2AOWK-5010Mobile Phone

Shenzhen Gotron Electronic CO.,LTD. Family models difference declaration Mobile Phone Model: GQ5010 Family Model: Armor Mini 20T Pro, Armor Mini 20 Pro, Armor Mini 20 Ultra, Armor Mini 20T Ultra Difference declaration: All models are the same circuit and RF module, except the Model Name. Regards, Signature Yongbin Tang / Manager Date/City: 2024-09-11 / Shenzhen Phone: 0755-8389 5989 E-mail: [email protected]

(Shenzhen Gotron Electronic CO.,LTD.) (2024-09-11) Eurofins Electrical and Electronic Testing NA, Inc. 914 West Patapsco Avenue Baltimore, MD 21230 RE: Attestation Statements Part 2.911(d)(5)(i) request for (FCC ID: 2AOWK-5010) [Shenzhen Gotron Electronic CO.,LTD.] (“the applicant”) certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. Sincerely, Yongbin Tang (Shenzhen Gotron Electronic CO.,LTD.) (2024-09-11) Eurofins Electrical and Electronic Testing NA, Inc. 914 West Patapsco Avenue Baltimore, MD 21230 RE: Attestation Statements Part 2.911(d)(5)(ii) request for (FCC ID: 2AOWK-5010) [Shenzhen Gotron Electronic CO.,LTD.] (“the applicant”) certifies that, as of the date of the filing of the application, the applicant is not identified on the Covered List as an entity producing “covered” equipment. Sincerely, Yongbin Tang

THREE STONES MEDIA LLC U.S. Agent Letter of Attestation To: Federal Communications Commission 7435 Oakland Mills Road, Columbia, MD 21046, USA Date: 9/11/2024 Ref: Attestation Statement – Part2.911(d)(7) filing FCC ID: 2AOWK-5010 Shenzhen Gotron Electronic CO.,LTD. (“the applicant”) certifies that, as of the date of the filing of the application, THREE STONES MEDIA LLC(“the agent”) is our designated U.S. agent for service of process for the above reference FCC ID. The applicant accepts to maintain an agent for service of process in the United States for no less than one year after either the grantee has permanently terminated all marketing and importation of the applicable equipment within the U.S., or the conclusion of any Commission-related administrative or judicial proceeding involving the equipment, whichever is later. The applicant further acknowledges it is our responsibility to inform the FCC whenever the agent information changes. TH REE STONES MEDIA LLC ("the agent) understand it is the agent's obligation to accept service of process in the United States for matters related to the applicable equipment, and at the physical U.S. address and email address. Designated U.S. Agent Company Name: THREE STONES MEDIA LLC FRN: 0033401761 GC: 2A99E Address: 1200 Broadway St. APT 329, Los Angeles, CA90015 Signature: Contact Person: Sijie Zhang Tel: +1 267 909 3692 Email: [email protected] Applicant Company Name: Shenzhen Gotron Electronic CO.,LTD. Address: 7B01, Building A, Block 1, Anhongji Tianyao Plaza, Longhua District, Shenzhen City, Guangdong Province China Signature: Contact Person: Yongbin Tang FRN: 0027174960 Tel: 0755-8389 5989 Email: [email protected]

Shenzhen Gotron Electronic CO.,LTD. Agent Authorization Letter (2024-09-10) Eurofins Electrical and Electronic Testing NA, Inc. 914 West Patapsco Avenue Baltimore, MD 21230 RE: LETTER OF AGENT AUTHORIZATION To Whom It May Concern: We, the undersigned, hereby authorize Shenzhen NTEK Testing Technology Co., Ltd. 1/F, Building E, Fenda Science Park Sanwei, Xixiang, Bao'an District, Shenzhen, Guangdong, China Alex.li [email protected] to act on our behalf in all matters relating to application for equipment authorization, including the signing of all documents relating to these matters. We also hereby certify that no party to the application authorized hereunder is subject to the denial of benefits, including FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C.853(a). This agreement expires one year from the current date. Sincerely, Yongbin Tang / Manager Date/City: 2024-09-10/Shenzhen Phone: 0755-8389 5989 E-mail: [email protected]

