2AOU9-HWCH12V-24V Waterproof Wireless Charger

ATTACHING YOUR PHONE DETACHING YOUR PHONE 2. 1. 45° 2.1. Annex Products Pty Ltd, Australia, declares that the product QL-5764 is in compliance with RED Directive (2014/53/EU) . The CE certificate of conformity can be found at: www.quadlock.com.au/compliance Annex Products Pty Ltd, Australia, declares that the product QL-5764 is in compliance with the following Directives: Radio Equipment Regulations 2017, Electrical Equipment (Safety) Regulations 2016 and The Restrictions of the Use of Certain Hazardous Substances in Electrical and Electronic Equipment 2012. The certificate of conformity can be found at: www.quadlock. com.au/compliance Radiated H-Field -19.03 dBμA/m (@10m) (only for EU and UK) TX/RX frequency range 120.0kHz - 126.4kHz (only for EU and UK) FCC Compliance Statements This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules and has been assigned FCC ID: 2AOU9-HWCH. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: - Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. - Consult the dealer or an experienced radio/TV technician for help. - Reorient or relocate the receiving antenna. - Increase the separation between the equipment and receiver. Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. RF Exposure Compliance This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance 20cm between the radiator and your body. This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter. INDUSTRIE CANADA ( IC: 27134-HWCH ) IC Caution: This device contains licence-exempt transmitter(s) that comply with Innovation, Science and Economic Development Canada’s licence-exempt RSS(s). Operation is subject to the following two conditions: (1) this device may not cause interference, (2) this device must accept any interference, including interference that may cause undesired operation of the device. This equipment complies with Canada radiation exposure limits set forth for an uncontrolled environment. IC Caution: L’émetteur exempt de licence contenu dans le présent appareil est conforme aux CNR d’Innovation, Sciences et Développement économique Canada applicables aux appareils radio exempts de licence. L’exploitation est autorisée aux deux conditions suivantes : (1) L’appareil ne doit pas produire de brouillage; (2) L’appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible d’en compromettre le fonctionnement. Cet équipement est conforme Canada limites d’exposition aux radiations dans un environnement non contrôlé. ISED Radiation Exposure statement This equipment complies with IC RSS-102 radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance 20 cm between the radiator and your body. This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter. Cet équipement est conforme aux limites d’exposition aux radiations IC CNR-102 établies pour un environnement non contrôlé. Cet équipement doit être installé et utilisé avec une distance minimale de 20 cm entre le radiateur et votre corps. Cet émetteur ne doit pas être colocalisé ou fonctionner en conjonction avec une autre antenne ou un autre émetteur. 1 2V-24V WATE R P ROO F WIRELESS CHARGER 2303-098-2 Model No.: QL-5764 2303-098-2_12V-24V Waterproof Charger Instructions_PO-1.indd 2-42303-098-2_12V-24V Waterproof Charger Instructions_PO-1.indd 2-427/7/2023 4:30 pm27/7/2023 4:30 pm INSTALLATION WHAT’S IN THE BOX 1x 12-24v Weatherproof Wireless Charging Head 2x Cable grommet plugs 1x 3mm hex key 1x M5x35mm CSK head hex socket Screw 5x 5x200mm Nylon zip ties NOTE. Use supplied 35mm screw 1. Tighten (4Nm) +– +– WIRING DIAGRAM 12V - 24V BAT TERY SWITCH FUSE 3A R ATED Hardwired 20 AWG Cable18 AWG Extension Cable (minimum) (not supplied) Waterproof heatshrink extension REFER TO ELECTRICAL SAFETY LEAFLET > Customer SourcedQuad Lock Supplied < CABLE FITMENT USING CABLE TIES? Recommend not to tighten the cable ties too much to avoid stressing the cables and causing damage. Ensure there is some slack in the cable near the Wireless Charging Head to allow for ease of engaging / disengaging the phone on Wireless Charger. Wireless Charger has a cable routing groove on the underside to hold the cable. LED STATES POWER ON / STAND BY ERROR MODE CHARGING / FULL CHARGE Attaches to a Quad Lock 360 BASE & ARM INSTALLATION WITH GROMMET GROMMET (supplied) Substrate Ø8mm CABLE CLEARANCE Once the Wireless Charging Head is installed in the preferred orientation, push down on it to ensure the cable does not interfere with other devices or any operation (steering, breaking, etc). 2303-098-2_12V-24V Waterproof Charger Instructions_PO-1.indd 5-82303-098-2_12V-24V Waterproof Cha…

Text truncated - open the document above for the full version.

