2AONA-WX06610-AMagnetic wireless charger

W elcome Guide 90 90 Wireless Charging Paid service:customer will incur a repair charge as follows: -No valid warranty card or warranty card incompatible. -No S/N or S/N incompatible with warranty card -Malfunction caused by artificial damages(like external impact or submerging product into water ,ect.) -Misuse of the product.User has not followed the instructions in the manual. -Product disassembled or repaired by individual or unauthorized service center. -Damages caused by storing the product in a hot or humid environment. -Defects or malfunctions due to force majeure. Thank you for purchasing the iWALK product. Our product’s warranty period is 12 months starting from the date of purchase.Within the warranty period, free service will be provided to the consumer. if the product has any quality problems(requiring warranty card with distributor’s official stamp and valid S/N). Carte de garantie | Garantiekarte | Scheda di garanzia Hoja de garantía | 製品パラメータ Warranty card Dealer ’s Information (Please complete warranty card and use for any future warranty service) User ’s Information Dealer Name: Product Type: Tel: Sales Date: Model No.: Product Name: User’s Name: E-mail: Tel: ADD: Warranty Content: 使用说明书 | user's manual | Manuel d'utilisation Bedienungsanleitung | Manuale d’istruzione Manual de instrucciones | 取扱説明書 1）请勿靠近带磁条或者芯片的磁卡(身份证、银行卡等), 避免造成磁卡失效。 2）请保持植入医疗设备(心脏起搏器、植入性耳蜗等)与产品的直接的距离至少为20cm,以避免对 医疗设备造成潜在的干扰。 3）请勿接触液体。 4）请勿拆卸。 5）避免跌落产品。 6）避免在过低或过高温度下使用。 1) ne pas placer le produit à proximité d’une carte magnétique (carte d’identité, carte bancaire, etc.) munie d’une bande magnétique ou d’une puce, afin d’éviter que la carte ne soit invalidée. 2）Maintenir le dispositif médical implanté (stimulateur cardiaque, cochléaire implantable, etc.) à une distance directe d’au moins 20cm du produit afin d’éviter toute interférence potentielle avec le dispositif médical. 3）Ne le laisser pas toucher du liquide. 4）Veuillez ne pas démonter. 5）Évitez la chute du produit. 6）Évitez de l'utiliser à des températures trop faibles ou trop élevées. 产品参数/Specifications/Paramètre produit/Produktparameter Parametri del prodotto/Parámetros del producto/製品パラメータ 安全注意事项 1）Do not put the product near the magnetic card with magnetic stripe or chip (ID card, bank card, etc.) to avoid the invalidation of the magnetic card. 2）Please keep the implanted medical device (pacemaker, implantable cochlea, etc.) at least 20cm directly away from the product to avoid potential interference with the medical device. 3）Do not expose to liquids. 4）Do not disassemble. 5）Avoid dropping. 6）Avoid extreme temperatures. Safety Precautions 1）Stellen Sie das Produkt nicht in der Nähe von Magnetkarten (Personalausweisen, Bankkarten usw.) mit Magnetstreifen oder Chips auf, um eine Ungültigmachung der Magnetkarten zu vermeiden. 2）Bitte halten sie die direkte entfernung zwischen implantaten (herzschrittmacher, implantat usw.) und den produkten auf einer höhe Von mindestens 20cm. 3）Berühren Sie keine Flüssigkeiten. 4）Zerlegen Sie das Gerät nicht. 5）Vermeiden Sie das Produkt fallen zu lassen. 6）Vermeiden Sie die Verwendung bei zu niedrigen oder zu hohen Temperaturen. Sicherheitsvorkehrungen Précautions de sécurité 1）por favor, no coloque el producto cerca de una tarjeta magnética (tarjeta de identificación, tarjeta bancaria, etc.) con banda magnética o chip, para evitar la anulación de la tarjeta magnética. 2）Mantenga el dispositivo médico implantado (marcapasos, implantes cocleares, etc.) a una distancia directa del producto de al menos 20cm para evitar posibles interferencias con el dispositivo médico. 3）No tocar con el líquido. 4）No lo desmonte. 5）Evitar la caída del producto. 6）Evite el uso del presente a temperaturas demasiado bajas o demasiado altas. Precauciones de seguridad 1）Non posizionare il prodotto vicino a carte magnetiche (carte d'identità, carte bancarie, ecc.) Con strisce o chip magnetici per evitare l'invalidamento delle carte magnetiche. 2）Si prega di mantenere la distanza diretta dei dispositivi medici impiantati (pacemaker cardiaci, coclear impiantabili, ecc.) dal prodotto almeno 20cm, per evitare eventuali interferenze con i dispositivi medici. 3）Non toccare il liquido. 4）Non smantellare il prodotto. 5）Evitare la caduta del prodotto. 6）Evitare l’utilizzo alla temperatura troppo bassa o alta. Precauzioni di sicurezza 1）1)制品を磁気ストライプまたはチップ付きの磁気カード(身分証明書、カードカードなど)に 近づけないでください。 2）埋め込まれた医療機器（ペースメーカー、埋め込み可能な蝸牛など）は、医療機器との干渉の 可能性を避けるために、製品から直接20cm以上離してください。 3）液体との接触を避けてください。 4）無断に解体しないでください。 6）度が低すぎまたは高すぎな環境での使用を避けてください。 安全注意事項 MCC010L 产品名称: Magnetic wireless charger 产品型号: 输 入: 5V 2A, 9V 2A, 无线输出: 5W/7.5W/10W 产品尺寸: 60x4.9mm 产品重量: 45g 执行标准: GB/4943.1-2011 Product Name: Magnetic wireless charger Model No.: Input: 5V 2A, 9V 2A Wireless Charging: 5W/7.5W/10W Size: 60x4.9mm Weight: 45g - Recommend to connect USB wall adapter with PD、Quick Charge 2.0/3.0 output to optimeze the charging efficiency. - Pour améliorer l’efficacité de la charge, il est recommandé d’utiliser des chargeurs rapides compatibles PD, QC2.0/QC3.0. - Um die Ladeeffizienz zu verbessern, wird empfohlen, ein mit PD und QC2.0 / QC3.0 kompatibles Schnellladegerät zu verwenden. - Per migliorare l’efficienza della ricarica si raccomanda di utilizzare apparecchi compatibili PD, QC2.0/QC3.0 per il caricamento rapido. - Para mejorar la eficiencia de la carga, se recomienda el uso de cargadores rápidos compatibles PD, QC2.0/QC3.0. - 充電効率を上げるために、互換性のあるPD、QC2.0 /QC3.0急速充電充 電器を使用することをお勧めします。 - 为提高充电效率，建议使用兼容PD、QC2.0/QC3.0快充充电器。 FCC Notice: This device complies with Part 15 of the FCC rules. Operation is subject to the following twoconditions: 1) this device may not cause harmful interference, and 2) this device must acceptany interference received, including interference that may cause undesired operation. Note: This equipment has been tested and found to comply with the limits for a Class B digitaldevice, pursuant to part 15 of the FCC Rules. These limits are designed to provide re…

