2AOWK-5008TFMobile Phone

(Shenzhen Gotron Electronic CO.,LTD.) (2024.09.18) Eurofins Electrical and Electronic Testing NA, Inc. 914 West Patapsco Avenue Baltimore, MD 21230 RE: Attestation Statements Part 2.911(d)(5)(i) request for (FCC ID: 2AOWK-5008TF) [Shenzhen Gotron Electronic CO.,LTD.] (“the applicant”) certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. Sincerely, Yongbin Tang (Shenzhen Gotron Electronic CO.,LTD.) (2024.09.18) Eurofins Electrical and Electronic Testing NA, Inc. 914 West Patapsco Avenue Baltimore, MD 21230 RE: Attestation Statements Part 2.911(d)(5)(ii) request for (FCC ID: 2AOWK-5008TF) [Shenzhen Gotron Electronic CO.,LTD.] (“the applicant”) certifies that, as of the date of the filing of the application, the applicant is not identified on the Covered List as an entity producing “covered” equipment. Sincerely, Yongbin Tang

THREE STONES MEDIA LLC U.S. Agent Letter of Attestation To: Federal Communications Commission 7435 Oakland Mills Road, Columbia, MD 21046, USA Date: 9/18/2024 Ref: Attestation Statement – Part2.911(d)(7) filing FCC ID：2AOWK-5008TF Shenzhen Gotron Electronic CO.,LTD. (“the applicant”) certifies that, as of the date of the filing of the application, THREE STONES MEDIA LLC(“the agent”) is our designated U.S. agent for service of process for the abovereference FCC ID. The applicant accepts to maintain an agent for service of process in the United States forno less than one year after either the grantee has permanently terminated all marketing and importation of theapplicable equipment within the U.S., or the conclusion of any Commission-related administrative or judicialproceeding involving the equipment, whichever is later. The applicant further acknowledges it is ourresponsibility to inform the FCC whenever the agent information changes. THREE STONES MEDIA LLC ("the agent) understand it is the agent's obligation to accept service of process in the United States for matters related to the applicable equipment, and at the physical U.S. address and email address. Designated U.S. Agent Company Name: THREE STONES MEDIA LLC FRN: 0033401761 GC: 2A99E Address: 1200 Broadway St. APT 329, Los Angeles, CA90015 Signature: Contact Person: Sijie Zhang Tel: +1 267 909 3692 Email: [email protected] Applicant Company Name: Shenzhen Gotron Electronic CO.,LTD. FRN: 0027174960 GC: 2AOWK Address: 7B01, Building A, Block 1, Anhongji Tianyao Plaza, Longhua District, Shenzhen City, Guangdong Province China Signature: Contact Person: Yongbin Tang Tel: 0755-8389 5989 Email: [email protected]

Shenzhen Gotron Electronic CO.,LTD. Family models difference declaration Mobile Phone Model: GQ5008TF, Armor 27T, Armor 27, Armor 27 Ultra, Armor 27T Ultra, Armor 27 Lite, Armor 27s, Armor 27s Pro Difference declaration: All the model are the same circuit and RF module, except the model names. Regards, Signature Yongbin Tang / Manager Date/City: 2024-09-18/ Shenzhen Phone: 86-0755-8389 5989 Fax: N/A E-mail: [email protected]

Shenzhen Gotron Electronic CO.,LTD. Short Term Confidentiality Request Letter (2024-09-18) Eurofins Electrical and Electronic Testing NA, Inc. 914 West Patapsco Avenue Baltimore, MD 21230 RE: Short Term Confidentiality Request For Product: Mobile Phone Model: GQ5008TF, Armor 27T, Armor 27, Armor 27 Ultra, Armor 27T Ultra, Armor 27 Lite, Armor 27s, Armor 27s Pro FCC ID: 2AOWK-5008TF To Whom It May Concern: In accordance with sections 0.457 and 0.459 of CFR 47, < Shenzhen Gotron Electronic CO.,LTD.>. requests short-term Confidentiality of following sections of this application for a period of 180 days after grant is issued. Test setup photos External photos Internal photos User’s manual These documents contain detailed system and equipment descriptions and related information about the product, which < Shenzhen Gotron Electronic CO.,LTD. > considers to be proprietary, confidential, and a custom design and otherwise, would not release to the general public. Since this design is a basis from which future technological products will evolve, < Shenzhen Gotron Electronic CO.,LTD.> feels that this information would be of benefit to its competitors, and that the disclosure of the information in these documents would give our competitors an unfair advantage in the market. Please contact me if there is any information you may need. Sincerely, Yongbin Tang / Manager Date/City: 2024-09-18 / Shenzhen Phone: 86-0755-8389 5989 Fax: N/A E-mail: [email protected]