Applicant Declaration QSF27-14-04 Rev 1.0 Rev. Feb 6, 2023 Page 1 of 1 Original Issue: Jan. 4, 2021 SGS North America Inc. 620 Old Peachtree Road SUITE 100 Suwanee, Georgia 30024 United States Applicant Legal Business Name Annex Products Pty Ltd Address Level 3 Suite 6A, 299 Toorak Road, South Yarra, VIC 3141 Australia Grantee Code 2AOU9 FCC ID 2AOU9-HWCH Authorized Contact Name Chris Peters Contact Email [email protected] Contact Phone +61 3 9069 9698 I, the undersigned, certify that I am an authorized signatory for the Applicant and therefore declare; a) in accordance with 47CFR2.911(d), all of the statements herein and the exhibits attached hereto are true and correct to the best of my knowledge and belief. b) in accepting a Grant of Equipment Authorization issued by a TCB, under the authority of the FCC, as a result of the representations made in this application, the Applicant is responsible for: (1) labeling the equipment with the exact FCC ID as specified in this application, (2) compliance statement labeling pursuant to the applicable rules, (3) compliance of the equipment with the applicable technical rules, c) if the Applicant is not the actual manufacturer of the equipment, appropriate arrangements have been made with the manufacturer to ensure that production units of this equipment will continue to comply with the FCC’s technical requirements. d) in accordance with 47 CFR 2.909 and KDB394321, the Applicant has read, understood and agrees to accept that they are the responsible party and agree to abide by their responsibilities as specified under 47 CFR 2.909 and KDB394321. e) in accordance with ISO 17065, FCC KDB641163, FCC KDB610077, KDB394321 and RSP-100, the Applicant has read, understood, accepts and agrees to abide by the post market surveillance requirements. (1) the Applicant understands, accepts and agrees that a sample may be requested for surveillance testing. (2) the Applicant shall make provisions to always have a production sample available upon request by SGS, FCC and/or ISED. (3) the Applicant shall, upon request by SGS, at the Applicant’s expense, provide a production sample of the requested product to SGS, FCC and/or ISED as instructed. The sample shall include all support devices, cables, software, accessories or other hardware or software required for evaluation, review, certification and audit surveillance of products certified by SGS. f) neither the Applicant nor any party to the application is subject to a denial of Federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. §862 because of a conviction for possession or distribution of a controlled substance. See 47CFR 1.2002(b) for the definition of a “party” for these purposes. g) the Applicant has read, understood, accepts and agrees to abide by the SGS North America, Inc.(TCB) terms and conditions. Link to CFRs: https://www.fcc.gov/wireless/bureau-divisions/technologies-systems-and-innovation-division/rules-regulations-title-47 Link to KDBs: https://apps.fcc.gov/oetcf/kdb/index.cfm Link to RSP-100: https://www.ic.gc.ca/eic/site/smt-gst.nsf/eng/sf01130.html Link to the Covered List: Covered List [ Annex Products Pty Ltd ] (“the applicant”) certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. [ Annex Products Pty Ltd] (“the applicant”) certifies that, as of the date of the filing of the application, the applicant [ is not] identified on the Covered list, established pursuant to §1.50002, as an entity producing “covered” equipment. Applicant Signature: Date: Print Name: Chris Peters Title: Co-founder & CIO *NOTE: This declaration cannot be signed by an Agent, it shall be signed by an authorized person listed in the FCC database 27/06/2023