Shenzhen Gotron Electronic CO.,LTD. Long Term Confidentiality Request Letter (2024-09-11) Eurofins Electrical and Electronic Testing NA, Inc. 914 West Patapsco Avenue Baltimore, MD 21230 RE: CONFIDENTIALITY REQUEST FOR Product: Mobile Phone Model No.: GQ5010, Armor Mini 20T Pro, Armor Mini 20 Pro, Armor Mini 20 Ultra, Armor Mini 20T Ultra To Whom It May Concern: This letter serves as an official request for confidentiality under sections 0.457 and 0.459 of CFR 47. We have requested that the  Schematic Diagram  Block Diagram  Part List / BOM List / PCB Layout  Operational Description  Tune-up Procedure  Software Security Requirements for UNII devices Required to be submitted with this application be permanently withheld from public review. Above mentioned document contains detailed system and equipment description are considered as proprietary information in operation of the equipment. The public disclosure of above documents might be harmful to our company and would give competitor an unfair advantage in the market. It is our understanding that all measurement test reports, FCC ID label format and correspondent during certification review process cannot be granted as confidential documents and those information will be available for public review once the grant of equipment authorization is issued. Please contact me if there is any information you may need. Sincerely, Yongbin Tang / Manager Date/City: 2024-09-11/Shenzhen Phone: 0755-8389 5989 E-mail: [email protected]

Shenzhen Gotron Electronic CO.,LTD. Short Term Confidentiality Request Letter (2024-09-11) Eurofins Electrical and Electronic Testing NA, Inc. 914 West Patapsco Avenue Baltimore, MD 21230 RE: Short Term Confidentiality Request For Product: Mobile Phone Model No.: GQ5010, Armor Mini 20T Pro, Armor Mini 20 Pro, Armor Mini 20 Ultra, Armor Mini 20T Ultra To Whom It May Concern: In accordance with sections 0.457 and 0.459 of CFR 47, < Shenzhen Gotron Electronic CO.,LTD. >. requests short-term Confidentiality of following sections of this application for a period of 180 days after grant is issued. Test setup photos External photos Internal photos User’s manual These documents contain detailed system and equipment descriptions and related information about the product, which < Shenzhen Gotron Electronic CO.,LTD. > considers to be proprietary, confidential, and a custom design and otherwise, would not release to the general public. Since this design is a basis from which future technological products will evolve, < Shenzhen Gotron Electronic CO.,LTD. > feels that this information would be of benefit to its competitors, and that the disclosure of the information in these documents would give our competitors an unfair advantage in the market. Please contact me if there is any information you may need. Sincerely, Yongbin Tang / Manager Date/City: 2024-09-11/Shenzhen Phone: 0755-8389 5989 E-mail: [email protected]

Mobile Phone Model Name: GQ5010 FCC ID: 2AOWK-5010 This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