Shenzhen Gotron Electronic CO.,LTD. Agent Authorization Letter (2024-09-18) Eurofins Electrical and Electronic Testing NA, Inc. 914 West Patapsco Avenue Baltimore, MD 21230 RE: LETTER OF AGENT AUTHORIZATION To Whom It May Concern: We, the undersigned, hereby authorize Shenzhen NTEK Testing Technology Co., Ltd. 1/F, Building E, Fenda Science Park Sanwei, Xixiang, Bao'an District, Shenzhen, Guangdong, China Alex.li [email protected] to act on our behalf in all matters relating to application for equipment authorization, including the signing of all documents relating to these matters. We also hereby certify that no party to the application authorized hereunder is subject to the denial of benefits, including FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C.853(a). This agreement expires one year from the current date. Sincerely, Yongbin Tang / Manager Date/City: 2024-09-18 / Shenzhen Phone: 86-0755-8389 5989 Fax: N/A E-mail: [email protected]

Shenzhen Gotron Electronic CO.,LTD. Long Term Confidentiality Request Letter (2024-09-18) Eurofins Electrical and Electronic Testing NA, Inc. 914 West Patapsco Avenue Baltimore, MD 21230 RE: CONFIDENTIALITY REQUEST FOR Product: Mobile Phone Model: GQ5008TF, Armor 27T, Armor 27, Armor 27 Ultra, Armor 27T Ultra, Armor 27 Lite, Armor 27s, Armor 27s Pro FCC ID: 2AOWK-5008TF To Whom It May Concern: This letter serves as an official request for confidentiality under sections 0.457 and 0.459 of CFR 47. We have requested that the  Schematic Diagram  Block Diagram  Part List / BOM List / PCB Layout  Operational Description  Tune-up Procedure  FCC Software Configuration Control Declaration  FCC Software Security Requirements for UNII devices Required to be submitted with this application be permanently withheld from public review. Above mentioned document contains detailed system and equipment description are considered as proprietary information in operation of the equipment. The public disclosure of above documents might be harmful to our company and would give competitor an unfair advantage in the market. It is our understanding that all measurement test reports, FCC ID label format and correspondent during certification review process cannot be granted as confidential documents and those information will be available for public review once the grant of equipment authorization is issued. Please contact me if there is any information you may need. Sincerely, Yongbin Tang / Manager Date/City: 2024-09-18 / Shenzhen Phone: 86-0755-8389 5989 Fax: N/A E-mail: [email protected]

