2AOSJ-EKPL2BLE Smart Padlock

C5266091_X24_Ed.2 1/1 “Attestation Statements” TO: Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 The Commission adopted rules that prohibit equipment authorization for “covered” telecommunications equipment and video surveillance equipment produced by entities identified on the Commission’s Covered List 1 , which is periodically updated. See the Covered List for more details. This Attestation Statement is to confirm that we follow the Section 2.911(d)(5)(i)-(ii) Applicant Company name: Smlpretty Technology Co., Ltd Grantee code: 2AOSJ FCC ID:2AOSJ-EKPL2 FRN:0027142736 Contact Name: Peter Zhang Address:Unit 4J, Block B, Central, Xixiang Town, Bao'an District, Shenzhen, China Telephone No:+8618682028871 Fax No:0755-23280482 Email: [email protected] i.[SmlprettyTechnologyCo.,Ltd] (“the applicant”) certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. The applicant must sign this certification. ii. [SmlprettyTechnologyCo.,Ltd] (“the applicant”) certifies that, as of the date of the filing of the application, the applicant is not (as a specifically named entity or any of its subsidiaries or affiliates) identified on the Covered List as an entity producing “covered” equipment. The applicant must sign this certification. [SmlprettyTechnologyCo.,Ltd] (“the applicant”) certifies that, as of the date of the filing of the application, the applicant is not identified on the Covered List as an entity producing “covered” equipment . Date: 2024/08/13 Applicant’s Name:Peter Zhang Title:Manager Signature 1 The Commission’sCovered Listis published by the Public Safety and Homeland Security Bureau and posted on the Commission’s website. This Covered List, which is periodically updated, identifies particular equipment, produced by particular entities, that constitutes “covered” equipment.https://www.fcc.gov/supplychain/coveredlist

SmlprettyTechnologyCo.,Ltd Product Similarity Declaration Product name:BLE Smart Padlock Model name: EKPL2, ZX-5211 FCC ID:2AOSJ-EKPL2 We ( Smlpretty Technology Co., Ltd ) hereby state that all the models are electrical identical including the same software parameter and hardware design (i.e., circuit design, PCB Layout, RF module/circuit, antenna type(s) and antenna location, components on PCB, etc.,), same mechanical structure and design (including product enclosure, materials, etc.,), the only difference is the model number. Signature: Name:Peter Zhang Title: Manager Place, date:Shenzhen, 2024.08.27

C5266091_X8_Ed.1 1/1 Letter of Authorization Smlpretty Technology Co., Ltd Company:Smlpretty Technology Co., Ltd Address:Unit 4J, Block B, Central, Xixiang Town, Bao'an District, Shenzhen, China Product Name: BLE Smart Padlock Model Number:EKPL2, ZX-5211 FCC Identifier: 2AOSJ-EKPL2 We authorize LGAI Technological Center S.A., Ronda de la Font del Carme, s/n, 08193 Bellaterra, Spain, to act on our behalf on all matters concerning the above named equipment. Any individual within LGAI Technological Center S.A. is authorized to act on our behalf and take action on the application. We declare that authorize LGAI Technological Center S.A., Ronda de la Font del Carme, s/n, 08193 Bellaterra, Spain, is allowed to forward all information related to the approval project to the Federal Communication Commission and to discuss any issues concerning the approval application. Any and all acts carried out by LGAI Technological Center S.A. on our behalf shall have the same effect as acts of our own. Name:Peter ZhangDate: 2024-08-13 Title: Manager Signature of applicant:

C5266091_X10_Ed.2 1/1 SmlprettyTechnologyCo.,Ltd Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 Date: 2024-08-13 Subject: Request for Confidentiality FCC ID: 2AOSJ-EKPL2 To Whom It May Concern, Pursuant to the provisions of Sections 0.457 and 0.459 of Commission's rules (47CFR0.457, 0.459), we are requesting the Commission to withhold the following attachment(s) as confidential document from public disclosure. ExhibitsLong-Term Confidentiality Short-Term Confidentiality NOTE 2 ID Label/LocationNoNo Attestation StatementNoNo External PhotosNo ☒ Block Diagram ☒☐ Schematics ☒☐ Test ReportNoNo Test Setup PhotosNo ☒ User’s Manual ☐ NOTE 1 ☒ Internal Photos ☐ NOTE 1 ☒ Parts List / Tune Up ☐☐ RF Exposure InfoNoNo Operational Description ☒☐ Cover Letter(s)NoNo SDR Software / Security Info ☐ No NOTE 1: Long‐Term Confidentiality may be permitted under special conditions (SeeII. LONG‐TERM CONFIDENTIALITY, Section 3 of KDB 726920, use last in force) NOTE 2: Short‐Term Confidentiality can be requested for a maximum of 180 days from the date of the grant. Above mentioned document contains detailed system and equipment description are considered as proprietary information in operation of the equipment. The public disclosure of above documents might be harmful to our company and would give competitor an unfair advantage in the market. In case of short-term Confidentiality, the applicant requests the exhibits selected above are withheld from public view for a period of ___180___ days from the date of the Grant of Equipment Authorization and prior to marketing. It is our understanding that all measurement test reports, FCC ID label format and correspondent during certification review process cannot be granted as confidential documents and those information will be available for public review once the grant of equipment authorization is issued. C5266091_X10_Ed.2 1/1 Sincerely, Signature: Nam e : Peter Zhang Title: Manager

Label: BLE Smart Padlock Model ： EKPL2 FCC ID: 2AOSJ‐EKPL2

FCC ID:2AOSJ-EKPL2 RF Exposure Evaluation According toKDB 447498 D01 General RF Exposure Guidance v06and part 2.1093， Unless specifically required by thepublished RF exposure KDB procedures, standalone 1-g head or body and 10-g extremity SAR evaluation for general population exposure conditions, by measurement or numerical simulation, is not required when the correspondingSAR Test Exclusion Thresholdcondition(s), listed below, is (are) satisfied. For 100 MHz to 6 GHz and test separation distances≤5mm,the1-gand10-gSARtest exclusion thresholds aredetermined by the following: [(max. power of channel, including tune-up tolerance, mW) / (min. test separation distance, mm)]ꞏ[√f (GHz) ]≤3.0 for 1-g SAR, and≤7.5 for 10-g extremity SAR, where f (GHz) is the RF channel transmit frequency in GHz Power and distance are rounded to thenearest mW and mm before calculation The result is rounded to one decimal place for comparison Here, So a SAR test is not required Mode Frequen cy (MHz) Max Power (dBm) Target power W/ tolerance (dBm) Max tune up power tolerance (dBm) Max Power (mW) Min. Distance (mm) Calc. thresholds limit BLEGFSK 2402 -4.19 -4±1.0 -3 0.5015.000.155 3.0 2440 -4.25 -4±1.0 -3 0.5015.000.157 3.0 2480 -5.15-5±1.0 -4 0.3985.000.125 3.0

1、技术指标(TechnicalSpecification) 电性能指标Electrical Specifications 频率范围Frequency Range（MHz） 2400-2500 频带宽度Bandwidth (-10dB)（MHz）≥100 输入阻抗 Input Impedance （Ω） 50 电压驻波比 VSWR (max at all of frequency range) ＜ 1.8 增益 Gain (@2.45GHz max) （ dBi ） 0.338 极化形式Polarization Type 雷电保护Lightning Protection 功率容量Power Capacity（mW） 1000 Linear polarization DC ground Smlpretty Technology Co., Ltd 2. 天线尺寸 Antenna size XY Plane XZ Plane YZ Plane