Text truncated - open the document above for the full version.

Shenzhen Pilot Technology Co., Ltd 101 A1 Industrial Park, building a1, No.7, Shankeng Road, Shanxia Community, Pinghu Street, Longgang District, Shenzhen City China Series Models Description Date: 2021/07/03 To: Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD FCC ID: 2AONA-WX06610-A Dear Sir/Madam, We, Shenzhen Pilot Technology Co., Ltd Hereby declares the following statement for Federal Communications Commission, PCB board, circuit, structure and internal of these model(s) are the same, Only color and model number is different for these model: Product name: Magnetic wireless charger Model no.: WX06610-A,WX06610-C,WX08610-A,WX08610-C Sincerely, Name: Tina Huang Company: Shenzhen Pilot Technology Co., Ltd Address: 101 A1 Industrial Park, building a1, No.7, Shankeng Road, Shanxia Community, Pinghu Street, Longgang District, Shenzhen City China Phone: +86 13530903195 Fax: +86 0755-84018865 E-Mail: [email protected]

CONFIDENTIALITY REQUEST for Certification Service in USA Federal Communication Commission Equipment Authorization Division, Application Processing Branch 7435 Oakland Mills Road Columbia, MD 21046 Date: 2021/07/03 TO WHOM IT MAY CONCERN Pursuant to Paragraphs §0.457 and 0.459 of the Commission’s Rules (47 C.F.R.) and Section §552(b)(4) of the Freedom of Information Act, we requests confidentiality for the following products: FCC ID Model name 2AONA-WX06610-A WX06610-A,WX06610-C,WX08610-A,WX08610-C For the product stated above, we request that the following information be held confidential; Exhibits Long-Term Confidentiality Short-Term Confidentiality Short-Term Confidentiality Days External Photos Internal Photos Block Diagram Schematics Test Setup Photos User’s Manual Parts List Tune Up Operational Descriptions The long-term confidentiality exhibits contain our trade secrets and proprietary information that could be of benefit to our competitors. The short-term confidentiality on the basis of ensuring that business sensitive information remains confidential until the actual marketing of our new device. If you have any questions, please feel free to contact me at the address shown below. Sincerely, Name: Tina Huang Company: Shenzhen Pilot Technology Co., Ltd Address: 101 A1 Industrial Park, building a1, No.7, Shankeng Road, Shanxia Community, Pinghu Street, Longgang District, Shenzhen City China Phone: +86 13530903195 Fax: +86 0755-84018865 E-Mail: [email protected]