Page 1 of 230 Report No.: S24080806806001 FCC SAR EVALUATION REPORT In accordance with the requirements of FCC 47 CFR Part 2(2.1093) and IEEE Std 1528-2013 Product Name： Mobile Phone Brand Name： ulefone Model Name： GQ5008TF Family Model： Armor 27T, Armor 27, Armor 27 Ultra, Armor 27T Ultra, Armor 27 Lite, Armor 27s, Armor 27s Pro Report No.： S24080806806001 FCC ID： 2AOWK-5008TF Prepared for Shenzhen Gotron Electronic CO.,LTD. 7B01, Building A, Block 1, Anhongji Tianyao Plaza, Longhua District, Shenzhen City, Guangdong Province China Prepared by Shenzhen NTEK Testing Technology Co., Ltd. 1/F, Building E, Fenda Science Park, Sanwei Community, Xixiang Street Bao’an District, Shenzhen 518126 P.R. China Tel. 400-800-6106, 0755-2320 0050, 0755-2320 0090 Website: http://www.ntek.org.cn Page 2 of 230 Report No.: S24080806806001 TEST RESULT CERTIFICATION Applicant’s name ................. : Shenzhen Gotron Electronic CO.,LTD. Address .................................. : 7B01, Building A, Block 1, Anhongji Tianyao Plaza, Longhua District, Shenzhen City, Guangdong Province China Manufacturer's Name .......... : Shenzhen Gotron Electronic CO.,LTD. Address .................................. : 7B01, Building A, Block 1, Anhongji Tianyao Plaza, Longhua District, Shenzhen City, Guangdong Province China Product description Product name ........................ : Mobile Phone Brand Name ......................... : ulefone Model and/or type reference .............................. : GQ5008TF Family Model ......................... : Armor 27T, Armor 27, Armor 27 Ultra, Armor 27T Ultra, Armor 27 Lite, Armor 27s, Armor 27s Pro Standards ............................. : FCC 47 CFR Part 2(2.1093) IEEE Std 1528-2013 Published RF exposure KDB procedures This device described above has been tested by Shenzhen NTEK. In accordance with the measurement methods and procedures specified in IEEE Std 1528-2013 and KDB 865664 D01. Testing has shown that this device is capable of compliance with localized specific absorption rate (SAR) specified in FCC 47 CFR Part 2(2.1093). The test results in this report apply only to the tested sample of the stated device/equipment. Other similar device/equipment will not necessarily produce the same results due to production tolerance and measurement uncertainties. This report shall not be reproduced except in full, without the written approval of Shenzhen NTEK, this document may be altered or revised by Shenzhen NTEK, personal only, and shall be noted in the revision of the document. Test Sample Number ............................. S240808068006 Date of Test Date (s) of performance of tests .............. : Aug. 12, 2024 ~ Aug. 30, 2024 Date of Issue ........................................... : Sep. 14, 2024 Test Result ............................................... : Pass Prepared By : Reviewed By : Approved By : Owen Xiao (Project Engineer) Aaron Cheng (Supervisor) Alex Li (Manager) Page 3 of 230 Report No.: S24080806806001 ※ ※ Revision History ※ ※ REV. DESCRIPTION ISSUED DATE REMARK Rev.1.0 Initial Test Report Release Sep. 14, 2024 Owen Xiao Page 4 of 230 Report No.: S24080806806001 TABLE OF CONTENTS 1. General Information ............................................................................................ 6 1.1. RF exposure limits .................................................................................... 6 1.2. Statement of Compliance ........................................................................ 7 1.3. EUT Description ....................................................................................... 7 1.4. Test specification(s) .................................................................................. 9 1.5. Ambient Condition ................................................................................... 9 2. SAR Measurement System ................................................................................. 10 2.1. SATIMO SAR Measurement Set-up Diagram .......................................... 10 2.2. Robot ..................................................................................................... 11 2.3. E-Field Probe .......................................................................................... 12 2.3.1. E-Field Probe Calibration ................................................................. 12 2.4. SAM phantoms ...................................................................................... 13 2.4.1. Technical Data .................................................................................. 14 2.5. Device Holder ........................................................................................ 15 2.6. Test Equipment List ................................................................................ 16 3. SAR Measurement Procedures .......................................................................... 19 3.1. Power Reference ................................................................................... 19 3.2. Area scan & Zoom scan .......................................................................... 19 3.3. Description of interpolation/extrapolation scheme .............................. 21 3.4. Volumetric Scan ..................................................................................... 21 3.5. Power Drift ............................................................................................ 21 4. System Verification Procedure .......................................................................... 22 4.1. Tissue Verification ................................................................................. 22 4.1.1. Tissue Dielectric Parameter Check Results ...................................... 23 4.2. System Verification Procedure .............................................................. 24 4.2.1. System Verification Results .............................................................. 25 5. SAR Measurement variability and uncertainty .........…

Text truncated - open the document above for the full version.