Annex Products (Quad Lock) Como Centre, Level 3, Suite 6A, 299 Toorak Rd, South Yarra VIC 3141, Australia Phone: +61 3 9069 9698 [email protected] UNITED STATES DESIGNATED AGENT LETTER Date: 27 th Jun, 2023 TO: Federal Communication Commission Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MID 21046 Applicant U.S. designated agent Company Name: Annex Products Pty Ltd Company Name: United Consulting Technology Services Co., Ltd. Grantee Code: 2AOU9 FRN 0033495714 Contact Name: Chris Peters Contact Name: David Wu Address: Level 3 Suite 6A, 299 Toorak Road, South Yarra, VIC 3141 Australia Address: 17800 CASTLETON ST STE 665 CITY OF INDUSTRY CA 91748 United States City/Province/Zip: City/Province/Zip: Telephone: +61 3 9069 9698Telephone: (626) 217-4022 Fax: Fax: United Consulting Technology Services Co., Ltd. Email: [email protected] Email: [email protected] Applicable Equipment: FCC ID: 2AOU9-HWCH ATTN: Director of Certification: We, Annex Products Pty Ltd and United Consulting Technology Services Co., Ltd. understand and acknowledge the applicants consent and the designated agent’s obligation to accept service of process in the United States for matters related to the applicable equipment, and at the physical U.S. address and e- mail of the designated agent listed above. We, Annex Products Pty Ltd and United Consulting Technology Services Co., Ltd. acknowledge the applicant’s acceptance of its obligation to maintain an agent for service of process in the United States for no less than one year after either the grantee has permanently terminated all marketing and importation of the applicable equipment within the U.S., or the conclusion of any Commission-related administrative or judicial proceeding involving the equipment, whichever is later. Applicant Name (Printed): Chris Peters Title: Co-founder & CIO Signature: U.S. designated agent Name (Printed): David Wu Title: CEO Signature:

Annex Products (Quad Lock) Como Centre, Level 3, Suite 6A, 299 Toorak Rd, South Yarra VIC 3141, Australia Phone: +61 3 9069 9698 [email protected] Date: 27 th June, 2023 TO: Federal Communication Commission Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MID 21046 Regarding: FCC ID: 2AOU9-HWCH To whom it may concern: We, the undersigned, hereby authorize SGS-CSTC Standards Technical Services Co., Ltd. (SGS) Shenzhen Branch to act on our behalf in all manners relating to application for equipment authorization with respect to the FCC ID above, including signing of all documents relating to these matters. Any and all acts carried out by the agent on our behalf shall have the same effect as acts of our own. We, the undersigned, hereby certify that we are not subject to a denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 853(a). Where our agent signs the application for certification on our behalf, I acknowledge that all responsibility for complying with the terms and conditions for Certification, as specified by SGS North America, Inc., still resides with Annex Products Pty Ltd This authorization is valid until further written notice from the applicant. Print Name: Chris Peters Title: Co-founder & CIO Signature: On behalf of Company: Annex Products Pty Ltd Telephone: +61 3 9069 9698 E-mail: [email protected]

Annex Products (Quad Lock) TO: Federal Communication Commission Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MID 21046 Regarding: Confidentiality Request regarding application for FCC ID: 2AOU9-HWCH LONG TERM CONFIDENTIALITY Pursuant to 47 CFR Section 0.459 and 0.457 of the commission’s rules, the applicant hereby request confidential treatment of the documents listed below, associated with the certification application referenced above. Schematic(s) Block Diagrams Operational Descriptions The documents above contain proprietary information not released to the public. Public disclosure of this information may prove harmful to the business of the applicant. SHORT TERM CONFIDENTIALITY（Remark：如下资料需要短期保密请选择天数0，45,90或者180天，短期保密期间产品不能在美国市场上售卖。) Additionally, the applicant requests the following documents be held confidential until the device is marketed or 0 days from the grant date, whichever is less. If the device is marketed within 0 days of the Grant Date, the applicant will notify the TCB per FCC KDB 726920 D01 Confidentiality Request Procedures. External Photos Internal Photos Test Setup Photos User manual(s) Sincerely, Print Name: Chris Peters Title: Co-founder & CIO Signature: On behalf of Company: Annex Products Pty Ltd Telephone: +61 3 9069 9698 E-mail: [email protected]

Annex Products (Quad Lock) Como Centre, Level 3, Suite 6A, 299 Toorak Rd, South Yarra VIC 3141, Australia Phone: +61 3 9069 9698 [email protected] Cover Letter-Wireless Charger Approval Date: 2023-06-27 Gentlemen: There’s a 11V-32V Waterproof Wireless Charger that would like to have your authorization as an Inductive wireless power transfer applications approval. The specific product as below, 11V-32V Waterproof Wireless Charger, with its designed features and specified description, meets special requirements for KDB 680106 D01 section 5.2 requirements. Company: Annex Products Pty Ltd Product Name: 12V-24V Waterproof Wireless Charger Model Number: QL-5764 FCC ID: 2AOU9-HWCH KDB 680106 D01 Section 5.2 Requirements Product Technical Specification Result a) Power transfer frequency is less that 1 MHz120 – 126.4kHzComplied b) Output power from each primary coil is less than or equal to 15 watts. 5W / 7.5W / 10W / 15W Complied c) The transfer system includes only single primary and secondary coils. This includes charging systems that may have multiple primary coils and clients that are able to detect and allow coupling only between individual pairs of coils Complied d)Client device is placed directly in contact with the transmitter. Complied e) Mobile exposure conditions only This equipment installed and operated with minimum distance 20cm between the radiator and User’s body. Complied f)The aggregate H-field strengths at 15 cm surrounding the device and 20 cm above the top surface from all simultaneous transmitting coils are demonstrated to be less than 50% of the MPE limit. Please refer to RF exposure report Complied Sincerely, Print Name: Chris Peters Title: Co-founder & CIO Signature: On behalf of Company: Annex Products Pty Ltd Telephone: +61 3 9069 9698 E-mail: [email protected]

SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch SZEMC-TRF-A02 Rev.A/0 Page: 1 of 5 External Photos for SZCR2305001701AT FCC ID: 2AOU9-HWCH SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch SZEMC-TRF-A02 Rev.A/0 Page: 2 of 5 EUT Constructional Details (EUT Photos) SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch SZEMC-TRF-A02 Rev.A/0 Page: 3 of 5 SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch SZEMC-TRF-A02 Rev.A/0 Page: 4 of 5 SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch SZEMC-TRF-A02 Rev.A/0 Page: 5 of 5

TRADEMARK: QUAD LOCK COMPLIANCE MARKING & RATING LABEL 12V-24V WATERPROOF WIRELESS CHARGER - REGULATORY MARKINGS FOR REFERENCE REV.DESCRIPTION DRAWN BY APPROVERDATE APP 3215 C D 46 A B A4 SCALE 1:1 THIS DRAWING CONTAINS CONFIDENTIAL INFORMATION AND SHOULD NOT BE COPIED OR REPRODUCED WITHOUT WRITTEN PERMISSION FROM QUAD LOCK DESCRIPTION DRAWING NO. 1 of 1 SHEETREVISIONSHEET SIZE APPROVED DRAWNDATE DATE 050100200250150 0 50 100 150 DO NOT SCALE - IF IN DOUBT ASK DRAWN TO AS1100 ALL DIMENSIONS IN MILLIMETERS PHONE +61 3 9069 9698 [email protected] WWW.QUADLOCKCASE.NET QUAD LOCK® LEVEL 3 SUITE 6A, 299 TOORAK ROAD, SOUTH YARRA, VIC 3141 AUSTRALIA DIMENSIONAL TOLERANCE TO DIN ISO 2768-1 (m) (UNLESS SPECIFIED) 0.1 - 6mm 0.1 6 - 30mm 0.2 30 - 120mm 0.3 120 - 400mm 0.5 DRAFT WHERE APPLICABLE MUST REMAIN WITHIN DIMENSIONS

SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch SZEMC-TRF-A03 Rev.A/0 Page: 1 of 4 Internal Photos for SZCR2305001701AT FCC ID: 2AOU9-HWCH SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch SZEMC-TRF-A03 Rev.A/0 Page: 2 of 4 EUT Constructional Details (EUT Photos) SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch SZEMC-TRF-A03 Rev.A/0 Page: 3 of 4 SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch SZEMC-TRF-A03 Rev.A/0 Page: 4 of 4 - End of the Appendix -

SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch SZEMC-TRF-01 Rev. A/0 Aug01,2022 Report No.: SZCR230500170102 Page: 1 of 9 Keny Xu EMC Laboratory Manager 1 COVER PAGE Human Exposure Report Application No.: SZCR2305001701AT Applicant: Annex Products Pty Ltd Address of Applicant: Level 3 Suite 6A, 299 Toorak Road, South Yarra, VIC 3141 Australia Manufacturer: Annex Products Pty Ltd Address of Manufacturer: Level 3 Suite 6A, 299 Toorak Road, South Yarra, VIC 3141 Australia Factory: Shenzhen Huagon Technology Co., Ltd Address of Factory: 401-403, Building B, Weihuada Industrial Park, No. 5, Lirong Road, Xinshi community, Dalang street, Longhua District, Shenzhen Equipment Under Test (EUT): EUT Name: 12V-24V Waterproof Wireless Charger Model No.: QL-5764 Trade Mark: QUAD LOCK FCC ID: 2AOU9-HWCH Standards: 47 CFR PART 1, Subpart I, Section 1.1310 47 CFR PART 2, Subpart J, Section 2.1091 Date of Receipt: 2023-05-30 Date of Test: 2023-06-01 to 2023-06-08 Date of Issue: 2023-06-29 Test Result : Pass* * In the configuration tested, the EUT complied with the standards specified above SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch SZEMC-TRF-01 Rev. A/0 Aug01,2022 Report No.: SZCR230500170102 Page: 2 of 9 Revision Record Version Chapter Date Modifier Remark 01 2023-06-29 Original Authorized for issue by: Leo Li/Project Engineer Eric Fu/Reviewer SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch SZEMC-TRF-01 Rev. A/0 Aug01,2022 Report No.: SZCR230500170102 Page: 3 of 9 2 Contents 1 COVER PAGE .................................................................................................................................................. 1 2 CONTENTS ....................................................................................................................................................... 3 3 GENERAL INFORMATION ............................................................................................................................. 4 3.1 DETAILS OF E.U.T. .......................................................................................................................................... 4 3.2 DESCRIPTION OF SUPPORT UNITS...................................................................................................................... 4 3.3 TEST LOCATION ............................................................................................................................................... 5 3.4 TEST FACILITY ................................................................................................................................................ 5 3.5 DEVIATION FROM STANDARDS ......................................................................................................................... 6 3.6 ABNORMALITIES FROM STANDARD CONDITIONS ............................................................................................... 6 4 EQUIPMENTS USED DURING TEST ............................................................................................................ 6 4.1 RF EXPOSURE TEST.......................................................................................................................................... 7 4.1.1 E.U.T. Operation.................................................................................................................................. 7 5 TEST SETUP PHOTOS ................................................................................................................................... 9 SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch SZEMC-TRF-01 Rev. A/0 Aug01,2022 Report No.: SZCR230500170102 Page: 4 of 9 3 General Information 3.1 Details of E.U.T. Power supply: Input: DC 12-24V 2A Max Output: 5W/7.5W/10W/15W Cable(s): DC cable: 150cm unshielded Operation frequency: 120.0kHz to 126.4kHz Modulation type: Load modulation Antenna type: Loop Antenna Remark: The information in this section is provided by the applicant or manufacturer, SGS is not liable to the accuracy, suitability, reliability or/and integrity of the information. 3.2 Description of Support Units Description Manufacturer Model No. Serial No. DC power supply ZHAOXIN PS-3005D REF. No.SEA27B01 E-loading N/A N/A REF. No.SEA42A00 Mobile Phone SAMSUNG SM-G9810 REF. No.SEA16K00 SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch SZEMC-TRF-01 Rev. A/0 Aug01,2022 Report No.: SZCR230500170102 Page: 5 of 9 3.3 Test Location All tests were performed at: SGS-CSTC Standards Technical Services Co., Ltd., Shenzhen Branch No. 1 Workshop, M-10, Middle Section, Science & Technology Park, Nanshan District, Shenzhen, Guangdong, China. 518057. Tel: +86 755 2601 2053 Fax: +86 755 2671 0594 No tests were sub-contracted. 3.4 Test Facility The test facility is recognized, certified, or accredited by the following organizations: • A2LA (Certificate No. 3816.01) SGS-CSTC Standards Technical Services Co., Ltd., Shenzhen EMC Laboratory is accredited by the American Association for Laboratory Accreditation(A2LA). Certificate No. 3816.01. • VCCI (Member No. 1937) The 3m Fully-anechoic chamber for above 1GHz, 10m Semi-anechoic chamber for below 1GHz, Shielded Room for Mains Port Conducted Interference Measurement and Telecommunication Port Conducted Interference Measurement of SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen EMC laboratory have been registered in accordance with the Regulations for Voluntary Control Measures with Registration No.: G-20026, R-14188, C-12383 and T-11153 respectively. • FCC –Designation Number: CN1336 SGS-CSTC Standards Technical Services Co., Ltd., Shenzhen EMC Laboratory has been recognized as an accredited testing laboratory. Designation Number: CN1336. Test Firm Registration Number: 787754. • Innovation, Science and Economic Development Canada SGS-CSTC Standards Technical Services Co., Ltd., Shenzhen EMC Laboratory has been recognized by ISED as an accredited testing laborato…

Text truncated - open the document above for the full version.