Shenzhen Pilot Technology Co., Ltd 101 A1 Industrial Park, building a1, No.7, Shankeng Road, Shanxia Community, Pinghu Street, Longgang District, Shenzhen City China Federal Communications Commission Authorization and Evaluation Division Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 7/12/2021 To whom it may concern: We, the undersigned, hereby authorize Eurofins Product Service GmbH to act on our behalf in all matters relating to applications for equipment authorization FCC ID: 2AONA-WX06610-A including the signing of all documents related to these matters. Any and all acts carried out by Eurofins Product Service GmbH on our behalf shall have the same effect as acts of our own. We also hereby certify that no party to this application is subject to a denial of benefits, including FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 862. Sincerely, Name: Tina Huang Company: Shenzhen Pilot Technology Co., Ltd Address: 101 A1 Industrial Park, building a1, No.7, Shankeng Road, Shanxia Community, Pinghu Street, Longgang District, Shenzhen City China Phone: +86 13530903195 Fax: +86 0755-84018865 E-Mail: [email protected]

FCC ID: 2AONA-WX06610-A

FCC ID: 2AONA-WX06610-A

FCC ID: 2AONA-WX06610-A Antenna

Shenzhen Global Test Service Co.,Ltd. No.7-101 and 8A-104, Building 7 and 8, DCC Cultural and Creative Garden, No.98, Pingxin North Road, Shangmugu Community, Pinghu Street, Longgang District, Shenzhen, Guangdong TEST REPORT Report Reference No. ..................... : FCC ID. ............................................ : GTS20210605013-1-2 2AONA-WX06610-A Compiled by ( position+printed name+signature) .. : File administrators Jimmy Wang Supervised by ( position+printed name+signature) .. : Test Engineer Aaron Tan Approved by ( position+printed name+signature) .. : Manager Jason Hu Date of issue ..................................... : June 17, 2021 Representative Laboratory Name .: Shenzhen Global Test Service Co., Ltd. Address ............................................ : No.7-101 and 8A-104, Building 7 and 8, DCC Cultural and Creative Garden, No.98, Pingxin North Road, Shangmugu Community, Pinghu Street, Longgang District, Shenzhen, Guangdong Applicant’s name ............................ : Shenzhen Pilot Technology Co., Ltd Address ............................................ : 101 A1 Industrial Park, building a1, No.7, Shankeng Road, Shanxia Community, Pinghu Street, Longgang District, Shenzhen City China Test specification ...........................: Standard ........................................... : FCC Rules and Regulations part 2.1091 KDB680106 D01 v03r01 TRF Originator .................................. : Shenzhen Global Test Service Co.,Ltd. Master TRF ....................................... : Dated 2014-12 Shenzhen Global Test Service Co.,Ltd. All rights reserved. This publication may be reproduced in whole or in part for non-commercial purposes as long as the Shenzhen Global Test Service Co.,Ltd. is acknowledged as copyright owner and source of the material. Shenzhen Global Test Service Co.,Ltd. takes no responsibility for and will not assume liability for damages resulting from the reader's interpretation of the reproduced material due to its placement and context. Test item description .....................: Magnetic wireless charger Trade Mark ....................................... : N/A Manufacturer .................................... : Shenzhen Pilot Technology Co., Ltd Model/Type reference....................... : WX06610-A Listed Models .................................. : WX06610-C,WX08610-A,WX08610-C Modulation Type ............................... : ASK Operation Frequency ........................ : From 110KHz~205KHz Rating ............................................... : Input: DC 5V 2A, 9V 2A Output: Wireless Charging: 5W/7.5W/10W Result................................................ : PASS Report No.: GTS20210605013-1-2 Page 2 of 12 T E S T R E P O R T Test Report No. : GTS20210605013-1-2 June 17, 2021 ____________________________________________________________________________________ Date of issue Equipment under Test : Magnetic wireless charger Model /Type : WX06610-A Listed Models : WX06610-C,WX08610-A,WX08610-C Applicant : Shenzhen Pilot Technology Co., Ltd Address : 101 A1 Industrial Park, building a1, No.7, Shankeng Road, Shanxia Community, Pinghu Street, Longgang District, Shenzhen City China Manufacturer : Shenzhen Pilot Technology Co., Ltd Address : 101 A1 Industrial Park, building a1, No.7, Shankeng Road, Shanxia Community, Pinghu Street, Longgang District, Shenzhen City China Test Result: PASS The test report merely corresponds to the test sample. It is not permitted to copy extracts of these test result without the written permission of the test laboratory. Report No.: GTS20210605013-1-2 Page 3 of 12 Contents 1 S U MM A R Y ............................................................................ 4 1.1 General Remarks 4 1.2 Product Description 4 1.3 Description of the test mode 4 1.4 Special Accessories 5 1.5 Modifications 5 2 TES T E N V I R O N M E N T .............................................................. 6 2.1 Address of the test laboratory 6 2.2 Test Facility 6 2.3 Environmental conditions 6 2.4 Summary of measurement results 7 2.5 Statement of the measurement uncertainty 7 2.6 Equipments Used during the Test 7 3 T E S T C O N D I T I O N S A N D R E S U L T S ............................................. 8 3.1 Applicable Standard 8 3.2 Limit 8 3.3 Test Setup 8 3.4 Measurement Procedure 9 3.5 Test Result of E and H field Strength 9 3.6 Equipment Approval Considerations 11 3.7 Conclusion 11 4 T E S T S E T U P P H O T O S O F T H E E U T ......................................... 12 Report No.: GTS20210605013-1-2 Page 4 of 12 1 S U M M A R Y 1.1 General Remarks Date of receipt of test sample : June 05, 2021 Testing commenced on : June 06, 2021 Testing concluded on : June 16, 2021 1.2 Product Description Product Name: Magnetic wireless charger Model/Type reference: WX06610-A Hardware version: N-JX-WX06610-A-V1.1 Software version: V1.0 Test samples ID: GTS20210605013-1-1# Power supply: DC 9V/2A or 5V/2A Operation frequency: 110KHz - 205KHz Modulation type: ASK Antenna type: Loop coil antenna 1.3 Description of the test mode Equipment under test was operated during the measurement under the following conditions: Charging and communication mode Test Modes: Mode 1 AC/DC Adapter (9V/2A) + EUT + Wireless charger tester (Load 10W) Record Mode 2 AC/DC Adapter (9V/2A) + EUT + Wireless charger tester (Load 7.5W) Record Mode 3 AC/DC Adapter (9V/2A) + EUT + Wireless charger tester (Load 5W) Record Mode 4 AC/DC Adapter (5V/2A) + EUT + Wireless charger tester (Load 10W) Pre-tested Mode 5 AC/DC Adapter (5V/2A) + EUT + Wireless charger tester (Load 7.5W) Pre-tested Mode 6 AC/DC Adapter (5V/2A) + EUT + Wireless charger tester (Load 5W) Pre-tested Note: All test modes were pre-tested, but we only recorded the worst case in this report. Report No.: GTS20210605013-1-2 Page 5 of 12 1.4 Special Accessories Follow auxiliary equipment(s) test with EUT that provided by the manufacturer or laboratory is listed as follow: Description Manufacturer Model T…

Text truncated - open the document above for the full version.