Page 113 of 230 Report No.: S24080806806001 MEASUREMENT 8 Date of measurement: 16/8/2024 A. Experimental conditions. Area Scan dx=15mm dy=15mm, h= 5.00 mm ZoomScan 5x5x7,dx=8mm dy=8mm dz=5mm Phantom Validation plane Device Position Body Band Band4_WCDMA1700 Channels Middle Signal WCDMA (Crest factor: 1.0) ConvF 2.45 B. SAR Measurement Results Frequency (MHz) 1732.600000 Relative permittivity (real part) 40.084381 Relative permittivity (imaginary part) 13.964505 Conductivity (S/m) 1.343696 Variation (%) -0.680000 SURFACE SAR VOLUME SAR Maximum location: X=2.00, Y=-55.00 SAR Peak: 0.41 W/kg SAR 10g (W/Kg) 0.134838 SAR 1g (W/Kg) 0.253067 Page 114 of 230 Report No.: S24080806806001 Z (mm) 0.00 4.00 9.00 14.00 19.00 24.00 29.00 SAR (W/Kg) 0.4114 0.2678 0.1529 0.0878 0.0499 0.0284 0.0156 3D screen shot Hot spot position Page 115 of 230 Report No.: S24080806806001 MEASUREMENT 9 Date of measurement: 30/8/2024 A. Experimental conditions. Area Scan dx=15mm dy=15mm, h= 5.00 mm ZoomScan 5x5x7,dx=8mm dy=8mm dz=5mm Phantom Left head Device Position Cheek Band Band5_WCDMA850 Channels Middle Signal WCDMA (Crest factor: 1.0) ConvF 2.32 B. SAR Measurement Results Frequency (MHz) 836.400000 Relative permittivity (real part) 42.153271 Relative permittivity (imaginary part) 19.965986 Conductivity (S/m) 0.927753 Variation (%) 0.270000 SURFACE SAR VOLUME SAR Maximum location: X=-52.00, Y=-20.00 SAR Peak: 0.05 W/kg SAR 10g (W/Kg) 0.034568 SAR 1g (W/Kg) 0.043299 Page 116 of 230 Report No.: S24080806806001 Z (mm) 0.00 4.00 9.00 14.00 19.00 24.00 29.00 SAR (W/Kg) 0.0472 0.0432 0.0383 0.0330 0.0277 0.0244 0.0194 3D screen shot Hot spot position Page 117 of 230 Report No.: S24080806806001 MEASUREMENT 10 Date of measurement: 30/8/2024 A. Experimental conditions. Area Scan dx=15mm dy=15mm, h= 5.00 mm ZoomScan 5x5x7,dx=8mm dy=8mm dz=5mm Phantom Validation plane Device Position Body Band Band5_WCDMA850 Channels Middle Signal WCDMA (Crest factor: 1.0) ConvF 2.32 B. SAR Measurement Results Frequency (MHz) 836.400000 Relative permittivity (real part) 42.153271 Relative permittivity (imaginary part) 19.965986 Conductivity (S/m) 0.927753 Variation (%) 3.580000 SURFACE SAR VOLUME SAR Maximum location: X=5.00, Y=-57.00 SAR Peak: 0.14 W/kg SAR 10g (W/Kg) 0.062075 SAR 1g (W/Kg) 0.097378 Page 118 of 230 Report No.: S24080806806001 Z (mm) 0.00 4.00 9.00 14.00 19.00 24.00 29.00 SAR (W/Kg) 0.1350 0.1012 0.0698 0.0483 0.0354 0.0263 0.0221 3D screen shot Hot spot position Page 119 of 230 Report No.: S24080806806001 MEASUREMENT 11 Date of measurement: 20/8/2024 A. Experimental conditions. Area Scan dx=10mm dy=10mm, h= 2.00 mm ZoomScan 7x7x12,dx=4mm dy=4mm dz=2mm Phantom Left head Device Position Cheek Band IEEE 802.11n U-NII Channels Low Signal IEEE802.11n (Crest factor: 1.0) ConvF 2.07 B. SAR Measurement Results Frequency (MHz) 5180.000000 Relative permittivity (real part) 37.020890 Relative permittivity (imaginary part) 15.949439 Conductivity (S/m) 4.589894 Variation (%) -2.370000 SURFACE SAR VOLUME SAR Maximum location: X=-5.00, Y=24.00 SAR Peak: 0.97 W/kg SAR 10g (W/Kg) 0.124985 SAR 1g (W/Kg) 0.346339 Page 120 of 230 Report No.: S24080806806001 Z (m m) 0.00 2.00 4.00 6.00 8.00 10.0 0 12.0 0 14.0 0 16.0 0 18.0 0 20.0 0 22.0 0 SA R (W/ Kg) 0.62 61 0.36 29 0.13 48 0.09 43 0.04 35 0.03 34 0.02 16 0.02 12 0.02 14 0.01 59 0.02 39 0.02 11 3D screen shot Hot spot position Page 121 of 230 Report No.: S24080806806001 MEASUREMENT 14 Date of measurement: 21/8/2024 A. Experimental conditions. Area Scan dx=10mm dy=10mm, h= 2.00 mm ZoomScan 7x7x12,dx=4mm dy=4mm dz=2mm Phantom Left head Device Position Cheek Band IEEE 802.11a U-NII Channels Low Signal IEEE802.11a (Crest factor: 1.0) ConvF 2.04 B. SAR Measurement Results Frequency (MHz) 5745.000000 Relative permittivity (real part) 35.711995 Relative permittivity (imaginary part) 16.080480 Conductivity (S/m) 5.132353 Variation (%) -4.300000 SURFACE SAR VOLUME SAR Maximum location: X=-5.00, Y=24.00 SAR Peak: 0.41 W/kg SAR 10g (W/Kg) 0.062428 SAR 1g (W/Kg) 0.142202 Page 122 of 230 Report No.: S24080806806001 Z (m m) 0.00 2.00 4.00 6.00 8.00 10.0 0 12.0 0 14.0 0 16.0 0 18.0 0 20.0 0 22.0 0 SA R (W/ Kg) 0.25 34 0.15 04 0.07 15 0.04 94 0.03 16 0.01 97 0.02 04 0.01 39 0.02 65 0.02 29 0.01 29 0.01 20 3D screen shot Hot spot position Page 123 of 230 Report No.: S24080806806001 MEASUREMENT 15 Date of measurement: 20/8/2024 A. Experimental conditions. Area Scan dx=10mm dy=10mm, h= 2.00 mm ZoomScan 7x7x12,dx=4mm dy=4mm dz=2mm Phantom Validation plane Device Position Body Band IEEE 802.11n U-NII Channels Low Signal IEEE802.11n (Crest factor: 1.0) ConvF 2.07 B. SAR Measurement Results Frequency (MHz) 5180.000000 Relative permittivity (real part) 37.020890 Relative permittivity (imaginary part) 15.949439 Conductivity (S/m) 4.589894 Variation (%) -4.740000 SURFACE SAR VOLUME SAR Maximum location: X=-25.00, Y=50.00 SAR Peak: 0.23 W/kg SAR 10g (W/Kg) 0.038112 SAR 1g (W/Kg) 0.076475 Page 124 of 230 Report No.: S24080806806001 Z (m m) 0.00 2.00 4.00 6.00 8.00 10.0 0 12.0 0 14.0 0 16.0 0 18.0 0 20.0 0 22.0 0 SA R (W/ Kg) 0.20 58 0.12 29 0.06 44 0.04 26 0.01 87 0.01 89 0.01 67 0.01 47 0.01 81 0.01 30 0.01 30 0.01 54 3D screen shot Hot spot position Page 125 of 230 Report No.: S24080806806001 MEASUREMENT 16 Date of measurement: 21/8/2024 A. Experimental conditions. Area Scan dx=10mm dy=10mm, h= 2.00 mm ZoomScan 7x7x12,dx=4mm dy=4mm dz=2mm Phantom Validation plane Device Position Body Band IEEE 802.11n U-NII Channels Low Signal IEEE802.11n (Crest factor: 1.0) ConvF 2.04 B. SAR Measurement Results Frequency (MHz) 5745.000000 Relative permittivity (real part) 35.711995 Relative permittivity (imaginary part) 16.080480 Conductivity (S/m) 5.132353 Variation (%) -0.270000 SURFACE SAR VOLUME SAR Maximum location: X=-19.00, Y=49.00 SAR Peak: 0.09 W/kg SAR 10g (W/Kg) 0.031671 SAR 1g (W/Kg) 0.041226 Page 126 of 230 Report No.: S24080806806001 Z (m m) 0.00 2.00 4.00 6.00 8.00 10.0 0 12.0 0 14.0 0 16.0 0 18.0 0 20.0 0 22.0 0 SA R (W…

