1 Hand control User Manual 1. Performance parameter Model KDH231 Voltage 4.5VDC（3AAA 1.5V battery） Current MAX 50mA Keys 21 Protection class IP 42 Main material HIPS-2230 RF 2420Mhz Key 1: press button 1, flashlight lit; release button 1, flashlight extinguished; Key 2: press button 2 for 3 seconds ， remember the current position (cover before memory), while backlight flash 3 times, control box buzzing 1 time; 2 After remembering the position, press button 2, the bed switch to the current memory position; Key 3: press button 3 ， bed bottom lamp lit ； press button 3 again， bed bottom lamp extinguished; Key 4: press button 4 for 3 seconds, remember the current position (cover before memory), while backlight flash 3 times, control box buzzing 1 time; After remembering the position, press the button 4 and switch the bed to zero gravity position; Key 5: press button 5 for 3 seconds , backlight flash 3 times, key lock, while press any key invalid, background light flash 2 times; press button 5 for 3 seconds again, backlight flash 3 times, key unlock, all keys return to normal function; Key 6: press button 6 for 3 seconds, remember the current position (cover the memory before), while backlight flash 3 times, control box buzzing 1 time; After remembering the position, press the button 6, the bed body switch to stop snoring position; Key 7: press button 7 for 3 seconds, remember the current position (cover the memory before), while backlight flash 3 times, control box buzzing 1 time; After remembering the position, press the button 7, the bed body switch to the viewing position; Key 8: press button 8 for 3 seconds, remember the current position (cover before memory), while backlight flash 3 times, control box buzzing 1 time; After remembering the position, press button 8, the bed body switch to BOOK position; Key 9: press button 9,bed back rise; Key 10: press button 10,bed leg down; Key 11:press button 11,bed back down; Key 12:press button 12,bed leg rise; Key 13:press button 13, bed body lying flat; Key 14: press button 14, bed back and legs rise at the same time; Key 15:press button 15, bed back and legs down at the same time; Key 16: short press button 16, head massage motor vibration enhancement. It is divided into four; Key 17: short press button 17 ， 15 min indicator light work, vibration motor working for 15 minutes to stop; Press the button 17 again，30 min the indicator light work, the vibration motor continues to work for 30 minutes to stop; three short press the button 17 on the third ， 45 min indicator light work, vibration motor work for 45 minutes after stopping; Key 18: short press button 18, foot massage motor vibration enhancement.It 3 is divided into four files; Key 19: short press button 19, foot massage motor vibration weakened, It is divided into four files; Key 20: short press key 20, switch vibration motor different modes. There are four modes; Key 21: short press key 21, head massage motor vibration weakened.It is divided into four files. This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. FCC warning: Any Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: -Reorient or relocate the receiving antenna. -Increase the separation between the equipment and receiver. -Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. -Consult the dealer or an experienced radio/TV technician for help. The device has been evaluated to meet general RF exposure requirement. T he device can be used in portable exposure condition without restriction.