Shenzhen Global Test Service Co.,Ltd. No.7-101 and 8A-104, Building 7 and 8, DCC Cultural and Creative Garden, No.98, Pingxin North Road, Shangmugu Community, Pinghu Street, Longgang District, Shenzhen, Guangdong FCC PART 15 SUBPART C TEST REPORT Report Reference No. ..................... : FCC ID. ............................................ : GTS20210605013-1-1 2AONA-WX06610-A Compiled by ( position+printed name+signature) .. : File administrators Jimmy Wang Supervised by ( position+printed name+signature) .. : Test Engineer Aaron Tan Approved by ( position+printed name+signature) .. : Manager Jason Hu Date of issue ..................................... : June 17, 2021 Representative Laboratory Name .: Shenzhen Global Test Service Co., Ltd. Address ............................................ : No.7-101 and 8A-104, Building 7 and 8, DCC Cultural and Creative Garden, No.98, Pingxin North Road, Shangmugu Community, Pinghu Street, Longgang District, Shenzhen, Guangdong Applicant’s name ............................ : Shenzhen Pilot Technology Co., Ltd Address ............................................ : 101 A1 Industrial Park, building a1, No.7, Shankeng Road, Shanxia Community, Pinghu Street, Longgang District, Shenzhen City China Test specification ...........................: Standard ........................................... : FCC Rules and Regulations Part 15 Subpart C (Section 15.209), ANSI C63.10: 2013 TRF Originator .................................. : Shenzhen Global Test Service Co.,Ltd. Master TRF ....................................... : Dated 2014-12 Shenzhen Global Test Service Co.,Ltd. All rights reserved. This publication may be reproduced in whole or in part for non-commercial purpses as long as the Shenzhen Global Test Service Co.,Ltd. is acknowledged as copyright owner and source of the material. Shenzhen Global Test Service Co.,Ltd. takes no responsibility for and will not assume liability for damages resulting from the reader's interpretation of the reproduced material due to its placement and context. Test item description .....................: Magnetic wireless charger Trade Mark ....................................... : N/A Manufacturer .................................... : Shenzhen Pilot Technology Co., Ltd Model/Type reference....................... : WX06610-A Listed Models .................................. : WX06610-C,WX08610-A,WX08610-C Modulation Type ............................... : ASK Operation Frequency ........................ : From 110KHz~205KHz Rating ............................................... : Input: DC 5V 2A, 9V 2A Output: Wireless Charging: 5W/7.5W/10W Result................................................ : PASS Report No.: GTS20210605013-1-1 Page 2 of 23 T E S T R E P O R T Test Report No. : GTS20210605013-1-1 June 17, 2021 ____________________________________________________________________________________ Date of issue Equipment under Test : Magnetic wireless charger Model /Type : WX06610-A Listed Models : WX06610-C,WX08610-A,WX08610-C Applicant : Shenzhen Pilot Technology Co., Ltd Address : 101 A1 Industrial Park, building a1, No.7, Shankeng Road, Shanxia Community, Pinghu Street, Longgang District, Shenzhen City China Manufacturer : Shenzhen Pilot Technology Co., Ltd Address : 101 A1 Industrial Park, building a1, No.7, Shankeng Road, Shanxia Community, Pinghu Street, Longgang District, Shenzhen City China Test Result: PASS The test report merely corresponds to the test sample. It is not permitted to copy extracts of these test result without the written permission of the test laboratory. Report No.: GTS20210605013-1-1 Page 3 of 23 Contents 1 T E S T S T A N D A R D S ................................................................. 4 2 S U M M A R Y ............................................................................ 5 2.1 General Remarks 5 2.2 Product Description 5 2.3 Description of the test mode 5 2.4 Special Accessories 6 2.5 Modifications 6 3 T E S T E N V I R O N M E N T .............................................................. 7 3.1 Address of the test laboratory 7 3.2 Test Facility 7 3.3 Environmental conditions 7 3.4 Summary of measurement results 8 3.5 Statement of the measurement uncertainty 8 3.6 Equipments Used during the Test 8 4 T E S T C O N D I T I O N S A N D R E S U L T S ........................................... 10 4.1 AC Power Conducted Emission 10 4.2 Radiated Emission 13 4.3 Occupied Bandwidth 17 4.4 Antenna Requirement 18 5 T E S T S E T U P P H O T O S O F T H E E U T ......................................... 19 6 PH O T O S O F T H E E U T ........................................................... 20 Report No.: GTS20210605013-1-1 Page 4 of 23 1 T E S T S T A N D A R D S The tests were performed according to following standards: FCC Rules and Regulations Part 15 Subpart C (Section 15.207): Conducted limits. FCC Rules and Regulations Part 15 Subpart C (Section 15.209): Radiated emission limits; general requirements. ANSI C63.10: 2013: American National Standard for Testing Unlicensed Wireless Devices Report No.: GTS20210605013-1-1 Page 5 of 23 2 S U M M A R Y 2.1 General Remarks Date of receipt of test sample : June 05, 2021 Testing commenced on : June 06, 2021 Testing concluded on : June 16, 2021 2.2 Product Description Product Name: Magnetic wireless charger Model/Type reference: WX06610-A Hardware version: N-JX-WX06610-A-V1.1 Software version: V1.0 Test samples ID: GTS20210605013-1-1# Power supply: DC 9V/2A or 5V/2A Operation frequency: 110KHz - 205KHz Modulation type: ASK Antenna type: Loop coil antenna 2.3 Description of the test mode Equipment under test was operated during the measurement under the following conditions: Charging and communication mode Test Modes: Mode 1 AC/DC Adapter (9V/2A) + EUT + Wireless charger tester (Load 10W) Recorded Mode 2 AC/DC Adapter (9V/2A) + EUT + Wireless charger tester (Load 7.5W) Pre-tested Mode 3 AC/DC Adapter (9V/2A) + EUT + Wireless charger test…

Text truncated - open the document above for the full version.

FCC ID: 2AONA-WX06610-A