Text truncated - open the document above for the full version.

Page 177 of 230 Report No.: S24080806806001 Page 178 of 230 Report No.: S24080806806001 Page 179 of 230 Report No.: S24080806806001 Page 180 of 230 Report No.: S24080806806001 Page 181 of 230 Report No.: S24080806806001 Page 182 of 230 Report No.: S24080806806001 Page 183 of 230 Report No.: S24080806806001 Page 184 of 230 Report No.: S24080806806001 Page 185 of 230 Report No.: S24080806806001 Page 186 of 230 Report No.: S24080806806001 Page 187 of 230 Report No.: S24080806806001 Page 188 of 230 Report No.: S24080806806001 Page 189 of 230 Report No.: S24080806806001 Page 190 of 230 Report No.: S24080806806001 Page 191 of 230 Report No.: S24080806806001 Page 192 of 230 Report No.: S24080806806001 Page 193 of 230 Report No.: S24080806806001 Page 194 of 230 Report No.: S24080806806001 Page 195 of 230 Report No.: S24080806806001 Page 196 of 230 Report No.: S24080806806001 Page 197 of 230 Report No.: S24080806806001 Page 198 of 230 Report No.: S24080806806001 Page 199 of 230 Report No.: S24080806806001

Page 200 of 230 Report No.: S24080806806001 Page 201 of 230 Report No.: S24080806806001 Page 202 of 230 Report No.: S24080806806001 Page 203 of 230 Report No.: S24080806806001 Page 204 of 230 Report No.: S24080806806001 Page 205 of 230 Report No.: S24080806806001 Page 206 of 230 Report No.: S24080806806001 Page 207 of 230 Report No.: S24080806806001 Page 208 of 230 Report No.: S24080806806001 Page 209 of 230 Report No.: S24080806806001 Page 210 of 230 Report No.: S24080806806001 Page 211 of 230 Report No.: S24080806806001 Page 212 of 230 Report No.: S24080806806001 Page 213 of 230 Report No.: S24080806806001 Page 214 of 230 Report No.: S24080806806001 Page 215 of 230 Report No.: S24080806806001 Page 216 of 230 Report No.: S24080806806001 Page 217 of 230 Report No.: S24080806806001 Page 218 of 230 Report No.: S24080806806001 Page 219 of 230 Report No.: S24080806806001 Page 220 of 230 Report No.: S24080806806001 Page 221 of 230 Report No.: S24080806806001 Page 222 of 230 Report No.: S24080806806001