Page 1 of 222 Report No.: S24070203406001 FCC SAR EVALUATION REPORT In accordance with the requirements of FCC 47 CFR Part 2(2.1093) and IEEE Std 1528-2013 Product Name： Mobile Phone Brand Name： ulefone Model Name： GQ5010 Family Model： Armor Mini 20T Pro, Armor Mini 20 Pro, Armor Mini 20 Ultra, Armor Mini 20T Ultra Report No.： S24070203406001 FCC ID： 2AOWK-5010 Prepared for Shenzhen Gotron Electronic CO.,LTD. 7B01, Building A, Block 1, Anhongji Tianyao Plaza, Longhua District, Shenzhen City, Guangdong Province China Prepared by Shenzhen NTEK Testing Technology Co., Ltd. 1/F, Building E, Fenda Science Park, Sanwei Community, Xixiang Street Bao’an District, Shenzhen 518126 P.R. China Tel. 400-800-6106, 0755-2320 0050, 0755-2320 0090 Website: http://www.ntek.org.cn Page 2 of 222 Report No.: S24070203406001 TEST RESULT CERTIFICATION Applicant’s name ................. : Shenzhen Gotron Electronic CO.,LTD. Address .................................. : 7B01, Building A, Block 1, Anhongji Tianyao Plaza, Longhua District, Shenzhen City, Guangdong Province China Manufacturer's Name .......... : Shenzhen Gotron Electronic CO.,LTD. Address .................................. : 7B01, Building A, Block 1, Anhongji Tianyao Plaza, Longhua District, Shenzhen City, Guangdong Province China Product description Product name ........................ : Mobile Phone Brand Name ......................... : ulefone Model and/or type reference .............................. : GQ5010 Family Model ......................... : Armor Mini 20T Pro, Armor Mini 20 Pro, Armor Mini 20 Ultra, Armor Mini 20T Ultra Standards ............................. : FCC 47 CFR Part 2(2.1093) IEEE Std 1528-2013 Published RF exposure KDB procedures This device described above has been tested by Shenzhen NTEK. In accordance with the measurement methods and procedures specified in IEEE Std 1528-2013 and KDB 865664 D01. Testing has shown that this device is capable of compliance with localized specific absorption rate (SAR) specified in FCC 47 CFR Part 2(2.1093). The test results in this report apply only to the tested sample of the stated device/equipment. Other similar device/equipment will not necessarily produce the same results due to production tolerance and measurement uncertainties. This report shall not be reproduced except in full, without the written approval of Shenzhen NTEK, this document may be altered or revised by Shenzhen NTEK, personal only, and shall be noted in the revision of the document. Test Sample Number ............................. S240702034006 Date of Test Date (s) of performance of tests .............. : Jul. 07, 2024 ~ Jul. 14, 2024 Date of Issue ........................................... : Aug. 30, 2024 Test Result ............................................... : Pass Prepared By : Reviewed By : Approved By : Owen Xiao (Project Engineer) Aaron Cheng (Supervisor) Alex Li (Manager) Page 3 of 222 Report No.: S24070203406001 ※ ※ Revision History ※ ※ REV. DESCRIPTION ISSUED DATE REMARK Rev.1.0 Initial Test Report Release Aug. 30, 2024 Owen Xiao Page 4 of 222 Report No.: S24070203406001 TABLE OF CONTENTS 1. General Information ............................................................................................ 6 1.1. RF exposure limits .................................................................................... 6 1.2. Statement of Compliance ........................................................................ 7 1.3. EUT Description ....................................................................................... 7 1.4. Test specification(s) .................................................................................. 8 1.5. Ambient Condition ................................................................................... 9 2. SAR Measurement System ................................................................................. 10 2.1. SATIMO SAR Measurement Set-up Diagram .......................................... 10 2.2. Robot ..................................................................................................... 11 2.3. E-Field Probe .......................................................................................... 12 2.3.1. E-Field Probe Calibration ................................................................. 12 2.4. SAM phantoms ...................................................................................... 13 2.4.1. Technical Data .................................................................................. 14 2.5. Device Holder ........................................................................................ 15 2.6. Test Equipment List ................................................................................ 16 3. SAR Measurement Procedures .......................................................................... 19 3.1. Power Reference ................................................................................... 19 3.2. Area scan & Zoom scan .......................................................................... 19 3.3. Description of interpolation/extrapolation scheme .............................. 21 3.4. Volumetric Scan ..................................................................................... 21 3.5. Power Drift ............................................................................................ 21 4. System Verification Procedure .......................................................................... 22 4.1. Tissue Verification ................................................................................. 22 4.1.1. Tissue Dielectric Parameter Check Results ...................................... 23 4.2. System Verification Procedure .............................................................. 24 4.2.1. System Verification Results .............................................................. 25 5. SAR Measurement variability and uncertainty .........................................…

Text truncated - open the document above for the full version.

Page 100 of 222 Report No.: S24070203406001 MEASUREMENT 4 Date of measurement: 8/7/2024 A. Experimental conditions. Area Scan dx=15mm dy=15mm, h= 5.00 mm ZoomScan 5x5x7,dx=8mm dy=8mm dz=5mm Phantom Validation plane Device Position Body Band GSM1900 Channels Middle Signal TDMA (Crest factor: 8.0) ConvF 2.63 B. SAR Measurement Results Frequency (MHz) 1880.000000 Relative permittivity (real part) 38.948967 Relative permittivity (imaginary part) 13.792142 Conductivity (S/m) 1.440513 Variation (%) 0.190000 SURFACE SAR VOLUME SAR Maximum location: X=5.00, Y=-13.00 SAR Peak: 0.80 W/kg SAR 10g (W/Kg) 0.306058 SAR 1g (W/Kg) 0.534937 Page 101 of 222 Report No.: S24070203406001 Z (mm) 0.00 4.00 9.00 14.00 19.00 24.00 29.00 SAR (W/Kg) 0.9602 0.5461 0.2677 0.2218 0.1346 0.0957 0.0678 3D screen shot Hot spot position Page 102 of 222 Report No.: S24070203406001 MEASUREMENT 5 Date of measurement: 8/7/2024 A. Experimental conditions. Area Scan dx=15mm dy=15mm, h= 5.00 mm ZoomScan 5x5x7,dx=8mm dy=8mm dz=5mm Phantom Left head Device Position Cheek Band Band2_WCDMA1900 Channels Middle Signal WCDMA (Crest factor: 1.0) ConvF 2.63 B. SAR Measurement Results Frequency (MHz) 1880.000000 Relative permittivity (real part) 38.948967 Relative permittivity (imaginary part) 13.792142 Conductivity (S/m) 1.440513 Variation (%) 1.820000 SURFACE SAR VOLUME SAR Maximum location: X=-53.00, Y=-50.00 SAR Peak: 0.52 W/kg SAR 10g (W/Kg) 0.214080 SAR 1g (W/Kg) 0.360771 Page 103 of 222 Report No.: S24070203406001 Z (mm) 0.00 4.00 9.00 14.00 19.00 24.00 29.00 SAR (W/Kg) 0.5239 0.3735 0.2497 0.1709 0.1221 0.0830 0.0583 3D screen shot Hot spot position Page 104 of 222 Report No.: S24070203406001 MEASUREMENT 6 Date of measurement: 8/7/2024 A. Experimental conditions. Area Scan dx=15mm dy=15mm, h= 5.00 mm ZoomScan 5x5x7,dx=8mm dy=8mm dz=5mm Phantom Validation plane Device Position Body Band Band2_WCDMA1900 Channels Middle Signal WCDMA (Crest factor: 1.0) ConvF 2.63 B. SAR Measurement Results Frequency (MHz) 1880.000000 Relative permittivity (real part) 38.948967 Relative permittivity (imaginary part) 13.792142 Conductivity (S/m) 1.440513 Variation (%) -1.580000 SURFACE SAR VOLUME SAR Maximum location: X=-25.00, Y=-12.00 SAR Peak: 0.77 W/kg SAR 10g (W/Kg) 0.293995 SAR 1g (W/Kg) 0.511824 Page 105 of 222 Report No.: S24070203406001 Z (mm) 0.00 4.00 9.00 14.00 19.00 24.00 29.00 SAR (W/Kg) 0.6898 0.5079 0.3418 0.2289 0.1508 0.1003 0.0659 3D screen shot Hot spot position Page 106 of 222 Report No.: S24070203406001 MEASUREMENT 7 Date of measurement: 9/7/2024 A. Experimental conditions. Area Scan dx=15mm dy=15mm, h= 5.00 mm ZoomScan 5x5x7,dx=8mm dy=8mm dz=5mm Phantom Left head Device Position Cheek Band Band4_WCDMA1700 Channels Middle Signal WCDMA (Crest factor: 1.0) ConvF 2.45 B. SAR Measurement Results Frequency (MHz) 1732.600000 Relative permittivity (real part) 39.389881 Relative permittivity (imaginary part) 13.699847 Conductivity (S/m) 1.318230 Variation (%) -0.250000 SURFACE SAR VOLUME SAR Maximum