2AONA-WX1905CWireless Power Bank

WX1905C Wireless Charging Power Bank User Manual Indicator (1) To check the power level,press the button once, the LED lights will indicate the power status. Safety Precautions Please note: Improper use may result in product damage, decreased battery life and loss of charging capacity not covered by the manufactures warranty. ● Check device voltage for compatibility before use ● Only charge the unit from your computer or a certified approved power adaptor (certification depends on your region) ● Do not store WX1905-C in high or low temperature environments, small enclosed areas without ventilation or place in fire ● Do not drop, bump, throw or shake the unit, this may damage internal components ● Do not disassemble or try to repair or modify ● Do not allow the unit to come in contact with water or moisture ● If battery becomes excessively hot, emits odour, gets dented or experiences any abnormal deformity you should stop using it immediately. ● Only dispose of battery at authorized recycling centre ● Do not use harsh chemicals or cleaning agents on the exterior of this unit Congratulations on your purchase! We recognize the stress and annoyance of running out of battery power when you are on the go, so we created the power bank WX1905-C, a quick and easy way to stay connected and powered up no matter where you are. Charging your Devices Wireless Charging: ● Check if your device supports Qi standard wireless charging; ● If it supports, place your device on the marked wireless charging area on the power bank; ● If your device is placed on the correct position of the power bank, one wireless charging indicator of the power bank will turn on green whilst wireless charging. ● Note: The WX1905-C wireless charging power bank is engineered to work with the most lightweight smartphone cases. However, if the back of the smartphone case is thicker than 3mm or contains metallic, magnetic or battery materials, it may affect the funcitonatlity of the wireless carge. . ● Insert one end of the charging cable into the USB-A or USB-C output port of power bank. ● Insert t he other end into your electronic device. ● Your device should indicate that charging has started. Charging the power bank Please note: Before using your power bank for the first time, please charge it to full. This unit requires 3-4 full charges and drain cycles before the battery is optimized to its full potential. The unit should be recharged every 3 months when not in use. * Insert the regular USB end into the output USB jack of computer or wall outlet adaptor. * Insert the other end into the micro input or USB-C port of the power bank. Specifications: ● Battery type: Polymer battery ● Micro Input: DC 5V - 2000mA ● USB-C Input: DC 5V - 2000mA ● USB-C Output: DC 5V- 2100mA ● USB-A Output1: DC 5V-2100mA ● USB-A Output2: DC 5V-2100mA ● Wireless Ouput: 5W ● Total Output: DC 5V-2100mA ● Capacity: 5000mAh, 18.5Wh ● Size: 122*66*12.4mm ● Weight: 118g Charging through USB-A and USB-C ports : (2) The 4 LED lights indicate the power level status of WX1905-C. ---4 lights --76-100% charge ---3 lights--51-75% charge ---2 lights--26%-50% charge ---1 light--0-25% charge * The indicator is flashing showing it is charging. * All indicators will light on continuously once fully charged. In DC 5V-2A Out DC 5V-2.1A Out DC 5V-2.1A USB-C In DC 5V-2A USB-C Out DC 5V-2.1A FCC STATEMENT : This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation. Warning: Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: Reorient or relocate the receiving an tenna. Increase the separation between the equipment and receiver. Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. Consult the dealer or an experienced radio/TV technician for help. FCC Radiation Exposure Statement: This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance 20cm between the radiator & your body.

FCC ID: 2AONA-WX1905C

Label Location On EUT Label Product Name: Wireless Power Bank Model No.: WX1905C FCC ID: 2AONA-WX1905C This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation.

FCC ID: 2AONA-WX1905C

version01 Shenzhen Pilot Technology Co., Ltd Declaration concerning Antenna Specification It is hereby declared that the product Model No.: WX1905C, WX1905A FCC ID : 2AONA-WX1905C fulfills the requirement in FCC test relating to the antenna type. The device specified above confirms to the FCC recommendations for internal antenna type(s) described below: Model No. of antenna: WX1905C Type of antenna:Inductive loop coil Antenna Gain of the antenna: 0 dBi Frequency range:110.1-205KHz The mounting of the antenna is fixed to the radio module and no other antenna should be used. Company name: Shenzhen Pilot Technology Co., Ltd Address: A1 Building, No.7 Shankeng Road, Shankeng Industrial Park, Shanxia Community, Pinghu Street, Longgang District, Shenzhen, China. City:Shenzhen ZIP / Postal code: N/A Country: China Place: China Date: 2020-04-02 Signature:

Report No.: 18220WC00017002FCC ID: 2AONA-WX1905CPage 1 of 13 Code:AB-RF-05-a FCC TEST REPORT Client Name: Shenzhen Pilot Technology Co., Ltd Address: A1 Building, No.7 Shankeng Road, Shankeng Industrial Park, Shanxia Community, Pinghu Street, Longgang District ,Shenzhen,China. Product Name: Wireless Power Bank Date: Mar. 31, 2020 Shenzhen Anbotek Compliance Laboratory Limited Report No.: 18220WC00017002FCC ID: 2AONA-WX1905CPage 2 of 13 Code:AB-RF-05-a Contents 1. General Information ............................................................................................................................................... 4 1.1. Client Information ....................................................................................................................................... 4 1.2. Description of Device (EUT) ..................................................................................................................... 4 1.3. Auxiliary Equipment Used During Test ................................................................................................... 5 1.4. Test Equipment List .................................................................................................................................... 5 1.5. Measurement Uncertainty ......................................................................................................................... 5 1.6. Description of Test Facility ........................................................................................................................ 5 2. Measurement and Result ..................................................................................................................................... 6 2.1. Requirements .............................................................................................................................................. 6 2.2. Test Setup .................................................................................................................................................... 7 2.3. Test Procedure ............................................................................................................................................ 7 2.4. Test Result ................................................................................................................................................... 7 2.4.1. Equipment Approval Considerations item 5.b of KDB 680106 D01 v03. ...................................... 7 2.4.2. Environmental evaluation and exposure limit according to FCC CFR 47 part 1, 1.1307(b), 1.1310 .................................................................................................................................................................. 9 APPENDIX I -- TEST SETUP PHOTOGRAPH ................................................................................................... 11 Report No.: 18220WC00017002FCC ID: 2AONA-WX1905CPage 3 of 13 Code:AB-RF-05-a TEST REPORT Applicant: Shenzhen Pilot Technology Co., Ltd Manufacturer: Shenzhen Pilot Technology Co., Ltd Product Name: Wireless Power Bank Model No.: WX1905C, WX1905A Trade Mark: N.A. Rating(s): Micro/Type-C Input: DC 5V, 2A (with DC 3.7V, 5000 mAh battery inside) USB-A/Type-C Output: DC 5V, 2.1A Wireless output: 5W Test Standard(s) : FCC Part 1.1310, 1.1307(b) Test Method(s): KDB680106 D01 RF Exposure Wireless Charging Apps v03 The device described above is tested by Shenzhen Anbotek Compliance Laboratory Limited to determine the maximum emission levels emanating from the device and the severe levels of the device can endure and its performance criterion. The measurement results are contained in this test report and Shenzhen Anbotek Compliance Laboratory Limited is assumed full of responsibility for the accuracy and completeness of these measurements. Also,this report shows that the EUT (Equipment Under Test) is technically compliant with the FCC Part 1.1307 & KDB680106 D01 requirements. This report applies to above tested sample only and shall not be reproduced in part without written approval of Shenzhen Anbotek Compliance Laboratory Limited. Date of ReceiptMar. 12, 2020 Date of TestMar. 12~28, 2020 Prepared By (Engineer / Dolly Mo) Reviewer (Supervisor / Bibo Zhang) Approved & Authorized Signer (Manager / Tom Chen) Report No.: 18220WC00017002FCC ID: 2AONA-WX1905CPage 4 of 13 Code:AB-RF-05-a 1. General Information 1.1. Client Information 1.2. Description of Device (EUT) Product Name : Wireless Power Bank Model No.: WX1905C, WX1905A (Note: All samples are the same except the model and appearance, so we prepare "WX1905C" for test only.) Trade Mark: N.A. Test Power Supply: AC 120V, 60Hz for adapter / DC 3.7V Battery inside Test Sample No.: 1-2-1(Normal Sample), 1-2-1(Engineering Sample) Product Description : Operation Frequency:110.1-205KHz Modulation Type:QI Antenna Type:Inductive loop coil Antenna Antenna Gain(Peak):0 dBi Remark:1) For a more detailed features description, please refer to the manufacturer’s specifications or the User’s Manual. Applicant: Shenzhen Pilot Technology Co., Ltd Address: A1 Building, No.7 Shankeng Road, Shankeng Industrial Park, Shanxia Community, Pinghu Street, Longgang District, Shenzhen, China. Manufacturer: Shenzhen Pilot Technology Co., Ltd Address : A1 Building, No.7 Shankeng Road, Shankeng Industrial Park, Shanxia Community, Pinghu Street, Longgang District, Shenzhen, China. Factory: Shenzhen Pilot Technology Co., Ltd Address : A1 Building, No.7 Shankeng Road, Shankeng Industrial Park, Shanxia Community, Pinghu Street, Longgang District, Shenzhen, China. Report No.: 18220WC00017002FCC ID: 2AONA-WX1905CPage 5 of 13 Code:AB-RF-05-a 1.3. Auxiliary Equipment Used During Test Adapter: Manufacturer: ZTE M/N: STC-A2050I1000USBA-C S/N: 201202102100876 Input: 100-240V~ 50/60Hz, 0.3A Output: DC 5V, 2000mA 1.4. Test Equipment List ItemEquipmentManufacturerModel No.Serial No.Last Cal.Cal. Interval 1 Magnetic field meter NARDAELT-400423623 …

Text truncated - open the document above for the full version.

FCC ID: 2AONA-WX1905C Photo of Conducted Emission Measurement Photo of Radiation Emission Test Photo of MPE Measurement