Page 223 of 230 Report No.: S24080806806001 Page 224 of 230 Report No.: S24080806806001 Page 225 of 230 Report No.: S24080806806001 Page 226 of 230 Report No.: S24080806806001 Page 227 of 230 Report No.: S24080806806001 Page 228 of 230 Report No.: S24080806806001 Page 229 of 230 Report No.: S24080806806001 Page 230 of 230 Report No.: S24080806806001 _______________________________________END _____________________________________

Report No.: S24080806805005 1 / 21 01 Conducted output power Band Channel Frequency (MHz) Power (dBm) Verdict HSDPA Band2 Subtest1 9262 1852.4 21.98 PASS HSDPA Band2 Subtest2 9262 1852.4 21.50 PASS HSDPA Band2 Subtest3 9262 1852.4 20.23 PASS HSDPA Band2 Subtest4 9262 1852.4 20.37 PASS HSDPA Band2 Subtest1 9400 1880 21.82 PASS HSDPA Band2 Subtest2 9400 1880 21.15 PASS HSDPA Band2 Subtest3 9400 1880 20.28 PASS HSDPA Band2 Subtest4 9400 1880 20.09 PASS HSDPA Band2 Subtest1 9538 1907.6 21.94 PASS HSDPA Band2 Subtest2 9538 1907.6 21.37 PASS HSDPA Band2 Subtest3 9538 1907.6 20.55 PASS HSDPA Band2 Subtest4 9538 1907.6 20.51 PASS HSUPA Band2 Subtest1 9262 1852.4 21.40 PASS HSUPA Band2 Subtest2 9262 1852.4 21.92 PASS HSUPA Band2 Subtest3 9262 1852.4 19.97 PASS HSUPA Band2 Subtest4 9262 1852.4 21.92 PASS HSUPA Band2 Subtest5 9262 1852.4 20.35 PASS HSUPA Band2 Subtest1 9400 1880 21.54 PASS HSUPA Band2 Subtest2 9400 1880 21.58 PASS HSUPA Band2 Subtest3 9400 1880 20.47 PASS HSUPA Band2 Subtest4 9400 1880 21.74 PASS HSUPA Band2 Subtest5 9400 1880 21.13 PASS HSUPA Band2 Subtest1 9538 1907.6 21.70 PASS HSUPA Band2 Subtest2 9538 1907.6 21.76 PASS HSUPA Band2 Subtest3 9538 1907.6 20.55 PASS HSUPA Band2 Subtest4 9538 1907.6 21.89 PASS HSUPA Band2 Subtest5 9538 1907.6 21.11 PASS WCDMA Band2 9262 1852.4 22.89 PASS WCDMA Band2 9400 1880 22.67 PASS WCDMA Band2 9538 1907.6 22.87 PASS HSDPA Band4 Subtest1 1312 1712.4 22.04 PASS HSDPA Band4 Subtest2 1312 1712.4 21.59 PASS HSDPA Band4 Subtest3 1312 1712.4 20.80 PASS HSDPA Band4 Subtest4 1312 1712.4 20.64 PASS HSDPA Band4 Subtest1 1413 1732.6 21.97 PASS HSDPA Band4 Subtest2 1413 1732.6 21.34 PASS HSDPA Band4 Subtest3 1413 1732.6 20.46 PASS HSDPA Band4 Subtest4 1413 1732.6 20.57 PASS HSDPA Band4 Subtest1 1513 1752.6 22.01 PASS HSDPA Band4 Subtest2 1513 1752.6 21.51 PASS HSDPA Band4 Subtest3 1513 1752.6 20.28 PASS Report No.: S24080806805005 2 / 21 HSDPA Band4 Subtest4 1513 1752.6 20.59 PASS HSUPA Band4 Subtest1 1312 1712.4 21.65 PASS HSUPA Band4 Subtest2 1312 1712.4 22.04 PASS HSUPA Band4 Subtest3 1312 1712.4 20.29 PASS HSUPA Band4 Subtest4 1312 1712.4 22.04 PASS HSUPA Band4 Subtest5 1312 1712.4 20.63 PASS HSUPA Band4 Subtest1 1413 1732.6 21.79 PASS HSUPA Band4 Subtest2 1413 1732.6 21.94 PASS HSUPA Band4 Subtest3 1413 1732.6 20.68 PASS HSUPA Band4 Subtest4 1413 1732.6 21.97 PASS HSUPA Band4 Subtest5 1413 1732.6 21.36 PASS HSUPA Band4 Subtest1 1513 1752.6 21.83 PASS HSUPA Band4 Subtest2 1513 1752.6 21.91 PASS HSUPA Band4 Subtest3 1513 1752.6 20.82 PASS HSUPA Band4 Subtest4 1513 1752.6 22.03 PASS HSUPA Band4 Subtest5 1513 1752.6 21.33 PASS WCDMA Band4 1312 1712.4 22.97 PASS WCDMA Band4 1413 1732.6 22.92 PASS WCDMA Band4 1513 1752.6 22.99 PASS HSDPA Band5 Subtest1 4132 826.4 21.97 PASS HSDPA Band5 Subtest2 4132 826.4 21.51 PASS HSDPA Band5 Subtest3 