FCC TEST REPORT FCC ID: 2AOSJ-EKPL2 Product:BLE Smart Padlock Model Name :EKPL2, ZX-5211 Brand:N/A Report No.:NCT24032187E Prepared for Smlpretty Technology Co., Ltd Unit 4J, Block B, Central, Xixiang Town, Bao'an District, Shenzhen, China Prepared by Shenzhen NCT Testing Technology Co., Ltd. A101&2F B2, Fuqiao 6th Area, Xintian Community, Fuhai Street, Baoan District, Shenzhen, People’s Republic of China TEL: 400-8868-419 FAX: 86-755-27790922 Report No.: NCT24032187E Page 2 of 46 Hotline: 400-8868-419Fax: 86-755-27790922http://www.ncttesting.cn 1 TEST RESULT CERTIFICATION Applicant’s name: Smlpretty Technology Co., Ltd Address: Unit 4J, Block B, Central, Xixiang Town, Bao'an District, Shenzhen, China Manufacture's name : Smlpretty Technology Co., Ltd Address: Unit 4J, Block B, Central, Xixiang Town, Bao'an District, Shenzhen, China Product name: BLE Smart Padlock Model name: EKPL2, ZX-5211 Standards: FCC CFR47 Part 15 Section 15.247 Test procedure: ANSI C63.10:2013 Date of test: Aug. 08, 2024-Aug. 14, 2024 Date of Issue: Aug. 15, 2024 This device described above has been tested by NCT, and the test results show that the equipment under test (EUT) is in compliance with the FCC requirements. And it is applicable only to the tested sample identified in the report. This report shall not be reproduced except in full, without the written approval of NCT, this document may be altered or revised by NCT, personal only, and shall be noted in the revision of the document. Test Engineer: Keven Wu / Engineer Technical Manager: Henry Wang / Manager Report No.: NCT24032187E Page 3 of 46 Hotline: 400-8868-419Fax: 86-755-27790922http://www.ncttesting.cn Contents Page 1 TEST RESULT CERTIFICATION...............................................................................................................................2 2 TEST SUMMARY.......................................................................................................................................................... 5 2.1 T ESTSITE............................................................................................................................................................6 3 GENERAL INFORMATION..........................................................................................................................................7 3.1 G ENERALDESCRIPTION OFE.U.T.....................................................................................................................7 3.2 C HANNELLIST..................................................................................................................................................... 8 3.3 T ESTSETUPCONFIGURATION............................................................................................................................9 3.4 T ESTMODE......................................................................................................................................................... 9 4 EQUIPMENT DURING TEST.................................................................................................................................... 10 4.1 E QUIPMENTSLIST............................................................................................................................................. 10 4.2 M EASUREMENTUNCERTAINTY......................................................................................................................... 12 4.3 D ESCRIPTION OFSUPPORTUNITS...................................................................................................................12 5 CONDUCTED EMISSION.......................................................................................................................................... 13 5.1 E.U.T. O PERATION............................................................................................................................................13 5.2 EUT S ETUP....................................................................................................................................................... 13 5.3 T ESTSET-UP (BLOCKDIAGRAM OFCONFIGURATION)................................................................................. 14 5.4 M EASUREMENTPROCEDURE............................................................................................................................14 5.5 C ONDUCTEDEMISSIONLIMIT........................................................................................................................... 14 5.6 M EASUREMENTDESCRIPTION.......................................................................................................................... 14 5.7 C ONDUCTEDEMISSIONTESTRESULT.............................................................................................................14 6 RADIATED SPURIOUS EMISSIONS...................................................................................................................... 17 6.1 EUT O PERATION...............................................................................................................................................17 6.2 T ESTSETUP...................................................................................................................................................... 18 6.3 S PECTRUMANALYZERSETUP.......................................................................................................................... 19 6.4 T ESTPROCEDURE.............................................................................................................................................20 6.5 S UMMARY OFTESTRESULTS...........................................................................................................................23 7 CONDUCT BAND EDGE AND SPURIOUS EMISSIONS MEASUREMENT....................................................30 7.1 T ESTPROCEDURE............................................................................................…