location: X=-54.00, Y=-50.00 SAR Peak: 0.63 W/kg SAR 10g (W/Kg) 0.271555 SAR 1g (W/Kg) 0.440077 Page 107 of 222 Report No.: S24070203406001 Z (mm) 0.00 4.00 9.00 14.00 19.00 24.00 29.00 SAR (W/Kg) 0.6221 0.4616 0.3196 0.2289 0.1632 0.1198 0.0866 3D screen shot Hot spot position Page 108 of 222 Report No.: S24070203406001 MEASUREMENT 8 Date of measurement: 9/7/2024 A. Experimental conditions. Area Scan dx=15mm dy=15mm, h= 5.00 mm ZoomScan 5x5x7,dx=8mm dy=8mm dz=5mm Phantom Validation plane Device Position Body Band Band4_WCDMA1700 Channels Middle Signal WCDMA (Crest factor: 1.0) ConvF 2.45 B. SAR Measurement Results Frequency (MHz) 1732.600000 Relative permittivity (real part) 39.389881 Relative permittivity (imaginary part) 13.699847 Conductivity (S/m) 1.318230 Variation (%) -2.400000 SURFACE SAR VOLUME SAR Maximum location: X=-2.00, Y=-12.00 SAR Peak: 0.67 W/kg SAR 10g (W/Kg) 0.284556 SAR 1g (W/Kg) 0.467047 Page 109 of 222 Report No.: S24070203406001 Z (mm) 0.00 4.00 9.00 14.00 19.00 24.00 29.00 SAR (W/Kg) 0.6473 0.4853 0.3371 0.2363 0.1645 0.1098 0.0769 3D screen shot Hot spot position Page 110 of 222 Report No.: S24070203406001 MEASUREMENT 9 Date of measurement: 7/7/2024 A. Experimental conditions. Area Scan dx=15mm dy=15mm, h= 5.00 mm ZoomScan 5x5x7,dx=8mm dy=8mm dz=5mm Phantom Left head Device Position Cheek Band Band5_WCDMA850 Channels Middle Signal WCDMA (Crest factor: 1.0) ConvF 2.32 B. SAR Measurement Results Frequency (MHz) 836.400000 Relative permittivity (real part) 41.522217 Relative permittivity (imaginary part) 19.557144 Conductivity (S/m) 0.908755 Variation (%) 1.510000 SURFACE SAR VOLUME SAR Maximum location: X=-51.00, Y=-22.00 SAR Peak: 0.23 W/kg SAR 10g (W/Kg) 0.195432 SAR 1g (W/Kg) 0.222365 Page 111 of 222 Report No.: S24070203406001 Z (mm) 0.00 4.00 9.00 14.00 19.00 24.00 29.00 SAR (W/Kg) 0.2185 0.2304 0.2235 0.2053 0.1868 0.1729 0.1552 3D screen shot Hot spot position Page 112 of 222 Report No.: S24070203406001 MEASUREMENT 10 Date of measurement: 7/7/2024 A. Experimental conditions. Area Scan dx=15mm dy=15mm, h= 5.00 mm ZoomScan 5x5x7,dx=8mm dy=8mm dz=5mm Phantom Validation plane Device Position Body Band Band5_WCDMA850 Channels Middle Signal WCDMA (Crest factor: 1.0) ConvF 2.32 B. SAR Measurement Results Frequency (MHz) 836.400000 Relative permittivity (real part) 41.522217 Relative permittivity (imaginary part) 19.557144 Conductivity (S/m) 0.908755 Variation (%) -1.580000 SURFACE SAR VOLUME SAR Maximum location: X=-11.00, Y=-1.00 SAR Peak: 0.61 W/kg SAR 10g (W/Kg) 0.496065 SAR 1g (W/Kg) 0.579502 Page 113 of 222 Report No.: S24070203406001 Z (mm) 0.00 4.00 9.00 14.00 19.00 24.00 29.00 SAR (W/Kg) 0.5918 0.5949 0.5454 0.4793 0.4127 0.3605 0.3350 3D screen shot Hot spot position Page 114 of 222 Report No.: S24070203406001 MEASUREMENT 11 Date of measurement: 10/7/2024 A. Experimental conditions. Area Scan dx=10mm dy=10mm, h= 2.00 mm ZoomScan 7x7x12,dx=4mm dy=4mm dz=2mm Phantom Left head Device Position Cheek Band IEEE 802.1…

