2AONA-WX1910APDPower Bank

WX1910APD 5W、7.5W、10W Micro In DC 5V-2A/9V-2A USB-C In DC 5V-3A/9V-2A USB-C Out DC 5V-3A/9V-2A/12V-1.5A USB-A 1/2 Out DC 5V-3A/ 9V-2A/ 12V-1.5A FCC STATEMENT : This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation. Warning: Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: Reorient or relocate the receiving an tenna. Increase the separation between the equipment and receiver. Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. Consult the dealer or an experienced radio/TV technician for help. FCC Radiation Exposure Statement: This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance 20cm between the radiator & your body.

FCC ID: 2AONA-WX1910APD

Label Location On EUT Label Product Name: Power Bank Model No.: WX1910APD FCC ID: 2AONA-WX1910APD This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation.

FCC ID: 2AONA-WX1910APD ANT

version01 Shenzhen Pilot Technology Co., Ltd Declaration concerning Antenna Specification It is hereby declared that the product Model No.: WX1910APD, WX1910CPD FCC ID : 2AONA-WX1910APD fulfills the requirement in FCC test relating to the antenna type. The device specified above confirms to the FCC recommendations for internal antenna type(s) described below: Model No. of antenna: WX1910APD Type of antenna:Inductive loop coil Antenna Gain of the antenna: 0 dBi Frequency range:110.1-205KHz The mounting of the antenna is fixed to the radio module and no other antenna should be used. Company name: Shenzhen Pilot Technology Co., Ltd Address: 101 A1 Industrial Park, building a 1, No.7, Shankeng Road, Shanxia community, Pinghu Street, Longgang District, Shenzhen City, China City:Shenzhen ZIP / Postal code: N/A Country: China Place: China Date: 2020-04-26 Signature:
