation ASK Battery CR2032 Key durability More than 70,000 times This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: -- Reorient or relocate the receiving antenna. -- Increase the separation between the equipment and receiver. -- Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. -- Consult the dealer or an experienced radio/TV technician for help. The distance between user and products should be no less than 20cm -English Warning Statement: “This device complies with Industry Canada licence-exempt RSS standard(s). Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this device must accept any interference, including interference that may cause undesired operation of the device." The digital apparatus complies with Canadian CAN ICES-3 (B)/NMB-3(B). -French Warning Statement: “Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux appareils radio exempts de licence. L'exploitation est autorisée aux deux conditions suivantes : (1) l'appareil ne doit pas produire de brouillage, et (2) l'utilisateur de l'appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible d'en compromettre le fonctionnement." Cet appareil numérique de la classe B est conforme à la norme NMB-003 du Canada. This equipment complies with IC radiation exposure limits set forth for an uncontrolled environment and meets RSS-102 of the IC radio frequency (RF) Exposure rules. This equipment has very low levels of RF energy that are deemed to comply without testing of specifc absorption ratio (SAR).Cet équipement est conforme aux limites d’exposition aux rayonnements énoncées pour un environnement non contrôlé et respecte les règles d’exposition aux fréquences radioélectriques (RF) CNR-102 de l’IC. Cet équipement émet une énergie RF très faible qui est considérée conforme sans évaluation du débit d’absorption spécifque (DAS).

Remote Tech LLC Agent Authorization Company: Remote Tech LLC Address: 310 ALDER RD, Dover, DE 19904,USA Product Name: Remote Key Model Number(s): RT-FD601 Product Description: Remote Key We authorize MiCOM Labs Inc., 575 Boulder Court, Pleasanton, California 94566, USA, to act on our behalf on all matters concerning the certification of above named equipment. We declare that MiCOM Labs Inc. is allowed to forward all information related to the approval and certification of equipment to the regulatory agencies as required and to discuss any issues concerning the approval application. Any and all acts carried out by MiCOM Labs on our behalf shall have the same effect as acts of our own. Signature: Date: 12/24/2020 Name: John Strong Title: Technical Manager Company: Remote Tech LLC

Remote Tech LLC Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 Date: 2020-12-24 Subject; Request for Long Term Confidentiality FCC ID: 2AOKM-FD11 To Whom It May Concern, Pursuant to the provisions of the Commission’s rules Title 47 Sections §0.457 and §0.459, we are requesting the Commission to withhold the following attachment(s) as confidential documents from public disclosure indefinitely. These documents contain detailed system and equipment descriptions and are considered as proprietary information in operation of the equipment. The public disclosure of these documents might be harmful to our company and would give competitors an unfair advantage in the market. Schematic Diagram Block Diagram Operational Description It is our understanding that all measurement test reports, FCC ID label format and correspondence during the certification review process cannot be granted as confidential documents and this information will be available for public review once the grant of equipment authorization is issued. Sincerely, Signature: Name: John Strong Title: Technical Manager

FCC ID: 2AOKM-FD11 IC: 24223-FD11

Label Size: 1.5x1.0cm Location FCC ID: 2AOKM-FD11 IC: 24223-FD11 Remote Tech LLC Model Name: Remote Key Model No.: RT-FD601

FCC ID: 2AOKM-FD11 IC: 24223-FD11

FCC TEST REPORT FCC ID: 2AOKM-FD11 On Behalf of Remote Tech LLC Remote Key Model No.: RT-FD601 Prepared for : Remote Tech LLC Address : 310 ALDER RD, Dover, DE 19904, USA Prepared By : Shenzhen Alpha Product Testing Co., Ltd. Address : Building i, No.2, Lixin Road, Fuyong Street, Bao’an District, 518103, Shenzhen, Guangdong, China Report Number : A2011252-C01-R01 Date of Receipt : December 2, 2020 Date of Test : December 2, 2020- December 17, 2020 Date of Report : December 17, 2020 Version Number : V0 Page 2 of 32 Report No.: A2011252-C01-R01 Contents 1. General Information ............................................................................................................... 5 1.1. Description of Device (EUT) ...............................................................................5 1.2. Accessories of Device (EUT)...............................................................................6 1.3. Tested Supporting System Details .......................................................................6 1.4. Test Facility ..........................................................................................................6 2. Summary of Test ..................................................................................................................... 7 2.1. Summary of Test Result .......................................................................................7 2.2. Block Diagram .....................................................................................................7 2.3. Test Mode .............................................................................................................8 2.4. Test Conditions .....................................................................................................8 2.5. Measurement Uncertainty (95% confidence levels, k=2) ....................................8 2.6. Test Equipment .....................................................................................................9 3. Radiation Emission ............................................................................................................... 10 3.1. Radiation Emission Limits(15.209&231) ..........................................................10 3.2. Test Setup ...........................................................................................................10 3.3. Test Procedure .................................................................................................... 11 3.4. Test Equipment Setting For emission test. .........................................................12 3.5. Test Condition ....................................................................................................12 3.6. Test Result ..........................................................................................................12 4. Power Line Conducted Emission ......................................................................................... 18 4.1. Conducted Emission Limits (15.209) ................................................................18 4.2. Test Setup ...........................................................................................................18 4.3. Test Procedure ....................................................................................................18 4.4. Test Results ........................................................................................................19 5. Occupied bandwidth ............................................................................................................. 20 5.1. Test Limit ...........................................................................................................20 5.2. Method of Measurement ....................................................................................20 5.3. Test Setup ...........................................................................................................20 5.4. Test Results ........................................................................................................20 6. Transmission Time ............................................................................................................... 22 6.1. Test Limit ...........................................................................................................22 6.2. Method of Measurement ....................................................................................22 6.3. Test Setup ...........................................................................................................22 6.4. Test Results ........................................................................................................22 7. Antenna Requirement .......................................................................................................... 24 7.1. Standard Requirement ........................................................................................24 7.2. Antenna Connected Construction ......................................................................24 7.3. Result..................................................................................................................24 8. Test Setup Photo ................................................................................................................... 25 9. Photos of EUT ....................................................................................................................... 26 Page 3 of 32 Report No.: A2011252-C01-R01 TEST REPORT DECLARATION Applicant : Remote Tech LLC Address : 310 ALDER RD, Dover, DE 19904, USA Manufacturer : Remote Tech LLC Address : 310 ALDER RD, Dover, DE 19904, USA EUT Description : Remote Key (A) Model No. : RT-FD601 (B) Trademark : N/A Measurement Standard Used: FCC Rules and Regulations Part 15 Subpart C Section 15.231 ANSI C63.10-2013 The device described above is tested by Shenzhen Alpha Product Testing Co., Ltd. to determine the maximum emission levels emanat…

Text truncated - open the document above for the full version.

FCC ID: 2AOKM-FD11 IC: 24223-FD11 Photos of Radiated emission