Text truncated - open the document above for the full version.

Page 166 of 222 Report No.: S24070203406001 Page 167 of 222 Report No.: S24070203406001 Page 168 of 222 Report No.: S24070203406001 Page 169 of 222 Report No.: S24070203406001 Page 170 of 222 Report No.: S24070203406001 Page 171 of 222 Report No.: S24070203406001 Page 172 of 222 Report No.: S24070203406001 Page 173 of 222 Report No.: S24070203406001 Page 174 of 222 Report No.: S24070203406001 Page 175 of 222 Report No.: S24070203406001 Page 176 of 222 Report No.: S24070203406001 Page 177 of 222 Report No.: S24070203406001 Page 178 of 222 Report No.: S24070203406001 Page 179 of 222 Report No.: S24070203406001 Page 180 of 222 Report No.: S24070203406001 Page 181 of 222 Report No.: S24070203406001 Page 182 of 222 Report No.: S24070203406001 Page 183 of 222 Report No.: S24070203406001 Page 184 of 222 Report No.: S24070203406001 Page 185 of 222 Report No.: S24070203406001 Page 186 of 222 Report No.: S24070203406001 Page 187 of 222 Report No.: S24070203406001

Page 188 of 222 Report No.: S24070203406001 Page 189 of 222 Report No.: S24070203406001 Page 190 of 222 Report No.: S24070203406001 Page 191 of 222 Report No.: S24070203406001 Page 192 of 222 Report No.: S24070203406001 Page 193 of 222 Report No.: S24070203406001 Page 194 of 222 Report No.: S24070203406001 Page 195 of 222 Report No.: S24070203406001 Page 196 of 222 Report No.: S24070203406001 Page 197 of 222 Report No.: S24070203406001 Page 198 of 222 Report No.: S24070203406001 Page 199 of 222 Report No.: S24070203406001 Page 200 of 222 Report No.: S24070203406001 Page 201 of 222 Report No.: S24070203406001 Page 202 of 222 Report No.: S24070203406001 Page 203 of 222 Report No.: S24070203406001 Page 204 of 222 Report No.: S24070203406001 Page 205 of 222 Report No.: S24070203406001 Page 206 of 222 Report No.: S24070203406001 Page 207 of 222 Report No.: S24070203406001 Page 208 of 222 Report No.: S24070203406001

Page 209 of 222 Report No.: S24070203406001 Page 210 of 222 Report No.: S24070203406001 Page 211 of 222 Report No.: S24070203406001 Page 212 of 222 Report No.: S24070203406001 Page 213 of 222 Report No.: S24070203406001 Page 214 of 222 Report No.: S24070203406001 Page 215 of 222 Report No.: S24070203406001 Page 216 of 222 Report No.: S24070203406001 Page 217 of 222 Report No.: S24070203406001 Page 218 of 222 Report No.: S24070203406001 Page 219 of 222 Report No.: S24070203406001 Page 220 of 222 Report No.: S24070203406001 Page 221 of 222 Report No.: S24070203406001 Page 222 of 222 Report No.: S24070203406001 _______________________________________END ____________________________________