Justification statement for Antenna To: Federal Communication Commission Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MID 21046 Regarding: FCC ID: 2AOU9-HWCH Dear Sir/Madam, Only radiated measurements are used for EUT with FCC ID: 2AOU9-HWCH to show compliance with FCC limits for fundamental and spurious emissions. All measurements were performed radiated and therefore additional antenna gain documentation is not required. The detailed information for antenna as below shows: Output 1 Antenna： Design Specifications Typical Antenna Type Loop Working Frequency 120.0kHz to 126.4kHz Overall Dimensions 20.5mm Turns 10 18mm

SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch SZEMC-TRF-01 Rev. A/0 Aug01,2022 Report No.: SZCR230500170101 Page: 1 of 23 Keny Xu EMC Laboratory Manager TEST REPORT Application No.: SZCR2305001701AT Applicant: Annex Products Pty Ltd Address of Applicant: Level 3 Suite 6A, 299 Toorak Road, South Yarra, VIC 3141 Australia Manufacturer: Annex Products Pty Ltd Address of Manufacturer: Level 3 Suite 6A, 299 Toorak Road, South Yarra, VIC 3141 Australia Factory: Shenzhen Huagon Technology Co., Ltd Address of Factory: 401-403, Building B, Weihuada Industrial Park, No. 5, Lirong Road, Xinshi community, Dalang street, Longhua District, Shenzhen Equipment Under Test (EUT): EUT Name: 12V-24V Waterproof Wireless Charger Model No.: QL-5764 Trade Mark: QUAD LOCK FCC ID: 2AOU9-HWCH Standard(s) : 47 CFR Part 15, Subpart C Date of Receipt: 2023-05-30 Date of Test: 2023-06-01 to 2023-06-08 Date of Issue: 2023-06-29 Test Result: Pass* * In the configuration tested, the EUT complied with the standards specified above. SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch SZEMC-TRF-01 Rev. A/0 Aug01,2022 Report No.: SZCR230500170101 Page: 2 of 23 Revision Record Version Chapter Date Modifier Remark 01 2023-06-29 Original Authorized for issue by: Leo Li/Project Engineer Eric Fu/Reviewer SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch SZEMC-TRF-01 Rev. A/0 Aug01,2022 Report No.: SZCR230500170101 Page: 3 of 23 2 Test Summary Radio Spectrum Technical Requirement Item Standard Method Requirement Result Antenna Requirement 47 CFR Part 15, Subpart C N/A 47 CFR Part 15, Subpart C 15.203 Pass Radio Spectrum Matter Part Item Standard Method Requirement Result 20dB Bandwidth 47 CFR Part 15, Subpart C ANSI C63.10 (2013) Section 6.9.2 47 CFR Part 15, Subpart C 15.215 Pass Restricted Bands ANSI C63.10 (2013) Section 6.10.5 47 CFR Part 15, Subpart C 15.205 Pass Radiated Emissions (9kHz-30MHz) ANSI C63.10 (2013) Section 6.4 47 CFR Part 15, Subpart C 15.205 & 15.209 Pass Radiated Emissions (30MHz-1GHz) ANSI C63.10 (2013) Section 6.5 47 CFR Part 15, Subpart C 15.205 & 15.209 Pass SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch SZEMC-TRF-01 Rev. A/0 Aug01,2022 Report No.: SZCR230500170101 Page: 4 of 23 3 Contents Page 1 Cover Page ......................................................................................................................................... 1 2 Test Summary ..................................................................................................................................... 3 3 Contents ............................................................................................................................................. 4 4 General Information............................................................................................................................ 6 4.1 Details of E.U.T. ........................................................................................................................... 6 4.2 Description of Support Units ......................................................................................................... 6 4.3 Measurement Uncertainty ............................................................................................................ 6 4.4 Test Location ............................................................................................................................... 7 4.5 Test Facility .................................................................................................................................. 7 4.6 Deviation from Standards ............................................................................................................. 7 4.7 Abnormalities from Standard Conditions ....................................................................................... 7 5 Equipment List ................................................................................................................................... 8 6 Radio Spectrum Technical Requirement ..........................................................................................10 6.1 Antenna Requirement .................................................................................................................10 6.1.1 Test Requirement: ..................................................................................................................10 6.1.2 Conclusion ..............................................................................................................................10 7 Radio Spectrum Matter Test Results ................................................................................................11 7.1 20dB Bandwidth ..........................................................................................................................11 7.1.1 E.U.T. Operation ....................................................................................................................…