4132 826.4 20.65 PASS HSDPA Band5 Subtest4 4132 826.4 20.48 PASS HSDPA Band5 Subtest1 4182 836.4 21.68 PASS HSDPA Band5 Subtest2 4182 836.4 21.11 PASS HSDPA Band5 Subtest3 4182 836.4 20.18 PASS HSDPA Band5 Subtest4 4182 836.4 20.27 PASS HSDPA Band5 Subtest1 4233 846.6 21.87 PASS HSDPA Band5 Subtest2 4233 846.6 21.39 PASS HSDPA Band5 Subtest3 4233 846.6 20.25 PASS HSDPA Band5 Subtest4 4233 846.6 20.32 PASS HSUPA Band5 Subtest1 4132 826.4 21.55 PASS HSUPA Band5 Subtest2 4132 826.4 21.80 PASS HSUPA Band5 Subtest3 4132 826.4 20.25 PASS HSUPA Band5 Subtest4 4132 826.4 21.97 PASS HSUPA Band5 Subtest5 4132 826.4 20.74 PASS HSUPA Band5 Subtest1 4182 836.4 21.60 PASS HSUPA Band5 Subtest2 4182 836.4 21.62 PASS HSUPA Band5 Subtest3 4182 836.4 20.41 PASS HSUPA Band5 Subtest4 4182 836.4 21.70 PASS HSUPA Band5 Subtest5 4182 836.4 20.80 PASS HSUPA Band5 Subtest1 4233 846.6 21.73 PASS HSUPA Band5 Subtest2 4233 846.6 21.79 PASS HSUPA Band5 Subtest3 4233 846.6 20.58 PASS Report No.: S24080806805005 3 / 21 HSUPA Band5 Subtest4 4233 846.6 21.89 PASS HSUPA Band5 Subtest5 4233 846.6 21.04 PASS WCDMA Band5 4132 826.4 22.93 PASS WCDMA Band5 4182 836.4 22.67 PASS WCDMA Band5 4233 846.6 22.84 PASS 03 Peak-to-Average Ratio Band Channel Frequency (MHz) Result (dB) high Limit (dB) Verdict WCDMA Band2 9262 1852.4 2.96 13 PASS WCDMA Band2 9400 1880 3.10 13 PASS WCDMA Band2 9538 1907.6 3.15 13 PASS WCDMA Band4 1312 1712.4 3.19 13 PASS WCDMA Band4 1413 1732.6 3.39 13 PASS WCDMA Band4 1513 1752.6 3.37 13 PASS WCDMA Band5 4132 826.4 3.26 13 PASS WCDMA Band5 4182 836.4 3.23 13 PASS WCDMA Band5 4233 846.6 3.22 13 PASS WCDMA Band2 Channel=9262 WCDMA Band2 Channel=9538 Report No.: S24080806805005 4 / 21 WCDMA Band2 Channel=9400 WCDMA Band4 Channel=1413 Report No.: S24080806805005 5 / 21 WCDMA Band4 Channel=1312 WCDMA Band4 Channel=1513 Report No.: S24080806805005 6 / 21 WCDMA Band5 Channel=4132 WCDMA Band5 Channel=4182 Report No.: S24080806805005 7 / 21 WCDMA Band5 Channel=4233 04 Occupied bandwidth Report No.: S24080806805005 8 / 21 Band Channel Frequency (MHz) 99% OBW (kHz) -26dB EBW (kHz) Verdict WCDMA Band2 9262 1852.4 4169.686 4669.740 PASS WCDMA Band2 9400 1880 4161.931 4672.049 PASS WCDMA Band2 9538 1907.6 4152.395 4656.787 PASS WCDMA Band4 1312 1712.4 4164.588 4714.266 PASS WCDMA Band4 1413 1732.6 4172.860 4659.990 PASS WCDMA Band4 1513 1752.6 4163.817 4686.486 PASS WCDMA Band5 4132 826.4 4166.362 4694.222 PASS WCDMA Band5 4182 836.4 4149.693 4678.710 PASS WCDMA Band5 4233 846.6 4161.374 4676.692 PASS WCDMA Band2 Channel=9262 WCDMA Band2 Channel=9400 Report No.: S24080806805005 9 / 21 WCDMA Band2 Channel=9538 WCDMA Band4 Channel=1312 Report No.: S24080806805005 10 / 21 WCDMA Band4 Channel=1413 WCDMA Band4 Channel=1513 Report No.: S24080806805005 11 / 21 WCDMA Band5 Channel=4132 WCDMA Band5 Channel=4233 Report No.: S24080806805005 12 / 21 WCDMA Band5 Channel=4182 05 Band edge Report No.: S24080806805005 13 / 21 Band Channel Frequency (MHz) Spur Freq (MHz) Spur Level (dBm) Limit (dBm) Verdict WCDMA Band2 9262 1852.4 1850.00 -23.87 -13 PASS WCDMA Band2 9538 1907.6 1910.01 -24.35 -13 PASS WCDMA Band4 1312 1712.4 1709.88 -22.84 -13 PASS WCDMA Band4 1513 1752.6…

Text truncated - open the document above for the full version.