OTA Test Report Shenzhen Fu Bang Wireless Technology Co., Ltd. This report shall not be reproduced except in full, without the written approval ofShenzhen FuBang Wireless Technology Co.,Ltd. Page1 OTA TEST REPORT Applicant Shenzhen General Test System Co., Ltd ProductRayZone1800 Issue DateJuly15, 2024 Shenzhen Fu Bang Wireless Technology Co., Ltd.tested the above equipment in accordance with the requirements in ANTI/IEEE Std 149-2008.The test results show that the equipment tested is capable of demonstrating compliance with theRequirements as documented in this report. Prepared by: Lunkang Yan Approved by: Zhanghong Lai Shenzhen Fu Bang Wireless Technology Co., Ltd. Room 302, lianjian Industry Part, Huarong road, Longhua District, Shenzhen, P.R. China OTA Test Report Shenzhen Fu Bang Wireless Technology Co., Ltd. This report shall not be reproduced except in full, without the written approval ofShenzhen FuBang Wireless Technology Co.,Ltd. Page2 1. Test Laboratory 1.1 Notes of the Test report This report shall not be reproduced in full or partial.Theresults documented in this report applyonly to the tested sample, under the conditions and modes of operation as described herein. Measurement Uncertainties were not taken into account and are published for informational purposesonly. This report is written to support regulatory compliance of applicable standards stated above. 1.2 Test facility GTS1800Microwave Anechoic Chamber ：testing frequency ranges from 600MHz to 6GHz . 1.3 Testing Location Company: Shenzhen Fu Bang Wireless Technology Co., Ltd Address: Room 302, lianjian Industry Part, Huarong road, Longhua District, Shenzhen, P.R. China Contact: lunkang Yan Telephone: 13760182610 E-mail: [email protected] 1.4 Laboratory Environment Temperature Min.= 19°C, Max.=25°C Relative humidity Min.=40%，Max.=72% Shield effect 0.6-7GHz >100dB Ground resistance <0.5Ω OTA Test Report Shenzhen Fu Bang Wireless Technology Co., Ltd. This report shall not be reproduced except in full, without the written approval ofShenzhen FuBang Wireless Technology Co.,Ltd. Page3 2. General Description of Equipment under Test 2.1 Applicant and Manufacturer information Applicant Name Shenzhen General Test System Co., Ltd Applicant address Building C-A7 Suite 805,2190 Liuxian Avenue,Nanshan District,Shenzhen,P.R. China Manufacturer Name Shenzhen General Test System Co., Ltd Manufacturer address Building C-A7 Suite 805,2190 Liuxian Avenue, Nanshan District, Shenzhen,P.R. China 2.2 General information EUT Description Product Name RayZone1800 Model GTS-ANT D-H HW Version RayZone1800 V1.0 SW Version MaxSign 100 Antenna Type PCB Antenna Antenna Manufacturer Shenzhen General Test System Co., Ltd Test Frequency 600MHz-5.8GHz 2.3 Applied Standards According to the specifications of the manufacturer,it must comply with the requirements of the following standards: Test Method:ANSI/IEEE Std 149-2008 3. Test Conditions 3.1 Test Configuration The method is used to measure the antenna 3D GAIN of EUT in OTA qualified anechoic chamber. Equipment Under Test(EUT) geometry centre vertical projection at the centre of platform, the distance from EUT to measurement antenna is 1m. 3.2Test Measurement Spherical coordinate system OTA Test Report Shenzhen Fu Bang Wireless Technology Co., Ltd. This report shall not be reproduced except in full, without the written approval ofShenzhen FuBang Wireless Technology Co.,Ltd. Page4 Figure 1 Test coordinate system Note: Theta is from 0-180degree.Phi is from EUT and record the Date, the step of rotation is 15 degree. Test Setup 4. Test Results 4.1 Gain and Efficiency OTA Test Report Shenzhen Fu Bang Wireless Technology Co., Ltd. This report shall not be reproduced except in full, without the written approval ofShenzhen FuBang Wireless Technology Co.,Ltd. Page5 Model Test State Frequency (MHz) Efficiency (%) Gain (dBi) Frequency (MHz) Efficiency (%) Gain (dBi) Note Free Space 620 14.2 -6.5 1820 27.2 -0.3 630 14.5 -6.3 1840 27.7 -0.4 640 15.0 -5.9 1860 27.9 -0.3 650 15.5 -5.5 1880 29.4 -0.3 660 15.9 -5.1 1900 30.6 -0.2 670 15.4 -5.1 1920 32.3 -0.1 680 14.8 -6.1 1940 32.2 -0.5 690 14.4 -6.4 1960 33.2 -0.4 700 14.5 -6.3 1980 33.7 -0.7 710 14.7 -6.0 2000 34.3 -1.0 720 17.2 -5.2 2020 34.4 -1.3 730 18.3 -4.5 2040 32.3 -1.8 740 17.7 -4.4 2060 29.5 -1.5 750 16.9 -5.3 2080 25.6 -1.9 760 15.6 -5.5 2100 24.2 -1.9 770 14.9 -6.0 2120 23.1 -2.0 780 14.7 -6.3 2140 23.4 -1.7 790 14.4 -6.4 2160 24.0 -1.8 800 13.8 -6.6 2180 24.7 -2.0 810 15.7 -5.5 2200 24.9 -1.9 820 16.9 -5.0 2300 24.5 -1.8 830 17.8 -4.4 2320 24.3 -1.8 840 18.6 -4.2 2340 25.4 -1.6 850 19.8 -3.7 2360 26.4 -1.2 860 20.7 -3.5 2380 26.5 -1.2 870 21.8 -3.2 2400 26.0 -1.3 880 17.8 -4.0 2420 26.3 -1.6 890 20.2 -3.6 2440 26.2 -1.5 900 21.4 -2.9 2460 25.8 -1.4 910 22.0 -2.4 2480 26.3 -1.5 920 21.8 -2.6 2500 25.4 -1.6 930 20.3 -3.4 2520 25.4 -1.6 940 18.7 -3.8 2540 26.0 -1.3 950 17.3 -4.1 2560 26.3 -1.2 960 15.9 -5.4 2580 28.3 -0.9 1700 23.9 -1.5 2600 27.0 -1.0 1720 25.5 -1.1 2620 26.6 -1.0 1740 26.9 -0.9 2640 26.6 -1.1 1760 27.5 -0.8 2660 26.2 -0.9 1780 27.1 -0.9 2680 26.8 -1.2 1800 27.6 -0.7 2700 25.7 -1.4 OTA Test Report Shenzhen Fu Bang Wireless Technology Co., Ltd. This report shall not be reproduced except in full, without the written approval ofShenzhen FuBang Wireless Technology Co.,Ltd. Page6 Model Test State Frequency (MHz) Efficiency (%) Gain (dBi) Frequency (MHz) Efficiency (%) Gain (dBi) Note Free Space 3300 30.2 -0.2 3310 30.7 -0.2 3320 30.9 -0.2 3330 30.4 -0.2 3340 31.6 -0.1 3350 32.3 -0.1 3360 32.5 -0.1 3370 33.3 -0.1 3380 33.7 -0.1 3390 34.5 0.2 4000 34.4 0.2 4010 32.3 0.1 4020 31.8 -0.2 4030 31.6 -0.2 4040 31.3 -0.2 4050 33.1 -0.1 4060 33.4 -0.1 4070 34.0 -0.1 4080 34.7 -0.2 4090 34.9 -0.3 4100 34.5 -0.4 4120 34.3 -0.7 4130 35.4 -0.8 4140 36.4 -0.6 4150 36.5 -0.7 4160 34.0 -1.0 4170 33.3 -1.0 4180 32.2 -1.0 4190 31.8 -1.1 4200 30.3 -1.2 OTA Test Report Shenzhen Fu Bang Wireless Technology Co., Ltd. This report shall not be reproduced except in full, wi…

Text truncated - open the document above for the full version.

Page 1 of 27 Report No.: S24070203407007 ` FCC RADIO TEST REPORT FCC ID: 2AOWK-5010 Product： Mobile Phone Trade Mark： ulefone Model Name： GQ5010 Family Model： Armor Mini 20T Pro, Armor Mini 20 Pro, Armor Mini 20 Ultra, Armor Mini 20T Ultra Report No.： S24070203407007 Issue Date: Aug. 21, 2024 Prepared for Shenzhen Gotron Electronic CO.,LTD. 7B01, Building A, Block 1, Anhongji Tianyao Plaza, Longhua District, Shenzhen City, Guangdong Province China Prepared by Shenzhen NTEK Testing Technology Co., Ltd. 1/F, Building E, Fenda Science Park, Sanwei Community,Xixiang Street Bao’an District, Shenzhen 518126 P.R. China Tel. 400-800-6106, 0755-2320 0050, 0755-2320 0090 Website: http://www.ntek.org.cn Page 2 of 27 Report No.: S24070203407007 ` TEST RESULT CERTIFICATION Applicant’s name ................. : Shenzhen Gotron Electronic CO.,LTD. Address ................................. : 7B01, Building A, Block 1, Anhongji Tianyao Plaza, Longhua District, Shenzhen City, Guangdong Province China Manufacturer's Name .......... : Shenzhen Gotron Electronic CO.,LTD. Address ................................. : 7B01, Building A, Block 1, Anhongji Tianyao Plaza, Longhua District, Shenzhen City, Guangdong Province China Product description Product name ........................... : Mobile Phone Model and/or type reference : GQ5010 Family Model ......................... : Armor Mini 20T Pro, Armor Mini 20 Pro, Armor Mini 20 Ultra, Armor Mini 20T Ultra Test Sample number .............. : S240702034007 Standards ............................. : FCC Part15.225 Test procedure ............................... : ANSI C63.10-2013 This device described above has been tested by NTEK, and the test results show that the equipment under test (EUT) is in compliance with the FCC requirements. And it is applicable only to the tested sample identified in the report. This report shall not be reproduced except in full, without the written approval of NTEK, this document may be altered or revised by NTEK, personnel only, and shall be noted in the revision of the document. Date of Test ......................…

Text truncated - open the document above for the full version.