Report No.: S24080806805005 1 / 41 01 Conducted output power Band Channel Frequency (MHz) Power (dBm) Verdict EGPRS1900 1 Slot 512 1850.2 26.46 PASS EGPRS1900 1 Slot 661 1880 26.69 PASS EGPRS1900 1 Slot 810 1909.8 27.12 PASS EGPRS1900 2 Slot 512 1850.2 25.56 PASS EGPRS1900 2 Slot 661 1880 25.43 PASS EGPRS1900 2 Slot 810 1909.8 25.91 PASS EGPRS1900 3 Slot 512 1850.2 22.90 PASS EGPRS1900 3 Slot 661 1880 23.38 PASS EGPRS1900 3 Slot 810 1909.8 23.76 PASS EGPRS1900 4 Slot 512 1850.2 21.85 PASS EGPRS1900 4 Slot 661 1880 22.03 PASS EGPRS1900 4 Slot 810 1909.8 21.57 PASS EGPRS850 1 Slot 128 824.2 27.06 PASS EGPRS850 1 Slot 189 836.4 27.04 PASS EGPRS850 1 Slot 251 848.8 27.08 PASS EGPRS850 2 Slot 128 824.2 25.89 PASS EGPRS850 2 Slot 189 836.4 26.22 PASS EGPRS850 2 Slot 251 848.8 25.62 PASS EGPRS850 3 Slot 128 824.2 23.49 PASS EGPRS850 3 Slot 189 836.4 23.88 PASS EGPRS850 3 Slot 251 848.8 24.19 PASS EGPRS850 4 Slot 128 824.2 22.11 PASS EGPRS850 4 Slot 189 836.4 22.22 PASS EGPRS850 4 Slot 251 848.8 21.80 PASS GPRS1900 1 Slot 512 1850.2 30.39 PASS GPRS1900 1 Slot 661 1880 30.13 PASS GPRS1900 1 Slot 810 1909.8 29.77 PASS GPRS1900 2 Slot 512 1850.2 29.65 PASS GPRS1900 2 Slot 661 1880 29.43 PASS GPRS1900 2 Slot 810 1909.8 29.05 PASS GPRS1900 3 Slot 512 1850.2 27.86 PASS GPRS1900 3 Slot 661 1880 27.68 PASS GPRS1900 3 Slot 810 1909.8 27.39 PASS GPRS1900 4 Slot 512 1850.2 26.68 PASS GPRS1900 4 Slot 661 1880 26.56 PASS GPRS1900 4 Slot 810 1909.8 26.33 PASS GPRS850 1 Slot 128 824.2 33.16 PASS GPRS850 1 Slot 189 836.4 33.05 PASS GPRS850 1 Slot 251 848.8 32.91 PASS GPRS850 2 Slot 128 824.2 32.40 PASS GPRS850 2 Slot 189 836.4 32.29 PASS Report No.: S24080806805005 2 / 41 GPRS850 2 Slot 251 848.8 32.15 PASS GPRS850 3 Slot 128 824.2 30.61 PASS GPRS850 3 Slot 189 836.4 30.50 PASS GPRS850 3 Slot 251 848.8 30.36 PASS GPRS850 4 Slot 128 824.2 29.43 PASS GPRS850 4 Slot 189 836.4 29.37 PASS GPRS850 4 Slot 251 848.8 29.22 PASS GSM1900 512 1850.2 30.44 PASS GSM1900 661 1880 30.16 PASS GSM1900 810 1909.8 29.79 PASS GSM850 128 824.2 33.22 PASS GSM850 189 836.4 33.12 PASS GSM850 251 848.8 32.97 PASS 15 Peak-to-Average Ratio Band Channel Frequency (MHz) Result (dB) high Limit (dB) Verdict EGPRS1900 512 1850.2 6.20 13 PASS EGPRS1900 661 1880 6.06 13 PASS EGPRS1900 810 1909.8 5.43 13 PASS EGPRS850 128 824.2 8.35 13 PASS EGPRS850 189 836.4 8.02 13 PASS EGPRS850 251 848.8 8…
